DSAW

A Dynamic and Static Aspect Weaving Platform

Luis Vinuesa, Francisco Ortin, José M. Félix and Fernando Álvarez

Computer Science Department, University of Oviedo, Calvo Sotelo s/n – 33007 Oviedo, Spain

Keywords: Aspect Oriented Programming, static, dynamic, reflection, code instrumentation, performance, flexibility.

Abstract: Aspect Oriented Software Development is an effective realization of the Separation of Concerns principle.

A key issue of this paradigm is the moment when components and aspects are weaved together, composing

the final application. Static weaving tools perform application composition prior to its execution. This

approach reduces dynamic aspectation of running applications. In response to this limitation, dynamic

weaving aspect tools perform application composition at runtime. The main benefit of dynamic weaving is

runtime adaptability; its main drawback is runtime performance.

Existing research has identified the suitability of hybrid approaches, obtaining the benefits of both methods

in the same platform. Applying static weaving where possible and dynamic weaving when needed provides

a balance between runtime performance and dynamic adaptability. This paper presents DSAW, an aspect-

oriented system that supports both dynamic and static weaving homogeneously over the .Net platform. An

aspect can be used to adapt an application both statically and dynamically, without needing to modify its

source code. Moreover, DSAW is language and platform neutral, and source code of neither components

nor aspects is required.

1 INTRODUCTION

Aspect Oriented Software Development AOSD

(Kiczales, 1997) is a concrete approach of the

Separation of Concerns (SoC) principle. AOSD

offers a direct support to modularize different

concerns that cut across the main functionality of

applications. Separating the application functional

code from its crosscutting aspects, the application

source code would not be tangled, being easy to

debug, maintain and modify (Parnas, 1972). Typical

examples of cross-cutting concerns are persistence,

authentication, logging and tracing (Ortin, 2004).

The process of integrating the aspects into the

main application code is called weaving and a tool

called aspect weaver performs it. The weaving

process can be performed statically or dynamically

at runtime.

Most programming environments that offer

AOSD employ static weavers. Once the final

application has been weaved, compiled and

executed, it is not possible to add new aspects, or

remove existing ones, at runtime. However, there are

specific scenarios when it is necessary to adapt

running applications in response to runtime

emerging requirements (Popovici, 2001), (Zinki,

1997), (Matthijs, 1997), (Segura–Devillechaise,

2003). In these cases, dynamic weavers are a

powerful tool to create runtime adaptable software.

The main benefit of static weaving is runtime

performance. Since the combination of components

and aspects is performed prior to application

execution, there is little performance cost when

compared to traditional object-oriented development

(Böllert, 1999), (Haupt and Mezini, 2004). On the

other hand, dynamic weaving AOSD tools imply a

performance penalty.

Dynamic weaving provides higher flexibility in

the development of software. While developing

aspect-oriented applications, the dynamic adaptation

mechanism is preferable because it facilitates

incremental weaving and makes application

debugging easier (Ortin and Cueva, 2002). Upon

deployment, aspects that do not need to be adapted

at runtime should be woven statically for

performance reasons.

Another limitation of existing runtime weavers is

a more reduced join-point set, because runtime

adaptation is more complicated to be implemented

(Blackstock, 2004).

Previous work has identified the appropriateness

of integrating both static and dynamic weaving in

the same development environment (Blackstock,

Vinuesa L., Ortin F., M. Félix J. and Álvarez F. (2008).

DSAW - A Dynamic and Static Aspect Weaving Platform.

In Proceedings of the Third International Conference on Software and Data Technologies - PL/DPS/KE, pages 55-62

DOI: 10.5220/0001872900550062

 SciTePress

2004), (Böllert, 1999), (Gilani et al, 2007). Benefits

of both approaches would be obtained in the

software development process. This approach is the

result of applying the separation of the weaving-time

concern to AOSD. This process should be performed

transparently, reducing the impact of changing this

concern in the application’s source code. As an

example of this benefit, the programmer could use

non-invasive dynamic weaving for agile

development. Once the application has been tested,

static weaving, where possible, could be applied to

obtain a better runtime performance.

