MULTI-CLASS FROM BINARY

Divide to conquer

Anderson Rocha and Siome Goldenstein

Institute of Computing

University of Campinas (Unicamp), Campinas, Brazil

Keywords:

Multi-class classiﬁcation, Error correcting output codes, ECOC, Afﬁne Bayes, Bayesian approach.

Abstract:

Several researchers have proposed effective approaches for binary classiﬁcation in the last years. We can

easily extend some of those techniques to multi-class. Notwithstanding, some other powerful classiﬁers (e.g.,

SVMs) are hard to extend to multi-class. In such cases, the usual approach is to reduce the multi-class problem

complexity into simpler binary classiﬁcation problems (divide-and-conquer). In this paper, we address the

multi-class problem by introducing the concept of afﬁne relations among binary classiﬁers (dichotomies), and

present a principled way to ﬁnd groups of high correlated base learners. Finally, we devise a strategy to reduce

the number of required dichotomies in the overall multi-class process.

1 INTRODUCTION

Supervised learning is a Machine Learning strategy to

create a prediction function from training data. The

task of the supervised learner is to predict the value

of the function for any valid input object after having

seen a number of training examples (Bishop, 2006).

Many supervised learning techniques are conceived

for binary classiﬁcation (Passerini et al., 2004). How-

ever, a lot of real-world recognition problems often

require that we map inputs to one out of hundreds or

thousands of possible categories.

Several researchers have proposed effective ap-

proaches for binary classiﬁcation in the last years.

Successful examples of such approaches are margin

and linear classiﬁers, decision trees, and ensembles.

We can easily extend some of those techniques to

multi-class problems (e.g., decision trees). However,

we can not easily extend to multi-class some others

powerful and popular classiﬁers such as SVMs. In

such situations, the usual approach is to reduce the

multi-class problem complexity into multiple simpler

binary classiﬁcation problems. Binary classiﬁers are

more robust to the curse of dimensionality than multi-

class approaches. Hence, it is worth dealing with a

larger number of binary problems.

A class binarization is a mapping of a multi-class

problem onto several two-class problems (divide-and-

conquer) and the subsequent combination of their out-

comes to derive the multi-class prediction (Pedrajas

and Boyer, 2006). We refer to the binary classiﬁers as

base learners or dichotomies.

There are many possible approaches to reduce

multi-class to binary classiﬁcation problems. We can

classify such approaches into three broad groups (Pu-

jol et al., 2006): (1) One-vs-All (OVA), (2) One-

vs-One (OVO), and (3) Error Correcting Out-

put Codes (ECOC). Also, the multi-class decomposi-

tion into binary problems usually contains three main

parts: (1) the ECOC matrix creation; (2) the choice of

the base learner; and (3) the decoding strategy.

Our focus here is on the creation of the ECOC ma-

trix and on the decoding strategy. For the creation of

the ECOC matrix, it is important to choose a feasible

number of dichotomies to use. In general, the more

base learners we use, the more complex is the overall

procedure. For the decoding strategy, it is essential to

choose a deterministic strategy robust to ties and er-

rors in the dichotomies’ prediction.

In this paper, we introduce a brand new way to

combine binary classiﬁers to perform large multi-

class classiﬁcation. We present a new Bayesian

treatment for the decoding strategy, the Afﬁne-Bayes

Multi-class. We propose a decoding approach based

on the conditional probabilities of groups of high-

correlated binary classiﬁers. For that, we introduce

323

Rocha A. and Goldenstein S.

MULTI-CLASS FROM BINARY - Divide to conquer.

DOI: 10.5220/0001777803230330

In Proceedings of the Fourth International Conference on Computer Vision Theory and Applications (VISIGRAPP 2009), page

ISBN: 978-989-8111-69-2

the concept of afﬁne relations among binary clas-

siﬁers and present a principled way to ﬁnd groups

of high correlated dichotomies. Furthermore, we

present a strategy to reduce the number of required

dichotomies in the multi-class process.

