EMOTION ASSESSMENT TOOL FOR HUMAN-MACHINE

INTERFACES

Using EEG Data and Multimedia Stimuli Towards Emotion Classification

Jorge Teixeira, Vasco Vinhas, Luís Paulo Reis and Eugénio Oliveira

FEUP - Faculdade de Engenharia da Universidade do Porto, Rua Dr. Roberto Frias s/n, Porto, Portugal

DEI - Departamento de Engenharia Informática, Rua Dr. Roberto Frias s/n, Porto, Portugal

LIACC - Laboratório de Inteligência Artificial e Ciência de Computadores, Rua do Campo Alegre 823, Porto, Portugal

Keywords: Medical Signal Acquisition, Data Analysis and Processing, Emotion Assessment, Electroencephalography.

Abstract: The identification and assessment of human being emotional states belongs to one of the primordial

objectives of the scientific research in disparate areas such as artificial intelligence, medicine or psychology.

The main objective of this project is related to automatic assessment of a subject’s basic emotional states by

using electroencephalography as a source for biometric data acquisition. This evaluation is based on

predefined mechanisms of emotional induction, as well as specific methods and tools capable of data

analysis and processing. From the experimental results attained in several experimental sessions and

through the support tools developed, the most pertinent conclusion extracted from this work refers to the

capability of effectively performing automatic classification of the subject’s predominant emotional state.

The emotional conditions were induced through the presentation of specific visual multimedia contents. The

success rate of this tool, compared against the self assessment interviews carried out immediately after the

experimental session, was approximately 75%. It was also experimentally concluded that female subjects

are emotionally more demonstrative than the male ones.

1 INTRODUCTION

Emotions play an important role in all human

activities, from the trivial to the most complex ones.

This significance is translated both in terms of

reality perception and even in the cognitive decision

process. Meanwhile, computers have gained such a

relevant presence in the modern society that they

have been introduced in almost every aspect of it,

enhancing the magnitude of ubiquitous computing.

Having these two realities in mind – the

importance of emotional states and the necessity of

daily interaction with multiple devices – merging

them would be a great improvement. By providing

the distributed computer systems with the perception

of their users’ emotions, the applications would be

able to adjust their interface, promote and suggest

functionalities accordingly. It is believed that this

approach would increase the global system’s

transparency and efficiency as its dynamism would

follow in the encounter to user’s intentions and

temper.

Alongside the ubiquitous computing, multimedia

contents are becoming constantly more complex and

seemlier to reality, enabling a greater action

immersion sensation, the primitive absolute need of

achieving a perfect match between audiovisual

contents and the audience desires is still present and

constitutes the main key to the industry success.

The alliance between the multimedia contents

choice possibility that enables the audience to

individually presence what desires and accurate

emotional states detection systems leads to

subconscious individual interaction between the

audience and the multimedia control system,

potentiating the perfect match between content and

individual audience desires.

This study illustrates an application that enables

automatic emotional state assessment using minimal

invasive solutions.

2 METHODOLOGIES

The emotional induction approach defines the

number and main characteristics of the emotional

states that will be reproduced in the subject and it

can be developed through two main different paths.

In order to guarantee the control of the induced

emotions and optimize the biometric device (EEG)

185

Teixeira J., Vinhas V., Paulo Reis L. and Oliveira E. (2008).

EMOTION ASSESSMENT TOOL FOR HUMAN-MACHINE INTERFACES - Using EEG Data and Multimedia Stimuli Towards Emotion Classiﬁcation.

In Proceedings of the International Conference on Signal Processing and Multimedia Applications, pages 185-188

DOI: 10.5220/0001932901850188

 SciTePress

used, the emotions’ induction throw image stimuli is

the most suitable method for this study since its

quality is greater and more realistic than using other

kinds of approaches as audio and video stimuli

(Chanel, 2005). The IAPS library is an indicated

emotional induction method, as it has been widely

used throw the research community with similar

intentions (Aftanas, 2002) (Chanel, 2005) (Müller,

1999). All the pictures are classified according to

their valence, arousal and dominance. The picture

selection was based on the concept that the

detection, post-analysis and interpretation of the

biosignals became more accessible as the pictures

are stratified accordingly to its valance value

(Aftanas, 2006) (Takahashi K., 2004). For these

experimental sessions two discrete emotional states

were studied: joy and sadness. It was added a neutral

state for control purposes.

The demanding task of finding a specific area of

the skull where the brain activity is sufficiently high

to detect oscillations, according to the emotional

state of the subject, undertook significant

improvements with recent studies developed during

the last decade (Chanel et al, 2005)(Aftanas et al,

2006) (Aftanas et al, 2004) (Rusalova et al, 2003)

(Ebrahimi et al, 2003). The emotional induction

produces, in parallel with physiological responses,

individual patterns along brain wave amplitude.