In this paper we present DSAW, an aspect

platform that support both static and dynamic

weaving. DSAW offers the better performance of

static weaving and the agile interactive development

of dynamic weaving in a transparent way. Moreover,

DSAW is language and platform independent and it

has a set of join-points wider to most dynamic

weaving tools.

The rest of this paper is structured as follows. In

the next section we present a classification of AOSD

systems based on when the weaving is done and

describe some requirements on AOSD. We

introduce the basic architecture of the system

presented in section 3. Section 4 comments the

benefits we obtain with our system. Section 5 gives

an overview of some tools that offer static and

dynamic weaving and the conclusions are presented

in Section 6.

2 ASPECT WEAVING

A classification of AOSD is based on when the

weaver is executed. Static tools perform weaving

prior to application execution. A well-know example

of static weaving is AspecJ (Kiczales, 2001). There

are AOSD tools that offer some kind of dynamic

adaptation of aspects, being PROSE (Popovici et al,

2001) (Nicoara and Alonso, 2005) and JBoss AOP

(JBoss, 2008) two well-known examples of this

approach.

Most dynamic AOSD systems are not totally

adaptable at runtime. The majority of them require

the static specification of which aspects are going to

be weaved at runtime. Others offer dynamic addition

of new aspects but they do not support dynamic

deletion. In addition, the set of join-points they offer

is significantly smaller than static ones (Blackstock,

2004) (Vinuesa and Ortin, 2004).

Although static weaving offers undeniable

performance benefits, it also involves some

limitations. If the weaving process is only static,

AOSD is not especially suitable for rapid

prototyping development. If we take logging or

testing aspects as an example, it is needed to weave,

compile, run and debug the application. Runtime

contexts should be reproduced and all the

information generated by the aspects analyzed. If

some error occurs, the application should be

modified, re-weaved, re-compiled and re-executed

(Böllert, 1997), (Eaddy, 2007c).

In case a dynamic weaver is used, aspects could

be added in the exact execution point indicated by

the user, and subsequently removed. Moreover,

application execution should not be stopped if we

want to modify an aspect, and debugging is easier

because of the non-intrusive weaving approach.

These different scenarios motivate the use of

static weaving where possible and dynamic weaving

when needed (Gilani et al, 2007), (Böllert, 1999),

(Schröder-Preikschat et al., 2006). A tool that

supports both techniques should define aspects

independently of when they are weaved. This

approach will benefit from both static and dynamic

weaving in the same system. The result is the

separation of the weaving-time aspect in the AOSD

process (Gilani et al, 2007).

Apart from the dynamism an aspect platform

would benefit from a language-neutrality feature.

Language independence permit the adaptation of

applications by aspects developed in a different

programming language. This promotes component

and aspect reutilization. Furthermore, if platform

neutrality is also achieved, aspect-oriented systems

could be run over any platform.

Another important characteristic of AOSD

systems is the adaptation of binary modules, where

source code is not required to adapt the application.

Taking into account all these requirements an

AOSD platform must support to obtain the benefits

previously described, we have developed the DSAW

(Dynamic and Static Aspect Weaving) platform.

This system offers both static and dynamic weaving,

a wide set of join-points, language and platform

neutrality, and an executable-level aspect injection.

3 DSAW

DSAW is a homogeneous static and dynamic

weaving aspect-oriented platform. Its main aim is to

achieve language and weaving-time neutrality. Not

only is it possible to weave aspects both statically

and dynamically, but also the same implementation

of components and aspects is maintained in both

scenarios. The application need not to be changed if

we need to make static a dynamic aspect and vice

ICSOFT 2008 - International Conference on Software and Data Technologies

versa. This way, it is possible to use aspect-

orientation for rapid prototyping (dynamic weaving)

and later optimize the released application (static

weaving) without performing any change to its

source code. The programmer should finally indicate

the trade-off between performance and flexibility,

regarding to the system requirements (Gilani et al,

2007).

