JAVA-C++ BRIDGE FOR SYMBIAN BASED SMARTPHONES

Bal´azs Goldschmidt, Gerg˝o Gy´an´o and Zolt´an L´aszl´o

Department of Control Engineering and Information Technology

Budapest University of Technology and Economics

Magyar tud´osok krt 2, Budapest, Hungary

Keywords:

Symbian, smartphone, j2me.

Abstract:

Authors propose a simple framework in order to help smartphone developers gain both from the advantages

of J2ME and C++ in Symbian OS. The idea is that while JNI is not supported by J2ME, with the help of the

built-in networking support a daemon written in C++ can serve as a function-provider in cases when problems

with pure J2ME features can not be solved.

1 INTRODUCTION

The penetration of mobile phones is continuously in-

creasing. In 2006 more than 30 countries passed

100% penetration.(Wallace, 2006) The proportion of

smartphones among recent buyers in 2006 was 8.8%

in Western Europe.(Telephia, 2006; m:metrics, 2007)

The major advantage of smartphones is that new

applications can be installed on them after the device

has been released and sold. In a wide range of devices

the newapplicationscan be Java midlets(J2ME, 2002)

or native applications. The beneﬁt is obvious: at pur-

chase time the phones don’t have to have all possible

applications installed on them, it is the customer who

can install new software later.

When developing a mobile application, the devel-

oper has to choose an implementation basis (J2ME or

native OS). The most widespread native platform is

Symbian(Symbian, 2005) that is supported by major

smartphone manufacturers. This is why authors fo-

cused their attention on this platform alone.

J2ME is a well-deﬁned subset of Java SE that is

supported by smartphones. The phones usually pro-

vide a virtual machine (KVM), that runs the Java ap-

plications, while different speciﬁcations describe fur-

ther support like the use of bluetooth, etc.

Advantages of developing J2ME applications are

(1) wide acceptance: most newly released mobile

phones support J2ME, (2) gradual learning curve and

ease of use: programmers with knowledge of Java

standard edition can easily learn the speciﬁcs and spe-

cialties of J2ME, and can easily develop and deploy

J2ME midlets.

The disadvantage of J2ME applications is their

limited access to native resources. Although a lot

of JSR-s are speciﬁed for accessing native resources

(bluetooth, calendar and ﬁles, SMS, etc), only a few

of these speciﬁcations are implemented in different

phones (for Nokia phone capabilities see ﬁgure 1).

Symbian platform provides an OS and runtime en-

vironment for applications usually written in C++.

The advantages of developing applications for this

platform are (1) wide acceptance: many smartphones

that allow consumers to install new software on them

run a version of Symbian; (2) low level access to

system resources: when writing native applications,

the programmer is allowed to access the phone’s re-

sources – like communication stacks, calendar entries

and ﬁles, etc. – directly.

The disadvantages if this platform include (1) a

steep learning curve: learning to develop Symbian

applications even for programmers with ﬁrm C++

knowledge is hard. To get accustomed to the devel-

opment process, to conforming special requirements,

etc. need lots of training and effort. (2) Difﬁcult de-

velopment: the development process of Symbian ap-

plications needs signiﬁcantly greater effort than that

of J2ME.

Authors motivation was to make it possible to

combine the advantages of both platforms. Let the

241

Goldschmidt B., Gyánó G. and László Z. (2008).

JAVA-C++ BRIDGE FOR SYMBIAN BASED SMARTPHONES.

In Proceedings of the International Conference on Wireless Information Networks and Systems, pages 241-244

DOI: 10.5220/0002027402410244

 SciTePress

JSR API description

75 File & PIM

172 Web services

177 Security and Trust Services

179 Location

180 SIP

234 Advanced Multimedia Supplements

248 Mobile Service Architecture for CLDC

JSR 5320 6212 6600 N90

N82 N70

E51

75 • • • •

172 • • •

177 • •

179 •

180 •

234 • •

248 •

Figure 1: JSR support of selected Nokia smartphones. JSR-

s supported by all phone types are not shown here. (Source:

http://www.forum.nokia.com).

developers write the major part of an application in

Java, and implement only speciﬁc parts C++, parts

that need features not supported by J2ME or the JSRs

implemented in smartphones.

In order to combine the advantages of the two

platforms, however, the usual method used in J2SE,

where the necessary native code based modules can

be inserted into Java applications using Java native in-

terface (JNI, 2003; Liang, 1999), can not be applied,

because J2ME doesn’t support JNI at all. It was also

not an option for authors to create a new J2ME vir-

tual machine that supports such native codes. The in-

tention was to ﬁnd a solution that is standards-based,

portable and easy-to-use.

