USING MESSAGE PASSING FOR DEVELOPING

COARSE-GRAINED APPLICATIONS IN OPENMP

Bielecki Wlodzimierz and Palkowski Marek

Faculty of Computer Science, Technical University of Szczecin, Zolnierska 49 st., 71-210 Szczecin, Poland

Keywords: Coarse-grained parallelism, send-receive mechanism, synchronization, agglomeration, locks.

Abstract: A technique for extracting coarse-grained parallelism in loops is presented. It is based on splitting a set of

dependence relations into two sets. The first one is to be used for generating code scanning slices while the

second one permits us to insert send and receive functions to synchronize the slices execution. Codes of

send and receive functions based on both OpenMP and POSIX locks functions are presented. A way of

proper inserting and executing send and receive functions is demonstrated. Using agglomeration and free-

scheduling are discussed for the purpose of improving program performance. Results of experiments are

presented.

1 INTRODUCTION

Extracting coarse-grained parallelism available in

loops is of great importance to develop shared

memory parallel programs. To develop such

programs, the OpenMP standard can be used

(OpenMP, 2007). OpenMP is an Application

Program Interface (API), jointly defined by a group

of major computer hardware and software vendors.

The API supports C/C++ and Fortran on multiple

architectures, including UNIX & Windows NT. It

permits for specifying parallel regions, work

sharing, both barrier and mutual exclusion

synchronization. However OpenMP does not

support directly message passing (send and receive

functions) among threads.

In this paper, we show the need for massage

passing while we develop an OpenMP coarse-

grained parallel program. Then we present how such

a mechanism can be implemented on the basis of

both OpenMP and POSIX locks. Agglomeration and

free-scheduling are discuss to improve program

performance. Results of experiments are presented.

In this paper, we deal with affine loop nests

(Darte 2000). For extracting coarse-grained

parallelism, we use an exact representation of loop-

carried dependences and consequently an exact

dependence analysis which detects a dependence if

and only if it actually exists. To implement our

algorithms, we use the dependence analysis

proposed by Pugh and Wonnacott (Pugh 1998).

2 MOTIVATING EXAMPLE

Let us consider the following loop.

for( i=1; i<=n; i++)

for( j=1; j<=n; j++)

a(i,j) = a(i,j-1) + a(i-1,1);

Figure 1: Dependences in the motivating example.

Using the Petit tool (Kelly 1997), we can extract

the following dependence relations for this loop:

R1 = {[i,j] -> [i,j+1] : 1 <= i <= n && 1 <= j < n},

R2 = {[i,1] -> [i+1,1] : 1 <= i < n && j=1}.

Figure 1 shows the loop iteration space and

dependences for n=m=6. To produce a coarse-

grained parallel program, we may proceed as

follows. Using relation R1, we can generate code

scanning synchronization-free slices. For this

145

Wlodzimierz B. and Marek P. (2008).

USING MESSAGE PASSING FOR DEVELOPING COARSE-GRAINED APPLICATIONS IN OPENMP.

In Proceedings of the Third International Conference on Software and Data Technologies - PL/DPS/KE, pages 145-152

DOI: 10.5220/0001873801450152

 SciTePress

purpose, we can apply any well-known technique,

for example those presented in (Beletska 2007,

Bielecki 2008). The following loop, scanning

synchronization-free slices being described by

relation R1(see Figure 2), is generated by the Omega

Calculator codegen function (Kelly 1995).

if(n >=2)

for(t1 = 1; t1 <= n; t1++) {

a(t1,1) = a(t1,0) + a(t1-1,1);

if (n >= t1 && t1 >= 1) {

for(t2 = 2; t2 <= n; t2++) {

a(t1,t2) = a(t1,t2-1) +

a(t1-1,1);

}

Figure 2: Synchronization-free slices described by R1.

To made this code to be semantically the same as

the working loop, we may insert in it send and

receive functions responsible for preserving

dependences represented by R2. To properly insert

and execute send and receive functions, the values of

the iteration index vector have to be checked. Let us

suppose that a pair of associated send and receive

functions are executed in such a way that the receive

function will wait until the execution of the

correspondent send function is completed. Then for

the motivating example, we may apply the following

way of inserting and executing send and receive

functions.

