APPLICATION OF GENETIC PROGRAMMING IN SOFTWARE

ENGINEERING EMPIRICAL DATA MODELLING

Athanasios Tsakonas and Georgios Dounias

Department of Financial and Management Engineering, University of the Aegean, 31 Fostini St., Chios, Greece

Keywords: Genetic programming, software engineering, data mining, effort estimation, defect prediction.

Abstract: Research in software engineering data analysis has only recently incorporated computational intelligence

methodologies. Among these approaches, genetic programming retains a remarkable position, facilitating

symbolic regression tasks. In this paper, we demonstrate the effectiveness of the genetic programming

paradigm, in two major software engineering duties, effort estimation and defect prediction. We examine

data domains from both the commercial and the scientific sector, for each task. The proposed model is

proved superior to past literature works.

1 INTRODUCTION

Among the software engineering management

duties, the effort estimation and the assessment of

the software quality are still considered challenging

tasks. Undoubtedly, an enhancement in software

effort estimation could affect dramatically the

overall project cost. Accordingly, appropriate quality

assessment can also result into proper resource

allocation and avoidance of further expenditures. In

the past, various parametric models, such as

COCOMO (Boehm, 1980), have been used for

software effort estimation. To address software

quality, the development of code metrics has taken

place, aiming to facilitate the diagnosis of error-

prone code (McCabe, 1976). Most of these models

make use of past information, in an attempt to

develop simple or complex mathematical

expressions, usually in ad-hoc or exhaustive

manners. On the other hand, the genetic

programming paradigm (Koza, 1992), which has

been around during the last decades, is applied in

numerous domains, successfully addressing data

mining and knowledge extraction tasks. The

evolutionary search and the expression ability of the

genetic programming have made this approach a

popular research tool in symbolic regression

problems. Consequently, this paradigm is expected

to provide competitive results into the effort

estimation and the prediction of error-prone code in

software projects. In this paper, the genetic

programming approach is applied into the two

aforementioned software engineering tasks, effort

estimation and defect prediction. Regarding effort

estimation, we aim to provide symbolic regression,

deriving accurate and small-sized expressions. For

this, we examine datasets from both a commercial

software domain, and a scientific one. In respect to

prediction of error-prone code, the target is to

produce discriminators between faulty and non-

faulty modules, in the form of if-then rules. These

formulas should be relatively small and accurate.

Here too, two domains are examined, one from the

commercial sector, and a scientific one. The genetic

programming system we used, adopts recent

developments in respect of the operation rates and

the use of the validation set. The paper is organized

as follows. Next section describes the scientific

background, presenting in short the characteristics of

the examined software engineering tasks and the

genetic programming principle. Section 3 describes

the data domains and the GP system design. The

results and a followed discussion are shown in

Section 4. The paper ends with our conclusions and

future directions in Section 5.

2 BACKGROUND

One of the principal factors affecting the software

project cost is the labor cost. Effort estimation and

defect prediction aim to effectively allocate

personnel in tasks and assure the software quality,

both helping at reducing the software project cost.

295

Tsakonas A. and Dounias G. (2008).

APPLICATION OF GENETIC PROGRAMMING IN SOFTWARE ENGINEERING EMPIRICAL DATA MODELLING.

In Proceedings of the Third International Conference on Software and Data Technologies - PL/DPS/KE, pages 295-300

DOI: 10.5220/0001871302950300

 SciTePress

The software project effort estimation involves the

definition of resources, the management of the

development activities and the calculation of the

estimation risk (Lum et al., 2003). There are four

types of effort estimation: historical analogy,

experts’ decision, use of models and rules-of-thumb.

Historical analogy is used when there are similar

data available from the past and it involves

comparison, using measures or data that has been

observed in previous software works. Experts’

decision describes the estimates produced by a

human expert based on what he has experienced

from past projects. Use of models is estimating by

mathematical or parametric cost models (which are

derived usually statistically). Finally, rules-of-thumb

are used for effort estimation, usually in the form of

very simple mathematical equations. A data-mining

task is therefore a historical analogy approach.

