SEPARATING PROGRAM SEMANTICS FROM DEPLOYMENT

Nurudeen Lameed and Peter Grogono

Department of Computer Science and Software Engineering, Concordia University

1455 de Maisonneuve Blvd. W, Montreal, Canada

Keywords:

Concurrency, mapping, communication, protocol, abstraction.

Abstract:

Designing software to adapt to changes in requirements and environment is a key step for preserving software

investment. As time passes, applications often require enhancements as requirements change or hardware en-

vironment changes. However, mainstream programming languages lack suitable abstractions that are capable

of providing the needed ﬂexibility for the effective implementation, maintenance and refactoring of parallel

and distributed systems. Software must be modiﬁed to match today’s needs but must not place even greater

strain on software developers. Hence, software must be specially designed to accommodate future changes.

This paper proposes an approach that facilitates software development and maintenance. In particular, it ex-

plains how the semantics of a program can be separated from its deployment onto multiprocessor or distributed

systems. Through this approach, software investment may be preserved when new features are added or when

functionality does not change but the environment does.

1 INTRODUCTION

Advances in software development practices facili-

tated the programming of many hard problems. Many

interesting and crucial problems have been solved.

The success however, is generating an increasing de-

mand for ever more challenging computations. Con-

sequently, softwareis becoming increasingly complex

to design. To cope with this challenge, various tools,

languages and techniques have been proposed, imple-

mented and utilized. The transition from procedu-

ral to object-oriented programming helped to facili-

tate the construction of software that otherwise would

have been inconceivable. However, increase in soft-

ware complexity as a result of changes in environ-

ment and functionality has exposed some signiﬁcant

limitations of object-oriented approach: current prac-

tice makes software enhancement and refactoring dif-

ﬁcult.

Furthermore, the drive for continued performance

gains is causing major processor manufacturers to

produce microprocessors with multiple cores on a

chip. Multi-core architectures have potentials to boost

performance. However, existing applications are

largely sequential. To achieve true performance gains

software must be carefully written to exploit hardware

parallelism (Olukotun and Hammond, 2005; Sutter,

2005a). But concurrent programmingis hard. Experts

agree that concurrent programming is hard because

mainstream programming languages do not provide

suitable abstractions for expressing and controlling

concurrency. (Lee, 2006; Sutter, 2005b; Harris and

Fraser, 2003).

We have implemented our approach in a new

process-oriented language named Eramsus. Although

in this paper, we describe the approach within the

context of Erasmus; we believe due to the nature of

process-oriented design, the approach can be imple-

mented in any process-oriented language. The paper

is structured into the following sections: section 2 ex-

amines the object and the process-oriented models;

section 3 brieﬂy describes the Erasmus programming

language; section 4 explains how software compo-

nents may be mapped onto processors; section 5 ex-

amines the implementation; section 6 discusses test-

ing and performance evaluation; section 7 discusses

the results; section 8 reviews some related work and

ﬁnally, section 9 concludes the paper.

2 THE OBJECT AND THE

PROCESS MODELS

This section reviews the object-oriented and the

process-oriented models.

Lameed N. and Grogono P. (2008).

SEPARATING PROGRAM SEMANTICS FROM DEPLOYMENT.

In Proceedings of the Third International Conference on Software and Data Technologies - PL/DPS/KE, pages 63-70

DOI: 10.5220/0001877300630070

 SciTePress

2.1 The Object-Oriented Model

Object-oriented programming has been very success-

ful for general purpose programming tasks for almost

two decades. It is hard to imagine another paradigm

replacing it. The idea behind OO programming is that

an object encapsulates data and provides controlled

access to the data via its methods; the behaviour of

an object is determined by its class and may be ex-

tended incrementally through inheritance. In practice

however, OO programming has become more com-

plex than this simple model suggests. For instance,

an object does not have control over the sequence in

its methods are called. Thus, it cannot ensure that an

initialization method is called before any other meth-

ods (Grogono et al., 2007). This makes it difﬁcult to

design objects. The designer must handle all possible

calling sequences or trust clients to call methods in

the intended sequence. The compiler cannot enforce

correct call sequencing.

