BEHAVIOR CHARACTERIZATION AND PERFORMANCE

EVALUATION OF A HYBRID P2P FILE SHARING SYSTEM

Juan Pedro Mu˜noz-Gea, Josemaria Malgosa-Sanahuja, Pilar Manzanares-Lopez

Juan Carlos Sanchez-Aarnoutse and Joan Garcia-Haro

Department of Information Technologies and Communications

Polytechnic University of Cartagena, Campus Muralla del Mar, 30202, Cartagena, Spain

Keywords:

Peer-to-Peer systems, simulation tools, analytical models, performance evaluation.

Abstract:

Peer-to-Peer (P2P) networks show a set of distinctive features which increase the need to previously simulate

the new proposals. In order to perform an adequate evaluation of a P2P application, it is necessary a real char-

acterization of the queries behavior and the node dynamism. After validating the new P2P algorithm by means

of simulation, developers have the possibility to prove a real P2P application instance in an emulated environ-

ment. In each step, the detected errors or misbehaviors are appropriately corrected. The main contribution of

this paper is twofold: ﬁrst, to adequately characterize the real behavior of P2P overlay networks (including

dynamic and static aspects) and second, evaluate a real P2P overlay network under the above constraints using

one of the most popular (high level and user friendly) simulation frameworks.

1 INTRODUCTION

The cost associated with the implementation of a net-

work application is too large in most cases. There-

fore, to avoid a costly failure, it is recommended to

simulate the proposed algorithms and speciﬁcations

before. This methodology makes possible both to

correct any kind of mistake and to validate the ﬁ-

nal design. In addition, peer-to-peer (P2P) networks

(Steinmetz and Wehrle, 2005) show a set of distinc-

tive features which increase the need to previously

simulate the new proposals. First of all, these applica-

tions involve a massive number of nodes (1,000,000

or more), and they require to operate in large-scale

environments, i.e. on Internet. Therefore, scalabil-

ity is one of the most important characteristics that

researchers have to prove. Secondly, P2P nodes are

usually home computers. Therefore, they are prone

to unpredictabledisconnections and consequently, de-

velopers have to ensure that the new applications can

appropriately adapt to the node failures and the con-

tinuous joining and leaving of nodes inherent to the

P2P nets. Hence, node dynamism is another key fac-

tor to take into consideration.

On the other hand, in order to perform an adequate

performance evaluationof a P2P application, it is nec-

essary to program a realistic model of the system.

Therefore, it is necessary to characterize the queries

behavior, the node connection interarrival time, the

distribution of the session length and the dynamism

of the ﬁles.

Ideally, a simulator should implement all the

mechanisms and procedures of the real algo-

rithm/application, but coded in a completely different

way: for instance, a P2P application may need to use

the system call socket() or create a new thread, but

usually a simulator of this application does not need

to use this type of procedures to simulate the behavior

of the application. On the other hand, normally a sim-

ulated application is a characterization of the real sys-

tem and thus, more lightweighted than its correspond-

ing actual software, because a real application is tied

to heavy operating system resources such as processes

and threads. In conclusion, the simulated experiments

are developed in a complete different way to the real

implementation.

After validating the new (under study) P2P algo-

rithm, developers have the possibility to prove a real

P2P application instance (natural programming) in an

emulated environment. A network emulator is a pro-

gram running in a set of computers (at least one) that

appears to be a network; applications can be attached

to the emulator and will behave as they are attached

to a real network. The behavior of an emulated envi-

Pedro Muñoz-Gea J., Malgosa-Sanahuja J., Manzanares-Lopez P., Carlos Sanchez-Aarnoutse J. and Garcia-Haro J. (2008).

BEHAVIOR CHARACTERIZATION AND PERFORMANCE EVALUATION OF A HYBRID P2P FILE SHARING SYSTEM.

