AN EXTENDED MASTER WORKER MODEL FOR

A DESKTOP GRID COMPUTING PLATFORM (QADPZ)

Monica Vlădoiu

Departament of Informatics, PG University of Ploieşti Romania, Bd. Bucureşti, Nr. 39, Ploieşti, Romania

Zoran Constantinescu

ZealSoft Ltd., Str. Tg. Neamţ, Nr. 60, Bucureşti, Romania

Keywords: Grid computing, desktop grid computing, distributed and parallel computing, master worker paradigm.

Abstract: In this paper we first present briefly QADPZ, an open source platform for heterogeneous desktop grid

computing, which enables users from a local network (organization-wide) or Internet (volunteer computing)

to share their resources. Users of the system can submit compute-intensive applications to the system, which

are then automatically scheduled for execution. The scheduling is made based on the hardware and software

requirements of the application. Users can later monitor and control the execution of the applications. Each

application consists of one or more tasks. Applications can be independent, when the composing tasks do

not require any interaction, or parallel, when the tasks communicate with each other during the computation.

QADPZ uses a master worker-model that is improved with some refined capabilities: push of work units,

pipelining, sending more work-units at a time, adaptive number of workers, adaptive timeout interval for

work units, and use of multithreading, to be presented further in this paper. These improvements are meant

to increase the performance and efficiency of such applications.

1 INTRODUCTION

Usually, complex computational and visualization

algorithms require large amounts of computational

power. The computing power of a single desktop

computer is insufficient for running such complex

algorithms, and, usually, large parallel super-

computers or dedicated clusters are used for this job.

However, very high initial investments and

maintenance costs limit their availability. A more

convenient solution is based on the use of non-

dedicated desktop PCs in a Desktop Grid (DG)

computing environment. Harnessing idle CPU

cycles, storage space and other resources of

networked computers to work together on a

particularly computational intensive application, and

increasing power and communication bandwidth of

desktop computers provides for this solution.

In a DG system, the execution of an application

is orchestrated by a central scheduler node, which

distributes the tasks amongst the worker nodes and

awaits workers' results. It is important to note that an

application only finishes when all tasks have been

completed. The attractiveness of exploiting DGs is

further reinforced by the fact that costs are highly

distributed: every volunteer supports her resources

(hardware, power costs and internet connections)

while the benefited entity provides management

infrastructures, namely network bandwidth, servers

and management services, receiving in exchange a

massive and otherwise unaffordable computing

power. The usefulness of DG computing is not

limited to major high throughput public computing

projects. Many institutions, ranging from academics

to enterprises, hold vast number of desktop

machines and could benefit from exploiting the idle

cycles of their local machines.

We present briefly here QADPZ, an open source

platform for heterogeneous desktop grid computing,

which enables users from a local network (enterprise

DG) or Internet (volunteer computing) to share their

resources. The system allows a centralized

management and use of the computational power of

idle computers from a network of desktop

computers. Users of the system can submit compute-

intensive applications to the system, which are then

169

adoiu M. and Constantinescu Z. (2008).

AN EXTENDED MASTER WORKER MODEL FOR A DESKTOP GRID COMPUTING PLATFORM (QADPZ).

In Proceedings of the Third International Conference on Software and Data Technologies - PL/DPS/KE, pages 169-174

DOI: 10.5220/0001882301690174

 SciTePress

automatically scheduled for execution. The

scheduling is made based on the application’s

hardware and software requirements. Users can later

monitor and control the execution of the

applications, each of them consisting of one or more

tasks. Applications can be independent, when the

composing tasks do not require any interaction, or

parallel, when the tasks communicate with each

other during the computation.

QADPZ has pioneered autonomic computing for

desktop grids and presents specific self-management

features: self-knowledge, self-configuration, self-

optimization and self-healing (Constantinescu,

2003). It is worth to mention that to the present the

QADPZ has over a thousand users who have

download it, and many of them use it for their daily

tasks (SOURCEFORGE, 2008).

