VERIFICATION OF SCENARIOS USING THE COMMON

CRITERIA

Atsushi Ohnishi and Hiroya Itoga

Department of Computer Science, Ristumeikan University, 1-1-1 Noji-Higashi, Kusatsu, Shiga, Japan

Keywords: Scenario analysis, security requirements elicitation.

Abstract: Software is required to comply with the laws and standards of software security. However, stakeholders

with less concern regarding security can neither describe the behaviour of the system with regard to security

nor validate the system’s behaviour when the security function conflicts with usability. Scenarios or use-

case specifications are common in requirements elicitation and are useful to analyze the usability of the

system from a behavioural point of view. In this paper, the authors propose both (1) a scenario language

based on a simple case grammar and (2) a method to verify a scenario with rules based on security

evaluation criteria.

1 INTRODUCTION

Scenarios are important in software development

(Cockburn, 2001), particularly in requirements

engineering (Alexander and Maiden, 2004), since

they provide concrete system description (Sutcliffe

et al., 1998), (Weidenhaupt, 1998). Moreover

scenarios are useful in defining system behaviors

done by system developers and validating the

requirements undertaken altogether with customers

(Carroll, 2000). In many cases, scenarios become

foundation of system development. Incorrect

scenarios will lead to negative impact on system

development process in overall. However, scenarios

are informal and it is difficult to verify the

correctness of scenarios. The errors in incorrect

scenarios may include:

1. Vague representations,

2. Lack of necessary events,

3. Extra events,

4. Wrong sequence among events.

The authors have developed a scenario language

for describing scenarios in which simple action

traces are embellished to include typed frames based

on a simple case grammar (Fillmore, 1968) of

actions and to describe the sequence among events

(Zhang and Ohnishi, 2004). Since this language is a

controlled language, the vagueness of the scenario

written using this language can be reduced (Ohnishi,

1996). Furthermore, the scenario created with this

language can be transformed into internal

representation. In the transformation, both lack of

cases and illegal usage of noun types can be detected,

and concrete words will be assigned to pronouns and

omitted indispensable cases (Ohnishi, 1996). As a

result, the scenario with this language can avoid

errors typed 1 previously mentioned.

Furthermore, software security requirements

affect the whole behavior of the software system and

not only parts of the system. Most stakeholders may

not be software security professionals. Almost all

users and clients of the system will have no

knowledge about software security. However, they

still feel that it is important to comply with the laws

and standards for information systems and software

security.

Therefore, they may suggest requirements to

comply with such standards although they may not

be able to envision the behavior of the system once

these suggestions are incorporated. Consequently, it

is necessary for them to leave validation of

requirements about their business rules to developers

who do not have knowledge about the business rules.

Although developers have knowledge about

software security, this is usually limited to general

knowledge. They cannot decide who to apply the

techniques of software security to specific business

rules. If the system satisfies the laws and the

standards, the users may find that the behavior

differs from that initially envisioned after the

completion of development.

Ohnishi A. and Itoga H. (2008).

VERIFICATION OF SCENARIOS USING THE COMMON CRITERIA.

In Proceedings of the Third International Conference on Software and Data Technologies - SE/GSDCA/MUSE, pages 5-11

DOI: 10.5220/0001873900050011

 SciTePress

Behaviors related to software security often

conflict with other requirements, such as usability,

cost and performance. Therefore, the developers

cannot include all functional and non-functional

requirements regarding software security in the

software requirements specification.

There are a number of reasons why it is necessary

to focus on elicitation of security and usability

requirements. The requirements regarding usability

will conflict with security requirements. The

remaining requirements, such as cost or performance

requirements, can be resolved by increasing other

resources.

We focus on the verification method of scenarios

with rules (Toyama and Ohnishi, 2005) and

customize the rules to satisfy the software security

common criteria (ISO/IEC 15408, 2005).

2 SCENARIO LANGUAGE

2.1 Outline

Our scenario language has been already introduced

in several papers such as in (Zhang and Ohnishi,

2004), (Ohnishi and Potts, 2001). However, in this

paper, a brief description of this language will be

given for convenience.