In Proceedings of the Third International Conference on Software and Data Technologies - PL/DPS/KE, pages 95-102

DOI: 10.5220/0001870300950102

 SciTePress

Simulated

Application

Simulated

Network

Real App.

(v. 1.0)

Network

Emulated

Network

Real

Validation

Protocol Code Depuration

& Optimization

Real App.

(v. 2.0)

Figure 1: Procedure to develop an error-free network appli-

cation.

ronment is exactly the same as the real world. This

mechanism enables developers to test and improve

their algorithms with a large number of nodes on a

single computer or on few computers in a small lab

(in that case the control messages are encapsulated

and forwarded via UDP or TCP sockets between the

computers).

Fig. 1 graphically summarizes the above discus-

sion. Generally, the procedure to launch a new net-

work application is ﬁrst to simulate it, next to prove

it in an emulated environment, and ﬁnally to issue the

application to the market. In each step, the detected

errors or misbehaviors are appropriately corrected.

Some examples of speciﬁc P2P simulation frame-

works are P2PSim (P2PSim, 2005) and OverSim

(OverSim, 2007), and some of the most popular net-

work emulators are ModelNet (ModelNet, 2005) and

Overlay Weaver (Overlay Weaver, 2007). Simulation

tools can operate with approximately ten thousands of

nodes. Emulators work only with hundreds of nodes

on a single PC.

The main contribution of this paper is twofold:

First, to adequately characterize the real behavior of

P2P overlay networks (including dynamic and static

aspects) and second, evaluate a P2P overlay network

designed and published by the authors (Mu˜noz-Gea

et al., 2006) under the above constraints using one of

the most popular (high level and user friendly) simu-

lation framework. The results reported by the simula-

tion model are evaluated in order to verify its correct-

ness.

The remainder of the paper is organized as fol-

lows. Section 2 summarizes the most relevant prop-

erties of the well-known OMNeT++ simulation en-

gine and the OverSim simulation framework. Section

3 brieﬂy describes the most recent P2P applications

models. Section 4 describes the proposed P2P simu-

lation model, while the corresponding numerical re-

sults are discussed in Section 5. Finally, Section 6

concludes the paper.

2 P2P SIMULATION

FRAMEWORK

We ﬁnd interesting to remark and brieﬂy describe

the most relevant open-source P2P simulation frame-

works available (a comprehensive survey of P2P sim-

ulation frameworks can be found in (Naicken et al.,

2007)). P2PSim (P2PSim, 2005) is a discrete event

simulator for structured P2P networks written in C++.

However, it is largely undocumented and therefore

hard to extend. Additionally, it has a limited set of

statistics. PeerSim (PeerSim, 2006) uses query-cycle

or discrete-event techniques to simulate unstructured

P2P networks. However, the underlying TCP/IP net-

work is not modeled and only the query-cycle simu-

lator is documented. PlanetSim (PlanetSim, 2005) is

a discrete event simulator written in Java. However,

it has a limited simulation of the underlying TCP/IP

network and it does not provide any mechanism to

gather statistics.

Among all the available tools we have chosen

OverSim because of its ﬂexibility: Its modular design

and the use of the Common API (Dabek et al., 2003)

facilitate its extension with new protocols. In addi-

tion, its ﬂexible underlying network scheme can be

very useful during the application development. An-

other reason to select OverSim is that its code is well

documented.

OverSim is built over OMNeT++. OMNeT++ is

a well-known open-source network simulation engine

and it is one of the most used simulation frameworks

for the research community. Additionally, its coding

procedure is well documented and it also offers a mul-

tiplicity of network simulation models already imple-

mented.

The development of a simulation model with OM-

NeT++ has several steps, which we brieﬂy point out:

1. Description of the system structure using the NED

language.

2. Implementation of the simple modules in C++.

The node functionality must be implemented in

the handleMessage() method.

3. To obtain an executable, the modules have to be

compiled and linked with the simulation library.

