Towards a Framework for Integrated Natural Language

Processing Architectures for Social Robots

Matthias Scheutz

and Kathleen Eberhard

Human-Robot Interaction Laboratory, Cognitive Science Program

Indiana University, Bloomington, IN 47401, U.S.A.

Department of Psychology, University of Notre Dame, Notre Dame, IN 46556, U.S.A.

Abstract. Current social robots lack the natural language capacities to be able

to interact with humans in natural ways. In this paper, we present results from

human experiments intended to isolate spoken interaction types in a search and

rescue task and brieﬂy discuss implications for NLP architectures for embodied

situated agents.

1 Introduction

Natural language processing on robots is currrently achieved in a sequential fashion,

where interpretations are built from utterances in a sequence that mirrors the different

linguistic abstractions. Yet, the sequential approch is very different from how humans

process language. The implications for human-robot interactions are that robots need

a different processing architecture with different processing algorithms if they are to

interact with humans in natural language in natural ways, for the properties of the hu-

man language processing system allows for interaction types that sequential processing

systems do not permit. For example, in natural human language interaction, the listener

often signals his/her understanding of the speaker’s utterance via backchannels or feed-

back (e.g., head nods, “uh huh” or “mhm”), which overlap with the speaker’s utterance

at precise points. For such feedback to occur before an utterance has ﬁnished, a language

processing system must be able to generate partial semantic interpretation on an incom-

plete sentence. Similarly, human listeners initiate various language-drivenactions, from

changing eye gaze, to head movements, to gestures and other bodily movements, while

the speaker has not ﬁnished the utterance. Again, being able to initiate actions based on

partial sentences (e.g., looking for referents described by referential phrases) requires a

system to be able to determine partial meanings.

In this paper, we will ﬁrst review some of the psycholinguistic work that analyzes

the coordinated goal structure of language interactions as well as the mental processing

that underlies rapid incremental comprehension in the face of ambiguity. We then sum-

marize some of the implications for language processing on robots. We will present a

human experiment that required two individuals to coordinate with each other via re-

mote audio communication in order to achieve several task goals in a timely fashion.

Scheutz M. and Eberhard K. (2008).

Towards a Framework for Integrated Natural Language Processing Architectures for Social Robots.

In Proceedings of the 5th International Workshop on Natural Language Processing and Cognitive Science, pages 165-174

DOI: 10.5220/0001741001650174

 SciTePress

The results are analyzed with respect to (a) the structure of dialogue that facilitated

versus interfered with effective coordination, and (b) the content and form utterances

that present challenges to successful comprehension in a remote communicative situ-

ation. We conclude with a brief discussion of the implications of our results for NLP

architectures for embodied situated agents.

2 Background

Clark (1996) views human language use as a joint project consisting of 4 hierarchical

levels of speaker-addressee coordinated actions, which he refers to as an “action lad-

der”. Consider the case of a speaker asking an addressee, “What is the current time?”.

At the ﬁrst level, the speaker executes a communicative behavior, which consists of

producing the sounds of the utterance. The addressee, in turn, attends to the behav-

ior (speech). At the second level, the speaker presents words and phrases, which are

identiﬁed as such by the addressee. At the third level, the speaker signals an intended

meaning (a request for the current time), and the addressee understands the meaning. At

the fourth level, the speaker proposes a joint project, namely that the addressee inform

him of the current time, and the addressee considers accepting the proposal. There are

two essential properties of this hierarchy of actions. The ﬁrst is upward causality: The

actions at a lower level cause the actions at the next level up. The second property is

downward evidence: Evidence of successful completion of the actions at a higher level

constitutes evidence of successful completion of the actions at all levels below it.