Contemporary Vision and Pattern Recognition

problems such as face recognition, ﬁngerprinting

identiﬁcation, image categorization, DNA sequencing

among others often have an arbitrarily large number

of classes to cope with. Finding the right descriptor

is just a ﬁrst step to solve a problem. Here, we show

how to use a small number of simple, fast, and weak

or strong base learners to get better results, no matter

the choice of the descriptor. This is a relevant issue

for large-scale classiﬁcation problems.

We validate our approach using data sets from the

UCI repository, NIST, Corel Photo Gallery, and the

Amsterdam Library of Objects. We show that our ap-

proach provides better results than OVO, OVA, and

ECOC approaches based on other decoding strate-

gies. Furthermore, we also compare our approach to

Passerini et al. (Passerini et al., 2004), who proposed

a Bayesian treatment for decoding assuming indepen-

dence among all binary classiﬁers.

2 STATE-OF-THE-ART

Most of the existing literature addresses one or more

of the three main parts of a multi-class decomposi-

tion problem: (1) the ECOC matrix creation; (2) the

dichotomies choice; and (3) the decoding.

In the following, let T be the team (set) of used

dichotomies D in a multi-class problem, and N

the size of T . Recall that N

is the number of classes

There are three broad groups for reducing multi-

class to binary: One-vs-All, One-vs-One, and Error

Correcting Output Codes based methods (Pedrajas

and Boyer, 2006).

1. One-vs-All (OVA). Here, we use N

= N

O(N

) binary classiﬁers (dichotomies) (Clark and

Boswell, 1991; Anand et al., 1995). We train the

classiﬁer using all patterns of class i as pos-

itive (+1) examples and the remaining class pat-

terns as negative (−1) examples. We classify an

input example x to the class with the highest re-

sponse.

2. One-vs-One (OVO). Here, we use





= O(N

) binary classiﬁers.

We train the ij

dichotomy using all patterns

of class i as positive and all patterns of class j

as negative examples. In this framework, there

In the Appendix, we provide a table of symbols.

are many approaches to combine the obtained

outcomes such as voting, and decision directed

acyclic graphs (DDAGs) (Platt et al., 1999).

3. Error Correcting Output Codes (ECOC). Pro-

posed by Dietterich and Bakiri (Dietterich and

Bakiri, 1996), in this approach, we use a coding

matrix M ∈ {−1, 1}

×N

to point out which

classes to train as positive and negative examples.

Allwein et al. (Allwein et al., 2000) have extended

such approach and proposed to use a coding ma-

trix M ∈ {−1, 0 , 1}

×N

. In this model, the

column of the matrix induces a partition of

the classes into two meta-classes. An instance x

belonging to a class i is a positive instance for

the j

dichotomy if and only if M

= +1.

If M

= 0, then it indicates that the i

class

is not part of the training of the j

dichotomy.

In this framework, there are many approaches

to combine the obtained outcomes such as vot-

ing, Hamming and Euclidean distances, and loss-

based functions (Windeatt and Ghaderi, 2003).

When the dichotomies are margin-based learners,

Allwein et al. (Allwein et al., 2000) have showed

the advantage and the theoretical bounds of us-

ing a loss-based function of the margin. Klau-

tau et al. (Klautau et al., 2004) have extended such

bounds to other functions.

Pedrajas et al. (Pedrajas and Boyer, 2006) have

proposed to combine the strategies of OVO and

OVA. Although the combination improves the over-

all multi-class effectiveness, the proposed approach

uses N





+ N

= O(N

) dichotomies

in the training stage. Moreira and Mayoraz (Mor-

eira and Mayoraz, 1998) also developed a combi-

nation of different classiﬁers. They have consid-

ered the output of each dichotomy as a probability

of the pattern of belonging to a given class. This

method requires

+1)

= O(N

) base learners.

Athisos et al. (Athisos et al., 2007) have proposed

class embeddingsto choose the best dichotomies from

a set of trained base learners.

Pujol et al. (Pujol et al., 2006) have pre-

sented a heuristic method for learning ECOC ma-

trices based on a hierarchical partition of the class

space that maximizes a discriminative criterion.

The proposed technique ﬁnds the potentially best

− 1 = O(N

) dichotomies to the classiﬁ-

cation. Crammer and Singer (Crammer and Singer,

2002) have proven that the problem of ﬁnding opti-

mal discrete codes is NP-complete. Hence, Pujol et al.

have used a heuristic solution for ﬁnding the best can-

didate dichotomies. Even such solution is computa-

tionally expensive, and the authors only report results

for N

≤ 28.