Object-oriented languages have extended levels of

visibility because the original levels of visibility —

private, public and protected — were inadequate. The

extensions such as package scope, static method, in-

terfaces, inner classes, anonymous inner classes, sim-

plify programming but make application maintenance

difﬁcult.

2.2 The Process-Oriented Model

The process-oriented model represents an alternative

to the object-oriented model. A process is a program

module that deﬁnes a data structure and a sequence

of statements that operate on it. The idea of organiz-

ing programs into collections of processes is not new.

This idea was pioneered at MIT in the CTSS project

(Salzer, 1965).

The beneﬁts of the process-oriented model are

well known. Processes are more general. They are

loosely coupled and have more autonomy as com-

pared to objects. This is because they only have ef-

fect on one another during rare and brief communi-

cation. In addition, unlike objects that do not have

control over the way in which its methods are called,

a process owns its thread of control and can choose

when to communicate or not communicate. Besides,

if a process operates only on its private data, it will be

completely independent of other processes. Dijkstra

declares:

We have stipulated that processes should be

connected loosely; by this we mean that apart

from the (rare) moments of explicit intercom-

munication, the individual processes them-

selves are to be regarded as completely inde-

pendent of each other. (Dijkstra, 1968)

Process-based code can be refactored into object-

based code but the converse is difﬁcult, if not impossi-

ble. It is easier to map processes onto multiple address

spaces than objects. Furthermore, it is often easier to

model applications with processes than objects.

Processes have been utilized in operating sys-

tems and programming languages. Hoare (Hoare,

1978) proposed communicating sequential processes

as a method of structuring programs. Joyce

(Brinch Hansen, 1987), Erlang (Armstrong et al.,

2004), Occam-π (Barnes and Welch, 2003; Barnes

and Welch, 2004) are based on communicating pro-

cesses. The next section describes the Erasmus Pro-

gramming language.

3 THE LANGUAGE, ERASMUS

The programming language, Erasmus is being de-

veloped by Peter Grogono at Concordia University,

Canada and Brian Shearing at The Software Factory,

UK. Erasmus is based on communicating processes.

Concurrency in Erasmus is based on communicat-

ing processes. A closure is an autonomous process

with its own state and instructions. Closures may have

parameters and communicate over synchronous chan-

nels satisfying some well-deﬁned protocols. A port

serves as an interface for a closure to communicate

with another closure.

The basic building block of an Erasmus program

are cells, closures and protocols. A cell is a collection

of one or more closures. Protocols deﬁne constraints

on messages that can be transferred with any port that

is associated with the protocol. Cells and processes

can be created dynamically. Erasmus cells, processes

and ports are ﬁrst-class entities: they can be transmit-

ted from one process to another and may be sent over

a network. A program is a sequence of deﬁnitions fol-

lowed by the instantiation of a cell. An example of a

simple Erasmus program is

sayHello = {| sys.out := "Hello"; };

cell = ( sayHello() );

cell ();

The program prints the string “Hello” to the stan-

dard output device. It comprises of a process named

sayHello, followed by a cell deﬁnition and an instan-

tiation of the cell. When the cell is instantiated, it

instantiates sayHello, and sayHello starts to execute.

ICSOFT 2008 - International Conference on Software and Data Technologies

4 MAPPING OF CELLS TO

PROCESSORS

Erasmus separates program semantics from its de-

ployment: programmer deﬁnes cells and messages

that cells exchange; separately, the programmer spec-

iﬁes how cells are assigned to processors — a task

commonly referred to as mapping. This clear sepa-

ration of concerns makes it possible to use the same

syntax for communications regardless of the environ-

ment.

