COST-BENEFIT ANALYSIS FOR THE DESIGN OF PERSONAL

KNOWLEDGE MANAGEMENT SYSTEMS

Max Völkel and Andreas Abecker

FZI – Forschungszentrum Informatik Karlsruhe, Haid-und-Neu-Straße 10-14, Karlsruhe, Germany

Keywords:

Knowledge management, personal knowledge, cost-beneﬁt analysis.

Abstract:

Knowledge Management (KM) tools have become an established part of Enterprise Information Systems in

the recent years. While traditional KM initiatives typically address knowledge exchange within project teams,

communities of practice, within a whole enterprise, or even within the extended enterprise (customer knowl-

edge management, KM in the supply chain, . . . ), the relatively new area of Personal Knowledge Management

(PKM) investigates how knowledge workers can enhance their productivity by better encoding, accessing, and

reusing their personal knowledge. In this paper, we present a cost-beneﬁt analysis of PKM – where beneﬁt

comes from efﬁciently ﬁnding task-speciﬁc, useful knowledge items, and costs come from search efforts as

well as externalisation and (re-)structuring efforts for the personal knowledge base.

1 INTRODUCTION

During the last decade, Knowledge Management

(KM) has reached a consolidated status as a manage-

ment discipline and has provided manifold impress-

ing business success stories in an economic world that

becomes increasingly knowledge-based. In balanced

socio-technical solutions, which holistically combine

organizational, psychological, and IT measures, En-

terprise Information Systems often play a central, en-

abling role. Originally KM functionalities enter the

area of standard EIS solutions (e. g. groupware func-

tionalities in Microsoft Sharepoint), and, vice versa,

sophisticated KM tool suites are stepwisely further

developed towards a central Information Backbone of

the enterprise (Maier, 2004).

However, in spite of all such developments, the

most important area of knowledge creation and pro-

cessing is still the most underdeveloped area of KM:

namely that of the individual knowledge workers

personal knowledge management (PKM) (Daven-

port, 2005). In the European Integrated Research

Project NEPOMUK

, we develop methods and tools

http:\\nepomuk.semanticdesktop.org Part of this

work has been funded by the European Commission in the

context of the IST NEPOMUK IP - The Social Semantic

Desktop, FP6-027705. Part of this work has been done in

WAVES – Wissensaustausch bei der verteilten Entwicklung

von Software, funded by BMBF, Germany.

for the Semantic Desktop, an integrative infrastruc-

ture for organizing, interlinking, querying and ex-

ploiting personal information from different everyday

applications through common semantics-based meta-

data. Later on, such personally created, collected,

and managed information shall – partly – be made

available to the peer group of the end user (their

team colleagues, project partners, buddy networks,

. . . ) through peer-to-peer technology, thus fostering

an integrated community-knowledge space.

As one of the ﬁrst and most important, yet still

largely unsolved, questions arises that of appropriate

methods and tools to support (and seduce) the user to

articulate more, and more complex, parts of their ex-

pert knowledge in computer-based forms – for stor-

ing, sharing, further developing it, etc. Obviously,

the more structure the user formally represents up-

front (e. g. by indexing or tagging content, by ﬁll-

ing a given document template, by adding metadata,

etc.), the better prepared is such personal knowledge

for later efﬁcient ﬁnding again, for context-speciﬁc

reuse, or also for sharing with other users. But this

is a central KM barrier: Chronically overloaded man-

agers, technicians, and creative workers simply do not

invest time and effort in extra work to prepare for

far-off, potential KM beneﬁts. Hence, assuming that

knowledge workers act – at least to a signiﬁcant ex-

tent – rationally and economically, it is a central ques-

tion to better understand the trade-offs between actual

Völkel M. and Abecker A. (2008).

COST-BENEFIT ANALYSIS FOR THE DESIGN OF PERSONAL KNOWLEDGE MANAGEMENT SYSTEMS.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - AIDSS, pages 95-105

DOI: 10.5220/0001713200950105

 SciTePress

costs and expected beneﬁts of knowledge articulation

and of adding more structure to articulated knowl-

edge. Insights in this area are required for building

suitable Personal KM systems which will be accepted

and used by knowledge workers and which can prove

their Return-on-Investment in an enterprise setting.

Outline. We ﬁrst describe the relations between

knowledge management (KM), personal information

management (PIM), and personal knowledge man-

agement (PKM). In brief, PKM can be seen as the

KM perspective on PIM or the personal perspective

on KM. Then we look from a high-level on costs and

beneﬁts in PKM. We develop a uniﬁed knowledge

model (UKM) and explain how it can represent doc-

uments and ontologies in a uniﬁed way. Using the

UKM, we reﬁne the cost model and explain general

cost drivers and beneﬁts of PKM. Finally we apply

the resulting formula as an example to the possible

extend on a semantic wiki.

1.1 Knowledge Management

Drucker (1985) was among the ﬁrst to use the term

knowledge worker when stating

The most important contribution of manage-

ment in the 20th century was to increase man-

ual worker productivity ﬁfty-fold. The most

important contribution of management in the

21st century will be to increase knowledge

worker productivity – hopefully by the same

percentage. [...] The methods, however, are

totally different from those that increased the

productivity of manual workers.

At times when knowledge management was be-

coming popular, Nonaka and Takeuchi (1995) pub-

lished a book on knowledge processes which de-

scribes two basic states of knowledge: tacit (implicit)

and external. Later works (Despres and Chauvel,

2000) conclude that external and internal knowledge

are two extremes on a spectrum, but do not exist in

reality. Maurer (1999) states that knowledge resides

in the heads of people and the computer can only

store "computerized knowledge" which is to be un-

derstood as “shadow knowledge”, a “weakish image”

of the real knowledge. The high-level processes in

knowledge management are externalisation, internal-

isation, combination and socialisation (Nonaka and

Takeuchi, 1995). North (2007) deﬁnes knowledge

work as “work based on knowledge with an immate-

rial result; value creation is based on processing, gen-

erating and communicating knowledge.