4. Conﬁguration of the omnetpp.ini ﬁle.

The layered structure of OverSim appears in

(Baumgart et al., 2007). It includes all the facilities

about underlay and overlay networks and its primi-

tives. Therefore, users only need to code the overlay

application in the application layer.

The communicationbetween the overlay layer and

the application layer uses the API described and well

ICSOFT 2008 - International Conference on Software and Data Technologies

documented in (Dabek et al., 2003). The set of func-

tions deﬁned in this API are the same independently

of the overlay network selected (Chord, Kademlia,

GIA). Therefore, the same overlay application can be

easily translated from one overlay system to another

with a minimum effort.

However, although OverSim is a new overlay net-

work simulation framework, developed to overcome

several drawbacks of existing peer-to-peer simulators,

it is necessary to introduce appropriate models to pro-

gram the behavior of these applications in OverSim.

Next section describes the most recent models for this

behavior.

3 P2P MODELLING

In order to perform an adequate evaluation of a P2P

application, it is necessary to program a realistic

model of the system. Therefore, it is necessary to

characterize the queries, the node connection inter-

arrival time, the distribution of the session length, the

ﬁles life-time, the ﬁles arrival rate and the number of

peers receiving them. Next, we are going to brieﬂy

describe the most recent models for the previous pa-

rameters.

3.1 Queries Characterization

An accurate characterization of peer query behavior

is absolutely indispensable. This characterization in-

cludes the time until the ﬁrst query, the query interar-

rival time and the query popularity. In (Klemm et al.,

2004a) the authors provide a model that is based on

passive measurement of a peer in the Gnutella P2P

system over a period of 40 days.

Speciﬁcally, the time until the ﬁrst query can be

modeled by a bimodal distribution composed of a

Weibull distribution for the body and a log-normal

distribution for the tail. In the same way, the query

interarrival time is modeled by a bimodal distribution

composed of a log-normal distribution for the body

and a Pareto distribution for the tail.

On the other hand, the query popularity follows a

Zipf-like distribution. Zipf’s law states that the size

of the rth largest occurrence of an event is inversely

proportial to its rank r:

≈ 1/r

(r = 1,2,3,...,N) (1)

where α is close to unity, and N is the number of dis-

tinct occurrences of an event. Under a Zipf-like dis-

tribution, the probability of requesting the ith most

popular document is given by:

K · i

where, K =

∑

j=1

1/ j

(2)

3.2 Dynamics of Peer Participation

The dynamics of peer participation, or churn, are an

inherent and critical property of P2P systems. A peer

joins the system when a user starts the application,

contributes with some resources while making use of

the resources provided by others, and leaves the sys-

tem when the user exits the application. This join-

participate-leave cycle is deﬁned as a session. Thou-

sands of independent sessions creates the collective

effect called churn.

The two fundamental properties of churn are the

following: (i) the inter-arrival time between sessions

and (ii) the session length. Several simulation and

analytical studies have typically assumed both distri-

bution to be exponential, though some studies have

modeled the session length distribution as Pareto. In

(Stutzbach and Rejaie, 2006) authors found other dis-

tributions for inter-arrival time and session length.

Exponential distributions are typically used to

model behavior resulting from a large number of inde-

pendents events. However, peer arrivals are not com-

pletely independent. Users are less likely to be active

during certain times of day (or during certain days of

the week), and a surge of arrivals may occur when a

link to a ﬁle appears on a popular website. In this sce-

nario, Weibull distributions are a more ﬂexible alter-

native to exponential distributions (in fact, exponen-

tial distributions are a special case of the Weibull dis-

tributions where the shape parameter is 1). Therefore,

for inter-arrival times, a Weibull distribution provides

a much better ﬁt.

In the same way, session lengths do not follow

the commonly-used exponential distribution. Several

studies have reported that peer sessions lengths are

heavy-tailed. However, neither the exponential nor

heavy-tailed distributions proved consistent with re-

cent observations. There are other two models that

might provide a good ﬁt: log-normal distributions and

Weibull distributions. The reason is that while most

session are short (minutes), some sessions are very

long (days or weeks). This differs from exponen-

tial distributions, which exhibit values closer together

in length, and heavy-tailed distributions, which have

more pronounced extremes (years).

