A Multi-Dimensional Classification for Users of Security

Patterns

Michael VanHilst

, Eduardo B. Fernandez

and Fabrício Braz

Florida Atlantic University, Department of Computer Science and Engineering

777 Glades Road, Boca Raton, Florida 33431, U.S.A.

Universidade de Brasília, Departamento de Ciência da Computação, Campus

Universitário - Asa Norte, 70910-900 Brasília - DF - Brazil

Abstract. This paper presents a classification for security patterns that ad-

dresses the needs of users. The approach uses a matrix defined by dividing the

problem space along multiple dimensions, and allows patterns to occupy re-

gions, defined my multiple cells in the matrix. It supports filtering for narrow or

wide pattern selection, allows navigation along related axes of concern, and

identifies gaps in the problem space that lack pattern coverage. Results are pre-

liminary but highlight differences with existing classifications.

1 Introduction

Computer application security is no longer an option; it is a necessity. Our well being

depends on an interconnected and ever growing web of information systems and

applications. Threats to those systems are real with the potential for dire conse-

quences. Threats come from all directions – external, internal, accidental, intentional,

and highly organized. Any point can be exploited; comprehensive security is not easy

to achieve.

Security must be addressed for all components in all activities in all phases of the

software lifecycle. For complex applications, a comprehensive approach to security –

top-to-bottom, beginning-to-end, and everywhere-in-between – is a requirement. The

problem is vast. Inspection and testing is only a small part. Building secure software

involves more than plugging holes.

The security challenge is compounded by the way real world applications are built.

Consider the issues of component source and standards compliance. Components can

come from new code, legacy application, commercial-off-the-shelf, open-source,

remote web service, reuse library, runtime script, wizard code generation, model

transformation, and outsourced development. It is a rare and inefficient project that

doesn’t leverage more than a couple of these sources. Development, design, and dep-

loyment must comply with multiple standards, including FISMA [10], HIPAA [13],

Sarbanes/Oxley [24], and Graham-Leach-Bliley [11]. Amidst this complexity, the

focus on security must be maintained.

VanHilst M., Fernandez E. and Braz F. (2008).

A Multi-Dimensional Classiﬁcation for Users of Security Patterns.

In Proceedings of the 6th International Workshop on Security in Information Systems, pages 89-98

DOI: 10.5220/0001741300890098

 SciTePress

In our work, we have come to the conclusion that a single end-to-end methodology,

by itself, cannot realistically address all the security concerns in every situation and

variation a developer is likely to face. While a systematic approach is essential, it

must be augmented by the delivery of focused elements of security knowledge when

and where they are needed.

We address the problem of secure software development through the use of pat-

terns. Patterns are well known solutions to common problems in given contexts. Pat-

terns make it possible for developers looking at a specific problem or task to benefit

from the experience of others in a conveniently packaged form. While the best known

patterns are design patterns, we develop security patterns for a wide range of con-

cerns and many different phases of the software life cycle [4, 6, 23].

There are several groups developing security patterns [27, 28]. Many books on se-

curity also package material in the form of patterns [28]. With so many patterns now

available, it ought to be possible for software developers to find patterns for just

about any phase, activity, and need. But how do developers find patterns that are

relevant to what they are doing? Are all concerns covered, and if not, where are the

gaps?

Traditional pattern classification serves pattern collectors’ need to determine the

extent to which a new pattern is the same as other patterns in the collection. Such

classifications are typically hierarchical [8, 9, 12, 30], and based on the solution being

presented rather the problems being addressed [12]. Existing classifications mimic

classification in biology, where hierarchical classification enables identification by

following a decision tree (e.g. Does it have a backbone?) and conforms to a view of.

speciation by mutation from a parent gene. But biological classification is not in-

tended for the consumer (e.g. Does it offer taste and protein to complement my

menu?), and, not surprisingly, yields little value on a trip to the grocery store. Simi-

larly, traditional pattern classification is ill suited to the needs of developers.

The remainder of the paper is classified as follows: Section 2 gives an overview of

our approach, describing the matrix of concerns, its theoretical foundation, and how it

differs from existing classifications based on hierarchies and tagging. Sections 3 and

4 provide more details about the dimensions of the matrix and their use. Section 5

gives some preliminary observations and an example of its use, while Section 6 dis-

cusses related work.