”

translation by the author

1.2 Personal Knowledge Management

The knowledge-based organisation is no more effec-

tive than the sum of its knowledge workers’ effec-

tiveness (Davenport, 2005). Knowledge can be em-

brained (conceptual, implicit), embodied (tacit, im-

plicit), encultured (shared beliefs), embedded (in pro-

cesses) or encoded (symbolic, external) (Blackler,

1995).

We use the term personal knowledge management

(PKM) to denote the process of the individual to man-

age knowledge. In contrast to general knowledge

management, PKM denotes the perspective of the in-

dividual. This perspective is potentially better suited

to explain individual motivations and behaviour, even

in organisational contexts.

The term personal knowledge has already been

used in (Polanyi, 1958), the term PKM appears

in (Frand and Hixon, 1999; Mitchell, 2005). The

ﬁelds “ePortfolio” and “personal learning environ-

ment” deal with similar topics.

Higgison (2005) deﬁnes personal knowledge

management as “managing and supporting personal

knowledge and information so that it is accessible,

meaningful and valuable to the individual; maintain-

ing networks, contacts and communities; making life

easier and more enjoyable; and exploiting personal

capital”.

Organizing information is a central part of the

inquiry process focused on making the con-

nections necessary to link pieces of informa-

tion. Techniques for organizing information

help the inquirer to overcome some of the lim-

itations of the human information processing

system. In some ways the key challenge in

organizing information is for the inquirer to

make the information his or her own through

the use of ordering and connecting principles

that relate new information to old information.

. . . (Avery et al., 2001)

The related topic of Personal information manage-

ment (PIM) got academic attention around 2005

when the ﬁrst PIM workshop was held. The report

of the second workshop (Jones and Bruce, 2005) de-

ﬁnes the term Personal Space Of Information (PSI)

as the space that “ includes all the information items

that are, at least nominally, under that person’s control

(but not necessarily exclusively so).” This includes a

number of analog and digital storage locations.

There is no sharp distinction between PIM and

PKM, rather a difference of scope and perspective.

PIM focuses on managing all the information around

an individual, i. e. only encoded knowledge. PKM

deals with embrained, embodied and encoded knowl-

ICEIS 2008 - International Conference on Enterprise Information Systems

edge, i. e. mostly with personal, self-authored arte-

facts. This paper tackles the continuum between em-

brained and encoded knowledge, with regards to costs

and beneﬁts.

Jones et al. (2001) introduces the problem of

“keeping found things found” which reports on the

difference between knowing something and merely

storing information. E. g. obviously an unread email

can be managed in the sense of information manage-

ment, but the knowledge one can get from the email

has not yet been realised.

The basic processes in PIM are (Jones and Bruce,

2005): 1. keeping (input of information into a PSI);

2. ﬁnding/re-ﬁnding (output of information from a

PSI); and 3. meta-activities like mapping between in-

formation and need, maintenance and organisation .

The role of handling an external memory is apparent.

In the next section we analyse costs associated to each

phase. Note that the basic processes are the same for

PIM and PKM, the difference is the perspective. PKM

emphasises information from the users mind encoded

by the user himself. PIM has a broader focus. PKM

focuses on the knowledge in the users mind evoked

by a piece of information presented by the system.

Many real-world notes seem to fall between em-

brained and encoded (Blackler, 1995) or between im-

plicit and external (Nonaka and Takeuchi, 1995). E. g.

a personal note with the content “milk” is not really

an external, encoded representation of the knowledge

“I need to buy some milk today”. On the other hand,

without the note, the action to buy milk might not hap-

pen. Different audiences and topics require different

degrees of explicitness (Boettger, 2005).

Deﬁnition. A knowledge cue is an artifact which

evokes (acts as a cue to) some kind of knowledge

in the readers mind. I. e. knowledge is either re-

activated by consuming the artifact representing the

knowledge cue or new knowledge is obtained by con-

suming the information, e. g. when reading a book.

The reader and author of a knowledge cue are the

same person; other persons might not be able to gain

knowledge from using the artifact representing the

knowledge cue.

It is not possible to deﬁne precisely the amount

of knowledge contained in one knowledge cue.

Roughly, one knowledge cue evokes one concept or

family of related concepts. As an example, a shop-

ping list consisting of n items contains n knowledge

cues. A description of a single business innovation

could be treated as one cue. Bernstein et al. (2007)

uses the term “information scrap” to denote one or

several knowledge cues. On aspect of PKM is efﬁ-

cient and effective management of knowledge cues.

Use

Benefit of use (B)

Creation

Cost of Creation (C

)

Figure 1: A Simpliﬁed Model for Cost/Beneﬁt-Analysis in

PKM without external memory stores.

2 COSTS AND BENEFITS IN PKM

We need to think in terms of investment, allocation of

costs and beneﬁts between the organizer and retriever

(Glushko, 2006)[p. 24-31]. In PKM, organizer and

retriever are the same person. Different from an or-

ganisational context, there is a personal motivation to

organize knowledge.

Jones and Bruce (2005) reports on difﬁculties of

evaluating PIM systems, as almost no person is will-

ing to try out an experimental, potential unstable PIM

system for a long period of time (months or years) for

critical personal tasks such as remembering appoint-

ments, managing email or keeping personal notes.

The analysis in this paper can help to evaluate sys-

tems used for PKM, e. g. also PIM systems.

This section analyses costs and beneﬁts of an in-

dividual doing PKM from the perspective of a neutral

observer. First we describe the PKM process without

external storage and then extend this model.

2.1 Knowledge Creation and Use

If no external tools are used, the PKM process

(c. f. Fig. 1) consists of

• Knowledge creation at a cost C

and

• Knowledge use with a beneﬁt B.

The cost of knowledge creation C

is the amount of

time, money and effort an individual spends on think-

ing, researching, experimenting, and learning. Cost

can maybe best be measured by the amount of time

spend – but how to measure the value? Maybe the

time needed to re-create the knowledge? But if it

takes long to re-create some knowledge that has a low

beneﬁt, then one would intuitively not assign a high

value to it. Also knowledge might be cheap to create

and store now but much more costly to re-create later,

e.g. Where have I been on a given day in 1999?

