HOW MUCH SEQUENCE IDENTITY GUARANTEE GOOD

MODELS IN HOMOLOGY MODELING

Proteins from Serine Protease Family as a Test Case?

Jamal Riayn and Anwar Rayan

QRC-Qasemi Research Center, Al-Qasemi Academic College, P.O.B. 124, Baka El-Garbiah 30100, Israel

Keywords: Homology/comparative modeling, 3D-structure prediction, multiple sequence alignment.

Abstract: Homology modelling is utilized to predict the 3-D structure of a given protein (target) based on its sequence

alignment to a protein whose structure (template) has been experimentally determined. The use of such

technique is already rewarding and increasingly widespread in

biological research and drug

development. The accuracy of the predictions as commonly accepted is dependent on the score of

target protein - template sequence identity. Given the sequence identity score of pairs of proteins,

certain questions are raised as to whether we can assess or quantitate the quality of the obtained

model. Also, whether we should choose, the protein with the highest sequence identity as a

template. The answer to these questions is critical since only with such determinations, we could

decide how to choose the template and to which usage the model is reliable.

We intend in the

paper to assess the accuracy of sequence identity-based homology modeling by analyzing a

database of 4560 pair-wise sequence and structural alignments. The decision making process

regarding to which parts of the known protein to perform structural alignment is not trivial and

clearer rules should be extracted.

1 INTRODUCTION

The 3D structure determination of a certain protein

greatly helps unravelling its function and binding

mechanisms. Such structural information can also

aids in designing experiments in mutagenesis and

even utilized for structure-guided drug development

or virtual screening

. Since experimental structures

are available only for a small number of sequenced

proteins, alternative strategies are required to predict

reliable models for protein structures when X-ray

diffraction or NMR are not yet available

. Among

the different strategies currently used for

constructing 3-dimensional structures of certain

proteins, we shall find the homology modeling

(termed also as comparative modeling) as the most

accurate method among the computational methods,

yielding reliable models. Another approach termed

“ab-initio” modeling, is not practical yet for the

construction of reliable models

. According to the

state of art, a three dimensional template is chosen

by virtue of having the highest level of sequence

identity with the target sequence, and similar

secondary and tertiary structure (belongs to the same

"fold"). Baker and Sali

have shown that a homology

model for a protein at medium size at least and with

sequence identity of less than 30% to the template

crystal structure is unreliable. The rule of =>30% of

sequence identity score does not specify how

identity should be distributed along a sequence. The

quality of the models obtained by comparative

modeling is mostly quantitated by the root mean

square deviation of the backbone atoms or the

positions of alpha carbons (termed Cα RMSD)

between model and experimental structure. A model

can be considered 'accurate’ or ‘reliable’ model

when its RMSD is within certain spread of

deviations. How big is this spread?

The comparative modeling procedure for

developing a three-dimensional model from a

protein sequence based on the structure of

homologous protein is built generally from few

steps: after identifying the homologous protein and

performing optimal sequence alignment (based on

score of identity or similarity), the structurally

conserved regions (SCRs) are identified and

coordinates for the core of the models are generated.

Following the core generation, one predicts the

455

Raiyn J. and Rayan A. (2009).

HOW MUCH SEQUENCE IDENTITY GUARANTEE GOOD MODELS IN HOMOLOGY MODELING - Proteins from Serine Protease Family as a Test

Case?.

In Proceedings of the International Conference on Bio-inspired Systems and Signal Processing, pages 455-458

DOI: 10.5220/0001379204550458

 SciTePress

conformations of the structurally variable regions

(termed loops) and adds the side chains. Some

approaches, align multiple known structures firstly,

then, identifying structurally conserved regions to

construct an average structure, for modeling these

regions of the inquiry protein.

In this communication, we analyze a database of

pairs of proteins, sequence and structurally aligned

and raised few questions:

i. Can we predict the accuracy of the modelled

structure based on sequence identity score?

ii. When the selection of the protein with highest

identity score is justified?

iii. Can we formulate a set of rules for homology

modeling?

1.1 Materials and Methods

More than 124 unique homologs of the serine

protease family of proteins that have sequence

identity below 99% were downloaded from the

Brookhaven Protein Databank (PDB). Then, IMSA -

Intelligent Multiple Sequence Alignment

(in-house

software based on the Intelligent Learning Engine

(ILE) optimization technology) was utilized to

optimally align the whole set of all sequences.

Sequence identity score was calculated for each pair

of sequences. All residues from the multiple

sequence alignment were found only on 96 proteins

(see table 1). Other proteins lack coordinates of one

residue at least in their 3D structures. The alpha

carbons for residues of selected proteins were

extracted from the PDB structures and structurally

superimposed.