2 Matrix of Concerns

We propose to address the problem of pattern classification and problem coverage

through the use of a multi-dimensional matrix of concerns. Each dimension of the

matrix is a list of concerns along a single continuum, defined by a common set of

distinctions. A single dimension thus addresses a simple logical concept. The catego-

ries within the dimension should be easily understood and represent widely used and

accepted classifications within that concept. For example, one dimension would be a

list of life-cycle activities, covering domain analysis, requirements, problem and solu-

tion analysis, design, implementation, integration, deployment (including configura-

tion), operation, and maintenance. The list of component source types, described

earlier, forms another dimension. Types of security response could form yet a third

dimension, covering avoidance, deterrence, prevention, detection, mitigation, recov-

ery, and investigation (or forensics).

Cells at the intersections of two or more dimensions represent a concern that is

more specific than would be expressed by the list of classifications in any one dimen-

sion. For example, with two dimensions we can target security patterns for require-

ments when using COTS or for outsourced components. Similarly, we can target

security patterns for analysis and design with web services, and of those, more specif-

ically, patterns that address detection or recovery.

The design of the matrix is motivated by a notion of coverage of concerns. For se-

curity, coverage must be comprehensive. Security must be addressed in every activity

of every role in every phase. Security must be addressed in every component at every

level of architecture. Security must also be addressed at every transition or interface.

Security must be appropriate to every language, platform, and domain. Security must

be addressed in depth, with all forms of response. Security is more than a few choices

– it applies to everything. We express coverage as a grid or matrix of concerns, where

comprehensive coverage would mean there is something for every cell at every inter-

section of every dimension.

Our approach starts with a complete problem space, and then carves it into differ-

ent concerns along different dimensions. Each dimension should be logically cohe-

sive with simple, well understood distinctions over a single continuum or whole. By

treating classification as a partitioning, we never loose sight of the whole. In logic,

the drawing of a distinction defines both that which is included, and that which is not.

In contrast, when classification starts with a known, but unstructured collection of

items, and puts them into groups, there is no way to know what is missing. We view

coverage of concerns as a complement to separation of concerns in top-down decom-

position.

Developers can identify their current focus or concern by choosing the applicable

element, or range of elements, along each dimension, and then looking for patterns

that fall into the intersection of all. In this sense, it is no different than tagging pat-

terns with identifier keys and using the tags to search. But there are several important

distinctions. First, by defining tags along continua in an n-dimensional space, the

developer can navigate to adjoining, and thus related, regions of the space for related

patterns, added context, and deeper understanding. Second, by looking at the number

of cells a pattern covers, and the region they represent, developers gain insight into

not only the degree of generality, but also the type of generality the pattern entails.

Third, by looking at regions and cells where “tagged” patterns are missing, pattern

developers can identify gaps that have yet to be addressed.

The use of a concern matrix is not specific to any methodology. Developers in any

method can use concern matrices to better identify tasks and concerns and to locate

patterns relevant to a specific concern. A chosen method dictates the sequence and

timing of certain tasks, while the matrix provides guidance to more specific know-

ledge or ideas for how to perform the tasks. This approach is consistent with, for

example, McGraw’s notion of security “touch points” [19].

The matrix can be easily extended to adapt to new technologies and concerns. En-

tries can be added along existing dimensions, or new dimensions added entirely. In

essence, there is one comprehensive matrix with all dimensions and all elements of all

dimensions. All other matrices are subsets of the one, collapsed or filtered along dif-

ferent dimensions. Extending the matrix does not obsolete earlier matrices – they just

don’t include as many distinctions.

2.1 Primary Dimensions

Primary dimensions are generally useful and should be considered in any classifica-

tion. We also consider secondary dimensions which identify or bring focus to addi-

tional concerns that may be useful in some cases, but need not be in focus for others.

Later on, we also introduce a concept of auxiliary dimension. An auxiliary dimension

presents a list of concerns that may be useful for ranking or scoring patterns, like a

checklist, but do not divide the space along a continuum, for concern navigation or

subdividing tasks.

Earlier, we introduced three dimensions for classifying security patterns: lifecycle

stage, component source, and security response type. In our work so far, we have

found six primary dimensions to be of value. The remaining three dimensions are

domain, architecture layer, and level of constraint.