The value of knowledge does not exist as such

(Iske and Boekhoff, 2002); it depends highly on the

COST-BENEFIT ANALYSIS FOR THE DESIGN OF PERSONAL KNOWLEDGE MANAGEMENT SYSTEMS

Use

Later …

Personal

Information

Space

Externalisation

(authoring,

structuring)

Personal

Information

Space

Retrieval

Cost of Externalisation (C

) Cost of Retrieval (C

) Benefit of use (B)

Creation

Cost of Creation (C

)

Figure 2: A Simpliﬁed Model for Cost/Beneﬁt-Analysis in PKM. Goal: more beneﬁt than costs (B > C

task. The value of some knowledge can be deﬁned

as “increment in expected utility resulting from an

improved choice” made possible by this knowledge

(Varian, 1999). I. e. one estimates the value of the

state of the world that would result from actions per-

formed in absence of the knowledge (V

) and com-

pares it with the value of the state of the world result-

ing from actions taking in presence of the knowledge

). Then the beneﬁt B of having this knowledge for

this task is the difference in value, i. e. B = V

−V

. B

then represents the additional created value or saved

costs. B can (in theory) be measured in money, saved

time, improved quality or better emotions. In practice,

measuring the value of the state of the world is often

hard to quantify, i. e. consider long-term effects and

the difﬁculty to measure quality of better emotions.

Most approaches resort to measure only costs (Feld-

man et al., 2005). Economists use an abstract “utility

value” without deﬁning a unit of measurement.

For comparing different PKM systems one needs

a pragmatic way to take the beneﬁt into account. We

believe in PKM, the value of a certain piece of knowl-

edge with respect to a task can be estimated by indi-

viduals on a Likert scale (Likert, 1932). The added

value of using a knowledge management system for

a given period of time (t) is the overall cost-beneﬁt

gain G which can be approximated by summing up

all beneﬁts B and subtracting the sum of all costs C

(G = B − C). For a given amount of knowledge one

can compare the costs of different PKM systems.

2.2 Using External Storage

In this section we extend the simple model introduced

in Sec. 2.1 with an external storage system. The pro-

cess of managing knowledge cues can be represented

as (c. f. Fig. 2):

1. Creation: Knowledge is created at some costs C

2. Externalisation: Some parts of the implicit knowl-

edge become external. Knowledge cues are cre-

ated. These user has externalisation costs C

3. Time passes by and the author might start to for-

get some or all details of the articulated knowl-

edge. Sometimes even the knowledge to know

something is forgotten as well.

4. Retrieval: At a certain moment, while perform-

ing a certain task, the user initiates a retrieval pro-

cess in his PKM system. As information retrieval

system have become faster, the classic informa-

tion retrieval measure of “time to execute query”

becomes less relevant to determine the costs per-

ceived by the user. The human-computer interac-

tion becomes more often the bottleneck and cost-

driver of efﬁcient knowledge work.

After having executed a query or performed a

browsing step, the user reads the search results,

and reﬁnes the search query. After some steps, the

user either found one or several matching knowl-

edge cues or cancels the search with no result. The

process of reading through a list of search results

takes time and therefore adds to the search costs.

If a knowledge artifact is long in size, the time to

read through it takes longer. If the desired knowl-

edge is only a part of the artifact, reading through

the artifact is thus additional search cost. All these

costs are subsumed under retrieval costs C

5. Usage: If results where found, the user has some

beneﬁt from having available the external knowl-

edge or from remembering knowledge from the

knowledge cue.

Esser (1998) analyses factors that determine when

and which external memory humans use. Three vari-

ables were observed: Expected likelihood of success-

ful remembering a piece of knowledge when stored

in an external store, cost of storing it there and most

importantly: perceived value of the knowledge to be

stored. The higher the perceived importance of re-

membering the knowledge, the higher costs for stor-

age were accepted.

The basic hopes of each person doing PKM should

be:

ICEIS 2008 - International Conference on Enterprise Information Systems

Zone of lo

est

total

costs (C

+ C

)

Figure 3: Assumed relation between externalisation costs

) and retrieval costs (C

• There is more beneﬁt of having the knowledge

(again) than it had cost to manage it, i. e. C

< B

• Managing knowledge externally is cheaper than

re-creating it from scratch, i. e. C

< C

Estimating the beneﬁt of storing an item for later use

+ C

)) compared with the expected costs to re-

generate the contained knowledge later (C

) is cer-

tainly hard. An assumption underlying this paper is

that better organisation, structuring, and formalisation

of content is expected to lower the costs of retrieval

(Glushko, 2006).

2.3 Knowledge Representation

For a long time in history, knowledge cues were only

stored in documents, ﬁrst analog then digital. Digital

document retrieval is the prime application domain of

information retrieval (IR) techniques. The ﬁeld of IR

has a history of quantitative research, mostly focusing

on precision and recall. These measures were ﬁrst de-

ﬁned in Cleverdon et al. (1966). However, Cleverdon

et al. (1966) proposed to measure not only these two

factors but also “the extent to which the system in-

cludes relevant matter”, and “the effort involved on

the part of the user in obtaining answers to his search

requests”. Maybe because these two factors cannot so

easily be measured automatically, they were mostly

ignored by IR research.

The TREC conferences have heavily inﬂuenced

IR research. In the last ten years it ran the novelty

track, in which each sentence of a document was re-

garded as an information item on its own. The ques-

tion answering track goes in a similar direction, here

the user is not querying for a set of documents but for

a concise, factual answer to his question. Both tracks

show a tendency towards smaller content granularity.

A fact given within a document requires on average to

read half of the document until the fact is found. The

granularity of information thus inﬂuences its retrieval

costs. The coarse granularity of documents leads to

high costs for locating relevant parts of documents,

e. g. for re-use, aggregate queries, or question answer-

ing. The extreme case of a document is a mere list of

sentences, devoid any further structure.

Data bases and ontologies allow for more struc-

tured access, i. e. browsing and searching. In contrast

to documents, data bases and ontologies allow to re-

trieve sets of items together with relevant properties.