3.3 Files Characterization

Characterizing available ﬁles among participants

peers is valuable because it reveals the properties,

distribution and heterogeneity of the contributed re-

BEHAVIOR CHARACTERIZATION AND PERFORMANCE EVALUATION OF A HYBRID P2P FILE SHARING

SYSTEM

sources (i.e. storage space and available ﬁles) by indi-

viduals users in the system. The reference (Stutzbach

et al., 2007) is the ﬁrst study that has explored the

dynamic characteristics of stored ﬁles in P2P sys-

tems. Among them, we can ﬁnd the variations in the

shared ﬁles by individual peers. There are two types

of changes that may occur in the list of shared ﬁles at

each peer: First, the user may add new ﬁles, either by

downloading them from other peers or by manually

adding them to the shared folder. Second, the user

may remove ﬁles, by moving (or deleting) those ﬁles

from the sharing folder. The total number of added

and deleted ﬁles at a single peer is deﬁned as the de-

gree of change.

On the other hand, ﬁle replication can be mod-

eled by a Zipf-like distribution. In (Klemm et al.,

2004b) authors relate query popularity and ﬁle repli-

cation by characterizing the matching probability be-

tween queries and ﬁles. They showed that this match-

ing probability is given by a probability function com-

posed by a summation of an exponential and a normal

distributions. The probability function depends on the

popularity rank of the query, but it is independent of

the replication rank of the ﬁle. Thus, the matching

probability between queries and ﬁles is easily com-

putable.

4 MODEL DESCRIPTION

4.1 Introduction

In (Mu˜noz-Gea et al., 2006) the authors proposed an

unstructured overlay network which uses a structured

lookup procedure to organize the peers, forming a hy-

brid P2P network. This network was evaluated with-

out considering the requirements explained in Section

3 and using a custom simulator implemented in C

language. Now, this network will be evaluated pro-

gramming a realistic model of the system and using

one of the most popular (high level and user friendly)

simulation frameworks. First, subsection 4.2 summa-

rizes the overlaynetwork architecture. Second, its im-

plementation in the OverSim simulator is brieﬂy pre-

sented in subsection 4.3. Finally, the results reported

by the simulation model will be evaluated in order to

verify its correctness.

4.2 Overlay Network Architecture

We took (Mu˜noz-Gea et al., 2006) as reference pro-

tocol. In this proposal, peers are grouped into sub-

groups in an unstructured way. However, this topol-

GENERAL OVERLAY NETWORK

MULTICAST GROUP

Figure 2: General architecture of the system.

ogy is maintained by means of an structured lookup

mechanism.

Every subgroup is managed by one of the sub-

group members, that we call super-peer. The super-

peer is the node that has the best features in terms of

CPU, bandwidth and reliability. When searching for

a content, the user will send the lookup parameters to

its local super-peer. The local super-peer will resolve

the complex query, obtaining the results of this query.

To allow the super-peers to locate contents placed

in remote subgroups, all the super-peers of the net-

work are going to be members of a multicast group.

The structured P2P network can be also used to imple-

ment an Application Level Multicast (ALM) service.

Among all the possibilites, we have selected Chord-

multicast (Stoica et al., 2003)(El-Ansary et al., 2003)

as mechanism to send messages to all the members of

the multicast group.

To implement the structured-based maintenance

of the unstructured topology, all the nodes (peers)

must be immersed into a a Chord structured network.

Therefore, every node has an identiﬁer (NodeID), and

they have to contact with an existing node to join this

network. Figure 2 describes the general architecture

of the system.