Application domain can provide an important differentiator or filter to narrow the

field of applicable knowledge. Some solutions are specific to a particular domain or

application type. Ubiquitous computing, e-commerce, and SCADA (sensing and

control) all pose distinct security challenges. For example, security for 3-Tier busi-

ness applications may differ from solutions for SCADA systems of sensors and con-

trols. Organizations can create patterns for their own domain, following a template, as

a form of knowledge capture. The concern matrix provides a useful and easy way to

organize such patterns and position them within the context of other patterns.

Architectural layer provides another useful dimension, since problems and their so-

lutions in different layers of the architecture differ, yet all are important. Roughly the

same architecture continuum has been divided in different ways for communication

protocols, business systems, and execution environments, but always with an ordering

from low to high level of abstraction, and from network to platform to application.

Combining elements from each, and allowing for overlap between views, we chose

the following distinctions: network, transport, distribution (including gateways and

brokers), operating system, data, business logic, and client. The simpler notion of an

application layer spans the last three layers in our model. Since patterns can be placed

in more than one cell, there is no real need for exact or disjoint classification.

Leveson defines four levels of constraint: regulatory, organizational, opera-

tor/developer, and mechanism. In Leveson’s work on system safety [17], each level

of constraint plays an important role in safety failures and their prevention. By exten-

sion, we use the same levels for security. The Common Criteria has functional re-

quirements that apply at the level of mechanisms [1]. But it also has assurance re-

quirements that concern organizational processes to document actions taken. The

development of a configuration management plan is a Common Criteria assurance

requirement that applies at the organizational level in the lifecycle stage of domain

analysis. The Common Criteria and other standards such as SOX and SSE-CMM [29]

themselves belong at the regulatory level.

2.2 Secondary and Auxiliary Dimensions

We did not include testing in the lifecycle stages since testing is an orthogonal con-

cern that applies to all stages. But the lifecycle stages, in turn, can all be subdivided

by the application of another dimension, with elements for preparation, execution,

validation/verification, and transition (to another stage). This added granularity not

only creates a placeholder for testing and formal verification, but, for the purpose of

verifying coverage, it elevates all of the distinctions in this secondary dimension, and

their concerns, within each of the software lifecycle stages.

Collections of security practices often include a list of security principles, like the

principle of least privilege. Viega and McGraw [31], for example, use a list of 10

security principles, while in [28] there are 12. OWASP [21] lists 15 principles, as

well as 10 secure coding principles, 20 weaknesses or vulnerabilities and 12 counter-

measures. Such lists do not really divide up the problem space. But they could pro-

vide an auxiliary dimension to rank solution patterns, based on how many and which

principles they apply or address.

A danger in composing point solutions occurs at the interface between components

of the solution. For example, in a heterogeneous system, some parts may be .NET

while others are J2EE. New code may interface to a legacy system or interchangeable

web services. On a different dimension, subsystems may be formed by combining

outsourced with legacy code. Unique security issues may occur at the interface, where

the two interact or coexist. The matrix can be used to isolate and document interface

issues by replicating an axis, orthogonal to itself. The resulting 2-dimensional slice is

analogous to a mileage chart, with lists of cities on both axes. Chart elements

represent interfaces between corresponding components: outsource to legacy, legacy

to web service, .NET to J2EE, etc.

3 Usage Experience

We are currently applying our matrix to a classification of security patterns for Ser-

vice Oriented Architecture. The results, however, are preliminary and will be pre-

sented in a later, separate paper. Here, we discuss only a few observations.

Classification is proving to be quite easy. The classifications were chosen to be

easily understood. Experience bears this out. Patterns are mapped in the same way

they would be tagged. Each dimension is considered separately. Patterns are identi-

fied at the point in each dimension, and thus the matrix, where their content affects

decisions that will be made. If the distinctions of a dimension are not relevant, for

example, if the pattern is not specific to any domain but applicable to all, then its

classification on that dimension is “all.”