Ontologies (and some database systems as well) al-

low to answer queries to which the answer has only

implicitly been entered. It requires effort to structure

and formalise knowledge to make it ﬁt into a database

or ontology, but retrieval abilities are also higher –

ontologies are built for re-using knowledge.

Taken to its extreme, one could try to formalise all

personal knowledge, leading to exorbitant externali-

sation costs and very low retrieval costs. In reality,

one can expect a “sweet cost spot” for the total costs

(C = C

+ C

) as depicted in Fig. 3. For efﬁcient

knowledge work, a user should be able to work close

to the sweet spot, using something half document and

half ontology.

3 UNIFIED KNOWLEDGE

MODEL (UKM)

In this section we present a uniﬁed knowledge model

(UKM). It is uniﬁed in the sense that it can repre-

sent a range of existing knowledge formalisms such

as documents and formal ontologies. The UKM is

also uniﬁed in the sense that it represents both textual

content and relations among content items. These re-

lations can be formal or informal. The term knowl-

edge model is used instead of ontology to emphasize

a large amount of stored textual content.

There is a basic tradeoff between acquirability of

a knowledge representation language and it expres-

sive power (Gruber, 1989). The purpose of the uniﬁed

knowledge model (UKM) is to analyse costs in PKM

processes, not to be used by end-users for their PKM.

A slightly modiﬁed version of the UKM is used for

PKM. This version is called Semantic Web Content

Model (SWCM) (Völkel, 2007). The main difference

between SWCM and UKM is that SWCM allows dif-

ferent sizes of items whereas UKM has a maximal

item content size of one sentence. SWCM has also

more features which make it more usable for PKM.

To be able to model both documents, semantic

nets and the continuum between these two models,

the UKM must take into account different “degrees of

formality”, a notion introduced by Lethbridge (1991)

Granularity is an important cost driver (c. f.

Sec. 2.2). The smallest units of content that make

Lethbridge uses a kind of semantic net with concept

and relation subsumption hierarchies.

COST-BENEFIT ANALYSIS FOR THE DESIGN OF PERSONAL KNOWLEDGE MANAGEMENT SYSTEMS

sense to a human are single or multiple words (encod-

ing concepts) or sentences (encoding facts or ques-

tions). The UKM must also be able to represent for-

mal statements. Given these two constraints, we de-

ﬁne:

Deﬁnition. A knowledge item is the smallest unit

of content in the UKM. A knowledge item is either

• a snippet of content which can contain something

between a single word up to a sentence, or

• a knowledge item is a statement between other

knowledge items. A formal statement is mod-

elled similar to a semantic net or the RDF stan-

dard (Klyne and Carroll, 2004) as a triple of

three items, the middle item playing the role of

the relationship type. Representing statements

as knowledge items themselves allows full meta-

modelling.

A knowledge item is a technical counterpart of a

knowledge cue. Knowledge cues can also be persisted

in other forms, e. g. in real-world objects such as a

knot in the handkerchief.

For cost analysis we need to formalise the UKM.

A knowledge model K is deﬁned as a set of nodes N

and arcs A, i. e. K := {N, A,C, f , S}, where the arcs

are deﬁned as A := {N × N × N}. We use items as

relations to allow the user to extend the vocabulary

and to represent arbitrary knowledge. A function f

can assign each node a piece of content from the set

C of all content: f : N 7→ C. A content snippet c is

a simple linear stream of symbols (S) devoid further

machine processable structure. We ignore aspects of

natural language processing as we care about measur-

ing explicitly structured knowledge. All structural as-

pects of a document or other representation format are

expressed as relations between content items c ∈ C.

Modelling the symbols explicitly allows to formalise

the ability of the computer to map search queries via

bag-of-word, vector space, or other IR-models to the

content.

In the next two subsections we analyse how UKM

can represent existing knowledge representation for-

mats.

3.1 Documents

Most importantly, we analyse documents, which have

been used for several thousand years now. How to

model the structure and content of documents?

A French team of over 50 researchers analysed

the term document in depth (Pédauque, 2003) and

gives three co-existing deﬁnitions of the term "doc-

ument": (i) Document as form, where a document

is seen mostly as a container, which assembles and

structures the content to make it easier for the reader

to understand it. (ii) Document as sign, which em-

phasizes the argumentative structure of the content.

Also, a document that can be referenced acts as a sign

for its meaning. (iii) Document as medium, concen-

trates on the "reading contract", that is the intention

or assumption of the author what will happen with the

document.

A document contains a number of knowledge

items (c. f. Sec. 3). This act of “packaging” together

a set of knowledge items inﬂuences the interpretation

of each item by the reader. A document is a knowl-

edge artefact consisting of several layers. Aspects of

information in a document are:

Reference-ability. Once a document is published,

the reference can act as a placeholder for the con-

tent expressed within. A reference to a document

can act as a meta-symbol on top of the knowl-

edge items the document contains. The usage of

document references as symbols allows a docu-

ment to “participate” in conversations, which lead

to scholastic methods and modern academia. To

represent a document in UKM, we use one knowl-

edge item to represent the root of the document

and store the title as the content of it.

Process Metadata. Each document is written by a

number of authors for a certain audience with a

certain goal. By sending this process metadata

along with the document the reader has the ability

to put the document in context and interpret it bet-

ter. Such metadata is used by the reader as a frame

of reference for interpretation and for search. In

UKM it is modelled as additional items linked to

the document root, similar to the way how RDF is

used.

Linearity. A document can typically be read from

start to end by navigating through all contained

knowledge items. This is modelled via an hasNext

relation between the items holding the document

sentences.

Visual Structure. A document is not only a stream

of sentences, but uses type-setting, i.e. bold, ital-

ics, different font styles and size, and placement

of ﬁgures. For sake of simplicity, we ignore these

properties in the UKM.

Logical Structure. The visual structure is used to

encode a logical structure consisting of i.e. para-

graphs, headlines, footnotes, citations, and title.