VISAPP 2009 - International Conference on Computer Vision Theory and Applications

324

Takenouchi and Ishii (Takenouchi and Ishii, 2007)

have used the information transmission theory to

combine ECOC dichotomies. The authors use the

full coding matrix M for the dichotomies, i.e.,

−2

= O(3

) dichotomies. The

authors only report results for N

≤ 7 classes.

Young et al. (Young et al., 2006) have used dy-

namic programming to design an one-class-at-a-time

removal sequence planning method for multi-class

decomposition. Although their approach only re-

quires N

= N

−1 dichotomies in the testing phase,

the removal policy in the training phase is expensive.

The removal sequence for a problem with N

classes

is formulated as a multi-stage decision-making prob-

lem and requires N

− 2 classiﬁcation stages. In the

ﬁrst stage, the method uses N

dichotomies. In each

one of the N

− 3 remaining stages, the method uses

−1)

dichotomies. Therefore, the total number

of required base learners are

−4N

+5N

= O(N

Passerini et al. (Passerini et al., 2004) have intro-

duced a decoding function that combines the margins

through an estimate of their class conditional proba-

bilities. The authors have assumed that all base learn-

ers are independent and solved the problem using a

Na¨ıve Bayes approach. Their solution works regard-

less of the number of selected dichotomies and can be

associated with each one of the previous approaches.

3 AFFINE-BAYES MULTI-CLASS

In this section, we present our new Bayesian treat-

ment for the decoding strategy: the Afﬁne-Bayes

Multi-class. We propose a decoding approach based

on the conditional probabilities of groups of afﬁne bi-

nary classiﬁers. For that, we introduce the concept of

afﬁne relations among binary classiﬁers, and present

a principled way to ﬁnd groups of high correlated di-

chotomies. Finally, we present a strategy to reduce

the number of required dichotomies in the multi-class

classiﬁcation.

To classify an input, we use a team of trained base

learners T . We call O

a realization of T . Each

element of T is a binary classiﬁer (dichotomy) and

produces an output ∈ {−1, +1}. Given an input el-

ement x to classify, a realization O

contains the in-

formation to determine the class of x. In other words,

P (y = c

|x) = P (y = c

However, we do not have the probability

P (y = c

| O

). From Bayes theorem,

P (y = c

) =

P (O

|y = c

)P (y = c

)

P (O

)

∝ P (O

|y = c

)P (y = c

) (1)

P (O

) is just a normalizing factor and it is sup-

pressed.

Previous approaches have solved the above model

by considering the independence of the dichotomies

in the team T (Passerini et al., 2004). If we con-

sider independence among all dichotomies, the model

in Equation 1 becomes

P (y = c

) ∝

t ∈ T

P (O

|y = c

)P (y = c

(2)

and the class of the input x is

cl(x) = arg max

t ∈ T

P (O

|y = c

)P (y = c

Although the independence assumption simpliﬁes

the model, it comes with limitations and it is not the

best choice in all cases (Narasimhamrthy, 2005). In

general, it is quite difﬁcult to solve independence

without using smoothing functions to deal with

numerical instabilities when the number of terms in

the series is too large. In such cases, it is necessary

to ﬁnd a suitable density distribution to describe the

data, making the solution more complex.

We relax the assumption of independence among

all binary classiﬁers. When two of these dichotomies

have a lot in common, it would be unwise to threat

their results as independent random variables (RVs).

In our approach, we ﬁnd groups of afﬁne classiﬁers

(high correlated dichotomies) and represent their out-

comes as dependent RVs, using a single conditional

probability table (CPT) as an underlying distribution

model. Each group then has its own CPT, and we

combine the groups as if they are independent from

each other — to avoid a dimensionality explosion.

Our technique can be interpreted as a Bayesian

Network inspired approach for RV estimation. We

decide the RV that represent the class based on the

RVs that represent the outcomes of the dichotomies.

