PARSING TREE ADJOINING GRAMMARS USING

EVOLUTIONARY ALGORITHMS

Adrian Horia Dediu

GRLMC, Rovira i Virgili University, Pl. Imperial T`arraco 1, 43001, Tarragona, Spain

Faculty of Engineering in Foreign Languages, University “Politehnica” of Bucharest, Romania

C˘at˘alin Ionut¸ Tˆırn˘auc˘a

GRLMC, Rovira i Virgili University, Pl. Imperial T`arraco 1, 43001, Tarragona, Spain

Keywords:

Evolutionary Algorithms, Grammatical Evolution, Tree Adjoining Grammars, Parsing.

Abstract:

We use evolutionary algorithms to speed up a rather complex process, the tree adjoining grammars parsing.

This improvement is due due to a linear matching function which compares the ﬁtness of different individuals.

Internally, derived trees are processed as tree-to-string representations. Moreover, we present some practical

results and a post running analysis that may encourage the use of evolutionary techniques in mildly context

sensitive language parsing, for example.

1 INTRODUCTION

Evolutionary algorithms (EAs) were introduced in

(Holland, 1962; Schwefel, 1965; Fogel, 1962), and

several were gradually developed during the past four

decades: evolutionary strategies (Rechenberg, 1973),

genetic algorithms (Holland, 1975) and evolutionary

programming (Fogel et al., 1966). Although they are

different approaches and independently studied, all

are inspired by the same principles and share common

components such as a searching space of individuals,

a coding scheme representing solutions for a given

problem, a ﬁtness function or operators to produce

offspring. Roughly speaking, EAs try to stochasti-

cally solve searching problems by mimic of natural

principles of selecting and surviving the ﬁttest indi-

vidual from a population. Real-world applications of

EAs deal with maximizing or minimizing objective

functions such as resource location or allocation opti-

mization.

Due to the lack of theoretical proofs, many for-

mal methods tried to model their behavior. For exam-

ple, EAs are simulated with the use of eco-grammar

systems in (Dediu and Grando, 2005). Networks of

evolutionary processors (NEPs) are another compu-

tational model having biological inspiration, and to-

gether with the above mentioned is closely related

to grammar systems (Castellanos et al., 2001). Al-

though NEPs are computationally complete (Csuhaj-

Varj´u et al., 2005), it is rather difﬁcult for them to sim-

ulate EAs due to the difﬁculties given by the genera-

tion of the initial population with random individuals

and the implementation of a general ﬁtness function

evaluation.

Recently, EAs have been also used for automatic

program generation such as LISP and the method of

genetic programming was established (Koza, 1992).

In (Ryan et al., 1998) even a more complex approach

which uses the parse trees of context-free grammars

and called grammatical evolution was proposed to

automatically evolve computer programs in arbitrary

languages.

Following this lead, we extended the applicabil-

ity of the parallel and cooperativesearching processes

of EAs to tree adjoining grammars parsing. We pro-

posed a new algorithm, called EATAG

, and we could

evolve derived trees using a tree-to-string representa-

tion (see Section 4.1). Implementing a linear match-

ing function to compare the yield of a derived tree

with a given input we obtained several encouraging

results during the running tests (see Section 4.2 and

Tables 2 and 1). For a better understanding of the al-

gorithm, a running example is given in Section 4.3.

Due to the high complexity of some classical pars-

ing algorithms, long sentences analysis could repre-

sent a very difﬁcult task for a computer program. We

concluded that evolutionary algorithms used for pars-

ing process long sentences due to their reduced com-

632

Horia Dediu A. and Ionu¸t Tîrn

auc

a C. (2009).

PARSING TREE ADJOINING GRAMMARS USING EVOLUTIONARY ALGORITHMS.

In Proceedings of the International Conference on Agents and Artiﬁcial Intelligence, pages 632-639

DOI: 10.5220/0001811506320639

 SciTePress

putational complexity. In one of our examples, we

could implement a linear complexity ﬁtness function.

