A FAST AND ROBUST HAND-DRIVEN 3D MOUSE

Andrea Bottino and Matteo De Simone

Dipartimento di Automatica e Informatica, Politecnico di Torino

Corso Duca degli Abruzzi 24, 10129 Torino, Italy

Keywords: Computer vision, Image processing, 3D hand tracking, Non intrusive motion capture, Real time tracking.

Abstract: The development of new interaction paradigms requires a natural interaction. This means that people should

be able to interact with technology with the same models used to interact with everyday real life, that is

through gestures, expressions, voice. Following this idea, in this paper we propose a non intrusive vision

based tracking system able to capture hand motion and simple hand gestures. The proposed device allows to

use the hand as a “natural” 3D mouse, where the forefinger tip or the palm centre are used to identify a 3D

marker and the hand gesture can be used to simulate the mouse buttons. The approach is based on a

monoscopic tracking algorithm which is computationally fast and robust against noise and cluttered

backgrounds. Two image streams are processed in parallel exploiting multi-core architectures, and their

results are combined to obtain a constrained stereoscopic problem. The system has been implemented and

thoroughly tested in an experimental environment where the 3D hand mouse has been used to interact with

objects in a virtual reality application. We also provide results about the performances of the tracker, which

demonstrate precision and robustness of the proposed system.

1 INTRODUCTION

In the recent years there has been a growing interest

in the scientific and industrial communities to

develop innovative devices allowing a natural

interaction with machines, and recent products, like

the Nintendo Wii console and the Microsoft Surface,

try to introduce novel habits for computer users.

From this point of view, one of the most natural

ways to interact with objects is using our bare hands.

In real world, we use our hands to touch, grasp and

move the objects and we typically use our fingers to

point at something. Acting in the same way on the

objects, allows people to transfer already acquired

abilities to the interaction with the computer and to

expand possibilities and complexities in human-to-

computer communication.

Several commercial gesture based devices exist

at present. They usually require extraneous wearable

hardware, such as markers or sensing gloves. These

solutions provide high quality results but they are

expensive, intrusive and they could disturb the

movements of the user.

On the contrary, vision based techniques could

offer a simple, expressive, and meaningful manner

to interact with the computer. These techniques are

cost-effective and non invasive, and they have been

used in many contexts.

In this paper, we propose a simple, fast and

robust hand tracking system that can be used to

develop a “natural” 3D mouse. The output of the

tracker is the position of a 3D marker and an

indication of the actual posture of the hand, which

can be used to mimic the click of the mouse buttons.

Our system uses two video cameras and the

proposed approach separates the elaboration of the

two image streams, refining the results in a merging

stage at the end of the process. In more details, for

each image stream, we evaluate the perceived hand

posture and the 2D position, on the image plane, of

the reference point. The results are then combined in

order to evaluate the final 3D marker position and

hand posture.

Experimental results demonstrate that the

proposed system is fast, robust and computationally

manageable on medium level computers. The paper

is organized as follows. In Section 2, we describe

our approach. Section 3 evaluates the experimental

results. Concluding remarks are reported in Section

567

Bottino A. and De Simone M. (2009).

A FAST AND ROBUST HAND-DRIVEN 3D MOUSE.

In Proceedings of the Fourth International Conference on Computer Vision Theory and Applications, pages 567-574

DOI: 10.5220/0001746005670574

 SciTePress

1.1 Related Works

The general approach to vision based hand tracking

usually requires three main processes: hand

segmentation, hand tracking and gesture estimation.

Colour is the most common image clue for feature

extraction (Bradski, 1998), (Chen, Fu and Huang,

2003), (Pantrigo, Montemayor and Sanchez, 2005).

Other visual cues, like motion, edges and shading

have been proposed in order to reduce influences of

varying illumination and cluttered background (Cui

and Weng, 2000), (Liu and Jia, 2004). Recent results

in integrating different visual information offer more

robust solutions (Akyol and Alvarado, 2001), (Shan

Lu et al, 2003).

Several approaches have been applied to the

tracking problem: a review of the most popular

algorithms is presented in Mahmoudi and Parviz

(2006). The CAMShift algorithm (Bradski, 1998) is

a robust nonparametric technique derived form

Mean Shift (Cheng, 1995). Improvements of

CAMShift algorithm can be found in Liu et al.