As Clark (1996, p. 222) states, “A fundamental principle of any intentional action

is that people look for evidence that they have done what they intended to do.” Fur-

thermore, people strive to provide evidence that is sufﬁcient for current purposes, in a

timely manner, and with the least effort. In the example above, valid, timely, and suf-

ﬁcient evidence comes from the addressee responding with the current time soon after

the end of the speaker’s utterance. In doing so, the addressee provides positive evidence

of her acceptance of the speaker’s proposed joint project at level 4, as well as posi-

tive evidence of her understanding the meaning of the speaker’s utterance (level 3), her

identiﬁcation of the speaker’s words (level 2), and her attending to the speaker’s speech

(level 1). In other words, the evidence allows both the speaker and addressee to reach

the mutual belief of success at all four levels well enough for current purposes, which

is the process of grounding.

Often, a joint project may be extended across a sequence of utterances, as in the case

of telling a story, or providing a complex response to a question, or giving a complex

direction, where complexity refers to number of propositions or informational units. In

these situations, each utterance is an iteration through the ﬁrst 3 levels, and positive

evidence at level 3 (understanding) is provided by addressees in the form of acknowl-

edgments, which may be verbal (e.g., yes, uh huh, mkay, okay) or nonverbal (head

nods). Acknowledgments may occur on a separate turn or they may overlap with the

speaker’s utterance (i.e., Yngve’s (1970) backchannels).

Most psycholinguistic research as well as research in developing artiﬁcial natural

language processing systems has focused on the processes involved at the ﬁrst 3 lev-

els of action (i.e., producing and perceiving a speech signal, identifying words and the

166

phrase structure, understanding the propositional content of the utterance, including the

establishment of referents). The former research has shown that humans rapidly inte-

grate bottom-up constraints from the linguistic input, such as the sounds, words, syntax,

and semantics with top-down constraints from the discourse and pragmatic context,

such as the set of possible referents (e.g., [1]) and expectations about the speaker’s

communicative goals (e.g., [2]). The strength of both the linguistic and contextual con-

straints depends on their availability. The availability of linguistic constraints is affected

by the clarity of the acoustical signal, the ﬂuency and rate of speech, the frequency of

the words, the speciﬁcity of their meaning, and the frequency, complexity and speci-

ﬁcity of syntactic structure. The availability of contextual constraints is determined by

the “quality of evidence” for the bases of the speaker’s and addressee’s common ground

[3] or shared knowledge. The quality is high when, among other things, both the speaker

and addressee know the goal structure of the communicative task, and the set of rele-

vant referents is visually co-present (e.g., [4]. Importantly, the availability of linguistic

constraints interacts with the availability of contextual constraints in the incremental

construction of an interpretation [5], such that when the linguistic constraints are weak

or underspeciﬁed there will be greater reliance on contextual constraints [6]. Further-

more, speakers are likely to produce weakly underspeciﬁed utterances when there are

strong contextual constraints for their interpretation (i.e., when there is reliable evi-

dence for the speaker’s and addressee’s common ground). For instance, in face-to-face

conversations about visually co-present referents, speakers may use short deictic ex-

pressions accompanied by indicative gestures (e.g., saying, “move the box over there”,

while pointing to the location that is the referent of “there”) [7, 4].

3 Experiment and Results

To be able to isolate the design principles that are required for an NLP system for robots

that interact with humans in natural ways, we designed a human experiment in which

two individuals must coordinate with each other via remote audio communication to

accomplish several tasks. In particular, one person, the “director”, direct the other per-

son, the “member”, through an unfamiliar environment to locate and perform various

actions on target objects scattered throughout the environment. In the following we will

ﬁrst describe the experimental task, and the report some of the ﬁndings that are useful

for extracting principles of the processing architecture.

The chosen task is a team search task where two humans, who are not co-located

in the same physical space, must coordinate their actions using natural language to

accomplish several goals within a limited amount of time. One individualis assigned the

role as the director, the other is assigned the role of member. Neither was familiar with

the search environment, which consisted of several (cluttered) rooms and a surrounding

hallway. The director was seated at a table in a quiet room outside of the environment.

S/he wore headphones and a microphone for communicating with the member. The

member wore a helmet ﬁtted with a camera for recording the visual scene (not viewable

to the director), and a microphone and headphones for communicating with the director.

