SECURITY AND AUTHENTICATION FOR NETWORKED

STORAGE

V. Kumar Murty

Department of Mathematics, University of Toronto, Toronto, ON, Canada

Guangwu Xu

Department of EE & CS, University of Wisconsin-Milwaukee, Milwaukee, WI, U.S.A.

Keywords:

Storage area network, authentication, ID based cryptography.

Abstract:

Authentication and access control are important measures for the security of a storage area network (SAN). In

this paper, the current methods of authentication and access control in a SAN are reviewed and a new identity-

based authentication scheme is proposed. This scheme has the advantage that it is lighter weight and more

suited for the high speed switches that operate in a SAN fabric.

1 INTRODUCTION

Storage Area Networks (SANs) are an infrastructure

for data storage solutions. SANs were originally de-

signed for high reliability and security was not a ma-

jor concern. It was felt that the security threat to

a SAN was contained because the components were

concentrated in one physical location that could be

easily secured. With the advent of the internet, there

is an increasing use of SANs with components spread

in diverse locations. Thus, security is now becoming

an issue.

Firewalls provide perimeter security but do not of-

fer internal security. Also, WAN/LAN security does

not help the SAN. In a storage environment, the in-

sider threat is high. Indeed, it is estimated that in the

data center, 70% of security threats are from insiders

(source: Electric Crimes Task Force). There are risks

from snooping, unauthorized access to and modiﬁca-

tion of data, and prevention of legitimate access. At

present, the SAN infrastructure is sufﬁciently compli-

cated that attacks may not be widespread. Security

breaches will become more common as scripts be-

come generally available and as intruders see a higher

reward/(risk of being caught) ratio. This ratio in-

creases dramatically with the connection of SANs to

the internet. Restricting what can be accessed by a

client in a SAN is a common method to provide se-

curity. This can be achieved using zoning and Logi-

cal Unit Number (LUN) Masking. In a FibreChannel

(FC) storage network, zoning divides the members by

port, name, or address and is implemented at the level

of fabric switches. A further restriction of access is

given by LUN Masking, which speciﬁes logical stor-

age units.

However, access control does not address all se-

curity concerns. Other security issues are also of con-

siderable importance, one of them being authentica-

tion. Currently, there are two authentication schemes

used in SANs, namely the Difﬁe- Hellman Challenge-

Handshake Authentication Protocol (DH-CHAP) and

the Fibre Channel Authentication Protocol (FCAP).

The former is based on shared secret (passphrase)

while the latter uses certiﬁcates from Public Key In-

frastructure (PKI). Both methods carry an overhead

that make them impractical in the context of the high-

speed switches that operate in a storage fabric.

In 1984, Shamir (Shamir, 1984) proposed the con-

cept of identity based cryptography. The idea is, in-

stead of using certiﬁcates as in PKI, the users iden-

tiﬁer (such as e-mail address, IP) is used as the pub-

lic key. Therefore, the systems complexity can be re-

duced.

Some ID based signature methods have been pro-

posed some time ago, see (Fiat and Shamir, 1987;

Feige et al., 1988). More recently, two well deﬁned

ID based encryption schemes were suggested (Boneh

and Franklin, 2001; Cocks, 2001). A mathematical

object called pairing is used in the Boneh-Franklin ID

based encryption system. Since then, the construc-

477

Kumar Murty V. and Xu G. (2008).

SECURITY AND AUTHENTICATION FOR NETWORKED STORAGE.

In Proceedings of the International Conference on Security and Cryptography, pages 477-480

DOI: 10.5220/0001927804770480

 SciTePress

tions of ID based cryptography using pairings has be-

come a very active ﬁeld of research. (See for example,

the monograph (Blake et al., 2004).)

In this article, we discuss the application of ID

based methods for SAN security, especially for au-

thentication. Some similar discussion for private area

networks (PANs) can be found in (Garefalakis and

Mitchell, 2002).

The organization of the paper is as follows. In sec-

tion 2, current technologies on SAN authentication

are reviewed. The ID based cryptography is intro-

duced in section 3. We describe authentication based

on the new crypto-methodology in section 4.