2 MASTER WORKER

PARADIGM

The QADPZ framework is based on an extended

version of the master-worker paradigm. Some of the

disadvantages in using this model in a heterogeneous

and dynamic environment are briefly described here.

The traditional master-worker has the worker nodes

downloading small tasks from a central master node,

executing them, and then sending back the results to

the master. The master-worker computing paradigm

is built on the observation that many computational

problems can be broken into smaller pieces that can

be computed by one or more processes in parallel.

That is, the computations are fairly simple consisting

of a loop over a common, usually compute-

intensive, region of code. The size of this loop is

usually considered to be long.

In this model, a number of worker processes are

available, each can perform any one of the steps in a

particular computation. The computation is divided

into a set of mutually independent work units by a

master node. Worker nodes then execute these work

units in parallel. A worker repeatedly gets a work

unit from its master, carries it out and sends back the

result. The master keeps a record of all the work

units of the computation it is designed to perform.

As each work unit is completed by one of the

workers, the master records the result. Finally, when

all the work units have been completed, the master

produces the complete result. The program works in

the same way irrespective of the number of workers

available - the master just gives out a new work unit

to any worker who has completed the previous one.

Whereas the master worker model is easily

programmed to run on a single parallel platform,

running such a model for a single application across

distributed machines presents interesting challenges.

On a parallel platform, the processors are always

considered identical in performance. In a distributed

environment, and especially in a heterogeneous one,

processors usually have different types and

performance. This raises the problem of load

balancing of work-units between the workers in such

a way to minimize the total computing time of the

application. The ideal application is coarse-grain and

embarrassingly parallel. Granularity is defined as the

computation-to-communication ration, with coarse

grain applications involving small communication

time compared to computation time, and fine

grained application requiring much more time for

communication than computation.

Coarse-grain applications are ideal for DG

computing because most DG systems employ

commodity network links, which have limited

bandwidth and high latencies. Embarrassingly

parallel applications are those problems that easily

decompose into a collection of completely

independent tasks. Examples of such scientific

problems are: genetic and evolutionary algorithms,

Monte Carlo simulations, distributed web crawling,

image processing, image rendering.

In a heterogeneous environment, scheduling,

which includes both problem decomposition and

work-unit distribution (placement to workers), has a

dramatic effect on the program's performance. An

inappropriate decision regarding decomposition or

distribution can result in poor performance, due to

load imbalance. Effective scheduling in such

environments is a difficult problem.

This problem can be overcome by using

relatively simple heuristics, if appropriate

mechanisms are provided to the scheduler to

determine the complexity of the problem wrt.

computation and communication. This information

is then used to decompose the problem and schedule

the work-units in a manner that provides good load

balance, and thus good performance. The idea of

using dynamic creation of subtasks is also presented.

Subtasks are generated according to the

requirements of the problem, by taking into

consideration the available performance parameters

of the system (network bandwidth, latency, CPU

availability and performance).

ICSOFT 2008 - International Conference on Software and Data Technologies

170

3 IMPROVED MASTER

WORKER MODEL

We present in this section an improved version of

the master-worker model, which is based on an

algorithm with dynamic decomposition of the

problem and dynamic number of workers. The

improvements regard the performance of the original

model, by increasing the time workers are doing

computations, and decreasing the time used for

communication delays. This is achieved by using

different techniques, such as pipelining of the work-

units at the worker, redundant computation of the

last work-units to decrease the time to finish,

overlapped communication and computation at the

workers and the master, use of compression to

reduce the size of messages. We will describe in the

following subsections each of these techniques.

3.1 Pull vs. Push for Work-Units

In the original master-worker model, each time a

worker finishes a work-unit, it has to wait until it

receives the next work-unit for processing. If this

communication time is comparable with the time

needed for executing a work-unit, the efficiency of

the worker is reduced very much. The time intervals

used for communication and computation

(processing) are described in Figure 1.

The master-worker model uses the pull

technology, which is based on the request/response

paradigm. This is typically used to perform data

polling. The user (in our case the worker) is

requesting data from the publisher (in our case the

master). The user is the initiator of the transaction.