Comparing with the O(n

) that is the complexity of

the classical parsing algorithm for TAGs, we could

increase the limit of the parsed words per sentence.

In the end of the paper we present a post run-

ning analysis (Table 2) that allowed us to propose sev-

eral research directions in order to extend the actual

known computational mechanisms in the mildly con-

text sensitive class of languages.

2 PRELIMINARIES

In this paper we follow standard deﬁnitions and nota-

tions in formal language theory. A wealth of further

information about this area can be found in (Hopcroft

and Ullman, 1990), and details about trees in (G´ecseg

and Steinby, 1997). An alphabet is a ﬁnite nonempty

set of symbols. A string is any sequence of symbols

from an alphabet X. The set of all strings over X is de-

noted by X

∗

, and subsets of X

∗

are called languages.

Moreover, |X| denotes the cardinality of the ﬁnite set

X, i.e., its number of elements, and N the set of non-

negative integers.

Now let us recall brieﬂy the two core notions of

the present contribution: tree adjoining grammars

(TAGs) and evolutionary algorithms (EAs).

A TAG is a quintuple

T = (X,N, I,A,S) (1)

where:

• X is a ﬁnite alphabet of terminals,

• N is a ﬁnite alphabet of nonterminals,

• I is a ﬁnite set of ﬁnite trees called initial trees,

each of them having

– all interior nodes labeled by nonterminals, and

– all leaf nodes labeled by terminals, or by non-

terminals marked for substitution with ↓,

• A is a ﬁnite set of ﬁnite trees called auxiliary trees,

each of them having

– all interior nodes labeled by nonterminals, and

– all leaf nodes labeled by terminals, or by non-

terminals marked for substitution with ↓ except

for one node, called foot node, annotated by

“*”; the label of the foot node must be identical

to the label of the root node, and

• S ∈ N is a distinguished nonterminal called start

symbol.

A tree constructed from two other trees by us-

ing the two operations permitted in a TAG, substitu-

tion and adjoining, is called derived tree. Roughly

speaking, adjunction builds a new tree from an auxil-

iary tree and an initial, auxiliary or derived tree. On

the other hand, substitution replaces the node marked

with ↓ by the tree to be substituted (only trees de-

rived from the initial trees can be substituted for it).

For restrictions imposed on operations, examples and

details, the reader is referred to (Joshi and Schabes,

1997).

The tree set of a TAG contains all the trees that can

be derived from an S-rooted initial tree and in which

no node marked for substitution exists on the fron-

tier. The language generated by a TAG consists of

the yields of all trees in the tree set.

The other central notion, the EA, is deﬁned as a

7-tuple

EA = (I, f,Ω,µ,λ,s,StopCondition) (2)

where:

• I is the set of the searching space instances called

individuals,

• f : I → F is a ﬁtness function associated to indi-

viduals, with F a ﬁnite ordered set of values,

• Ω is a set of genetic operators (e.g., substitution,

mutation) which applied to the individuals of one

generation, called parents, produce new individu-

als called offspring,

• µ is the number of parents,

• λ is the number of offspring inside the population,

• s : I

× I

→ I

is the selection operator which

changes the number of individuals from parents

and offspring producing the next generation of

parents (there are variants of EAs where after one

generation the parents are not needed anymore,

and in this case s selects only from the offspring,

i.e., s : I

→ I

), and

• StopCondition : F

× N → {True,False} is the

stop criteria which may be interpreted as “Stop

when a good enough value was reached by an

individual ﬁtness function”, “Stop after a certain

number of generations” or “Stop after a maximum

time available for computations”.

Note that sometimes associated with individuals we

can keep useful information for genetic operators.

