AUTOMATED ACQUISITION OF ACTION KNOWLEDGE

T. L. McCluskey, S. N. Cresswell, N. E. Richardson and M. M. West

School of Computing and Engineering,The University of Huddersﬁeld,Huddersﬁeld HD1 3DH, U.K.

Keywords:

Planning and scheduling, Machine learning.

Abstract:

AI planning engines require detailed speciﬁcations of dynamic knowledge of the domain in which they are to

operate, before they can function. Further, they require domain-speciﬁc heuristics before they can function

efﬁciently. The problem of formulating domain models containing dynamic knowledge regarding actions is a

barrier to the widespread uptake of AI planning, because of the difﬁculty in acquiring and maintaining them.

Here we postulate a method which inputs a partial domain model (one without knowledge of domain actions)

and training solution sequences to planning tasks, and outputs the full domain model, including heuristics that

can be used to make plan generation more efﬁcient.

To do this we extend GIPO’s Opmaker system (Simpson et al., 2007) so that it can induce representations of

actions from training sequences without intermediate state information and without requiring large numbers of

examples. This method shows the potential for considerably reducing the burden of knowledge engineering,

in that it would be possible to embed the method into an autonomous program (agent) which is required to do

planning. We illustrate the algorithm as part of an overall method to acquire a planning domain model, and

detail results that show the efﬁcacy of the induced model.

1 INTRODUCTION

Applications of AI planning technology require per-

sistent resources comprising of teams of highly

skilled engineers to formulate and maintain a plan-

ner’s knowledge base. The amount of effort needed to

encode error free, accurate action speciﬁcations and

planning heuristics, and to maintain them, is signif-

icant. Actions are real world operations that change

the state of object(s) in the world in some way. These

actions are invariably encoded in planning knowledge

bases as generalised representations called operator

schema. Additionally, heuristics are often hand coded

in the form of methods which encapsulate the pre-

ferred solutions of a generalised subtask. Our work is

aimed at automating the formulationof such operators

and methods by employing a trainer to create training

tasks and example solution sequences of these tasks.

The solutions are fed to a knowledge acquisition tool,

Opmaker2, as a sequence of action instances, where

each action instance is identiﬁed by name plus the ob-

ject instances that are affected by, or are necessarily

present at, action execution. The sequences are pro-

duced by a trainer - a domain expert who may not

be familiar with the languages and notations used by

planners. Opmaker2 constructs operator schema and

planning heuristics from training sessions which are

composed of a handful of such action sequences. In

other words, it outputs detailed speciﬁcations of oper-

ator schema from single action traces automatically,

without requiring intermediate state information for

each training example. The induced actions are de-

tailed enough for use in planning engines and com-

pare well with hand crafted operators.

This paper describes Opmaker2, an extension

of the earlier Opmaker system (McCluskey et al.,

2002), in that the latter is an interactive learning tool,

whereas the former can be run in batch mode with-

out the need for user assistance. Opmaker was im-

plemented within the GIPO system (Simpson et al.,

2007), an experimental tools environment for use

in the acquisition of AI planning knowledge, con-

taining a wide range of engineering and validation

tools. GIPO was based on the planning language

of OCL (McCluskey and Porteous, 1996). To moti-

vate the rest of the paper, we will describe in a little

more depth the problem that we are aiming to solve,

in terms of a learning, or more speciﬁcally a knowl-

edge acquisition problem. Automated planning sys-

tems can be logically described as having three com-

ponents.

(a) The domain model (sometime referred to as a

L. McCluskey T., N. Cresswell S., E. Richardson N. and M. West M. (2009).

AUTOMATED ACQUISITION OF ACTION KNOWLEDGE.

In Proceedings of the International Conference on Agents and Artiﬁcial Intelligence, pages 93-100

DOI: 10.5220/0001662500930100

 SciTePress

domain description) is the speciﬁcation of the

objects, structure, states, goals and dynamics of

the domain of planning. The language family

used for the communication of domain models is

PDDL (AIPS-98 Planning Competition Commit-

tee, 1998), although in this paper we use a higher

level language called OCL(Liu and McCluskey,

2000) for domain modelling. Component (a) is

further split into:

(i) knowledge of objects, object classes, domain

constraints, and possible states of objects - collec-

tively called static knowledge.

(ii) knowledge of action and change - knowledge

of dynamics. This knowledge is in both PDDL

and OCL represented as a set of parameterised op-

erator schema representing generic actions in the

domain of interest.