In contrast, a push technology relies on the

publish/subscribe/distribute paradigm. The user

subscribes once to the publisher, and the publisher

will initiate all further data transfers to the user. This

is better suited in certain situations.

Figure 1: Worker timeline in execution.

We first extend the master-worker model by

replacing the pull technology with the push

technology, as it is illustrated in Figure 2.

Figure 2: Pull vs. Push technology.

In this model, the worker doesn't send any more

requests for work-units. Instead, it first announces its

availability to the master when it starts, and the

master is responsible for sending further work-units.

The workers just wait for work-units, and process

them when received. At the end of each work-unit, it

sends back the results to the master. The master will

further send more work-units to the worker. This

moves all decisions about initiating work-units

transfers to the master, allowing a better control and

monitoring of the overall computation.

3.2 Pipelining of Work-Units

The worker efficiency increases if we reduce the

total time spent in waiting for communication. One

way to do that is to use work-units pipelining at the

worker, thus making sure that the worker has a new

work-unit available when it finishes the processing

of the current work-unit. Pipelining is achieved by

sending more that one work-unit to the workers, as

shown in Figure 3. Each worker will have at least

one more work-unit in addition to the one being

processed at that worker. This is done so that the

worker, after finishing a work-unit, will have ready

the next one for processing. In the beginning, the

master sends more than one work-units to the

worker, then after each received result, sends

another work-unit to be queued on the worker. The

worker does not need to wait again for a new work-

unit from the master after sending the result, the next

work-unit being already available for processing.

AN EXTENDED MASTER WORKER MODEL FOR A DESKTOP GRID COMPUTING PLATFORM (QADPZ)

171

Figure 3: Pipelining of worker tasks.

The immediate advantage of pipelining is that the

waiting time for a new work-unit is eliminated. This

is described in Figure 4. While the worker is

processing the next work-unit, a new work-unit is

sent by the master and is queued in the operating

system. When using non-blocking communication,

the waiting time for sending the result to the master

after finishing a computation can be also eliminated.

Figure 4: Worker timeline for unit pipeline.

Keeping one new work-unit available at the worker

seems to be enough to reduce the waiting time for

communication. However, there is a situation when

this is not adequate. It can happen that the execution

time of a work-unit is much shorter than the

communication time (consisting of sending back the

result and receiving the new work-unit). In this case,

the worker finishes the current work-unit, but the

new one is not yet received. Thus, a certain waiting

time is involved for receiving it (see Figure 5).

Figure 5: Unit pipeline - worst case.

If there are many work-units with short execution

times, than the overall waiting time can increase

significantly, reducing the efficiency of the worker.

The condition for this not to happen is the following:

execreswu

ttt

≤

for the average

time values, or

(1)

(

)

∑

−−

≤+

unitswork unitswork

execreswu

ttt

for the

individual

time values

This situation can be improved by pipelining more

than two work-units at the worker, thus using a

larger pipeline. The master starts by sending out a

number of work-units to the worker to fill the

pipeline. Each time a result is received back from

the worker, the master sends a new work-unit, thus

keeping the pipeline full. This algorithm works as

long as the average execution time for a work-unit is

larger than the average communication time for

sending a result and a new work-unit between the

worker and the master. If the communication time is

too large, the pipeline will eventually become empty

and the worker will need to wait for new work-units.

3.3 Sending More Work-Units at a

Time

To overcome this situation, the master needs to send

more than one work-units per each message. The

master starts by sending a message containing more

than one work-unit, and then keeps sending as long

as the pipeline is not full. Each time it receives a

result, it sends another work-unit, to compensate the

decreasing number of work-units from the pipe. If

the worker sends only one result per message back

to the master, and the master sends only one new

work-unit, then, eventually the pipeline will become

empty. In order to prevent that, the worker will need

to send back more results at a time.

We could consider, for example, that the number

of results per message is equal to the number of

work-units per message sent from the master. In this

case, all results from the work-units, which came in

one message, are sent back to the master the same

way in one message after all of them were

successfully computed.

Figure 6: More work-units per message.