The logical structure makes it possible to refer-

ence smaller, meaningful parts within a document,

i.e. "Sec. 4.2". Following the approach of Groza

et al. (2007), we model a document structurally as

a tree consisting of root, sections nested into each

ICEIS 2008 - International Conference on Enterprise Information Systems

100

other, paragraph and sentence. Sections can also

contains ﬁgures and tables, which are not further

modularised. In our cost model we introduce a re-

lation hasPart which is used to model the different

kinds of containment. To distinguish the different

types of structural unit we use a relation hasType

and a number of type-items, e. g. section, para-

graph, etc.

Argumentative Structure. On top of the linear con-

tent, a document follows an argumentative struc-

ture to convey its content to the reader. Argu-

mentative structures appear on all scales. A typ-

ical structure is the "Introduction - Related work

- Contribution - Conclusion"-pattern of scientiﬁc

articles. On smaller scales, patterns like "claim-

proof" and "question-answer" are used. Groza

et al. (2007) also describes ways to encode argu-

mentative structures.

Content Semantics. Documents content’s mean

something. Building upon logical and argumen-

tative structure, the author encodes statements

about a domain within the content. We allow to

store semantic statements in the UKM.

3.2 Ontologies

How to encode ontologies in UKM? A mapping from

RDF to UKM is pretty straightforward. Each triple in

RDF consists of URIs (U), blank nodes (B) and lit-

erals (L) and is of the form (U, B) × (U) × (U, B, L).

First we replace all literals with nodes and assign the

literals content as node content, f (n) =literal. Next

we replace all URIs and blank nodes with nodes, us-

ing the same nodes where the same URI or same blank

nodes is denoted. Now each triple is converted to the

form N × N × N and can be stored in UKM. Subtleties

such as language tags and data-types of literals can be

stored as further statements in UKM, so there is no

information loss.

We expect future PKM systems to allow mod-

elling textual and semantic content in the same en-

vironment, as described in (Bettoni et al., 1998; Lud-

wig, 2005; Oren et al., 2006)

4 A COST-MODEL FOR PKM

In this section we use the UKM to measure the ex-

ternalisation and retrieval costs in PKM system. We

have the following basic factors for costs and beneﬁts:

• Each knowledge cue x that is externalised has ex-

ternalisation costs C

(x). We detail these costs in

the next section.

• For each task t ∈ T, the user has the option to

search for knowledge cues. This has retrieval

costs C

(t). Note that a user might retrieve an

item several times or not at all.

• Retrieved items have a beneﬁt B(t) for the given

task t.

The overall process has thus the following gain:

G =

∑

B(t) − (

∑

(x) +

∑

(t))

∑

(B(t) −C

(t)) −

∑

(x)

4.1 Externalisation Costs

can be divided into cost of authoring the content

) and costs of (re-)structuring existing knowledge,

classifying new or existing items or linking between

items (C

). Linking items can also be an act of for-

malisation if the relation is speciﬁed with a relation

that has a formal semantics. Hence C

= C

Let N be the set of all knowledge cues in the sys-

tem. Cost of content externalisation is correlated to

the size of externalised artefacts. E. g. writing more

words takes more time. Let | n

| be the size of the

jth item, measured in the number of symbols it con-

tains (c. f. UKM). Articulating a single symbol costs

. Articulating the jth item costs | n

| c

. Then

∑

The structuring costs C

will often involve more

then one item, e. g. when linking two items. Structur-

ing is the process of linking, tagging, typing and cate-

gorising items. The cost of restructuring are indepen-

dent of the items size. The more items a knowledge

base contains, the more effort it might take to ﬁnd

the right element to link another item to. Structuring

is expected to make more of the knowledge accessi-

ble to the computer, which should enable to answer

queries with better (more) results. Note: The structure

of a knowledge models contains itself knowledge. It

is not possible to specify the structuring costs per se,

but we can expect the degree of formality of a knowl-

edge model to correlate with the structuring costs

spend. The degree of formality d

can be measured

by the amount of formal statements (|A|)compared to

the number of knowledge items, similar to the deﬁni-

tions given in (Lethbridge, 1998) as d

|A|

|N|

. If we

further assume a ﬁxed cost c

for articulating a for-

mal statement, we can estimate C

= |A|c

. We get

the total externalisation costs

= C

∑

+ |A|c

(1)

This equation assumes that no content and no for-

mal statement is ever deleted or changed. But in re-

ality, the cues need to be maintained to keep or im-

prove their value over time. E. g. some knowledge is

COST-BENEFIT ANALYSIS FOR THE DESIGN OF PERSONAL KNOWLEDGE MANAGEMENT SYSTEMS

101

no longer applicable or needs to be updated to reﬂect

changes in the world. Informal ideas undergo sev-

eral transitions until some of them might become text

books (Maier and Schmidt, 2007).

Some structuring operations could as a side ef-

fect increase (split) or decrease (merge) the number

of cues. We ignore changes to the number of cues

for sake of simplicity. Deleting outdated or erro-

neous knowledge could improve the value of using

the knowledge model quite a lot, but some costs do

occur for these maintenance tasks, too. Therefore in-

stead of measuring the knowledge model as such, we

measure the costs of the operations that lead to the

current state, i. e. all operations performed.

Let c be a function that assigns each operation

some costs. Basic operations on a model are:

add content (content

) Adding m symbols to a

knowledge cue costs m × c(c

) with c

being the

costs of adding one symbol.

delete content (content

) Deleting m symbols from

a knowledge cue costs m × c

with c

being the

cost of deleting a symbol. Deleting has often

lower cost than adding, e. g. when deleting a com-

plete item in the user interface which causes dele-

tion of many symbols.

Cost of updating can be modelled as the sum of

deletion costs and addition costs.

add formal statement (stmt

) Adding a formal

statement. The cognitive costs (measured in time

and ultimately money) should vary according

to the severity of the formal statement. E. g. it

should take less time to create a hasPart or hasIn-

stance relation than a hasSubclass statement.

These differences will be taken into account in

future versions of the cost model.

delete formal statement (stmt

) Deleting a single

statement could have dramatic effects, depending

on the used inference rules.