The explicit mapping of cells onto processors has

several other beneﬁts. Cells that communicate fre-

quently may be mapped onto processors that are phys-

ically close to reduce communication time. Being fa-

miliar with the nature of the problem that is solved

by the program, programmer may map cells onto pro-

cessors considering the speciﬁc nature of the prob-

lem and the characteristics of the individual proces-

sors (Bal et al., 1989).

Erasmus program may be compiled to run on a

standalone system. The same program may be re-

compiled to run on a multicomputer — a network of

computers with independent memory. Furthermore,

the program code may be moved to a multiprocessor

system with shared memory. All this is possible with-

out changing the source program. However, compi-

lation of an Erasmus program for a multiprocessor

or distributed system requires a separate conﬁgura-

tion ﬁle that speciﬁes speciﬁc detail about mapping

of cells onto the participating processors.

A typical conﬁguration ﬁle is an XML ﬁle; it

contains speciﬁc properties about processors encap-

sulated within a pair of

and

</mapping>

tags. A record is deﬁned for each processor within

and

</processor>

. A processor

record speciﬁes the name of the processor, the port

number of its communicating agent called broker

and, a list of cells mapped onto this processor. The

port number is enclosed within a pair of

<port>

and

</port>

tags. A cell is deﬁned within

<cell>

and

</cell>

. A sample conﬁguration ﬁle is shown be-

low.

<processor> alpha.encs.concordia.ca

<cell> squareCell </cell>

</processor>

<processor> latvia.encs.concordia.ca

<cell> clientCell </cell>

</processor>

</mapping>

The conﬁguration ﬁle shown above maps

squareCell onto the processor identiﬁed by

alpha.encs.concordia.ca and clientCell onto

latvia.encs.concordia.ca. If the following pro-

gram is compiled without any conﬁguration ﬁle, it

generates code for standalone systems. However,

the two cells: squareCell and clientCell may be

mapped onto different processors as shown in the

conﬁguration ﬁle above.

sqProt = [*(query:Float; ˆreply:Text)];

square = { p: +sqProt |

loop

q: Float := p.query;

p.reply := text (q * q);

end };

squareCell = (prot: +sqProt |

square(prot) );

client = { p: -sqProt |

num : Float := 10;

p.query := num;

sys.out := text num + "ˆ2 = ";

sys.out := p.reply + "\n"; };

clientCell = ( prot: -sqProt |

client(prot) );

mainCell = ( chan: sqProt;

clientCell(chan);

squareCell(chan) );

mainCell();

square

client

squareCell clientCell

mainCell

chan: sqProt

p p

Figure 1: A diagram corresponding to the program above.

In the program shown above, two cells, client-

Cell and squareCell are connected to a channel named

chan through their local ports. Figure 1 shows a di-

gram corresponding to the program. The ports use

the protocol deﬁned by sqProt. The processes square

and client have ports that are connected to chan as

shown in Figure 1. A port that provides a service is

referred to as a server port and is declared using the

preﬁx

‘+’

before the name of the protocol associated

with the port. A port that needs a service is called a

client port and is declared using the symbol

‘-’

. A

port declaration with no sign creates a channel.

The port p of square is a server port (i.e. it pro-

vides a square service) while client has a client port

i.e it needs a square service. When mainCell is instan-

tiated, clientCell and squareCell are also instantiated.

This causes a concurrent execution of processes in the

two cells. The cell clientCell sends a number (10) to

SEPARATING PROGRAM SEMANTICS FROM DEPLOYMENT

the squareCell via its local port, prot. The squareCell

sends a reply (i.e. a string containing 100, the square

of 10) to the client.

4.1 Compilation Process

Compilation of an Erasmus program that comprises

of cells mapped onto some processors requires a con-

ﬁguration ﬁle. The compiler reads the XML ﬁle, ex-

tracts the data and organizes the contents into a ta-

ble. The compiler generates a unique identiﬁcation

for each cell. Later, it retrieves mapping information

for each cell. This is eventually written to a ﬁle —

hosts.txt — in an order determined by cell id; each

line of the ﬁle contains a record about a cell. If there

is no entry for a cell in the conﬁguration ﬁle, ‘local-

host’ and port number 0 is written for the cell. This

indicates that any available processor may execute the

cell.