The quality of the models obtained by homology

modeling is quantitated with the Cα RMSD between

model and experimental structure. We have defined

'highly accurate’ model as one having <=2 Å RMSD

from the experimentally determined structure, while

models having Cα RMSD above this threshold and

<=4 Å were termed “reliable” models which could

fit for designing mutagenesis experiments but not

drug design and binding affinity tests. BioLib was

used for performing structural alignment and for

computing the Cα RMSD (BioLib is an open-

environment developing toolkit developed by

BioLog Technologies Ltd.).

The multiple sequence alignment matrix

obtained from running our in-house software on the

selected database of serine proteases, was processed

as described below, in order to specify which parts

of the whole set of sequences to select for homology

modeling. We use a “voting” approach, in which

each amino acid contributes to the conservation at a

sequence position according to its frequency in that

particular position (see equation 1). These

frequencies are measured in all sequences of the

database.

%100∗=

(1)

is thus the conservation factor for residue type i

at sequence position j.

is the number of

sequences, which have amino acid i at position j of

the multiple alignment, and k is the total number of

sequences in the database.

Table 1: PDB codes of 96 serine proteases (the first four

letters are the code of the protein in the PDB while the last

letter is the chain ID).

1AMHA 1ANB0 1ANC0 1AND0 1BRBE

1CO7E 1DPO0 1F7ZA 1SLUB 1SLWB

3TGJE 1QL9A 1J16A 1TRMA 1EZSC

1F5RA 1FY8E 3TGKE 1AN1E 1MCTA

1S83A 1TAWA 1UTNA 1OPHB 1V2OT

1V2QT 1V2RT 1V2ST 1V2WT 1V2NT

1V2LT 1H4WA 1TRNA 1UTMA 1HJ8A

1MBQA 1BIT0 1A0JA 1DX5M 1JOUB

1RD3B 1THPB 1C5LH 1H8DH 2THFB

1H8IH 1B7XB 1BTHH 1TQ7B 1SHHB

1VR1H 1UCYK 1EUFA 1FI8A 1PJPA

1NN6A 1KLT0 1IAUA 1GVKB 1HAXB

1QNJA 1BRUP 1DST0 1BIO0 1RFNA

1PFXC 1A0LA 1CGHA 1FXYA 1LO6A

1G2LA 1FAXA 1LTOA 1TON0 1NPMA

1MZAA 3RP2A 1AO5A 1KLIH 1KIGH

1AZZA 1EAXA 1GVZA 1PYTD 1OP8A

1ORFA 1RTFB 1AUTC 1P57B 1FIZA

1FIWA 1BQYA 1A5IA 1MD8A 1EQ9A

1EKBB

2 RESULTS AND DISCUSSION

In this study, we aim to assess models obtained by

homology protein modeling by looking on a large

set of sequence/structure alignments that belong to

the same protein family (adopt the same “fold”). We

have used in-house software for multiple sequence

alignment and the regions for model construction

(firstly using all the Cα atoms of the 160 common

residues and at the second time, we chose for model

construction SCRs based on the structural analysis

of one protein (1A0JA), see figure 1. The pair-wise

sequence alignments in our database ranges between

28% and 100%.

Sequence analysis of the database revealed

highly conserved amino acids that where distributed

along the protein chain (see figure 1, number of

BIOSIGNALS 2009 - International Conference on Bio-inspired Systems and Signal Processing

456

amino acids found above certain conservation

thresholds, and see table 2, residues with

conservation threshold above 95% as an example).

We expect that those residues in there spatial

coordinates play important role in the protein

function and/or in stabilizing the protein folding (or

conformation). Thus, the inter-residue distance

matrix should be somehow similar in each protein.

This could be assessed qualitatively by extracting

those residues from the x-ray structures of the

proteins and performing pair-wise superposition. As

depicted in table 3, the Cα RMS deviation is very

low in average in all pairs. These results reveal the

correctness of the multiple sequence alignment and

could be used in model refinement of serine

proteases. The averaged root mean square coordinate

deviation correlates well with the percentage identity

within the highly conserved residues with

correlation coefficient of 0.9695. 4560 models of

proteins were generated and as depicted on figure 2,

when the sequence identity with the template is

>60%, the constructed model is always highly

accurate, while when the sequence identity is less

than 50% models based on templates with sequence

identity less than protein with the highest score

should be assessed. We have reached the same

conclusion when analysing parts of the proteins

including variable regions (loops). Since the

methods for predicting the loop conformations and

not yet highly accurate, we should model them based

on the template structure in certain circumstances.

For all 160 residues in our multiple sequence

alignment models, we have computed the sequence

identity percentage between target and template

sequences and the RMSD of the models from their

corresponding experimental template. Although the

stretches of the models contain large parts from the

variable regions, we have obtained mostly reliable

models.

