TOWARDS AN INTEGRATIVE METHODOLOGY

FOR DEVELOPING MULTI-AGENT SYSTEMS

José M. Gascueña and Antonio Fernández-Caballero

Universidad de Castilla-La Mancha, Escuela Politécnica Superior de Albacete

Instituto de Investigación en Informática de Albacete, 02071-Albacete, Spain

Keywords: Multi-agent systems, Agent development methodologies.

Abstract: A great number of methodologies to develop MAS systems have been proposed in the last few years. But, a

perfect methodology that satisfies all the developer necessities can not be found. This is the reason why

different methodologies are studied to create a new one. In this article, a methodology that includes all steps

from the capture of requirements to the implementation and deployment of an agent-based application is

proposed. In first place, an Analysis Overview Diagram is created to obtain an initial sketch of the

application. Afterwards, the model obtained - by following the two first stages proposed by Prometheus

methodology - is integrated into INGENIAS through UML-AT language. Next, the modelling goes on with

INGENIAS. Finally, code is generated for the ICARO-T platform.

1 INTRODUCTION

Multi-agent systems (MAS) technology is adequate

for developing open, complex, and distributed

systems, and they offer a natural way of operating

with legacy systems (Jennings & Wooldridge,

1995). A great number of methodologies to develop

MAS systems have been proposed in the last few

years. Gaia, Tropos, MaSE, MESSAGE,

Prometheus, and INGENIAS are just a few

examples.

Nonetheless, a perfect methodology that satisfies

all the developer necessities can not be found.

Usually, techniques and tools proposed in different

methodologies to provide a solution to the specific

problem that is being approached are combined. The

result is a new methodology fruit of combining

several proposals of the analyzed methodologies. In

fact, in the literature, methodologies can be found

that are influenced by other methodologies that

already were proposed previously. For instance,

INGENIAS (Pavón, Gómez-Sanz & Fuentes, 2005)

together with a methodology to model real-time

behaviors were adopted to define a MAS

methodology for Holonic Manufacturing Systems

(Giret, Botti & Valero, 2005).

In this article, INGENIAS is chosen as the basis,

due to its recent direction towards model-driven

development (MDD) (Pavón, Gómez-Sanz &

Fuentes, 2006) in order to define a new methodology

to develop MAS. But, the two first stages proposed

in Prometheus (Padgham & Winikoff, 2004),

namely system specification and architectural

design, are previously integrated in order to solve

some current deficiencies in INGENIAS (see section

2). The language used by Prometheus is diffeerent

from the INGENIAS language. Therefore, in order

to use INGENIAS, it is necessary to transform the

model obtained with Prometheus into an equivalent

INGENIAS model. This transformation is performed

with language UML-AT (Fuentes, Gómez-Sanz &

Pavón, 2006), (Fuentes, Gómez-Sanz & Pavón,

2007). Later we propose to continue modelling with

INGENIAS. Finally, code is generated for the

ICARO-T platform (Garijo et. al, 2004), (Garijo et.

al, 2008). The result of using the mentioned

technologies, Prometheus, INGENIAS, UML-AT

and ICARO-T, turns into a new methodology to

develop MAS. The process followed in the

methodology assists the MAS developer from the

capture of requirements to the implementation and

deployment of the application.

The article structure is as follows. Section 2

describes the contributions made by INGENIAS and

the deficiencies that it presents. Methodologies

Prometheus and INGENIAS, as well as the tools that

support them, are compared in section 3. In section 4

392

Gascueña J. and Fernández-Caballero A. (2009).

TOWARDS AN INTEGRATIVE METHODOLOGY FOR DEVELOPING MULTI-AGENT SYSTEMS.

In Proceedings of the International Conference on Agents and Artiﬁcial Intelligence, pages 392-399

DOI: 10.5220/0001658203920399

 SciTePress

the phases of the integrative methodology to develop

MAS are proposed and described. Finally, some

conclusions are offered.

2 WHY STARTING WITH

INGENIAS?

In the initial INGENIAS proposal (Pavón, Gómez-

Sanz & Fuentes, 2005) there are several

contributions to develop MAS. First, it offers a

meta-model to specify MAS. A MAS is considered

from five complementary viewpoints: organization,

agent, goals and tasks, interaction, and environment.