One of the features that have been considered in

the design of DSAW is the set of join-points to be

provided. The collection of join-points DSAW offers

is similar to the one supplied by AspectJ (Kiczales,

2001). We currently support the following static and

dynamic join-points: method and constructor

execution, method and constructor call, field and

property read and write, field and property write,

and exception handling. We also provide before,

after, and around aspects.

The design of the platform has been performed

following the .Net standard reference (ECMA,

2006), without modifying, neither extending, the

semantics of the platform. This fact guarantees

complete platform independence, permitting the

deployment of our system over any .Net

implementation (such as Mono, SSCLI and

DotGNU).

DSAW performs software adaptation at the

intermediate language (IL) of the virtual machine –

executable files. This means that our weaver does

not require source code, and it is not language

dependent either.

Finally, point-cuts are specified by means of

XML documents that specify the mapping between

join-points and advices. The schema of this XML

documents is an evolution of the one used on the

Weave.Net platform (Weave.Net, 2008). We have

modified this original schema to provide wide set of

point-cut, similar to the one supplied by AspecJ.

This separation between point-cuts and advices

improves the reutilization of aspects. In fact, aspects

can be also treated as components. They may be

adapted by other aspects, statically or dynamically,

regardless of its programming language.

3.1 ReadyAOP

DSAW is the enhancement of a previous AOSD tool

called Ready (Really Dynamic) AOP (Vinuesa,

2007) (Vinuesa and Ortin, 2004). ReadyAOP is a

language and platform neutral system that offers a

real separation of aspects at runtime. It is possible to

add new aspects (and remove existing ones) to a

running application, even if the aspects were

developed later than the application. There is no

static coupling between components and aspects.

The system was implemented over the standard

.Net platform specification, obtaining full language

independence. The weaving process is performed at

the virtual machine level, without requiring

applications source code. Its join-point set is similar

to the one offered by AspectJ. Both ReadyAOP and

DSAW are freely available at

http://www.reflection.uniovi.es.

DSAW extends the core of ReadyAOP to

provide the programmer a transparent static and

dynamic weaving, maintaining all the advantages of

ReadyAOP. This way, it is possible to mix dynamic

and static aspects in the same application. It is also

possible to change in any moment of the software

development process if an aspect must be static or

dynamic. The programmer manages the trade-off

between performance and flexibility, following the

separation of the weaving-time concern.

3.2 System Architecture

Our system is composed of three main elements: 1)

the JoinPoint Injector (JPI) performs both static and

dynamic weaving; 2) the application server that

coordinates components with dynamic aspects; and

3) the aspect framework that consists of a set of

interfaces to integrate all the elements of the system

in dynamic weaving scenarios.

In our system, there are two stages in

applications life cycle. The first one is prior to

program execution. Once the application has been

compiled, the JoinPoint Injector (JPI) manipulates

the program, weaving static aspects and including

code to make possible a future dynamic aspect

weave.

The second stage of application life cycle is

about application execution. The running program is

launched together with its statically-weaved aspects.

The application server provides the dynamic

adaptation of the program at runtime. Any aspect,

making use of the interfaces defined in the aspect

framework, will be capable of adapting running

applications.

The application server is the Mediator

component of the system (Gamma, 1994). This

server works as a registry of running applications,

making them capable of being adapted by the

aspects. The application server offers the aspects the

list of running applications, facilitating their

adaptation at runtime.

The aspect framework provides a set of

interfaces that orchestrates all the elements of the

DSAW - A Dynamic and Static Aspect Weaving Platform

system at runtime. These interfaces are implemented

by the applications in order to be able to be adapted

at runtime. Applications do not implement these

interfaces explicitly. It is the JPI the responsible for

adding this implementation at weaving time.

In DSAW aspects could also be processed by the

JoinPoint Injector to become fully-functional

applications in our system –i.e. components.

