Increasing Translation Speed in Phrase-based Models

via Suboptimal Segmentation

Germ´an Sanchis-Trilles and Francisco Casacuberta

Instituto Tecnol´ogico de Inform´atica

Camino de Vera s/n, 46022 Valencia, Spain

Abstract. Phrase-Based Models constitute nowadays the core of the state of the

art in the statistical pattern recognition approach to machine translation. Being

able to introduce context information into the translation model, they usually

produce translations whose quality is often difﬁcult to improve. However, these

models have usually an important drawback: the translation speed they are able

to deliver is mostly not sufﬁcient for real-time tasks, and translating a single sen-

tence can sometimes take some minutes. In this paper, we describe a novel tech-

nique for reducing signiﬁcantly the size of the translation table, by performing a

Viterbi-style selection of the phrases that constitute the ﬁnal phrase-table. Even

in cases where the pruned phrase table contains only 6% of the segments of the

original one, translation quality is not worsened. Furthermore, translation quality

remains the same in the worst case, achieving an increase of 0.3 BLEU in the best

case.

1 Introduction

The grounds of modern Statistical Machine Translation (SMT), a pattern recognition

approach to Machine Translation, were established in [1], where the problem of ma-

chine translation was deﬁned as following: given a sentence x from a certain source lan-

guage, an adequate sentence

y that maximises the posterior probability is to be found.

Such a statement can be speciﬁed with the following formula:

y = argmax

P r(y|x) (1)

Applying the Bayes theorem on this deﬁnition, one can easily reach the next formula

y = argmax

P r(y) · P r(x|y)

P r(x)

(2)

and, since we are maximising over t, the denominator can be neglected, arriving to

y = argmax

P r(y) · P r(x|y) (3)

where P r(y|x) has been decomposed into two different probabilities: the statistical

language model of the target language P r(y) and the (inverse) translation model P r(x|y).

Sanchis-Trilles G. and Casacuberta F. (2008).

Increasing Translation Speed in Phrase-based Models via Suboptimal Segmentation.

In Proceedings of the 8th International Workshop on Pattern Recognition in Information Systems, pages 135-143

 SciTePress

Although it might seem odd to model the probability of the source sentence given

the target sentence, this decomposition has a very intuitiveinterpretation: the translation

model P r(x|y) will capture the word or phrase relations between both input and output

language, whereas the language model P r(y) will ensure that the output sentence is a

well-formed sentence belonging to the target language.

In the last years, SMT systems have evolved to become the present state of the art,

specially since the up-rise of Phrase Based (PB) models. Introducing information about

context, PB models have widely outperformed word based models [2,3]. However, an

importantdrawbackof the systems which implementthe former models is the enormous

size the phase tables need, which has as consequencethe high requirements such models

need, in terms of space but also time. In this paper, we propose a novel technique for

reducing the amount of segment pairs needed for translating a given test set.

Related work was performed by [4]. In this work, the authors present a method for

reducing the phrase table by performing signiﬁcance testing. Our work, however, does

not perform a statistical analysis of the phrases in the phrase table, but instead uses

the concept of optimal segmentation of each sentence pair to reduce signiﬁcantly the

amount of segments to be included in the ﬁnal phrase table. In addition, we also perform

a speed analysis of the different systems built, both before and after the reduction.

The rest of the paper is structured as follows: In Section 2 we will brieﬂy review the

main ideas of Phrase Based models. In Section 3 we propose the algorithm which has

been used for pruningthe phrase table. Section 4 presents the experimentswe performed

showing that BLEU and WER scores are not affected by the pruning. In Section 5 we

analyse the results and give some insight on why this pruning can be performed. Lastly,

we conclude on Section 6.

2 Phrase-based Models

Phrase based (PB) [5–8] models have succeeded to achieve predominance in the state

of the art in SMT. One would only need to take a look at the most recent international

competitions [2,3] to realise that PB models have succeeded to achieve predominance

in the state of the art in SMT. Under this framework, phrases (i.e. word sequences) are

extracted automatically from a word-aligned bilingual corpus. Because of their nature,

PB models make use of context information, which has led them to outperform single-

word SMT models.