5 IMPLEMENTATION

5.1 Inter-process Communication

Various approaches for implementing communica-

tion and synchronization between isolated processes

have been proposed and implemented. Gregory An-

drews (Andrews, 2000) proposed a centralized mes-

sage passing implementation that uses a “clearing

house”. A clearinghouse process matches pairs of

communication requests. A template is a message

that describes a communication request. When a pro-

cess wants to communicate, it sends a template or a

set of templates, if several communications are pos-

sible. When the clearinghouse receives a template, it

checks if it has received before a “matching” template

otherwise, it stores the template. If it has a match-

ing template, it sends some synchronization messages

to the processes that sent the templates. These pro-

cesses then use the information received from the

clearinghouse to communicate. Subsequently, both

processes continue at their next statements after ex-

changing data.

A disadvantage of a centralized implementation

is the inherent potential for the clearinghouse to be-

come a bottleneck in the system. This is likely to be

exacerbated where large number of processes is in-

volved. Other implementations can be found in (Sil-

berschatz, 1979; Bernstein, 1980; Schneider, 1982;

Buckley and Silberschatz, 1983; Bagrodia, 1989).

The implementation described in this section uses a

distributed clearinghouse for inter-process communi-

cation. Since we require reliable communications and

TCP/IP guarantees that messages are delivered in the

order in which they have been sent, our implementa-

tion is based on TCP/IP.

5.2 The Broker Process

Each processor runs a special process named broker.

The broker is responsible for handling all commu-

nications by processes. The port address on which

the broker attached to a processor runs is speciﬁed as

a property of the processor in the conﬁguration ﬁle.

During start-up, a broker loads a table with the data

from the ﬁle, hosts.txt created earlier during compila-

tion by the compiler. As described earlier, a record in

hosts.txt comprises of a host name and a port number.

A broker also maintains a table of valid connections

to cells and brokers running on other hosts. Brokers

are daemons that match communications.

A cell that wishes to communicate with another

cell sends the request to its local broker. Cells must

ﬁrst establish connections to their local brokers before

executing any instructions. If a connection has been

established, the cell activates its processes. Mean-

while, the broker listens for requests from commu-

nicating agents (cells or brokers). When a broker re-

ceives such request, it stores it until it ﬁnds a matching

request from another cell. The message transferred in

a particular request depends on whether the request is

a read (receive) or write (send) operation.

The distributed nature of the broker reduces the

likelihood of a broker becoming a bottleneck in sys-

tem. Messages received by a broker are addressed to

cells running on the host.

server

client

broker broker

hostA hostB

Figure 2: The broker process.

Every cell that communicates with another cell is

given a port to do so. A port is connected to a shared

channel. A channel connects two or more processes.

Ports are shown in the diagram as small circles. Com-

munication takes place when a port is referenced (i.e.

a qualiﬁed name refers to a ﬁeld of the associated pro-

tocol). When a process in a cell sends a message to

another cell, it constructs a message containing some

useful headers and sends the message to the broker

running on the host. The broker inspects the mes-

sage and retrieves some of the headers to determine

the location of the communicating partner. A mes-

sage comprises of

ICSOFT 2008 - International Conference on Software and Data Technologies

1. a port direction (0 or 1) which indicates whether

the sending port is a server or a client;

2. the cell id of the server connected to the channel;

3. the cell id of the source of the message;

4. policy type; values include: 0 (

ordered

), 1

(

fair

) and 2 (

random

);

5. input/output direction; 0 for read and 1 for write;

6. the type of the data carried, if the request is a write

operation;

7. the id of the destination cell (client/server);

8. a tag for the beginning of the data;

9. the data to be sent, if it is a write operation; empty

if it is a read operation;

10. a tag for the end of the data; a message may carry

more than one request.