Fig. 1 illustrates a mapping of design patterns to lifecycle phase and different le-

vels of architecture. Only a small sample of patterns is shown. While all of the pat-

terns in the figure are applicable to Service Oriented Architecture, some apply more

generally to other domains, as well. We grouped the patterns within Design along a

secondary dimension with Access Control and Authentication. A developer might

navigate to adjoining Analysis phase cells (not shown) and look for general patterns

on Access Control and Authentication. In the figure, we show patterns from the Do-

main Analysis phase, where the developer would find patterns that explain the do-

main standards and technologies later used in the design phase. While the patterns are

found in these locations in the matrix, understanding their role in a system, and how

they relate to one another, still requires a pattern language diagram and other tools

and methods for pattern application.

Fig. 1. A small sample showing patterns found in a 2D snippet of the matrix.

Many of the patterns we have looked at appear also in [28]. Steel et al. grouped their

patterns only according to the layers in a 4-tier architecture, while we, of course, have

applied more distinctions. A number of differences can be observed. By forcing each

pattern to occupy only one cell, important information was lost or distorted. For ex-

ample, in [28] Yoder and Barclow’s Checkpoint was identified as a Client (Web)

pattern, and merged with the Open Group’s Checkpointed System pattern as one of a

group of checkpoint patterns in the same cell. In our classification, Checkpoint is an

analysis phase pattern applicable to all three application layers and addresses a gener-

al approach to prevention, while Checkpointed System is a design phase pattern ap-

plicable to the client layer and addresses a mechanism for recovery. The two patterns

are quite different.

The Open Group presents a number of security patterns together with a methodology

for their application [2]. But they classify their patterns into only two groups: Availa-

ble Systems Patterns, and Protected Systems Patterns. Their approach assumes that

Application

Firewall

Reference

Monito

Authenticator

OS Ref.

Monito

Authen

icato

SAML

Authenticato

Remote

Authenticato

Proxy

Firewall

Packet Filter

Firewall

XACML

Access

XML

Firewall

Application

Operating

System

Distribution

Transport

Network

TLS

IPsec

SAML

Domain

Analysis

Access Control Authentication

Design

the domain and problem analysis are already understood. Our matrix shows that their

approach offers quite good coverage with design solutions for components and low

level code, and several of the security response types. But it still leaves large parts of

the space of developer concern unaddressed, particularly in early and late lifecycle

phases.

Most of the security patterns we find in other work are design patterns describing

mechanisms for prevention. Our own work has long been motivated by the needs of

developers and the development process. This concern has driven us to pioneer a

number of new pattern types and cover a larger variety of concerns. For example, our

semantic analysis patterns [4] provide domain models and context, extending cover-

age along the lifecycle axis to domain analysis. Our standards patterns explain the

security aspects of interchange languages and network infrastructure protocols [3, 7],

covering more of the dimension of architectural levels. Lastly we developed forensics

patterns for methods and mechanisms of attack investigation [22], covering more of

the dimension for types of security response.

4 Related Work

Lists are often used in security. DoD and NIST maintain lists of checklists for secure-

ly configuring various software applications, while CERT and NIST list 24,000+

known software exploits. The Common Criteria [1] and SSE-CMM (ISO/IEC 21827)

[sse] both include lists of assurance areas that must be documented to satisfy certifica-

tion. Hoglund and McGraw list 49 types of software attacks [14]. Microsoft has pro-

duced lists of flaws, attack trees, and a secure development process [15, 16, 18]. In

contrast to these long lists of heterogeneous concerns, each dimension of our matrix

is comparatively easy to understand with generally recognizable partitions.

Schumacher has defined a methodology for secure systems design using security

patterns [25, 26]. He analyzed social and technical weaknesses impeding the devel-

opment of secure systems and proposed applying security at all stages of the software

lifecycle. He originally proposed a knowledge management approach involving a

Security Improvement Feedback Loop and a vulnerability database to keep track of

possible attacks and countermeasures. In our experience, vulnerability databases

focus largely on low level code exploits to be addressed in implementation. We be-

lieve that by providing a rich framework for organizing and reasoning about patterns,

the same model of improvement and knowledge feedback can be applied at a higher

level, addressing weaknesses at a system level.

