SOFTWARE EFFORT ESTIMATION AS A CLASSIFICATION

PROBLEM

Ayşe Bakır, Burak Turhan and Ayşe Bener

Department of Computer Engineering, Boğaziçi University, 34342 Bebek, Istanbul, Turkey

Keywords: Software effort estimation, Interval prediction, Classification, Cluster analysis, Machine learning.

Abstract: Software cost estimation is still an open challenge. Many researchers have proposed various methods that

usually focus on point estimates. Software cost estimation, up to now, has been treated as a regression

problem. However, in order to prevent over/under estimates, it is more practical to predict the interval of

estimations instead of the exact values. In this paper, we propose an approach that converts cost estimation

into a classification problem and classifies new software projects in one of the effort classes each

corresponding to an effort interval. Our approach integrates cluster analysis with classification methods.

Cluster analysis is used to determine effort intervals while different classification algorithms are used to find

the corresponding effort classes. The proposed approach is applied to seven public data sets. Our

experimental results show that hit rates obtained for effort estimation are around 90%-100%s. For point

estimation, the results are also comparable to those in the literature.

1 INTRODUCTION

Software cost estimation is one of the critical steps

in software development lifecycle (Leung and Fan,

2002; Boehm, 1981). It is the process of predicting

the effort required to develop a software project.

Such predictions assist project managers when they

make important decisions such as bidding, etc.

Although most methods proposed in literature

produce point estimates, Stamelos and Angelis states

that producing interval estimates is safer (Stamelos

and Angelis, 2001). Up to now, interval estimation is

composed of finding either the confidence intervals

for point estimates or the posterior probabilities of

predefined intervals (Angelis and Stamelos, 2000;

Jorgensen, M., 2003; Sentas et al. 2004; Sentas et al.

2003) and then fitting regression-based methods to

these intervals. However, none of these approaches

address cost estimation problem as a pure

classification problem. In this paper, by using

interval estimation as a tool, we aim to convert cost

estimation into a classification problem. By using

cluster analysis, effort classes are determined

dynamically instead of using manually-predefined

intervals. Then, classification methods are applied

on clustered data in order to find the estimated effort

interval.

2 RELATED WORK

Previous work on software cost estimation mostly

produces point estimates by using regression

methods. There is less number of studies that focus

on interval estimation. These studies can be grouped

into two main categories: (1) those which produce

confidence intervals for point estimates and (2) those

which produce the probabilities of predefined

intervals. In (1), interval estimates are generated

during the estimation process (Angelis and

Stamelos, 2000; Jorgensen, M., 2003). In (2) the

intervals are predefined before the estimation

process (Sentas et al. 2004; Sentas et al. 2003). In

contrast to these studies, in this paper, firstly, effort

intervals are not predefined manually; rather, they

are determined by clustering analysis. Secondly,

instead of using regression-based methods, we use

classification algorithms that originate from machine

learning area. Thirdly, point estimates can still be

derived from these intervals; this will be shown in

the following sections.

We also use cluster analysis for grouping similar

projects in this paper as in (Lee et al. 1998; Gallego

et al. 2007). The difference of our research with

these studies is that we combine clustering with

classification methods for effort estimation.

274

Bakır A., Turhan B. and Bener A. (2008).

SOFTWARE EFFORT ESTIMATION AS A CLASSIFICATION PROBLEM.

In Proceedings of the Third International Conference on Software and Data Technologies - SE/GSDCA/MUSE, pages 274-277

DOI: 10.5220/0001877802740277

 SciTePress

Figure 1: Our proposed model.

On Each Cluster

Data

Min-Max Normalization

Normalized Data

Leader Cluster

Find Effort Intervals

for Each Cluster

10x10 Cross-Validation

K-NN

Calculate Errors

LD DT

PCA

3 THE APPROACH

There are three main steps in our approach: (1)

grouping similar projects together by cluster

analysis, (2) determining the effort intervals for each

cluster and specifying the effort classes, and (3)

classifying new projects into one of the effort

classes. The resulting class shows the effort interval

that contains the new project’s effort value.

In step (1), we use an incremental clustering

algorithm called Leader Cluster (Alpaydin, 2004). In

this algorithm, the number of the clusters is not

predefined; instead, the clusters are generated

incrementally and Euclidean distance is used as

similarity measure (Bakar et al. 2005; Lee et al.

1998).

In step (2), firstly, the minimum and maximum

of the efforts of the projects that reside in the same

cluster are found. Secondly, these minimum and

maximum values are chosen as the upper and lower

bounds of the interval that will represent that cluster.

Finally, each cluster is given a class label which will

be used to classify the new projects into.