We model the multi-class classiﬁcation problem

conditioned to groups of afﬁne dichotomies G

. The

model in Equation 1 becomes

P (y = c

, G

) ∝ P (O

, G

|y = c

)P (y = c

(3)

We assume independence only among the groups of

afﬁne dichotomies g

∈ G

. Therefore, the class of

an input x is given by

cl(x) = arg max

∈ G

P (O

, g

|y = c

)P (y = c

(4)

To ﬁnd the groups of afﬁne classiﬁers G

, we deﬁne

an afﬁnity matrix A among the classiﬁers. The afﬁn-

ity matrix measures how afﬁne are two dichotomies

when classifying a set of training examples X. In

Section 3.1, we show how to create the afﬁnity ma-

trix A. After calculating the afﬁnity matrix A, we use

MULTI-CLASS FROM BINARY - Divide to conquer

325

a clustering algorithm to ﬁnd the groups of correlated

binary classiﬁers in A. In Section 3.2, we show how

to ﬁnd the groups of afﬁne dichotomies from an afﬁn-

ity matrix A.

The groups of afﬁne classiﬁers can contain classi-

ﬁers that do not contribute signiﬁcantly to the overall

classiﬁcation. Therefore, we can deploy a procedure

to identify the less important dichotomies within an

afﬁne group and eliminate them. In this stage, we are

able to reduce the number of required dichotomies

to perform the multi-class classiﬁcation and hence

speed-up the overall process and make robust CPTs

estimations. In Section 3.3, we show a consistent

approach to eliminate the less important dichotomies

within an afﬁne group.

In Algorithm 1, we present the main steps of our

model for multi-class classiﬁcation. In line 1, we di-

vide the training data into ﬁve parts and use four parts

to train the dichotomies and one part to validate the

trained dichotomies and to construct the conditional

probability tables. In lines 3–6, we train and validate

each dichotomy using a selected method. The method

can be any binary classiﬁer such as LDA, or SVM.

Each dichotomy produces an output ∈ {−1, +1 } for

each input x. In line 8, O contains all realizations of

the available dichotomies for the input data X

′

. In

lines 10 and 11, we ﬁnd groups of afﬁne dichotomies

using the realization O

. Using the information of

groups of afﬁne dichotomies, in line 12, we create a

CPT for each afﬁne group. These CPTs provide the

joint probabilities of a realization O

and the afﬁne

groups g

⊂ G

when testing an unseen input data

x. In line 13, our approach ﬁnds the best dichotomies

within the afﬁne groups. This information can be used

in the testing phase to reduce the number of used di-

chotomies.

3.1 Afﬁnity Matrix A

Given a training data set X, we introduce a metric to

ﬁnd the afﬁnity between two dichotomies realizations

, D

whose outputs ∈ {−1, +1}

i,j



∀ x ∈ X

(x)D

(x)



, ∀ D

and D

∈ T .

(5)

According to the afﬁnity model, if two dichotomies

have the same output for all elements in X, their afﬁn-

ity is 1. For instance, this is the case when D

= D

If D

6= D

in all cases, their afﬁnity is also 1. On

the other hand, if two dichotomies have half outputs

different and half equal, their afﬁnity is 0. Using this

model, we can group binary classiﬁers that produce

similar outputs and, further, eliminate those which do

not contribute signiﬁcantly to the overall classiﬁca-

tion procedure.

Algorithm 1 Afﬁne-Bayes Multi-class.

Require: Training data set X, Testing data X

, a team of

binary classiﬁers T .

1: Split X into k parts, X

such that i = 1 . . . k;

2: for each X

do ⊲ Inner k-fold cross-validation.

3: X

′

← X \ X

;

4: for each dichotomy d ∈ T do

5: D

train

← TRAIN(X

′

, d, method);

6: O

←TEST(X

, d, method, D

T rain

);

7: end for

8: O

←

);

9: end for

10: Create the afﬁnity matrix A for

;

11: Perform clustering on A to ﬁnd the afﬁne groups of

dichotomies G

;

12: Create a CPT for each group g ⊂ G

of afﬁne di-

chotomies using O;

13: Perform the shrinking. GS

← SHRINK(G

);

14: for each x ∈ X

15: Perform the classiﬁcation of x from the model

on Equation 4 either using the set of afﬁne di-

chotomies G

or the shrinked GS

16: end for

3.2 Clustering

Given an afﬁnity matrix A representing the relation-

ships among all dichotomies in a team T , we want to

ﬁnd groups of classiﬁers that have similar afﬁnities.

