DISTRIBUTED LEARNING ALGORITHM BASED ON DATA

REDUCTION

Ireneusz Czarnowski and Piotr Je¸drzejowicz

Department of Information Systems, Gdynia Maritime University, Morska 83, 81-225 Gdynia, Poland

Keywords:

Distributed data mining, Distributed learning classiﬁers, Data reduction, Agent-based approach.

Abstract:

The paper presents an approach to learning classiﬁers from distributed data, based on a data reduction at

a local level. In such case, the aim of data reduction is to obtain a compact representation of distributed

data repositories, that include non-redundant information in the form of so-called prototypes. In the paper

data reduction is carried out by simultaneously selecting instances and features, ﬁnally producing prototypes

which do not have to be homogenous and can include different sets of features. From these prototypes the

global classiﬁer based on a feature voting is constructed. To evaluate and compare the proposed approach

computational experiment was carried out. The experiment results indicate that data reduction at the local

level and next merger of prototypes into the global classiﬁer can produce very good classiﬁcation results.

1 INTRODUCTION

Usually data mining algorithms base on the assump-

tion that all the training data can be pooled together

in a centralized data repository. In the real life there

are, however, numerous cases where the data have to

be physically distributed due to some constraints (for

example, data privacy or others).

Applying traditional data mining tools to discover

knowledge from distributed data sources may not be

possible (Kargupta et al., 1999). In the real life it is of-

ten unrealistic or unfeasible to collect distributed data

for centralized processing. The need to extract po-

tentially useful patterns out of separated, distributed

data sources created a new, important and challenging

research area, known as the distributed data mining

or knowledge discovery from multi-databases (Xiao-

Feng Zhang et al., 2004).

Recently, several approaches to distributed clas-

siﬁcation have been proposed. In (Prodromidis et

al., 2000) a meta-learning process was proposed as

a learning tool for combining a set of locally learned

classiﬁers into the global classiﬁer. Meta-learning in-

volves running, possibly in parallel, learning algo-

rithms for each distributed database or set of data

subsets from an original database, and than combin-

ing predictions from classiﬁers learned from the dis-

tributed sources by recursively learning ”combiner”

and ”arbiter” models in a bottom-up tree manner.

Generally, meta-learning methodologies view data

distribution as a technical issue and treat distributed

data sources as parts of a single database. It was

pointed out in (Tsoumakas et al., 2004) that such an

approachoffers rather a narrowviewof the distributed

data mining, since the data distributions in different

locations often are not identical, and is considered as

sub-optimal heuristic.

Tsoumakas et al. (2004) proposed approach based

on clustering local classiﬁer models induced at phys-

ically distributed databases. This approach groups to-

gether classiﬁers with their similar behavior and with

ﬁnal indication of a classiﬁcation model for each clus-

ter that together guarantees a better results than the

single global model. This approach belongs to the

set of methods based on common methodology for

distributed data mining known as a two-stage (Xiao-

Feng Zhang et al., 2004).

Generally, two-stage methods base on extraction

of prototypes from distributed data sources. The ﬁrst

stage involves the local data analysis, the second com-

bines or aggregates the local results producing the

global classiﬁer.

Another two-stage approach to confront the dis-

cussed problem is to move all data from distributed

repositories to a central location and to merge the data

together for a global model building. Such approach

escapes the sub-optimality problems of local models

combination as it was pointed out by Tsoumakas et

198

Czarnowski I. and JÄ

Zdrzejowicz P. (2009).

DISTRIBUTED LEARNING ALGORITHM BASED ON DATA REDUCTION.