These patterns have been studied and interpreted in

order to locate a suitable position on the human skull

where there are strong evidences between specific

brain waves oscillations and emotional induction.

Accordingly to Aftanas (Aftanas ET AL., 2006),

Frontal and Central areas of the brain are the ones

where is most likely to occur slight changes of the

amplitudes’ brain waves due to emotional states.

In Figure 1 it is depicted the amplitude variations

along all the brain areas for Joy and Anger. By

observing it, it is denoted a higher variation of the

waves’ amplitude in the Frontal-Central and Central

areas for the Anger case. For the Joy case, both

Frontal-Central and Central brain areas have a high

value for the amplitudes’ brain waves variation.

Figure 1: Electrical Brain Activity Variation (Aftanas,

2006).

Before Aftanas’s studies, Damásio concluded

that patients with the ventromedial areas damaged

have significant changes on their emotional

behaviour (Damásio, 1994). In Figure 2, it is

represented the location of the ventromedial areas,

which are integrated in the Frontal-Central and

Central areas of the brain.

Taking in account the two opposite emotional

states, joy and sadness, as well as the physical

limitation of the EEG (one active electrode plus two

references), and based on the studies previously

developed, the most appropriate area of the skull to

locate the active electrode is the middle line,

between the Central and the Frontal area, in the

ventromedial areas.

Figure 2: Ventromedial areas. Adapted (Damásio, 1994).

Apart from the electrode location, special

attention was given to samples choice and these

procedures were carefully followed during the

experimental sessions. For this reason, a subject

exclusion principle was created. Before each

experimental session, a survey had to be filled by the

subject in order to discard eccentric subjects –

epilepsy, alcohol, caffeine, etc. A total of twenty

eight subjects, seventeen males and eleven females,

all right-handed, aged eighteen-thirty years old took

part in this study.

3 RESULTS

The experimental results are presented here, starting

with the achieved results and the proof of the initial

hypothesis.

3.1 Results Achieved

From the experimental sessions conducted two

different kind of results were achieved: the first

belongs to the visual analysis performed and is

based on the pattern-behaviour defined for the high

frequency brain waves; the other concerns to the

results obtained from the application of the EAT to

SIGMAP 2008 - International Conference on Signal Processing and Multimedia Applications

186

the biomatric data captured during the experimental

sessions.

The gathered biometric data showed a high

degree of similarity between the behaviour of the

high frequency brain waves and the hypothesis

previously stated when the predominant emotional

state of the subject is coincident.

Figure 3: Beta wave (a) and Gamma wave (b) comparison

for men and women.

Apart from these results, the comparasion of

men and women brain wave behaviour, presented in

Figure 4, indicates differences in amplitude directly

related with the sex of the subject. The presented

charts were based on the average amplitude of all

subjects, male and female seperatly, for the three

distinct session stages. Through this ilustration, it is

shown a slighty decreasing variation of the average

amplitude along the entire experimental session,

which proves the pattern-behaviour previously

described.

Together with these results, also an amplitude

diference between male and female waves is

presented during the session, with a higher

amplitude for the female behaviour. Based on the

previously described results, as well as the statistical

analysis, the EAT was able to follow the initial

hypothesis. The emotional state decision taken by

the aplicaiton is based on the clusters’ length,

centroides’ value and the respective high frequency

brain wave. Figure 5 represents the cluster analysis

of one experimental session for the Gamma wave.

These results indicate a clear majority of data

associated with the lowest centroide value, and a

small density of data near the high value centroide.

Based on this approach, the emotional state

classification is based on the clusters’ length and its

degree of correlation between each others.

Figure 4: Cluster analysis for the Gamma wave.

3.2 EAT

The Emotion Assessment Tool was developed with

the main intention of evaluating and assessing the

predominant emotional state of the subject that has

been previously induced by some type of multimedia

content. For this specific project, there were studied

two different emotional states plus the neutral one,

so that three clusters were adopted for the statistical

analysis. The integration of this tool in a project with

a bigger scope is suitable and advantageous, since

the number of clusters is dependent on the number

of emotional states to analyse and the specific

multimedia content used for the emotional induction.

Besides the emotion assessment functionality,

this tool also integrates some important features for

data analysis as: plotting the original biometric data

gathered from the EEG; calculate the weighted

means directly from the original signal in intervals

of 5, 10 and 20 seconds, defined by the user; activate

or deactivate the spikes removal technique, affecting

and improving the assessment results for more

unstable experimental sessions. Figure 6 represents

an EAT running screenshot, where the final

conclusion led to a predominant emotional state of

sadness after a decimation of 20 seconds of the load

of raw session data file.