3.3 Static Weaving and JoinPoint

Injection

Before to its execution, the application to be adapted

is processed by the JPI. The JPI receives the

application, aspects to be statically weaved, and the

XML document mapping join-points to advices. The

JPI generates a new program that includes the main

functionality plus the aspects that have been

statically weaved.

The JPI also instruments the application with

code that allows its dynamic adaptation by aspects at

runtime. Concretely, what is added is a Meta-Object

Protocol (MOP) that offers dynamic computational

reflection (Ortin, 2002). A MOP is a technique that

permits the dynamic adaptation of running

applications. This behavior is called computational

reflection.

This MOP modifies virtual machine semantics

such as the message passing mechanism or field

access. This way, it will be possible to adapt running

applications with dynamic aspects. Finally, the JPI

adds other functionalities of the platform such as

application registration at startup, intra-application

introspection, and application deregistration at exit

(Figure 1).

Application

.exe

Aspects

.dll

PointCuts

.xml

Aspects

Application

Adapted Application(.exe)

codefordynamicadaptation

Figure 1: Static weaving and JoinPoint injection.

The JPI performs the following operation:

1. The JPI takes the compiled application, its static

aspects, and the XML file that specifies the

join-point / advice mapping.

2. Analyzing the IL code, the JPI detects the

application join-point shadows -the mapping

between join-points and the points in the

program text where the compiler actually

operates- (Masuhara and Kiczales, 2003) .

3. When a join-point shadow is selected by any

point-cut described in the XML document, a

call to the selected advice is included into the

program’s IL code.

4. Besides the code added to the application

described in the previous point, a reflective

MOP is included in each join-point shadow.

This MOP will make the application capable of

being adapted at runtime by new runtime

aspects. In order to obtain a better runtime

performance this MOP injection could be

avoided in certain join-point shadows –this is

described in the XML file. This is part of the

trade-off between performance and runtime

adaptability.

5. The JPI adds new code to make the application

also included a deregistration routine at exit,

and the publication of .Net reflective

information to permit runtime aspects inspect

application’s structure.

6. The final application is generated.

3.4 Application Execution

The application, once processed by the JPI, has been

weaved together with its static aspects. These

aspects are included in the application until its

execution is over. If new static aspects should be

added, or any existing one removed, the JPI must re-

process the application.

However, if the application needs to be adapted

at runtime, our system will facilitate the dynamic

addition or deletion of aspects. Notice that this

behavior is obtained after the instrumentation of the

application by the JPI.

ICSOFT 2008 - International Conference on Software and Data Technologies

Aspects

Application

Adapted Application(.exe)

codefordynamicadaptation

Server

Aspect

1)App. registers itself

at startup (GUID)

2,6)Aspect sends

PointCuts and

GUID of the App.

to adapt

3,7)JoinPoint activation

4)Execution reaches

an activated JoinPoint

5)Aspect accesses

application to adapt it

8) App. Execution finished

Figure 2: Dynamic adaptation.

These are the steps followed at runtime to

dynamically adapt an application with dynamic

aspects (Figure 2):

1. At startup the application is registered into the

application server with a GUID. This GUID was

generated by the JPI during code

instrumentation and is used to identify the

application in the system.

2. Once the application is running, an aspect may

be used to dynamically adapt it. If so, the aspect

calls the application server via .Net remoting.

The information passed is a reference to the

aspect, a point-cut XML document, and the

GUID of the application to be adapted.

3. The application server parses the XML

document finding the point-cuts required by the

aspect. These point-cuts are activated in the

application join-points by means of the MOP

added in the JoinPoint injection phase. This

activation implies the precise call to the aspect

at runtime, making use of all the framework

services. The result of this process is a dynamic

weaving.

4. When the dynamically weaved application

execution reaches an activated join-point, the

system calls the aspects that have been

previously weaved with the application. Aspects

should implement the specific interfaces

described in the application framework

(Vinuesa and Ortin, 2004) to make this happen.