(2003), Zhai et al. (2005). The Condensation

algorithm (Isard and Blake, 1998) is a powerful

stochastic approach based on Monte Carlo method

that has been applied to several challenging

environments, such as wearable computers (Liu and

Jia, 2004) and real-time humanoid interaction

(Gumpp et al, 2006). Improvements of Condensation

are Icondesation (Isard and Blake, 1998), particle

filtering (Weiser and Brown, 1995), (Shan et al,

2004), smart particle filtering (Bray, Koller-Meier

and Van Gool, 2004) and local search particle filter

(Pantrigo, Montemayor and Sanchez, 2005).

Articulated and deformable 3D hand model driven

techniques have also been proposed by Stenger,

Mendonca and Cipolla (2001), (Heap and Hogg,

1996).

As for the gesture estimation problem, a good

survey on the subject is Erol et al., (2007). We can

have partial pose approaches (Oka, Sato and Koike,

2002), (Letessier and Bèrard, 2004), which are

usually based on rough models of the hand and

cannot reconstruct all the degrees of freedom (DOF)

of the hand, and full DOF approaches, usually

exploiting complex 3D models (Drummond and

Cipolla, 2002), and performing single frame pose

estimation offering the advantage of self-initializing

and re-initializing algorithms, capable of handling

fast hand motion where time coherence is an useless

clue (Stenger et al., 2004), (Tomasi, Petrov and

Sastry, 2003).

2 THE MULTIPLE CAMERA

APPROACH TO HAND

TRACKING

The goal of our work is to develop a simple and

effective input device which allows a “natural” way

of interacting with the computer using the bare

hands. In our scenario, a single user sitting at a

desktop interacts with a VR application picking 3D

points, selecting and moving objects in the

environment or changing the view on the simulated

world. To perform these tasks, the 3D counterpart of

a desktop mouse, that is a device capable of moving

a 3D marker in the environment and to issue

commands by pushing some buttons, could be

sufficient. From the point of view of the user, which

is immersed in a virtual environment where the

objects are floating in front of his eyes, the most

natural way to select an object would be by touching

it, to change its position by moving it with the hand,

and picking a location by pointing it. To select a

different view of the scene, a commonly used

approach is the virtual trackball paradigm: the

objects are enclosed in a glass ball which can be

rotated around its centre to change the world view.

Again, a natural way to perform this operation

would be to touch the glass ball and rotate it with the

hand. Therefore, the position of the forefinger tip

can be used as a “natural” 3D marker that can be

controlled moving the hand (Figure 1a-b). A simple

way to simulate the click of the mouse could be to

associate the event to a specific, and comfortable,

hand posture. For instance, when the forefinger is

extended, such a posture could be the one where also

the thumb is stretched out (Figure 1c-d). Thumb-

index enslaving is not a problem for ergonomy,

since Olafsdottir (2005) shows that the indices of

digit interaction does not depend whether the thumb

is one of the involved digits.

Figure 1: Interaction with the virtual environment.

The click of a second button, e.g. the right

button, could then be mimicked with another

VISAPP 2009 - International Conference on Computer Vision Theory and Applications

568

posture. We experienced that extending another

finger is not comfortable for the user, while it is

much easier to close the hand. Using this posture,

the forefinger tip cannot be used anymore as 3D

marker, and another reference point, for instance the

centre of the palm, can be chosen.

The proposed hand tracking system uses two

cameras to reconstruct the (x,y,z) position of the

marker and of the hand posture. The two cameras

are located on the sides of the desktop where the

user sits and are positioned and oriented in order to

observe a common area, the active area, where the

user can move its hand.

Our approach works in two phases. First, the

information about 2D marker position and perceived

hand posture are extracted from each image stream

separately. Then, these data are combined in order to

obtain precise 3D information. The rationale of this

approach is that the 2D information can be obtained

in a fast and reliable way, and that processing

separately the two image streams allows the two

threads to be executed in parallel on multi-cpu or

multi-core based architecture, guaranteeing a

substantial improvement of the execution times.

The result is a simple and computationally fast

system, which is very robust against noise and

cluttered backgrounds. The outline of the proposed

hand tracking system is the following.

After initializing some of the parameters used by

the system, the two image streams are processed

separately. This step involves three processes:

1. Detection/ tracking: identifies in the

incoming image the user hands and

tracks it along the video sequence.

2. Segmentation: extracts the silhouettes of

the hand from the incoming image.