It is usual to associate to each individual its ﬁtness

value, using the notation h

−→

(u),Φ(

−→

(u))i, where

−→

(u) denotes the vectorial representation of the

chromosome of the q

individual in the generation

u and Φ(

−→

(u)) corresponds to the ﬁtness value as-

sociated to that individual. Hence, we may consider

I = {h

−→

(u),Φ(

−→

(u))i | q,u ∈ N,1 ≤ q ≤ µ + λ}.

A good overview on EAs is (B¨ack, 1996).

PARSING TREE ADJOINING GRAMMARS USING EVOLUTIONARY ALGORITHMS

633

In Figure 1 we present a general description of

an EA, where gen is a numerical variable that indi-

cates the current number of generation, P(gen) rep-

resents the set of µ individuals that are potential par-

ents in generation gen and P’(gen) is the set of new

λ offspring that we get by the application of genetic

operators to individuals in P(gen). Depending on

the coding chosen for the EA each gene belongs to

a certain data type. Let L = (C

,...,C

) be the

list of the sets of genes values, where n ∈ N is the

number of genes of the chromosomes. Without loss

of generality, we consider each C

, 1 ≤ j ≤ n, a ﬁ-

nite and discrete set of values of a given type, such

that all values of genes in the position i of a chro-

mosome of an individual are of type C

. Also note

that in the Step 2 of the EA, (n,µ,L) initializes with

random values the chromosomes and is deﬁned on

N × N ×C

×C

× .. . ×C

with values on I

3 APPLYING EVOLUTIONARY

ALGORITHMS TO PARSE

CONTEXT-FREE GRAMMARS

Context-free grammars (CFGs) are a well-know class

of language generative devices extensively used for

describing syntax of programming languages and

some signiﬁcant number of structures of natural lan-

guage sentences. For rigorous deﬁnitions and details,

the reader is referred to (Hopcroft and Ullman, 1990).

The tree structure of a string, called derivation tree,

shows how that string can be obtained by applying the

rules of the grammar. Note that a string can have mul-

tiple derivation trees associated. Parsing represents

the process of analyzing a string and constructing its

derivation tree. A parser is an algorithm that takes as

input a string and either accepts or rejects it (depend-

ing on whether it belongs or not to the language gen-

erated by the grammar), and in the case it is accepted,

also outputs its derivation trees. More about parsers

can be found in (Sippu and Soisalon-Soininen, 1988).

Due to the importance and applications of the

parsing algorithms, many efﬁcient parsing techniques

were developed over the years. Yet there are sev-

eral computational models for which parsing is per-

formed in O(n

) for CFGs (Hopcroft and Ullman,

1990) or even O(n

) for more powerful generating

devices (Joshi and Schabes, 1997). For some long

sentences (e.g., more than 15 words), the computa-

tion time is rather large for practical approaches. In

this context, alternative parsing techniques appeared

in an attempt to reduce the complexity of the parsers,

sometime even with the price of inexactness (Schmid,

1997).

Grammatical Evolution (GE) is a new approach

proposedin (Ryan et al., 1998), which uses the deriva-

tion trees generated by CFGs and the searching capa-

bilities of EAs (especially genetic algorithms) to au-

tomatically evolve computer programs written in ar-

bitrary high-level programming languages. Such a

technique orders the productions for every nontermi-

nal of the CFG, and then uses the gene values to de-

cide which production to choose when it is necessary

to expand a given nonterminal. Recall that the genetic

coding (i.e., the sequence of chosen genes) is a string

of bytes.

Let us brieﬂy describe the pioneering method of

(Ryan et al., 1998). Roughly speaking, EA ﬁnds a

function of one independent variable and one depen-

dent variable in symbolic form that ﬁts a given sample

of 20 data points (x

). The quadratic polynomial

function f(x) = x

+ x

+ x with values from the

interval [−1,1] was used with this purpose.

The considered CFG was:

1) hexpri ::= hexprihopihexpri

| (hexprihopihexpri)

| hpre− opi(hexpri)

| hvari

2) hopi ::= +| − |/|∗

3) hpre− opi ::= sin| cos|tan|log

4) hvari ::= X.