Depending on the problem encountered, various data

can be recorded for use. Two such domains are

described in Table 1 and Table 2. On the other hand,

aiming to enhance software quality and the resources

allocation, various approaches of software code

assessment have been developed, such as the static

code metrics. These mostly come from the research

of (McCabe, 1976) and (Halstead, 1977). McCabe’s

metrics are the cyclomatic complexity, the essential

complexity, the design complexity and the number of

lines of code. Cyclomatic complexity, v(G), counts

the number of linearly independent paths:

v(G) = e – n +2 (1)

where G is the module's flow-graph, e are the

arcs in the flow-graph, and n are the nodes. The

essential complexity, ev(G), measures the potential

shrink of the flow-graph:

ev(G)= v(G) – m (2)

where m are the sub-flow-graphs of G that are

D-structured primes (Fenton and Pfleeger 1977).

Design complexity, iv(G), is the cyclomatic

complexity of a module's reduced flow-graph

(McCabe, 1976). Lines of code are counted based on

to McCabe's conventions. Halstead’s measures are

classified into three groups: base measures, derived

measures and measures related to lines of code.

Table 4 summarizes the aforementioned measures.

Other frameworks are often adopted for defect

prediction, regarding special needs of a project, such

as the Quality Improvement Paradigm (QIP) (Basili

et al., 1994), in order to apply a systematic quality

assurance, by reusing the experience. This

framework involves software measurement and

analysis from carefully designed experiments. The

metrics selected from such an approach, are shown

in Table 3. Genetic programming - GP (Koza, 1992)

is an advance to the genetic algorithms paradigm.

This paradigm enables symbolic regression, i.e. the

search for complex solutions in the form of

mathematical formulas. Further research extended

this concept to calculate any kind of boolean or

programming expression. Although widely used

during the last two decades, the GP has only recently

been applied into software engineering tasks, such as

the evaluation of software project managers

(Boetticher et al., 2006). In order to improve the

search and expression ability, the function set that

composes a GP desired solution is often traced with

the aid of a grammar. Here, we apply grammar-

guided search for the two defect prediction tasks

(e.g. classification problems), using a context-free

grammar for the production of if-then hierarchical

rules (Tsakonas and Dounias, 2002).

3 SYSTEM DESIGN

3.1 Domain Description

The following detailed description of the datasets

aims to denote the high variance in their

composition (in terms of the features used), which

could assist in generalising on the performance of

our system. Regarding effort estimation, we first

address the Desharnais domain. This is consisted of

Canadian software house data for commercial

projects (Desharnais, 1989). It contains 81 records.

Table 1 summarizes the variables’ descriptions.

Table 1: Desharnais data feature description.

Variable Explanation

TEM Team experience (in years)

MNG Manager experience (in years)

YER Year end

LEN Length

TRN System’s basic transactions

ENT # entities in the system’s data model

PTA Adjusted points

ENV Envergure

PTN Non-adjusted points

LAN Language

Person-months Effort in months (regression target)

The NASA93 dataset consists of 93 NASA projects

from different centres for projects taken place

between 1971-1987. This software comes from the

aerospace domain. There are 17 attributes that are all

numeric: 15 attributes are the effort multipliers, one

ICSOFT 2008 - International Conference on Software and Data Technologies

296

is the Lines-of-Code (LOC) and one attribute is the

actual development effort. The LOC variable has

been estimated directly or computed beforehand,

using function point analysis (Dreger 1989).

Table 2: NASA93 data description.

Variable Explanation

rely Required software reliability

data Data base size

cplx Process complexity

time Time constraint for CPU

stor Main memory constraint

virt Machine volatility

turn Turnaround time

acap Analysts capability

aexp Application experience

pcap Programmers capability

vexp Virtual machine experience

lexp Language experience

modp Modern programming practices

tool Use of software tools

sced Schedule constraint

ln(KSLOC) Software size lines-of-code

ln(months) Effort in months (regression target)

Table 3: Datatrieve data description – measurements

according to QIP.