3. Recognition: identifies the posture of the

hand and the 2D marker position.

Finally, stereoscopy is used to combine 2D

information and to obtain the required 3D marker

posture and hand gesture. In the following, the

single components of these processes will be

described in details.

2.1 Initialization

Initialization is an offline process that involves

several system’s parameters.

First, the camera needs to be calibrated. This

process establishes a relation between the image

planes of the cameras and a fixed reference system

in the 3D world. In this work we used the approach

described in the Open Computer Vision Library

(n.d.).

Second, since the tracking algorithm uses a

probability distribution image of the chromatic

components of the objects to be tracked, a reference

colour model needs to be initialized. In this case, we

are interested in detecting skin-like pixels. It has

been demonstrated (Bradski, 1998) that different

skin colour models are not needed for different races

of people. This fact allows building a priori a skin

model that can be used to identify the hand. This is

modelled with a simple chromaticity histogram,

created interactively by selecting a part of the image

corresponding to the hand. The RGB values of the

pixels of the selected region are converted into the

Hue Saturation Value (HSV) colour system,

allowing to create a simple colour model taking 1D

histograms from the hue channel.

2.2 Single-stream Processing

Single stream processing is based on the approach

presented by Bottino and Laurentini (2007). It

combines several computer vision algorithms, in

order to exploit their strengths and to minimize their

weakness.

2.2.1 Detection/ Tracking

The detection/tracking module is a state machine,

whose state diagram is shown in Figure 2. In the

detection state, the input image is processed until a

hand enters the image. Then, in the tracking state,

the hand is tracked until it exits the image.

Figure 2: Detection/ tracking module.

This module uses two different algorithms: Mean

shift (Cheng, 1995) for object detection and

CAMShift (Bradski, 1998) for object tracking.

The input of both algorithms is a probability

image, where pixels more likely to belong to the

searched object have a higher value. This probability

image is obtained by back projecting on the image

the chromaticity histogram evaluated during the

initialization step. The probability image is then

filtered, as suggested by Bradski (1998), in order to

ignore pixels whose hue value is not reliable. An

example of an image frame and its corresponding

A FAST AND ROBUST HAND-DRIVEN 3D MOUSE

569

probability image is shown in Figure 3a and Figure

3b.

Mean shift uses a search window, whose size is

fixed, which is iteratively moved along the image

“climbing” the probability distribution until the

optimum is reached. At each step, the centre of mass

of the search windows is evaluated and the search

window is centred on it. In our implementation, in

order to avoid systematic errors, the initial position

of the search window is randomly set in several

positions of the image. The final location giving the

best score is chosen (Figure 3c and Figure 3d). To

find when an object is detected, the percent of

object-like pixels in the search window is compared

with a pre-defined threshold.

CAMShift is a generalization of the Mean shift.

While Mean shift is designed for static distributions,

CAMShift is designed for dynamically changing

distributions, such as those occurring in video

sequences where the tracked object moves, so that

size and location of the probability distribution

change in time. Hence, at every iteration, also the

size of the search windows is adapted to the

incoming distribution. Again, to find when an object

is lost, the percent of object-like pixels in the search

window is compared with a pre-defined threshold.

The output of this module is a flag indicating if the

object has been detected and the region R where it is

located.

Figure 3: a) An incoming image and b) the corresponding

histogram back projection. c) The initial detection region.

d) The Mean Shift moves the R region to the optimum.

2.2.2 Segmentation

The segmentation module, given position and

dimension of R, extracts the silhouette of the hand

from the probability image. First, the probability

image is thresholded in order to obtain a binary

image. Then, morphological operators are applied to

remove spurious pixels and holes are removed with

a flood fill algorithm. Finally, the bounding box of

the main connected component contained in the

search window is evaluated. Any further processing

on the images will take place only on this Region of

Interest (ROI), reducing the computational burden.

Other disturbing connected components, not

belonging to the hand, are discarded (Figure 4).

Figure 4: segmentation process. a) source image, b)

probability image and R region, c) thresholded image, d)

the main connected component in R and the correspondng

ROI.

2.2.3 Recognition

The input of this process is the silhouette of the

moving object and the R and ROI regions. The

output is the 2D position of the marker and the

posture of the hand.