If the iteration index vector, I, belongs to the set

SET_RECV = (Domain(R1) union Range(R1))

intersection Range(R2), comprising all the

dependence sources and destinations described by

R1 that are simultaneously dependence destinations

described by R2, then a receive function must be

inserted and executed prior the first loop statement

that executes at iteration I. Its arguments are

coordinates of the vector J= R2

-1

(I).

The correspondent send function must be

inserted and executed after the last loop statement

executing at iteration J= R2

-1

(I). Its arguments are

also coordinates of J. That is, we may form a set

SET_SEND as R2

-1

(SET_RECV). It comprises all

the iterations, after which execution, send functions

must be executed.

To preserve the presented rules, we may insert

send and receive functions as the body of if

condition statements.

Using the Omega Calculator, we get the following

sets for the working example

SET_RECV={[i,1]:2<=i<=n},

SET_SEND={[i,1] : 1 <= i <= n-1}.

Below we present the loop being formed taking

into account the above presented rules. Figure 3

illustrates for which iterations send and receive

functions should be executed and what are their

arguments.

if (n >= 2) {

par for(t1 = 1; t1 <= n; t1++) {

if(2 <= t1 && t1 <= n)

recv(t1-1,1);

a(t1,1) = a(t1,0) + a(t1-1,1);

if(1 <= t1 && t1 < n)

send(t1,1);

if (n >= t1 && t1 >= 1) {

for(t2 = 2; t2 <= n; t2++) {

a(t1,t2) = a(t1,t2-1) +

a(t1-1,1);

}

send(1,1)

recv(1,1)

send(1,2)

recv(1,2)

send(1,3)

recv(1,n-1)

Figure 3: Parallel threads with synchronization.

3 ALGORITHM OF

GENERATING

COARSE-GRAINED LOOPS

WITH SEND AND RECEIVE

FUNCTIONS

Below we present an algorithm permitting for proper

inserting and executing send and receive functions.

Algorithm. Inserting send and receive functions.

ICSOFT 2008 - International Conference on Software and Data Technologies

146

Input. 1) set S1 including dependence relations

originating at least two synchronization-free slices;

2) set S2 comprising dependence relations to be used

for the synchronization of the execution of slices

produced by set S1(set S1 and set S2 together

comprise all dependence relations extracted for the

source loop); 3) relations Rel1 and Rel2 representing

the unions of all the relations being comprised in set

S1 and set S2, respectively; for sets S1 and S2, the

following limitation is satisfied: Domain (Rel2)

union Range (Rel2) ∈ Domain (Rel1) union Range

(Rel1).

Output. Coarse-grained parallel code.

Method.

1. Using relations in set S1, generate code scanning

synchronization-free slices applying any well-known

technique, for example (Beletska 2007, Bielecki

2008) and extract all sets, I

, representing the

iteration space of statement st

, j=1,2,...,q; q is the

number of the loop body statements.

2. Calculate set SET_RECV

= (Domain(Rel1) union

Range(Rel1)) intersection Range(R2

) for each

relation R2

in S2, i=1,2,...,n; n is the number of

relations in S2.

3. Calculate set SET_SEND = Rel2

-1

(Domain(Rel1)

union Range(Rel1)) intersection Range(Rel2).

4. Before each statement, st

, of the code generated

in step 1 and for each relation R2

, if (SET_RECV

intersection I

) ≠ FALSE insert the following code

if(I ∈ SET_RECV

)

recv(R2

-1

(I)); /*I is the

iteration vector being defined by the

loops surrounding st

5. After each statement st

of the code generated in

step 1, if (SET_SEND intersection I

) ≠ FALSE

insert the following code:

if(I ∈ SET_SEND)

send(I); /*I is the iteration

vector being defined by the loops

surrounding st

Let us generate now code for the motivating

example according to the presented algorithm.

Input.

S1 = {R1}, Rell

={[i,j] -> [i,j+1] : 1 <= i <= n &&

1 <= j < n},

S2= {R2}, Rel2 ={[i,1] -> [i+1,1] : 1 <= i < n

&& j=1}.