A scenario can be regarded as a sequence of

events. Events are behaviors employed by users or

systems for accomplishing their goals. We assume

that each event has just one verb, and that each verb

has its own case structure. The scenario language

has been developed based on this concept. Verbs and

their own case structures depend on problem

domains such as elevator control (Ohnishi and Potts,

2001), PC chair’s job (Barish, 1997) and train ticket

reservation (Railway Information System, 2001), but

the roles of cases are independent of problem

domains. The roles include agent, object, recipient,

instrument, and source, etc (Fillmore, 1968),

(Ohnishi and Potts, 2001).

We provide Requirements Frames (Ohnishi,

1996) in which verbs and their own case structures

are specified. This frame depends on problem

domains. Each action has its case structure, and each

event can be transformed into internal representation

based on this frame. In the transformation, concrete

words will be assigned to pronouns and omitted

indispensable cases. With Requirements Frame, we

can detect both the lack of cases and the illegal

usage of noun types (Ohnishi, 1996).

We assume four kinds of time sequences among

events: 1) sequence, 2) selection, 3) iteration, and 4)

parallelism. Actually most events are sequential

events. Our scenario language defines the semantic

of verbs with their case structure. For example, data

flow verb has source, goal, agent, and instrument

cases. Since such case structure can define the

abstraction level, scenario provided using our

scenario language becomes the almost same level of

the abstraction.

2.2 Scenario Example

We consider a scenario of train ticket reservation in

a railway company. Figure 1 shows a scenario of

customer’s purchasing a ticket of express train at a

service center. This scenario is written with our

scenario language based on a video that records

behaviors of both a user and a staff at one particular

service center.

[Scenario title: A customer purchases a train ticket of

reservation seat]

[Viewpoints: Staff, customer]

[Pre-condition: the customer has enough money to buy

a ticket & has not a ticket & has not reserved a seat]

[Post-condition: the customer will get a ticket &

reserved a seat]

1. A staff asks a customer leaving station and

destination as customer’s request.

2. He sends the customer’s request to reservation center

with a terminal.

3. He retrieves available trains with the request.

4. He informs the customer of a list of available trains.

5. The customer selects a train that he/she will get.

6. The staff retrieves available seats of the train.

7. He shows a list of available seats of the train.

8. The customer selects a seat of the train.

9. If (there exists a seat selected by the customer) then

the staff reserves the seat with the terminal.

10. He gets a permission to issue a ticket of the seat.

11. He receives money for the ticket from the customer.

12. He gives the ticket to the customer.

Figure 1: Scenario example.

A title of this scenario is given at the first two

lines in Fig.1. Viewpoints of considered scenario are

specified at the third line. In this paper, viewpoints

mean active objects such as human or system

appearing in the scenario. There exist two

viewpoints, namely staff and customer. The order of

specified viewpoints means the priority. In this

example, the first featured object is staff and the

second one is customer. In such a case, the former

becomes the subject of an event.

In addition, pre-condition specifies a condition

that satisfies at the start of the scenario. Post-

condition specifies a condition that satisfies at the

ICSOFT 2008 - International Conference on Software and Data Technologies

end of the scenario.

In this scenario, most events are sequential,

except one selective event (the 9

event). Selection

can be expressed with if-then syntax like program

languages. Actually, event number is for reader’s

convenience and not necessary.

3 VERIFICATION OF

SCENARIOS

When a scenario is described, necessary events may

be missing, unnecessary events may be mixed or

time sequence among events may be inaccurate.

These errors may have a negative impact on system

development; therefore, it is necessary to detect

these errors. The errors, also employed as

correctness verification items, of scenarios include:

1. Lack of necessary events

2. Extra events

3. Wrong time sequence among events

We can check whether an event is lacking, being

extra one or being sufficient one by comparing its

correct occurrence times with the times that it

occurred in the scenario. Similarly, we can check

whether the time sequence among events is wrong

by comparing the correct time sequence with the

time sequence described in the scenario.

We propose a method to verify the correctness of

scenarios by using rules to detect the errors in

scenarios. We assume that a rule is a description of

the correct occurrence times of an event and/or the

correct time sequence among events, which the

scenario ought to satisfy. One scenario may be

verified with several rules.

3.1 Rule

Rule is composed of the description of rule's event

and the description of event's occurrence times

and/or time sequence among events. In this sense,

our rules just specify the occurrence of events and/or

the sequence of events. If the abstraction level of

events of rules becomes high, the rules can be

applied to scenarios of several different domains.