When a process sends a write request to a broker,

it sends along with the message, the data to be written

to the other process. If the broker receives a match-

ing request, the data is copied into the variable of the

other process and both the sender and the receiver can

proceed independently and concurrently. Considering

the program and the XML ﬁle shown in shown in Sec-

tion 4, when squareCell executes

q:Float := p.query;

assuming that squareCell and clientCell have been as-

signed unique ids, 1 and 2 respectively, the compiler

builds a message (used later by the runtime system to

send and receive data) of this form:

1 2 3 4 5 6 7 8 9 10

----------------------------------------

| 0 | 1 | 1 | 0 | 0 | 1 | 2 | $ | | $ |

----------------------------------------

items at the subscripts 1-7, corresponds to the items

1-7 of the list describing the contents of a message.

Items eight and ten (“$$”) are tags that demarcate re-

spectively, the beginning and the end of the data in a

message. This is a read request, hence item nine —

the data — is empty.

This message (“

0 1 1 0 0 1 2 $$

”) is then sent

to the broker. When the broker receives the message,

it retrieves the ﬁrst two items in the message and per-

forms one of the following two actions:

1. if the port is a client port, it checks whether the

server that is connected to the channel is running

on this host or on a remote host. If the server is on

a remote host, it forwards the request to the broker

running at the host of the server and waits for a

reply from the broker. The reply is subsequently

forwarded to the client cell.

2. if the port is a server port, the broker queues the

message until (hopefully) a matching request is

received from the client.

Therefore in this case, the broker running on al-

pha.encs.concordia.ca forwards the message to the

broker running on latvia.encs.concordia.ca. This

message is matched by the receiving broker when it

receives a matching request i.e. a message of the form

1 1 2 0 1 1 1 $d$

from clientCell. The symbol d

denotes the data which can be of any size. This mes-

sage is generated when clientCell executes the state-

ment

p.query := num;

Typically, the communication broker marshals the

data carried in a message before sending the mes-

sage to a broker on another host. It unmarshals the

data when it receives a message from another bro-

ker. As an optimization, this process, i.e. mar-

shalling/unmarshalling may be avoided if both the

source and the destination hosts are known to have

the same architecture.

Matching occurs when a broker receives two mes-

sages: one from a client and another from a server.

The two input/output requests must be opposite. One

must be a read operation while the other must be a

write operation. The type of the data in the messages

must also match. The compiler checks the type and

direction of each message, ensuring that communi-

cation cannot fail at runtime. During matching, data

received is copied and sent to the process executing

a read command. The message may contain a set of

requests if the process is willing to communicate with

more than one process.

6 TESTING

The compiler has been used to compile the program

shown in Section 4 for a standalone computer. The

same program was also distributed on two computers:

the server cell running in one process on a computer

while the client runs in another process in a differ-

ent host. The broker processes on both hosts matched

communications between these cells. The program

works as a client-server system as speciﬁed by proto-

col sqProt. The client process sends a request to com-

pute the square of 10. The server responds by sending

the corresponding result (100) to the client. Although

the program (Section 4) solves a trivial problem, it

nevertheless shows how Erasmus facilitates distribu-

tion of programs to different architectures. In prac-

SEPARATING PROGRAM SEMANTICS FROM DEPLOYMENT

tice, this approach may help preserve software invest-

ment where software environment changes.

Tests conducted to evaluate impact of communi-

cations on the overall performance of programs writ-

ten in Erasmus are described next. The two com-

puters used for these tests, i.e. { latvia, lithuania }

.encs.concordia.ca have the same speciﬁcation. The

speciﬁcation is given below:

• Intel(R) Pentium(R) 4 CPU 3.00 GHz, 2.99 GHz,

1.00 GB of RAM; Operating System: Windows

XP Professional, version 2002; Service Pack 2.