A simple 3D model of the hand is used to

reconstruct the desired information. It is composed

by one to three ellipsoids, depending on the gesture

to represent. Each ellipsoid is represented in matrix

form as x’Qx, where x’ = [x y z 1] and Q is a

coefficient matrix. Using this representation, every

transformation (translation, rotation, scaling) can be

applied to the model with a simple matrix

multiplication. The model has 7 degrees of freedom,

3 for the position, 3 for the orientation and 1 for the

posture, which determines also the number of

ellipsoids composing the model. The posture can

assume three discrete values: 0, hand closed 1, hand

closed with the forefinger extended, and 2, hand

closed with thumb and forefinger extended. The

three postures, the shapes of the corresponding

models and the assigned values are shown in Figure

5. The projections of the ellipsoids on a plane are

quadrics and can be obtained, again, with a simple

multiplication between matrices. Then, knowing the

VISAPP 2009 - International Conference on Computer Vision Theory and Applications

570

projection matrix obtained from calibration is

sufficient to project the model on the image plane.

Figure 5: the three hand postures identifiable, the

corresponding model shape and the assigned value.

The state of the model is reconstructed using the

ICondensation algorithm (Liu and Jia, 2004), which

is a combination of the statistical technique of

importance sampling with the Condensation

algorithm (Isard and Blake, 1998). Basically, it tries

to approximate the unknown statistic distribution of

the state of a process with a discrete set of samples

and associated weights. This set evolves iteratively

from an initial set of random samples, and at each

step t their weights are updated. From these weights,

it is possible to predict the probability distribution

over the search space at time t+1. Thus, samples

with higher probability are more likely to be

propagated over time. The process is iterated for a

predefined number of steps, and the final state is

given by the weighted sum of the final samples. In

our case, each sample represents a model state and

the weighting function is defined from the projection

of the model on the image plane. Given I

, the result

of the exor of model projection and silhouette of the

hand, the weight of the sample s is given by:

∑

∈

Iyx

yxI

),(

),(1

(1)

The initial set is created from random samples in

the neighborhood of an initial guess of the hand

state. This is obtained from an analysis of the

incoming silhouette, which works as follows. From

the segmentation process we have the R and ROI

regions (Figure 6). The palm of the hand as a high

probability to fall into R, while finger pixels are

mainly in the area (ROI-R). Therefore, R can be

used to extract 2D position and orientation of the

palm.

The first order moments of R give a reasonable

indication of the centre of the palm, while dimension

and orientation of the ellipse corresponding to the

palm can be deduced from the covariance ellipse

built on the second order moments. From these

parameters, we can obtain, given the dimension of

the user hand, a rough approximation of the distance

from the camera and of the orientation of the

ellipsoid corresponding to the 3D palm. An initial

indication of the hand gesture can be obtained

analyzing the moments of the ROI region. In

particular, the third order moments give us an

indication of the asymmetry of the image along its

principal axes. A significant asymmetry along the

major axis is a strong indication of the forefinger

presence, while a significant asymmetry along the

minor axis is an indication of the thumb presence.

Figure 6: ROI, external rectangle, and R, inner rectangle.

Figure 7: Marker identification. a) Input data: model (left)

and silhouette (right). b) The model is used to mask the

palm. c) Curvature evaluation of boundary points. d) The

marker is located on the point with maximum curvature.

The output of Icondensation is then used to

identify precisely the 2D position of the marker. If

the posture is 0 (closed hand), the marker is given by

the centre of the projection of the 3D palm.

Otherwise, we identify the fingertip projecting the

palm on the image and using it to mask the region

corresponding to the forefinger. In case the posture

is 2, the connected component of interest is the one

overlapping the projection of the 3D ellipsoid

corresponding to the forefinger. Identification of the

marker position is based on the analysis of the local

curvature of the boundary of the obtained region.

The farthermost point at maximal curvature away

from the centre of the projection of the palm is taken

as the 2D position of the fingertip. An example can

be seen in Figure 7.

A FAST AND ROBUST HAND-DRIVEN 3D MOUSE

571

2.2.4 Merging

The merging process involves two steps:

• A reconstruction step, where the 3D

position of the marker and the hand posture

are reconstructed on the base of the

information evaluated from the left and

right images

• A data filtering step, where a Kalman filter

is used to smooth the noise in the extracted

data

Regarding the first step, the hand posture is

evaluated by means of the following voting scheme:

Table 1: The voting scheme used to evaluate the hand

posture.