Common assumptions under PB models are that only sequences of contiguous

words are considered, that the number of source phrase (or segment) is equal to the

number of target segments, and that a given source segment is aligned with exactly one

target segment. Hence, when learning a PB model, the purpose is to compute a phrase

translation table, where each input phrase is assigned to one or more output phrases

with a given probability.

In the last years, a wide variety of techniques to produce PB models have been

researched and implemented [9]. Firstly, a direct learning of the probabilities of each

segment was proposed [5,6]. At the same time, heuristics for extracting all possible

segmentations coherent with a word-aligned corpus [7], where the alignments were

learnt by means of the GIZA++ toolkit [10], were also proposed. Other approaches

have been suggested, exploring more linguistically motivated techniques [11,12]. In

this paper, we report experiments using the heuristic, (word) alignment-based phrase

extraction algorithm.

However, these models have an important drawback, which must be tackled with

whenever being applied to real time tasks: PB models tend to produce huge phrase

tables, which entail slow translation speeds. In this paper, we propose a Viterbi style re-

duction of the phrase table, as it is done in the Viterbi re-estimation of Hidden Markov

Models, achieving size reductions of over 90% and multiplying translation speed, mea-

sured as words per second, by almost a factor of 10.

3 Phrase Table Reduction via Suboptimal Bilingual Segmentation

The problem of segmenting a bilingual sentence pair in such a manner,that the resulting

segmentation is the one that contains, without overlap, the best phrases that can be

extracted from that pair is a difﬁcult problem. In the ﬁrst place, because all possible

segmentations must be considered, and this number is a combinatorial number. In the

second place, because a measure of “optimality” must be established. Consider the

following example:

Source: The table is red .

Target: La mesa es roja .

At the sight of this example, one would probably state that {{ The table , La mesa} ,

{is red, es roja}, {. , .}} is a good segmentation for this bilingual pair. However, why

is such a segmentation better than {{The , La},{ table is , mesa es},{red . , roja .}}?

As humans, we could argue with more or less convincing linguistic terms in favour of

the ﬁrst option, but that does not necessarily mean that such a segmentation is the most

appropriate one for SMT, and, moreover,one could easily think of several linguistically

appropriate segmentations of this small example. To overcome this problem, PB SMT

systems are forced to extract a large number of possible overlapping segmentations, and

hope that one of them will be useful. Obviously, such an aggressive approach is bound

to be computationally costly, and decoding time greatly suffers because of this issue.

When considering all possible segmentations of a bilingual sentence pair and as-

suming a “bag of words” model for the target sentence, the probability P r(x|y) in

Equation 3 can be modelled as:

P (x|y) =

k=1

p(x

k−1

) (4)

where K is the number of bilingual segments into which each bilingual pair is divided,

µ is the set of possible segmentations of the source sentence x and γ the set of possible

segmentations of the target sentence y. In this formula we have assumed monotonic

translation, in which no word (or segment) reordering is performed for the sake of

simplicity.

Our approach for solving the problem of the overwhelming amount of possible seg-

mentations, and the consequent increase of the phrase table, is based on the concept of

Viterbi re-estimation [13]. Following this idea, we can approximate P(x|y) by chang-

ing the summations by maximisations:

P (x|y) ≈

P (x|y) = max

max

k=1

p(x

k−1

) (5)

Given that the phrase table establishes the probability of an input segment given

a certain output segment, we can use the scores within the phrase table to compute

P (x|y), and then build a phrase table by only taking into account those segments used

to compute the optimal segmentation of each bilingual sentence in the training corpus.

However,computing

P (x|y) according to a given phrase table is not an easy task: if

we establish a certain maximum length for the segments contained in the phrase table,

it is common that, due to non-monotonic alignments, certain words of a sentence will

not be contained in the segments extracted. Observing all possible segments without

constraining the maximum length is not a solution either, since the number of entries in

the phrase table would grow too much. This implies that the phrase table has coverage

problems even on the training set.