3.1.1 Events in Rule

In a rule, there are one or more events, whose

occurrence times and/or time sequences are

specified. When a scenario is verified with a rule,

the rule's events can correspond to the scenario's

events. By finding the corresponding events in the

scenario, and by checking the occurrence times

and/or the time sequence of these events, one

scenario can be verified.

As a result, it is necessary to get the

corresponding relation between the rule's events and

the scenario's events. For this reason, the rule's

events are also described based on Requirements

Frames, and can also be transformed into the internal

representation. If the rule's event and the scenario's

event have the same internal representation, then

they are deemed as corresponding events.

In order to improve the verification effect, it is

not sufficient that the corresponding relation

between the rule's event and the scenario's event is 1

to 1 ratio. It is expected that a rule's event can

correspond to several scenario's events. As a result,

the occurrence times and/or the time sequence of

these scenario's events can be checked with one rule.

In such a case, the rule's event has an abstract

representation, and the corresponding scenario's

events have several concrete representations.

For the above reason, we permit the abstract

description of rule's event. An abstract event may be

transformed into several concrete events, when

finding its corresponding events in the scenario. At

this time, the corresponding relation between the

rule's event and the scenario's event is 1 to many.

There are two kinds of abstract events in the rule.

1. Some indispensable cases are omitted in the

event sentence.

2. There include "something," "someone," "same

thing," "same one," etc. in the event sentence.

In the first kind of abstract events, the omitted

cases fit any noun. This kind of abstract events will

be transformed into concrete events by substituting

concrete nouns for omitted cases, when finding its

corresponding events in observed scenario. For

example, a rule's event "system feedbacks to user"

can be transformed into an internal representation.

This event can correspond to any scenario's event

whose action is "feedback, etc.", agent case is

"system", and recipient case is "user". In the second

kind of abstract events, "something" / "someone" is

similar to the omitted case in the first kind of

abstract events, and fit anything / anyone. The

reason of dividing abstract events into two kinds

should be explained. We assume that there is a rule

that describes the time sequence among events.

Under this rule there exist two separate events and

under these two events there exist a case A and a

case B. We want to specify that case A and case B

can have any content but they have to be the same

content. If we simply omit case A and case B in the

VERIFICATION OF SCENARIOS USING THE COMMON CRITERIA

rule description, it cannot be warranted that case A

and case B have the same content. By specifying

"something" / "someone" for case A, "same thing" /

"same one" for case B, case A and case B can have

any content, and they are the same content.

In the second kind of abstract events, "same

thing" / "same one" fits the same noun with

"something" / "someone" that appears in the same

rule. This kind of abstract events will be transformed

into concrete events by substituting concrete nouns

for "something" / "someone" / "same thing" / "same

one", etc. when finding its corresponding events in

the scenario.

3.1.2 Occurrence Times of an Event

The correct occurrence times of an event, which the

scenario ought to satisfy, can be specified as a rule.

By comparing the correct occurrence times with the

times that this event occurred in the scenario,

whether this event is lack of or excess of occurrence

can be checked. The occurrence times of an event

are described based on regular expression as follows.

1. E: event E occurs just one time.

2. E+: event E occurs one or more times.

3. E?: event E occurs one time or does not occur.

4. E!: event E never occurs.

5. E{m}: event E occurs m times.

6. E{m,}: event E occurs m or more times.

7. E{,n}: event E occurs n or less times.

8. E{m,n}: the occurrence times of event E is from

m to n.

We adopted the syntax of regular expression and

similar its semantics.

3.1.3 Time Sequence Among Events

The correct time sequence among events that

scenario ought to satisfy can be specified as rules.

By comparing the correct time sequence with the

time sequence described in the scenario, time

sequence among events can be checked. According

to the time sequence in the scenario described in

section 2.1, we assume the following rules.

1. Before/After E1, E2: Before/After event E1

occurs, event E2 should occur.

2. If (condition) (E1, E2): Event E1 and event E2

occur selectively. If the condition is true, event

E1 occurs. If the condition is false, event E2

occurs.

3. Do (E1,E2,...) until(condition): Until the

condition becomes true, event E1, E2, ... occur

iteratively.

4. AND(E1,E2,...): All of the events E1, E2, and

others parallel occur.