The previous existing node also gives to the new

node the identiﬁer of the subgroup it belongs (Sub-

groupID), and using the structured lookup mechanism

the new node will ﬁnd the super-peer of that sub-

group. This is possible because each time a node

becomes a super-peer, it must contact with the node

which NodeID ﬁts with the SubgroupID and sends it

its own IP address.

Initially, the new node will try to connect the same

subgroup than the existing node. However, if there is

no room, the new node will be asked to create a new

(randomly generated) subgroup or it will be asked

to join the subgroup that the resquested super-peer

urged to create previously. The use of different ex-

ICSOFT 2008 - International Conference on Software and Data Technologies

isting nodes allows the system to ﬁll up incomplete

subgroups.

When a new node ﬁnds its super-peer, it notiﬁes

its resources of bandwidth and CPU. Thus, the super-

peer forms an ordered list of future super-peer can-

didates: the longer a node remains connected (and

the better resources it has), the better candidate it be-

comes. This list is transmitted to all the members of

the subgroup.

4.3 Simulator Implementation

In this section the most relevant steps to conﬁgure

a simulation in OverSim are discussed. First, it is

necessary to implement the support for the joins and

departures of the DHT service used by the appli-

caton software. As mentioned above, in OverSim

the communication between the overlay and the ap-

plication layers corresponds to the API presented in

(Dabek et al., 2003). Speciﬁcally, the upcall up-

date(nodehandle n, bool joined) is invoked by the

overlay to inform the application that node n has ei-

ther joined or left the neighbor set. In order to imple-

ment the mechanism that this function has to perform

in our application, we have to include and code ac-

cordingly this function. Since our application uses

the Chord overlay network, the actions performed

by our update() function only have to take into ac-

count when a new node joins the network between

the current predecessor node and itself (remember

that Chord nodes are virtually organized in a ring).

This is because in this case, the keys between the cur-

rent predecessor and the new node have to be sent to

the new node. These keys are delivered encapsulated

in a message deﬁned in our application and called

AppChurnMessage. In addition, when a node leaves

the network it has to send its keys to the ﬁrst succesor

node.

On the other hand, our application uses the

SubgroupID as key and the IP of the super-peer as

value, and both of them are organized in a DHT over

a Chord structured network. In order to appropriately

implement this functionality, our application must use

the routing functions deﬁned in the Common API

(Dabek et al., 2003). These routing functions are the

following:

• void route(key k, msg m). This operation forwards

a message, m, towards the responsible node of

key k. This function is implemented in the over-

lay layer. The application layer offers the call-

Route(key k, msg m) function in order to call the

route-method in the overlay-layer.

• void forward(key k, msg m, nodehandle nexthopn-

ode). This function is implemented in the appli-

cation layer. It is invoked from the overlay layer

of each node that forwards message m during its

routing.

• void deliver(key k, msg m). This function is also

implemented in the application layer. It is invoked

from the overlay layer of the node that is respon-

sible for key k upon the arrival of message m.

When the overlay layer facilities supply the IP ad-

dresses of the peers in our application, the commu-

nication between nodes is established by means of a

UDP/IP socket. This activity requires two actions,

ﬁrst of all, nodes have to bind to a local port in or-

der to allow the reception of messages (bindToPort()

function); then, in order to send messages to a speciﬁc

destination node (destAddr, destPort) we will use the

sendToUDP() function.

The rest of the implementation is in the han-

dleMessage() function. As already mentioned, this

function is invoked when the module receives a mes-

sage, and it has to implement the most important func-

tionality of the simulator.

Regarding characterization of peer query be-

havior, we have followed the models presented in

(Klemm et al., 2004a). Therefore, the time until the

ﬁrst query is modeled by a bimodal distribution com-

posed of a Weibull distribution for the body, with

parameters α = 0.9821 and λ = 0.02662 and a log-

normal distribution for the tail, with parameters σ =

2.359 and µ = 6.301.

In the same way, the query interarrival time is

modeled by a bimodal distribution composed of a

log-normal distribution for the body, with parameters

σ = 1.625 and µ = 3.353, and a Pareto distribution for

the tail, with parameters α = 0.90411 and β = 103.

