2.4 The Four Regimes of the Integrated
Weibull Distribution
We can now distinguish four types of natural images
according to the behavior of the integrated Weibull
distribution. When the integrated Weibull distribution
fits the data well, its sub-models define the first three
types, being: the power law, the exponential or the
Gaussian. The fourth type of natural images occurs
when the integrated Weibull distribution does not de-
scribe the data well. Our aim is to assign one particu-
lar type to a (sub-)image.
3 EXPERIMENTS
To illustrate the different regimes of the integrated
Weibull distribution, we analyze a data set contain-
ing 107 natural images of size 800x540 pixels. These
images are selected from three categories of National
Geographic wallpapers
1
: animals, landscapes, and
people. We are interested in the intensity edge dis-
tribution and its sub-models according to the four
regimes of the integrated Weibull distribution. To ob-
tain the intensity edge distribution, we do not use the
standard edge filters, e.g. Sobel style, instead we ap-
ply the Gaussian derivative filter (σ = 1) and steer
it in the gradient direction. Then we consider a his-
togram (101 bins) of the responses, and fit the inte-
grated Weibull distribution to this histogram. Finally,
we select the appropriate sub-model using Akaike’s
information criterion.
3.1 Global Image Statistic Analysis
We start by analyzing the presence of the various in-
tegrated Weibull sub-models in the statistics of the
whole image. We extract edges and study their dis-
tribution globally for each image from the data set.
The results are shown in Table 1.
Table 1: Four regimes of the integrated Weibull distribution
for global image analysis.
Int. Weibull Not Int. Weibull
100% 0%
Power Law Exp. Gauss. -
20% 78% 2% -
All images fit well to the integrated Weibull distri-
bution according to the g-test (α = 0.05). Power law
distribution is chosen as an appropriate sub-model for
1
http://www.nationalgeographic.com/
20% of the images. These images have well separated
foreground and uniform background regions, see Fig-
ure 2(a). Only 2% of the images are Gaussian dis-
tributed, these are images which contain mostly high-
frequency texture, illustrated in Figure 2(c). Most of
the images (78%) follow the exponential distribution,
which refers to moderate contrast contents. These im-
ages usually contain a lot of details at different scales,
see Figure 2(b).
Figure 3 gives an overview of the occurrence of
each sub-model in the entire image collection. Each
of the sub-models indicates different image content.
Images with strong object-background contrasts are
close to the power law behavior. Images with mod-
erate contrast tend to follow the exponential distribu-
tion. High-frequency texture images are described by
the Gaussian distribution.
(a)
(b) (c)
Figure 2: Typical images for three sub-models of the inte-
grated Weibull distribution. Figure (a) corresponds to the
power law sub-model, (b) and (c) show, respectively, exam-
ples for the exponential and the Gaussian sub-models.
3.2 Local Image Statistic Analysis
Edge distributions of natural images follow the in-
tegrated Weibull when looking at global statistics
as shown above. More important, the various sub-
models of the integrated Weibull distribution seem to
reflect visual content. One would expect this effect
to be even stronger when considering local patches,
as local visual content is more coherent. Therefore,
for the local analysis, we divide images into rectan-
gular patches (60x60 pixels) and consider the edge
histogram and model selection over these patches.
Results are presented in Table 2. For experimen-
tal setup reasons (see below), we consider a subset
of 49 images, however, results for the whole data set
are similar (data not shown). Comparing these re-
sults with the global analysis (Table 1), local patches
do not always follow the integrated Weibull distribu-
tion according to the g-test (α = 0.05). For one, re-
gions without edges are dominated by compression
artifacts and may not follow the integrated Weibull
distribution. Furthermore, in many cases, patches are
composed of a few parts, each following a different
sub-model. Thus, each part seems to conform the
integrated Weibull distribution, but all together they
do not follow one of the sub-models. In the global
VISAPP 2009 - International Conference on Computer Vision Theory and Applications
358