We want to ﬁnd groups of dependent classiﬁers while

the groups are independent from one another. A good

clustering approach is important to provide balanced

groups of dichotomies. Such balancing is interesting

because it leads to simpler conditional probability ta-

bles. In this paper, we use a simple, yet effective,

greedy algorithm for ﬁnding the dependent groups of

dichotomies from the afﬁnity matrix.

In our greedy clustering approach, ﬁrst we ﬁnd the

dichotomy with the highest afﬁnity sum with respect

to all its neighbors (row with highest sum in A). Af-

ter that, we select the neighbors with afﬁnity greater

or equal than a threshold t. Next, we check if each

dichotomy in the group is afﬁne to the others and se-

lect those satisfying this requirement. This procedure

results the ﬁrst afﬁne group. Afterwards, we remove

the selected dichotomies from the main team T and

repeat the process until we analyze all available di-

chotomies. Throughout experiments, we have found

that t = 0.6 is a good threshold. We use this value in

all experiments in this paper.

VISAPP 2009 - International Conference on Computer Vision Theory and Applications

326

3.3 Shrinking

Sometimes, when modeling a problem using condi-

tional probabilities, we have to deal with large condi-

tional probability tables which can lead to over-ﬁtting.

One approach to cope with this problem is to suppose

independence among all dichotomies which results

in the smallest possible CPT. However, as we show

in this paper, this approach limits the representative

power of the Bayes approach. In the following, we

show a clever and alternative approach.

In the shrinking stage, we want to ﬁnd the di-

chotomies within a group that are more relevant for

the overall multi-class classiﬁcation. We ﬁnd the ac-

cumulative entropy of each classiﬁer within a group

from the examples in the training data X. The higher

the accumulative entropy, the more representative is a

speciﬁc dichotomy. Let h

be the accumulative en-

tropy for the classiﬁer j within a group of afﬁne di-

chotomies i. We deﬁne h

c∈C

x∈X

log

(1−p

) log

(1− p

)) (6)

where p

= P (y = c | x, g

, O

), g

is the j

dichotomy within the afﬁne group g

, O

is its real-

ization for the input x, and c ∈ C

the available class

labels.

We choose the classiﬁers with the highest cumu-

lative entropy to select the best classiﬁers within an

afﬁne group. We have found in the experiments, that

selecting 60% of the classiﬁers is a good tradeoff be-

tween multi-class overall effectiveness and efﬁciency.

One could use another cutting criteria, such as the

maximum CPT size.

During the training phase, our approach ﬁnds the

afﬁne groups of binary classiﬁers and marks the most

relevant dichotomies within each group. This infor-

mation can be used afterwards in the testing phase to

reduce the number of required classiﬁers in the multi-

class task.

In summary, with our solution, we measure the

afﬁnity on the training data to learn the binary classi-

ﬁers relationship and decision surface. It is a simple

and fast way to estimate the distribution. Sometimes,

a dichotomy may be in the team because it is criti-

cal for discriminating between two particular classes.

If so, it is unlikely it will share a group of high-

correlated classiﬁers because it would require this di-

chotomy to be high-correlated with all dichotomies in

such group. We have performed some experiments

to test that and, in all tested cases, such dichotomies

speciﬁc for rare classes are kept in the ﬁnal pool of

dichotomies.

4 EXPERIMENTS AND RESULTS

In this section, we compare our Afﬁne-Bayes Multi-

class approach to: OVO, OVA, and ECOC approaches

based on distances decoding strategies. We also com-

pare our approach to Passerini et al. (Passerini et al.,

2004) who have proposed a Bayesian treatment for

decoding assuming independence among all binary

classiﬁers.

We validate our approach using two scenarios. In

the ﬁrst scenario, we use data sets with a relative small

number of classes (N

< 30). For that, we use two

UCI

, and one NIST

data sets. In the second sce-

nario, we have considered two large-scale multi-class

applications: one for the Corel Photo Gallery (Corel)

data set and one for the Amsterdam Library of Ob-

jects (ALOI)

. Table 1 presents the main features of

each data set we have used in the validation. Recall

that, N

is the number of classes, N

if the number of

features, and N is the number of instances.