On the other hand, the query popularity follows a

Zipf-like distribution with α = 1 and N = 5. This is

because the available contents have been divided in 5

different popularities.

For inter-arrival times, a Weibull distribution with

scale parameter k = 0.62 is used, as it was presented

in (Stutzbach and Rejaie, 2006). In the same way, the

session length is modelled with a Weibull distribution

with shape and scale paramters k = 0.59 and λ = 41.9.

These parameters are introduced in a OverSim facility

(ChurnGenerator) which manages the peers birth and

death processes automatically.

Finally, regarding of the dynamic characteristics

of stored ﬁles, (Stutzbach et al., 2007) is the ﬁrst

study that has explored it. However, it has not been

implemented in our simulation model. The reason is

that the previous work depicts the evaluated CDF for

this characteristic but it does not present an analytical

model to represent it.

BEHAVIOR CHARACTERIZATION AND PERFORMANCE EVALUATION OF A HYBRID P2P FILE SHARING

SYSTEM

1 2 3 4 5

0,01

0,1

Query Rank

Relative Frequency of Query

Fitted Zipf

Measured Query Popularity

Figure 3: Query popularity.

0 10 20 30 40 50 60 70

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

Time (days)

Probability Content in Super−Peer

Figure 4: Probability that the content is in the super-peer.

5 SIMULATION MODEL

RESULTS

In this section the simulation results are presented. To

better understand the performances, the results have

been divided in two scenarios: In the ﬁrst one, called

static, the peers never die. In the second one, called

dynamic, the peer birth and death processes are con-

veniently modeled.

The parameters of the network are: 2,500 peers,

25,000 ﬁles and 50 super-peers. At the end of the

section, in order to characterize the model scalability,

considerations about simulation time, computational

and memory resource requests will be reported.

5.1 Static Overlay Network Simulations

First, we are interested in studying the P2P system

performance with respect to query popularity. It is

well known that the number of queries issued to re-

0 100 200 300 400 500 600 700

Queries

Number of Visited Super−Peers

Figure 5: Number of visited super-peers.

0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500

Queries

Number of Found Sources

Figure 6: Number of found sources.

quest a speciﬁc ﬁle is directly connected to its pop-

ularity. Due to the popularity has been assigned to

every query according to Zipf distribution, it is rea-

sonable that the number of queries issued during a

simulation has somehow to follow the Zipf popular-

ity distribution. These results are presented in Fig. 3,

which shows (in logarithmic scale) that the number of

queries performed in the simulation perfectly matches

with a Zipf distribution.

Fig. 4 shows the probability that the requested

content is in the same requester’s sub-group. It is

observed that this probability grows as the time in-

creases, but converging to a value of one, which as-

sures that our system reaches a steady state. This also

indicates that with the typical (real) parameters that

model the queries behavior our architecture assures

that, in one month, the contents will be almost equally

distributed among all the sub-groups.

Fig. 5 reports the number of consulted super-

peers for the queries that cannot be resolved in the

requester’s subgroup. In this case, a multicast process

ICSOFT 2008 - International Conference on Software and Data Technologies

100

0 50 100 150 200 250 300 350 400 450

x 10

Time (h)

Number of Messages by Hour

Figure 7: Number of control messages.

starts and tries to send the query to all the super-peers.

However, when a super-peers has a reference to a peer

which can resolve the query, it immediately stops the

multicast process. As it can be seen, the number of

consulted super-peers decreases when the number of

queries increses, because the proposal is able to efﬁ-

ciently distributed the most popular contents among

all the subgroups. This behavior can be viewed more

precisely following the time behavior of the average

value of this parameter which it is also represented.

Finally Fig. 6 represents, for each query, the num-

ber of found peers wich have the requested content.

For the ﬁrst queries, the number of peers increases

because the multicast procedure is frequently used.