We take the restructuring operations into account and

deﬁne n(content

) as the total number of added sym-

bols – and respectively n(content

) as the number of

deleted symbols. Let τ be the total costs of an opera-

tion, calculated by multiplying the number the opera-

tion is performed with the costs of the operation, i. e.

= n

. We can reformulate the externalisation

costs as

= τ

content

+ τ

content

+ τ

stmt

+ τ

stmt

4.2 Retrieval Costs

In order to precise the relation of structures in the

knowledge base and search costs one ﬁrst needs to

develop a uniﬁed model for the search process, which

does not exist yet. A ﬁrst work in this direction is

the “information foraging process” (Pirolli and Card,

1995). There are three basic ways to retrieve infor-

mation when interacting with an information system

(Bates, 2002):

Browsing a collection of items related to the infor-

mation need. In principle, two kinds of collec-

tions are possible: explicit, i. e. created by a user,

and implicit, i. e. the members in the set are deter-

mined by a (semantic) query. Toms (2000) and

Teevan et al. (2004) emphasise the importance

of ﬁnding information “by accident”, e. g. when

searching for something else. Such (re-)ﬁndings

are important for creative processes and knowl-

edge creation.

Formally, browsing is the act of scanning a list of

items and evaluating each of them for relevance.

Evaluating a single item has the costs e. The user

is free to stop evaluating items from the list at any

time.

Searching denotes the process of executing a query

(e. g. keywords) and reﬁning it until the top re-

sults are relevant to the information need. Seman-

tic queries, utilising knowledge indirectly for in-

ferencing, also ﬁt into this category.

Formulating a query has the costs q. Systems that

allow several kinds of queries need different val-

ues for q to model the difference in cost. After

each search-step the user is confronted with a list

of search results which need to be evaluated, sim-

ilar to browsing.

The search costs depend on the complexity of the

query and the structure of the knowledge base. A

complex query has a higher cost to be formulated,

but has the ability to return exactly the required

cue. Simpler queries return usually too many re-

sults and need reﬁnement. From a users perspec-

tive, starting with simpler queries that are gradu-

ally reﬁned is more economic than asking directly

a complex query. The interactive reﬁnement pro-

cess gives earlier feedback about how many re-

sults are returned, which guides query reﬁnement

until the query is complex enough to ﬁlter out the

desired cues. This way, queries do not become

more complex than needed.

Following links should not be confused with brows-

ing. A common practice in large search spaces for

which neither suitable collections nor query terms

are known is to explore e. g. citation links. Fol-

lowing links is thus a kind of associative retrieval.

Following a link has the costs l.

ICEIS 2008 - International Conference on Enterprise Information Systems

102

A complete search process involves typically all three

kinds of operations. Instead of measuring each step,

we model the complete retrieval process as a process

that involves some costs C

(t). These costs can be

broken down to C

(t) for formulating queries and fol-

lowing links and costs for evaluating items.

Assuming the user evaluates k(t) items in the re-

trieval process, we can deﬁne task-speciﬁc precision

and recall r

(Van Rijsbergen, 1979). As a reﬁne-

ment of this idea, an relevant item has a certain bene-

ﬁt for the given task (in range 0 . . . 1). We deﬁne the

beneﬁt of an item j for a given task t to be v

(t). For

irrelevant items, v

(t) is zero.

Let k(t) be the total number of all retrieved items

in the search process. There is a certain cost e to

evaluate each item in order to be able to decide if the

knowledge represented in the item is relevant for the

task. We assume the effort of evaluating a single item

is not correlated to precision and recall of the com-

plete process. The complete costs of the retrieval pro-

cess for task t are then C

(t) = C

(t) + k(t)e.

Only retrieved knowledge cues can bring beneﬁt

for the user. Knowledge that is never used is of zero

value. The complete beneﬁt B(t) of the k(t) retrieved

items is B(t) =

∑

(t). Both p

or k(t) might also

be zero. Assuming all retrieved items in a task are

either relevant (value = 1) or not, we can simplify the

formula as B(t) = p

k(t).

For each retrieval process we get:

B(t) −C

(t)

= p

k(t) −C

(t) + k(t)e

= k(t)(p

− e)−C

(t)

Thus the query formulation costs are a kind of ﬁxed

costs, whereas the relation between precision and

evaluation costs decides if the whole retrieval process

was worth the hassle. Interestingly, higher recall val-

ues seem in the light of cost-beneﬁt analysis less rele-

vant than high precision values. Precision in retrieval

values is typically heavily dependent on the degree of

structuredness and formality of the data.

If we analyse the equation, we see three factors

than can negatively inﬂuence the gain of using a PKM

system:

1. If the user does not try to retrieve knowledge for a

task t;

2. if no or too few relevant items are retrieved, i. e. if

the precision too low;

3. if the value of the successfully retrieved items is

too low, i. e. results ﬁt, but of too low value.

Factor (1) is addressed by (Cutrell et al., 2006) which

proposes to automatically start a search when certain

triggers are encountered. Factor (2) is addressed by

works in knowledge articulation and modelling, in-

formation retrieval and improved search algorithms.

Factor (3) can maybe only be addressed by personal

experience or training.

4.3 The Complete Cost Function

Stitching the parts together we get:

G =

∑

(B(t) −C

(t)) −

∑

(x)

∑

k(t)(p

− e)−C

(t)

− τ

content

− τ

content

− τ

stmt

− τ

stmt

As we see one of the most important cost drivers is

the question how well the costs spend on externalisa-

tion and query formulation can improve the precision

of the retrieved items. Note that most works address

improvements of precision only by looking at the data

as “given”. In PKM, this is not true, as the knowledge

items are authored and retrieved by the same audi-

ence.

5 APPLYING THE COST MODEL

TO SEMANTIC WIKIS

As an example, we apply the cost model (i. e. Sec.

4.1) to a semantic wiki, in this case to Semantic Me-

diaWiki (SMW) (Krötzsch et al., 2006). First we need

to represent the data model of SMW in terms of the

UKM. Each wiki page in SMW can be regarded as a

knowledge item. SMW has two types of formal state-

ments: Type (a) links a page to another page; type

(b) links a page to a value stored within that page.