Step 1.

if (n >= 2) {

for(t1 = 1; t1 <= n; t1++) {

s(t1,1) ; /* a(t1,1) = a(t1,0) +

a(t1-1,1); */

if (n >= t1 && t1 >= 1) {

for(t2 = 2; t2 <= n; t2++) {

s(t1,t2); /* a(t1,t2) =

a(t1,t2-1) + a(t1-1,1); */

}

= {[t1,1] : t1 >= 1 && t1 <=n },

= {[t1,t2 : t1 >= 1 && t1 <=n && t2 >= 2 && t2

<=n}

Steps 2,3.

SET_RECV

={[i,1]:2<=i <= n}, SET_SEND={[i,1]

: 1 <= i <= n-1}.

Steps 4,5.

if (n >= 2) {

for(t1 = 1; t1 <= n; t1++) {

if(2 <= t1 && t1 <= n)

recv(t1-1,1);

s(t1,1) ; //

if(1 <= t1 && t1 < n)

send(t1,1);

if (n >= t1 && t1 >= 1) {

for(t2 = 2; t2 <= n; t2++) {

s(t1,t2); //

}

} }

For I

, we have SET_RECV

intersection I

FALSE, SET_SEND

intersection I

= FALSE,

therefore send and receive functions are not inserted

for statement st

4 IMPLEMENTATION OF SEND

AND RECEIVE FUNCTIONS

In order to implement send and receive functions,

we use lock functions. A lock function takes a lock

variable as an argument. Firstly we present send and

receive functions based on OpenMP lock functions,

then we demonstrate how they can be implemented

on the basis of POSIX lock functions.

4.1 Send and Receive Functions based

on OpenMP Lock Functions

For each vector I, belonging to set S_SEND or set

S_RECV, a structure, s_synch, is created. The

structure consists of a binary released lock mutex

and a boolean variable executed initialized with the

false value. Below we present the code of the send

USING MESSAGE PASSING FOR DEVELOPING COARSE-GRAINED APPLICATIONS IN OPENMP

147

function.

void send(int t1, int t2,...,int tn)

{

struct s_synch *set_c =

&SET_SEND[t1][t2]..[tn];

omp_set_lock(&set_c->mutex);

set_c->executed = 1;

omp_unset_lock(&set_c->mutex);

}

The arguments of the send function are

coordinates of vector I, n is the number of

coordinates of I. Firstly the function gets the

reference to a correspondent structure. The function

omp_set_lock acquires the correspondent lock and

waiting until it becomes available, if necessary. The

next statement sets the variable executed to true. The

function omp_unset_lock releases the lock mutex,

resuming a waiting thread.

Below is the code of the receive function.

void recv(int t1, int t2,...,int tn)

{

struct s_comm *set_c =

&SET_RECV[t1][t2]...[tn];

while(1)

{

omp_set_lock(&set_c->mutex);

if(!(set_c->executed))

omp_unset_lock(

&set_c->mutex);

else {

omp_unset_lock(

&set_c->mutex);

break;

}

The arguments of the receive function are

coordinates of vector I. Firstly the function gets the

reference to a correspondent structure. In order to

check the variable executed, the lock has to be set by

means of the function omp_set_lock. A thread

executes the while loop as long as the value of the

variable executed is false (at each iteration, it

releases the lock and next locks the lock again).

When the value of the variable executed becomes

true(a correspondent send function was executed),

the execution of the receive function is terminated

allowing a waiting thread to be resumed.

4.2 Send and Receive Functions based

on POSIX Lock Functions

The disadvantage of the OpenMP lock functions is

that waiting is active, causing wasting processor

cycles. The send and receive functions, implemented

with POSIX Threads (Posix 2004), do not posses

such a disadvantage.

A condition variable in POSIX allows threads to

wait until some event is occurred without wasting

CPU cycles. Several threads may wait on the same

condition variable until some other thread signals

this condition variable (sending a notification).

Then, one of the threads waiting on this condition

variable wakes up. It is possible also to wake up all

threads waiting on a condition variable by using a

broadcast method on this variable.