In Proceedings of the International Conference on Agents and Artiﬁcial Intelligence, pages 198-203

DOI: 10.5220/0001655401980203

 SciTePress

al. (2004). However, moving all data into a central-

ized location can be limited by communication band-

width among sites and may be too expensive. Select-

ing out of the distributed databases only the relevant

data can eliminate or reduce the above restriction. Se-

lection of relevant data at local sites can also speed up

the data transfer for centralized learning and global

knowledge extraction. Selection of relevant data is

very often referred to as data reduction with the objec-

tive to ﬁnd patterns, called prototypes, references vec-

tors, or regularities within certain attributes (see e.g.,

Liu et al., 1998). Generally, the goal of data reduc-

tion approaches is to reduce the number of instances

in each of the distributed data subsets without loss

of extractable information, to enable either pooling

the data together and using some mono-database min-

ing tools or effectively applying meta-learning tech-

niques. Learning models based on the reduced data

sets combined later into a meta-model seems to be

one of the most successful current approaches to dis-

tributed data mining (Stolfo et al., 1997). Learning

classiﬁers on the reduced data sets and then combin-

ing them is computationally much more efﬁcient then

moving all distributed data sets into a centralized site

for learning a global model.

The paper deals with a distributed learning clas-

siﬁer. The proposed approach involves two stages.

At the local level the prototype selection from dis-

tributed data is carried out. Prototypes are selected

by simultaneously reducing data set in two dimen-

sions through selecting reference instances and re-

moving irrelevant attributes. The prototype selection

proposed in this paper is an extension of the approach

introduced by Czarnowski and Je¸drzejowicz (2008a),

where instance reduction only was proposed. In the

present approach the data reduction scheme is car-

ried out independently at each site through applying

an agent-based population search. Thus obtained pro-

totypes do not have to be homogenous and can be

based on different sets of of features. Next, at the

second stage, the prototypes are merged at the global

level and classiﬁer models are combined to produce a

meta-classiﬁer called combiner.

The paper is organized as follows. Section 2 con-

tains problem formulation and provides basic deﬁni-

tions. Section 3 explains the proposed agent-based

population learning algorithm, that has been used for

reducing distributed data sets, and provides details

on how the combiner classiﬁer is constructed. Sec-

tion 4 contains results of the computational experi-

ment carried out with a view to validate the proposed

approach. Finally, the last section contains conclu-

sions and suggestions for future research.

2 DEFINITIONS AND PROBLEM

FORMULATION

The problem of learning from data can be formulated

as follows: Given a data set D, a set of hypothesis H,

a performance criterion P, the learning algorithm L

outputs a hypothesis h ∈ H that optimize P. In pattern

classiﬁcation application, h is a classiﬁer. The data

D consists of N training examples. Each example is

described by a set of attributes A and is labeled with

a class. The total number of attributes is equal to n.

The goal of learning is to produce a hypothesis that

optimizes the performance criterion (e.g. function of

accuracy of classiﬁcation, complexity of the hypothe-

sis, classiﬁcation cost or classiﬁcation error).

In the distributed learning a data set D is dis-

tributed among K data sources D

, . . . , D

, with

, . . . , N

respectively, where

∑

i=1

= N and where

all attributes are presented at each location. In the dis-

tributed learning a set of constraints Z can be imposed

on the learner. Such constraints may for example pro-

hibit transferring data from separated sites to the cen-

tral location, or impose a physical limit on the amount

of information that can be moved, or impose other re-

strictions to preserve data privacy. The task of the

distributed learner L

is to output a hypothesis h ∈ H

optimizing P using operations allowed by Z.

In case of using prototypes as suggested in this

paper, the data sources D

, . . . , D

are replaced by re-

duced subsets S

, . . . , S

of local patterns, which in

general are heterogeneous. In this case A

, . . . , A

are sets of attributes from sites 1, . . . , K respectively.

However, it is possible that some attributes can be

shared across more then one reduced data set S

where i = 1, . . . , K.

Thus, the goal of data reduction is to ﬁnd subset

from given D

by reducing of number of exam-

ples or/and feature selection and with retaining essen-

tially extractable knowledge and preserving the qual-

ity of data mining results. Let the cardinality of the

reduced data set S

be denoted as card(S

). Then the

following inequality holds card(S

) < card(D

). Sim-

ilarly, when the cardinality of the set of attributes A

is denoted as card(A

), the following inequality holds

card(A

) < card(A). Ideally card(A

) ≪ card(A). It

is expected that the data reduction results in data com-

pression. The instance reduction compression rate C

is deﬁned asC

∑

k=1

card(S

)

. The attribute selection

compression rate C

is deﬁned as C

card(

i=1

)

Overall, data reduction guarantees total compression

equal to C = C

DISTRIBUTED LEARNING ALGORITHM BASED ON DATA REDUCTION

199

3 AN AGENT-BASED APPROACH

TO LEARNING CLASSIFIER

FROM DISTRIBUTED DATA

3.1 Main Features of the Proposed

Approach

It is well known that instance reduction, feature selec-

tion and also learning classiﬁer from distributed data

are computationally difﬁcult combinatorial problems

(Dash and Liu, 1997; Rozsypal and Kubat, 2003).

