SUCCINCT ACCESS CONTROL POLICIES

FOR PUBLISHED XML DATASETS

Tomasz Müldner

, Jan Krzysztof Miziołek

and Gregory Leighton

Jodrey School of Computer Science, Acadia University, Wolfville, N.S. Canada

IBI AL, University of Warsaw, Warsaw, Poland

Department of Computer Science, University of Calgary, Calgary, Canada

Keywords: Access control, XML, parameterized roles.

Abstract: We consider the setting of secure publishing of XML documents, in which read-only access control policies

(ACPs) over static XML datasets are enforced using cryptographic keys. The role-based access control (RBAC)

model provides a flexible method for specifying such policies. Extending the RBAC model to include role

parameterization addresses the problem of role proliferation which can occur in large scale systems. In this

paper, we describe the complete design of a parameterized RBAC (PRBAC) model for XML documents. We

also describe algorithms for generating the minimum number of keys required to enforce an arbitrary PRBAC

policy; for distributing to each user only keys needed for decrypting accessible nodes; and for applying the

minimal number of encryption operations to an XML document required to satisfy the protection requirements

of the policy. The time complexity of our approach is linear w.r.t. document size and the number of roles.

1 INTRODUCTION

There is growing interest in providing controlled and

secure access to XML documents [(Bertino et al,

2002), (Bertino et al., 2004), (Damiani et al, 2002),

(Devanbu et al, 2001)]. In this context, controlled

access allows the owner of data to specify permission

policies indicating which users can access specific

documents, or parts thereof. Secure access to data

means that data is confidential, i.e., visible only to

authorized parties. Since XML data has become a de

facto standard for many applications, in particular for

Web applications, much of the research done on

controlled access in recent years deals with data in this

format. In addition to proposed standards for

encrypting portions of an XML document, such as the

W3C XML Encryption Syntax and Processing

recommendation (W3C XML Encryption, 2001),

secure publishing approaches have been proposed in

the research community that illustrate how multiple

users holding varying permissions over an XML

document can gain controlled access to the same

version of that document, through the selective

application of cryptographic keys [(Bertino et al,

2002), (Mikalu et al, 2003), (Müldner et al, 2006)].

Using this technique, a single version of an XML

document is published (e.g., posted to an HTTP

server). Each user is provided with a set of keys via a

secure channel; by applying her available decryption

keys, a user gains access only to the portions of the

document authorized by the designated ACP. For

example, the contents of a statistical or scientific

database may be periodically sanitized (to remove

sensitive information), exported as XML, and

published. In such a setting, it is important to note that

each published document is static, and hence access

control policies only allocate read permissions. The

role-based access control (RBAC) model provides a

powerful and flexible method for specifying such

policies. However, the RBAC model is susceptible to

role proliferation. For example, thousands of scientists

may be granted access to various parts of an XML

380

Müldner T., Krzysztof Miziołek J. and Leighton G. (2008).

SUCCINCT ACCESS CONTROL POLICIES FOR PUBLISHED XML DATASETS.

In Proceedings of the Tenth International Conference on Enterprise Information Systems - DISI, pages 380-385

DOI: 10.5220/0001726103800385

 SciTePress

dataset; the access permissions accorded to each

scientist may vary according to their specialization and

their affiliation. In the worst case, it is possible that a

role-based policy must assign a unique role to each

scientist. The concept of role parameterization has

been shown to be an effective solution to role

proliferation (Ge et al, 2004); instead of defining a

separate role for each scientist, one can use a much

smaller number of roles and parameterize each role

with variables representing area of specialization and

affiliation. With a smaller number of roles, it becomes

easier to formulate and enforce the desired access

control restrictions.

In this paper, we introduce techniques that can be used

to implement controlled and secure access to published

XML documents. Specifically, we define

parameterized role-based ACPs (PRBAC policies);

each such policy consists of a set of rules associating a

role with one or more views (or fragments) defined

over an XML document. Policy rules may contain role

parameters and/or system variables. Once a user is

authenticated to play role R, any role parameters and

system variables are instantiated and the user can

access only those views which are associated with role

R. We have designed a key assignment algorithm

which, given a PRBAC policy and an XML document

(or dataset), generates the minimal number of keys

required to enforce the stated policy. Generated keys

are used to multi-encrypt a document so that each

element of the document is encrypted with at most one

key. Since each view may be encrypted with multiple

keys, users playing a specific role R are provided with

an R-accessible keyring, consisting of the set of keys

needed to decrypt and access exactly the document

portions they are allowed to see.