The tests are grouped into two cases namely:

6.1 Case One

sp = [*(ask:Integer; ˆanswer:Integer)];

square = { p: +sp |

loop

in: Integer := p.ask;

x: Integer := in * in;

--- do more work

j: Integer := 0;

loop while j < 1000000 j += 1; end;

p.answer := x; end };

client = { p: -sp | x: Integer := 1;

loop

xs: Integer := x * x;

sys.out := text x + "ˆ2=" + text xs +"\n";

--- do more work

j: Integer := 0;

loop while j < 1000000 j += 1; end;

x := x + 1;

if x > 1500 then exit end end };

squareCell = ( p: +sp | square(p) );

clientCell = ( p: -sp | client(p) );

cell = (p: sp; clientCell(p);squareCell(p));

cell();

Considering the last program (above), it takes

145s

on latvia.encs.concordia.cafor clientCell to dis-

play the squares of the numbers from 1 to 1500. In

the program, clientCell essentially performs the re-

quired computation since no request whatsoever was

sent from clientCell to squareCell.

• Scenario One: if clientCell in the previous pro-

gram is replaced with the clientCell given below,

it takes

289s

to display the squares. In this case,

clientCell communicates frequently with square-

Cell by sending numbers whose squares are com-

puted by squareCell through the port p.

client = { p: -sp |x: Integer := 1;

loop

p.ask := x;

xs: Integer := p.answer;

sys.out := text x + "ˆ2=" + text xs +"\n";

--- do more work

j: Integer := 0;

loop while j < 1000000 j += 1; end;

x := x + 1;

if x > 1500 then exit end end };

Both clientCell and squareCell run in one mem-

ory space and therefore the compiler generates code

that is executable on a standalone computer. No con-

ﬁguration ﬁle is required and none was used in this

scenario. The difference in the elapsed-times (145s

vs 289s) for clientCell to display all the computed re-

sults can be attributed to the communication overhead

in executing the program above.

• Scenario Two: if this program is compiled using

the conﬁguration ﬁle shown below, it takes

236s

on latvia.encs.concordia.ca for clientCell running

in a separate address space to display the squares

of the numbers from 1 to 1500. It is interesting to

note that clientCell runs faster than in the previous

scenario. This suggests that the combined over-

head of the inter-process communication and the

runtime process scheduling overheads is higher in

scenario one than the communicationdelay in sce-

nario two.

<Processor> latvia.encs.concordia.ca

<Cell> squareCell </Cell>

<Cell> clientCell </Cell>

</Processor>

</Mapping>

• Scenario Three: if the same program is compiled

with the conﬁguration ﬁle shown below, it takes

clientCell running on latvia.encs.concordia.ca

241s

to completely display the squares of all the

numbers from 1-1500 as speciﬁed in the program.

This is slightly longer than that in scenario two.

This means that in this case, clientCell runs slower

than in scenario two. Frequent network communi-

cations between the client process in one host and

the server process in another host cause delays,

which are likely to offset any performance gains

in faster execution of clientCell due to the host’s

processor having fewer processes to execute.

<Processor> latvia.encs.concordia.ca

<Cell> clientCell </Cell>

</Processor>

<Processor> lithuania.encs.concordia.ca

<Cell> squareCell </Cell>

</Processor>

</Mapping>

In scenarios two and three, communication bro-

kers add to the communication delays. One broker

ICSOFT 2008 - International Conference on Software and Data Technologies

is involved in scenario two but two broker processes

(one on each host) are involved in scenario three.

6.2 Case Two: Infrequent Inter-process

Communications

The test described here is similar to the last three sce-

narios in case one. The only difference is that client-

Cell is replaced with the following code.

client = { p: -sp | x: Integer := 1;

loop

xs: Integer;

if x % 500 = 0 then

p.ask := x;

xs := p.answer;

else xs := x * x; end;

sys.out := text x + "ˆ2=" + text xs +"\n";

--- do more work

j: Integer := 0;

loop while j < 1000000 j += 1; end;

x := x + 1;

if x > 1500 then exit end end };

If the processes run in one memory space, client-

Cell takes

145s

to display all the squares. However, if

the last two conﬁguration ﬁles are used for scenario 2

and scenario 3 respectively as in case 1 above, client-

Cell takes roughly

116s

to ﬁnish. Tables 1 and 2 give

a summary of the tests in case one and case two re-

spectively.