5. OR(E1,E2,...): One of the events E1, E2, ... or

more parallel occurs.

6. XOR(E1,E2,...): Just one of the events E1,

E2, ... occurs.

As previously described, when a scenario is

verified with a rule that includes the abstract event,

it is possible that an abstract event corresponds to

several scenarios' events. In this case, it is necessary

to check the time sequence of every corresponding

event in the scenario and the results should be shown

one by one.

3.2 Scenario-checking with Rule

Our scenario-checking procedure consists of two

phases. The first phase is selection of applicable

rules from rule DB. We specify both (1) pre-

conditions and post-conditions and (2) viewpoints in

each of the rules. When the conditions and

viewpoints of a rule are much the same as those of a

given scenario, the rule is selected for checking the

scenario.

The second phase is analysis of rules and

checking the consistency between a rule and the

scenario as described in 3.1. The result will be

passed to a checking-system user. The scenario

checking can be achieved by automatically checking

whether the scenario satisfies the rules, through the

internal representation of scenario and the internal

representations of rules.

Initialize a counter (counter=0).

Find the scenario's event that corresponds to the rule's

event

while (the corresponding event in the scenario will be

found)

counter=counter+1

Show the corresponding event and its occurrence

condition to user.

Find the next scenario's event that corresponds to the

rule's event.

Compare the occurrence times specified in the rule with

the counter, and show the result.

Figure 2: Checking procedure of the occurrence of events.

We firstly find events in a scenario each of which

corresponds to an event in a rule as described in

3.1.1. When a scenario is checked with a rule, the

occurrence times and/or the time sequence of

corresponding events in the scenario will be checked.

ICSOFT 2008 - International Conference on Software and Data Technologies

We provide two checking procedures. One is for

checking the occurrence time and the other is for

checking the time sequence. Figure 2 shows outline

of checking procedure for the occurrence time of an

event and Figure 3 shows outline of checking

procedure for the time sequence between events E1

and E2.

Find the scenario's event that corresponds to E1 from

the beginning of the scenario.

if (the corresponding event of E1 not be found)

then show this error, and the checking ends.

else do

Show the corresponding event and its occurrence

condition.

Find an event that corresponds to E2 and satisfies

the time sequence

if (the corresponding event of E2 not be found)

then show the result that the scenario does not

satisfy the rule

else do

Show the corresponding event and its

occurrence condition.

Find the next scenario's event that

corresponds to E2 and satisfies the time

sequence.

until (the corresponding event of E2 not be

found)

Find the next scenario's event that corresponds to

E1.

until (the corresponding event of E1 not be

found)

Figure 3: Checking procedure of the sequence of events.

3.3 Evaluation

We have developed a prototype system based on the

method. There exist 35 errors in 15 scenarios. These

35 errors can be classified into three categories,

namely (1) wrong sequence of events, (2) lack of

events, and (3) extra events. The number of errors

grouped into the above categories are 16, 8 and 11,

respectively. We could detect part of these errors

with our method shown in Table 1.

The detection ratio is 63%. The reason why our

method seems to be weak for detecting extra events

is that it is very difficult to predict extra events and

make rules for them in advance. On contrast, it is not

so difficult to predict indispensable events and

correct sequence of events and make rules for them

in advance. Another reason why our method is

strong for detecting wrong sequence of events and

lack of events is that rules for the occurrence time of

events are effective to detect lack of events and rules

for the sequence of events are effective to detect

wrong sequence of events. To improve the detection

ratio, we have to introduce another type of rules for

detecting extra events.

The describers can easily correct the detected

errors. Since scenario writers can determine the

abstraction level of scenarios, the number of events

may differ depending on the scenario writers. Causes

of undetected errors related to both lack of events

and extra events are misunderstandings of the

reservation jobs.

Table 1: Detected errors in scenario.

The

number

of errors

The number of

detected errors

Wrong

sequence

of events

16 14

Lack of events 8 6

Extra events 11 2

Total 35 22

3.4 Rules Based on Common Criteria

7. Class FIA: Identification and authentication

7.1 Authentication failures (FIA_AFL) require

that the system be able to terminate the session

establishment process after a specified number of

unsuccessful user authentication attempts. It also

requires that, after termination of the session

establishment process, the system be able to

disable the user account or the point of entry

from which the attempts were made until an

administrator-defined condition occurs.