This paper is organized as follows. Section 2 describes

related work. Section 3 introduces preliminary

notation and concepts and Section 4 defines the

language of parameterized roles and the PRBAC

model. Section 5 describes key generation and multi-

encryption of documents. Section 6 describes areas for

future work. Because of space restrictions, proofs are

omitted.

Contributions. Our contributions include the

complete description of a PRBAC model tailored for

static, published XML datasets. To our knowledge,

this is the first formulation of such a model. We also

detail an approach that, for a given uninstantiated

PRBAC policy (i.e. even before values of parameters

and system variables are known) and XML document

D (1) generates the minimum number of keys needed

to multi-encrypt D; (2) applies the minimal number of

encryption operations on D needed to enforce the

PRBAC policy; and (3) for each role R in the PRBAC,

generates the R-accessible keyring. All of these steps

can be carried out using two SAX-based traversals of

2 RELATED WORK

Motivated by the increasing use of XML as a data

representation format, several access control models

specifically tailored for XML have been proposed in

recent years. Such approaches permit the formulation

of fine-grained access control policies at the schema,

document, and/or element level. At a high level, it is

possible to distinguish between materialized view-

oriented approaches, in which client queries are

answered over a sub-document (view) generated by

the database management system, containing only the

accessible regions of an XML database.[(Bertino et al,

2002), (Damiani et al, 2002)], and secure publishing

approaches (Miklau et al 2003) and (Müldner et al,

2006), in which a single, partially-encrypted version of

a document is distributed and access control policies

are enforced using public-key cryptography. While

materialized view-oriented approaches hide the

original document from the client, a very large number

of materialized views may be required in applications

dealing with large, complex documents and/or several

users. Secure publishing approaches are designed for

cases in which it is unnecessary, and even undesirable,

to allow users direct access to a database, and instead

provide to users a published, static “snapshot” of the

database contents. Our approach follows the secure

publishing paradigm.

Role based ACPs have been extensively

researched [(Ferraiolo et al, 2001), (Osborn et al,

2000), (RBAC, 2008), (Wang et al, 2004)]. (Ge, 2004)

describes an extension to the role-based access control

model in which parameterized roles are used to deal

with scenarios in which data access is dependent on

certain characteristics held by an individual user. In

applications with a small number of users, it is feasible

to define a separate role for each individual user, yet

this approach clearly becomes unmanageable if the

user base is moderately large. Rather than defining

several thousand roles with a membership of one, an

administrator can define a single, parameterized role,

and specify an access control rule which dictates

SUCCINCT ACCESS CONTROL POLICIES FOR PUBLISHED XML DATASETS

381

access to specific data. Our approach applies the

notion of parameterized roles to ACPs for XML

documents, allowing them to be used for expressing

access control policies.

3 PRELIMINARIES

3.1 Introduction to Roles

In most systems, access rights are defined using access

control policies (ACPs) which state which subjects

have specific rights. In the role-based access control

model (RBAC), users are identified through roles, and

access rights are associated with each role. When a

user is assigned to a role, they acquire the role’s

permissions.

In general, XML access control policy rules are five-

tuples (subject, resource, action, permission,

propagation), with actions such as read, write, or

modify; permissions such as add or remove; and a

propagation policy that allows one to limit the rule to a

local scope or apply it to a more global scope

(Fundulaki et al, 2004). In this paper, we consider only

read access (since we focus on secure publishing

scenarios, writes are not applicable), and we do not

consider various permissions. We fix a no propagation

policy: specifying an element e in an access control

rule applies the rule only to e, and not to other

elements within the sub-tree rooted at e. Therefore,

role-based access control rules for XML documents in

this paper will consist of pairs of the form (role,

resource), where a resource is a document fragment

specified using an XPath expression (XPath, 2008).

3.2 Documents and Views

The focus of our work is to define ACPs for fragments

of XML documents, which we call views. In our

approach, we publish a single multi-encrypted XML

document (or dataset).

We assume that at the system level, there are pre-

defined system variables (such as user ID), and we use

identifiers starting with $ to denote these variables

(e.g., $ID). System variables are typed using XML

Schema types (XML Schema, 2008) (e.g., $ID:

xs:integer), and they must remain static during the

course of a user session (i.e., we do not consider

dynamic system variables representing values such as

the current time or the number of users currently in the

system). In other words, there is a fixed set of static

variables, and for each user values of all these

variables are initialized and do not change during the

session, i.e., until this user logs off.

Views are specified using a subset of XPath

expressions referred to as document paths. Document

paths may have conditions, and in XPaths these

conditions use element names and attributes. Here, we

extend XPaths and allow free variables to appear in

conditions. There are two kinds of free variables: those

that represent system variables and whose names start

with $, and those that represent formal parameters and

whose names start with % (for more on formal

parameters of roles, see Section 4.1). We assume that a

single comparison in the path can use at most one free

variable; e.g. we don’t allow conditions of the form

[$Id = %Id].