Second, it adopts the unified software development

process (USDP) (Jacobson, Booch & Rumbaugh,

1999) as a guideline to define the steps necessary to

develop the elements and diagrams of MAS during

the analysis and design phases. Third, INGENIAS

Development Kit (IDK) is a tool that supports the

methodology. IDK has integrated a set of utilities

that allow model edition, verification, validation,

and automatically generate code and documentation.

Now, INGENIAS is being reformulated in terms

of the MDD paradigm (Pavón, Gómez-Sanz &

Fuentes, 2006). Nowadays the use of model-driven

engineering (MDE) techniques along the life cycle

of software development is gaining more and more

interest (Schmidt, 2006). The key idea underlying

this paradigm is that if the development is guided by

models there will be important benefits in

fundamental aspects such as productivity,

portability, interoperability and maintenance.

Therefore, in the MAS field, it seems quite useful to

use a methodology such as INGENIAS, which

supports this approach. There are some other works

using MDE in the area of MAS (Perini & Susi,

2005), (Rougemaille et. al, 2007), (Jarraya &

Guessoum, 2007), among others.

Indeed, there are other reasons for studying the

methodology INGENIAS and the tools created

around. The INGENIAS engineer, connoisseur of

the INGENIAS meta-model, can (a) define the meta-

model for the domain of a concrete application, (b)

personalize the IDK for a specific application

domain, and, (c) create transformations to generate

source code for the final platform on which the

agents will run. There exist some previous

experiences to adapt the INGENIAS language to

more specific systems. For example, the IDK

framework has been used to construct an editor for

Holonic Manufacturing Systems (Giret, Botti &

Valero, 2005). Also the INGENIAS language has

been adapted for social simulation environments

(Sansores, Pavón & Gómez-Sanz, 2004).

Unfortunately, in our opinion, the process

followed in INGENIAS during the analysis and

design phases of MAS is very complex and difficult

to understand, because it is not clear how the

different models are being constructed along the

phases, despite the documented general guidelines.

Moreover, INGENIAS does not provide any

mechanism to discover which will be the agents of

the system and their interactions. Thus, it is

necessary to raise a process of alternative

development that makes system development

simpler. In order to make the MAS methodology

easy to use for non expert people in the development

of such systems, it is necessary that it offers a

collection of detailed guidelines, including examples

and heuristics, which help better understanding what

is required in each step of the development process

used in the methodology. These guidelines also

serve as a help to the experts in MAS development.

They will be able to transmit their experience to

other users explaining why and how they have

obtained the different elements (agents, interactions,

etc.) of the agent-based application.

3 COMPARISON

INGENIAS has several advantages as opposed to

Prometheus (see Table 1): (a) it follows an MDD

approach, (b) it facilitates a general process to

transform the models generated during the design

phase into executable code. The advantages of

Prometheus can be used (following the process to

discover which be the agents of the system and its

interactions) to enhance INGENIAS. In Table 2 the

Prometheus Design Tool (PDT) (Padgham,

Thangarajah & Paul) and INGENIAS Development

Kit (IDK) (Gómez Sanz & Pavón) tools are

compared. It may be observed that PDT only has

one advantage with respect to IDK: it has a

mechanism to prioritize parts of a project. In the rest

of considered characteristics, IDK equals or

surpasses PDT. Thus, the tool used to support the

new methodology proposed is IDK as it is

independent from the development process and it

may be personalized for the application under

development.

TOWARDS AN INTEGRATIVE METHODOLOGY FOR DEVELOPING MULTI-AGENT SYSTEMS

393

Table 1: Comparing Prometheus and INGENIAS.

Prometheus INGENIAS

Proper development process YES NO: Based in the USDP (analysis

and design phases)

General process to generate code

from the models

NO: Only obtains code for

JACK language

YES: Based in template

definitions

Iterative development process YES YES

Model-driven development (MDD) NO: Only proposes a

correspondence between design

models and JACK code

YES

Requirements capture YES: A version of KAOS is

used to describe the system's

goals (van Lamsweerde, 2001)

complemented with the

description of scenarios that

illustrate the operation of the

system. In addition, in

(Cysneiros & Zisman, 2004)

guidelines appear to generate

the artefacts of the Prometheus

system specification from

organizational models

expressed in i*

YES: Performed by means of use

case diagrams. Then, use cases are

associated to system goals, and a

goals analysis is performed to

decompose them into easier ones;

and finally tasks are associated to

get the easiest goals

Meta-model YES (Dam, Winikoff &

Padgham, 2006)

YES

Mechanisms to discover agents and

interactions among agents

YES: Groups functionalities

through cohesion and coupling

criteria.