In step (3), we use three different classification

algorithms with different complexities. Linear

Discrimination is the simplest one whereas Decision

Tree is the most complex one. K-Nearest Neighbor

has a moderate complexity depending on the training

set size (Alpaydin, 2004; Quinlan, 1993).

4 EXPERIMENTAL STUDY

MATLAB is used for the implementation of the

approach.

4.1 Data Set Description

In our experiments, data from two different sources

are used: Promise Data Repository and Software

Engineering Research Laboratory (SoftLab)

Repository (Boetticher et al., 2007; SoftLab). An

overview of all the datasets used is given in Table 1.

Table 1: An overview of the datasets used.

Data Source Dataset Name # of Projects

cocomonasa_v1 60

coc81 63

desharnais_1_1

(updated version)

Promise

nasa93 93

sdr05 25

sdr06 24

SoftLab

sdr07 40

4.2 Model

Our proposed model is shown in Figure 1. Before

applying any method, all of the datasets are

normalized in order to remove scaling effects in

different dimensions by using Min-max

normalization.

Firstly, clustering algorithm is applied to the

normalized data to obtain project groups. Secondly,

with Principal Component Analysis (PCA), each

cluster’s dimensions are reduced individually by

using their own covariance matrices (Alpaydin,

2004). The aim here is to prevent data loss within

clusters while extracting relevant features. Thirdly,

each cluster is assigned a class label and the effort

intervals for each of them are determined. Then, the

effort data containing projects with corresponding

class labels is given to each of the classification

algorithms described in Section 3. Since there are

not separate training and test sets, the classification

process is done in a 10x10 cross-validation loop. In

the cross-validation loop, data is 10 times shuffled

into random order and then divided into 10 bins.

Training set is built from nine of the bins, and the

SOFTWARE EFFORT ESTIMATION AS A CLASSIFICATION PROBLEM

275

coc81 cocomonasa desharnais nasa93 sdr05 sdr06 sdr07

KNN

remaining bin is used as validation set.

Classification algorithms are firstly trained on the

training set and then error calculations are made by

using the validation set. The errors are collected

during 100 cross-validation iterations.

In order to make a comparison with other

studies, at the classification step, point estimates are

calculated for each classification method. For this

process, both mean and median of the effort values

of the projects that belong to the class found by each

classifier are taken (Sentas et al., 2003).

4.3 Accuracy Measures

In our experimental study, there are two types of

accuracy measures: (a) misclassification rate for

classification and (b) MMRE, MedianMRE, and

PRED (25) for point estimates. Misclassification rate

can be thought as the complement of the hit rate that

has been mentioned in interval prediction studies. In

order to say that a model performs well, MdMRE

and MMRE values should be low and PRED (25)

values should be high.

5 RESULTS AND DISCUSSION

The effort clusters created for each dataset and the

minimum and maximum numbers of projects

assigned to a cluster are given in Table 2.

The classification results for effort interval

estimation are given in Figure 2. K-NN and LD

performs similar for coc81, desharnais_1_1, nasa93,

and sdr05. They both give 0% misclassification rate

for coc81 and sdr05. For cocomonasa_v1 and sdr06,

K-NN outperforms the others whereas for sdr07, LD

is the best one. In general, considering classifiers, K-

NN is the best performing one; LD follows it with a

slight difference whereas DT is the worst performing

one. The misclassification rates are 0% for most

cases and around 17% in the worst case.

The most recent study on effort interval

classification is Sentas et al.’s study. In Table 3 we

compare our results with that of Sentas et.al. Note

that the intervals in their study are manually pre-

defined intervals.

Table 2: Effort clusters for each dataset.

# of Projects

Dataset

# of

Clusters

Min Max

coc81

4 2 44

cocomonasa_v1

5 3 36

desharnais_1_1

9 2 21

nasa93

6 3 44

sdr05

3 3 16

sdr06

3 2 12

sdr07

4 6 16

In order to show how our results can be easily

converted to point estimates, in Table 4, we present

the point estimation results found by either taking

the mean or median of the projects’ effort values. K-

NN and LD perform nearly the same and better than

DT for all datasets. All classifiers’ performances

improve for all measures when median is used for

point estimation. MMRE and MdMRE results

decrease down to 13% and PRED results increase up

to 86% for some datasets. Note that an 86 % PRED

value means that 86% of all estimations are within

25% confidence interval, which shows the stability

and robustness of our proposed model.

Table 3: Comparison of the results.

Hit rate (%)

Min Max

Sentas et al.

