CREDIT SCORING MODEL BASED ON THE AFFINITY SET

Jerzy Michnik

Department of Operations Research, The Karol Adamiecki University of Economics in Katowice

ul. Bogucicka 14, 40-226 Katowice, Poland

Anna Michnik

Department of Medical Physics, University of Silesia, ul. Uniwersytecka 4, 40-007 Katowice, Poland

Berenika Pietuch

ul. Polna 26/32, 41-600 Swietochlowice, Poland

Keywords:

Afﬁnity set, credit score, data mining, logistic regression, rough sets.

Abstract:

The signiﬁcant development of credit industry led to growing interest in sophisticated methods which can

support making more accurate and more rapid credit decisions. The parametric statistical methods such as

linear discriminant analysis and logistic regression were soon followed up by nonparametrical methods and

other techniques: neural networks, decision trees, and genetic algorithms.

This paper investigates the afﬁnity set – a new concept in data mining ﬁeld. The afﬁnity set model was applied

to credit applications database from Poland. The results are compared to those received by Rosetta (the rough

sets and genetic algorithm procedure) and logistic regression.

1 INTRODUCTION

The afﬁnity set (Chen and Larbani, 2006; Larbani and

Chen, 2006) is inspired from the vague interaction

between people in social sciences and developed as

the data mining tool to classify, analyze, and build

the relationship between observed outcomes (conse-

quences) and possible incomes (causes) of an infor-

mation system.

For several last decades the growth of the credit

industry is observed. The large loan portfolios moti-

vated the industry to develop the more accurate scor-

ing models. It is expected that good scoring model

can signiﬁcantly improve the future cash ﬂows of

credit institution. The main goal of credit scoring

models is to classify the objects (loan applications)

into the two classes: granted and denied.

At the beginning simple parametric statistical

models like linear discriminant analysis were em-

ployed. Linear discriminant analysis is still very pop-

ular, however has been questioned because the credit

data do not fulﬁll the strict assumptions underlying

this method . Logistic regression has appeared to be a

powerful parametric statistical method when applied

to credit databases. Several other techniques like k

nearest neighbor, classiﬁcation trees and neural net-

work models have been developed.

Five neural network architectures has been inves-

tigated by West: the traditional MLP network, mix-

ture of experts (MOE), radial basis function (RBF),

learning vector quantization (LVQ), and fuzzy adap-

tive resonance (FAR) (West, 2000). 10-fold cross-

validation method of testing was performed with two

real world data sets: Australian and German. Lo-

gistic regression has been found to be the most ac-

curate of the traditional methods. Comparable ac-

curacy have been achieved by two neural network

models: the mixture-of-experts and radial basis func-

tion. The results of Lee at al. revealed that clas-

siﬁcation and regression tree (CART) and multivari-

ate adaptive regression splines (MARS) outperformed

traditional discriminant analysis, logistic regression,

neural networks, and support vector machine (SVM)

approaches in terms of credit scoring accuracy (Lee

et al., 2006).

To improve the performance of credit scoring, the

mixed methods have been also proposed. Integrating

the backpropagation neural networks with traditional

discriminant analysis approach allowed to simplify

the network structure and improved the credit scoring

287

Michnik J., Michnik A. and Pietuch B. (2008).

CREDIT SCORING MODEL BASED ON THE AFFINITY SET.

In Proceedings of the Tenth International Conference on Enterprise Information Systems, pages 287-290

DOI: 10.5220/0001723902870290

 SciTePress

accuracy (Lee et al., 2002). Lee and Chen reported

that a two-stage hybrid modeling procedure with arti-

ﬁcial neural networks and MARS accomplished bet-

ter results then single method such as discriminant

analysis, logistic regression, artiﬁcial neural networks

or MARS (Lee and Chen, 2005).

A wide study of different approaches was pre-

sented recently (Xiao et al., 2006). The authors com-

pared the efﬁciency of the classical methods (e.g. lin-

ear discriminant analysis, logistic regression, neural

networks and k-nearest neighbor) and some recently

developed advanced data mining techniques such as

SVM, CART, and MARS. They tested all the chosen

methods on German, US and Australian credit data

sets. The experiment results show that SVM, MARS,

logistic regression and neural networks yield a very

good performance. However, CART and MARS’s ex-

planatory capability outperforms the other methods.