Trowbridge et al. [30] describe an “organizing table” to organize patterns and

identify gaps, and includes a discussion of identifying relationships by exploring

adjacent cells. But they limited their classification to two heterogeneous dimensions

for viewpoints and interrogatives. Their 5 viewpoints were business, integration,

application, operation, and development, each then subdivided into architect, design-

er, and developer. The 110 patterns classified fell into only two categories: integra-

tion and application, and three concerns: data, function, and network. Their view-

points roughly correspond to our lifecycle stages, though the distinctions are less

clear. Without a method of connecting classification to the whole, identification of

gaps can only be ad hoc.

Hafiz et al. [12] identify four potential classification dimensions: protection type,

application context, threat, and Trowbridge’s viewpoints. In the end they proposed a

hierarchy based on application context (core, perimeter, exterior), followed by threat.

Developer contexts like lifecycle stage, domain, and component source, and levels of

response are not considered. The collector perspective was apparent in their effort to

uniquely place each pattern and their expressed concern that too many patterns fell in

too few cells. In the paper, they state, “Any organization effort must begin by collect-

ing the items to be organized.” For our purposes, we reject this notion, and begin with

the space to be covered.

E.B. Fernandez et al. also discuss classifying patterns for designers [8]. The paper

describes the importance of architecture layer and how to use architectural layer clas-

sifications and concerns to make systems more secure. For example, access control

can be defined in the application and reflected to the database and operating system

layers. The paper also discusses pattern diagrams and their important relationship to

classifications. The ideas in that paper complement those presented here.

The work of German and Cowan [9] classify user interface patterns in a deep hie-

rarchy of domain, phase, elaboration, general to specific, and value (a kind of Google

ranking). Their ordered elaboration categories make sense for user interface design,

but are unrelated to security. Issues in that paper make it clear that our matrix would

have to be extended if we wanted to classify patterns in domains other than security.

It should be noted that a multidimensional space can be aligned with cell divisions

in Trowbridge, Hafiz, and even German and Cowen without hierarchical grouping.

From the users’ perspective, reducing orthogonal classifications to a single hierarchy

achieves little and hinders the exploration of relationships along different dimensions.

Moreover, if patterns are meaningful in multiple places, then they should be found in

multiple places.

5 Conclusions

In the past, we proposed patterns-based methodologies [5]. In this paper we propose a

method of organizing patterns to address pattern coverage, and facilitate pattern dis-

covery, exploration, and navigation by the application developer. The approach uses a

multi-dimensional matrix where each dimension divides the problem space into gen-

erally understood concerns. The combination of concerns from multiple dimensions

allows patterns to be precisely associated with regions of applicability, and supports

developer navigation to find related patterns with relevant information.

Although we have only begun to use this tool, preliminary results are promising.

The matrix is proving quite easy to use, and provides insights relevant to the under-

standing and selection of patterns not found in other classification schemes. Some

examples are presented from our work with security patterns for Service Oriented

Architecture.

Acknowledgements

We wish to acknowledge Paul Black of NIST for his participation in the initial dis-

cussion of using a matrix of concerns for developing secure systems.

References

1. Common Criteria, http://www.commoncriteriaportal.org/

2. Blakley, B., Heath, C., members of The Open Group Security Forum: Technical Guide:

Security Design Patterns. The Open Group, UK, April 2004.

3. Delessy, N., Fernandez, E.B.: Patterns for the eXtensible Access Control Markup Lan-

guage. Proc. 12th Pattern Languages of Programs Conference, Monticello, Illinois, USA,

(2005) http://hillside.net/plop/2005/proceedings/

4. Fernandez, E.B., Yuan, X.: Semantic Analysis Patterns. Proc. 19th Int. Conf. on Concep-

tual Modeling (2000), 183-195 http://www.cse.fau.edu/~ed/SAPpaper2.pdf

5. Fernandez, E.B., Larrondo-Petrie, M.M., Sorgente, T., VanHilst, M.: A Methodology to

Develop Secure Systems Using Patterns. In: Mouratidis, H., Giorgini, P. (Eds.): Integrating

Security and Software Engineering: Advances and Future Vision. IDEA Press (2006) 107-

126

6. Fernandez, E.B., VanHilst, M., Larrondo Petrie, M.M., Huang, S.: Defining Security Re-

quirements through Misuse Actions. In: Ochoa, S.F., Roman, G.-C. (Eds.): Advanced