(b) The planning engine is the software that rea-

sons with the knowledge in (a) to solve plan-

ning goals. The development of fast planning en-

gines which can deal with expressive variants of

PDDL (eg modelling domains containing durative

actions and metric resources) has been a primary

goal of the AI Planning community.

of AI Planning is well known to be intractable,

and a set of heuristics for each domain is required

to make the application of (b) to (a) tractable.

Whereas the form and content of (a) and (b)

are well understood, what form heuristics take is

more contentious. Putting domain heuristics with

the planning engine may limit its application (they

anticipate the domain). Encoding heuristics into

the domain model when constructing it is equally

contentious - as the authors of PDDL claim it is

for “physics and nothing else”(AIPS-98 Planning

Competition Committee, 1998).

The knowledge acquisition problem that this paper

addresses is:

Given knowledge of (a)(i), can we design a

simple process to enable a system to automat-

ically acquire knowledge of type (a)(ii) and

(c)?

The reason for setting up this knowledge acquisition

problem is that hand crafting knowledge of dynamics

(in particular operator schema), and planner and do-

main speciﬁc heuristics, is much harder than acquir-

ing knowledge of type (a)(i). The difﬁculty in acquir-

ing knowledge of actions is invariably pointed out in

reports of AI planning applications (for example, in

reports of Space applications (S. A. Chien (editor),

1997)).

The general method that we are proposing is for a

system to acquire knowledge from examples of solved

tasks, represented as sequences of actions, given to it

by a benevolent trainer. Operator schema (type (a)(ii)

knowledge) are induced from each example action,

whereas heuristics (type (c) knowledge) are induced

from the whole sequence of actions the trainer uses to

solve a task.

The rest of the paper is structured as follows: in

section 2 we outline the Opmaker2 system, starting

with its inputs and outputs, and then detail the op-

eration of its state-deriving component. We use a

tyre-change domain to illustrate the algorithm which

contains the knowledge acquisition process. Section

3 contains our experimental results, and Section 4 a

brief survey of related work.

2 THE OPMAKER2 SYSTEM

In this section we describe the Opmaker2 system, and

explain how it can form a solution to the knowledge

acquisition problem introduced in the last section. We

will use as a running example throughout the rest of

the paper a domain which represents changing the

tyre of a car wheel. This domain is an extended ver-

sion of the simpler ’tyre world’(Russell, 1989). It in-

volves knowledge about such objects as tyre, wheel,

nuts, wheel-trim, jack, wrench, and such actions as

undo-nuts, put-on-wheel etc.

In Opmaker2, components of type (a)(i) knowledge

are referred to collectively as the partial domain

model P D M . For our running example, the par-

tial domain of the tyre-change domain is provided

in the appendix, in the native code of OCL. There

are two inputs to Opmaker2: the P D M and a set of

hand crafted solution sequences to planning tasks. A

P D M consists of:

Object Identiﬁers and Sort Names: denoted Objs

and Sorts respectively; there are a number of sorts

(or classes) each containing a set of objects where

each object belongs to one set (called a sort). An

example of an object is hub1 belonging to the hub

sort. The behaviour of each object in a sort is as-

sumed to be the same as all others in the sort.

Predicate Deﬁnitions: denoted Prds, where each

object of each class may be related to objects

of other classes, and have property - value re-

lationships with sets of basic values (boolean

or scalar). Examples are on ground(hub),

jacked up(hub, jack), relating to whether an ob-

ject of sort hub is on the ground or jacked up.

Object State Expressions: denoted Exps; these de-

ICAART 2009 - International Conference on Agents and Artificial Intelligence

ﬁne implicitly all the possible values of an ob-

ject’s state. An object’s state is deﬁned by its re-

lationship with other objects and/or the value of

its properties. Sorts are engineered so that the ob-

ject state space is deﬁned by a small number of

expressions. For example, the tyre-change P D M

speciﬁes that any object H of sort hub can occupy

a state satisfying exactly one of the following ob-

ject expressions:

[on_ground(H),fastened(H)],

[jacked_up(H,J),fastened(H)],

[free(H),jacked_up(H,J),unfastened(H)],

[unfastened(H),jacked_up(H,J)]

(as a convention we choose upper case variables

as parameters - here J represents any object of sort

jack).

Domain Invariants: denoted Invs; these are used to

deﬁne domain constraints and are written in terms

of the predicates given above. Informally, a set

of invariants is adequate if any ‘common sense’

inference can be made from them, such as normal

inferences about spatial relations. For example:

“Only a single wheel can be on a hub”.