The algorithm constructs a symbolic expression

using a given sentential form. First, it starts with the

starting symbol hexpri, and it expands the leftmost

symbol considering the gene value modulo the num-

ber of choices (this way, the invalid gene value prob-

lem is solved). After that, the next leftmost symbol

is processed, and the next gene is used. If there is

only one choice, then the symbol is expanded without

considering the gene value. This procedure continues

until all the nonterminals in the sentential form were

expanded. If the string of genes is exhausted before

the nonterminals in the sentential form, then the string

of genes is used once again from the beginning as if

it were a circular string, so the problem of not having

enough genes is removed.

The ﬁtness function evaluation promotes a multi-

criterial optimization, that is, maximizes the number

of ﬁtting points and minimizes the error using the for-

mula

∑

i=1

| f(x

) − y

|. (3)

We can observe that GE cannot really evolve pro-

grams, only functions speciﬁed by samples.

ICAART 2009 - International Conference on Agents and Artificial Intelligence

634

The structure of an Evolutionary Algorithm is:

1 gen:=0;

2 Initialization process (n,µ,L);

3 Evaluate P(0):=

−→

(0),Φ(

−→

(0))i,. .. ,h

−→

(0),Φ(

−→

(0))i};

4 do while not(StopCondition(Φ(

−→

(gen)),. .., Φ(

−→

(gen)),gen))

5 Apply genetic operators;

6 Evaluate (P(gen))→ P

′

(gen)=

−→

′

(gen),Φ(

−→

′

(gen))i,. ..,h

−→

′

(gen),Φ(

−→

′

(gen))i};

7 Select the next generation P(gen+1):=s(P(gen),P

′

(gen));

8 gen := gen+1;

end do;

Figure 1: The description of an evolutionary algorithm.

4 EVOLUTIONARY

ALGORITHMS FOR TREE

ADJOINING GRAMMARS

PARSING

Even if the usefulness of CFGs in representing

the syntax of natural languages is well established,

there are still several important linguistics aspects

that cannot be represented by this class of gram-

mars. For example, the languages multiple agreement

...a

|n ≥ 1, k ≥ 3}, copy {ww|w ∈ {a,b}

∗

} and

cross agreement {a

|n,m ≥ 1} ⊂ {a,b,c,d}

∗

cannot be generated by any CFG. Thus, a more pow-

erful class of grammars, called tree adjoining gram-

mars (TAGs), was introduced (Joshi et al., 1975),

yielding interesting mathematical and computational

results over the past decades.

In this section we show how to apply a similar

technique with the one described in Section 3 to a

TAG in order to construct a derivation tree of a given

input string; progressively, we build at each step a de-

rived tree until we get a tree with the yield matching

the input string. This parsing algorithm for TAGs that

uses EAs will be called EATAG

in the following. Af-

ter presenting it, we point out some complexity issues

and show some tests performed.

Let us assume that for the rest of the paper the

TAG T = (Σ,N,I,A,S) and the input string is are

given.

4.1 The Algorithm EATAG

First we should mention that we adapted the tree-to-

string notation to simplify the internal representation

of the trees. We use curly brackets to specify the con-

straints, rectangular brackets to specify the children of

a node labeled by a nonterminal and a blank separator

after terminals. For nonterminals we have the con-

vention: they start with an uppercase letter followed

by other characters, then the speciﬁcation of the con-

straints, and ﬁnally a “[” which marks the end of their

representation. Inside a balanced pair (“[”, “]”) we

have all the children of that nonterminal. A foot node

of an auxiliary tree has no children therefore there is

no need for the pair(“[”, “]”); instead, we have only

the foot marker “*”. An example is shown in the be-

ginning of Section 4.3 (see Figure 2 also).