It is worth to note that a condition variable does

not provide locking. Thus, a lock is used along with

a condition variable, to provide necessary locking

when accessing this condition variable.

The code of the send function is as follows.

void send(int t1, int t2,...,int tn)

{

struct s_comm *set_c =

&SET_SEND[t1][t2]...[tn];

pthread_mutex_lock(&set_c->mutex);

set_c->executed = 1;

pthread_cond_broadcast(

&set_c->cond);

pthread_mutex_unlock(

&set_c->mutex);

}

Firstly, the function pthread_mutex_lock

acquires the lock on the mutex variable. If the mutex

variable is already locked by another thread, the call

of this function will block the calling thread until the

mutex variable is unlocked. Then the variable

executed is set to true, signaling that the iteration

defined by vector I=(t1,t2,…,tn) has been executed.

The POSIX function pthread_cond_brodcast

signals all waiting threads on the condition variable

cond and causes their awaking up. Finally, the

function pthread_mutex_unlock unlocks the mutex

variable. Below the code of the receive function is

presented.

void recv(int t1, int t2,...,int tn)

{

struct s_comm *set_c =

&SET_RECV[t1][t2]...[tn];

pthread_mutex_lock(&set_c->mutex);

if(!(set_c->executed))

pthread_cond_wait(

&set_c->cond, &set_c->mutex);

pthread_mutex_unlock(

&set_c->mutex);

}

ICSOFT 2008 - International Conference on Software and Data Technologies

148

Firstly the lock is locked. Then the variable

executed is checked. If its value is false, the thread,

calling the receive function, is put to sleep. The

function pthread_cond_wait blocks the calling

thread until the specified condition, cond, is

signaled. This function is called while the mutex

variable is locked, and it will automatically release

the mutex variable while it waits. After the signal is

received and the tread is awakened, the mutex

variable will be automatically locked for use by the

tread. Finally the thread releases the lock calling the

function pthread_mutex_unlock. If the variable

executed was set to true, the thread only releases the

mutex variable and continues computing.

5 SLICES AGGLOMERATION

AND ORDER OF ITERATIONS

SCANNING

To reduce the volume of synchronization among

threads, it is worth to agglomerate several slices into

one macro-slice to be executed by an OpenMP

thread. This permits for eliminating synchronization

among slices within a macro-slice. For this purporse,

we can combine several slices into one macro-slice.

Let us suppose that applying agglomeration we

produced N macro-slices. Then we add an additional

parallel loop to scan those N macro-slices. The

remaining inner loops with new lower and upper

bounds lb, ub(their values depend on N) are

executed serialy and scan iterations of a particular

macro-slice.

To avoid inner synchronization in a macro-slice,

additional constraints in if statements must be added

(step 4, 5 in the algorithm presented in Section 3).

We have to check for each vector I whether

iterations R2

-1

(I) and R2(I) belong to the iterations

of a macro-slice. If this is not true, synchronization

is required.

Program performance will depend not only on

the volume of synchronization but also on how we

scan iterations of macro-slices. Figure 4 represents

two different ways to scan iterations of macro-slices.

On the left-hand side, iterations are scanned in

lexicographic order, for example, for the first macro-

slice the order of the iteration execution is (1,1),

(1,2),...., (2,1), (2,2),.... On the right-hand side,

iterations are executed according to the free-

scheduling policy (Darte 2000) that supposes that in

each step we execute those iterations whose input

data is already completed, i.e., in each step the

iterations between a pair of skewing neighborhood

lines are executed (the order of their execution can

be arbitrary because they all have completed data).

There is barrier synchronization in the end of each

step. For example, for the first macro-slice the

following order of the iterations execution is valid:

step1: (1,1), step2: (2,1) , (1,2), step3: (3,1), (2,2),

(1,3) and so on. It is obvious that applying the free-

scheduling policy improves the program

performance because it reduces the waiting time. For

example, applying lexicographic scanning, the

second macro-slice can start its execution after the

execution of 13 iterations(see Figure 4) while

applying the free-scheduling policy, we can start the

execution of the second macro-slice after the

execution of 4 iterations only.