2 ACCESS CONTROL AND

AUTHENTICATION

Components of network security include conﬁdential-

ity, data integrity, non-repudiation, and authentica-

tion.

Currently, there are two approaches for SAN

authentication. They are based on shared secret

(passphrase) and certiﬁcates (public key infrastruc-

ture) respectively. It is noted that the former has been

adopted as an ANSI standard. Existing access con-

trols in SANs include zoning and LUN Masking. The

former is an infrastructure level access control, while

the latter is a SCSI access control. Detailed descrip-

tion of these schemes is given below.

2.1 DH-CHAP

DH-CHAP stands for Difﬁe-Hellman Challenge-

Handshake Authentication Protocol and is the current

standard of shared secret approach in SAN.

We ﬁrst describe CHAP–the Challenge-

Handshake Authentication Protocol. Suppose

that we have two characters A and B. A wants to

prove to B that it knows a shared secret K (the

passphrase) without sending the secret in the clear. If

this can be done, then B authenticates A.

The procedure works as follows:

Step 1. A requests inclusion in the network of trust

from a trusted central authority S.

Step 2. S veriﬁes A and with A’s help generates a

password. The password is sent to A and stored

securely in both S and A. All of this is done of-

ﬂine.

Step 3. A requests a service from B that requires

authentication.

Step 4. B sends A a challenge C and session identi-

ﬁer id.

Step 5. A sends B a response R. The computation

of R involves C, id and A’s passphrase K. To be

more speciﬁc, R = H(CkKkid), where H is a hash

function (e.g., SHA-2).

Step 6. Since A’s passphrase is stored in S, a query

(involves R, C, and id) is sent by B to S to verify

the correctness of A’s response R.

Step 7. Once S conﬁrms that R is the correct re-

sponse, B authenticates A.

CHAP as it stands is vulnerable to an off-line dic-

tionary attack. To remedy, it is augmented with a

Difﬁe-Hellman key exchange. The resulting proto-

col is called DH-CHAP. In the Difﬁe-Hellman pro-

tocol, a cyclic group G =< g > of order p is speci-

ﬁed, where p is a large prime number. A generates

a random number x and computes g

, B generates a

random number y and computes g

. Each of them

transmits its result to the other party:

Therefore, both of them can compute g



= (g

)



DH-CHAP integrates the the transmission of g

and g

into the original CHAP. In step 4, B sends

C, id and g

to A, while in step 5, A sends R =

H(idkKkH(Ckg

)) and g

to B. In step 6, B sends

R, id and H(Ckg

) to S for conﬁrmation.

It is noted that this process generates a shared key

as a by-product of authentication. DH-CHAP is

now the ANSI standard for authentication in the SAN

environment. DH-CHAP is stronger but is still vul-

nerable to a combination of an on-line man-in-the-

middle attack and an off-line dictionary attack.

2.2 FCAP

The second approach to authentication is to use cer-

tiﬁcates as in PKI. In this scenario, each entity has

two keys (a public key and a private key). What is

locked by the public key can be unlocked only by the

private key and vice versa. More speciﬁcally, an en-

cryption can be created by a public key, so the private

key is used to decrypt; while a digital signature can

be created using a private key, the public key is for

signature veriﬁcation. PKI is the basis of the Fiber

Channel Authentication Protocol (FCAP).

In PKI, the certiﬁcate authority (CA) issues cer-

tiﬁcates to its clients. A certiﬁcate contains informa-

tion about identiﬁcation of the holder of the certiﬁ-

cate, period of validity of the certiﬁcate, public key of

the holder, and signature of the authority that issued

SECRYPT 2008 - International Conference on Security and Cryptography

478

the certiﬁcate. Other ﬁelds of a certiﬁcate are optional

and can specify the services that a client is eligible for

etc.

A more detailed description of FCAP follows.

Step 1. At set up, A presents its credentials off-line

to the CA and requests a digital certiﬁcate.

Step 2. After the CA veriﬁes the credentials of A, it

issues a certiﬁcate.