Table 1: Summary of tests in Case one (Frequent Commu-

nications).

Scenario Execution time

Scenario one 289s

Scenario two 236s

Scenario three 241s

Table 2: Summary of tests in Case two (Infrequent Com-

munications).

Scenario Execution time

Scenario one 145s

Scenario two 116s

Scenario three 116s

7 DISCUSSION

Communication granularity concerns the frequency

and the size of messages sent from one process to

another process within a system. In a system that

uses ﬁne-grained communication, small messages are

sent by processes. This might be reasonable in envi-

ronments where the processors are physically close

to one another (closely coupled environments e.g.

multi-core architectures). In contrast to ﬁne-grained

communication, in a system that uses coarse-grained

communication, few large messages are sent from

one process to another process. This is most useful

in a loosely coupled (processors are physically dis-

persed) distributed environment where processes per-

form large computations and send very few but large

messages.

The approach described in this paper favours com-

munication at any level of granularity. However, pro-

grammers are supposed to match granularity to hard-

ware. Time measurements show that true concurrency

improves performances.

8 RELATED WORK

Communicating Sequential Processes (CSP) is a for-

mal language for specifying concurrent systems. Pro-

cesses in CSP communicate over synchronous chan-

nels (Hoare, 2004). Channel simpliﬁes synchro-

nization of interactions between communicating pro-

cesses. The π-calculus is a model of computation for

communicating systems that have changing structures

(Milner, 1980). This is especially useful for model-

ing systems that may be deployed on many different

platforms. Channels may be sent from one process to

another process to facilitate communication between

processes within a system. Our approach has been

inﬂuenced by CSP and π-calculus models.

Actor model (Hewitt, 1976; Hewitt and Baker,

1977) is an early attempt at formalizing concurrent

systems. Here, actor represents the basic construct

of computation. Actors interact by passing messages

over asynchronous channels. An actor include a con-

tinuation in its message if the receiver of the mes-

sage needs to send a reply. The receiver uses the

continuation to direct its reply. SALSA (Varela and

Agha, 2001) is actor-based language for program-

ming dynamically reconﬁgurable open distributed ap-

plications.

Clear separation of program semantics from its

distribution has never been the main goal of main-

stream languages. Recently, Erlang has become pop-

ular for programming concurrent applications. How-

ever, network transparency in Erlang requires pro-

grammers to address messages to process ids; sub-

stantial code would have to be re-written when hard-

ware environment changes. Mozart/Oz (Roy, 2004)

separates the functionality of a program from its

distribution thereby allowing the same programs to

be executed on different architectures. Following

Mozart/Oz, we believe the approach described thus

SEPARATING PROGRAM SEMANTICS FROM DEPLOYMENT

far will facilitate reconﬁguration of systems when

hardware environment changes.

9 CONCLUSIONS AND FUTURE

WORK

It has been shown in this paper that a distributed en-

vironment may be more suitable for a system where

processes rarely communicate. Frequent communica-

tions between the participating nodes in a distributed

system may degrade the overall performance of the

entire system. Clear separation of semantics and de-

ployment of a program helps to adapt the program to

different architectures. In practice, this may help to

preserve software investment. As we have seen the

feasibility of our approach, we hope implement other

aspects of the project and conduct further tests on dif-

ferent architectures, including the multi-core architec-

tures.

ACKNOWLEDGEMENTS

We are grateful to the faculty of Engineering and

Computer Science, Concordia University for support-

ing in part the work described in this paper.

REFERENCES

Andrews, R. G. (2000). Foundations of Multithreaded, Par-

allel, and Distributed Programming. Addison-Wesley.

Armstrong, J., Virding, R., Wikstrom, C., and Williams, M.

(2004). Concurrent Programming in ERLANG. Pren-

tice Hall, second edition.