FIA_AFL.1.1.

The security function shall detect when

[selection: [assignment: positive integer

number], an administrator configurable positive

integer within [assignment: range of acceptable

values]] unsuccessful authentication attempts

occur related to [assignment: list of

authentication events].

FIA_AFL.1.2.

When the defined number of unsuccessful

authentication attempts has been met or

surpassed, the security function shall

[assignment: list of actions].

Figure 4: An excerpt of security evaluation criteria.

VERIFICATION OF SCENARIOS USING THE COMMON CRITERIA

[Authentication failures][system, user]

{

The system requests the user for a password.

The system receives the password from the user.

The system authenticates the user via the

password

if ( unsuccessful authentication attempts meet or

exceeds 3 times ) then

The system switches to “Invalidate ID”.

}

Figure 5: An example of a scenario.

The security evaluation criteria suite used in this

paper is ISO/IEC 15408 Evaluation Criteria for IT

Security (ISO/IEC 15408, 2005). The evaluation

criteria suite is useful to verify scenarios because

some of them are easily represented as rules. We can

detect scenarios which do not satisfy rules based on

the security evaluation criteria.

We can verify the scenario shown in Fig. 5 with

rules shown in Fig. 4 and confirm the scenario

satisfies the rules.

If the authentication event occurs more than

three times, the verifier can detect the unsuccessful

status and also detect the switching to “invalidate

ID.” These results will be provided to a user and he

will judge the correctness of the scenario.

4 DISCUSSION

ISO/IEC 15408 is a most commonly used security

evaluation criteria suite and it has descriptions of

functional requirements classified according to

purpose and function of IT system to be developed.

The suite also has descriptions of simple behaviors

to meet the functional requirements.

In the security evaluation criteria suite, there are

68 families of functional requirements into 11

components, such as encryption, authentication, etc.

In this paper, we focus mainly on usability, and

consider 12 functional requirements families and

other related families, because these families can be

easily represented as rules for the verification.

The remaining requirements families are for

quality of function or evaluation of the functions

themselves, and so they do not affect the behaviors

that can be seen by the users. The remaining families

are difficult to transform rules. This point is a major

problem of the proposed research. Actually, we can

represent 23 rules for security requirements of the

security evaluation criteria, while 44 security

requirements of the criteria cannot be represented as

rules.

In this paper, we consider “7.1 Authentication

failures” and show the verification process of the

scenario with rules.

The rules must be written by security

professionals to detect wrong scenarios which

involve incorrect security behavior that causes a

critical vulnerability in the system. The professionals

can rewrite the scenario to meet the security

evaluation criteria into scenario easily.

Some criteria are not suitable to represent as rules

and scenarios cannot be verified with these points of

view. To solve this problem is left as a future work.

5 RELATED WORKS

Araujo and Whittle et al. proposed an analysis

method in their scenario description process (Araujo,

Whittle and Kim, 2004) (Whittle and Araujo, 2004).

This method focuses on generation of state machines

by synthesizing scenarios and validating their

correctness. This method is very useful for

requirements analysis and the design process after

requirements elicitation. Instead, our method focuses

on validation in the requirements elicitation phase

and finding the conflicts of requirements.

Sindre and Opdahl proposed Misuse Cases

(Sindre and Opdahl, 2005) and McDermott and Fox

proposed Abuse Cases (McDermott and Fox, 1999)

for security requirements elicitation. These methods

are useful for brainstorming or discussion by

clarifying the threats. However, our method uses the

security evaluation criteria and focuses on the

comprehensive elicitation of security requirements.

SIREN is a security requirements management

method that focuses on security evaluation criteria or

common criteria (Toval et al., 2002), but this method

focuses on reuse of requirements specifications

regarding security requirements and they did not

mention the behavior of the security requirements

functions.

Sutcliffe et al. propose a verification method of

scenarios based on validation-frame (Sutcliffe et al.,

1998). This frame consists of situation part and

requirements part. In situation part, pattern of events

and actions are defined. In requirements one, some

generic requirements are needed to handle each of

these patterns. Using validation-frame,

crosschecking between scenario and requirements is

possible. Our approach is similar, but we enable to

check (1) wrong sequence of events and (2) the

number of occurrence of events. On contrast,

ICSOFT 2008 - International Conference on Software and Data Technologies

validation-frame does not check them.