ICSOFT 2008 - International Conference on Software and Data Technologies

172

This would solve the previous problem if the time to

send a larger message (more work-units) were much

smaller than the time to send the individual

messages (one work-unit). This is usually possible if

the data required to describe one work-unit is small

enough, so the messages are kept short. However, it

could still happen that communication time is larger

than the execution time, so that the worker will end

up waiting for new work-units. The condition for

this not to happen is the following:

nexecmresnwu

ttt

,,,

≤+ for the average time

values of multiple work-units per message

and execution.

(2)

3.4 Adaptive Number of Workers

As mentioned before, in a heterogeneous

environment based on idle desktop computers, the

total number of workers available could be changing

during the computation. New workers can register to

the master, and other can become temporarily

unavailable. The master controls the total number of

workers used for computation, since he is the one

sending out work-units to the workers. If necessary,

the master can choose not to use all the available

workers for computation, only a few of them. This

might be for different reasons, as described further.

In the master-worker model, the master can

become a bottleneck, especially when there are a lot

of workers, which connect to get work-units and

send results back. Overloading the master could

cause the bottleneck. Because the master has also to

do a small amount of processing each time when it

receives results from the workers, if too many

workers connect to the master, the processing

resource available might not be enough and the

request will be delayed. There is an upper limit on

the number of workers that can connect to the master

without overloading it. Finding out this number is

not easy and it depends on a variety of parameters

from the entire system: computational capabilities of

workers and master, communication delays, the

amount of processing involved for each results, etc.

Another bottleneck could be caused by too much

communication. Considering that there is enough

computational power on the master to serve a large

number of workers, it could happen that there are

too many messages exchanged between the master

and workers, thus communication delays can occur.

This might happen either because there are too many

messages per time unit, or because the amount of

data transferred is too high, exceeding thus the

available network bandwidth. On the contrary, if

there is too few workers used, then the total time of

the computation will be too large, not exploiting all

the resources available. This suggests that there is

some optimum for the number of workers, which

can increase the overall efficiency of the whole

computation, and reduce the time to complete it.

We define the overall efficiency of the

computation as being the ratio between the total

amount of time since the beginning of the

computation (t

total

) and the sum of execution times

for all completed work-units on all workers:

∑

−

unitswork

exec

total

serial

parallel

system

(3)

We propose an adaptive algorithm to choose the

number of workers, based on performance measures

and estimates of execution times for work-units and

communication times for sending and receiving

messages. The number of workers is automatically

reduced if the efficiency of the computation

decreases. We employ a heuristic-based method that

uses historical data about the behavior of the

application. It dynamically collects statistical data

about the average execution times on each worker.

3.5 Use of Multithreading

The multithreaded programming paradigm allows

the programmer to indicate to the run-time system,

which portions of an application can occur

concurrently. Synchronization variables control the

access to shared resources and allow different

threads to coordinate during execution. The

paradigm has been successfully used to introduce

latency hiding in distributed systems or in a single

system where different components operate at

different speeds.

The paradigm of multithreading can provide

many benefits for the applications. In our situation,

it can provide good runtime concurrency, while

parallel programming techniques can be easier

implemented. The most interesting and probably

most important advantages are performance gains

and reduced resource consumption.

Operating system kernels supporting

multithreaded application perform thread switching

to keep the system reactive while waiting on slow

I/O services, including networks. In this way, the

system continues to perform useful work while the

network or other hardware is transmitting or

receiving information at a relatively slow rate.

Another benefit of multithreaded programming is

in the simplification of the application structure.

AN EXTENDED MASTER WORKER MODEL FOR A DESKTOP GRID COMPUTING PLATFORM (QADPZ)

173

Threads can be used to simplify the structure of

complex, server-type applications. Simple routines

can be written for each activity (thread), making

complex programs easier to design and code, and

more adaptive to a wide variation in user demands.

This has further advantages in the maintainability of

the application and future extensions.

The multithreaded paradigm can also improve

server responsiveness. Complex requests or slow

clients do not block other requests for service, the

overall throughput of the server being increased.