Although a variety of data reduction methods have

been so far proposed in the literature (see, for exam-

ple Dash and Liu, 1997; Raman and Ioerger, 2003,

Rozsypal and Kubat, 2003; Skalak, 1994; Vucetic and

Obradovic, 2000), no single approach can be consid-

ered as superior nor guaranteeing satisfactory results

in the process of learning classiﬁers.

To overcome some of the difﬁculties posed by

computational complexity of the distributed data

reduction problem it is proposed to apply the

population-based approach with optimization proce-

dures implementedas an asynchronousteam of agents

(A-Team). The A-Team concept was originally intro-

duced by Talukdar et al. (1996). The design of the

A-Team architecture was motivated by other archi-

tectures used for optimization including blackboard

systems and genetic algorithms. Within the A-Team

multiple agents achieve an implicit cooperation by

sharing a population of solutions, also called individ-

uals, to the problem to be solved. An A-Team can be

also deﬁned as a set of agents and a set of memories,

forming a network in which every agent remains in a

closed loop. All the agents can work asynchronously

and in parallel. Agents cooperate to construct, ﬁnd

and improve solutions which are read from the shared,

common memory.

In our case the shared memory is used to store a

population of solutions to the data reduction problem.

Each solution is represented by the set of prototypes

i.e. by the compact representation of the data set from

given local level. The team of agents is used to ﬁnd

the best solution at the local level and them the agent

responsible for managing all stages of the data mining

is activated.

3.2 Solution Representation

Population of solutions to data reduction problem

consists of feasible solutions. A feasible solution s,

corresponding to the set of selected data, is repre-

sented by a string consisting of numbers of selected

reference instances and numbers of selected features.

The ﬁrst t numbers represent instance numbers from

the reduced data set D

, where t is determined by a

number of clusters of potential reference instances.

The value of t is calculated at the initial popula-

tion generation phase, where at ﬁrst, for each in-

stance from original set, the value of its similarity co-

efﬁcient, proposed by Czarnowski and Je¸drzejowicz

(2004), is calculated, and then instances with identi-

cal values of this coefﬁcient are grouped into clusters.

The second part of the string representing a feasible

solution consists of numbers of the selected features.

The minimum number of features is equal to one.

3.3 Agents Responsible for Data

Reduction

Data reduction is carried out, in parallel, for each dis-

tributed data site. Data reduction, carried-out at a data

site, is an independent process which can be seen as

a part of the distributed data learning. Each data re-

duction subproblem is solved by two main types of

agents. The ﬁrst one - optimizing agents, are imple-

mentations of the improvement algorithms, each op-

timizing agent represents a single improvement algo-

rithm. The second one, called the solution manager,

is responsible for managing the population of solu-

tions and updating individuals in the population. Each

solution manager is also responsible for ﬁnding the

best solution for the given learning classiﬁer subprob-

lem.

The solution manager manages the population of

solutions, which at the initial phase is generated ran-

domly and stored in the shared memory. When the

initial population of solutions is generated the solu-

tion manager runs a procedure producing clusters of

potential reference instances. Next the solution man-

ager continues reading individuals (solutions) from

the common memory and storing them back after

attempted improvement until a stopping criterion is

met. During this process the solution manager keeps

sending single individuals (solutions) from the com-

mon memory to optimizing agents. Solutions for-

warded to optimizing agents for improvement are ran-

domly drawn by the solution manager. Each optimiz-

ing agent tries to improvequality of the received solu-

tions and afterwards sends them back to the solution

manager, which, in turn, updates common memory

by replacing a randomly selected individual with the

improved one.