The aim of our research is to test an ability of

the concept of afﬁnity set to become the tool for

data mining and compare its results with the method

basing on the concept of rough sets and logistic re-

gression. We applied those selected methods to the

database which contained the individual credit appli-

cations from Poland.

2 AFFINITY CONCEPT IN DATA

MINING

2.1 Afﬁnity as a Performance Measure

The starting point of our analysis is database which

has a form of several input and output data. We as-

sume that there are k input data and each input data

can have several values which belong to the set

, consequently x = (x

, . . . , x

) belongs to Cartesian

product X

× . . . × X

= X. Similarly, there are l out-

put data y

with values from Y

, and (y

, . . . , y

) = y ∈

Y = Y

× . . . ×Y

. Each case c = (x, y) from database

is a member of Cartesian product X ×Y.

Any rule, which can explain the underlying re-

lationships in analyzed database can be considered

as a relation in the above deﬁned Cartesian product:

⊆ X ×Y, where the index p enumerates the rules.

We also can separate the input and output part of the

rule and write R

= (R

, R

), so that R

⊆ X and

⊆ Y.

We assume that the output values are mutually ex-

cluding. It means that some of the rules are contradic-

tory and can not explain the underlying relationships

simultaneously; e. g. for k = 2 and l = 1, the rules

, x

, y

) and (x

, x

, y

) are contradictory. This ob-

servation leads to the conclusion that an explanatory

power of the rule depends not only on that how many

times the rule explains correctly cases in database but

also on the difference of its frequency and frequency

of all contradictory rules

When we want to measure an explanatory power

of the rule, we need to take into account both above

properties. Consequently, we deﬁne the afﬁnity of the

rule as

A(R

) =

max

(

f(R

) −

∑

q∈C

f(R

), 0

)

, (1)

where C

contains the indices of all rules contra-

dictory to the rule R

; N is the number of records

in database. f(R

) = |{c

∈ R

}|, i = 1. . . , N;

f(R

) is an integer number which measure how many

cases match the rule R

(| | – denotes the cardinality

of the set). With the function ’max’ in the above deﬁ-

nition, only the rule which is matched by the maximal

number of cases in the group of competitive rules has

positive value of afﬁnity.

Let assume that the output consists of only single

binary variableY = {y

, y

} and the set of rules S have

been selected. We consider the deﬁnite input ¯x. Let S

¯x

denotes all rules from S which match with input, i.e.

¯x ∈ R

. f(R

( ¯x, y

)) represents the number of cases in

training set which support output y

for i = 1, 2. We

calculate the difference:

∆f =

∑

¯x

f(R

( ¯x, y

)) −

∑

¯x

f(R

( ¯x, y

)) (2)

and decide the output:

∆f ≥ 0 ⇒ y

, (3)

∆f ≤ 0 ⇒ y

, (4)

∆f = 0 undecided. (5)

To get the performance of the set of rules S we calcu-

late the ratios of matched, unmatched and undecided

outputs against actual outputs from the testing set.

2.2 Testing the Set of Rules

The beginning step is to generate all possible rules

from training set. Depending on particular require-

ment this usually large set can be reduced using the

concept of the a − core(A). The a − core(A) repre-

sents all elements with afﬁnity greater then or equal to

a, so its deﬁnition is: a− core(A) = {R

|A(R

) ≥ a}.

It seems practical to take for further analysis a to be

around 1%.

This reasoning is parallel to the concepts of coverage

and accuracy of the rule discussed in the information sys-

tems theory.

ICEIS 2008 - International Conference on Enterprise Information Systems

288

The following procedure for extracting the set of

rules S is proposed:

1. Move the rule with greatest afﬁnity from a −

core(A) to S. Check the performance of the set

2. If the performance of the set S is less then previ-

ous one, remove the rule from the set S. If perfor-

mance is equal or greater then previous, keep the

rule in the set S.

3. Unless the a − core(A) is empty: go to the step 1.

4. Stop

It need to be mentioned that the set of rules received

by above procedure may not be the minimal one, as

there was not any optimization routine built in it.