Variable Explanation

LOC60 Number of LOC of module m in version 6.0

LOC61 Number of LOC of module m in version

6.1.

aLOC LOC added to module m in v.6.1

dLOC LOC deleted from module m in v.6.0

DBLK Number of different blocks module m

between versions 6.0 and 6.1

MRAT Rate of modification of module m, equals to

(

)

(

60 a

)

OC dLOC LOC LOC

MKNW Team's knowledge on module m

rLOC LOC of module m in v.6.0 reused in v.6.1

Class 0 for non-faulty modules, 1 for the rest

The task is to tune a new cost model, for a given

background knowledge. Table 2 describes the

dataset features. The Datatrieve data set follows the

QIP approach and it contains 130 records (Morasca

and Ruhe, 2000). This data is from the Datatrieve

product, which was undergoing both adaptive and

corrective maintenance. The objective of the data

analysis is to examine whether it was possible to

predict the faulty modules based on a set of

measures that have been collected on the project.

Table 3 summarizes the descriptions of the

calculated features. The JM1 domain is consisted of

10,885 records that contain measurements from

NASA’s C modules of a real time predictive ground

system that uses simulations to generate predictions.

Table 4: NASA JM1 data description – McCabe and

Halsted metrics.

Variable Explanation

number of unique operators

number of unique operands

total occurrences of operators

total occurrences of operands

N N = N

+ N

(length)

mu mu = mu

+ mu

(vocabulary)

P P = V = N log

(mu) (volume)

V* V* = (2 + mu

') log

(2 + mu

L L = V * / N (program length)

D D = 1 / L (difficulty)

L’ L’= 1 / D

I I = L’ V’ (intelligence)

E E = V / L (effort to write program)

T T = E / 18

lco Halstead count of lines of code

lcm Halstead count of lines of comments

lcb Halstead count of blank lines

lcc Halstead count of LOC and comments

brc Branch count of the flow-graph

LOC

McCabe's lines of code

v(G)

v(G) = e – n +2

ev(G)

ev(G)= v(G) – m

iv(G) iv(G)=v(G), module's reduced flow-graph

class binary, whether the case had defects or not

This data has been publicly available by NASA’s

Metrics Data Program (MDP) (

http://mdp.

ivv.nasa.gov/

). It has 22 input features and one

binary output, whether the case had defects or not.

Table 4 summarizes the feature descriptions. All

these data are publicly available from the PROMISE

reporitory

(http:// promise.site.uottawa.

ca/SERepository/).

3.2 System Setup

We normalized each data set linearly (i.e. using the

min-max transformation) in the range [-1,1], in order

to improve the search process. The genetic

programming parameters are shown in Table 5. We

applied 10-fold cross validation, having each time a

10% of the data outside of the training procedure, to

be checked as test set. A validation set is used to

avoid overfitting to the training set. In order to

promote a solution that carries a higher value in the

training set, the candidate should either also have a

higher value in the validation set or the absolute

difference between validation fitness and training

APPLICATION OF GENETIC PROGRAMMING IN SOFTWARE ENGINEERING EMPIRICAL DATA MODELLING

297

fitness score should be smaller, the latter being a

property empirically driven during our experiments,

found to increase generalization strength. For the

regression problems (effort estimation), as fitness

measure we have used the mean magnitude relative

error, MMRE, (eq. 3):

100

MMRE

−

∑

(3)

Due to critics on using a single measure for

evaluating models (Foss et al., 2003), as well as for

comparison reasons, the measures (4)-(6) are also

calculated:

()()

= /

ii ii

RSE y y y y

−−

∑∑

(4)

ii ii

AE yy yy

−−

∑∑

(5)

100

PRED( )=

100

otherwise

−

⎧

⎪

−

⎪

≤

⎪

⎨

⎪

⎩

∑

(6)