Bagrodia, R. (1989). Synchronization of Asynchronous

Processes in CSP. ACM Transaction on Programming

Languages and Systems, 11(4):585–597.

Bal, H. E., Steiner, J. G., and Tanenbaum, A. S. (1989).

Programming Languages for Distributed Computing

Systems. ACM Computing Surveys, 21(3):261–322.

Barnes, F. and Welch, P. (2003). Prioritized Dynamic Com-

municating and Mobile Processes. IEE Proceedings -

Software, 150(2):121–136.

Barnes, F. R. and Welch, P. H. (2004). Communicating mo-

bile processes. In East, I., Martin, J., Welch, P., Duce,

D., and Green, M., editors, Communicating Process

Architectures, pages 201–218. IOS Press.

Bernstein, A. J. (1980). Output Guards and Non-

determinisn in CSP. ACM Transaction on Program-

ming Languages and Systems, 2(2):234–238.

Brinch Hansen, P. (1987). Joyce - A Programming Lan-

guage for Distributed Systems. Software Practice &

Experience, 17(1):29–50.

Buckley, G. N. and Silberschatz, A. (1983). An Effective

Implememtation for The Generalized Input-Output

Construct of CSP. ACM Transaction on Programming

Languages and Systems, 5(2):223–235.

Dijkstra, E. W. (1968). Cooperating Sequential Pro-

cesses. In Genuys, F., editor, Programming Lan-

guages: NATO Advanced Study Institute, pages 43–

112. Academic Press.

Grogono, P., Lameed, N., and Shearing, B. (2007). Modu-

larity + Concurrency = Manageability. Technical Re-

port TR E–04, Department of Computer Science and

Software Engineering, Concordia University.

Harris, T. and Fraser, K. (2003). Language Support for

Lightweight Transactions. ACM SIGPLAN Notices,

38(11):388–402.

Hewitt, C. (1976). Viewing Control Structures as Pattern of

Passing Messages. Technical Report AIM-410, De-

partment of Artiﬁcial Intelligence, MIT.

Hewitt, C. and Baker, H. (1977). Actors and Continuous

Functionals. Technical Report MIT/LCS/TR-194, De-

partment of Artiﬁcial Intelligence, MIT.

Hoare, C. A. R. (1978). Communication Sequential Pro-

cesses. Communications of the ACM, 21(8):666–677.

Hoare, C. A. R. (2004). Communicating Sequential Pro-

cesses. Prentice Hall International, third edition.

Lee, E. A. (2006). The Problem With Threads. IEEE Com-

puter, 39(5):33–42.

Milner, R. (1980). A Calculus of Communicating Systems.

Springer.

Olukotun, K. and Hammond, L. (2005). The Future of Mi-

croprocessors. ACM Queue, 3(7):26–34.

Roy, P. V. (2004). General Overview of Mozart/Oz. Slides

for a talk given at the Second International Mozart/Oz

Conference (MOZ 2004).

Salzer, J. H. (1965). M. I. T. Project MAC. Technical

Report MAC-TR-16, Department of Artiﬁcial Intel-

ligence, MIT.

Schneider, F. B. (1982). Synchronisation in Distributed Pro-

grams. ACMTransaction on Programming Languages

and Systems, 4(2):125–148.

Silberschatz, A. (1979). Communication and Synchroniza-

tion in Distributed Programs. IEEE Transaction on

Software Engineering, 5(6):542–546.

Sutter, H. (2005a). The Free Lunch Is Over - A

Fundamental Turn Toward Concurrency in Soft-

ware. Dr. Dobb’s Journal, 30(3). Available on-

line at http://www.gotw.ca/publications/concurrency-

ddj.htm.

Sutter, H. (2005b). The Trouble With Locks. Dr. Dobb’s

Journal.

Varela, C. and Agha, G. (2001). Programming Dynamically

Reconﬁgurable Open Systems with SALSA. ACM

SIG PLAN Notices, 36(12):20–34.

ICSOFT 2008 - International Conference on Software and Data Technologies