The basic idea is to create a simple C++ applica-

tion, a daemon, that provides the necessary functions,

and which can be accessed over TCP/IP by the Java

applications that need the functionality.

2 GENERAL ARCHITECTURE

2.1 Major Modules

The general architecture of the framework can be seen

on ﬁgure 2. It consists of the following major mod-

ules:

• C++ Daemon. Generated by the framework. This

module hosts the C++ function skeleton that im-

plements the necessary functionality. The module

KVM

Symbian OS

SmartPhone

C++ Daemon

Skeleton

Java Midlet

Java Stub

Figure 2: The general architecture of the framework.

Legend: italic: to be implemented by programmer, bold:

generated by framework, roman: shipped with smartphone.

accepts TCP/IP client connections, and calls the

required functions.

• Java Function Stub. Generated by the frame-

work. This function can be called from the Java

midlet, handles serialization, connects the C++

daemon, and returns the values passed back by the

daemon.

• C++ Function Skeleton. Implemented by the de-

veloper. It gets the serialized parameters passed

over TCP/IP, performs the necessary functional-

ity, and returns the result.

• Java Midlet. The Java midlet that performs some

task that depends on a functionality provided by

the C++ daemon. It is implemented by the devel-

oper.

2.2 Communication

The general communication scenario is the following:

1. Midlet needs a functionality provided by the dae-

mon. Calls the function of Stub (e.g. add(3, 5)).

2. Stub serializes parameters into a string, opens a

TCP/IP connection to the daemon, sends the op-

eration id and the parameters as character stream,

then waits for the return values.

3. Daemon accepts the connection, reads operation

id and parameters, calls the skeleton assigned to

the operation id, and passes parameters.

4. Skeleton deserializes the parameter values from

the character stream, then performs its task.

5. Daemon serializes the return value into a string,

and sends it to Stub.

WINSYS 2008 - International Conference on Wireless Information Networks and Systems

242

6. Stub receives the data, and deserializes the return

value and returns it to the caller Midlet. TCP/IP

connection is closed.

2.3 Protocol

The protocol of parameter-passing during the TCP/IP

communication is a simple string-based data-transfer.

Currently only integers, doubles and arrays of integers

or doubles are supported.

sending operation id and parameters uses this

form:

where

is the operation id coded as an integer,

and

values

is the parameters. Both serialized as

follows.

sending an integer or double uses this form:

<L>:<V>

where

<L>

stands for the length of variable,

stands for the value of variable.

Eg.:

3:1234:45.6

→ values sent: 123 and 45.6.

sending array of integers or doubles uses this

form:

where

LLA

stands for the length of the integer de-

scribing the length of the array,

stands for the

length of the array.

Eg.:

1:23:1233:456

→ array of two elements

sent: (123, 456)

3 EXAMPLE APPLICATION

In this section a simple example is shown. The task

is to create a function that is passed two integers, and

returns the sum of them. The Java Stub on the client

side looks like this:

public int

add(

int

b) {

ClientCommunication c =

new

ClientCommunication ();

c.setCommand(F_ADD);

c.add(a);

c.add(b);

(!c.communicate ())

return

Integer.MIN_VALUE;

return

c.getInt();

}

• The constructor of ClientCommunication initial-

izes variables and the input and output character-

streams.

• The function setCommand() sets the command

parameter to F

ADD, a constant that is deﬁned on

both sides of the communication.

• The function add() adds the parameters to the

character-stream that is to be sent to the C++ dae-

mon.

• The function communicate() sends the character-

stream to the daemon and receives the return val-

ues, which are then put into the output character-

stream. If the communication fails, it returns

false.

• The function getInt() retrieves an integer from the

output character-stream set by communicate().

The function is implemented in the skeleton (C++

server side) as follows:

// reads in two integers

// and returns their sum

void

CSRemoteFunctions ::add() {

TInt ia = getInt();

TInt ib = getInt();

TInt ret = ia+ib;

addInt(ret);

}

Function

add()

is accessed through an array of

function-pointers. After implementing the function it

has to be put into this array:

#define

F_ADD 0

#define

F_SUB 1

#define

F_SUM 2

...

void

CSRemoteFunctions ::ConstructL() {

funcArray[F_ADD] =

&CSRemoteFunctions ::add;

funcArray[F_SUB] =

&CSRemoteFunctions ::sub;

funcArray[F_SUM] =

&CSRemoteFunctions ::arraysum;

...

