Semantic Navigation of News

Walter Kasper, J

org Steffen and Yajing Zhang

DFKI GmbH, Stuhlsatzenhausweg 3, D-66123 Saarbr

ucken, Germany

Abstract. We present a system for browsing a news repository that is based on

semantic similarity of documents. News documents get automatically annotated

semantically using information extraction. Annotations are displayed to a user

who can easily retrieve crosslingual semantically related documents by selecting

interesting content items.

1 Introduction

In the MESH project (http://www.mesh-ip.eu) news from online sources get analyzed

for automatic annotation of their content with respect to domain speciﬁc information

about major reported events. News in English, German and Spanish from Deutsche

Welle (http://www.dw-world.de) and BBC (http://news.bbc.co.uk) are used. The service

enables professional users to search not only for news stories about speciﬁc events

but also to get a comprehensive overview of the information available from different

sources and supports intelligent navigation within related information and news about

the same and similar events. The most basic information about such events that gets

extracted is their time and location as well as involved persons and organizations.

The SENA system described here is based on a scenario like this: a professional user

is searching a news archive or repository for information about some event. He already

found some relevant document. Now he is interested to know whether there are other

documents about the same event or similar events in the same region, etc. This is where

SENA can help: when the user is viewing a document SENA also presents an overview

of relevant content items of some semantic categories that the user might be interested

in to ﬁnd more information about. By selecting interesting content items the user can

retrieve documents related and similar to the document he is viewing with respect to

the selected items. As SENA is based on semantic annotations to the news documents

and not just textual search, SENA supports crosslingual retrieval of documents in a

straightforward manner for multilingual news repositories.

The rest of the paper is organized as follows. Section 2 gives an overview of the

system environment and major components. SENA’s concept of semantic similarity is

discussed in section 3. Then the SENA user interface will be presented in section 4.

Section 5 discusses related attempts to news annotation and navigation. Finally, we will

give an outlook towards further development of SENA.

This work was supported by the European Commission, under contract number FP6-027685

(MESH).

Kasper W., Steffen J. and Zhang Y. (2008).

Semantic Navigation of News.

In Proceedings of the 5th International Workshop on Natural Language Processing and Cognitive Science, pages 42-51

DOI: 10.5220/0001735700420051

 SciTePress

Fig. 1. SENA architecture.

Fig. 2. Domain ontology.

2 System Environment

Figure 1 shows the overall architecture of the SENA system. Basically it consists of

three layers: the acquisition layer where new documents get analyzed, the storage layer

for storing the annotations and the retrieval layer that interacts with the user interface

to retrieve documents from storage. The main components will be described in the next

sections.

2.1 Knowledge Representation

Annotations about news documents are deﬁned by OWL ontologies, the most important

being a domain ontology derived from the IPTC subject code classiﬁcation

and an

ontology of news metadata that was derived from NewsML

. For multimedia documents

a multimedia ontology based on the MPEG-7 standard is used.

Annotations are stored

as instances of these ontologies in an RDF repository, linked to the document identiﬁer

or URL they belong to. Figure 2 shows parts of the domain ontology. The top-level

class is mesh event. Additionally, general properties of that class and some properties

speciﬁc for the earthquake subclass are shown.

The ontologies provide the conceptual core of the RDF knowledge base and the

basis for reasoning processes. In addition a repository of external knowledge is used to

support semantic reasoning. At present, this external repository mainly contains infor-

mation about locations, especially containment relations among them. Its current size

http://www.iptc.org/NewsCodes/

http://www.newsml.org

We use the SmartWeb multimedia ontology: http://smartweb.dfki.de/ontology en.html

is about 1.2 million RDF triples. In SENA this allows to retrieve documents concern-

ing e.g. Bavaria even if the document only mentions some place that is located in that

region.

2.2 Information Extraction

The core annotation and information extraction engine is provided by the SProUT plat-

form ([1, 2]). SProUT combines ﬁnite state techniques with uniﬁcation of typed fea-

ture structures (TFS). TFS provides a powerful device for representing and propagating

information. Rules are expressed by regular expressions over input TFSs that get in-

stantiated by the analysis. The uniform use of TFSs for input and output also allows

for cascaded application of rule systems. For the MESH application the rule system is

organized as

– a set of core named entity recognition (NER) grammars for date and time expres-

sions, locations, persons and organizations

– domain speciﬁc annotation and extraction grammars based on the domain ontolo-

gies

– an upper level merging component that merges partial annotations and information

into larger chunks, usually at paragraph level. It uses uniﬁability as main compati-

bility test.