We model type (a) as a formal statement in the UKM.

Type (b) links can be represented as a link from the

page to a knowledge item which contains that data

value. For structuring, SMW allows to create seman-

tic links or put wiki pages into categories. Categories

can be modelled as knowledge items containing only

their name and being linked to each category member.

Addition and deletion of category links and semantic

links can be measured as stmt

and stmt

Note: As SMW uses MediaWikis versioning his-

tory, one could in theory calculate all modelling op-

erations that ever happened. The time to externalise

knowledge as text or wiki links could be measured. In

the future, we consider to perform this kind of eval-

uation on existing public instances of SMW. Via ad-

ditional usage logs one could determine the average

time e. g. it takes to pose a query.

Although there has been until today no study on

personal wiki use, many of our colleagues do use se-

mantic wikis and in particular SMW as their PKM

tool. SMW allows all three basic kinds of retrieval:

COST-BENEFIT ANALYSIS FOR THE DESIGN OF PERSONAL KNOWLEDGE MANAGEMENT SYSTEMS

103

browsing, searching and following links. A user can

browse e. g. all pages in a category, or all members of

a list generated by an a semantic query embedded in a

page. For search the user can either perform standard

keyword search or pose semantic queries to the sys-

tem. The ability to follow links is obvious in a wiki.

These properties make SMW an ideal study ob-

ject for PKM, as it uses almost all imaginable ways to

state and retrieve knowledge – only statements about

statements are not possible in SMW.

6 RELATED WORK

There has not been much work on estimating cost and

beneﬁts in PKM.

A related work done by Bontas et al. (2006) in

the area of ontology engineering does not ﬁt our use

case as the use of a personal knowledge model is not

a linear, planned process with the goal of creating a

formal representation. Rather the contrary is true: An

individual is always reluctant to formalise anything,

because its unclear if the extra effort will ever pay off.

(Lethbridge, 1998) shows metrics for concept-

oriented knowledge bases, but does not take costs into

account.

7 CONCLUSIONS AND

OUTLOOK

This paper makes a ﬁrst attempt to understand the

complete PKM process in order to help design bet-

ter PKM tools. The overall beneﬁt of using a PKM

system could be characterised by summarizing over

the successfully retrieved knowledge items (content

or formal statements) for each task. Costs could be

characterised as the sum of the costs of all authoring

and structuring efforts. A quantiﬁcation of the effect

more structuring has on lower retrieval costs (or im-

proved beneﬁt) cannot be stated unless the semantics

of the formal statements and details of the search pro-

cess (browse, search, follow links) are speciﬁed. Thus

the resulting formulas can serve only as a conceptual

framework or starting point for tool-speciﬁc measure-

ments.

7.1 Future Work

As future work we intend to develop automatic mea-

sures of the information content of a knowledge

model, by counting the size and used symbols (here:

words) of each knowledge item as well as the num-

ber and kind of semantic links. We have to take the

semantics of the knowledge model into account, as

some formal statements have a much higher inﬂu-

ence than others, c. f. ontology evaluation (Vrandecic,

2006). SMW offers only a transitive category hierar-

chy, hence the transitive closure can be calculated and

taken into account. Counting the number and kind

of modelling steps used in the history of a semantic

wiki is also planned. To estimate value v

, precision

, search costs c

and number of returned items k

search processes, we intend to perform a diary study.

Another important aspect of future research is an

investigation in which way investments in structuring

) can lower the cost of retrieval (C

), e. g. by im-

proving p

or k

REFERENCES

Avery, S., Brooks, R., Brown, J., Dorsey, P., and O’Conner,

M. (2001). Personal knowledge management: Frame-

work for integration and partnerships. In Proc. of AS-

CUE Conf.

Bates, M. (2002). Speculations on browsing, directed

searching, and linking in relation to the bradford distribu-

tion. In Emerging frameworks and methods: Proceedings

of the Fourth International Conference on Conceptions of

Library and Information Science (CoLIS 4), pages 137–

150, Greenwood Village, CO. Libraries Unlimited.

Bernstein, M. S., Kleek, M. V., mc schraefel, and Karger,

D. R. (2007). Management of personal information

scraps. In Rosson, M. B. and Gilmore, D. J., editors,

CHI Extended Abstracts, pages 2285–2290. ACM.

Bettoni, M. C., Ottiger, R., Todesco, R., and Zwimpfer, K.

(1998). Knowport: A personal knowledge portfolio tool.

In Reimer, U., editor, PAKM, volume 13 of CEUR Work-

shop Proceedings. CEUR-WS.org.

Blackler, F. (1995). Knowledge, knowledge work and orga-

nizations: An overview and interpretation. Organization

Studies, 16(6):1021–1046.

Boettger, M. (2005). Pkm and “cues to knowledge”. Tech-

nical report, 25Uhr.de.

Bontas, E. P., Tempich, C., and Sure, Y. (2006). Ontocom:

A cost estimation model for ontology engineering. In

Cruz, I. et al., editors, Proceedings of the 5th Interna-

tional Semantic Web Conference (ISWC 2006), volume

4273 of Lecture Notes in Computer Science (LNCS),

pages 625–639. Springer-Verlag Berlin Heidelberg.

Cleverdon, C. W., Mills, L., and Keen, M. (1966). Factors

determining the performance of indexing systems. Tech-

nical report, ASLIB Cranﬁeld Research Project, Cran-

ﬁeld.

Cutrell, E., Dumais, S. T., and Teevan, J. (2006). Searching

to eliminate personal information management. Com-

mun. ACM, 49(1):58–64.

Davenport, T. H. (2005). Thinking for a Living: How to

Get Better Performances And Results from Knowledge

Workers. Harvard Business School Press.

ICEIS 2008 - International Conference on Enterprise Information Systems

104

Despres, C. and Chauvel, D. (2000). Knowledge Hori-

zons: the present and promise of Knowledge Manage-

ment. Butterworth-Heinemann.

Drucker, P. F. (1985). Management: Tasks, responsibilities,

practices (Harper & Row management library). Harper

& Row.