012

112

222

Left Camera Pose

Right

Camera

Pose

As a matter of facts, one or more fingers can be

hidden in one image, but visible in the other. If the

posture number indicates the number of extended

fingers, our voting scheme will choose the maximal

value identified for left and right posture.

When the posture is 0 or when the forefinger is

visible in both images, the 3D marker position is

evaluated intersecting the lines back projection in

3D the marker positions on the image planes from

the corresponding optical centres. The line equation

is evaluated by pseudo inverting the projection

matrix. Due to the noise introduced by the previous

reconstruction processes, the lines unlikely intersect

each other. So we choose as intersection the point at

minimal distance from both lines.

When a reference point, such as the fingertip in

our example, is visible in only one image, the

marker position can be reconstructed in the

following way. First, we assume that the forefinger

tip lies on the principal plane of symmetry of the

hand. Then we extract the orientation of this plane,

P, from the model corresponding to the image where

the forefinger is visible. Finally, we take the plane P’

parallel to P and passing through the 3D position of

the palm centre and we intersect it with the line back

projecting the visible forefinger tip.

3 SYSTEM EVALUATION

The proposed hand tracking device has been

implemented and tested on a PC with an Intel

DualCore E6600 CPU, 1GB of RAM. The frame

grabber used for image capturing is a cost-effective

PCI capture board and guarantees an overall 240

color frames per second. The system includes two

color cameras, with maximal frame rate of 50 fps,

and 752x582 color images. According to the

literature on the subject and referring to the available

commercial products, the device can be evaluated

according to a set of desirable characteristics.

3.1 Robustness

For robustness we mean the quality of being able to

cope well with variations in the operating

environment with minimal loss of functionality.

Initialization and Re-initialization. Since the hand

is continuously entering and exiting the active area,

the system must guarantee a robust identification of

the hand presence. In a single image stream, when

the hand is tracked, the CAMShift algorithm

provides useful information on the object identified

in order to understand when it exits the image. At

the same time, Mean shift can recover very

efficiently the object as soon as it enters again the

image. Distributing casually the search window over

the image allows easily to “hook” the object and

then to identify its position. Therefore, we can state

that the system provides robust initialization and re-

initialization of the tracking components at thread

level, which is reflected into the robustness of the

two integrated streams.

Cluttered Backgrounds. The system is not sensible

to non uniform backgrounds or moving objects,

unless their chromatic distribution is not similar to

the one of the tracked object. Examples can be seen

in Figure 3 and Figure 4, where a complex

background is present. Some small groups of pixels

not belonging to the hand can be present in the

probability image, but they are discarded during

segmentation. For skin-like objects entering the

image, such as leather tissues, we stress that the

CAMShift algorithm is very robust against

distracters. Once CAMShift is locked onto the mode

of a colour distribution, it will tend to ignore other

nearby but non-connected distributions.

It is true, however, that some problems can be

caused when the disturbing object and the hand form

a connected component or when a disturbing object,

whose area is bigger then the identification

threshold, is detected in the image when no hand is

present. This produces false hand identification.

Independence from Illumination. The system is

guaranteed to work for a wide range of variations of

VISAPP 2009 - International Conference on Computer Vision Theory and Applications

572

illumination intensity since the segmentation process

is theoretically independent from the illumination

conditions. However, if the global illumination falls

below a certain threshold, the segmentation

algorithm does not give good results anymore. The

same problem happens when the global level of

illumination is too high, for instance for direct

sunlight hitting the working area, since the camera

saturates.

3.2 Computational Manageability

The machine used during the test can be considered

as a medium cost processing unit (the complete

system, including capture board and camera has a

cost lower than 1.500€). Processing the image

streams at a frame rate of 25 frames/sec, the mean

latency is 20ms, and each single CPU is used at 30%

of its capacity. The maximal mean update rate of 50

updates/sec. A faster computational unit guarantees

to run the system reliably at 50 Hertz, which is

adequate to the frequencies of normal gestures in

human-computer interaction.

Figure 8: a) The test application. b) Selecting and moving

3D objects.

We developed, for test purpose, a simple VR

application shown in Figure 8. The user can move

the pointer (represented by a sphere), select and drag

objects around the virtual world and change the

user’s view (see Figure 1 for a schematic

representation). When the VR application is running

another 25% of a single core is used. This

demonstrates that there are resources available for

other tasks, and that the system can be effectively

used as an input device for other applications.