TFSs support well information extraction (IE) by allowing to model OWL domain

ontologies: basically, the OWL classes become types, the properties are treated as fea-

tures.

As a result the domain ontology is represented in TFS by complex types that

provide templates that need to be ﬁlled by IE. This approach also makes it easy to map

the results of IE to instances of the domain ontology for further semantic processing

and storage in the RDF repository.

So, IE in SENA goes beyond semantic tagging of phrases to detect co-occurrence of

entities but attaches the information to event types. The analysis would not just detect

that an earthquake event and that a location like Iran is mentioned but if possible would

link the location to the event by a hasLocation property.

The result of IE is an RDF representation such as this for earthquake in Iran:

mesh:id1 rdf:type mesh:earthquake ;

mesh:hasLocation mesh:id2 .

mesh:id2 rdf:type mesh:country ;

mesh:name "Iran" .

On average, IE generates about 300 (raw) RDF statements as annotations for a docu-

ment.

A similar idea is underlying the approach of [3].

Actually UUIDs are used as unique instance identiﬁers.

2.3 Temporal Anchoring of Events

Often news texts talk not only about one major event but refer to other events and

circumstances as well. Important clues to distinguish what belongs to the main topic

of a news article and what is subsidiary information is given by temporal information.

However, this information may not be given explicitly by some date or time expression

but by relative references such as the week before. In order to distinguish and relate

event information from different news sources, a Time Anchoring Component (TAC)

was developed to resolve temporal expressions and anchor events to some date or time.

The MESH ontology uses OWLTime ([4, 5]) which provides classes for representing

temporal instants, intervals and duration. The core date-time representation is the class

DateTimeDescription.

The use of OWLTime presupposes to some extent that dates or times are completely

speciﬁed. But it poses some problems for the representation of partial and underspec-

iﬁed temporal expressions as used in natural language text. The TAC component de-

scribed here bridges the gap between temporal natural language expressions and OWL-

Time representations.

We distinguish two types of temporal expressions:

– Explicit expressions refer to a speciﬁc point of time or period of time. It can be

unambiguously identiﬁed in a calendar, for instance, June 6th, 2006.

– Relative expressions refer to a point of time or period of time that can only be unam-

biguously identiﬁed with the help of a reference time given by context. Examples

include yesterday, two hours later, in summer, etc.

Different from the division made by [6], we do not distinguish deictic and relative ex-

pressions, since both of them require a contextually given reference time to anchor the

expression correctly. The difference is only in the type of context.

The result temporal representation consists of a structure with features

ordered by

their granularity: [second < minute < hour < pofd < dofw < day < weeknumber <

pofm < month < pofy < year]. Among all these features, the feature year is obligatory

which means each result at least must specify a value for year.

TAC includes a complete calendar model for date and time calculations as well as a

temporal interval reasoner (cf. section 2.4 below) for handling time spans.

TAC’s input consists of the RDF model from the IE system. The relevant temporal

representations are extracted by SPARQL queries ([7]) on the model. The reference

time is context-dependent. For news items it is often the publication or creation time.

But the reference time is a dynamic concept: when another explicit time is mentioned

in the text, it can become the new reference time for subsequent sentences in the same

paragraph.

TAC also decides about the granularity level at which completion is necessary. The

result inherits the granularity of the original incomplete expression. For instance, let

the reference date be October 24, 1997 (Friday). In example (1) the granularity of the

original expression is dofw and is anchored to Wednesday, October 15, 1997 while

example (2) has the granularity of minute and will be anchored to October 24, 1997,

4:20.

pofd: part-of-day, dofw: day-of-week, pofm: part-of-month, pofy: part-of-year

(1) The president ﬂew to Berlin on last Wednesday.

(2) The earthquake happened at 04:20 this morning.

2.4 Reasoning

The knowledge base (KB) is embedded into a reasoning component (RC). All access

to the KB has to go through the RC to prevent getting out of sync with the KB if that

were directly modiﬁed behind RC’s back. When the KB gets updated by analysis, the

RC can apply forward chaining reasoning to add immediately some standard types of

deductions.

SENA uses the Jena framework for RDF handling and storage

. Jena also provides

a generic rule reasoner. In addition to pure rule reasoning, the Jena reasoner provides

an extensible set of operators, e.g. for arithmetic operations. In SENA the base set of

built-ins was extended to provide the core operators speciﬁed by the Semantic Web Rule

Language (SWRL) standard.