To solve the data reduction problem four types

of optimizing agents representing different improve-

ment procedures, proposed earlier by Czarnowski and

Je¸drzejowicz (2008b) for the non-distributed case,

have been implemented.

ICAART 2009 - International Conference on Agents and Artificial Intelligence

200

These procedures include: local search with tabu

list for instance selection, simple local search for in-

stance selection, local search with tabu list for feature

selection and hybrid local search for instance and fea-

ture selection, where the both parts of the solution are

modiﬁed with the identical probability equal to 0.5.

In each of the above cases the modiﬁed solution

replaces the current one if it is evaluated as a better

one. Evaluation of the solution is done by estimat-

ing classiﬁcation accuracy of the classiﬁer, which is

created taking into account the instances and features

indicated by the solution. In all cases the constructed

classiﬁer is based on the C 4.5 algorithm (Quinlan,

1993).

If, during the search, an agent successfully has

improved the received solution then it stops and

the improved solution is transmitted to the solution

manager. Otherwise, agents stop searching for an

improvement after having completed the prescribed

number of iterations.

3.4 Agent Responsible for Managing

the Process of Distributed Learning

The proposed approach deals with several data reduc-

tion subproblems solved in parallel. The process is

managed by the global manager, which is activated

as the ﬁrst within the learning process. This agent is

responsible for managing all stages of the data min-

ing. At the ﬁrst step the global manager reads the dis-

tributed data mining task that should be solved. Than

global manager runs, in parallel, all subtasks, that

correspond to independent learning classiﬁers prob-

lem.

When all the subtasks have been solved, solutions

from the local level are used to obtain a global solu-

tion. Thus, the global manager merges local solutions

and ﬁnally produces the global classiﬁer, called also

meta-classiﬁer.

To compute the meta-classiﬁer a combiner strat-

egy based on voting mechanism has been applied.

This combiner strategy is used to obtain a global clas-

siﬁer from the global set of prototypes. The global set

of prototypes is created by integration of local level

solutions representing heterogeneous sets of proto-

types. To integrate local level solutions it has been de-

cided to use the unanimous voting mechanism. Only

features that were selected by data reduction algo-

rithms from all distributed sites are retained and the

global classiﬁer is formed based on the C 4.5 algo-

rithm.

4 COMPUTATIONAL

EXPERIMENT RESULTS

To validate the proposed approach computational ex-

periment has been carried out. The aim of the ex-

periments was to evaluate to what extend the pro-

posed approach could contribute towards increasing

classiﬁcation accuracy of the global classiﬁer induced

on the set of prototypes selected from autonomous

distributed sites by applying an agent-based popula-

tion learning algorithm. Classiﬁcation accuracy of the

global classiﬁers obtained using the set of prototypes

has been compared with the results obtained by pool-

ing together all instances from distributed databases,

without data reduction, into the centralized database

and with results obtained by pooling together in-

stances selected from distributed databases based on

the reduction of example space only. Generalization

accuracy has been used as the performance criterion.

The experiment involved three data sets - cus-

tomer (24000 instances, 36 attributes, 2 classes), adult

(30162, 14, 2) and waveform (30000, 21, 2). For

the ﬁrst two datasets the best known and reported

classiﬁcation accuracies are respectively 75.53% and

84.46%. These results have been obtained from

(Asuncion and Newman, 2007) and (”The European

Network”, 2002). The reported computational exper-

iment was based on the ten cross validation approach.

At ﬁrst the available datasets were randomly divided

into the training and test sets in approximately 9/10

and 1/10 proportions. The second step involved the

random partition of the previously generated training

sets into the training subsets each representing a dif-

ferent dataset placed in a separate location. Next,

each of the obtained datasets has been reduced us-

ing the agent-based population algorithm. The re-

duced subsets have been then used to compute the

global classiﬁer using the proposed combiner strat-

egy. Such scheme was repeated ten times, using a dif-

ferent dataset partitions as the test set for each trial.

Computations have been run with the size of ini-

tial population set to 50. A number of repetitions for

each improvement procedure was set to 100.