In all above equations,

: actual value of case i,

: estimated value of case i,

: mean value of test set

cases,

n : number of cases in test set,

: value

(range) for which the PRED function is calculated,

usually being equal to 25 or 30. For the

classification problems (defect prediction) we

selected the fitness function as follows. When the

system classifies a case, the following situations

may happen (Koza, 1992): tp: true positive, fp: false

positive, tn: true negative and, fn: false negative,

according to. Taking in respect these outcomes, we

used the following measure as fitness function

(Berlanga et al. 2005):

support=

tp tn

pd TNRate

tp fn tn fp

⋅=⋅

(7)

As other measures have been proposed in

literature (Menzies et al. 2007), they are also

calculated in our experiments; these are the

precision, the pf (probability of failure) and the

accuracy:

prec

ptp

(8)

tn fp

(9)

tp tn

accuracy

tp tn fp fn

++ +

(10)

Table 5: Genetic programming parameter setup.

Parameter Value

Population 9,000 individuals

implementation

Steady-state GP (regression

problems)

Steady-state grammar-guided GP

(classification problems)

Selection Tournament of 6 with elitist strategy

Training 10-fold cross validation

Crossover/

Mutation/ Copy

Adaptive (Tsakonas and Dounias,

2007)

Maximum size 650 nodes

Maximum

generations

200

4 RESULTS AND DISCUSSION

In order to allow direct comparison between the

proposed system and the past work, we selected to

report our results, for each dataset, using the

measures that past literature has adopted. Addressing

the effort estimation task, we first examine the

Desharnais domain. In Table 6, the results from our

10-fold validation are presented together with test

results from WEKA’s (

http://

www.cs.waikato.ac.nz/~ml/weka/) linear

regression system (10-fold validation) and the best

model from the work in (Shepperd and Schofield,

1997). The latter, previous work results are the only

ones found in literature, concerning this data set. As

it can be seen, our system maintains the highest

values in all compared accuracy measures. The

following simple solution was derived in fold #1, it

uses the adjusted points and the number of entities,

and it achieved 100% PRED(25).

()()()

0.1

NNN

ersonhours PTA ENT=−⋅

(11)

where

()

⋅ denotes that the normalized

values of the corresponding variables are used.

Table 6: Results comparison for the Desharnais effort

estimation domain.

RRSE RAE MMRE Pred(25)

WEKA L-R 67.7 64.99 n/a n/a

Shepperd n/a n/a 64 42

This work 67.15 62.01 31.32 77.78

The next domain to examine in regard of effort

estimation is the NASA93 data set. This problem has

only been addressed in (Menzies et al., 2006). Table

7 compares our 10-fold validation results to the best

of the models reported in that work. As it can be

ICSOFT 2008 - International Conference on Software and Data Technologies

298

seen, our model has the highest Pred(30) and a

competitive MMRE, whilst the standard deviation

remains the smallest.

Table 7: Results comparison for the NASA93 effort

estimation domain.

Pred(30) MMRE

mean

sd%

nasa93:center.2

83 22 38

nasa93:project.Y

78 22 20

nasa93:fg.g

65 32 39

This work 85.78 23.25 17.31

The following small solution that was derived in

fold #2, uses only one feature (apart KSLOC), and it

achieved 100% PRED(25).

()

ln ln 0.2

months KSLOC cplx=+⋅

(12)

where

()

⋅

is the symbol for the normalized

values of the corresponding variables, as previously.

Regarding the defect prediction task, we first

address the Datatrieve problem. The only past

research where this data is examined is in (Morasca

and Ruhe, 2000), using logistic regression and rough

sets (leave-one-out cross validation). We have

included the same measures for comparison reasons.

Table 8 presents analytic results of our model. Table

9 compares the three systems in terms of

classification accuracy, precision and recall. As it

can be seen, our system outperformed the previous

two in terms of accuracy. Our GP system has shown

more balanced results than the past models, since it

achieves high precision rate and good recall rate

whilst having the higher overall accuracy of all three

systems.

Table 8: Results in Datatrieve problem.