This way, the application will send the aspect

information regarding the join-point and the

own application (including a reference to the

application). The aspect has now the

opportunity to adapt the application behavior at

runtime.

5. The aspect may use the reference to the

application to access the latter by means of the

publication of .Net reflective services added by

the JPI. The operations offered by these

reflective services are inspection of the

application structure, field values modification,

and method invocation.

6. A runtime weaved aspect could have the

necessity of changing the point-cuts at runtime.

This operation is also offered by the application

server. The aspect should send a new XML

document specifying the new set of point-cuts.

The application server will then analyze this

XML file, activating new join-points and

deactivating old join-points in the running

application.

7. If a dynamic aspect does not want to adapt the

application any more, it notifies so to the

application server. The application server

deactivates the application join-points

previously turned on by the aspect. Therefore,

the aspect will not receive future notifications.

8. When the application execution finishes, the

code added by the JPI notifies all the registered

aspects and the application server that the

application has exited.

The application server acts as a mediator

between aspects and applications. This mediation is

only performed when join-points are activated or

deactivated. Once these operations have been

performed, the application and the aspect interact

directly one with the other. The application calls the

aspect when an activated join-point is reached. The

aspect may inspect the application when a join-point

notification is received.

With this design, applications do not need to

know the aspects that might be weaved at runtime.

At the same time, aspects can be applied to any

application, or even aspects, without any static

dependency. This behavior reduces coupling and

promotes aspect and component reutilization.

We have used .Net remoting to communicate the

application server, the aspects and the applications.

.Net remoting is a standard service over the .Net

platform and is channel independent. It could be

even used in distributed environments.

3.5 Aspect Conflict Resolution

DSAW provides the weaving of multiple aspects in

the same application join-point. This feature

involves the establishment of aspect coordination

strategies. The programmer could use this

coordination mechanism to control the order and

priority of aspect execution.

DSAW - A Dynamic and Static Aspect Weaving Platform

The coordination mechanism offered by DSAW

is based on the classification of aspect in static and

dynamic, plus the utilization of aspect priorities.

Since dynamic aspects are aimed at adapting

applications to runtime emerging requirements, we

have granted dynamic aspects a higher precedence

than the static ones.

Static aspects are weaved following a priority

strategy that the application developer could change

while the application is being developed. Therefore,

the execution of static aspects registered in the same

join-point will depend on their priority level. The JPI

is the responsible for adding this coordination

behavior while the application is being statically

weaved.

In the case of dynamic aspects, DSAW gives

precedence to dynamic aspects. However, conflicts

between dynamic aspects are solved following the

same priority-based strategy than the static ones.

The main difference is that this resolution of

dynamic aspects is performed by the application

server, whereas static conflicts are solved by the JPI.

Apart from that, dynamic aspects may modify their

priority at runtime, depending of their specific

requirements.

3.6 Runtime Performance

The main drawback of dynamic weaving is runtime

performance (Böllert, 1999) (Haupt and Mezini,

2004). A statically-weaved aspect-oriented program

may be almost as efficient as it was developed

without an AOSD approach (Böllert, 1999).

However, the process of adapting an application at

runtime, as well as the use of reflection, induces a

certain overhead at the execution of an application

(Popovici et al., 2003).

In our previously developed ReadyAOP system,

runtime performance penalties are produced by two

key features: 1) the MOP injected by the JPI to

dynamically enable or disable join-points, and 2) the

communication between different modules of our

system.

The first feature implies a dynamic check of join-

point activation. It is also performed some

verifications that manipulate the state of the stack,

implying a performance cost. The average

performance cost of this primitive is 70%.

The second penalization of runtime performance

is derived from the communication between aspects,

applications, and the application server. We have

used .Net remoting for this purpose. The

performance cost is linear with respect to the amount

of information exchanged. This inter-process

communication implies the highest performance cost

at runtime. This is the reason why DSAW is an

improvement of ReadyAOP. One of the benefits of

static weaving is the performance benefit obtained.