∀H : hub∀W

: wheel∀W

: wheel

wheel on(W

, H)∧

wheel on(W

, H) ⇒ (W

= W

)

The second input is a set of solution sequences

and the tasks that they solve. These are supplied by a

trainer (a domain expert). For the purposes of training

in Opmaker2, we deﬁne a task in terms of:

• an initial state comprising the initial states of ob-

jects in the domain

• a set of desired goal states for a set of objects

A solution sequence solves such a task and is writ-

ten in terms of verbs (action names) and affected ob-

jects. The trainer is expected to include references to

all objects that are needed for each action to be car-

ried out, indicating whether or not the objects change

as a result of the action. Typical tasks in the domain

should be chosen that often form the basis of solutions

to larger tasks. For example, in the sequence below a

changed wheel is secured on the hub and the vehicle

is made ready for use.

do_up unchanged - wrench0, jack0, wheel1;

changing - hub1, nuts1

jack_down unchanged - null

changing - hub1, jack0

tighten unchanged - wrench0, hub1, trim1;

changing - nuts1

apply_trim unchanged - hub1;

changing - trim1,wheel1

Objects preceded by unchanged remain unaf-

fected by the action, but have to be present in the

state during execution of the action. In the ﬁrst ele-

ment of the sequence, wrench0, jack0 and wheel1 all

have to be in a certain state speciﬁed by initial state

of the task (wrench0 is available, jack0 is jacking up

the hub, and wheel1 is trimless to allow the nuts to

be screwed). The changing objects must change state

(hub1 becomes fastened and nuts1 are done up).

The output of Opmaker2 is a full domain model,

consisting of:

Operator Schema: they make up the knowledge of

type (a)(ii), and represent actions or events that

change objects’ states. They are speciﬁed by a

name, a list of parameters, and a set of object tran-

sitions. Transitions may be null (in which case

they act as prevail conditions), necessary or con-

ditional. The template of a schema is as follows:

name(list of parameters)

zero or more prevail condition;

one or more necessary transitions;

zero or more conditional transitions

Prevails are represented by object state expres-

sions, whereas necessary and conditional transi-

tions are written in the form LHS ⇒ RHS where

LHS, RHS are object state expressions.

Methods: each training sequence results in a param-

eterised method, similar in form to hierarchical

(HTN) methods found in AI Planning. A method

comprises of a name, prevail conditions, and a se-

quence whose members can comprise both opera-

tor schema and (other) methods. Methods can be

used as a heuristic in planning engines as they en-

capsulate preferred ways to solve planning prob-

lems.

2.1 The Opmaker2 Algorithm

The main innovation of Opmaker2 is that it com-

putes its own intermediate states using a combination

of heuristics and inference from the P D M and the

training tasks and solutions. This gives a fully au-

tomated solution to the knowledge acquisition prob-

lem described above - there is no need for user ad-

vice. In contrast, its predecessor Opmaker is a mixed

initiative knowledge acquisition tool which requires

the same inputs as above (a P D M and a set of solu-

tion sequences to tasks) and, additionally, it requires

user advice. As Opmaker creates an operator schema

from each action in a training solution sequence, it

asks the user to input, if needed, the target state that

each object would occupy after execution of the ac-

tion. In order to build up transitions that form an op-

erator schema, the LHS is taken as the current state of

AUTOMATED ACQUISITION OF ACTION KNOWLEDGE

the object (object transitions are tracked as each ac-

tion is processed). The RHS is taken from the user in-

put, which indicates, where there is a choice, the state

an object is left in (this becomes that object’s current

state). Having the start and end states for each object

involved in the action, Opmaker proceeds with a gen-

eralisation phase where object instances are replaced

with sort parameters, which then form the parameter

variables X

, . . . X

of the resulting operator schema.

In supplying the solution sequences, the trainer

speciﬁes what objects take part in what actions. As

actions are executed, objects go through state transi-

tions and occupy intermediate states en route to reach-

ing their goal states. The space of states that an object

may occupy are deﬁned implicitly by the state expres-

sions of the P D M . To be able to automatically ac-

quire operator schema, Opmaker was able to resolve

exactly what are the intermediate states of each object

affected in the training sequence by asking for user

advice. In Opmaker2, the DetermineStatesprocedure

performs this function by tracking the changing states

of each object referred to within a training example,

taking advantage of the static, object-state informa-

tion and invariants within the domain model. The

output from DetermineStates is, for each object re-

ferred to in a training solution sequence, a map which

associates with each object its unique state value at

each point in the training sequence. Uniqueness is not

guaranteed, however, and depends on the information

in the P D M , hence sometimes this map may return

a set of states rather than a unique one (we return to

this problem below). Once the map determining in-

termediate states has been generated, the techniques

of the original Opmaker algorithm are used to gener-

alise object references and create parameterised oper-

ator schema.