Step 3. A sends a signed request for service from B

and includes its certiﬁcate to prove its identity

Step 4. B obtains A’s certiﬁcate and veriﬁes its va-

lidity (by consulting a Certiﬁcate Revocation List

(CRL)).

Step 5. If the certiﬁcate is okay, B uses information

from the certiﬁcate to interpret A’s request.

The advantages of FCAP is it does not require

a shared secret to be established at the outset and

securely stored (as in passphrase systems such as

CHAP). The only secret that has to be centrally safe-

guarded is the private key(s) of the CA. However, in

general, the implementation of PKI carries an over-

head. It needs to maintain a huge database for certiﬁ-

cates. To verify the validity of the certiﬁcate, B has

to consult the CRL (Certiﬁcate Revocation List). In

a storage environment, this could create unacceptable

delays as the high speed storage switches will time

out.

2.3 Zoning and Lun Masking

Zoning is a method by which one can control who

can see what in a SAN. It permits communication

only between deﬁned sets by switching port or by

World Wide Name (WWN) of components. It is im-

plemented at the infrastructure level (switches) and is

protocol independent. Within a zone, the member can

have any-to-any connectivity. Hard zoning deﬁnes a

zone by linking the ports of members. A zone estab-

lished by linking the member’s WWNs is referred to

as soft zoning. It is also desirable to deﬁne zone sets

as small as one can, and disable ports by default.

LUN Masking is a process that makes a LUN

available only to a subset of initiators. It masks off the

LUNs that are not assigned to the application server.

This restricts access even further. LUN Masking is

implemented primarily at end devices and applicable

only to SCSI protocol. Thus, it is another layer of se-

curity above zoning (protocol speciﬁc). In the use of

LUN masking, all access should be disabled by de-

fault. Only initiators that need the logical unit are en-

abled. Multi-pathing should be used. If authorization

types is implemented, they should also be used.

3 ID BASED CRYPTOGRAPHY

The purpose of ID based cryptography is to reduce

the overhead in the traditional PKI. In the ID based

environment, the public key is a string which can be

speciﬁed easily (eg. email address, IP, device identi-

ﬁer, etc.). It can also incorporate a period of validity.

There is a trusted third party in such a system, which

is also referred to as central authority (CA) or private

key generator (PKG).

In the setup stage, the central authority generates a

key pair, the public key pub

and private key priv

They are called the master public key and private key

of the CA.

The following is how the ID based encryption

(IBE) works. If A is intended to send a cipher to B,

it encrypts a plain text K using B’s identiﬁer ID

and

pub

, then transmits the cipher to B. To recover the

plaintext, B obtains its private key priv

(which key

is computed by CA using priv

and ID

) from CA

(if it has not done so), then performs the decryption.

A well-known IBE system was proposed by

Boneh and Franklin (Boneh and Franklin, 2001),

which uses a mathematical structure called the Weil

pairing. Digital signatures can be realized in the ID

based system as well.

If A wants tocreate a signature in ID based setting,

it ﬁrst obtains the private key priv

from CA (if it

has not already done so). Then A signs the message

K using priv

, and sends the signature to B.

B veriﬁes A’s signature using ID

and pub

An example of ID based signature (IBS) scheme is

found in (Cha and Cheon, 2003). In some sense, this

IBS can be regarded as a dual to the IBE in (Boneh

and Franklin, 2001).

Certiﬁcates are eliminated from ID based systems,

it is efﬁcient and easy to use. One of the disadvan-

tages of such systems is that they provide key escrow

since the central authority knows every user’s private

key. Some schemes were proposed to avoid key es-

crow, but they suffer other problems.

4 APPLICATIONS TO SAN

In this section, we propose the use of ID based cryp-

tography in the authentication problem for SANs. It

is parallel to FCAP under PKI, but has the advantage

of being light weight.

