SIMULATING THE HUMAN FACTOR IN REPUTATION

MANAGEMENT SYSTEMS FOR P2P NETWORKS

An Agent Based Model

Guido Boella, Marco Remondino

University of Turin, Department of Computer Science, Cso Svizzera 185, Turin, Italy

Gianluca Tornese

University of Turin, Italy

Keywords: Reputation system, Agent based simulation, Peer to peer network.

Abstract: A compelling problem in peer-to-peer (P2P) networks for file sharing, is the spreading of inauthentic files.

To counter this, reputation management systems (RMS) have been introduced. These systems dynamically

assign to the users a reputation value, considered in the decision to download files from them. RMS are

proven, via simulation, to make P2P networks safe from attacks by malicious peers spreading inauthentic

files. But, in large networks of millions of users, non-malicious users get a benefit from sharing inauthentic

files due to the credit system. In this paper we show, using agent based simulation, that reputation systems

are effective only if there is a widespread cooperation by users in verifying authenticity of files during the

download phase, while the size punishment derived by the reputation systems is less relevant. This was not

evident in previous works since they make several ideal assumptions about the behaviour of peers who have

to verify files to discover inauthentic ones. Agent based simulation allows to study the human factor behind

the behaviour of peers, in particular the advantage of spreading inauthentic files, of not checking as soon as

possible their authenticity during the download, thus unwillingly cooperating to the spreading of files-point.

1 INTRODUCTION

One of the most compelling problems in peer-to-

peer (P2P) networks for file sharing, at least from

the point of view of users, is the spreading of

inauthentic files; since multimedia files are usually

quite large, downloading the wrong ones causes

waste of time, of storage space and of bandwidth.

The percentage of inauthentic files circulating over a

P2P network is high, especially for those resources

which are recent and most requested.

Some of the reasons of this problem are the

possibility to attack a P2P networks introducing

malicious peers and how users exploits the protocol

with which the current P2P systems reward the users

for uploading files, no matter if they are authentic or

not. Since uploading bandwidth is a limited resource

and the download priority queues are based on a

uploading-credit system to reward the most

collaborative peers on the network, some malicious

users, if they see that a resource is rare or most

wanted, could decide to create an inauthentic file for

it, just to have something to share, thus obtaining

credits. In this way inauthentic files spread very

quickly on the network and those malicious users are

never penalized for their behaviour.

To balance the incentive for sharing inauthentic

files, reputation management systems (RMS) have

been introduced. These systems gather information

from users about the authenticity of files

downloaded by peers and based on this dynamically

assign a reputation to them, used as a value in the

decision to download files from them or not.

Reputation management systems are proven, via

simulation, to make P2P networks safe from attacks

by malicious peer, even when forming coalitions.

If attack to P2P network via inauthentic files is a

relevant problem, it is not the only one. In particular,

in large networks of millions of users attacks are

more difficult but users still have a benefit from

Boella G., Remondino M. and Tornese G.

SIMULATING THE HUMAN FACTOR IN REPUTATION MANAGEMENT SYSTEMS FOR P2P NETWORKS - An Agent Based Model.

DOI: 10.5220/0001821200050012

In Proceedings of the Fifth International Conference on Web Information Systems and Technologies (WEBIST 2009), page

ISBN: 978-989-8111-81-4

sharing inauthentic files. RMS have been proved

useful against attacks but it is not clear if they can be

effective against widespread selfish misbehaviour.

The reason is that they make many ideal

assumptions about the behaviour of peers who have

to verify files to discover inauthentic files: this

operation is assumed to be automatic and to have no

cost. Moreover, since in current systems files are

shared before downloading is completed, peers

downloading inauthentic files involuntarily spread

inauthentic files if they are not cooperative enough

to verify their download as soon as possible. In this

paper we address the following research questions:

• Which are the factors controlled by users which

determine the correct functioning of reputation

management systems in P2P network?

• How to evaluate the role of these factors by

means of agent based simulation? Which factors

have most impact?