167

3.1 Procedure

At the beginning of the experiment, both the director and member were told that the

director would be given a map of the search environment, which consisted of all rooms

with open doors. The director was told that s/he would have to remain seated at a table

in a room that was external to the search environment. They were told that the direc-

tor’s map showed the locations of a cardboard box, a number of blue boxes containing

colored wooden blocks, and 8 empty pink boxes. They were also informed that the

lab environment contained 8 empty green boxes, which were not shown on the map.

They were told that there were several tasks that needed to be completed as quickly as

possible:

1. The member was to tell the leader the location of each of the 8 green boxes, which

had numbers written on them. The leader was to mark the map with the location of

the green boxes by writing their number on the map.

2. The leader was to direct the member through the environment to the location of the

cardboard box, which the member was to retrieve.

3. The member wasto then empty the blocks in all of the blue boxesinto the cardboard

box, leaving the blue boxes in their location. The leader was to assist the member

with ﬁnding the blue boxes by giving directions to them from the map. However,

they were informed that some of the locations of the blue boxes on the map would

be inaccurate, and that the map did not show the location of all of the blue boxes.

4. They were told that instructions for the pink boxes would be given at some point

during the task.

The director and member were told that each would receive $5.00 for participat-

ing in the experiment and that each would receive an extra $5.00 if they successfully

completed all of the tasks. After a sound check, the member began walking through the

environment.

After 5 minutes, the experimenter interrupted the director and informed him of the

task for the pink boxes: Each of the blue boxes contained a yellow block, and the mem-

ber was to place one yellow block into each of the 8 pink boxes. In addition, the team

had only 3 minutes left in which to complete all of the tasks (recording the location of

the green boxes on the map, emptying the blocks from the 8 blue boxes into the card-

board box, and putting one yellow block into each of the 8 pink boxes). A cooking timer

with an audible ticking sound was set to 3 minutes and placed on the table in front of

the director. Then the experimenter left the room. The experiment ended when the bell

on the timer rang.

3.2 Results

There were 7 pairs of subjects run in the experiment. The ﬁrst pair was eliminated

because of problems with the audio recording equipment at the beginning of the experi-

ment. The second pair was eliminated because of poor audio recording. Thus, data were

collected for the 5 remaining pairs.

The results in Table 1 show that, with the exception of Team #5, there is no relation

between the number of green and blue box tasks completed during the 1st 5 minutes

and the grand total at the end.

168

Table 1. Table showing the number of tasks involving the green, blue, and pink boxes that were

successfully completed by each team. The maximum number for each type of box is 8. The teams

are sorted according to the total number of tasks completed. *Team #5 was the only team that did

not retrieve the cardboard box (for collecting the blocks from the blue boxes) before the 3 minute

warning.

1st 5 min. Last 3 min.

Team green blue* green+blue green blue pink Tl green Tl blue TOTAL

7 4 6 10 3 2 8 7 8 23

4 8 1 9 - 6 6 8 7 21

6 6 2 8 0 4 6 6 6 18

3 8 2 10 - 3 2 8 5 15

5 7 0 7 1 2 2 8 2 12

Dialogue Structure. The interactions between the pair that was most successful in

completing the task goals (Team 7) were compared with the interactions between the

pair that was least successful (Team 5) in order to identify structures of dialogue that

characterize effective vs. ineffective coordination, respectively.

For all teams, at the beginning of the experiment the nature of the task resulted in the

overarching goal in which the director uses his/her map to direct the member through

the multi-room environment to the location of the cardboard box, and an embedded

goal, in which the member reports the location of each green box as it is encountered

along the way. Thus, following Clark’s (1996) 4-level “action ladder” framework, the

overarching goal was an extended joint project requiring a sequence of directive ut-

terances that were subordinate joint projects, and the grounding of which required the

director and member to reach mutual belief of the member’s location in the environ-

ment.