The ﬁnal goal of the algorithm is to ﬁnd a derived

tree that has the root labeled with S and whose yield

matches the given input string is. To this end, we start

from an arbitrary S-rooted tree, and we may apply

substitutions and adjoinings to construct the target de-

rived tree. The searching process is exponential since

at every step several possible options to chose from

exist. From the beginning we may pick from several

S-rooted trees, then in the derived tree we may choose

from several nodes where to apply the next deriva-

tion, and once we do this, we may have several possi-

ble trees to substitute in or to adjoin at that particular

node.

EA’s individuals are viable solutions for the prob-

lem of the representation of a derived tree in a TAG

using a ﬁxed number of genes, and they proved to

speed up this searching process. For the moment, let

us brieﬂy explain how the algorithm works and which

are the issues that appear.

There are |I| initial trees and |I

| initial S-rooted

trees. We order all the trees in the sets I and A, respec-

tively, and all the nodes in every such tree according

to the node position in the tree-to-string representa-

tion. For example, if |I| = k, then we will identify

the trees in I by the numbers 1,2,. .., k. Thus, the

pairs (TreeNumber, NodeNumber) completely char-

acterize all the nodes in all the given trees of the TAG.

We start to construct a derived tree, and in this pro-

PARSING TREE ADJOINING GRAMMARS USING EVOLUTIONARY ALGORITHMS

635

gressive builded derived tree we carry on the nodes’

attributes such as substitution or adjoining constraints

(NA stands for non-adjoining).

We use the ﬁrst gene modulo |I

| to select the start-

ing tree from the initial S-rooted trees, tree which will

transform into the desired derived tree after the fol-

lowing algorithm.

1. We repeat the algorithm’s steps until the length

of the yield of the derived tree will be greater or

equal than the length of the input string (stopping

condition). If this is not the case yet, and if we

have obligatory adjoining constraints, we should

satisfy them ﬁrst.

2. Then we count how many nonterminals which do

not have the NA constraint are in the derived tree.

Let n

max

be this number. We use the next gene

modulo n

max

to select the next node, and there we

will apply a proper derivation. If somehow we

ﬁnish the genes, we start to use the string of genes

from the beginning.

3. Next, we proceed depending on the type of the

selected node:

(a) If the selected node is a substitution one, then

we count the trees that could be substituted in

our node, and let ns

max

be this number. We use

the next gene modulo ns

max

to select the next

substitution tree, and after that we perform the

substitution. Then, we go to Step 1.

(b) If the selected node is an adjoining node, then

we count the trees that could be adjoined at our

node, and let na

max

be this number. We use the

next gene modulo na

max

to select the next ad-

joining tree, and after that we do the adjoining.

Then, we go to Step 1.

Note that we can optimize the usage of genes, and

whenever we have a single option (node or tree) for

the next operation, we can perform the operation

without consuming the gene.

Now let us present the pseudocode for the infor-

mal description of the genetic decoding (a running

example can be found in Section 4.3). We mention

that in the line 17 of the algorithm, the “+” opera-

tor represents the usual concatenation for strings. We

describe only the adjoin part, the substitution being

similar (ng denotes the number of genes).

1) i=0 %counter for genes index

2) evolvedTree=initialTrees[gene[i] mod |I

3) do while len(yield(evolvedTree)) < len(is)

4) i=(i+1) mod ng

5) n

max

=|internalNodes|-|internalNodes

with NA attributes|

6) adjNode=nonTerCandidates[gene[i] mod n

max

]

7) i=(i+1) mod ng

8) adjSet=adjNode.Label-type

9) na

max

=|adjSet|

10) i=(i+1) mod ng

11) insertedTree=adjSet[gene[i] mod na

max

]

12) t

=evolvedTree.substring(0,p

)

13) t

=insertedTree.split("*")[0]

14) t

=evolvedTree.substring(p

+1,p

)

15) t

=insertedTree.split("*")[1]

16) t

=evolvedTree.substring(p

)

17) evolvedTree=t

18) enddo

4.2 Fitness Function and Complexity

Fitness function assigns values to individuals devel-

oped by the EA, and that is why it is the most impor-

tant factor that directs the searching process. There-

fore, a ﬁtness function that says “yes” or “no” to the

individuals of an EA is completely useless for the

searching process since the EA cannot know if a new

individual is a little bit better or worse than another

one.