Our system contains a central authority (CA) with

a master public key pub

and a master private key

priv

. For each user A, an identiﬁer will be speciﬁed

and denoted by ID

. This is A’s identity which can

be IP address, or device identiﬁer, or WWN, or other

SECURITY AND AUTHENTICATION FOR NETWORKED STORAGE

479

properties of A. ID

is regarded as the public key of

A. The private key privID

of A is obtained as a com-

bination of ID

and the master private key priv

Sometimes it is useful to include other informa-

tion such as key validity period or serial number of a

transaction, in ID

The following routines describe how a user A gets

authenticated by a server B.

Step 1. A asks for its private key (if it has not already

done so) from the CA via secure channel.

Get priv

/.-,()*+

Step 2. A sends a signed request for service from B.

/.-,()*+

Signed request

/.-,()*+

Step 3. B consults a key revocation list to verify that

A’s private key has not been compromised, or the

key has not expired.

/.-,()*+

Is key valid?

Step 4. If the key is okay, B uses A’s public key (i.e.,

ID of A, not a certiﬁcate) to interpret A’s request.

Key is OK!

/.-,()*+

In this setting, identiﬁers are acting as the pub-

lic key. These id’s can be world wide names, which

are easily obtained. Sophisticated certiﬁcates are not

needed. This means that the database for certiﬁcates

and the needs for transmitting certiﬁcates are all elim-

inated. Although we still need central authorities,

their duties are much lighter. The key escrow is an

acceptable (maybe a very useful) feature here. It is

still necessary to consult a key revocation list to en-

sure the validity of the key. The need for this can be

minimized by embedding a period of validity within

the public key. However, this does not address the

issue of malicious users.

Finally, we would like to remark that a signature

scheme, which is not ID based in nature, can be used

in SAN authentication. This is a pairing based (in

elliptic curve cryptography) scheme which was pro-

posed by Boneh, Lynn, and Shacham (Boneh et al.,

2004). The strength of the signature is that its length

is half the size of a DSA signature for a similar level

of security. The authentication can be made more ef-

ﬁcient if this signature is incorporated into FCAP.

5 CONCLUSIONS

In this paper, the security, especially the authentica-

tion, of storage area network is discussed. The new

technology of ID based cryptography is touched on

and its applications to SAN authentication and access

control are proposed.

REFERENCES

Blake, I., Seroussi, G., and Smart, N. (2004). Advances in

Elliptic Curve Cryptography. Cambridge University

Press, London.

Boneh, D. and Franklin, M. (2001). Identity-based encryp-

tion from the weil pairing. In Advances in Cryptology,

Crypt’01, LNCS, vol. 2139, pages 213–239. Springer-

Verlag Heidelberg.

Boneh, D., Shacham, H., and Lynn, B. (2004). Short signa-

tures from the weil pairing. In J. of Cryptology, vol.

17, pages 297–319.

Cha, J. C. and Cheon, J. H. (2003). An identity-based sig-

nature from gap difﬁe-hellman groups. In Public Key

Cryptography, PKC’03, LNCS, vol. 2567, pages 18–

30. Springer-Verlag Heidelberg.

Cocks, C. (2001). An identity based encryption scheme

based on quadratic residues. In Proc. the 8th IMA

International Conference on Cryptography and Cod-

ing, LNCS, vol. 2260, pages 360–363. Springer-Verlag

Heidelberg.

Feige, U., Fiat, A., and Shamir, A. (1988). Zero knowledge

proof of identity. In J. of Cryptology, vol 1, pages 77–

94.

Fiat, A. and Shamir, A. (1987). How to prove your-

self: Practical solutions to identiﬁcation and signa-

ture problems. In Advances in Cryptology, Crypto’86,

LNCS, vol. 263, pages 186–194. Springer-Verlag Hei-

delberg.

Garefalakis, T. and Mitchell, C. (2002). Securing personal

area networks. In 13th IEEE International Symposium

on Personal, Indoor and Mobile Radio Communica-

tions, Lisboa, Portugal, pages 1257–1259.

Shamir, A. (1984). Identity-based cryptosystems and signa-

ture schemes. In Advances in Cryptology, Crypto’84,

LNCS, vol. 196, pages 47–53. Springer-Verlag Heidel-

berg.

SECRYPT 2008 - International Conference on Security and Cryptography

480