Team 7’s dialogue begins with the director (D) proposing the overarching goal and

the member (M) acceptance of it:

Example from Team #7:

1 D: from this first hole do you wanna get the cardboard box?

2 M: yes

3 D: alright let’s do it

The embedded goal resulted in multiple individual joint projects, the grounding of

which required the director and member to reach mutual belief that the director suf-

ﬁciently marked the location of a green box on his/her map. One aspect of Team 7’s

dialogue that made it effective was that the addressee routinely provided evidence of

understanding the speaker’s direction as well as evidence of when the directed action

(joint project) was completed. This routine may have been encouraged by the director’s

explicit request for the latter evidence during the exchange that constituted the ﬁrst sub

joint project of the overarching goal:

Note that all subsquent transcriptions are verbatim and include disﬂuencies (false starts, re-

pairs, etc.). Pauses are indicated by periods and syllable lengthenings, such as pronouncing

“the” as “thee”, are indicated by a colon following the vowel that is lengthened, e.g., “the:”.

169

Example from Team #7:

4 D: um . go straight through the room you’re in to an open door

that’s right across from you

5 M: alright

6 D: let me know when you get there

7 M: I’m at-I’m at the open door

So, in line 5, the Member’s response acknowledges understanding and acceptance

of the director’s direction (sub joint project). In line 6, the director explicitly requests

verbal evidence from the member of the completion of the directed movement. The

member does provides this evidence in line 7, and, furthermore, his description of his

location provides more reliable evidence than simply providing evidence in the form of

acknowledgment such as “okay”.

The sequence above continues below, with an embedded joint project in which the

member describes the location of a green box that is to be marked by director on the

map. Like the exchange above, but with the director and member’s roles reversed, the

director provides evidence of understanding the member’s description, by repeating

it, followed by an acknowledgment by the member, and then the director providing

evidence of the action’s completion:

Example from Team #7:

8 D: okay go through the open door and towards the steps that are

right in front of you before the steps take a . take a right

9 M: okay . uh right-right on the steps there’s a green box

number two

10 D: oh number two right on the steps

11 M: yeah

12 D: okay I got it

Note that the Member’sutterance in line 9 simultaneous proposes an embedded joint

project (marking the location of a green box on the map) but also provides evidence of

the completion of the sub joint project proposed by the director’s utterance in line 8.

That is, upon completion of the embedded joint project, the director can assume that

the member’s location is near the steps. Thus, the director’s proposal of the next sub

joint project begins with that assumption:

Example from Team #7:

13 D: alright . if you’re looking at the steps you take a right

there should be another open door

14 M: so don’t actually go up the steps

15 D: don’t actually go up the steps

16 M: okay

17 M: yep I see the door

The exchange above also contains a side sequence that is initiated by the Member’s

request for clariﬁcation in line 14. The side sequence ends with the member’s acknowl-

edgment in line 16 of the director’s clariﬁcation in line 15, and the sub joint project is

completed with the member’s description of the door in line 17.

Unlike Team 7, Team 5’s dialogue lacks orderliness in providing evidence of both

understanding a proposed joint project and its completion. This is illustrated in the ﬁrst

two lines of the transcript below, where the member neither requests nor receives evi-

dence from the director of his understanding and acceptance of her description of the

170

location of the third green box in line 33 (i.e., an embedded joint project). More im-

portantly, however, as the complete exchange below shows, there was no established

agreement between the director and member on achieving the overarching goal of lo-

cating and retrieving the cardboard box by having the director direct the member to the

box’s location. Speciﬁcally, this agreement does not occur until line 47 in the transcrip-

tion below, which occurs approximately 3.5 minutes into the task. Until that point, the

member simply provided descriptions of her movement through the environment along

with descriptions of the location of green boxes (the embedded goal/joint project).

Example from Team #5:

33 M: Okay I’m going forward and then taking a right and the first

bo-in the f-to the first room there . so: right now I’ve got

um a green box number three on the chair on my right

it’s-it-as soon as I’m in the doorway I’m facing forward

green box on my right

34 M: and there’s also a blue box on my right but I don’t have the

brown box yet so I’m gonna turn around and keep looking for

the brown-or go back and look for the brown box or somethin

35 D: alright the brown box-let me-alright t-two questions for you

now you said you walked in u:h you walked in that- that room

which is . to the right of the doorway

36 M: uh huh

37 D: now you said as soon as you walked in, there was a chair on

your right hand side?