2.1.1 A Description of the DetermineStates

Procedure

To illustrate the workings of the Procedure, we

will use the example tyre domain solution se-

quence to form the initial stage of an example

walk-though. Let us consider A(1)-A(4) = do up,

jack down,tighten,apply trim as given above. The al-

gorithm is as follows:

Procedure DetermineStates

In:

P D M ,

I, F are maps of objects to their Initial, Final state, resp.

T = A(1)..A(N): training sequence of N actions

Out:

maps C

, i = 1, ..., N + 1, deﬁning the state space of objects

throughout the execution of the training sequence T

Deﬁne A.c to be the set of A’s changing objects

1. i := 1;C

:= I;C

N+1

= F;

2. for each i ∈ 1, ..., N − 1

3. for each object O 6∈ A(i).c

4. C

i+1

(O) := C

(O);

5. end for

6. for each object O ∈ A(i).c

7. if O 6∈ A(i+ 1).c∪ ... ∪ A(N).c then

8. C

i+1

(O) := F(O)

9. else

10. generate C

i+1

(O) = any legal state using P D M

11. test the choice using the following constraints

12. – C

i+1

(O) 6= C

(O)

13. – parameters of C

i+1

(O) must all be

14. satisﬁable by objects in A

15. – the conjunction of C

i+1

(O) for all O,

16. must be consistent with P D M ’s invariants

17. end if

18. end for

19. end for

In Line 1 the ﬁrst and last components of the map

C are initialised to be the same as the initial and ﬁnal

state respectively. The algorithm then iterates for all

actions in the sequence. When i = 1, Lines 3-5 deﬁne

as the same as C

when applied to non-changing

objects in the domain. Lines 6-18 attempt to deter-

mine the rest of map C

where it is applied to objects

that change as a result of the execution of A(1). Line

6 identiﬁes the changing objects (hub1 and nuts1) - let

us consider hub1. Lines 7-8 look ahead to see if hub1

will not change again in a subsequent action and ﬁnd

that it does in the second action in the sequence. If

we had chosen an example where the object does not

change again after the ﬁrst action then Line 8 would

set the object’s state to be the ﬁnal state. Consider-

ing Line 10, using the partial domain model there are

four potential values for C

(hub1):

a. [on_ground(hub1),fastened(hub1)]

b. [free(hub1),jacked_up(hub1,jack0),

unfastened(hub1)]

c. [jacked_up(hub1,jack0),fastened(hub1)]

d. [unfastened(hub1), jacked_up(hub1,jack0)]

Lines 12-16 of the algorithm determine which of

these states is appropriate. The constraint in Line

12 makes sure the new object state is different from

the last. hub1’s current state is [unfastened(hub1),

jacked up(hub1,jack0)], so this eliminates d. Lines

13-14 checks that an object state has no unreferenced

parameters (if part of the state description references

an object not taking part in the transition, then that

state would be inappropriate). This does not eliminate

any of the choices in the example. Lines 15-16 check

that the union of all the chosen states (in this case in-

corporating choices for hub1 and nuts1) are consis-

tent. Using these constraints, the states a. and b. are

eliminated, leaving c. to be chosen as the value of

(hub1).

ICAART 2009 - International Conference on Agents and Artificial Intelligence

To complete the Opmaker process, once the state

space map C has been determined, operator instances

are constructed by creating prevail components for

each unchanging object, and creating necessary tran-

sitions for each object that is changed by an action.

These instances are generalised to schema on the ba-

sis that each object in a sort behaves the same, and can

be replaced by a ’sort parameter’. The systems stores

the deﬁnition of the operator schema and checks them

against any previous deﬁnition. Finally, a method is

generated by combining the induced operator schema,

using the original Opmaker code.

For some domain models complications arise in

the binding of paramerterised object states from the

P D M to actual states (Line 10), in that more than

one binding may be possible. This, and the fact that

the tests (in Line 12-16) may not determine a unique

state, sometimes produce a non-deterministic map C.

However, we have found that this depends on the

strength of the invariants that are supplied with the

P D M .