In our algorithm we have to encourage two as-

pects: the matching of characters in the input string

and in the yield of the derived tree, and the equal

length of the two strings.

We can use several types of ﬁtness function. For

example, the values associated to individuals are

triples of integers (k

), where k

represents the

maximum length of a sequence of matched charac-

ters, k

is the number of matches, and k

gets negative

values for yields longer than the input string. When

we make the comparisons between different individu-

als during the selection process, we consider the ﬁrst

criterion the most important, then the second and then

the third.

Let M be the number of generations after which

we stop the evolution of the TAG. In our practical

implementation the crossover, mutation and selection

operators have the time complexity lower than the

ﬁtness function evaluation complexity. Under these

circumstances, our algorithm EATAG

has the time

complexity O(M · (µ + λ) · Time( f)), where µ and

λ are as speciﬁed in the deﬁnition of an EA, and

Time( f) is the time complexity of the ﬁtness func-

tion. During our tests we started with O(n

) time

complexity for the ﬁtness function, then we reduced

it to O(n

), but the best results were obtained with a

linear ﬁtness function.

4.3 Running Examples

For tests we used the TAG T = ({a},{S},{α

S{NA}[a S[a ]], α

: S{NA}[b S[b ]]}, {β

S{NA}[a S[S{NA} ∗ a ]], β

: S{NA}[b S[S{NA} ∗

b ]]},S) which generates the copy language {ww|w ∈

{a,b}

} (see Figure 2).

ICAART 2009 - International Conference on Agents and Artificial Intelligence

636

Table 1: Results of tests of EATAG

is: aaaabbbaaaaabbba is: aaaabbbaabbaaaaabbbaabba

GEN Max Average Min GEN Max Average Min

0 7 3.27 2 0 5 2.67 1

1 7 6.27 6 1 8 6.33 5

2 16 7.13 6 2 8 6.93 6

3 16 7.40 6 3 12 8.20 7

4 16 7.87 7 4 12 8.73 7

5 16 8.67 7 5 12 9.07 8

6 16 11.20 8 6 12 9.20 8

7 16 11.20 8 7 12 9.53 9

8 16 11.20 8 8 12 9.73 9

9 16 12.80 8 9 24 11.80 9

10 16 15.47 8 10 24 11.93 9

Table 2: Comparative tests for classical TAG parsing and EATAG

parsing.

First example len(input)=16 Second example len(input)=20

Computations Computations

classical 827,787 2,153,088

EATAG

268,886.3 661,745.5

a S

b S

a S

∗

b S

∗

Figure 2: The TAG T generating the copy language.

To explain better the decoding algorithm, we il-

lustrate it on an speciﬁc example. For the gram-

mar mentioned above and for the input string is =

“aaaabbbabbaaaabbbabb”, len(is) is 20, and the

number of initial S-rooted trees is 2. Moreover, we

have the following randomly generated sequence of

genes: 113,110,248,173,119,.. .. According to the

decoding algorithm’s line 2, gene[0] = 113, and the

evolvedTree is “S{NA} [b S[b ]]”. Since the length

of the yield of the evolvedTree is less than 20, the

algorithm continues with the while loop (code line

3). Next, n

max

is 1, and here due to the opti-

mization of genes’ usage we do not increment the

genes’ counter as described in code line 4. The

ad jNode position is 8 (strings’ index starts from

0), ad jNode.Label is “S”, na

max

is 2, gene[1]=248,

and the insertedTree is “S{NA}[a S[S{NA}*a

]]”. Moreover, we have p

= 8, p

= 13, t

“S{ NA}[b ”, t

= “S{NA}[a S[S{NA}”, t

= “[b ]”,

= “a ]]”, t

= “]”, and hence we get the evolvedTree

“S{ NA}[b S{NA} [a S[S{NA}[b ]a]]]”. The evolution

cycle continues generating more evolvedTree values

until we stop because the length of the yield of the

last derived evolvedtree (“baabbbaaaabaabbbaaaa”)

was 20.