However, when the number of queries is high enough

they are resolved in the requester’s subgroup. The

ﬁgure also represents the average value, which shows

that this parameters slowlyincreases and will stabilize

around 50 peers when time tends to inﬁnity, because

every subgroup is composed by this number of peers.

5.2 Dynamic Overlay Network

Simulations

In this simulation session, birth and death events of

peers and super-peers are also considered, driving, in

this way, the analysis to the case of dynamic overlay

networks closer to the reality.

In the dynamic scenario it has been noticed a lit-

tle increasing of the overall number of issued queries

with respect to the static situation. This behavior can

be explained by considering that, in the dynamic case,

all peer joining the network immediately execute a

query. Moreover, it has to be considered that when

the peers in the system reach the saturation, they do

not make any more queries, as they are sharing most

of the ﬁles. This effect is mitigated by the overlay net-

Table 1: Simulation Speed.

Number of nodes Simul. sec. / Real sec.

500 112.861

1000 46.3345

1500 26.6125

2000 18.9614

3000 10.4441

5000 4.4518

10000 3.1518

Table 2: Memory Consumption.

Number of nodes Memory [Mb]

500 30.72

1000 51.2

1500 73.72

2000 96.25

3000 141.31

5000 229.37

10000 315.39

work dynamism, since this last introduces a replace-

ment process of peers: in fact, while satured peers

dead, new and non-saturated peers enter the system.

Fig. 7 represents the average number of control

messages in function of time. These messages are

sent in order to update the overlay network architec-

ture when a super-peer dies. In steady state the av-

erage number of control messages is under 10,000

messages by hour. Usually, control messages have a

small payload (about 10 bytes) and a TCP/IP header

(40 bytes). If we suppose each control message has a

length of 50 bytes, control trafﬁc supposes only a 1.1

kbps trafﬁc rate.

5.3 Simulator Scalability

In this section we present the OverSim overall perfor-

mance. Table 1 represents the ratio between the simu-

lated seconds and the real seconds, for different num-

ber of nodes. For example, for 500 nodes in one real

second OverSim is able to simulate 112.861 seconds.

These results have been obtained using a Intel Core 2

architecture at 2.13 GHz with 2 GB of RAM memory.

We observe that the simulation speed decreases in an

exponential way when the number of nodes increases.

This is due to the increment in the number of overlay

connections among all the nodes in the network.

Table 2 represents the memory consumption as a

function of the number of simulated nodes. In this

case, the amount of memory increases linearly with

the number of nodes.

BEHAVIOR CHARACTERIZATION AND PERFORMANCE EVALUATION OF A HYBRID P2P FILE SHARING

SYSTEM

101

6 CONCLUSIONS

The main contribution of this paper is twofold: First,

to adequately characterize the real behavior of P2P

overlay networks (including dynamic and static as-

pects) and second, evaluate a hybrid P2P overlay net-

work proposed by the authors under the above con-

straints using one of the most popular (high level and

user friendly) simulation framework.

Among all the available tools we have chosen

OverSim because of its ﬂexibility. Its modular de-

sign and the use of the Common API facilitate the ex-

tension with new protocols. We have also described

the most recent models for the characterization of the

queries, the dynamicsof peer participation and the dy-

namics characteristics of stored ﬁles.

The overall performance ﬁgures of the simulation

are also presented and discussed. They reveal that the

exposed methodology can be easily applied and used

by the research community to obtain interesting and

useful R&D results.

ACKNOWLEDGEMENTS

This research has been supported by project grant

TEC2007-67966-C03-01/TCM(CON-PARTE-1) and

it is also developed in the framework of ”Programa

de Ayudas a Grupos de Excelencia de la Regi´on de

Murcia, de la Fundaci´on S´eneca, Agencia de Ciencia

y Tecnolog´ıa de la RM (Plan Regional de Ciencia y

Tecnolog´ıa 2007/2010)”. Juan Pedro Mu˜noz-Gea also

thanks the Spanish MEC for a FPU (AP2006-01567)

pre-doctoral fellowship.