Agent model BDI-like agents Agents with mental states

Figure 1: Mapping Prometheus into INGENIAS.

ICAART 2009 - International Conference on Agents and Artificial Intelligence

394

Table 2: Comparing PDT and IDK.

PDT IDK

Supported methodology Prometheus INGENIAS

Interface references the

development process

YES: Diagrams are grouped in

three levels according to the

three Prometheus phases

NO: Possibility to create packets that

correspond to the diverse phases of

the process. Models of each phase

are added to the corresponding

packet

Mechanisms to prioritize parts of

the project.

YES: Three scope levels

(essential, conditional and

optional) (Perepletchikov &

Padgham, 2005)

Code generation YES: JACK http://www.agent-

software.com/

YES: JADE http://jade.tilab.com/

Report generation of the MAS

specification in HTML

YES YES

Model fragmenting in various

pieces

NO: For instance, only one

diagram may be created to in

order to gather all the

objectives of the system

YES

Save a diagram as an image YES YES

Deployment diagrams NO YES

Agent communication Defined in basis of messages

and interaction protocols. Does

not use a specific

communication language. For

JACK, there is a module

compliant with FIPA

(Yoshimur, 2003).

Defined in accordance with

communication acts of the agent

communication language (ACL)

proposed by FIPA

http://www.fipa.org/specs/fipa00061/

Utility to simulate MAS

specifications before generating

the final code

NO YES: Realized on the JADE

platform. It is possible to manage

interaction and tasks, and to inspect

and modify the agents' mental states

4 PHASES OF THE NEW

METHODOLOGY

First Phase. In the first stage of the methodology

proposed an analysis overview diagram is created.

This diagram is used to develop a high level view of

the system requirements. This diagram will specify,

in main lines, which are the actors - entities (human

or software/hardware) external to the system – that

interact with our system, where the perceptions that

enter the system come from, which are the responses

of the system (actions), an initial proposal of which

might be the system roles, what messages are sent,

and some used data. This kind of diagram appeared

for the first time in PDT version 2.5.

Second Phase. Prometheus defines a proper

detailed process to specify, implement and

test/debug agent-oriented software systems. This

process incorporates three phases: (1) system

specification identifies the basic goals and

functionalities of the system, develops the use case

scenarios that illustrate the functioning of the

system, and specifies which are the inputs (percepts)

and outputs (actions); (2) architectural design uses

the outputs produced in the previous phase to

determine the agent types that exist in the system

and how they interact; and, (3) detailed design

TOWARDS AN INTEGRATIVE METHODOLOGY FOR DEVELOPING MULTI-AGENT SYSTEMS

395

centres on developing the internal structure of each

agent and how each agent will perform its tasks

within the global system. Finally, Prometheus details

how to obtain the implementation in the agent-

oriented programming language JACK.

The two first phases proposed in Prometheus

(system specification and architectural design) are

used to be the next phase of the new integrative

methodology. The user identifies the agents and

their interactions following the guidelines offered by

Prometheus in these phases. In general terms, the

mechanism provided by Prometheus to identify

agents consists in identifying the goals during the

system specification phase, and then in grouping the

goals to obtain functionalities. Next, in the

architectural design phase, functionalities are

grouped to obtain the system agents, using cohesion

and coupling criteria to decide which the best

groupings are. These two concepts are essential in

Software Engineering to obtain a good software

development (the one that has maximum cohesion

and minimum coupling) and to ease its further

maintenance. Thus, the MAS developer gets an

initial model according to Prometheus, following its

two first stages (system specification and

architectural design).

Afterwards, mappings are used to obtain an

equivalent model in INGENIAS. From this point on

the advantages offered by model-driven software

development are used. The mappings are defined

leaning in an intermediate language denominated

Unified Modelling Language for Activity Theory

(UML-AT) (Fuentes, Gómez-Sanz & Pavón, 2007).

UML-AT allows establishing bidirectional

transformations between models of different

languages. There exists a previous experience in

integrating two methodologies, Tropos and

INGENIAS, using UML-AT (Fuentes, Gómez-Sanz

& Pavón, 2006).