Now that we explained how our algorithm works,

we turn our attention to the study of the behavior of

EATAG

(in terms of computations) for two input

strings, and then we present a comparison of the ob-

tained results with the ones from the classical parsing

algorithm for TAGs (Joshi and Schabes, 1997, p.102).

The tests were done for the input strings “aaaabb-

baaaaabbba” and “aaaabbbaabbaaaaabbbaabba” hav-

ing the lengths 16 and 24, respectively.

We used an EA with 15 individuals as the popula-

tion size, each having 20 genes with values between 0

and 255 (one byte). We considered the linear ﬁtness

function as the maximum length of matching charac-

ters between the input string and the yield of the de-

rived tree.

Table 1 summarizes the results of the runs, where

GEN is the number of the generation, is represents

the input string, and Max, Average and Min, respec-

tively, are the best, the average and the worst, respec-

tively, ﬁtness function’s values of individuals during

one generation.

Let us now compare EATAG

and the classical

TAG parsing. It is well known that theoretically, the

classical algorithm for parsing TAGs has the worst

case complexity O(n

). For many examples it does

PARSING TREE ADJOINING GRAMMARS USING EVOLUTIONARY ALGORITHMS

637

not reach the worst case, and we believe that the com-

parison of the results of the two parsing algorithms for

an average behavior will be more appropriate. On the

other hand, even if the EA uses a linear ﬁtness func-

tion, the number of generations multiplied with the

number of individuals in the population could lead to

a signiﬁcant volume of computations while solving

the parsing problem.

To make those comparisons, we used a rather em-

pirical method to measure the number of computa-

tions. In every cycle we incremented a global vari-

able called computations. We estimated the num-

ber of computations for both algorithms using the

same input string. One may argue that other com-

paring methods could be considered (e.g., measuring

the necessary time until ﬁnding the solution) but since

we made the implementations in two different pro-

gramming environments (VBA and Java), the running

time would have been inﬂuenced by other aspects, not

only by the complexity of the algorithms. By tak-

ing again the two input samples “aaaabbbaaaaabbba”

and “aaaabbbabbaaaabbbabb” having the length 16

and 20, respectively, we needed for the classical TAG

parsing algorithm only one run to determine the num-

ber of computations for each input example, while

for EATAG

we obtained the average result after ten

tests. All the results are synthesized in Table 2.

5 CONCLUSIONS AND FUTURE

WORK

We proposed an evolutionary algorithm for tree ad-

joining grammars’ parsing called EATAG

. After

some preliminary tests, we observed that the classi-

cal tree adjoining grammar parsing algorithm needs

approximatively three times more computations than

our algorithm to solve the same problem. Maybe it is

worthy to do more tests and further investigate under

what circumstances it performs better, if a conjecture

can be outlined or what improvements can be added.

We believe that our algorithm can be a turning point

in developing new models for knowledge base rep-

resentation systems or automatic text summarization,

for example.

As a drawback, for some examples EATAG

will

not be able to say that there is no solution. We could

have some doubts that we did not let the algorithm to

run enough generations, but in any case, we could run

tests for other examples, and we could approximate

the requested number of generations required to ﬁnd

a solution for certain lengths of the input strings. This

will be done in the future.

Another intriguing aspect of EATAG

is that if the

grammar is ambiguous, we could ﬁnd different pars-

ings for different individuals in the population during

one run for the same input string.

To conclude, we believe that our research could be

a starting point for developing new and more efﬁcient

TAG parsing algorithms.