Software Engineering: Expanding the Frontiers of Software Technology, International Fed-

eration for Information Processing, Springer (2006) 123-137

7. Fernandez, E.B., VanHilst, M., Pelaez, J.C.: Patterns for WiMax Security. Proc. EuroPLoP

(2007) http://hillside.net/europlop/home.html

8. Fernandez, E.B., Washizaki, H., Yoshioka, N., Kubo, A., Fukazawa, Y.: Classifying Secu-

rity Patterns. Proc. 10th Asia-Pacific Web Conference, Shenyang, China, April 26-28

(2008)

9. German D., Cowan, D.: Towards a Unified Catalog of Hypermedia Design Patterns. Proc.

33rd Hawaii International Conference on System Sciences, Maui, Hawaii, (2000)

10. Federal Information Security Management Act (FISMA), March 18, 2007,

http://iase.disa.mil/fisma/index.html

11. Senate Banking Committee: Gramm-Leach-Bliley Act, Monday, November 1 (1999)

http://www.senate.gov/~banking/conf/fincon.pdf

12. Hafiz, M., Adamczyk, P., Johnson, R.E.: Organizing Security Patterns. IEEE Software,

24(4), July/August (2007) 52-60

13. United States Department of Health and Human Services, Office of Civil Rights: Health

Insurance Portability and Accountability Act of 1996. http://www.hhs.gov/ocr/hipaa/

14. Hoglan, G., McGraw, G.: Exploiting Software: How to Break Code. Addison-Wesley

(2004)

15. Howard, M., LeBlanc, D.: Writing Secure Code, (2nd Ed.). Microsoft Press (2003)

16. Howard, M., Lipner, S.: The Security Development Lifecycle. Microsoft Press (2006)

17. Leveson, N.: A New Accident Model for Engineering Safer Systems. Safety Science,

42(4), April (2004) 237-270

18. Lipner, S., Howard, M.: The Trustworthy Computing Development Lifecycle,

http://msdn2.microsoft.com/en-us/library/ms995349.aspx, March (2005)

19. McGraw, G.: Software Security: Building Security. Addison-Wesley (2006)

20. Nagaratnam, N., Nadalin, A., Hondo, M., McIntosh, M., Austel, P.: Business-Driven Ap-

plication Security: from Modeling to Managing Secure Applications. IBM Systems Jour-

nal, 44(4) (2005) 847-867

21. The OWASP Testing Project. http://www.modsecurity.org/archive/OWASPTesting_PhaseOne.pdf

22. Pelaez, J.C., Fernandez, E.B.: Network Forensics in Wireless VoIP Networks, Proc. 4th

Latin American and Caribbean Conference for Engineering and Technology. Mayaguez,

Puerto Rico, (2006)

23. Pelaez, J.C., Fernandez, E.B., Larrondo-Petrie, M.M., Wieser, C.: Attack Patterns in VoIP.

Proc. 14th Pattern Languages of Programs Conference, Monticello, Illinois, USA, (2007)

24. One Hundred Seventh Congress of the United States of America: Sarbanes-Oxley Act of

2002. http://news.findlaw.com/hdocs/docs/gwbush/sarbanesoxley072302.pdf

25. Schumacher, M., Ackermann, R., Steinmetz, R.: Towards Security at All Stages of a Sys-

tem’s Life Cycle. Proc. Int. Conf. on Software, Telecommunications, and Computer Net-

works (2000) 11-19

26. Schumacher, M., Roedig, U.: Security Engineering with Patterns. Proc. 8th Pattern Lan-

guages of Programs Conference (2001)

27. Schumacher, M., Fernandez, E.B., Hybertson, D., Buschmann, F., Sommerlad, P.: Security

Patterns: Integrating Security and Systems Engineering. Wiley (2006)

28. Steel, C., Nagappan, R., Lai, R.: Core Security Patterns: Best Practices and Strategies for

J2EE, Web Services, and Identity Management. Prentice Hall (2005)

29. Systems Security Engineering – Capability Maturity Model, http://www.sse-cmm.org

30. Trowbridge, D., Cunningham, W., Evans, M., Brader, L., Describing the Enterprise Archi-

tectural Space. MSDN (2004) http://msdn2.microsoft.com/en-us/library/ms978655.aspx

31. Viega, J., McGraw, G.: Building Secure Software: How to Avoid Security Problems the

Right Way. Addison-Wesley (2001)