3 CREDIT SCORE MODEL –

CASE STUDY

The individual credit application database consisted

initially of over 40 ﬁelds and over 12000 records. It

covered – among others – employment status, per-

sonal information, age, housing, and job. It contained

also variables which summarized the process of credit

appraisal, such as credit score, result of credit ap-

praisal and credit capability. With the aid of logistic

regression method, the 23 variables which were sta-

tistically signiﬁcant and uncorrelated have been se-

lected. The stepwise (forward, conditional) method

shown that only 4 variables signiﬁcantly contributed

to the classiﬁcation power of the model and those

were chosen for subsequent analysis (the variable

coding is given in parenthesis).

Input Variables

– Number of Debtors: 1 (1), 2 (2).

– Credit Score: below 0 (1), 0-200 (2), 200-400

(3), 400-600 (4), 600-800 (5), 800-1000 (6), above

1000 (7).

– Result of Loan Application Appraisal: Er-

ror (1), To Clarify (2), Negative (3), Positive (4), Not

Counted (5), Application for Too Large Loan Value

(6).

– Credit Capability: No (1), Yes (2).

Output Variable

y – Credit Decision: Denied (1), Granted (2).

The initial step database contained 12711 ran-

domly ordered records (with no missing data). First

5000 records were used as a training set, the rest as the

testing set. For almost 62% cases in the testing set the

credit decision was positive. The number of different

Table 1: 22 rules with the greatest afﬁnity (’∗’ means that

the variable is not counted in the rule).

No. x y f(R

) A(R

)

1 **42 2 2668 0,4636

2 1*42 2 2640 0,4592

3 **4* 2 2714 0,3934

4 1*4* 2 2645 0,3822

5 *542 2 1966 0,3398

6 1542 2 1943 0,3364

7 **3* 1 1496 0,2972

8 1*3* 1 1493 0,2966

9 **32 1 1441 0,2862

10 1*32 1 1441 0,2862

11 *54* 2 2007 0,2834

12 154* 2 1945 0,2734

13 *53* 1 1044 0,2078

14 153* 1 1041 0,2072

15 *532 1 1003 0,1996

16 1532 1 1003 0,1996

17 ***2 2 2681 0,1718

18 1**2 2 2653 0,1674

19 *5*2 2 1973 0,1362

20 15*2 2 1950 0,1328

21 1**1 1 442 0,0874

22 ***1 1 452 0,0812

rules which take into account at least one variable x

were equal 1006.

The procedure described in Sec. 2.2 have been ap-

plied to the 0.01− core(A) which contained 62 rules.

The rule with the greatest afﬁnity (∗∗42, 2) explained

correctly 31.40% of cases, incorrectly 4.68%, and left

unclassiﬁed 63.92%. The second rule did not changed

the result. The third rule improved result to: [corr:

31.80%, incorr: 7.21% and unclass: 60,99%]. The

next improvement appeared for the set of 7 rules with

the result: [corr: 53.75%, incorr: 7.43% and unclass:

38,81%]. This result ha been remaining stable until

the rule no. 17 which improved the result to: [corr:

80.78%, incorr: 11.27% and unclass: 7,95%]. The

rule no. 21 gave [corr: 85,46%, incorr: 12,26%, un-

class: 2,28%]. The best performance [corr: 85.96%,

incorr: 14.04%, unclass: 0.00%] was reached for the

set of 22 rules. Adding 23 rule lowered the perfor-

mance so it was removed. Continuing the procedure

until a−core(A) became empty did not make any fur-

ther improvement.

For the sake of comparison we employed also the

”Rosetta” system (Øhrn et al., 1994) which is the

computer implementation of rough set modeling to

knowledge discovery and data mining. The genetic

algorithm implemented in Rosetta have been applied

to our training set. We have made several runs of the

genetic algorithm changing the boundary region thin-

CREDIT SCORING MODEL BASED ON THE AFFINITY SET

289

ning. The received set of rules was then applied to

the testing set with the aid of ’Batch Classiﬁer’ tool.

The best result, which we gained (with the set con-

taining 10 rules, was: 63.42% cases classiﬁed cor-

rectly, 6.34% incorrectly and 30.24% unclassiﬁed.

Logistic regression model developed on the train-

ing set and applied to test set gained 86.47% of cor-

rectness. This result coincide with other investiga-

tions which report that logistic regression belongs to

the most efﬁcient methods in the ﬁeld (West, 2000;

Xiao et al., 2006).