38 M: yep

39 D: with it-so it’s basically on the wall where the door is

40 M: it’s a little bit off the wall but it’s like maybe my foots

worth of a distance between the

41 D: mkay

42 D: alright and that’s number three

43 M: yes

44 D: alright there’s a blue box in that room

45 M: yes

46 D: and you said that-uh the cardboard box is-is basically all

the way to the end so should I-should I se-should I send

you-do you want me to send you to where the cardboard box is

and then we can backtrack

47 M: u:m yeah that’s fine

Having established the overarching goal as well as established mutual belief as to

the member’s current location in the environment, the exchange above continues with

the director proposing the ﬁrst sub joint project, followed by the second. The member

provides evidence for both in the form of an acknowledgment, which is ambiguous with

respect to being evidence for level 3 (understandingthe direction) or level 4 (acceptance

and completion of the directed action). This ambiguity results in a side sequence in

which the director requests clariﬁcation with respect to the member’s current location:

Example from Team #5:

48 D: alright . uh so you’re gonna wanna go back-step back out of

the room you were just in

49 M: uh huh

50 D: and continue in through that doorway that was on your left

51 M: uh huh

52 D: u:h . are you in that room already?

53 M: yep

At this point, which is slightly more than 4 minutes into the task, the member pro-

poses explicitly establishing of agreement on the embedded goal of her informing the

director of the location of the green boxes.

171

Example from Team #5:

54 M: I actually see like three more green boxes do you want

those now or do you want those later

55 D: uh whatever you wanna do we can stop and get those on

the way if you want

56 M: okay let’s just do that now

The member continues with proposing an embedded joint project (description of

the location of a green box); however, the complexity of her proposal results in a

side sequence initiated by the director who needs further clariﬁcation before accept-

ing/completing the embedded joint project:

Example from Team #5:

57 M: so as I walked in I go to the room on my right there’s two

filing cabinets on the second filing cabinet there’s box

number four green box number four

58 D: alright as-the second one close to the wall that you are

entering in

59 M: I walk in there’s one on my right and then there-I just

make another step it’s-it’s the second one on my right so

this is gonna be the second one

60 D: alright and that’s number four you said?

61 M: yes

62 D: okay

3.3 Content and Forms of Utterances

As the example transcripts above illustrate, disﬂuencies were the norm, not the excep-

tion, which are potential impediments to the director and member’s successful ground-

ing of understanding. The disﬂuencies include frequent pauses within utterances often

signalled with the ﬁllers “um” or “uh”. In addition, there are numerous repairs (e.g.,

“the ﬁrst bo-in the f-to the ﬁrst room”), false starts/repetitions (e.g., “it’s-it’s the second

one on my right”, “uh right-right on the steps”, “so should I-should I se-should I send

you do-you want me to send you”), and omissions of words (e.g., “I’m facing forward

green box on my right”), which result in ungrammatical utterances. There also are in-

stances of uncorrected speech errors such as substituting the words “block” and “book”

for the intended word “box”.

In addition, there are numerous examples of lexically ambiguous words, most no-

tably, the word, “right”, which often would occur several times within a sequence of

utterances, with each occurrence correspondingto a differentmeaning (i.e., an acknowl-

edgment (correct), a direction (vs. left), and an intensiﬁer (right there)).

Example from Team #5:

M: alright . okay I’m going forward and then taking a right and

the first bo-in the f-to the first room . there so: right now

I’ve got um a green box number three on the chair on my right

it’s-it-as soon as I’m in the doorway I’m facing forward green

box on my right.

Much of the ambiguity in the linguistic input can be resolved by the contextual and

pragmatic constraints resulting from the director and member’s shared knowledge of

the task’s goals and their shared knowledge of the environment and referents in it that is

provided by the correspondence between the director’s map and physical environment.