However, our intention is to discard unnecessary segment pairs contained in the

phrase table. To this purpose, a suboptimal bilingual segmentation, in which we trans-

late the source sentence, may be enough. We are aware, nevertheless, that translating

the input sentence will not necessarily produce the output sentence in the training pair,

but our experiments show that this might be good enough to prune the phrase table

without a signiﬁcant loss in translation quality.

4 Experiments

We conducted our experiments on the Europarl corpus [14], with the partition estab-

lished in the Workshop on Statistical Machine Translation of the NAACL 2006 [15].

The Europarl corpus [14] is built from the proceedings of the European Parliament,

which are published on the web, and was acquired in 11 different languages. However,

in this work we will only focus on the German–English, Spanish–English and French–

English tasks, since these were the language pairs selected for the cited workshop. The

corpus is divided into four separate sets: one for training, one for development, one for

test and another test set which was the one used in the workshop for the ﬁnal evaluation.

This test set will be referred to as “Test”, whereas the test set provided for evaluation

purposes outside the ﬁnal evaluation will be referred to as “Devtest”. It must be noted

that the Test set included a surprise out-of-domain subset, and hence the translation

quality on this set will be signiﬁcantly lower. The characteristics of the corpus can be

seen in Table 1. It might seem surprising that the average sentence length in the training

set is signiﬁcantly lower than in the rest of the subsets. This is due to the fact that,

for the competition, the training corpus pruned to contain only those sentences with a

maximum length of 40, whereas this restriction was not imposed on the other subsets.

The translation systems were tuned using the development set with the MERT [16]

optimisation procedure, where the measure to be optimised was BLEU [17].

We performed experiments on both test sets, yielding similar results for both of

them. Because of this, and in order not to provide an overwhelming amount of results,

Table 1. Characteristics of the Europarl corpus.

German English Spanish English French English

Training

Sentences 751088 730740 688031

Running words 15.3M 16.1M 15.7M 15.2M 15.6M 13.8M

Average length 20.3 21.4 21.5 20.8 22.7 20.1

Vocabulary size 195291 65889 102886 64123 80349 61627

Development

Sentences 2000 2000 2000

Running words 55147 58655 60628 58655 67295 58655

Average length 27.6 29.3 30.3 29.3 33.6 29.3

Out of vocabulary 432 125 208 127 144 138

Devtest

Sentences 2000 2000 2000 2000 2000

Running words 54260 57951 60332 57951 66200 57951

Average length 27.1 29.0 30.2 29.0 33.1 29.3

Out of vocabulary 377 127 207 125 139 133

Test

Sentences 3064 3064 3064

Running words 82477 85232 91730 85232 100952 85232

Average length 26.9 27.8 29.9 27.8 32.9 27.8

Out of vocabulary 1020 488 470 502 536 519

we only report the results obtained with the Test set, being this result more interesting

because of the out-of-domain data it contains.

4.1 Suboptimal Segmentation Filtering

As a baseline system, we used the same system as the one used in the workshop. To

ﬁlter the phrase table as described in the previous section, we translated the whole

training subcorpus using the baseline model, and kept only those entries of the phrase

table which were used while doing this. Since the baseline system uses lexicalised re-

ordering [18], we also ﬁltered the reordering table according to the segments used. The

result of this setup can be seen in Table 2.

In this table, the sizes are given in number of entries in the phrase table and the

speed is given in words per second. fsize is the size of the phrase table after ﬁltering

out all segments which will not be needed for translating the current test set, which is

usual when dealing with big phrase tables. In this context, it must be noted that the

translation speed detailed in Table 2 was measured in all cases when translating using

the ﬁltered phrase table, since loading the complete phrase table into memory without

any ﬁltering is unfeasible with the baseline model. Moreover, the speed does not take

into account the time the system needs to load the model ﬁles (i.e. phrase table and

lexicalised reordering table), which is reduced in a factor of ten due to the difference

in model size. S

is the speedup, which is given by the formula S

= T

, where

is the time taken by the baseline system and T

is the time taken by the ﬁltered

system. The values appearing as “size red.” in the table represent the fsize reduction in

percentage with respect to the original fsize. Hence, this column displays the effective

reduction of data loaded into the decoder when translating.