REFERENCES

Baumgart, I., Heep, B., and Krause, S. (2007). Oversim:

A ﬂexible overlay network simulation framework. In

Proceedings of 10th IEEE Global Internet Symposium

(GI ’07) in conjunction with IEEE INFOCOM 2007,

Anchorage, AK, USA.

Dabek, F., Zhao, B., Druschel, P., Kubiatowicz, J., and

Stoica, I. (2003). Towards a common api for struc-

tured peer-to-peer overlays. In Proceedings of the

2nd International Workshop on Peer-to-Peer Systems

(IPTPS03), Berkeley, CA.

El-Ansary, S., Alima, L. O., Brand, P., and Haridi, S.

(2003). Efﬁcient broadcast in structured p2p net-

works. In IPTPS, pages 304–314.

Klemm, A., Lindemann, C., Vernon, M. K., and Waldhorst,

O. P. (2004a). Characterizing the query behavior in

peer-to-peer ﬁle sharing systems. In IMC ’04: Pro-

ceedings of the 4th ACM SIGCOMM conference on

Internet measurement, pages 55–67, New York, NY,

USA. ACM.

Klemm, A., Lindemann, C., and Waldhorst, O. P. (2004b).

Relating query popularity and ﬁle replication in the

gnutella peer-to-peer networks. In Proc. 12th GI/ITG

Conf. on Measuring, Modelling and Evaluation of

Computer and Communication Systems (MMB), Dres-

den, Germany.

ModelNet (2005). Modelnet. http://modelnet.ucsd.edu.

Mu˜noz-Gea, J. P., Malgosa-Sanahuja, J., Manzanares-

Lopez, P., Sanchez-Aarnoutse, J. C., and Guirado-

Puerta, A. M. (2006). A hybrid topology architecture

for p2p ﬁle sharing systems. In Proceedings of the 1st

International Conference on Software and Data tech-

nologies (ICSOFT 2006), Set´ubal, Portugal.

Naicken, S., Livingston, B., Basu, A., Rodhetbhai, S.,

Wakeman, I., and Chalmers, D. (2007). The state of

peer-to-peer simulators and simulations. SIGCOMM

Comput. Commun. Rev., 37(2):95–98.

Overlay Weaver (2007). Overlay weaver:

An overlay construction toolkit.

http://overlayweaver.sourceforge.net/.

OverSim (2007). The oversim p2p simulator.

http://www.oversim.org/.

P2PSim (2005). P2psim: A simulator for peer-to-peer pro-

tocols. http://pdos.csail.mit.edu/p2psim/.

PeerSim (2006). Peersim: A peer-to-peer simulator.

http://peersim.sourceforge.net/.

PlanetSim (2005). Planetsim: Object oriented

simulation framework for overlay networks.

http://planet.urv.es/trac/planetsim/.

Steinmetz, R. and Wehrle, K., editors (2005). Peer-to-Peer

Systems and Applications, volume 3485 of Lecture

Notes in Computer Science. Springer.

Stoica, I., Morris, R., Liben-Nowell, D., Karger, D. R.,

Kaashoek, M. F., Dabek, F., and Balakrishnan, H.

(2003). Chord: a scalable peer-to-peer lookup proto-

col for internet applications. IEEE/ACM Trans. Netw.,

11(1):17–32.

Stutzbach, D. and Rejaie, R. (2006). Understanding churn

in peer-to-peer networks. In IMC ’06: Proceedings

of the 6th ACM SIGCOMM conference on Internet

measurement, pages 189–202, New York, NY, USA.

ACM.

Stutzbach, D., Zhao, S., and Rejaie, R. (2007). Characteriz-

ing ﬁles in the modern gnutella network. Multimedia

Syst., 13(1):35–50.

ICSOFT 2008 - International Conference on Software and Data Technologies

102