3 EXPERIMENTS AND RESULTS

Opmaker2 has been implemented in Sicstus Prolog

incorporating the algorithm detailed above. We use

the same experimental approach that was used to test

the original Opmaker system, which was to:

• Compose training tasks and solution sequences

from a range of domains that have already been

captured within a hand-crafted model. The set of

training tasks should contain at least one instance

of each action in the domain, and each task is se-

lected on the basis of whether it is likely to form

building blocks for the solution of more complex

tasks. The (initial) partial domain model input

into Opmaker2 is the hand crafted domain with-

out its operator schema.

• Use Opmaker2 to induce operator schema and

methods from the training tasks and solution se-

quences, and the partial domain model.

• Use a planning engine to check that the automati-

cally acquired operator schema can solve the same

set of problems that the hand-crafted set has been

applied to.

• Use a planning engine to compare performance

of the old hand-crafted action schema versus the

induced schema and methods. In this case Hy-

HTN (McCluskey et al., 2003), a HTN planner

which can take advantage of the induced methods,

was used. For a comparison with a planner which

uses only operator schema (without methods), we

use Hoffman’s FF planner (Hoffmann, 2000).

Success is judged using the following kinds of cri-

teria:

1. Uniqueness: is a set of unique operator schema

acquired from the training tasks and the partial do-

main model that originated from the hand crafted

domain model? Or, more subtly, can Opmaker2

induce unique schema without having to encode

many invariants into the domain models?

2. Validity: Can a set of operator schema output

from Opmaker2 be used by a planner to solve

the same tasks that the original training sequences

were aimed at?

3. Efﬁciency: Is it more efﬁcient, in terms of plan-

ning time, to solve tasks using Opmaker2 de-

ﬁned operator schema and methods, rather than

the original hand-crafted operators?

We detail the results for the extended tyre domain

below, and describe other domains on which we have

experimented. More details can be found in a recent

doctoral thesis (Richardson, 2008).

Results in the Extended Tyre Domain. The hand-

crafted version of the extended tyre domain has 26

objects in 9 sorts, with 22 operators. We engaged

a researcher (who was not the author of Opmaker2

software) to create 7 sequences of tasks of between 2

and 5 actions in length, encapsulating useful subtasks

such as taking a wheel off a hub, or bringing tools

out of the car’s boot. When input to OpMaker2 with

the initial partial domain model, procedure generate

did not have enough information to discover unique

sequences of states for all objects in the training se-

quences. However, adding extra ’common sense’ in-

variants to the partial domain model (shown in the

appendix) was sufﬁcient to allow DetermineStates to

generate a unique set of state sequences, leading to

a set of 22 operator schema generated (Richardson,

2008). On inspection, these were identical in structure

to the original hand crafted version. This was con-

ﬁrmed by running the full domain model with a plan-

ner and ensuring that all tasks were correctly solved.

In addition to operators, the 7 sequences of training

tasks input lead to 7 methods being output. For ex-

ample, one of the 7 generated methods encapsulating

solution heuristics is as follows:

We use the GIPO tool to translate the generated OCL

domain models into PDDL (the strips version with typing,

equality, conditional effects) so that they can be input to

generally available planners.

AUTOMATED ACQUISITION OF ACTION KNOWLEDGE

method(

% name

discover_puncture(Tyre1,Boot,Pump0),

% pre-condition

[ pump_in(Pump0,Boot) ],

% necessary transitions of objects

[ flat(Tyre1) => punctured(Tyre1),

closed(Boot) => open(Boot)

% static constraints

[],

% temporal constraints

[before(1,2),before(2,3),before(3,4)],

% decomposition

[ open_container(Boot),

fetch_pump(Boot,Pump0),

find_puncture(Pump0,Tyre1),

putaway_pump(Boot,Pump0)]

)

Generating plans up to 10- 12 operations in length

was possible with standard planning engines, but

tasks demanding solutions of greater length were not

possible with the planning engines at our disposal.

However, when the induced operator schema and the

methods were used together with HyHTN, plan times

were signiﬁcantly shorter. For example, a complex

planning problem for this extended domain is para-

phrased as: “A car has two ﬂat tyres: one is intact and

can be ﬁxed by use of the pump, whilst the other is

punctured and requires a full tyre change”. No solu-

tion was found to this problem after 36 hours using

FF or HyHTN without the induced methods. How-

ever, using the induced domain schema and methods

a correct solution of length 24 was found by HyHTN

after only 11 seconds. It is not surprising that HTN-

type domain models are so efﬁcient: this is supported

by ﬁelded planning applications. What is signiﬁcant

here is that both the operator schema and the HTN-

type methods used in the domain model were gener-

ated by Opmaker2.