GP Predicted

non-

faulty

Predicted

faulty

Total

Actual

non-faulty

90.0% 3.8% 93.8%

Actual faulty 1.5% 4.6% 6.2%

Total 91.5% 8.5% 100%

One derived GP solution is shown in Figure 1, in

prefix notation. This is the #1 fold best solution and

it achieved 100% accuracy in the test set. As it can

be seen, all the available features from Table 3 -

except

LOC60- are used for making the

classification. In this formula,

CLS0 corresponds to

non-faulty class and

CLS1 to the faulty one.

Table 9: Results comparison for the Datatrieve defect

prediction domain.

Precisio

Recall

(pd)

Accurac

Logistic

Regressio

90.6% 21.3% 70.8%

Rou

h sets 50.0% 70.6% 93.8%

This wor

75.0% 54.5% 94.6%

IF> MKNW 0.76 (IF< aLOC -0.45 (IF<

LOC61 -0.35 CLS0 CLS1) CLS1) (IF= dLOC

1.05 (IF> LOC61 0.53 CLS0 (IF< CLS1 -

0.12 CLS1 (IF= DBLK 1.06 CLS0 (IF= MRAT

0.29 CLS0 CLS0)))) CLS0))

Figure 1: Hierarchical rule tree for the Datatrieve domain.

The next defect prediction domain to address is

the NASA JM1 data set. This problem has been

addressed previously only in (Menzies et al., 2004).

Table 10 compares the 10-fold validation mean, with

these literature results. As it can be seen, our system

outperformed the previous model regarding pd

(probability of detection).

Table 10: Results comparison for the NASA JM1 defect

prediction domain.

pd pf Precision Accuracy

Menzies et

al.

25 18 n/a n/a

This work 64.2 32.01 32.53 67.26

The solution in Figure 2, presented here in prefix

notation, derived during fold #10, and it has pd equal

to 66.67%, pf equal to 32.2%, precision 33.1% and

accuracy 67.58%. Here too in this formula,

CLS0

corresponds to non-faulty class and

CLS1 to the

faulty one. For the rest variables in this expression,

the reader is referred to Table 4.

5 CONCLUSIONS

This work presented the application of the genetic

programming for software engineering data analysis.

The problems addressed were selected in respect of

the data availability and the potential of applying

historical analogy estimation. The genetic

programming system incorporated recent advances

in respect of the operator rates and the use of the

validation set. Two tasks were designated aiming to

contribute in software cost control and software

APPLICATION OF GENETIC PROGRAMMING IN SOFTWARE ENGINEERING EMPIRICAL DATA MODELLING

299

quality. The first task was to produce effort

estimators using GP symbolic regression. The

second task was to produce classification rules using

grammar-guided GP for if-then rules. For each

problem, two available datasets were examined. In

the regression task of effort estimation, the system

produced short and comprehensible mathematical

expressions that outperformed previous models. In

the classification task of defect prediction, the

system produced the best-so-far or otherwise

competitive results, while succeeding in deriving

small hierarchical rule trees. Although the system

has been proved capable of producing highly

accurate and meaningful results for each case, this

success is only domain dependent, e.g. it seems that

due to the different dataset compositions, there is no

ability to drive overall conclusions on each of the

two tasks (effort estimation, defect prediction).

Further research involves the application of other

computational intelligent approach in these domains,

such as neuro-fuzzy rule-based systems, as well as

the application of genetic programming into other

related software engineering issues.

(IF= (% D 0.35) 0.01 CLS1 (IF> I -0.84

(IF> I -0.84 (IF> LOC -0.98 CLS1 CLS0)

(IF> LOC -0.98 CLS1 CLS0)) (IF> I -0.85

CLS1 (IF< LBL -0.98 (IF> L -0.53 CLS0

(IF> EVG -0.83 CLS1 (IF= (% D 0.35)

0.01 CLS1 (IF> I -0.84 (IF> I -0.84

(IF> LOC -0.98 CLS1 CLS0) (IF> LOC -

0.98 CLS1 CLS0)) (IF> I -0.85 CLS1 (IF<

IVG 0.06 (IF> I -0.80 (IF> I -0.83 CLS1

(IF= (% D 0.36) 0.01 CLS1 (IF> I -0.85

CLS1 (IF> LOC -0.98 CLS1 CLS0)))) (IF>

L -0.53 CLS0 (IF> I -0.87 CLS1 (IF> I -

0.85 CLS1 (IF> TON -0.82 CLS1 (IF> LOC

-0.98 CLS1 CLS0)))))) CLS1))))))

CLS1))))

Figure 2: Hierarchical rule tree for the NASA JM1

domain.