While applications are being developed, DSAW

offers a dynamic-weaving approach to facilitate the

creation of AOSD applications. This facilitates the

incremental development and the application of the

agile “fix-and-continue” debugging scheme (Ortin

and Cueva, 2002) (Dmitriev, 2002). Prior to the

deployment of the application, aspects that do not

require dynamic weaving could be statically injected

to the final application. This way, runtime

performance of the whole application will be notably

improved. This is the main benefit obtained from

separating the weaving-time concern in our system.

4 SYSTEM BENEFITS

The AOSD platform presented in this paper provides

the following benefits:

 Both static and dynamic weaving is supported

in a homogeneous way. Aspects could be

injected in an application statically or at runtime

without any modification.

 Separation of the weaving-time concern. The

homogeneity described in the previous point

provides the translation between static and

dynamic weaving without changing the source

code of the application, neither the aspects.

 Combination of dynamic and static adaptation.

Not only it is possible to statically and

dynamically aspectize applications, but it is also

viable to combine both approaches in the same

program.

 Really dynamic aspect weaving. Applications

need not to know anything of future aspects to

be weaved. Moreover, aspects could be added to

or removed from any running application.

 Language neutrality. DSAW works at the

intermediate language (IL) of the .Net platform.

Components and aspects could be implemented

in any programming language.

 IL instrumentation. The weaving process is

performed by means of IL instrumentation, once

applications and aspects have been compiled.

This feature is important when we need to adapt

components developed by third parties and its

source code is not provided.

 Platform neutrality. The use of the .Net platform

makes DSAW capable of being executed over

any standard .Net implementation.

ICSOFT 2008 - International Conference on Software and Data Technologies

 Wide join-point set. Our system offers an ample

set of join-points, similar to the one offered by

AspectJ. These join-points are provided for both

dynamic and static weaving.

 Aspect and components reutilization. The non-

invasive weaving technique followed and IL-

level instrumentation promotes aspect (and

component) reutilization. This is an effect of the

null coupling between aspects and components.

 Aspects aspectation. Aspects could be

considered as components in DSAW. This

involves the aspect adaptation by other aspects.

5 RELATED WORK

There exist many static weaving AOSD tools, and

there are also some dynamic ones. However, there

are few that offer both approaches.

Wicca is one example of a dynamic and static

aspect-oriented system (Eaddy, 2007a). Wicca has

been developed over the .Net platform making use

of the Phoenix framework –a back-end compiler

infrastructure (Phoenix, 2008). Wicca performs

static weaving by means of code instrumentation.

However, dynamic weaving is achieved using the

debugging API of the CLR. The dynamic weaving is

released in an alpha version, and it does not support

dynamic aspect deletion. The static and the dynamic

weaver are not equivalents. This means that static

weaving is more expressive than the dynamic one

(Eaddy, 2007b). Moreover, Wicca makes use of the

debugging API specific of a single implementation

of .Net (the CLR), losing the platform neutrality.

Runtime performance is poor because applications

should be executing in debugging mode, enabling

the edit-and-continue support of the CLR (Eaddy,

2007b).

AOP.NET, also known as NAop, is another

dynamic and static weaving proposal –no

implementation has been released (Blackstock,

2004). Its design follows a proxy-based component

decoration. This proxy is used in both static and

dynamic scenarios. The weaver uses a proxy class

instead of any class in a component. The proxy is

capable of adapting the behavior of its decorated

class. Depending on the point-cuts, the proxy

delegates its functionality on the original class or it

calls the registered aspects. The static weaver

performs this process prior to the application

execution; the dynamic weaver does it at runtime.

The LOOM.NET project provides dynamic and

static weaving over the same core implementation,

using the .Net platform (Schult, 2003). Rapier

LOOM.NET is the dynamic weaver. Point-cuts in

aspects are expressed by means of .Net’s custom

attributes. At load-time, the application is weaved

together with its aspects. Applications and aspects

should be linked, prior to their execution. It is

currently being developed a static weaver, called

Gripper-LOOM.NET, which is in alpha version

(Köhne et al, 2005) (Schult, 2008). The syntax of the

point-cut language description is not the same in

both weavers. This makes it difficult to convert

static aspects into dynamic ones. The dynamic

weaver requires the source code of applications and

provides a reduced set of join-points (Schult, 2003)

(Köhne et al, 2005); it does not support dynamic

aspect deletion either (Frei et al, 2004).