Experiments with other Domains. We experi-

mented with an OCL encoding of a Blocks Domain,

with 7 blocks stacked on a table. 6 action names were

devised and one long training sequence that solved

the following task was created: given a set of seven

blocks stacked bottom to top block 1 to block7, use a

gripper to move one block at a time until the blocks

are in two stacks. The order of the blocks in these

stacks (bottom to top) is block6, block2, block4 form

ﬁrst stack; block5, block1, block7, block3 form the

other stack. A 22 solution sequence was composed

and fed into Opmaker is 6 separate batches, to enable

methods and operator schema to be induced. With the

original partial domain model enhanced with 4 invari-

ants, 6 operator schema were output by Opmaker2.

Table 1: Operator Testing in Blocks World Full Problem

Task No. Actions Operator Schema

1 4 2

2 2 2

3 2 2

4 4 4

5 2 2

6 2 2

7 22 6

These operators were identical in structure to the

hand-coded ones for this domain, and can be used op-

erationally by planning engines. Table 1 shows that

the overall task can be tackled in chunks (Tasks 1 - 6),

as well as in one sequence (task 7). Each of the 7 tasks

resulted in unique and accurate operator schema.

The Hiking Domain was used to illustrate the orig-

inal Opmaker, and models ’lazy’ hikers (recreational

walkers) who use two cars to carry their equipment

around a long (several day) circular route. Automated

planning is used to work out the logistics of where

to leave their cars, to put up their tent, to transport

their luggage etc. For Opmaker2 to produce an accu-

rate, unique set of operator schema, the partial domain

model required one extra invariantto strengthen it suf-

ﬁciently. This compares well with the original use of

the domain (McCluskey et al., 2002) which required

a fairly laborious interactive session before outputting

operator schema.

4 RELATED WORK

In his Ph.D. thesis (Grant, 1996) Grant showed

how a system could induce operators from a knowl-

edge of inconsistent constraints. In more recent

work (Grant, 2007) he shows how his system, Plan-

ning Operator Induction (POI), extends to a multi-

agent system. The work is based on representations of

operators and constraints which between them model

the domains. The emphasis is on how the recipient

agent assimilates the knowledge another agent has

given it into its own knowledge.

Learning expressive theories from examples is

a central goal in the Inductive Logic Programming

community. In his thesis (S.S.Benson, 1996), Ben-

son describes an ILP method for learning more ex-

pressive operator schema than Opmaker2, using mul-

tiple examples. However, the focus of Opmaker2 is

to learn from (ideally) one example sequence, and to

learn heuristics as well as operator structure.

Perhaps closest to our work is ARMS (Wu et al.,

2005), a system in which operators are learned with-

ICAART 2009 - International Conference on Agents and Artificial Intelligence

out the need for user intervention. Further work by

these authors (Yang et al., 2007) involves learning re-

cursive HTN structures. The authors focus on match-

ing sub-sequences to tasks assuming no knowledge

of observed states achieved by low-level actions. The

output consists of pairs of action sequences and the

high-level tasks achieved by them. As with our sys-

tem they begin with solution sequences of deﬁned

tasks, and compare learned methods to hand-crafted

ones to judge success. Whilst ARMS does not require

a partial domain model, it requires many training sets

(about 40 training sets is quoted). Once learned they

were ﬁne tuned by domain experts by hand. By con-

trast our system does not require multiple examples,

as we focus on an expert transferring heuristic knowl-

edge encapsulated in a handful of well chosen exam-

ples solution sequences.

5 CONCLUSIONS

In this paper we have set up a knowledge acquisition

problem which is very relevant to tackling the cen-

tral problem of using AI planning engines - the ac-

quisition of formulations of actions (in the form of

operator schema), and acquisition of heuristics (in the

form of HTN-type methods). Our work and the re-

sults reported here depend on a structured viewof par-

tial domain knowledge about objects being available.

Whereas in propositional, classical planning (epit-

omised by the PDDL language (AIPS-98 Planning

Competition Committee, 1998)), states are fairly ar-

bitrary sets of propositions, we assume that the space

of states is restricted in that objects are pre-conceived

to occupy a ﬁxed set of plausible states. Within this

framework, we have described a method for inducing

operator schema that advances the state of the art in

that it requires no intermediate state information, or

large numbers of training examples, to induce a valid

operator set. Further, our results give some evidence

that the methods induced with the operator schema

lead to more efﬁcient domain models.