Let denote as p

the percentage of actually de-

nied applications misclassiﬁed into the granted group

and as p

the percentage of actually granted appli-

cations misclassiﬁed into denied group. It can be ob-

served that in all three models p

is much greater

then p

. The Rosetta’s total misclassiﬁed 6.34%

cases was divided as follows: p

= 5.02% and p

1.32%. For the afﬁnity set model: p

= 11.05% and

= 3.00%. Similarly, the logistic regression shows

= 13.16% and p

= 0.37%.

In credit scoring applications, it is generally be-

lieved that the costs of granting credit to a bad candi-

date is signiﬁcantly greater than the cost of denying

credit to a good candidate. As Rosetta model has the

lowest p

, it’s results might get better score if the

pure classiﬁcation rate has been substituted by a kind

of cost analysis. On the other hand, logistic regres-

sion has the highest value of p

which can lower its

score. The problem is – that in contrast to full clas-

siﬁcation reached by afﬁnity and logistic regression –

Rosetta left the great amount (30.24%) of cases un-

classiﬁed. This fact makes difﬁcult exact calculations

and drawing well-founded conclusions.

4 CONCLUSIONS

Our results shows that the afﬁnity measure deﬁned in

eq.(1) and followed by extracting procedure described

in Sec. 2.2 is able to gain the promising results in

data mining. The method is rather simple in com-

parison to other approaches. It is also low demand-

ing (no preliminary assumptions and low demand for

computing resources). We received much higher clas-

siﬁcation rate then rough sets and genetic algorithm

implemented in Rosetta software. The performance

of our concept was very close to the level gained by

logistic regression model which was reported as one

of the best in the ﬁeld of credit scoring.

To conﬁrm the promising efﬁciency of the pro-

posed method further studies should be carried out.

First of all, there is a need for:

• comparison with the neural network models and

other highly efﬁcient modern methods of data

mining,

• checking the results with other credit databases.

In this paper the outcomes predicted by the model

were confronted with actual credit decisions. It would

be also interesting to check the model predictions

with actual credit performance.

Our model was tested on credit application

database but can be applied equally well to medi-

cal, marketing, managerial and other databases. The

model offers meaningful adaptability and several ex-

periments with various technical modiﬁcations can be

made.

REFERENCES

Chen, Y. and Larbani, M. (2006). Developing the afﬁnity

set and its applications. In Proceeding of the Distin-

guished Scholar Workshop by National Science Coun-

cil, Jul. 14-18, 2006, Taiwan. National Science Coun-

cil, Taiwan.

Larbani, M. and Chen, Y. (2006). Afﬁnity set and its ap-

plications. In Proceeding of the International Work-

shop on Multiple Criteria Decision Making, Apr. 14-

18, 2007, Poland. Publisher of The Karol Adamiecki

University of Economics in Katowice.

Lee, T.-S. and Chen, I.-F. (2005). A two-stage hybrid

credit scoring model using artiﬁcial neural networks

and multivariate adaptive regression splines. Expert

Systems with Applications, 28:743752.

Lee, T.-S., Chiu, C.-C., Chou, Y.-C., and Lu, C.-J. (2006).

Mining the customer credit using classiﬁcation and

regression tree and multivariate adaptive regression

splines. Computational Statistics & Data Analysis,

50:11131130.

Lee, T.-S., Chiu, C.-C., Lu, C.-J., and Chen, I.-F. (2002).

Credit scoring using the hybrid neural discrimi-

nant technique. Expert Systems with Applications,

23:245254.

Øhrn, A., Komorowski, J., Skowron, A., and Synak, P.

(1994). The design and implementation of a knowl-

edge discovery toolkit based on rough sets: The

rosetta system. In Polkowski, L. and Skowron, A., ed-

itors, Rough Sets in Knowledge Discovery 1: Method-

ology and Applications, volume 18 of Studies in

Fuzziness and Soft Computing, chapter 19, page 376.

Physica-Verlag, Heidelberg, Germany.

West, D. (2000). Neural network credit scoring models.

Computers & Operations Research, 27:1131–1152.

Xiao, W., Zhao, X., and Fei, Q. (2006). A compara-

tive study of data mining methods in consumer loans

credit scoring management. J. Syst. Sci. Syst. Eng.,

15(4):419–435.

ICEIS 2008 - International Conference on Enterprise Information Systems

290