The process of transforming Prometheus into

INGENIAS methodology elements, with the help of

intermediate language UML-AT, is shown in Figure

1. In first place (process 1), we start from the

Prometheus meta-model specified with language

GOPRR (Graph Object Property Relationship Role)

(Lyytinen & Rossi, 1999). Translation rules to

obtain elements, expressed in UML-AT language,

equivalent to the ones selected in Prometheus, are

created and used. Next (process 2), translation rules

are used to obtain the specification in INGENIAS

equivalent to the one obtained in UML-AT

language. The Repository of Translations contains

tuples indicating the matches and instantiation

functions used in the translation, as well as the

elements participating in it (either used in the

process or created as a result of it) and an identifier

of the specification to which each one belongs to.

A match represents the translation between two

sets of structures, the source pattern (it is described

in the source language) and the target pattern (it is

described in the target language). An instantiation

function describes the correspondence of the

variables in the source patterns with the elements in

the current specifications according to the matching

that is presented.

ATLAS Transformation Language (ATL)

(Bézivin, Jouault & Touzet, 2005), a model

transformation language compliant with the OMG

MOF/QVT (Queries / Views /Transformation), can

be used as an alternative to approach the problem of

transforming Prometheus to INGENIAS. A meta-

model and a model expressed in original language

(in this case, Prometheus), a destination meta-model

(in this case, INGENIAS) and rules defined with

ATL to perform the transformation are needed in

this case. The result is a destination model

(INGENIAS, in this case) equivalent to the original

model. The meta-models and models can be defined

in Ecore, the language used by Eclipse Modelling

Framework (EMF). The INGENIAS meta-model,

defined initially in GOPRR, has been migrated to

Ecore (García-Magariño, Gómez-Sanz & Pavón,

2007). Thus, it is only necessary to define: (1) the

Prometheus meta-model with Ecore, and, (2) the

transformation rules in ATL. We have decided to

use UML-AT because it is a technology related to

the research group that has developed INGENIAS.

In addition, it supposes the same service load as

using ATL: to define a meta-model (for Prometheus

in GOPRR) and translation rules (to transform a

Prometheus specification into a UML-AT

specification). The corresponding part to transform

UML-AT into INGENIAS is solved in (Fuentes,

Gómez-Sanz & Pavón, 2007). A tool called Activity

Theory Assistant (ATA) has been developed to help

using the techniques based on the theory of the

activity and to support the translation process. ATA

is embedded in a plug-in of the IDK. Notice,

however, that the current IDK version available in

SourceForge,

http://sourceforge.net/projects/ingenias,

does not include it.

In Prometheus, in order to describe the

interactions among agents, interaction protocols

using a reviewed version of Agent UML (AUML)

denominated AUML-2 are developed. UML-AT has

already been applied to establish correspondences

between FIPA protocols designed with AUML

ICAART 2009 - International Conference on Agents and Artificial Intelligence

396

models (Bauer & Odell, 2005) and INGENIAS

models (Fuentes, Gómez-Sanz & Pavón, 2007).

This work is taken as the starting point to

transform interaction protocols obtained with

Prometheus into the equivalent notation used in

INGENIAS. The IDK tool, which provides support

to INGENIAS, allows representing protocols

according to the AUML annotation (Gómez Sanz &

Pavón). This means that the interaction protocols

created with Prometheus could be used directly in

INGENIAS, with no need to use any transformation.

Nevertheless, its development has not evolved

enough. In fact, in version 2.6 of the IDK this utility

no longer appears.

Third Phase. The new methodology does not

reuse the last phase of Prometheus (detailed design)

because it is too much centred in BDI-like agents.

Moreover, Prometheus also describes how the

obtained entities are transformed in the design phase

into the concepts used for a specific implementation

language (JACK). These two aspects, centring in a

single type of agent and defining a mechanism to

generate code for a particular implementation

language, suppose, in principle, a loss of generality.

In the new methodology, once the equivalent model

in INGENIAS has been obtained, the architecture of

each type of identified agent is provided. The

possible types of agents are the ones available in

ICARO-T: cognitive agents and reactive agents. In

this phase the necessary guidelines for completing

all the INGENIAS models already exist.

Fourth Phase. With respect to code generation,

the INGENIAS proposal is followed. INGENIAS

generalizes a process to transform the models,

generated in the phase of design, in running code for

any destination platform (Pavón, Gómez-Sanz &

Fuentes, 2006). It is based in the definition of

templates for each destination platform and

procedures for extracting information present in the

models. Once the code has been obtained, the

developer refines the resulting code completing any

information that was not contained in the

specifications (models) or in the templates. Finally,

the application is deployed.