Opmaker2 is an improvement on Opmaker in

that it eliminates the need for the user or trainer to

give the system intermediate state information. Af-

ter Opmaker2 automatically infers this intermediate

state information, it proceeds in the same fashion as

Opmaker and induces the same operator schema. Our

experimental results show, however, that partial do-

main models may have to be strengthened with extra

invariants before a unique set of operator schema can

be synthesised. Hence, we could summarise our work

as arguing for the creation of planning domain models

by the crafting of a strong partial domain model, and

a set of training tasks, rather than crafting operator

schema and planning heuristics manually.

There are several directions for future work:

1. can our work be extended to capturing domains

with durative or probabilistic actions, or other,

more expressive formulations for action? What

extra details would be required as input to the op-

erator induction process?

2. can the Opmaker2 system be extended to deal

with model maintenance (for instance by incre-

mental learning), so that old operator schema can

be reﬁned in the presence of new example solution

sequences?

3. what resilience does our approach offer in the face

of errors in training tasks or in the partial domain

model?

Finally, we believe that this line of research is es-

sential if intelligent agents are to have general plan-

ning capabilities. If this is to be the case, it seems

unlikely that intelligent agents will always rely on hu-

man experts to encode and maintain their knowledge.

It seems reasonable that they would need the capabil-

ity to acquire knowledge of actions themselves, per-

haps by observing the actions of other agents, and us-

ing pre-existing static domain knowledge, to induce

operator schema and domain heuristics.

REFERENCES

AIPS-98 Planning Competition Committee (1998). PDDL

- The Planning Domain Deﬁnition Language. Tech-

nical Report CVC TR-98-003/DCS TR-1165, Yale

Center for Computational Vision and Control.

Grant, T. (2007). Assimilating planning domain knowl-

edge from other agents. In Proceedings of the 26th

Workshop of the UK Planning and Scheduling Spe-

cial Interest Group, Prague, Czech Republic, Decem-

ber 2007.

Grant, T.J. (1996). Inductive Learning of Knowledge-Based

Planning Operators. PhD thesis, de Rijksuniversiteit

Limburg te Maastricht, Netherlands.

Hoffmann, J. (2000). A Heuristic for Domain Independent

Planning and its Use in an Enforced Hill-climbing Al-

gorithm. In Proceedings of the 14th Workshop on

Planning and Conﬁguration - New Results in Plan-

ning, Scheduling and Design.

Liu, D. and McCluskey, T. L. (2000). The OCL Language

Manual, Version 1.2. Technical report, Department of

Computing and Mathematical Sciences, University of

Huddersﬁeld .

McCluskey, T. L., Liu, D., and Simpson, R. M. (2003). Gipo

ii: Htn planning in a tool-supported knowledge engi-

neering environment. In Proceedings of the Thirteenth

AUTOMATED ACQUISITION OF ACTION KNOWLEDGE

International Conference on Automated Planning and

Scheduling.

McCluskey, T. L. and Porteous, J. M. (1996). Engineering

and Compiling Planning Domain Models to Promote

Validity and Efﬁciency. Technical Report RR9606,

School of Computing and Maths, University of Hud-

dersﬁeld.

McCluskey, T. L., Richardson, N. E., and Simpson, R. M.

(2002). An Interactive Method for Inducing Operator

Descriptions. In The Sixth International Conference

on Artiﬁcial Intelligence Planning Systems.

Richardson, N. E. (2008). An Operator Induction Tool Sup-

porting Knowledge Engineering in Planning. PhD

thesis, School of Computing and Engineering, Uni-

versity of Huddersﬁeld, UK.

Russell, S. J. (1989). Execution architectures and compila-

tion. In Proc. IJCAI.

S. A. Chien (editor) (1997). 1st NASA Workshop on Plan-

ning and Scheduling in Space Applications. NASA,

Oxnard, CA.

Simpson, R. M., Kitchin, D. E., and McCluskey, T. L.

(2007). Planning domain deﬁnition using gipo. Jour-

nal of Knowledge Engineering, 1.

S.S.Benson (1996). Learning Action Models for Reactive

Autonomous Agents. PhD thesis, Dept of Computer

Science, Stanford University.

Wu, K., Yang, Q., and Jiang, Y. (2005). Arms: Action-

relation modelling system for learning acquisition

models. In Proceedings of the First International

Competition on Knowledge Engineering for AI Plan-

ning, Monterey, California, USA.