The above described experiment has been re-

peated four times for the four different partitions of

the training set into a multi-database. The original

data set was randomly partitioned into 2, 3, 4 and 5

multi-datasets of approximately similar size. The re-

spective experiment results are shown in Table 1. The

results cover two independent cases. In the ﬁrst case

only reference instance selection at the local level has

been carried out, and next the global classiﬁer has

been computed based on the homogenous set of pro-

totypes. In the second case full data reduction at the

DISTRIBUTED LEARNING ALGORITHM BASED ON DATA REDUCTION

201

Table 1: Average classiﬁcation accuracy (%) obtained by the C 4.5 algorithm and its standard deviation.

number of distributed data sources

Problem 2 3 4 5

Selection of reference instances at the local level only

customer 68.45±0.98 70.40±0.76 74.67±2.12 75.21±0.7

adult 86.20 ±0.67 87.20±0.45 86.81±0.51 87.10±0.32

waveform 75.52±0.72 77.61±0.87 78.32±0.45 80.67±0.7

Combiner strategy based on the feature voting

customer 69.10 ±0.63 73.43 ±0.72 75.35 ±0.53 77.20 ±0.49

adult 88.90 ±0.41 87.45 ±0.31 91.13 ±0.23 91.58 ±0.41

waveform 80.12 ±1.03 82.46 ±0.98 85.04±0.73 83.84±0.64

local level has been carried out and the global clas-

siﬁer has been computed by the combiner strategy

based on the feature voting.

Table 2: Compression ratio versus the number of distributed

data sources.

number of distributed data sources

Problem 2 3 4 5

192.9 124.1 100.5 88.2

customer C

1.9 1.6 1.8 1.6

C 357.9 196.0 177.3 140.4

79.6 68.0 60.7 52.7

adult C

1.2 1.4 1.3 1.2

C 98.6 98.2 81.0 62.5

56.5 51.8 46.7 39.7

waveform C

1.3 1.4 1.2 1.3

C 71.0 73.2 56.0 52.1

It should be noted that data reduction in two di-

mensions (selection of reference instances and fea-

ture selection) assures better results in comparison to

data reduction only in one dimension i.e. instance

dimension. The approach to learning classiﬁer from

distributed data, based on data reduction at the local

level, produces reasonable to very good results. The

data reduction at the local level resulted in both: a

very good accuracy of classiﬁcation, better then for

”full dataset” (calculated though pooling at the global

level all instances from local levels), and a very high

data compression rate (see, for example, Table 2).

5 CONCLUSIONS

The paper presents an approach to learning classiﬁers

from distributed data, based on a data reduction at the

local level. At the global level the combiner classi-

ﬁer with feature selection through majority voting has

been constructed and implemented. Computational

experiment carried out has shown that the proposed

approach can signiﬁcantly increase classiﬁcation ac-

curacy as compared with learning classiﬁers using

centralized data pool. An extensive compression of

the dataset size at the global level and parallel compu-

tations at distributed locations are additional features

increasing the efﬁciency of the approach.

Computational experiment results conﬁrmed that

the global classiﬁer based on data reduction at the lo-

cal level can produce very good results. However, the

quality of results depends on the choice of strategy

used for constructing the combiner.

Future work will focus on evaluating other com-

biner classiﬁer strategies in terms of classiﬁcation ac-

curacy and computation costs.

ACKNOWLEDGEMENTS

This research has been supported by the Polish Min-

istry of Science and Higher Education with grant for

years 2008-2010.

REFERENCES

Asuncion, A., Newman, D.J. (2007).

UCI Machine Learning Repository

(http://www.ics.uci.edu/ mlearn/MLRepository.html).

ICAART 2009 - International Conference on Agents and Artificial Intelligence

202

Irvine, CA: University of California, School of

Information and Computer Science.

Czarnowski, I., Je¸drzejowicz, P. (2004) An approach to

instance reduction in supervised learning. In: Co-

enen F., Preece A. and Macintosh A. (Eds.), Research

and Development in Intelligent Systems XX, Proc. of

AI2003, the Twenty-third SGAI International Confer-

ence on Innovative Techniques and Applications of

Artiﬁcial Intelligence, Springer-Verlag London Lim-

ited, 267-282.