ICARO-T is the platform selected for running

the agents (Garijo et. al, 2004), (Garijo et. al, 2008).

It offers four categories of reusable component

models: agent organization models to describe the

overall structure of the system, agent models,

resource models to encapsulate computing entities

providing services to agents, and basic computing

entities.

There are several reasons for selecting the multi-

agent platform ICARO-T. The use of its components

has allowed to significantly reducing time and effort

in the design and implementation phases by an

average of a 65 percent. In the phases of testing and

correction cycles the errors are also reduced.

Consequently, the applications require less resources

and lower implementation time (Pavón, Garijo &

Gómez-Sanz, 2007). The ICARO-T components

have been used in telecommunications company

Telefonica for developing several voice recognition

services. At the moment, it is also being used by

other research teams. This is the case, for example,

in an e-learning project denominated ENLACE

(Celorrio & Verdejo, 2007).

Figure 2 shows the technology and tools used in

the integrative methodology proposed.

5 CONCLUSIONS AND FUTURE

WORK

The combination of current technologies

(Prometheus, INGENIAS, UML-AT and ICARO-T)

has given rise to a new integrative methodology for

the development of agent-based systems. It uses the

guidelines offered by Prometheus to identify agents

and their interactions. Later, the obtained model,

following Prometheus methodology, is transformed

into INGENIAS to continue the development. This

transformation is performed under UML-AT. Once

modelling has ended up, code is generated for the

ICARO-T platform.

In order to use this methodology definitively it is

necessary: (1) to specify the Prometheus meta-model

in GOPRR, (2) to create the rules to translate

Prometheus concepts in UML-AT language, and, (3)

to define templates for the IDK to generate code for

the ICARO-T platform. A first proposal in order to

transform Prometheus models into equivalent

INGENIAS models using an informal language has

recently been considered (Gascueña & Fernández-

Caballero, 2008).

ACKNOWLEDGEMENTS

This work is supported in part by the Spanish

Ministerio de Educación y Ciencia TIN2007-67586-

C02 grant, and the Junta de Comunidades de

Castilla-La Mancha PBI06-0099 grant.

TOWARDS AN INTEGRATIVE METHODOLOGY FOR DEVELOPING MULTI-AGENT SYSTEMS

397

Figure 2: MAS development methodology.

ICAART 2009 - International Conference on Agents and Artificial Intelligence

398

REFERENCES

Bauer, B., & Odell, J. (2005). UML 2.0 and agents: How

to build with the new UML standard. Journal of

Engineering Applications in Artificial Intelligence,

Vol. 18, No. 2, pp. 141-157.

Bézivin, J., Jouault, F., & Touzet, D. (2005). An

introduction to the ATLAS model management

architecture. Research Report LINA, (05-01).

February 2005.

Celorrio, C., & Verdejo, M.F. (2007). Adapted activity

deployment and configuration in a pervasive learning

framework. Proceedings in Pervasive Learning,

Workshop at Pervasive 2007, PL2007, pp. 51-58.

Cysneiros, G., & Zisman, A. (2004). Refining Prometheus

methodology with i*. 3rd International Workshop on

Agent-Oriented Methodologies, OOPSLA 2004.

Dam, K.H., Winikoff, M., & Padgham, L. (2006). An

agent-oriented approach to change propagation in

software evolution. Proceedings of the Australian

Software Engineering Conference, ASWEC 2006, pp.

309-318.

Fuentes, R., Gómez-Sanz, J.J., Pavón, J. (2006).

Integrating agent-oriented methodologies with UML-

AT. Proceedings of the 5th International. Joint

Conference on Autonomous Agents and Multiagent

Systems, AAMAS 2006, pp. 1303-1310.

Fuentes, R., Gómez-Sanz, J.J., Pavón, J. (2007). Model

integration in agent-oriented development.

International Journal of Agent-Oriented Software

Engineering, Vol. 1, No.1, pp. 2-27.

García-Magariño, I., Gómez-Sanz, J.J., & Pavón, J.

(2007). Representación de las relaciones en los

metamodelos con el lenguaje Ecore. Desarrollo de

Software Dirigido por Modelos, DSDM07.