3.3 Success Rate

The performance attained through the application of

the EAT is directly related with the success rate of

the emotional assessment and is a determinant factor

for the verification and validation of this tool for

future work.

Accordingly to Table 1, where the confusion

table is presented, the final rate of success is 74%

and all the failures of the EAT are related with the

sadness emotional state, with low values for the

brain waves amplitude. The application of the EAT

for the automatic assessment was, for one of the

experimental sessions, able to determine the correct

predominant emotional state, which wasn’t possible

through the empirical visual inspection analysis of

the biometric data after processing it.

Due to the processes inherent to the emotional

classification, the decision algorithm needs to check

if both Beta and Gamma brain waves achieve a

similar emotional state. This indicates that the 16%

of failure of the EAT are related to a discrepancy

between the analysis of the Beta and Gamma brain

waves’ behaviour.

EMOTION ASSESSMENT TOOL FOR HUMAN-MACHINE INTERFACES - Using EEG Data and Multimedia Stimuli

Towards Emotion Classification

187

Figure 5: EAT running screenshot.

Table 1: Confusion Table.

EAT

Joy Neutral Sadness

Joy

11%

0% 11%

Neutral 0%

Subject

Sadness 0% 16%

63%

4 CONCLUSIONS

The initial enunciated hypothesis was validated and

the majority of the subjects included in this project

have reacted in a similar way to the multimedia

content presented. Starting with light, enjoyable

contents and finishing with sad ones, it was able to

conclude that the average amplitude of the high

frequency brain waves decreased along the entire

session based on the emotional state induced on the

subject. Secondly, and from the comparison of the

high frequency brain waves average amplitude

between male and female subjects, the females’ one

have a higher amplitude which indicates that they

are more sensible to sad multimedia contents.

In what concerns to the statistical analysis, two

different emotional states – joy and sadness – plus a

neutral one led to the use of three clusters,

characterized by its centroides’ value, the number of

samples included and the degree of correlation

between them. With this approach, the emotion

assessment tool was able to classify the predominant

emotional state, out of three, with an accuracy of

almost 75%. Multiple application domains have

been identified as some interesting applications.. In

this category, one shall consider system adaptations

in order to accommodate psychiatric diagnosis and

treatment procedures, either by simple emotional

state assessment or by complementing this feature

with audiovisual adequate contents. Videogame

related entertainment industry is also a potential

target with the introduction of emotional state

information as an extra variable for game play

enhancement. Another expected adaptation consists

in studying different human activities from the

emotional point of view, and it is believable to be an

important contribute to diverse social sciences.

As a final remark, one shall state that the

presented study achieved to develop an automatic

tool for basic emotional states detection with high

rates of success based on stable methodologies of

emotion induction and data processing and

validation. The used hardware solutions are believed

to be minimal invasive and are not costly which

enables its vast application at a larger scale.

REFERENCES

Aftanas, L. I., el al. 2002. Time-dependent cortical

asymmetries induced by emotional arousal: EEG

analysis of event-related synchronization and

desynchronization on individually defined frequency

bands. International Journal of Phychophysiology, pp.

67-82, nr 44.

Aftanas, L. I., et al. 2004. Analysis of Evoked EEG

Synchronization and Desynchronization in Conditions

of Emotional Activation in Humans: Temporal and

Topographic Characteristics. Neuroscience and

Behavioral Physiology, pp 859-867, vol 34, nr 8.

Aftanas, L. I., et al. 2006. Neurophysiological Correlates

of Induced Discrete Emotions in Humans: An

Individually Oriented Analysis. Neuroscience and

Behavioral Physiology, pp 119-130, vol 36, nr 2.

Chanel, G., et al. 2005. Emotion Assessment: Arousal

Evaluation using EEG's and Peripheral Physiological

Signals. University of Geneva, Switzerland: Computer

Science Department, pp 530-537, vol 4105/2006.

Damásio, A. R. 1994. Descartes error: Emotion, reason

and human brain. Europa-América.

Ebrahimi, T., et al. 2003. Brain Computer Interface in

Multimedia Communication. IEEE Signal Processing

Magazine, pp 14-24, vol 20, issue 1.

Rusalova, M. N., et al. 2003. Spatial Distribution of

Coefficients of Asymmetry of Brain Bioelectrical

Activity during the Experiencing of Negative

Emotions. Neuroscience and Behavioral Physiology,

pp 703-706, vol 33, nr 7.

SIGMAP 2008 - International Conference on Signal Processing and Multimedia Applications

188