6 CONCLUSIONS

AOSD is an effective approach to obtain the benefits

of the Separation of Concerns principle. In this

paradigm, final applications are built from the main

functionally of the application plus cross-cutting

aspects.

There are many tools that support AOSD. Some

of them offer application weaving prior to its

execution, while others provide this adaptation at

runtime. Although the static approach is suitable in

most cases, dynamic adaptation may also be

required when the application should respond to

runtime emerging contexts and requirements. Static

weaving supports efficient AOSD, whereas dynamic

weaving involves runtime application adaptation.

This paper describes the architecture of DSAW,

a dynamic and static weaving platform that provides

language and platform neutrality, and the separation

of the weaving-time concern.

DSAW has been designed over the .Net

platform, benefiting from its features. Both weavers

are built by means of IL code instrumentation. This

makes DSAW language neutral, permits the

adaptation of legacy applications, and promotes

aspects and components reutilization.

Both dynamic and static weavers supply the

same rich set of join-points. An aspect may be

weaved statically or dynamically without changing

its source code, not the component’s one. This

facilities the fix-and-continue development at first

stages of software development, and the later

efficient static weave when the application is about

to be released. That is, DSAW completely separates

the weaving-time concern. The programmer may

modify the flexibility / performance trade-off during

the development life cycle.

DSAW - A Dynamic and Static Aspect Weaving Platform

Finally, it is possible to create applications with

aspects that have been statically weaved, together

with aspects that are later added at runtime. The

conflict resolution mechanism is based on making

dynamic aspects have precedence over static ones.

Resolution between aspects of the same kind follows

a priority-base strategy.

REFERENCES

Blackstock, M. Aspect Weaving with C# and .NET. 2004.

www.cs.ubc.ca/ michael/ publications/ AOPNET5.pdf

Böllert, K. On Weaving Aspects. 1999. Proceedings of the

Workshop on Object-Oriented Technology, p.301-302.

Dmitriev, M., 2002. Applications of the Hotswap

Technology to Advance Profiling. In ECOOP 2002

International Conference.

Eaddy, M., 2007a. Wicca 2.0: Dynamic Weaving using

the .Net 2.0 Debugging API. In AOSD 2007.

Eaddy, M., 2007b. Wicca. [Online]

http://www1.cs.columbia.edu/~eaddy/wicca/ [accessed

January, 15, 2008].

Eaddy, M., Aho, A., Hu, W., McDonald, P., Burger, J.

2007c. Debugging Aspect-Composed Programs.

Software Composition, 2007. Portugal.

ECMA, 2006. Standard ECMA-335: Common Language

Infrastructure (CLI). [Online] Available from

http://www.ecma-international.org/publications/

standards/Ecma-335.htm [accessed December 2007].

Gamma, E., Helm, R., Johnson, R., Vlissides, J. 1994.

Design Patterns: Elements of Reusable Object-

Oriented Software. Addison-Wesley

Frei, A., Grawehr, P. & Alonso, G., 2004. A Dynamic

AOP-Engine for .NET. Technical Report 445,

Department of Computer Science, ETH Zürich.

Gilani, W., Scheler, F., Lohmann, D., Spinczyk, O.,

Schröder-Preikschat, W. 2007. Unification of Static

and Dynamic AOP for Evolution in Embedded

Software Systems. 2007. 6th International Symposium

on Software Composition Braga,Portugal.

Haupt, M. & Mezini, M., 2004. Micro-Measurements for

Dynamic Aspect-Oriented Systems Proc. of

Net.ObjectDays 2004 (NODe), LNCS 3263.