The RC consists of several reasoner modules: besides a generic OWL reasoner es-

pecially for inheritance and instance classiﬁcation there are special purpose reasoners

extending the Jena reasoner. These provide additional functionality that is difﬁcult, in-

efﬁcient or impossible to achieve by pure monotonic, open-world deductive reasoning.

One example of such reasoning is TAC that was developed as it would be hard to deal

with the necessary contextual and numeric calendar calculations in a strictly deductive

manner.

One set of reasoners is applied when the KB gets updated by new analysis data.

Speciﬁc reasoners provide the following functionalities:

– Validation: the RDF model from analysis is validated against the SENA ontolo-

gies for correctness. Also, the RDF model is purged with respect to intermediate

analysis data, not part of the system ontologies.

– Identity reasoner: the RDF data from IE typically contains distinct instances for

distinct occurrences of some entity. The identity reasoner checks whether entities

from this set of fresh instances can be identiﬁed with each other and with enti-

ties already contained in the knowledge base. Basically, the reasoner derives a set

of identity statements as owl:same-as statements, then merges all the information

about the identical entities and links it to a base representative instance. It uses a

mix of rule reasoning and heuristic reasoning, such as that person names might

refer to the same person if their last name and the initials of their ﬁrst names are

equal. Typically, the identity reasoner reduces the annotation set by about 30-40%

as persons, location etc. often can be identiﬁed with already known instances.

If there are several possible instances some entity might be identiﬁed with, disam-

biguation is necessary. E.g., our KB knows about eleven places named Paris, most

of them being in USA. For disambiguation, the reasoner then checks other locations

in the model whether they can be related to common location “containers”.

http://jena.sourceforge.net

The extensibility and adaptability of the Jena reasoning engine was the main reason for not

using an OWL DL reasoner such as Pellet ([8]) as basis.

A second set of reasoners is mainly responsible for reasoning services at retrieval

time. It helps to infer implicit information in response to queries to the KB. These

reasoners are monotonic based on standard ﬁrst-order logic implementing the OWL

semantics. This set includes a temporal reasoner, based on an efﬁcient implementation

of Allen’s interval logics ([9, 10]) as well as a location reasoner for reasoning on the

location database.

3 Semantic Similarity of Documents

The most important information pieces for a document are contained in the KB as in-

stances of the mesh event class and its subclasses. The properties of an event specify its

location, time and duration, etc. Given an unique document id (like its URL) a SPARQL

query ([7]) is used to get all event instances for that document from the KB.

Each event instance can be interpreted as the root of a directed graph, with the

properties as edges, instances and literals as nodes. We group all event instances of

a document under a single artiﬁcial root node to get a single graph representing the

events described in the document. We use these document graphs as a base for deﬁning

a similarity measure for documents. Numerous similarity measures for graphs exist.

We use a similarity measure based on the maximal common subgraph of two graphs

(e.g. [11]). This similarity measure has also the advantage that it is a metric. So for two

documents D

and D

represented by the two document graphs G

and G

, we deﬁne

the maximum common subgraph similarity (mcs) as:

sim

mcs

, D

) =

|mcs(G

, G

max(|G

|, |G

(1)

This results in a mcs document similarity measure in an interval [0,1], 1 if G

and G

are isomorphic and 0 if G

and G

are completely distinct.

Our implementation of mcs document similarity is based on the SimPack Java li-

brary ([12]). The SimPack accessor for Jena ontologies was extended to use instances of

classes instead of just classes as we are interested in instance similarity, not in ontology

similarity.

Besides the event annotations SENA creates additional annotations for information

that cannot be related directly to the main events mentioned in the documents but can

be of interest nevertheless such as persons or organizations mentioned. As we want to

use all annotations to compare two documents, we deﬁne a second similarity measure

that only considers these “unbound” instances.

We use a vector space model where

the extracted instances are arranged in a vector where each instance corresponds to a

dimension ([13]). The normalized frequency count of an instance c represents its weight

in the vector:

weight(c) =

|c|

ty pe(c)

(2)

These instances, of course, have also properties with literals as values and could also be treated

as graphs, but the identity reasoner described in section 2.4 makes sure that different occur-

rences of the same person, organization and location are represented by a single unique in-

stance in the knowledge base. This is why we consider these instances as single nodes.

where N

ty pe(c)

is the total number of occurrences of instances of that type.

The weight of instances from the headline of a document is boosted to accommodate

the fact that the headline often holds the most important concepts of the document. Such

instances are treated as if they appeared 5 times as often in the document. A similar

mechanism is used for re-ranking user selected concepts on retrieval (cf. section 4).