REFERENCES

Basili V.R., Caldiera G., and Rombach H.D., 1994,

Experience Factory, in Marciniak, J.J., Ed.,

Encyclopedia of Software Engineering, Vol. 1, pp.

469-476, John Wiley & Sons.

Berlanga F.J., del Jesus M.J., Herrera F., 2005, Learning

compact fuzzy rule-based classification systems with

genetic programming, in EUSFLAT05, 4th Conf. of the

European Society for Fuzzy Logic and Technology,

Barcelona, pp. 1027-1032.

Boehm B., 1981, Software Engineering Economics,

Prentice-Hall.

Boetticher, G., Lokhandwala, N., James C. Helm, 2006,

Understanding the Human Estimator, in 2

Int’l

Predictive Models in Soft. Eng.Workshop,

Philadelphia, PA, Sep. 2006.

Desharnais J.M., Analyse statistique de la productivite des

projets informatique a partie de la technique des point

des fonction, 1989, MSc thesis, Univ. of Montreal.

Dreger J., 1989, Function Point Analysis, Englewood

Cliffs, NJ, Prentice Hall.

Fenton N.E., and Pfleeger S., 1997, Software Metrics: A

Rigorous and Practical Approach, Thompson Press.

Foss T.,Stensrud E., Kitchenham B., Myrtveit I., 2003, A

Simulation Study of the Model Evaluation Criterion

MMRE, IEEE Trans. on Soft. Eng., 29:11, Nov. 2003.

Halstead M., 1977, Elements of Software Science,

Elsevier.

Koza J.R., 1992, Genetic Programming: On the

Programming of Computers by Means of Natural

Selection, Cambridge, MA, MIT Press.

Lum K., Bramble M., Hihn J., Hackney J., Khorrami M.

and Monson E., 2003, Handbook of Software Cost

Estimation, Jet Propulsion Laboratory, Pasadena, CA,

USA.

McCabe T., 1976, A Complexity Measure, IEEE Trans.

Software Eng.,2:4, pp. 308-320.

Menzies T., DiStefano J., Orrego A., and Chapman R.,

2004, Assessing Predictors of Software Defects, in

Proc. PSM-2004, Workshop in Predictive Software

Models, Chicago, IL.

Menzies T, Chen Z., Hihn J., and Lum K., 2006, Selecting

Best Practices for Effort Estimation, IEEE Trans.

Software Eng. 32:11, Nov 2006.

Menzies T., Dekhtyar A., Distefano J., Greenwald J.,

2007, Problems with Precision: A Response to

"Comments on; Data Mining Static Code Attributes to

Learn Defect Predictors, IEEE Trans. on Soft. Eng.,

33: 9, Sept. 2007 pp. 637 - 640.

Morasca S., and Ruhe G., 2000, A hybrid approach to

analyze empirical software engineering data and its

application to predict module fault-proneness in

maintenance, J. of Systems and Software, 53:3, Sep.

2000, pp. 225 – 237, Elsevier

Shepperd M. J., and Schofield C.,1997, Estimating

software project effort using analogies, IEEE Trans.

on Soft. Eng., 23, pp. 736-743.

Tsakonas A., Dounias G., Hierarchical Classification

Trees Using Type-Constrained Genetic Programming,

in Proc. of 1st Intl. IEEE Symposium in Intelligent

Systems, Varna, Bulgaria, 2002.

Tsakonas A., and Dounias G., Evolving Neural-Symbolic

Systems Guided by Adaptive Training Schemes:

Applications in Finance, App. Art. Intell., 21:7, 2007,

pp. 681-706.

ICSOFT 2008 - International Conference on Software and Data Technologies

300