In the present work the creation and spreading of

inauthentic files is not considered as an attack, but a

way in which some agents try to raise their credits,

while not possessing the real resource that's being

searched by others. A basic and idealized RMS is

introduced, acting as a positive or negative reward

for the users. We are not interested in simulating

factors like distribution of workload among the

peers, how reputation is calculate, bandwidth issues

and multiple sources downloading, since our focus is

different. Instead, the human factor behind a RMS is

considered, e.g. the decision of creating inauthentic

files and costs and benefits of verifying files.

To test the limits and effectiveness of a RMS

under different user behaviours we use agent based

simulation. A multi agent simulation of a P2P

network is used, employing reactive agents to model

the users. The P2P network is modelled using a

graph with a random distribution for the nodes and

the links. The RMS is decentralized and each agent

has a unique value, valid throughout the whole

system. Each agent has a dynamic set of goals; the

protocol used for searching is a request flooding one,

with a TTL (time to live) set to three.

Under certain conditions, even a simple RMS

can dramatically reduce the number of inauthentic

files over a P2P system and harshly penalize

malicious users, without directly banishing them

from the network (ostracism).

The main goal is to discover the malicious users

and penalize them for their behaviour, while

rewarding the loyal users. By using given values for

positive and negative payoffs, malicious users get

quickly discovered, in the sense that their reputation,

after some simulated turns, gets significantly lower

than that of loyal agents. Besides, the unaware

agents that unwillingly contributed to spread the

inauthentic files (since they didn't check and delete

them when they could do that) do not get penalized

too much by this system, keeping a reputation value

much higher than malicious agents. After few turns

the number of inauthentic files over the P2P network

is dramatically reduced, and so is the index of their

number/total number of requests. This guarantees

that this emerging result is not caused by the

reduction of the number of requests.

This paper is structured as follows. First in

Section “reputation” we discuss reputation

management systems, then in Section “model” we

present the P2P scenario we use. Section “results”

analyzes the parameters and results of simulations.

“Conclusions” discusses the results and future work.

2 REPUTATION

It is well known that selfish peers wish to use file

sharing services while contributing minimal or no

resources themselves: to minimize their cost in

bandwidth and CPU utilization freeholders refuse to

share files in the network. To incentive sharing of

files, credit systems are set up to give more

bandwidth or priorities in waiting queues to users

who share more files.

The credit mechanism, alas, can be exploited by

users who try to get more credits by distributing

highly requested files even if they do not have them,

it is sufficient to replace them with inauthentic

copies. This behaviour can take the form of an

explicit creation of inauthentic files or the

voluntarily or not voluntarily sharing of downloaded

(or still in download) inauthentic files. When a user

is downloading a file after a given amount of time he

can check its authenticity. If she does not verify, or

she does not remove that file, from the perspective

of the system she becomes a malicious user. RMS,

like EigenTrust (Kamvar et al., 2003), try to lower

the problem of inauthentic files by allowing users to

give feedback about the cooperativeness of other

users and the system uses this feedback to compute a

reputation of the different peers in the systems.

In general, a RMS assists agents in choosing a

reliable peer (if possible) to transact with when one

or more have offered the agent a service or resource.

To accomplish this, a RMS collects information on

the transactional behaviour of each peer

(information gathering), scores and ranks the peers

based on expected reliability (scoring/ranking), and

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

allows the system to take actions against malicious

peers while rewarding contributors.

The driving force behind RMS design is to

provide a service that mitigates misbehaviour while

imposing a minimal costs on the well-behaved users.

To that end, it is important to understand the

requirements imposed on system design by each of

the following: among them the behaviour and

expectations of typical good users, and the goals and

attacks of adversaries.