For vector space modeling also a number of similarity measures exist. We use the

cosine similarity. This measure quantiﬁes the similarity between the two vectors as the

cosine of the angle between the two vectors. The similarity of two documents D

and

with the document vectors

−→

and

−→

is then deﬁned as:

sim

cos

, D

) =

i=1

−−→

i=1

−−→

i=1

−−→

(3)

The resulting measure is also a value in the interval [0, 1].

Both similarity measures are combined to get a total similarity value for documents.

For each similarity measure sim

of a set of measures we deﬁne a weight w

to control

its inﬂuence on the total similarity value. The total similarity value is normalized to the

interval [0,1]:

sim(D

, D

) =

i=1

× sim

, D

)

i=1

(4)

In the current setup we use equal weights for w

mcs

and w

cos

In a similar way, additional similarity measure could get integrated into this frame-

work, e.g. text based document similarity measures such as TFIDF.

4 Navigating Documents

SENA is realized as a web-service. So only a browser is needed to access and use

the system. Figure 3 shows the main window of SENA’s user interface, the Document

Selection tab. A second tab (New Document) allows users to add new documents to

the repository by entering their URL. The new document is analyzed immediately and

added persistently to the repository including the extracted annotations. In the Docu-

ment Selection view the new documents are immediately available on a par with the old

documents.

The Document Selection view is made up of three major areas:

– the list of selected documents, the Selection

– the Document area displaying the actual document.

– the Navigator area to the right.

The selection list displays the selected documents with their title. The similarity or

relevance of the documents with respect to a start document the user had been viewing

before creating the selection is indicated by a numerical value. This start document

obviously always is the “most similar” selected document with a similarity value of

1. A second column shows the date, usually the publication or creation date of the

document. The ordering of documents can be changed by clicking on the Relevance

Fig. 3. SENA user interface for navigation.

or Date header to sort according to that dimension. Sorting by date corresponds to a

timeline view. The language buttons allow the user to exclude or include documents in

that language.

Clicking into the document list displays the corresponding document in the Doc-

ument area. For web documents, only the URL with the document’s annotations are

stored in the repository, not the document itself. So the document is retrieved directly

by its URL from the web when requested. The selected document becomes the start

document for further navigation.

The Navigator on the right side of the screen provides the main navigation de-

vice of SENA. Parts of the semantic annotations of the displayed document are shown

there, according to semantic categories such as event type, locations, persons and dates

mentioned. The date list contains not just the dates explicitly mentioned but also those

indirectly referenced that have been resolved by TAC. Each item is accompanied by

a relevance measure, based on the frequency, and a checkbox. The checkboxes allow

the user to select a combination of interesting items that he would like to get further

information about. Additionally, a time range for interesting documents and events can

be speciﬁed, e.g. by using the date list that is indicative of related events. The GetDocs

button then retrieves the documents according to his selection, computes their similar-

ity to the viewed document (the start document) with respect to the selected items. The

results of the retrieval then are displayed in the Selection area. From there the user can

select other documents. This way the user easily can navigate within a large set of doc-

uments by going from one document to the next along a path deﬁned by his selected

concepts and the document similarity. Logically, the user selection corresponds to a

Boolean AND query for the set of documents satisfying all the constraints.

In this ﬁrst version of SENA, the content items are displayed as ﬂat lists, giving

an incomplete view on the extracted information, as it does not exhibit the semantic

relations between the entities. E.g. that the earthquake event actually had been in Bam

(and not in Malta, also mentioned in the text) is not obvious from that ﬂat representation.

Better ways of representing the semantic information, maintaining the simplicity of use,

are under investigation.

5 Related Work

A large number of news services exist on the web that allow searching news archives.

Not only newspapers, journals or TV stations operate web portals for searching their

content, but there are also numerous cross-site news aggregators, e.g. from Google or

Yahoo. Usually they are based on some text indexing, classiﬁcation or clustering tech-

niques that deﬁne textual document similarity measures though these usually are ﬁxed

and not dependent on users’ choices. But there are also attempts to employ more seman-

tic based techniques. Most of the approaches appear to use more shallow term based se-

mantic tagging techniques, such as annotating documents with WordNet senses ([14]),

e.g. [15]. Recent examples of approaches employing semantic web ontologies and be-

ing more similar to what we are investigating in SENA are the NEWS project ([16]) and

especially the CALAIS project by Reuters ([17]) that provides a web based automatic

annotation service for news that can be integrated into applications. But, besides also

providing NER, their ontology framework seems to be more shallow than that of SENA,

resembling more classiﬁcation schemes rather than deﬁning complex domain speciﬁc

semantic objects that get instantiated by information extraction. In that, SENA’s ap-

proach is close to the research done in the ﬁeld of Topic Detection and Tracking (TDT;

[18]).