Definition 3.1. A local document path is a document

path with no free variables. A global document path is

a document path which is not local. A global

document path is called instantiated when each

occurrence of free variables is replaced by some

value.□

For a document D, by P

D, loc

we denote the set of

local paths in D. Each local document path defines a

fragment of the document D, which we call a view of

D (and we frequently refer to the path P as the view P).

Similarly, by P

D, glob

we denote the set of global paths

in D, and the set of all document paths is denoted by

= P

D, loc

∪ P

D, glob

. A local path and an instantiated

global path each define a fragment of the document D.

3.3 Multi-encryption

In this section, by a key we refer to a symmetric

cryptographic key (e.g., an AES key). A keyring is a

set of keys. An ACP may define multiple views for a

single document. By the multi-encrypted document m-

document, we denote a document with an associated

keyring Κ, in which various views may be encrypted

with different sets of keys from Κ. However, no node

in the m-document is super-encrypted, i.e., encrypted

more than once. Based on permissions defined in the

ACP, users will be provided a subset of Κ enabling

them to decrypt exactly those views they are entitled to

see.

ICEIS 2008 - International Conference on Enterprise Information Systems

382

4 ROLE BASED ACCESS

CONTROL

In this section, we first describe roles and then use

roles to define the document-level PRBAC.

4.1 Language of Roles

In our access control model, roles can be

parameterized or parameter-less. Parameterized roles

contain typed parameters. They are useful because

they help to avoid hard-coding multiple roles which

provide permissions depending on external values

known when the role is being assigned; for example:

• There are many departments with different names.

• There is a “security level” attribute and permissions

depend on the given security level.

A parameterized role is called instantiated if all its

formal parameters are replaced by actual values.

Let N be the set of role names, P the set of

parameter names, and T the set of parameter type

names (we assume that these three sets are mutually

disjoint). We define the alphabet A as the union N ∪ P

∪ T ∪ {(, ), ;}. We write role names in upper case

(e.g., STUDENT). Parameter names start with %.

Definition 4.1. A role grammar Γ over the alphabet A

is defined as follows:

role := roleName | parameterizedRole

parameterizedRole := roleName ‘(‘ rolePars ‘)’

rolePars := formalPar | formalPar ‘;’ rolePars

formalPar := parName‘:’ parTypeName

where roleName∈N, parName∈P, and

parTypeName∈T. □

Example 4.1.

An example of a parameterized role is:

USER(%id : xs:integer; %name : xs:string). □

4.2 Simple Roles

In Section 4.1 we defined the role grammar Γ, and by

we denote the language of all roles.

Definition 4.2. For an XML document D and a finite

set of simple roles Ψ⊂Λ

, the document-level ACP is a

mapping π

: Ψ→P

such that π

(Ψ) covers the set D;

i.e. each element of D belongs to at least one

document path that occurs in the policy. Often, the π

mapping is tabulated and shown as a tuple [(R

, P

),...,(R

)]. □

For a simple role R∈Ψ, if π

(R) is a local

document path then it defines a view of D. If π

(R) is

a global document path that contains free variables

(system variables or formal parameters for a

parameterized role R), then once this path is

instantiated, it defines a view of D. The designer of a

PRBAC policy for an XML document D may decide

to leave some parts of D unencrypted (accessible to all

users) or to make them inaccessible to all users (i.e., to

encrypt them, but not to provide the keys used for

encryption of these nodes to any user). For the former

case, the symbol ○ is used, while for the latter case we

use the symbol ●. Therefore, the actual definition of

the document-level ACP is that it is pair (π

, ♦),

where ♦ is either ○ or ●. For simplicity (unless

specified otherwise), in the sequel, we omit the second

element of this pair, and assume that by default it is

always ○ (i.e. by default, elements of D not covered by

are unencrypted).