In paper (Bielecki 2008), we proposed how to

generate code scanning iterations according to the

free-scheduling policy. For scanning macro-slices,

we should add a tuple to a set holding iterations to

be executed at the next step (Bielecki 2008), only if

an iteration R2

(I) belongs to the iterations of a

macro-slice.

Below, we present the pseudo-code that scans

iterations of macro-slices for our working example

according to the free-schedule policy. This code is

generated on the basis of the approach presented by

us in paper (Bielecki 2008), and the described above

way to insert send and receive functions. The

additional constraints permitting for avoiding inner

synchronization are bolded in the pseudocode below.

par for w = 1 to N {

// calculate upper and lower

//bounds, ub and lb as follows

// pack = ((o_ub-1)+1)/N,

//lb = pack *(w-1)+o_lb;

// ub = (w==N) ? n : pack *w;

// where o_lb, o_ub are the lower

//and upper bounds of the outermost

//loop generated in step 1 of the

//algorithm presented in Section 3

S’ = Ø;

for t=lb to ub {

I = [t,1]

Add I to S’;

}

while(S’ != Ø) {

S_tmp= Ø;

foreach(vector I=[i,j] in S’) {

if(j==1 && 2 <= i && i <= n &&

!(i-1>=lb && i-1 <= ub)) /*

receive message from another

macro-slice */

recv(i-1,1);

s1(I);

if(j==1 && 1 <= i && i < n &&

( !(i+1>=lb && i+1 <= ub) ) )

USING MESSAGE PASSING FOR DEVELOPING COARSE-GRAINED APPLICATIONS IN OPENMP

149

Figure 4: Illustrating slices agglomeration and the order of iterations scanning.

Table 1: Loops for experiments.

Loop 1 Loop 2 Loop3

for i=1 to n do

for j=1 to n do

a(i,j) = a(i,j-1) + a(i-1,1)/1.1

endfor

for i=1 to n do

a(i, 1) = a(1, i)

for j=1 to n do

a(i,j) = a(i,j+1)/1.001

endfor

for i=1 to n do

for j=1 to n do

if(i==2 and j==1) then

a(i,j) = a(i-1,j)

endif

a(i,j) = a(i,j-1)/1.1 + a(i-2,j+1)/1.1

endfor

/*send message to another macro-

slice */

send(i,1);

if(1 <= j && j < n && 1 <= i &&

i <= n){ /* if R1(I

∈

domain

R1*/

add J=[i,j+1] to S_tmp;

/* J=[ip,jp]= R2(I) */

if(j==1 && 1<=i && i<n &&

lb<=i+1 && i+1>=ub) /*if

R2(I)

∈

domain R2

and I

∈

Iterations of macro-slice

add J=[i+1,j] to S_tmp;

/* J=[ip,jp]= R2(I) */

}

S’ = S_tmp; }

6 EXPERIMENTS

To evaluate the performance of programs being

formed by the proposed approach, we have tested

three loops (see Table 1). OpenMP parallel coarse-

grained codes were produced by us on the basis of

presented approach. The POSIX library (POSIX

threads C+ access library2.2.1-2) was included in

OpenMP sources to permit us to use send and

receive functions based on POSIX lock functions.

We have carried experiments on the machine Intel

Xeon 1.6 Ghz, 8 processors (2 x 4-core CPU, cache

4 MB), 2 GB RAM, Ubuntu Linux.

The results are presented in Table 2, where time

is presented in seconds, S and E denote speed-up

and efficiency, respectively. The second column in

Table 2 indicates whether agglomeration was used

(+) or not(-), F means that free scheduling was used,

N is the number of macro-slices.

For Loop 1 and Loop 2, we examined how

agglomeration impacts speed-up and efficiency.

Loop 3 originates only two slices, hence

agglomeration was not considered.

Experiments with Loop 1 and Loop 2

demonstrate that i) increasing the volume of

calculations executing by a thread(increasing n)

increases S and E; ii) the positive impact of

agglomeration on S and E grows with increasing the

number of processors; iii) free scheduling is

important for the number of processors greater than

2. However it is not obvious what is the value of N

that optimizes program performance. As N grows,

the waiting time to start the macro-slice execution

decreases while the volume of synchronization

increases.