Garijo, F., Bravo, S., Gonzalez, J., & Bobadilla, E. (2004).

BOGAR-LN: An agent based component framework.

Lecture Notes in Artificial Intelligence, Vol. 3040, pp.

207-220.

Garijo, F., Polo, F., Spina, D., Rodríguez, C. (2008).

ICARO-T User Manual. Internal Report, Telefonica

I+D, May 2008.

Gascueña, J.M., & Fernández-Caballero, A. (2008).

Prometheus and INGENIAS agent methodologies: A

complementary approach. Proceedings of the 9th

International Workshop on Agent-Oriented Software

Engineering, AOSE'08.

Giret, A., Botti, V., & Valero, S. (2005). MAS

methodology for HMS. Lecture Notes in Artificial

Intelligence, Vol. 3593, pp. 39-49.

Gómez Sanz, J.J., & Pavón, J. (2008). INGENIAS

Development Kit (IDK) Manual. Version 2.5.2

(corresponds to version 2.5 of the IDK).

http://heanet.dl.sourceforge.net/sourceforge/ingenias/

ingeniasmanual.v2.5.pdf

Jarraya, T., and Guessoum, Z. (2007). Towards a model

driven process for multi-agent system. Lecture Notes

in Computer Science, Vol. 4696, pp. 256-265.

Jacobson, I., Booch, G. & Rumbaugh, J. (1999). The

unified software development process. Reading, MA:

Addison-Wesley.

Jennings, N.R., & M. Wooldridge. (1995). Applying agent

technology. International Journal of Applied Artificial

Intelligence, Vol. 9, No. 4, pp. 351-359.

Lyytinen, K.S., & Rossi, M. (1999). METAEDIT+ - A

fully configurable multi-user and multi-tool CASE and

CAME environment. Lecture Notes in Computer

Science, Vol. 1080, pp.1-21.

Padgham, L., & Winikoff, M. (2004). Developing

Intelligent Agents Systems: A Practical Guide. John

Wiley and Sons.

Padgham, L., Thangarajah, J., & Paul, P. (2008).

Prometheus Design Tool. Version 2.5. User Manual.

http://www.cs.rmit.edu.au/agents/pdt/docs/PDT-

Manual.pdf.

Pavón, J., Gómez-Sanz, J.J., & Fuentes, R. (2005). The

INGENIAS methodology and tools. In: Agent-

Oriented Methodologies. Idea Group Publishing.

Pavón, J., Gómez-Sanz, J.J., & Fuentes, R. (2006). Model

driven development of multi-agent systems. Lecture

Notes in Computer Science, Vol. 4066, pp. 284-298.

Pavón, J., Garijo, F., & Gómez-Sanz, J. (2007). Complex

systems and agent-oriented software engineering. In

Engineering Environment-Mediated Multiagent

Systems, EEMMAS 2007, pp. 3-16.

Perepletchikov, M., & Padgham, L. (2005). Systematic

incremental development of agent systems, using

Prometheus. In Fifth International Conference on

Quality Software, QSIC'05, pp. 413-418.

Perini, A., and Susi, A. (2005). Automating model

transformations in agent-oriented modelling. Lecture

Notes in Computer Science, Vol. 3950, pp. 167-178.

Rougemaille, S., Migeon, F., Maurel, Ch., Gleizes, M.P.

(2007). Model driven engineering for designing

adaptive multi-agent systems. Proceedings of the 8th

Annual International Workshop Engineering Societies

in the Agents World, ESAW07.

Sansores, C., Pavón, J. & Gómez-Sanz, J.J. (2006). Visual

modeling for complex agent-based simulation

systems. Lecture Notes in Artificial Intelligence, Vol.

3891, pp. 174-189.

Schmidt, D.C. (2006). Guest editor's introduction: Model-

driven engineering. Computer, Vol. 39, No. 2, pp. 25-

31.

van Lamsweerde, A. (2001). Goal-oriented requirements

engineering: A guided tour. Proceedings of the 5th

IEEE International Symposium on Requirements

Engineering, RE'01, pp. 249-263.

Yoshimura, K. (2003). FIPA JACK: A plugin for JACK

Intelligent Agents

. Technical Report, RMIT

University. September 2003.

TOWARDS AN INTEGRATIVE METHODOLOGY FOR DEVELOPING MULTI-AGENT SYSTEMS

399