Table 1: Data sets’ summary.

Data set Source N

Mnist digits NIST 10 785 10,000

Vowel UCI 11 10 990

Isolet UCI 26 617 7,797

Corel Corel 200 128 20,000

ALOI ALOI 1,000 128 108,000

In the ECOC-based experiments, we have selected

15 random coding matrices. For each coding matrix,

we perform 5-fold cross validation. For each cross-

validation fold, we perform a 5-fold cross validation

on the training set to estimate the CPTs. In all exper-

iments, we have used the base learners: Linear Dis-

criminant Analysis (LDA) and Support Vector Ma-

chines (SVMs) (Bishop, 2006).

4.1 Scenario 1 (10–26 Classes)

In Figure 1, we compare Afﬁne-Bayes (AB) to

ECOC based on Hamming decoding (ECOC),

One-vs-One (OVO), and Passerini’s approach

(PASSERINI) (Passerini et al., 2004). In this ex-

periment, Afﬁne-Bayes uses two different coding

matrices: AB-ECOC, and AB-OVO.

The use of conditional probabilities and afﬁne

groups on Afﬁne-Bayes to decode the binary classiﬁ-

cations and produce a multi-class prediction improves

the results for OVO and ECOC coding matrices. This

http://mlearn.ics.uci.edu/MLRepository.html

http://yann.lecun.com/exdb/mnist/

http://www.corel.com

http://www.science.uva.nl/˜aloi/

MULTI-CLASS FROM BINARY - Divide to conquer

327

Accuracy (%)

Number of Base Learners (N

)

AB-ECOC

ECOC

AB-OVO

OVO

PASSERINI

5 10 15

25 30

35 40

(a) Mnist .:. Base-learner = LDA.

Accuracy (%)

Number of Base Learners (N

)

AB-ECOC

ECOC

AB-OVO

OVO

PASSERINI

(b) Vowel .:. Base-learner = LDA.

Accuracy (%)

Number of Base Learners (N

)

AB-ECOC

ECOC

AB-OVO

OVO

PASSERINI

100

150

200 250 300

Accuracy (%)

Number of Base Learners (N

)

AB-ECOC

ECOC

AB-OVO

OVO

PASSERINI

100

150

200 250 300

(d) Isolet .:. Base-learner = SVM.

Figure 1: Afﬁne-Bayes (AB) vs. ECOC vs. OVO vs. Passerini for Mnist, Vowel, and Isolet data sets considering LDA and

SVM base learners.

is also true for other UCI data sets not shown here

such as abalone, covtype, optdigits, pendigits, vowel,

and yeast. Although unsubstantiated here, through-

out experiments we have found out that Afﬁne-Bayes

also improves OVA and ECOC approaches limited to

= N

dichotomies.

Weak classiﬁers (e.g., LDA) beneﬁts more from

Afﬁne-Bayes than strong ones (e.g., SVMs). This im-

portant result shows us that when we have a problem

with many classes, it may be worth using weak clas-

siﬁers (e.g., LDA) which often are considerably faster

than strong ones (e.g., SVMs).

When possible, all one-by-one dichotomies

(OVO) produce better results. However, random se-

lection of subsets of OVO are not better than ECOC,

and Afﬁne-Bayes improves both approaches.

For the UCI and Nist small data sets, the Afﬁne

Bayes results are, in average, one standard devia-

tion above Passerini’s results when using SVM and,

at least, two standard deviations above when using

LDA. However, we have found that Passerini’s as-

sumption on independence for all dichotomies is not

as robust as Afﬁne-Bayes when the number of di-

chotomies and classes becomes larger (c.f., Sec. 4.2).

For small data sets, there is no much gain in using

anything sophisticated.

This behavior is closely related to the curse of di-

mensionality, and most papers in the literature only

show the performance going up to 30 classes which is

not useful for large-scale problems. Here, we validate

our approach for up to 1,000 classes.