Definition 4.3. The document-level protection

requirement is said to be satisfied under the following

conditions. For an XML document D, a finite set of

roles Ψ⊂Λ

, and the document-level ACP π

: Ψ→P

user in role R can access precisely the set π

(R), and

those nodes in D which are not covered by any path.□

5 KEY GENERATION AND

MULTI-ENCRYPTION

Definition 5.1. A keyring Κ is a finite set of keys,

where each key is a 2-tuple <key name, symmetric

key>. By Κ

D,π

we denote a document-level keyring

for the document D and D’s policy π

5.1 Creating Local Paths from Global

Paths

In this section, we describe keyring generation at the

document level, corresponding to a document-level

policy π

: Ψ→P

. If all paths from the set P

are local

then keyring generation can take advantage of the fact

that data in the document D can be used to evaluate all

conditions in these paths, and therefore each path

uniquely identifies a fragment of D. The situation is

more complicated if the policy has some global paths;

for example, it has a parameter-less role and an

associated path with conditions using system variables,

or it has a parameterized role and an associated path

SUCCINCT ACCESS CONTROL POLICIES FOR PUBLISHED XML DATASETS

383

with conditions using formal parameters of this role. In

such cases, conditions in paths can not be evaluated

until values of corresponding free variables are

known. However, postponing keyring generation until

such time would mean that, for a parameterized role, a

keyring would be generated for each user that can play

this role (using specific actual parameters), possibly

resulting in unnecessary duplication of keys.

Therefore, we employ a different technique and deal

with global paths in a special way.

Recall that a global path P contains free variables

representing role parameters and/or system variables.

We require an algorithm that finds all values in P

which are being compared with free variables, and

replaces P with local paths in which these variables are

replaced with values relevant for evaluating

conditions. In the current version, there is a restriction

on the type T of any free variable that may appear in a

global path; specifically, we assume that T has a linear

ordering < and ≤, here called a linear order that

satisfies the following condition: for any three

elements x, y and z of type T; if x<y, then exactly one

of the following three inequalities holds: z<x,x≤z<y,

or y≤z. For example, integer or real free variables may

be used. We define intervals of the form(v

, v

) = {v:

< v < v

}, [v

, v

] = {v: v = v

}, (-∞, v

) = {v: v <

} and (v

, +∞) = {v: v > v

}. Then, the following

property holds: given n arbitrary values v

,...,v

type T, and intervals of the form (-∞, v

), [v

, v

], (v

), [v

, v

], … [v

, v

], (v

, +∞), the value of variable

x of type T belongs to exactly one of these intervals.

The auxiliary Algorithm 5.1 given below considers a

role R and a global path P, and splits P into one or

more local paths. More specifically, it builds a set of

intervals that partitions the set of values of type T,

based on values from the document D used in

comparisons with free variables in P, and a set of local

paths corresponding to all instantiations of P using

values of the set of intervals.

Algorithm 5.1. Input: A document D, a simple role R

(different from ○), and a global document path P with

n free variables A

,...,A

of respective types

,...,T

; each type T

has a linear order.

Note that some free variables may represent

parameters of a parameterized role R and others may

represent system variables; in particular R may be

parameter-less and all free variables in P may be

system variables, or vice-versa.

Output: A vector Locals[R] consisting of pairs of the

form (local path, keyring), and a table Intervals(D, R,

P) containing pairs (k-tuples of intervals, index into

Locals). The complexity of this algorithm is linear in

terms of the size of D.

5.2 Generating Keyrings and Encrypting

Consider an XML document D and its document-level

access control policy π

: Ψ→P

, where Ψ⊂Λ

is a

finite set of roles. In this section, we define a keyring

D, π

, and show how for each role R∈Ψ this keyring

defines the set Κ

D,π

(R) of R-accessible keys. A user

in role R will be provided with the R-accessible keys,

i.e. the keyring Κ

D,π

(R) allowing her to decrypt the

view π

(R).

We now consider various ways keys may be

assigned to documents. Since views may be

overlapping, we can not assign keys per view. Indeed,

if we did so, then for two overlapping views V

and V

we would have two corresponding keys κ

and κ

, and

the intersection of the two views would have to be

super-encrypted using both κ

and κ

(assigning keys

per view would mean that the user who has access to

the view V

would be given a key κ

and so other

options such as encrypting V

with one key and V

-V

with the other key would have given access to the part

that is not allowed). What we need to do is to partition

the set D (and at the same time each view) into disjoint

sets, and then assign one key for each set in this

partition.

Below, we will assume that all views in π

(Ψ) are

different. If this is not the case, then we proceed as

follows. For the policy π

obtained by removing

duplicate views from π

(and corresponding roles), we

generate a keyring Κ

D,π

(which also defines

D,π

(R)). Then, we define Κ

D,π

= Κ

D,π

, Κ

D,π

(R) =

D,π

(R) if R was not a duplicate role, and Κ

D,π

(R) =

D,π

) if R was removed and R

is its duplicate

(i.e., R and R

were associated with the same view).

We assume that conditions that appear in paths can

be evaluated during a single SAX-traversal of the

document D.

Algorithm 5.2. Input: XML document D, and policy

: Ψ→P

such that all views in π

(Ψ) are different.