Translation quality, as measured with BLEU [17] is not affected by the reduction of

the size of the phrase table we proposing. Moreover, we can see that, in the worst case,

Table 2. Performance comparison between the baseline system and our suboptimal-

segmentation-reduced approach. Lexicalised reordering is considered. Speed is measured in num-

ber of translated source words per second, and fsize is the size of the phrase table when ﬁltered

for the test set.

baseline reduced

pair WER BLEU size fsize speed WER BLEU size fsize speed size red. S

Es–En 57.8 30.6 19M 1.6M 5.3 57.5 30.9 1.9M 0.15M 13.1 91% 2.5

En–Es 57.5 30.3 19M 1.8M 5.7 57.4 30.6 1.7M 0.16M 11.3 92% 2.0

De–En 68.1 23.7 12M 1.1M 6.6 68.2 23.9 1.8M 0.18M 11.4 84% 1.7

En–De 72.5 16.4 13M 1.7M 4.3 72.4 16.5 1.9M 0.23M 9.0 86% 2.1

Fr–En 60.2 28.3 15M 1.6M 5.6 60.1 28.3 1.5M 0.12M 17.7 92% 3.2

En–Fr 60.5 30.5 16M 1.7M 4.5 60.1 30.9 1.6M 0.15M 9.5 91% 2.1

we get exactly the same score than with the baseline system, and in the best case we are

improving BLEU by 0.35 points. As measured with WER, which is an adaptation of the

edit distance used in Speech Recognition, the translation quality is slightly worsened in

some cases (with a maximum of 0.1 points), and in some cases improved.The behaviour

difference between BLEU and WER can be explained because of the measure being

optimised in MERT, which was BLEU.

Although the differences named in the previous paragraph are not signiﬁcant, it is

important to stress that we are improving translation speed by a factor of 3.2 in the best

case and 1.7 in the worst case, without a signiﬁcant loss of translation quality even in

cases where out-of-domain sentences were translated.

4.2 Increasing Translation Speed Further

Although the speeds achieved in the previous subsection are already competitive, they

may not be enough for real time applications: translating an average sentence of 25

words may take more than two seconds, and this might not be enough for the user who

is waiting for the translation.

A common resource for increasing translation speed is to consider only monotonic

translation. Under this decoding strategy, a given bilingual segment must occupy the

same position in both input and output sentences. For example, if the source part of a

certain bilingual segment is placed at the start of the source sentence, it cannot be placed

at the end of the target sentence (or anywhere else but at the start). Although it is true

that some translation quality is lost by doing so, the difference is relatively small the

language pairs considered in our work. Our phrase table reduction technique can also

be applied to monotonic translation. The results for this setup are shown in Table 3,

yielding, again, no signiﬁcant worsening (or improvement) of the translation scores,

but achieving speedups ranging from 3.2 to 9.5, depending mainly on the language pair

chosen and when compared to the non-reduced monotonic search.

In this case, it must be emphasised that the fsize of the baseline is the same as in

the case of the lexicalised reordering search, since the reordering has no effect on the

number of phrases extracted. This is not so, however,with our suboptimalsegmentation,

since the monotonicity constraint is also imposed when obtaining the segments that will

Table 3. Performance comparison between the baseline system and our suboptimal-

segmentation-reduced approach. Monotonic search is considered. Speed is measured in number

of translated source words per second, and fsize is the size of the phrase table when ﬁltered for

the test set.