4 CONCLUSIONS

We have presented here our extended master-worker

model, which has been used in the QADPZ

development. Our model includes some refined

capabilities that are meant to increase the

performance and efficiency of the computation: push

of work units, pipelining, sending more work-units

at a time, adaptive number of workers, adaptive

timeout interval for work units, and use of

multithreading. Further measurements need to be

made in order to sustain our preliminary benchmark

tests that suggest significant improvements

regarding efficiency of the computation.

REFERNCES

Berman, F., et al., 2003. Grid computing: making the

global infrastructure a reality, J. Wiley, New York

BOINC. (2006) Open Source Software for Volunteer

Computing and Grid Computing (online) Available

from http://boinc.berkeley.edu, (Accessed 25

November 2007)

Constantinescu, Z., 2003 Towards an autonomic

distributed computing environment, in Proceedings of

International Workshop on Autonomic Computing

Systems, held in conjunction with 14

Int. Conf. on

Database and Expert Systems Applications DEXA

2003, pp. 694-698, Prague, Czech Republic

Constantinescu, Z. & Petrovic, P., 2002, Q2ADPZ* an

open source, multi-platform system for distributed

computing. ACM Crossroads, 9, pp. 13-20.

Constantinescu, Z., 2008, A desktop grid computing

approach for Scientific Computing and Visualization,

PhD Thesis, Norwegian University of Science and

Technology, Trondheim, Norway

Cummings, M. P., (2007), Grid Computing (online)

Available from http://serine.umiacs.umd.edu/

research/grid.php (Accessed 25 March 2008)

David, P. A., et. al., 2002 SETI@home: an experiment in

public-resource computing. Communications, ACM,

45, pp. 56-61.

Distributed.Net (2008) (online) Available from

http://distributed.net, (Accessed 5 March 2008).

Distributedcomputing.Info (2008) (online) Available from

http://distributedcomputing.info, (Accessed 5 March

2008)

Foster, I. & Kesselman, C., 1999. The grid: blueprint for a

new computing infrastructure, San Francisco, Morgan

Kaufmann Publishers.

Foster, I. & Kesselman, C., 2004. The grid: blueprint for a

new computing infrastructure, Amsterdam, Boston,

Morgan Kaufmann.

Garg, V. K., 1996. Principles of distributed systems,

Boston, Kluwer Academic Publishers.

Garg, V. K., 2002. Elements of distributed computing,

New York, Wiley-Interscience.

Globus (2007) Globus (online) Available from http://

www.globus.org, (Accessed 15 March 2008)

Juhasz Z., Kacsuk P., Kranzlmuller D., 2004, Distributed

and Parallel Systems: Cluster and Grid Computing,

New York, Springer

Karniadakis, G. & Kirby, R. M., 2003. Parallel scientific

computing in C++ and MPI: a seamless approach to

parallel algorithms and their implementation, NY,

Cambridge University Press.

Leopold, C., 2001. Parallel and distributed computing: a

survey of models, paradigms, and approaches, New

York, Wiley.

Mustafee, N. & Taylor, S. J. E., 2006. Using a desktop

grid to support simulation modelling, in Proceedings

of 28th International Conference on Information

Technology Interfaces (ITI 2006), Dubrovnik, Croatia,

pp. 557 - 562

QADPZ (2008) (online) Available from http://

qadpz.sourceforge.net. (Acc. 1 April 2008).

SETI@HOME (2003) (online) Available from http://

setiathome.ssl.berkeley.edu, (Acc5 May 2003)

SOURCEFORGE (2008) (online) Available from http://

sourceforge.net, Acc 1 April 2008

Sunderam, V. S., 1990 PVM: a framework for parallel

distributed computing. Concurrency: Practice.

Experience, Vol. 2, pp 315-339.

Vahid, G., Lionel, C. B., Yvan, L., 2006 Traffic-aware

stress testing of distributed systems based on UML

models, in Proceeding of the 28th International

Conference on Software engineering, Shanghai, China

Zomaya, A. Y., 1996

Parallel and distributed computing

handbook, New York, McGraw-Hill.

ICSOFT 2008 - International Conference on Software and Data Technologies

174