Czarnowski, I., Je¸drzejowicz, P., Wierzbowska, I. (2008a)

An A-Team Approach to Learning Classiﬁers from

Distributed Data Sources. In: Ngoc Thanh Nguyen,

Geun Sik Jo, Robert J. Howlett,an Lakhmi C. Jain

(Eds.), KES-AMSTA 2008, Lecture Notes in Com-

puter Science, LNAI 4953, Springer-Verlag Berlin

Heidelberg, 536-546

Czarnowski, I., Je¸drzejowicz, P. (2008b) Data Reduction

Algorithm for Machine Learning and Data Mining.

In: Nguyen N.T. et al. (eds) IEA/AIE 2008, Lecture

Notes in Computer Science, LNAI 5027, Springer-

Verlag Berlin Heidelberg, 276-285.

Dash, M., & Liu H. (1997). Feature selection for classiﬁca-

tion. Intelligence Data Analysis 1(3), 131-156.

Kargupta, H., Byung-Hoon Park, Daryl Hershberger, &

Johnson, E. (1999). Collective Data Mining: A New

Perspective Toward Distributed Data Analysis. In Kar-

gupta H and Chan P (Eds.), Advances in Distributed

Data Mining. AAAI/MIT Press, 133-184.

Liu, H., Lu, H., & Yao, J. (1998). Identifying Relevant

Databases for Multidatabase Mining. In Proceedings

of Paciﬁc-Asia Conference on Knowledge Discovery

and Data Mining, 210-221.

Prodromidis, A., Chan, P.K., & Stolfo, S.J. (2000). Meta-

learning in Distributed Data Mining Systems: Issues

and Approaches. In H. Kargupta and P. Chan (Eds.)

Advances in Distributed and Parallel Knowledge Dis-

covery, AAAI/MIT Press, Chapter 3.

Raman, B., & Ioerger, T.R. (2003). Enhancing learning us-

ing feature and example selection. Journal of Machine

Learning Research (in press)

Rozsypal, A., & Kubat, M. (2003). Selecting Representa-

tive Examples and Attributes by a Genetic Algorithm.

Intelligent Data Analysis, 7(4), 291-304.

Quinlan, J.R. (1993). C4.5: programs for machine learning.

Morgan Kaufmann, SanMateo, CA.

Skalak, D.B. (1994). Prototype and Feature Selection by

Sampling and Random Mutation Hill Climbing Algo-

rithm. Procciding of the International Conference on

Machine Learning, 293-301.

Stolfo, S., Prodromidis, A.L., Tselepis, S., Lee, W., & Fan.

D.W. (1997). JAM: Java Agents for Meta-Learning

over Distributed Databases. In Proceedings of the 3rd

International Conference on Knowledge Discovery

and Data Mining, Newport Beach, CA, AAAI Press,

74-81.

Talukdar, S., Baerentzen, L., Gove, A., & P. de Souza

(1996). Asynchronous Teams: Co-operation Schemes

for Autonomous. Computer-Based Agents, Technical

Report EDRC 18-59-96, Carnegie Mellon University,

Pittsburgh.

The European Network of Excellence on Intelligence Tech-

nologies for Smart Adaptive Systems (EUNITE) -

EUNITE World Competition in domain of Intelligent

Technologies (2002). Accesed on 1 September 2002

from http://neuron.tuke.sk/competition2.

Tsoumakas, G., Angelis, L., & Vlahavas, I. (2004). Cluster-

ing Classiﬁers for Knowledge Discovery from Phys-

ical Distributed Database. Data & Knowledge Engi-

neering, 49(3), 223-242.

Xiao-Feng Zhang, Chank-Man Lam, & William K. Che-

ung (2004). Mining Local Data Sources For Learn-

ing Global Cluster Model Via Local Model Exchange.

IEEE Intelligence Informatics Bulletine, Vol. 4, No. 2.

Vucetic, S., & Obradovic, Z. (2000). Performance Con-

trolled Data Reduction for Knowledge Discovery in

Distributed Databases, Procciding of the Paciﬁc-Asia

Conference on Knowledge Discovery and Data Min-

ing, 29-39.

DISTRIBUTED LEARNING ALGORITHM BASED ON DATA REDUCTION

203