baseline reduced

pair WER BLEU fsize speed WER BLEU fsize speed S

Es–En 58.8 29.6 1.6M 17.6 58.4 29.7 0.13M 91.5 5.2

En–Es 58.5 29.2 1.8M 19.1 58.6 29.2 0.08M 125.0 6.5

De–En 68.9 22.6 1.1M 20.6 69.0 22.5 0.14M 107.0 5.2

En–De 73.1 16.0 1.7M 23.5 72.6 16.2 0.20M 80.0 3.4

Fr–En 60.3 27.6 1.6M 15.8 60.9 27.4 0.11M 147.0 9.3

En–Fr 61.7 29.4 1.7M 19.0 61.5 29.4 0.16M 74.7 3.9

Table 4. Performance as measured by BLEU and WER for the re-normalised system. Both mono-

tonic and non-monotonic search are considered.

baseline re-normalised

monotonic reordering monotonic reordering

pair WER BLEU WER BLEU WER BLEU WER BLEU

Es–En 58.8 29.6 57.8 30.6 59.0 29.1 57.8 30.5

En–Es 58.5 29.2 57.5 30.3 58.8 29.0 57.6 30.4

De–En 68.9 22.6 68.1 23.7 69.1 22.5 68.3 23.8

En–De 73.1 16.0 72.5 16.4 72.7 16.3 72.7 16.4

Fr–En 60.3 27.6 60.2 28.3 61.0 27.2 60.2 28.1

En–Fr 61.7 29.4 60.5 30.5 61.8 29.3 60.4 30.9

be part of the ﬁnal phrase table, which implies that fewer (but shorter) segments will be

kept.

5 Analysis and Side Notes

A question which could be asked at this point is whether we can truly obtain the same

translation quality by just taking into account the suboptimal segmentation, or rather

what we are doing is simply a ﬁltering, but we actually would need the probabilities

contained within the complete phrase table. In order to clarify this, we re-normalised the

phrase table, assigning to each segment the score obtained by only taking into account

those phrase pairs contained within the reduced phrase table. In Table 4 we can see the

results of performing such a renormalisation.

As can be seen in the table, the performance is not signiﬁcantly affected by the

renormalisation. In our opinion, this clearly reveals that computing the phrase transla-

tion probabilities by only taking into account the segments used to translate the training

set obtains a similar result than taking into account all possible segmentations that are

consistent with the word alignments, as is common in regular SMT systems. A possible

interpretation is that those segments which were selected to stay in the ﬁnal, ﬁltered

table are those which account for the biggest part of the probability mass.

Table 5. BLEU and WER scores for the Training set, with both monotonic and non-monotonic

search.

pair

monotonic reordering

WER BLEU WER BLEU

Es-En 44.9 48.2 43.2 50.6

En-Es 47.1 46.3 44.8 49.4

De-En 53.9 41.6 51.8 43.6

En-De 55.6 37.9 55.6 37.9

Fr-En 46.7 45.9 46.9 46.0

En-Fr 51.5 44.4 46.4 49.8

Lastly, and since we already had translated the training set, we found interesting to

compute the BLEU and WER scores over the training data. These scores, which can be

seen in Table 5, constitute an upper bound of the score that could be achieved in the test

set. However, these results are not as good as could be expected, which hints towards a

relatively weak (but even though state-of-the-art) performance of the translation models

and (or) decoding algorithm.

6 Conclusions and Future Work

In this work we have presented a straight-forward method for reducing the size of the

phrase table by a factor of ten, and increasing translation speed up to nine times. By

doing so, the translation quality as measured by WER and BLEU remains unaffected,

for both in-domain and out-of-domain data. Given that translation speed is a serious

issue in systems implementing phrase-based models, the approach presented in this

paper provides an efﬁcient solution for the problem.

As future work, we are planning on researching ways to obtain the optimal segmen-

tation of the sentences in the training corpus, without going through the drawback of

having to translate the corpus. This includes both segmenting the sentences according

to a phrase table, and without having the phrase table as a starting point.

Acknowledgements

This work has been partially supported by the Spanish MEC under scholarship AP2005-

4023 and under grant CONSOLIDER Ingenio-2010 CSD2007-00018, and by the EC

(FEDER) and the Spanish MEC under grant TIN2006-15694-CO2-01.