3.3 Performances of the HT System

Ground truth data was used to derive a quantitative

measure of tracker’s accuracy. Taken a grid of

points whose 3D position is known, the accuracy can

be evaluated through the difference between the 3D

positions reconstructed from the 2D projections of

the reference points and the ground truth data. Since

the accuracy is not constant, the reference points

must be located throughout the active area, in order

to evaluate a mean accuracy value. As a result, we

obtain an accuracy of 1.40 mm RMS.

The resolution is the minimal difference between

two 3D positions detectable as different from the

tracker that is when their projections on the image

planes are different, the minimal distance being one

pixel. Therefore the resolution is given by the ray of

the sphere enclosing all the 3D points obtained by

back projecting 2D image points at one pixel

distance point with the reference projection. Also the

resolution is not uniform in the active area and the

punctual resolution is computed and averaged over

the set of reference points. The obtained mean

resolution is 0.79 mm RMS.

Jitter and drift can be computed by placing the

forefinger in a fixed position and computing the

standard deviation of the reference position. The

resulting jitter is 0.46 mm RMS, and the drift is null.

The last result comes from the fact that none of the

algorithms used introduce any drift in its output. It

should be also outlined the fact that the jitter is

lower then the tracker resolution, producing a stable

output.

The characteristics of the tracker are summarized

in Table 2. These results show that the tracker

provides a sufficient precision for many

applications.

Table 2: Summary of tracker characteristics.

spatial position (3)

Jitter

0.4 mm RMS

hand posture (1)

Drift

none

Accuracy

1.4 mm RMS

Latency

20 ms

Resolution

0.8 mm RMS

Update Rate

>25 Hz

Tracker

data

4 CONCLUSIONS

In this paper we have proposed a novel hand

tracking system that can be used as object

manipulation interface to use the bare hand for

navigation, selection and manipulation tasks in

virtual environments. The system is non intrusive,

and reconstructs the position of a 3D marker and

simple hand postures using two separate image

streams. Each stream is processed separately with a

monoscopic algorithm, which is very robust against

noise and cluttered backgrounds. This allows

reducing computing times parallelizing the

processing of the two streams on multi-core or

multi-cpu machines. Information from the two

image planes are then combined in order to

reconstruct the required 3D data.

The system has been implemented, and the tests

demonstrates that it can run in real time (up to 50

A FAST AND ROBUST HAND-DRIVEN 3D MOUSE

573

samples per second) on today’s desktop computer

using off-the-shelf hardware components. Moreover,

the device uses only the 30% of the computing

resources, allowing the execution on the same

machine of other applications. As for precision, the

results are satisfactory, showing an accuracy of

1.4mm, a resolution of 0.8mm and a jitter of 0.4

mm.

At present, the system requires that only one

hand is present in the active area. As future work,

we are planning to expand the system in order to use

both hands for interaction.

REFERENCES

Akyol S., Alvarado P., 2001. ‘Finding Relevant Image

Content for mobile Sign Language Recognition’,

Proc. Signal Processing, Pattern Recognition and

Application, pp. 48-52

Bottino A., Laurentini A., 2007. ‘How to Make a Simple

and Robust 3D Hand Tracking Device Using a Single

Camera’, CSCC 2007, Agios Nikolaos, Greece.

Bray M., Koller-Meier E., Van Gool, L., 2004, ‘Smart

particle filtering for 3D hand tracking’, Proc. IEEE

Intern. Confer. on Automatic Face and Gesture

Recognition, pp. 675 – 680

Bradski G. R., 1998. ‘Computer Vision Face Tracking For

Use in a Perceptual User Interface’, Intel Technology

Journal (2), pp. 215.

Chen F.-S., Fu C.-M., Huang C.-L., 2003. ‘Hand Gesture

Recognition Using a Real-Time Tracking Method and

Hidden Markov Models’, Image and Vision

Computing vol. 21, August, pp. 745-758

Cheng Y., 1995. ‘Mean shift, mode seeking, and

clustering’, IEEE Trans. PAMI., vol. 17, pp. 790-799

Cui Y., Weng J., 2000. ‘Appearance-Based Hand Sign

Recognition from Intensity Image Sequences’.

Computer Vision Image Understanding, vol. 78,

February, pp. 157-176

Drummond T., Cipolla R., 2002. ‘Real-time visual

tracking of complex structures’. IEEE Trans. PAMI,

vol. 24, July, pp. 932–946.