4.2 Scenario 2 (200 and 1,000 Classes)

Here, we consider two large-scale Vision applica-

tions: Corel (N

= 200) and ALOI (N

= 1, 000)

categorization. In such applications, OVO is com-

putationally expensive. Sometimes, it is not advised

to use OVA at all, given that, even in this case,

the number of dichotomies and the number of el-

ements to train are too high. Hence, ECOC ap-

proaches with a few base learners are more appropri-

ate. In Figures 2(a–c), we show results using Afﬁne-

Bayes (AB-ECOC) vs. ECOC Hamming decoding

and Passerini et al. (Passerini et al., 2004) approaches

for LDA and SVM classiﬁers.

We show experiments up to 400 dichotomies in

the presence of 200 and 1,000 classes to emphasize

the performance for a small number of base learners

in comparison with the number of all possible separa-

tion choices. As we increase the number of classiﬁers,

all approaches fare steadily better, and as this number

approaches the limit, they converge to similar results.

For ALOI, the limit is



1,000



= 499, 500, much more

than the 400 we show.

As the image descriptor is not our focus in this pa-

VISAPP 2009 - International Conference on Computer Vision Theory and Applications

328

Accuracy (%)

Number of Base Learners (N

)

AB-ECOC

ABS-ECOC

ECOC

PASSERINI

100 150 200

250

300 350 400

(a) Corel Gallery .:. Base-learner = LDA.

Accuracy (%)

Number of Base Learners (N

)

AB-ECOC

ABS-ECOC

ECOC

PASSERINI

120

160

200 240

280

320 360 400

(b) ALOI .:. Base-learner = LDA.

Accuracy (%)

Number of Base Learners (N

)

AB-ECOC

ABS-ECOC

ECOC

PASSERINI

120 160 200 240 280

320

360 400

Figure 2: Afﬁne-Bayes (AB) and Afﬁne-Bayes-Shrinking (ABS) vs. ECOC vs. Passerini for two large-scale data sets.

per, we have used a simple extended color histogram

with 128 dimensions (Stehling et al., 2002). Corel

data set comprises broad-class images and it is more

difﬁcult to classify than the ALOI collection of con-

trolled objects.

Afﬁne-Bayes improves the effectiveness in the two

data sets regardless the base learner (LDA or SVM).

In both cases and for both data sets, we see that

Afﬁne-Bayes provides better results than Passerini’s

and other approaches. For ALOI and SVM base

learner, the difference is above 15 standard deviations

(∼7–8 percentual points) with respect to Passerini’s

results.

In addition, Afﬁne-Bayes with the shrinking phase

provides good results even with fewer dichotomies.

For instance, when we provide 200 dichotomies in

the training for ALOI data set, Afﬁne-Bayes (AB) pro-

vides an average accuracy of 80% while Afﬁne-Bayes-

Shrinking (ABS) provides 76% using only 135 di-

chotomies. For Corel, when we use AB with 90 di-

chotomies, the accuracy is 17% while for ABS it is

18%. Finally, in spite of the reduction in the num-

ber of dichotomies, Afﬁne-Bayes still provides better

effectiveness than previous approaches.

For more than 30 classes, the independence re-

striction play an important role. See Figure 2(b-c).

By not assuming independence, the SVM with only

200 dichotomies is more effective than the best K-

Nearest neighbors (not shown in the plots). KNN

yields ≈ 83% accuracy while our approach using

SVM and 200 dichotomies yields ≈ 88%. We can

improve even more if we use 400 dichotomies, and

yet, this is much less dichotomies than a solution us-

ing one versus all or all combinations of one versus

one.

5 CONCLUSIONS AND

REMARKS

In this paper, we have addressed two key issues of

multi-class classiﬁcation: the choice of the coding

matrix and the decoding strategy. For that, we have

presented a new Bayesian treatment for the decoding

strategy: Afﬁne-Bayes.

We have introduced the concept of afﬁne relations

among binary classiﬁers and presented a principled

way to ﬁnd groups of high correlated base learners.

Furthermore, we have presented a strategy to reduce

the number of required dichotomies in the multi-class

process.