Usability of a systems consists both in providing

an acceptable level of service, and in not demanding

costly behaviours, or at least providing incentives

for such behaviours. However, malicious behaviour

by peer is due not only by the will to attack the

system or to get higher credits, but also by the cost

of verifying the authenticity of files: the user needs a

correct version of the P2P software, has to find a

suitable viewer, to select a not yet verified file, to

wait until it opens, to check the content (sometimes

an embarrassing task) and to signal the

inauthenticity of the file. Since controlling the

authenticity of files is costly, and this operation is a

prerequisite for giving a feedback on the

cooperativity of peers, the RMS is not granted to

function as expected. Most approaches, most notably

EigenTrust (Kamvar et al., 2003), assume that

verification is made automatically upon the start of

download of the file. By looking as we do at the

human factor in dealing with RMS, we can question

their real applicability, a question which remains

unanswered in the simulation based tests made by

the authors. To provide an answer to this question it

is necessary to build a simulation tool aiming at a

more accurate modelling of the users' behaviour

rather than at modelling the RMS in detail.

3 MODEL

The P2P network is modelled as an undirected and

non-reflexive graph. Each node is an agent,

representing a P2P user. Agents are reactive: their

behaviour is thus determined a priori, and the

strategies are the result of the stimuli coming from

the environment and of the condition-action rules.

Their behaviour is illustrated in next section.

Formally the multi agent system is defined as MAS

= <Ag; Rel>, with Ag set of nodes and Rel set of

edges. Each edge among two nodes is a link among

the agents and is indicated by the tuple < ai; aj >

with ai and aj belonging to Ag. Each agent features

the following parameters:

– Unique ID (identifier),

– Reputation value (or credits) N(ai),

– Set of agent’s neighbors RP(ai),

– Set of owned resources RO(ai),

– Set of goals (resource identifiers) RD(ai),

– Set of resources being downloaded P(ai),

– Set of pairs < supplier; resource >.

A resource is a tuple <Name, Authenticity>,

where Name is the resource identifier and

Authenticity is a Boolean attribute indicating

whether the resource is authentic or not. The agent

owning the resource, however, does not have access

to this attribute unless he verifies the file.

The resources represent the object being shared

on the P2P network. A number of resources are

introduced in the system at the beginning of the

simulation; they represent both the owned objects

and the agents' goals. For coherence, an owned

resource can't be a goal, for the same agent. The

distribution of the resource is stochastic. During the

simulation, other resources are stochastically

introduced. In this way, each agent in the system has

the same probabilities to own a resource,

independently from her inner nature (malicious or

loyal). In the same way also the corresponding new

goals are distributed to the agents; the difference is

that the distribution probability is constrained by its

being possessed by an agent. Formally R be the set

of all the resources in the system. We have that:





R,RO





 RandRD





RO





Ø.

Each agent in the system features a set of

neighbours N(ai), containing all the agents to which

she is directly linked in the graph: Na

i





j  Ag|  ;  Rel



. This information

characterizes the information of each agent about the

environment. The implemented protocol is a totally

distributed one, so looking for the resource is

heavily based on the set of neighbours.

In the real word the shared resources often have

big dimensions; after finding the resource, a lot of

time is usually required for the complete download.

In order to simulate this the set of the "resources

being downloaded" (Ris) introduced. These are

described as Ris = <resource ID, completion, check

status>, where ID is the resource identifier,

completion is the percentage already downloaded

and "check status" indicates whether the resource

has been checked for authenticity or not. In

particular, it can be not yet verified, verified and

authentic and verified and inauthentic: 

checkstatus 



NOTCHECKED; AUTH;INAUTH



Another information is ID of the provider of a

certain resource, identified by P(ai). Each agent

keeps track of those which are uploading to him, and

SIMULATING THE HUMAN FACTOR IN REPUTATION MANAGEMENT SYSTEMS FOR P2P NETWORKS - An

Agent Based Model

this information is preserved also after the download

is finished. The real P2P systems allow the same

resource to be download in parallel from many

providers, to improve the performance and to split

the bandwidth load. This simplification should not

affect the aggregate result of the simulation, since

the negative payoff would reach more agents instead

of just one (so the case with multiple provider is a

sub-case of that with a single provider).