6 CONCLUSIONS

The authors proposed a scenario checking method

with rules based on the security evaluation criteria.

We can specify the occurrence times of events

and/or the time sequence among events as rules.

Both scenario and rules can be transformed into the

internal representation so that we can check scenario

with rules and evaluate the correctness of one

particular observed scenario.

The proposed method was demonstrated by

the example and was evaluated. The evaluation

results show that errors (the lack of events, extra

events, the wrong sequence among events, and

wrong behaviors against the security common

criteria) in scenario can be effectively detected by

checking the scenario with rules. By using this

correctness checking method, we can get a scenario

that satisfies security common criteria more

effectively in system development.

ACKNOWLEDGEMENTS

The authors thank to Mr. Tatsuya Toyama and Mr.

Kenta Nishiyuki for their contributions to the

research.

REFERENCES

Alexander, I. F., and Maiden, N., 2004. “Scenarios,

Stories, Use Cases – Through the Systems

Development Life-Cycle”, John Wiley & Sons.

Barish, R, 1997. ACM Conference Committee Job

Description, Conference Manual, Section No. 6.1.1,

http://www.acm.org/sig_volunteer_info/conference_m

anual/6-1-1PC.HTM.

Carroll, J.M., 2000. “Making Use: Scenario-based Design

of Human Computer Interactions”, MIT Press.

Cockburn, A., 2001. “Writing Effective Use Cases”,

Addison Wesley, USA.

Fillmore, C. J., 1968. “The Case for Case”, Universals in

Linguistic Theory, ed. Bach & Harms, Holt, Rinehart

and Winston Publishing, Chicago.

“IEEE Std. 830-1998, 1998.” IEEE Recommended

Practice for Software Requirements Specifications.

“ISO/IEC 15408 common criteria, 2005.”

McDermott, J. and Fox, C., 1999. “Using Abuse Case

Models for Security Requirements Analysis”,

Proceedings of the 15th IEEE Annual Computer

Security Applications Conference (ACSAC’99), pp.

55-65.

Ohnishi, A., 1996. “Software requirements specification

database based on requirements frame model”,

Proceedings of the Second IEEE International

Conference on Requirements Engineering (ICRE’96),

pp. 221-228.

Ohnishi, A., Potts, C. 2001. Grounding Scenarios in

Frame-Based Action Semantics, Proc. of 7th

International Workshop on Requirements Engineering:

Foundation of Software Quality (REFSQ’01),

Interlaken, Switzerland, June 4-5, pp.177-182.

Railway Information System Co., Ltd., 2001. JR System,

http://www.jrs.co.jp/keiki/en/index_main.html.

Schneier, B., 2001. Secrets & Lies Digital Security in a

Networked World, John Wiley & Sons.

Sindre, G. and Opdahl, A. L., 2005. “Eliciting security

requirements with misuse cases,” Requirements

Engineering, Vol. 10, pp. 34-44.

Sutcliffe, A. G., Maiden, N. A. M., Minocha S., Manuel

D., 1998. Supporting Scenario-Based Requirements

Engineering, IEEE Trans. Software Engineering,

Vol.24, No.12, pp.1072-1088.

Toval, A., Nicolaus, J. Moros, B. and Gracia, F., 2002.

Requirements Reuse for Improving Information

Systems Security: A Practitioner’s Approach,

Requirements Engineering, Vol. 6, No. 4, pp. 205-219.

Toyama, T., Ohnishi, A., 2005. Rule-based Verification of

Scenarios with Pre-conditions and Post-conditions,

Proc. Of the 13

IEEE International Conference on

Requirements Engineering (RE’05), Paris, France,

pp.319-328.

Weidenhaupt, K., Pohl, K., Jarke, M., Haumer, P., 1998.

Scenarios in System Development: Current Practice,

IEEE Software, Vol.15, No.2, pp.34-45.

Zhang, H. and Ohnishi, A., 2004. “Transformation

between Scenarios from Different Viewpoints”, IEICE

Transactions on Information and Systems, Vol. E87-

D, No. 4, pp. 801-810.

VERIFICATION OF SCENARIOS USING THE COMMON CRITERIA