Interesting navigation functionality beyond search is provided by the Europe Media

Monitor with its NewsExplorer ([19, 20]). But technically it seems to be closer to stan-

dard text based news services rather than using a semantic web ontology framework.

Similar to SENA it offers special navigation for some classes of named entities but does

not allow selection of multiple items.

6 Conclusions and Outlook

We presented a system that provides users with easy to use navigation clues for re-

trieving related documents based on his choice of points of interest. In contrast to most

other news services SENA’s retrieval is based on semantic similarity with respect to

domain speciﬁc ontologies that get instantiated by information extraction technologies

and supports also crosslingual retrieval in a straightforward manner. First feedback from

user evaluations with news professionals in the MESH project indicates high interest in

navigation aids as provided by SENA.

SENA is at an early stage of development. For the future, improvements to the user

interface such as better visualization including the relations between entities from the

underlying RDF graph are planned. Also, additional similarity measures such as text

based measures that also support textual search will be included. An evaluation of the

similarity measures and retrieval quality is another point on the agenda.

References

1. Becker, M., Dro

nski, W., Krieger, H.U., Piskorski, J., Sch

afer, U., Xu, F.: SProUT-

shallow processing with uniﬁcation and typed feature structures. In: International conference

on NLP, Mumbai, India (2002)

2. Drozdzynski, W., Krieger, H.U., Piskorski, J., Sch

afer, U., Xu, F.: Shallow processing with

uniﬁcation and typed feature structures — foundations and applications. K

unstliche Intelli-

genz 1 (2004) 17–23

3. P

erez, G., Amores, G., Manch

on, P., Gonz

ales, D.: Generating multilingual grammars from

OWL ontologies. Research in Computing Science 18 (2006) 3–14

4. Hobbs, J.R., Pan, F.: An ontology of time for the Semantic Web. ACM Transactions on

Asian Language Information Processing (TALIP) 3 (2004) 66–85

5. Hobbs, J.R., Pan, F.: Time Ontology in OWL. W3C Working Draft 27 September 2006.

http://www.w3.org/TR/2006/WD-owl-time-20060927/ (2006)

6. Han, B., Gates, D., Levin, L.: From language to time: A temporal expression anchorer.

Proceedings of the Thirteenth International Symposium on Temporal Representation and

Reasoning (TIME’06) (2006) 196 – 203

7. Prudhommeaux, E., Seaborne, A.: SPARQL Query Language for RDF.

http://www.w3.org/TR/2004/WD-rdf-sparql-query-20041012/ (2004)

8. Sirin, E., Parsia, B., Grau, B.C., Kalyanpur, A., Katz, Y.: Pellet: A practical OWL-DL rea-

soner. Journal of Web Semantics (2006)

9. Allen, J.F.: Maintaining knowledge about temporal intervals. Communications of the ACM

26 (1983) 832–843

10. Koomen, J.A.: The TIMELOGIC temporal reasoning system. Technical Report Technical

Report 231, Computer Science Dept., University of Rochester (1989)

11. Bunke, H., Shearer, K.: A graph distance metric based on the maximal common subgraph.

Pattern Recognition Letters 19 (1998) 255–259

12. Bernstein, A., Kaufmann, E., Kiefer, C., B

urki, C.: SimPack: A Generic Java Library for

Similiarity Measures in Ontologies. Technical report, Department of Informatics, University

of Zurich (2005)

13. Salton, G., Wong, A., Yang, C.: A vector space model for automatic indexing. Communica-

tions of the ACM (1975) 613–620

14. Fellbaum, C., ed.: WordNet: An Electronic Lexical Database. Cambridge/Mass.: MIT Press

(1998)

15. Oleshchuk, V., Pedersen, A.: Ontology based semantic similarity comparison of documents.

In: Proc. 14th International Workshop on Database and Expert Systems Applications. (2003)

735–738

16. Bernardi, A.: News engine web services. http://www.dfki.uni-kl.de/ berhardi/News (2004)

17. OpenCalais: Calais. http://www.opencalais.com (2008)

18. Allan, J., ed.: Topic Detection and Tracking: Event-based Information Organization.

Springer (2002)

19. EMM: Europe news monitor: News brief. http://emm.jrc.it (2007)

20. EMM: Europe media monitor: News explorer. http://press.jrc.it/NewsExplorer (2007)