JBoss AOP homepage, 2008. [Online]

http://labs.jboss.com/jbossaop/ [February 28, 2008]

Kiczales, G., Hilsdale, E., Hugunin, J., Kersten, M., Palm,

J. & Griswold, W., 2001. An Overview of AspectJ.

Proceedings of the ECOOP 2001.

Kiczales, G., Lamping, J., Mendhekar, A., Maeda, C.,

Lopes, C.V., Loingtier, J.M. & Irwin, J., 1997. Aspect

Oriented Programming. Proceedings of ECOOP 1997,

vol. 1241 of LNCS.

Köhne, K., Schult, W. & Polze, A., 2005. Design by

contract in .NET Using Aspect Oriented

Programming.

Masuhara, H., Kiczales, G., 2003. A Compilation and

Optimization Model for Aspect-Oriented Programs.

Compiler Construction (CC2003), LNCS 2622.

Matthijs, F., Joosen, W., Vanhaute, B., Robben, B. &

Verbaten, P., 1997. Aspects should not die. In:

ECOOP Workshop on Aspect-Oriented Programming.

Nicoara, A. & Alonso, G., 2005. Dynamic AOP with

PROSE. Proceedings of ASMEA 2005 in conjunction

with CAiSE 2005, Porto, Portugal.

Ortin, F., Cueva, J. 2002. Implementing a real

computational–environment jump in order to develop

a runtime–adaptable reflective platform. ACM

SIGPLAN Notices, Volume 37, Issue 8.

Ortin, F., Lopez, B., Perez-Schofield, J.B.G. 2004.

Separating Adaptable Persistence Attributes through

Computational Reflection. IEEE Software, Volume 21,

Issue 6.

Parnas, D, 1972. On the Criteria to be Used in

Decomposing Systems into Modules. Communications

of the ACM, Vol. 15, No. 12.

Phoenix, 2008. (Online). research.microsoft.com/phoenix

(accessed February, 28, 2008)

Popovici, A., Gross, T. & Alonso, G., 2001. Dynamic

Homogenous AOP with PROSE. Technical Report,

Dept. of Computer Science, ETH Zürich.

Popovici, A., Alonso, G. & Gross, T., 2003. Just in Time

Aspects: Efficient Dynamic Weaving for Java. AOSD

2003 Proceedings.

Schult, W., Trögger, P., 2003. Loom.NET – an Aspect

Weaving Tool. Workshop on Aspect-Oriented

Programming, ECOOP'03, Darmstadt.

Schult, W., 2008. Documentation Gripper-LOOM.Net.

[Online] http://www.gripper-loom.net [accessed

January, 15, 2008].

Schröder-Preikschat, W., Lohmann, D., Gilani, W., Schele

& F., Spinczyk, O., 2006. Static and dynamic weaving

in System Software with AspectC++. In HICSS '06

Mini-Track on Adaptive and Evolvable Software

Systems, IEEE, January.

Segura-Devillechaise, M., Menaud, J., Muller, G.&

Lawall, J., 2003. Web Cache Prefetching as an Aspect:

Towards a Dynamic-Weaving Based Solution. AOSD

2003 Proceedings, pp: 110-119.

Vinuesa, L. & Ortín, F., 2004. A Dynamic Aspect Weaver

over the .NET Platform. Metainformatics

International Symposium, MIS 2003. LNCS 3002.

Vinuesa, L, 2007. Separación Dinámica de Aspectos

independiente del Lenguaje y Plataforma mediante el

uso de Reflexión Computacional. Ph. D. Dissertation.

University of Oviedo.

Weave.Net, 2008. Weave.NET homepage

http://www.dsg.cs.tcd.ie/index.php?category_id=193.

[Accessed on February, 25, 2008].

Zinky, J., Bakken D. & Schantz, R., 1997. Architectural

Support for Quality of Service for CORBA Objects.

Theory and Practice of Object Systems (TAPOS).

ICSOFT 2008 - International Conference on Software and Data Technologies