ICSOFT 2008 - International Conference on Software and Data Technologies

150

Table 2: Results of experiments (POSIXfunctions).

Aggl.

CPU 1 2 4 8

Loop n seq. for synch time S E time S E time S E

Loop1

1500 0,0441 0,0462

0,0296

1,490 0,745 0,0231 1,281 0,320 0,0288 1,028 0,128

2000

0,0782

0,0814 0,0475 1,646 0,823 0,0346 2,263 0,566 0,0390 2,005 0,251

2500

0,1222

0,1271 0,0713 1,714 0,857 0,0461 2,651 0,663 0,0680 1,797 0,225

Loop1

+ / F

N =

200

1500 0,0441 0,0470 0,0299 1,475 0,737 0,0213 2,070 0,518 0,0272 1,621 0,203

2000

0,0782

0,0861 0,0479 1,633 0,816 0,0350 2,234 0,559 0,0312 2,506 0,313

2500

0,1222

0,1300 0,0721 1,695 0,847 0,0487 2,509 0,627 0,0461 2,651 0,331

Loop2

N =

1500

0,0446

0,0452 0,0308 1,449 0,724 0,0251 1,777 0,444 0,0247 1,806 0,226

2000

0,0793

0,0801 0,0516 1,537 0,768 0,0314 2,525 0,631 0,0318 2,494 0,312

2500

0,1238

0,1249 0,0720 1,719 0,860 0,0458 2,703 0,676 0,0382 3,241 0,405

Loop 3

1500

0,0578

0,0580 0,0391 1,478 0,739 - - - - - -

2000

0,0843

0,0844 0,0527 1,600 0,800 - - - - - -

2500

0,1148

0,1153 0,0648 1,772 0,886 - - - - - -

Table 3: Influence of the number of macro-slices on program performance (POSIX functions).

CPU 1 2 4 8

N seq. for synch time S E time S E time S E

0,0819

0,0908 0,0507 1,615 0,808 0,0428 1,914 0,478 0,0370 2,214 0,277

0,0819

0,0912 0,0498 1,645 0,823 0,0356 2,301 0,575 0,0346 2,367 0,296

128

0,0819

0,0878 0,0514 1,593 0,797 0,0324 2,528 0,632 0,0307 2,668 0,333

256

0,0819

0,0876 0,0538 1,522 0,761 0,0342 2,395 0,599 0,0364 2,250 0,281

Table 4: POSIX and OpenMP functions.

1 CPU, s 2 CPU, s 4 CPU, s 8 CPU, s

Seq. OpenMP POSIX WS OpenMP POSIX WS OpenMP POSIX WS OpenMP POSIX

512

0,0819 0,0894 0,0866 0,0837 0,0587 0,0516 0,0496 0,0392 0,0381 0,0378 0,0375 0,036 0,0359

(6,8%;3,5%) (18,3%;4%) (3,7%;0,8%) (4,5%;0,3%)

256

0,0819 0,0888 0,0853 0,0852 0,0568 0,0501 0,0499 0,0345 0,0309 0,0306 0,0386 0,036 0,0317

(4,2%;3,5%) (13,8%; 0,4%) (12,7%; 1,0%) (21,8%; 13,6%)

128

0,0819 0,0875 0,0866 0,0856 0,0576 0,0521 0,0512 0,0356 0,0318 0,0316 0,0365 0,0319 0,032

(2,2%; 1,2%) (12,5%; 1,8%) (12,7%; 0,6%) (14,1%; 0%)

0,0819 0,1001 0,0965 0,0845 0,0585 0,056 0,0509 0,0431 0,0401 0,0371 0,0372 0,0343 0,0311

(18,5%; 14,2%) (14,9%; 10%) (16,2%;8,1%) (19,6%;10,3%)

The size of a macro-slice impacts also program

locality – a very important factor defining program

performance. Table 3 presents how the number of

macro-slices (Loop 1, free-scheduling with

agglomeration), N, impacts S and E. For each

number of processors, there exists a particular value

of N optimizing program performance.