60.38 79.24

Our model

97 100

6 CONCLUSIONS AND FUTURE

WORK

In this paper, we handle cost estimation as a

classification problem rather than a regression

Figure 2: Effort misclassification rates for each dataset.

ICSOFT 2008 - International Conference on Software and Data Technologies

276

Table 4: Point estimation results (%).

Using the mean of projects Using the median of projects

Dataset Classifier

MMRE MdMRE PRED MMRE MdMRE PRED

LD 189 183 33 131 131 33.6

K-NN 189 183 33 131 131 33.6

coc81

DT 192 190 29.6 134 131 30.2

LD 69 45 42.2 51 32 54.8

K-NN 69 45 42 51 32 54.6

cocomonasa_v1

DT 76 50 26.8 58 40 39.4

LD 13 12 84.14 13 12 86.42

K-NN 13 12 84.14 13 12 86.71

desharnais_1_1

DT 16 15 79 15 15 81.85

LD 70 52 55.5 52 40 57.7

K-NN 69 52 55.5 52 40 57.7

nasa93

DT 72 52 51.2 55 41 53.4

LD 45 28 45.5 37 26 52

K-NN 45 28 45.5 37 26 52

sdr05

DT 59 44 28.5 52 38 35

LD 31 31 50.5 25 23 67

K-NN 30 31 50.5 24 23 67

sdr06

DT 34 36 44.5 27 25 61

LD 14 14 84.66 14 14 79.6

K-NN 14 13 81.33 14 14 76.3

sdr07

DT 14 13 81.33 14 14 76.3

problem and propose an approach that classifies new

software projects in one of the dynamically created

effort classes each corresponding to an effort

interval. In the experiments done, we obtain higher

hit rates than other studies in the literature. For point

estimation results, we can see that MdMRE, MMRE,

and PRED (25) values are comparable to those in the

literature for most of the datasets although we use

simple methods like mean and median regression.

Future work includes using different clustering

techniques to find effort classes and to apply

regression-based models for point estimation.

ACKNOWLEDGEMENTS

This research is supported by Boğaziçi University

research fund under grant number BAP 06HA104

and the Turkish Scientific Research Council

(TUBITAK) under grant number EEEAG 108E014.

REFERENCES

Alpaydin, E., 2004. Introduction to Machine Learning,

MIT Press.

Angelis, L., Stamelos, I., 2000. A Simulation Tool for

Efficient Analogy Based Cost Estimation, Empirical

Software Engineering, 5, 35-68.

Bakar, Z. A., Deris, M. M., Alhadi, A. C., 2005.

Performance Analysis of Partitional and Incremental

Clustering, SNATI 2005.

Boehm B. W., 1981. Software Engineering Economics,

Prentice-Hall.

Boetticher, G., Menzies, T., Ostrand, T., 2007. PROMISE

Repository of Empirical Software Engineering Data,

http://promisedata.org/repository, West Virginia

University, Department of Computer Science.

Gallego, J. J. C., Rodriguez, D., Sicilia, M. A., Rubio, M.

G., Crespo, A. G., 2007. Software Project effort

Estimation Based on Multiple Parametric Models

Generated through Data Clustering, Journal of

Computer Science and Technology, 22 (3), 371-378.

Jorgensen, M., 2003. An Effort Prediction Interval

Approach Based on the Empirical Distribution of

Previous Estimation Accuracy, Information and

Software Technology, 45, 123-126.

Lee, A., Cheng, C. H., Balakrishnan, J., 1998. Software

Development Cost Estimation: Integrating Neural

Network with Cluster analysis, Information &

Management, 34, 1-9.

Leung, H., Fan, Z., 2002. Software Cost Estimation,

Handbook of Software Engineering and Knowledge

Engineering, Vol. 2, World Scientific.

Quinlan, J. R., 1993. C4.5: Programs for Machine

Learning, Morgan Kaufman.

Sentas, P., Angelis, L., Stamelos, I., 2003. Multinominal

Logistic Regression Applied on Software Productivity

Prediction, PCI 2003, 9

Panhellenic Conference in

Informatics, Thessaloniki.

Sentas, P., Angelis, L., Stamelos, I., Bleris, G., 2004.

Software Productivity and Effort Prediction with

Ordinal Regression, Information and Software

Technology, 47 (2005), 17-29.

SoftLab, Software Research Laboratory, Department of

Computer Engineering, Bogazici University,

http://softlab.boun.edu.tr

Stamelos, I., Angelis, L., 2001. Managing Uncertainty in

Project Portfolio Cost Estimation, Information and

Software Technology, 43(13), 759-768.

SOFTWARE EFFORT ESTIMATION AS A CLASSIFICATION PROBLEM

277