Mostly, models of secondary structure segments

that where built based on templates which share any

degree of sequence identity (> 28%) with the target

are highly accurate (table 3) and seem to be useful

for drug design and docking experiments. However,

when the degree of sequence identity is lower

than 50%, the best template to thread on is not

always the one with the highest identity score.

Other templates should be evaluated in order to get

more accurate models. We obtain higher percentage

of accuracy when we chose the best structured

protein to be used as a template, perform the correct

alignment and choose the correct stretches to

remodel. One of the major contributors to the

models inaccuracy could be performing the

wrong threading. Position conservation threshold

may be used for further refinement of the model

applying molecular dynamics (MD), simulated

annealing (SA), iterative stochastic elimination

(ISE) or other optimization approaches

Conservation ratio (160 residue positions sequence

aligned in 98 serine proteases)

= 0.9829

100

50 60 70 80 90 100

Positional identity percentage threshold

Conserved residues

Figure 1: Analysis of positional conservations in the

sequences of 96 unique serine proteases. Each protein has

160 residues and the multiple sequence alignment was

performed without gaps.

Table 2: Positional Conservation Threshold (PCT)

calculated according to equation 1.

PCT* Average RMSD Median

Standard

Deviation

100 0.503 0.463 0.219

95 0.631 0.486 0.387

90 0.621 0.497 0.361

85 0.609 0.492 0.342

80 0.704 0.577 0.368

75 0.757 0.702 0.361

70 0.812 0.822 0.362

65 0.862 0.898 0.372

60 0.894 0.920 0.405

55 0.936 0.979 0.405

50 0.990 1.059 0.408

* Position Conservation Threshold – the residue should be

conserved above this threshold in the certain position.

3 CONCLUSIONS

We present in this paper, sequence and structural

analysis of 4560 pairs of proteins and raise few

questions regarding the homology modeling

procedure. In view of the data above, the most

important question was whether the sequence

HOW MUCH SEQUENCE IDENTITY GUARANTEE GOOD MODELS IN HOMOLOGY MODELING - Proteins from

Serine Protease Family as a Test Case?

457

Table 3: Probabilities of modeling approach accuracy for

target-template identity classes in serine protease family.

Secondary structure segments were used for Root Mean

Square Deviation (RMSD) measurements.

Percent

sequence

identity

Total

number

models

Percent

models

with

RMSD <

1 Å

Percent

models

with

RMSD < 2

Percent

models

with

RMSD <

3 Å

25-29 15 40 100 100

30-39 883 28 98 100

40-49 2365 50 99.9 100

50-59 423 75 100 100

60-69 51 90 100 100

70-79 181 100 100 100

80-89 289 100 100 100

90-95 44 100 100 100

α: Sequence identity range between target and template.

β: Total number of models in any given sequence identity range.

The table summarises 4251 model – template pairs.

π: Percent of models, in a given sequence identity range, deviates

by 1 Å or less from the corresponding experimental control

structure. The following columns provide these percantages for

other RMS deviations.

Figure 2: This plot describe the relationship between

RMSD and sequence identity percentage. We can

discriminate easily between surely good models when the

sequence identity is above 50-60% and models with high

uncertaintity when the sequence identity is less than 50%.

Each model contain all 160 residues.

identity score against all experimentally determined

structures of proteins will alone assist (or be

sufficient) in deciding which protein to use as the

template for the homology modeling and how to

improve the threading process. The results revealed

that when

the sequence identity with the template is

>60%, it is justified to select the protein with the

highest score as a template. While, when the

sequence identity is less than <50%, we should

select more than one template for assessing.

Alignment based on analysis of large database of

certain fold could give better results than those

obtained by optimized pair-wise alignment. Further

research and analysis of databases of proteins which

belong to other folds may aid us in formulating

clearer rules for the homology modeling process. As

well, usage of position conservation threshold in

model refinement is recommended and is currently

under evaluation in our lab.

REFERENCES

Patny A., Desai P.V., Avery M.A., 2006. Current

Medicinal Chemistry, 13(14), 1667-91

Eszter H., Zsolt B., 2008. Journal of Structural Biology,

162, 63-74

Baker D., Sali A., 2001. Science 294 (5540), 93-96

Rayan A.M., Raiyn J.A., 2008. Intelligent Learning

Engine (ILE) Optimization Technology, Provisional

Rayan A., Noy E., Chema D., Levitzki A., Goldblum A.,

2004. Current Medicinal Chemistry, 11, 675-692.

Sequence Identity versus RMS Deviation

(Secondary-structure based on 1aoj [code in

PDB])

20 40 60 80 100

Sequence Identity

RMSD

BIOSIGNALS 2009 - International Conference on Bio-inspired Systems and Signal Processing

458