}

When the daemon receives the client connection

and reads in the function id, it calls the respective

function, and the return value is converted back to

string format and sent back to the Java stub.

4 FRAMEWORK API

The functions needed to implement the Java stub are

collected in class ClientCommunication. The class

provides the following public methods. XXX stands

for Int or Double, xxx stands for int or double.

• ClientCommunication() Constructor. Initializes

the input-output streams.

JAVA-C++ BRIDGE FOR SYMBIAN BASED SMARTPHONES

243

• void add(xxx i) Adds an integer or a double to the

values sent to the daemon.

• void add(xxx[] array) Adds an array of integers

or doubles to the values sent to the daemon.

• xxx getXXX() Retrieves an integer or double from

the return values.

• xxx[] getXXXArray() Retrieves an array of inte-

gers or doubles from the return values.

• void setCommand(int cmd) Sets the identiﬁer of

the command to be called on the daemon’s side.

• boolean communicate() Opens the network con-

nection, sends the parameters, reads return values,

and closes the connection.

The following functions can be used during C++

skeleton implementation:

• TXXX CSRemoteFunctions::getXXX()

Reads an integer or double value from the input

stream that was received from the Java Stub.

• CArrayFixFlat<TXXX>* CSRemoteFunc-

tions::getXXXArray()

Reads an array of integers or doubles from the in-

put stream that was received from the Java Stub.

• void CSRemoteFunctions::addXXX (TXXX x)

Writes an integer/double to the output stream that

will be sent to the Java Stub.

• void CSRemoteFunctions::addXXXArray

(CArrayFixFlat<TXXX>* array)

Writes an integer/double array to the output

stream that will be sent to the Java Stub.

5 MEASUREMENTS

Tests were conducted to measure the overhead of the

function call in the framework between the Java stub

and C++ skeleton. For the test the add function intro-

duced above was used. It was called 1000 times from

a J2ME midlet. The function was also implemented

in Java for control purposes. The smartphone used in

the tests was a Nokia N90.

The results show that the average execution time

was 78.53ms when the connection was not opened for

each call, 105.33ms when for each call a new con-

nection was established, and 0.014ms when the Java

implementation of the function was called.

The measurements show that the overhead of the

network communication is considerable. Still, au-

thors are convinced that for numerous problems the

idea proposed offers the only solution.

6 SUMMARY AND FURTHER

WORK

Authors proposed a simple framework in order to help

smartphone developers gain both from the advantages

of J2ME and C++ in Symbian OS. The idea is that

while JNI is not supported by J2ME, with the help of

the built-in networking support a daemon written in

C++ can serve as a function-provider in cases when

problems with pure J2ME features can not be solved.

The results described in the paper are preliminary.

Authors consider the following the major focal points

in further development.

Adding more parameter types. The current set of

parameter types (int, double, and their arrays) is insuf-

ﬁcient. Authors plan to support more primitive types

(boolean, char, byte), as well as compound types (like

structs in IDL).

Automated skeleton and stub generation. Cur-

rently all code is written by the developer. In the near

future authors will develop an simpliﬁed IDL-like lan-

guage for specifying the functions, and a simple com-

piler that generates both C++ skeleton code and Java

stub code.

Protocol revision. The protocol currently used has

to be revised regarding efﬁciency and fault-tolerance.

Performance measurements. It has to be mea-

sured how the framework performs in different cir-

cumstances.

REFERENCES

J2ME (2002). Java 2 Micro Edition. http://www.jcp.org/en/

jsr/detail?id=68.

JNI (2003). Java Native Interface Speciﬁcation.

http://java.sun.com/javase/6/docs/technotes/guides/

jni/spec/jniTOC.html.

Liang, S. (1999). The Java Native Interface Programmer’s

Guide and Speciﬁcation. Prentice Hall PTR.

m:metrics (2007). Mobile market measures.

http://images.servicesmobiles.fr/press/passport-

sping2007.pdf.

Symbian (2005). Symbian OS. http://www.symbian.com/.

Telephia (2006). Americans lag behind europeans in smart-

phone adoption.

Wallace, B. (2006). 30 countries passed 100% mobile

phone penetration in q1. Telecommunications Online.

WINSYS 2008 - International Conference on Wireless Information Networks and Systems

244