Esser, K. B. (1998). Ein Modell zur Verknüpfung des per-

sönlichen Gedächtnisses mit externen Informationsspe-

ichern. PhD thesis, Freie Universität Berlin.

Feldman, S., Duhl, J., Marobella, J. R., and Crawford, A.

(2005). The hidden costs of information work. Technical

report, IDC.

Frand, J. and Hixon, C. (1999). Personal knowledge man-

agement : Who, what, why, when, where, how? Speech.

working paper.

Glushko, R. (2006). 3. information organization and,or,vs

search. Lecture Note.

Groza, T., Handschuh, S., Möller, K., and Decker, S.

(2007). Salt - semantically annotated latex for scientiﬁc

publications. In Franconi, E., Kifer, M., and May, W.,

editors, ESWC, volume 4519 of Lecture Notes in Com-

puter Science, pages 518–532. Springer.

Gruber, T. R. (1989). The acquisition of strategic knowl-

edge. Academic Press Professional, Inc., San Diego, CA,

USA.

Higgison, S. (2005). Your say: Personal knowledge man-

agement. Insight Knowledge, 7(7).

Iske, P. and Boekhoff, T. (2002). The value of knowledge

doesn’t exist. In Karagiannis, D. and Reimer, U., edi-

tors, PAKM, volume 2569 of Lecture Notes in Computer

Science, pages 632–638. Springer.

Jones, W. and Bruce, H. (2005). A report on the nsf-

sponsored workshop on personal information manage-

ment. report.

Jones, W., Bruce, H., and Dumais, S. (2001). Keeping

found things found on the web. In CIKM ’01: Proceed-

ings of the tenth international conference on Information

and knowledge management, pages 119–126, New York,

NY, USA. ACM Press.

Klyne, G. and Carroll, J. J. (2004). Resource de-

scription framework (RDF): Concepts and ab-

stract syntax. http://www.w3.org/TR/2004/

REC-rdf-concepts-20040210/.

Krötzsch, M., Vrandecic, D., and Völkel, M. (2006). Se-

mantic mediawiki. In Cruz, I., Decker, S., Allemang,

D., Preist, C., Schwabe, D., Mika, P., Uschold, M., and

Aroyo, L., editors, Proceedings of the 5th International

Semantic Web Conference (ISWC06), volume 4273 of

Lecture Notes in Computer Science, pages 935–942,

Athens, GA, USA. Springer.

Lethbridge, T. (1998). Metrics for concept-oriented knowl-

edge bases. International Journal of Software Engineer-

ing and Knowledge Engineering, 8(2):161–188.

Lethbridge, T. C. (1991). A model for informality in

knowledge representation and acquisition (an extended

abstract). presented at Workshop on Informal Comput-

ing, May 29-31 1991, Santa Cruz CA.

Likert, R. (1932). A technique for the measurement of atti-

tudes. s.n., New York.

Ludwig, L. (2005). Semantic personal knowledge manage-

ment. Technical Report D11.01_v0.01, DERI Galway.

Maier, R. (2004). Knowledge Management Systems: In-

formation and Communication Technologies for Knowl-

edge Management. Springer.

Maier, R. and Schmidt, A. (2007). Characterizing knowl-

edge maturing: A conceptual process model for integrat-

ing e-learning and knowledge management. In Gronau,

N., editor, 4th Conference Professional Knowledge Man-

agement - Experiences and Visions (WM ’07), Potsdam,

volume 1, pages 325–334, Berlin. GITO.

Maurer, H. (1999). The heart of the problem: Knowl-

edge management and knowledge transfer. In Proc. EN-

ABLE’99, pages 8–17. Espoo-Vantaa Institute of Tech-

nology.

Mitchell, A. (2005). The rise of personal km. Inside Knowl-

edge, 9(1).

Nonaka, I. and Takeuchi, H. (1995). The Knowledge-

Creating Company : How Japanese Companies Create

the Dynamics of Innovation. Oxford University Press.

North, K. (2007). Produktive wissensarbeit. In 5. Karl-

sruher Symposium für Wissensmanagement in Theorie

und Prxais. CD-ROM.

Oren, E., Völkel, M., Breslin, J. G., and Decker, S. (2006).

Semantic wikis for personal knowledge management.

In Database and Expert Systems Applications, volume

4080/2006, pages 509–518. Springer Berlin / Heidel-

berg.

Pédauque, R. T. (2003). Document: Form, sign and

medium, as reformulated for electronic documents.

Pirolli, P. and Card, S. K. (1995). Information foraging in

information access environments. In CHI, pages 51–58.

Polanyi, M. (1958). Personal Knowledge: Towards a Post-

Critical Philosophy. Routledge & Kegan Paul Ltd, Lon-

don.

Teevan, J., Alvarado, C., Ackerman, M. S., and Karger,

D. R. (2004). The perfect search engine is not enough:

a study of orienteering behavior in directed search. In

CHI ’04: Proc. of the SIGCHI conf. on Human factors in

computing systems, pages 415–422. ACM Press.

Toms, E. G. (2000). Serendipitous information retrieval. In

DELOS Workshop: Information Seeking, Searching and

Querying in Digital Libraries.

Van Rijsbergen, C. J. (1979). Information Retrieval, 2nd

edition. Dept. of Computer Science, University of Glas-

gow.

Varian, H. R. (1999). The economics of search. In SIGIR

’99: Proceedings of the 22nd annual international ACM

SIGIR conference on Research and development in in-

formation retrieval, page 1, New York, NY, USA. ACM.

Völkel, M. (2007). A semantic web content model and

repository. In Proceedings of the 3rd International Con-

ference on Semantic Technologies.

Vrandecic, D. (2006). Ontology evaluation for the web -

phd proposal. In Diederich, J., Motta, E., and Bontas,

E. P., editors, Proceedings of the KnowledgeWeb PhD

Symposium KWEPSY 2006, Budva, Montenegro.

COST-BENEFIT ANALYSIS FOR THE DESIGN OF PERSONAL KNOWLEDGE MANAGEMENT SYSTEMS

105