The advantages of our approach are: (1) it works

independent of the number of selected dichotomies;

(2) it can be associated with each one of the previ-

MULTI-CLASS FROM BINARY - Divide to conquer

329

ous approaches such as OVO, OVA, ECOC, and their

combinations; (3) it does not rely on the independence

restriction among all dichotomies. (4) its implemen-

tation is simply and it uses only basic probability the-

ory; (5) it is fast and does not impact the multi-class

procedure.

Future work include the deployment of better poli-

cies to choose the coding matrix and the design of

alternative ways to store the conditional probability

tables other than sparse matrices and hashes.

ACKNOWLEDGEMENTS

We thank FAPESP (Grant 05/58103-3), and CNPq

(Grants 309254/2007-8 and 551007/2007-9) for the

ﬁnancial support.

REFERENCES

Allwein, E., Shapire, R., and Singer, Y. (2000). Reducing

multi-class to binary: A unifying approach for margin

classiﬁers. JMLR, 1(1):113–141.

Anand, R., Mehrotra, K., Mohan, C., and Ranka, S. (1995).

Efﬁcient classiﬁcation for multi-class problems using

modular neural networks. TNN, 6(1):117–124.

Athisos, V., Stefan, A., Yuan, Q., and Sclaroff, S. (2007).

Classmap: Efﬁcient multiclass recognition via embed-

dings. In ICCV.

Bishop, C. (2006). Pattern Recognition and Machine

Learning. Springer, 1 edition.

Clark, P. and Boswell, R. (1991). Rule induction with CN2:

Some improvements. In EWSL, pages 151–163.

Crammer, K. and Singer, Y. (2002). On the learnability

and design of output codes for multi-class problems.

JMLR, 47(2–3):201–233.

Dietterich, T. and Bakiri, G. (1996). Solving multi-class

problems via ECOC. JAIR, 2(1):263–286.

Klautau, A., Jevtic, N., and Orlitsky, A. (2004). On nearest-

neighbor ECOC with application to all-pairs multi-

class support vector machines. JMLR, 4(1):1–15.

Moreira, M. and Mayoraz, E. (1998). Improved pairwise

coupling classiﬁcation with correcting classiﬁers. In

ECML.

Narasimhamrthy, A. (2005). Theoretical bounds of majority

voting performance for a binary classiﬁcation prob-

lem. TPAMI, 27(12):1988–1995.

Passerini, A., Pontil, M., and Frasconi, P. (2004). New re-

sults on error correcting output codes of kernel ma-

chines. TNN, 15(1):45–54.

Pedrajas, N. and Boyer, D. (2006). Improving multi-class

pattern recognition by the combination of two strate-

gies. TPAMI, 28(6):1001–1006.

Platt, J., Christiani, N., and Taylor, J. (1999). Large mar-

gin dags for multi-class classiﬁcation. In NIPS, pages

547–553.

Pujol, O., Radeva, P., and Vitria, J. (2006). Discriminant

ECOC: A heuristic method for application dependent

design of ECOC. TPAMI, 28(6):1007–1012.

Stehling, R., Nascimento, M., and Falc˜ao, A. (2002). A

compact and efﬁcient image retrieval approach based

on border/interior pixel classiﬁcation. In CIKM, pages

102–109.

Takenouchi, T. and Ishii, S. (2007). Multi-class classiﬁca-

tion as a decoding problem. In FOCI, pages 470–475.

Windeatt, T. and Ghaderi, R. (2003). Coding and decoding

strategies for multi-class learning problems. Informa-

tion Fusion, 4(1):11–21.

Young, C., Yen, C., Pao, Y., and Nagurka, M. (2006). One-

class-at-time removal sequence planning method for

multi-class problems. TNN, 17(6):1544–1549.

APPENDIX

Table 2: List of useful symbols.

X, x Data samples, and an element of X.

Y , y The class’ labels of X and an element of Y .

N Number of elements of X.

Number of classes.

The dimensionality X.

, c The class labels and a class such that c

∈ C

Ω All possible dichotomies for C.

T A team of dichotomies such that T ⊂ Ω.

The number of dichotomies in T .

M A coding matrix

A realization of T .

A The afﬁne matrix.

The groups of afﬁne dichotomies.

Group of afﬁne dichotomies such that g

⊂ G

VISAPP 2009 - International Conference on Computer Vision Theory and Applications

330