Yang, Q., Pan, R., and Pan, S. J. (2007). Learning recursive

htn-method structures for planning. In Proceedings

of the ICAPS’07 Workshop on Artiﬁcial Intelligence

Planning and Learning.

APPENDIX

% Sorts

sorts(primitive_sorts,[container,nuts,hub,

pump,wheel, wrench,jack,wheel_trim,tyre]).

% Objects

objects(container,[boot]).

objects(nuts,[nuts1,nuts2,nuts3,nuts4]).

objects(hub,[hub1,hub2,hub3,hub4]).

objects(pump,[pump0]).

objects(wheel,[wheel1,wheel2,

wheel3,wheel4,wheel5]).

objects(wrench,[wrench0]).

objects(jack,[jack0]).

objects(wheel_trim,[trim1,trim2,trim3,trim4]).

objects(tyre,[tyre1,tyre2,tyre3,tyre4,tyre5]).

% Predicates

predicates([ closed(container),open(container),

tight(nuts,hub),loose(nuts,hub),have_nuts(nuts),

on_ground(hub),fastened(hub),jacked_up(hub,jack),

free(hub),unfastened(hub),have_pump(pump),

pump_in(pump,container),have_wheel(wheel),

wheel_in(wheel,container),wheel_on(wheel,hub),

have_wrench(wrench),wrench_in(wrench,container),

have_jack(jack),jack_in_use(jack,hub),

jack_in(jack,container),trim_on(wheel_trim,wheel),

trim_off(wheel_trim),fits_on(tyre,wheel),

full(tyre),flat(tyre),punctured(tyre)]).

% Object Class Definitions

substate_classes([

container(C,[[closed(C)], [open(C)] ]),

nuts(N,[[tight(N,H)],[loose(N,H)],

[have_nuts(N)]]),

hub(H, [[on_ground(H),fastened(H)],

[jacked_up(H,J),fastened(H)],

[free(H),jacked_up(H,J),unfastened(H)],

[unfastened(H),jacked_up(H,J)] ]),

pump(Pu, [[have_pump(Pu)],[pump_in(Pu,C)] ]),

wheel(Wh, [[have_wheel(Wh)],[wheel_in(Wh,C)],

[wheel_on(Wh,H)]]),

wrench(Wr,[[have_wrench(Wr)],[wrench_in(Wr,C)]]),

jack(J,[[have_jack(J)],[jack_in_use(J,H)],

[jack_in(J,C)] ]),

wheel_trim(WT,[[trim_on(WT,Wh)],[trim_off(WT)]]),

tyre(Ty, [[full(Ty)], [flat(Ty)],

[punctured(Ty)], [fits_on(Ty,Wh)] ]) ]).

% Invariants

atomic_invariants([ fits_on(tyre1,wheel1),

fits_on(tyre2,wheel2), fits_on(tyre3,wheel3),

fits_on(tyre4,wheel4), fits_on(tyre5,wheel5)]).

invariant( all(H:hub,fastened(H)<==>

ex(N:nuts,tight(N,H)\/loose(N,H))) ).

invariant( all(H:hub,all(J:jack,jack_in_use(J,H)

<==>jacked_up(H,J))) ).

invariant( all(H:hub,˜free(H)<==>

ex(W:wheel,wheel_on(W,H))) ).

invariant(

all(T:wheel_trim,all(W:wheel,trim_on_wheel(T,W)

<==>trim_on(W,T))) ).

%Hub may only have one set of nuts attached

invariant(all(H:hub,all(N1:nuts,all(N2:nuts,

(tight(N1,H)\/loose(N1,H)) /\

(tight(N2,H)\/loose(N2,H))==>(N1=N2) ))) ).

%Hub may only have one wheel attached.

invariant( all(H:hub,all(W1:wheel,all(W2:wheel,

wheel_on(W1,H)/\wheel_on(W2,H)==>(W1=W2) ))) ).

%If nuts are tight then hub must be on the ground.

invariant(

all(H:hub, ex(N:nuts,tight(N,H))==>on_ground(H))).

%If a trim is on a wheel, then the wheel is on

% a hub and the nuts are tight.

invariant(

all(W:wheel,ex(T:wheel_trim,trim_on_wheel(T,W))

==>

ex(H:hub,wheel_on(W,H)/\ex(N:nuts,tight(N,H))))).

ICAART 2009 - International Conference on Agents and Artificial Intelligence

100