172

3.4 Implications for NLP Architectures for Natural spoken Language

The main implications for designing a natural language processing architecture for

robots is that, different from the standard picture of constructing meanings out of sen-

tences, meanings are obtained from interactions that serve particular purposes and ac-

complish particular goals. Language here serves a coordinating role in establishing a

joint project and humans deﬁne those projects, agree on them, and keep track of them

until they are accomplished or the goal structure changes. The goal structure can also

be seen as imposing constraints on the natural language processing system that allows

for dealing with disﬂuencies and ambiguity of various kinds. Moreover, perception,

action, and language processing are all instrinsically intertwined, sometimes involv-

ing complex patterns of actions, utterances and responses, where meaningful linguis-

tic fragments result from their context together with prosodic, temporal, task and goal

information, and not sentence boundaries. An NLP architecture for robots, therefore,

needs to be able to process language in the same kind of interactive, goal-oriented

way that humans use; this includes the timing of utterances, non-linguistic informa-

tion, backchannel feedback, and any other component involved in establishing meaning

(for a ﬁrst step towards implementing some of these principles, see [8–12]).

4 Conclusions

In this paper, we argued that processing multiple linguistic, perceptual, and contex-

tual constraints incrementally and determining partial meanings to be able to provide

backchanneling feedback and initiate actions early is of critical importance for robots

that are supposed to interact with humans in natural language in natural ways. We re-

ported results from human experiments in a search task that demonstrated these and

other important principles that can be used for specifying a natural language processing

architecture for robots which will allow robots to engage in more human-like interaction

patterns.

Acknowledgements

This work was in part funded by an ONR MURI grant N00014-07-1-1049 to both au-

thors.

References

1. Chambers, C., Tanenhaus, M., Magnuson, J.: Actions and affordances in syntactic ambigu-

ity resolution. Journal of Experimental Psychology: Learning, Memory, and Cognition 30

(2004) 687–696

2. Hanna, J., Tanenhaus, M.: Pragmatic effects on reference resolution in a collaborative task:

Evidence from eye movements. Cognitive Science 28 (2004) 75–88

3. Clark, H.H.: Using Language. Cambridge University Press, Cambridge (1996)

4. Clark, H., Krych, M.: Speaking while monitoring addressees for understanding. Journal of

Memory and Language 50 (2004) 62–81

173

5. Tanenhaus, M., Trueswell, J.: Sentence comprehension. In Miller, J.L., Eimas, P.D., eds.:

Handbook of Perception and Cognition. Vol 11: Speech, Language, and Communication.

Academic Press, Orlando (1995) 217–262

6. Reason, J.: Human Error. Cambridge University Press, New York (1990)

7. Bangerter, A.: Using pointing and describing to achieve joint focus of attention in dialogue.

Psychological Science 15 (2004) 415–419

8. Brick, T., Scheutz, M.: Incremental natural language processing for hri. In: Proceedings of

the Second ACM IEEE International Conference on Human-Robot Interaction, Washington

D.C. (2007) 263–270

9. Brick, T., Schermerhorn, P., Scheutz, M.: Speech and action: Integration of action and lan-

guage for mobile robots. In: Proceedings of the 2007 IEEE/RSJ International Conference on

Intelligent Robots and Systems, San Diego, CA (2007) forthcoming

10. Scheutz, M., Schermerhorn, P., Kramer, J., Anderson, D.: First steps toward natural human-

like HRI. Autonomous Robots 22 (2007) 411–423

11. Scheutz, M., Schermerhorn, P., Kramer, J., Middendorff, C.: The utility of affect expression

in natural language interactions in joint human-robot tasks. In: Proceedings of the 1st ACM

International Conference on Human-Robot Interaction. (2006) 226–233

12. Scheutz, M., Eberhard, K., Andronache, V.: A real-time robotic model of human reference

resolution using visual constraints. Connection Science Journal 16 (2004) 145–167

174