Table 4 presents differences in execution times

of programs being written with OpenMP and POSIX

lock functions for Loop 1, n=2048. The columns

named as WS present program execution times when

send and receive functions are removed from code.

In the brackets, the percentage of the program

execution time is inserted that characterizes

synchronization time on the basis of OpenMP and

POSIX functions, respectively. The data in Table 4

demonstrates that POSIX functions permit for better

program performance in comparison with OpenMP

functions.

USING MESSAGE PASSING FOR DEVELOPING COARSE-GRAINED APPLICATIONS IN OPENMP

151

7 RELATED WORK

Unimodular loop transformations (Banerjee 1990),

permitting the outermost loop in a nest of loops to be

parallelized, find synchronization-free parallelism.

However when there exist dependences between

slices, that approach fails to extract coarse-grained

parallelism.

The affine transformation framework

(polyhedral approach), considered in many papers,

for example, in papers (Darte 2000, Feautrier 1994,

Lim 1999) unifies a large number of previously

proposed loop transformations. It permits for

producing affine time and space partitioning and

correspondent parallel codes. For the motivating

example, there does not exist any affine space

partitioning permitting for extracting coarse-grained

parallelism; we are able to find only time

partitioning to extract fine-grained parallelism.

Our contribution consists in demonstrating how

to generate coarse-grained code on the basis of two

sets of dependence relations, the first of them

permits for extracting synchronization-free slices

(our previous results: Beletska 2007, Bielecki 2008)

while the second one is used for inserting send and

receive functions. The proposed approach extracts

coarse-grained parallelism when in a loop there does

not exist synchronization-free slices.

8 CONCLUSIONS AND FUTURE

WORK

We introduced the approach to extract coarse-

grained parallelism in loops. Send and receive

functions are used to synchronize the slices

execution. Our future research direction is to derive

techniques permitting for automatic splitting a set of

dependence relations into two sets such that the first

one is to be used for generating code scanning slices

while the second one is to insert send and receive

functions.

REFERENCES

OpenMP Application Program Interface 2007. In

http://www.openmp.org

Darte A., Robert Y., Vivien F., 2000. Scheduling and

Automatic Parallelization, Birkhäuser Boston.

Pugh W., Wonnacott D., 1998. Constraint-based array

dependence analysis. In ACM Trans. on Programming

Languages and Systems.

Beletska A., Bielecki W., San Pietro P., 2007 Extracting

Coarse-Grained Parallelism in Program Loops with

the Slicing Framework. In Proceedings of

ISPDC’2008.

Bielecki W., Beletska A., Pałkowski M., San Pietro P.,

2008. Finding synchronization-free parallelism

represented with trees of dependent operations. In

Proceedings of ICA3PP'2008.

Kelly W., Maslov V., Pugh W., Rosser E., Shpeisman T.,

Wonnacott, D., 1995. The omega library interface

guide. Technical Report CS-TR-3445, University of

Maryland.

The POSIX 1003.1-2001, 2004. Standard of an

application programming interface (API) for writing

multithreaded applications. In http://

www.unix.org/version3/ieee_std.html

Banerjee U., 1990. Unimodular transformations of double

loops. In Proceedings of the Third Workshop on

Languages and Compilers for Parallel Computing, pp.

192-219.

Feautrier P., 1994. Toward automatic distribution. Journal

of Parallel Processing Letters 4, pp. 233-244.

Lim W., Cheong G.I., Lam M.S., 1999. An affine

partitioning algorithm to maximize parallelism and

minimize communication. In Proceedings of the 13th

ACM SIGARCH International Conference on

Supercomputing.

Kelly W., Pugh W., Rosser E. and Shpeisman T., 1996.

Transitive Closure of Infinite Graphs and its

Applications. International Journal of Parallel

Programming, v. 24, n. 6, pp. 579-598.

Allen, R, Kennedy, K. 2001. Optimizing Compilers for

Modern Architectures, pages 790, Morgan Kaufmann.

ICSOFT 2008 - International Conference on Software and Data Technologies

152