Output: Keyring Κ

D,π

, multi-encrypted XML

document M

, for each R∈Ψ, and two vectors

ICEIS 2008 - International Conference on Enterprise Information Systems

384

Global[] and Local[] (which will be used to identify R-

accessible keyrings Κ

D,π

(R), as described below). □

Theorem 5.1. If the user in role R is provided only

with R-accessible keys, then the document-level

protection requirement (cf. Def. 4.3) is satisfied. □

5.3 Decrypting m-documents

Assume that a user U in role R has obtained the

keyring Κ

D,π

(R) of R-accessible keys and wants to

decrypt an m-document M

. U will traverse M

, and

use names of keys from Κ

D,π

(R) to extract the

appropriate key to decrypt R-accessible nodes.

5.4 Obtaining Keyrings

U may request a keyring that she will use to decrypt a

fragment of the m-document D. From the list of roles

U is currently playing, she selects a certain role R, and

then proves that she plays R by presenting the

certificate obtained when U was granted R. Being in

role R, U will specifically request the keyring Κ of R-

accessible keys for the document D. Let P = π

(R). If

R is a simple role and the path P = π

(R) is a local

path, then Κ is retrieved from the appropriate keyring

Local[]. If π

(R) is a global path, then the set

Intervals(D, R, P) is consulted. The set of values of

actual parameters (if any) of R and the values of

system variables are used to determine the specific

cube that contains all these values. If there is no such

cube, U has no permissions granted; otherwise, the

keyring at the index associated with this cube is

returned.

6 CONCLUSIONS AND FUTURE

WORK

In this paper, we described a parameterized role-based

access control (PRBAC) model allowing permissions

to be specified over fragments of published XML

datasets. Our future work will focus on implementing

the PRBAC model, and designing and implementing

algorithms allowing existing keyrings to be

incrementally altered in response to update operations

performed on the document and/or access control

policy.

REFERENCES

Bertino, E., Ferrari, E. Secure and Selective Dissemination

of XML Documents. ACM Transactions on Information

and System Security (TISSEC), 5(3):290–331, (2002).

Bertino, E., Carminati, B., Ferrari, E., Thuraisingham, B.,

and Gupta A. Selective and Authentic Third-Party

Distribution of XML Documents. IEEE Transactions on

Knowledge and Data Engineering (TKDE),

16(10):1263-1278, (2004).

Damiani, E., De Capitani di Vimercati, S., Paraboschi, S.

and Samarati, P. A Fine-grained Access Control System

for XML Documents. ACM Transactions on

Information and System Security, 5(2): 169-202, (2002).

Devanbu, P., Gertz, M., Kwong, A., Martel, C., Nuckolls, G.

and S.G. Stubblebine. Flexible Authentication of XML

documents. In Proc. of the 8th ACM Conf. on Computer

and Communications Security, ACM Press, (2001).

Ferraiolo, D.F., Sandhu, R., Gavrila, S., Kuhn, D.S. and

Chandramouli, R. Proposed NIST Standard for Role-

Based Access Control. ACM Transactions on

Information and System Security, Vol. 4, No. 3, (2001),

224–274.

Fundulaki, I. and Marx, M. Specifying access control

policies for XML documents. Proceedings of the ninth

ACM symposium on Access control models and

technologies (2004) 61 – 69.

Ge, M. and Osborn., S.L. A Design for Parameterized Roles.

DBSec (2004), 251-264.

Miklau, G. and Suciu, D. Controlling Access to Published

Data Using Cryptography, In Proc. of the 29th VLDB

Conference, Berlin, Germany, (2003).

Müldner, T., Leighton, G. and Miziołek, J.K. Using Multi-

Encryption to Provide Secure and Controlled Access to

XML Documents. Extreme Markup Languages 2006,

(2006), Montreal, Canada.

Osborn, S., Sandhu, R., Munawer, Q. Configuring Role-

Based Access Control to Enforce Mandatory and

Discretionary Access Control Policies. ACM Trans. on

Information and System Security, 3:2, (2000), 85–106.

Role Based Access Control. http://csrc.nist.gov/rbac/.

Wang, J. and Osborn, AS. A role-based approach to access

control for XML databases. Proceedings of the ninth

ACM symposium on Access control models and

technologies Yorktown Heights, US (2004): 70 – 77.

W3C XML Encryption http://w3.org/Encryption/2001.

XML Path Language. http://www.w3.org/TR/xpath.

XML Schema http://www.w3.org/TR/xmlschema-0/

SUCCINCT ACCESS CONTROL POLICIES FOR PUBLISHED XML DATASETS

385