ACKNOWLEDGEMENTS

The work of A.H. Dediu was supported by Rovira i

Virgili University under the research program “Ra-

mon y Cajal” ref. 2002Cajal-BURV4. Many thanks to

the anonymous reviewers who encourage us and help

us improve the clarity and exposition of the present

material.

REFERENCES

B¨ack, T. (1996). Evolutionary algorithms in theory and

practice: evolution strategies, evolutionary program-

ming, genetic algorithms. Oxford University Press.

Castellanos, J., Mart´ın-Vide, C., Mitrana, V., and Sempere,

J. M. (2001). Solving np-complete problems with net-

works of evolutionary processors. In IWANN ’01, 6th

International Work-Conference on Artiﬁcial and Nat-

ural Neural Networks. Springer.

Csuhaj-Varj´u, E., Mart´ın-Vide, C., and Mitrana, V. (2005).

Hybrid networks of evolutionary processors are com-

putationally complete. Acta Inf., 41(4):257–272.

Dediu, A. H. and Grando, M. A. (2005). Simulating evo-

lutionary algorithms with eco-grammar systems. In

IWINAC’05, 1st International Work-conference on the

Interplay between Natural and Artiﬁcial Computa-

tion. Springer.

Fogel, L. (1962). Autonomous automata. Industrial Re-

search, 4:14–19.

Fogel, L. J., Owens, A. J., and Walsh, M. J. (1966). Arti-

ﬁcial Intelligence through Simulated Evolution. The

University of Michigan Press, New York.

G´ecseg, F. and Steinby, M. (1997). Tree languages. In Sa-

lomaa, A. and Rozenberg, G., editors, Handbook of

formal languages, Vol. 3: beyond words, pages 1–68.

Springer, New York.

Holland, J. (1975). Adaptation in Natural and Artiﬁcial Sys-

tems. The University of Michigan Press.

Holland, J. H. (1962). Outline for a logical theory of adap-

tive systems. J. of the ACM, 9(3):297–314.

Hopcroft, J. E. and Ullman, J. D. (1990). Introduction

To Automata Theory, Languages, And Computation.

Addison-Wesley Longman Publishing Co., Inc.

Joshi, A. and Schabes, Y. (1997). Tree-adjoining grammars.

In Rozenberg, G. and Salomaa, A., editors, Handbook

of Formal Languages, Vol. 3: Beyond Words, pages

69–120. Springer, New York.

ICAART 2009 - International Conference on Agents and Artificial Intelligence

638

Joshi, A. K., Levy, L. S., and Takahashi, M. (1975). Tree

adjunct grammars. J. Comput. Syst. Sci., 10(1):136–

163.

Koza, J. (1992). Genetic Programming. The Theory of

Parsing, Translation, and Compiling. MIT Press.

Rechenberg, I. (1973). Evolutionsstrategie - Optimierung

technischer Systeme nach Prinzipien der biologischen

Evolution. Frommann-Holzboog, Stuttgart.

Ryan, C., Collins, J. J., and O’Neill, M. (1998). Gram-

matical evolution: Evolving programs for an arbitrary

language. In EuroGP’98, 1st European Workshop on

Genetic Programming. Springer.

Schmid, H. (1997). Parsing by successive approx-

imation. In IWPT’97, International Work-

shop on Parsing Technologies. Available

http://elib.uni-stuttgart.de/opus/

volltexte/1999/393/pdf/393_1.pdf

Schwefel, H.-P. (1965). Kybernetische Evolution als Strate-

gie der experimentellen Forschung in der Str¨omungs-

technik. Diplomarbeit, Technische Universit¨at Berlin,

Hermann F¨ottinger–Institut f¨ur Str¨omungstechnik.

Sippu, S. and Soisalon-Soininen, E. (1988). Parsing Theory

I: Languages and Parsing. Springer.

PARSING TREE ADJOINING GRAMMARS USING EVOLUTIONARY ALGORITHMS

639