Erol A., Bebis G., Nicolescu M., Boyle R. D., Twombly

X., 2007. ‘Vision-based hand pose estimation: A

review’. Computer Vision and Image Understanding

vol. 108, pp. 52–73

Gumpp T., Azad P., Welke K., Oztop E., Dillmann R.,

Cheng G., 2006. ‘Unconstrained Real-time Markerless

Hand Tracking for Humanoid Interaction’. Proc. of

6th IEEE-RAS Intern. Conf. on Humanoid Robots, pp.

88-93

Haiting Zhai, Xiaojuan Wu, Hui Han, 2005. ‘Research of

a Real-time Hand Tracking Algorithm’. Proc. of

ICNN&B 2005

Heap T., Hogg D., 1996. ‘Towards 3D hand tracking using

a deformable model’, Proc. of International

Conference on Automatic Face and Gesture

Recognition, pp. 140-145

Isard M., Blake A., 1998. ‘CONDENSATION -

conditional density propagation for visual tracking’,

Int. J. Computer Vision, vol. 29, pp. 5-28

Isard M., Blake A., 1998. ‘ICondensation: Unifying Low-

Level and High-Level Tracking in a Stochastic

Framework’, Proc. ECCV98, pp. 5-28

Letessier J., Bèrard F., 2004. ‘Visual tracking of bare

ﬁngers for interactive surfaces’, Procs. of UIST ’04:

17th Annual ACM symposium on User Interface

Software and Tec

Liu N., Lovell B., Kootsookos P., 2003. ‘Evaluation of

hmm training algorithms for letter hand gesture

recognition’, Proc. ISSPIT 2003, Darmstadt, Germany

Liu Y., Jia Y., 2004. ‘A Robust Hand Tracking and

Gesture Recognition Method for Wearable Visual

Interfaces and Its Applications’, Proc. of 3rd Int. Conf.

on Image and Graphgics IEEE

Mahmoudi F., Parviz M., 2006. ‘Visual Hand Tracking

Algorithms’, Geometric Modeling and Imaging--New

Trends, vol. 5/6, pp. 228 – 232

Oka K., Sato Y., Koike H., 2002. ‘Real-time tracking of

multiple ﬁngertips and gesture recognition for

augmented desk interface systems’, Proc of FGR ’02,

p. 429.

Olafsdottir, H. et al. Is the thumb a fifth finger? A study of

digit interaction during force production tasks. Exp

Brain Res (2005) 160: 203–213

Open Computer Vision Library, [on-line], Available:

http://sourceforge.net/ projects/opencvlibrary/

Pantrigo J.J., Montemayor A.S., Sanchez A., 2005. ‘Local

search particle filter applied to human-computer

interaction’, Proc. of ISPA’05, pp. 279 - 284

Shan Lu, Metaxas D., Samaras D., Oliensis J., 2003.

‘Using multiple cues for hand tracking and model

refinement’, Proc. IEEE Conf. on Computer Vision

and Pattern Recognition 2003, vol. 2, pp. 443-450.

Shan C., Wei Y., Tan T., Ojardias F., 2004. ‘Real time

hand tracking by combining particle filtering and

mean shift’, Proc. FG2004, pp. 669-674

Stenger B., Mendonca P.R.S., Cipolla R., 2001. ‘Model-

based 3D tracking of an articulated hand’, Proc. IEEE

CVPR 2001 vol. 2, pp. II-310 - II-315

Stenger B., Thayananthan A., Torr P. H. S., Cipolla R.,

2004. ‘Hand pose estimation using hierarchical

detection’, Proc. of Intl. Workshop on Human-

Computer Interaction 2004.

Tomasi C., Petrov S., Sastry A., 2003. ‘3D Tracking =

Classiﬁcation + Interpolation’, Ninth IEEE

International Conference on Computer Vision, vol, 2,

pp. 1441–1448

Yang Liu, Yunde Jia, 2004. ‘A robust hand tracking for

gesture-based interaction of wearable computers’,

Proc. ISWC 2004, pp. 22 - 29

Yang Liu, Yunde Jia, 2004. ‘A robust hand tracking and

gesture recognition method for wearable visual

interfaces and its applications’, Proc. International

Conference on Image and Graphics ICIG 2004, pp.

472 – 475

VISAPP 2009 - International Conference on Computer Vision Theory and Applications

574