References

1. Brown, P.F., Pietra, S.A.D., Pietra, V.J.D., Mercer, R.L.: The mathematics of machine trans-

lation. In: Computational Linguistics. Volume 19. (1993) 263–311

2. Callison-Burch, C., Fordyce, C., Koehn, P., Monz, C., Schroeder, J.: (meta-) evaluation of

machine translation. In: Proceedings of the Second Workshop on Statistical Machine Trans-

lation, Prague, Czech Republic, Association for Computational Linguistics (2007) 136–158

3. Fordyce, C.S.: Overview of the IWSLT 2007 evaluation campagin. In: International Work-

shop on Spoken Language Translation, Trento, Italy (2007)

4. Johnson, J., Martin, J., Foster, G., Kuhn, R.: Improving translation quality by discarding most

of the phrasetable. In: Proceedings of the 2007 Joint Conference on Empirical Methods in

Natural Language Processing and Computational Natural Language Learning, Prague, Czech

Republic (2007)

5. Tomas, J., Casacuberta, F.: Monotone statistical translation using word groups. In: Pro-

ceedings of the Machine Translation Summit VIII, Santiago de Compostela, Spain (2001)

357–361

6. Marcu, D., Wong, W.: Joint probability model for statistical machine translation. In: Pro-

ceedings of the Conference on Empirical Methods in Natural Language Processing and Very

Large Corpora (EMNLP02), Pennsylvania, Philadelphia, USA (2002)

7. Zens, R., Och, F., Ney, H.: Phrase-based statistical machine translation. In: Advances in

artiﬁcial intelligence. 25. Annual German Conference on AI. Lecture Notes in Computer

Science. Volume 2479. (2002) 18–32

8. Zens, R., Ney, H.: Improvements in phrase-based statistical machine translation. In: Proceed-

ings of the Human Language Technology Conference (HLT-NAACL), Boston, USA (2004)

257–264

9. Koehn, P., Och, F., Marcu, D.: Statistical phrase-based translation. In: Proceedings of the

2003 Conf. of the NAACL on Human Language Technology. Volume 1., Edmonton, Canada

(2003) 48–54

10. Och, F., Ney, H.: A systematic comparison of various statistical alignment models. In:

Computational Linguistics. Volume 29. (2003) 19–51

11. S´anchez, J., Bened´ı, J.: Stochastic inversion transduction grammars for obtaining word

phrases for phrase-based statistical machine translation. In: Proceedings of the Workshop

on SMT, New York City (2006) 130–133

12. Watanabe, T., Sumita, E., Okuno, H.: Chunk-based statistical translation. In: Proceedings of

the 41st. Annual Meeting of the ACL, Sapporo, Japan (2003)

13. Viterbi, A.: Error bounds for convolutional codes and an asymptotically optimum decoding

algorithm. 13 (1967) 260 – 269

14. Koehn, P.: Europarl: A parallel corpus for statistical machine translation. In: MT Summit.

(2005)

15. Koehn, P., Monz, C., eds.: Proceedings on the Workshop on Statistical Machine Translation.

Association for Computational Linguistics, New York City (2006)

16. Och, F.: Minimum error rate training for statistical machine translation. In: ACL 2003: Proc.

of the 41st Annual Meeting of the ACL, Sapporo, Japan (2003)

17. Papineni, Kishore, A., Roukos, S., Ward, T., Zhu, W.J.: Bleu: A method for automatic eval-

uation of machine translation. In: Technical Report RC22176 (W0109-022), IBM Research

Division, Thomas J. Watson Research Center, Yorktown Heights, NY (2001)

18. Koehn, P., Axelrod, A., Mayne, A.B., Callison-Burch, C., Osborne, M., Talbot, D.: Edin-

burgh system description for the 2005 IWSLT speech translation evaluation. In: International

Workshop on Spoken Language Translation, Pittsburgh, Pennsylvania, USA (2005)