3.1 The Reputation Model

In this work we assume a simple idealized model of

reputation, since the objective is not to prove the

effectiveness of a particular reputation algorithm but

to study the effect of users' behaviour on a reputation

system. We use a centralized system which assumes

the correctness of information provided by users,

e.g., it is not possible to give an evaluation of a user

with whom there was no interaction. The reason is

that we focus on the behaviour of common agents

and not on hackers who attack the system by

manipulating the code of the peer application. In the

system there are two reputation thresholds: the first

and higher one, under which it’s impossible to ask

for resources to other agents, the second, lower than

the other, which makes it impossible even to share

the owned files. This guarantees that an agents that

falls under the first one (because she shared too

many inauthentic files), can still regain credits by

sharing authentic ones and come back over the first

threshold. On the contrary, if she continues sharing

inauthentic files, she will fall also under the second

threshold, being de facto excluded from the network,

still being a working link from and to other agents.

3.2 The User Model

Peers are reactive agents replying to requests,

performing requests or verifying files. While upload

is performed each time another agent makes a

request, requesting a file and verification are

performed (in alternative) when it is the turn of the

agent in the simulation. All agents belong to two

disjoint classes: malicious agents and loyal agents.

The classes have different behaviours concerning

uploading, while they have the same behaviour

concerning downloading and verification: malicious

agents are just common agents who exploit for

selfishness the weaknesses of the system. When it is

the turn of another peer, and he requests a file to the

agent, he has to decide whether to comply with the

request and to decide how to comply with it.

- The decision to upload a file is based on the

reputation of the requester: if it is below the

"replying threshold", the requestee denies the upload

(even if the requestee is a malicious agent).

- The "replyTo" method refers to the reply each

agent gives when asked for a resource. When the

agent is faced with a request he cannot comply but

the requester's reputation is above the "replying

threshold", if he belongs to the malicious class, he

has to decide whether to create and upload an

inauthentic file by copying and renaming one of his

other resources. The decision is based depending on

a parameter. If the resource is owned, she sends it to

the requesting agent, after verifying if her reputation

is higher than the "replying threshold". Each agent

performs at each round of simulation two steps:

1) Performing the downloadings in progress. For

each resource being downloaded, the agents check if

the download is finished. If not, the system checks if

the resource is still present in the provider's "sharing

pool". In case it's no longer there, the download is

stopped and is removed from the list of the "owned

resources". Each file is formed by n units; when 2/n

of the file has been downloaded, then the file gets

automatically owned and shared also by the agent

that is downloading it.

2) Making new requests to other peers or

verifying the authenticity of a file downloaded or in

downloading, but not both:

a) When searching for a resource all the

agents within a depth of 3 from the requesting

one are considered. The list is ordered by

reputation. A method is invoked on every agent

with a reputation higher than the "requests

threshold", until the resource is found or the list

reaches the ending point. If the resource is

found, it's put in the "downloading list", the

goal is cancelled, the supplier is recorded and

linked with that specific download in progress

and her reputation is increased according to the

value defined in the simulation parameters. If

no resource is found, the goal is given up.

b) Verification means that a file is

previewed and if the content does not

correspond to its description or filename, this

fact is notified to the reputation system.

Verification phase requires that at least one file

must be in progress and it must be beyond the

2/n threshold described above. An agent has a

given probability to verify instead of looking

for a new file. In case the agent verifies, a

random resource is selected among those “in

download” and not checked. If authentic, the

turn is over. Otherwise, a "punishment" method

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

is invoked, the resource deleted from the

"downloading" and from the "owned " lists and

put among the "goals" once again.

The RMS is based on the "punishment" method

which lowers the supplier's reputation, deletes her

from the "providers" list in order to avoid cyclic

punishment chains, and recursively invokes the

"punishment" method on the punished provider. A

punishment chain is thus created, reaching the

creator of the inauthentic file, and all the aware or

unaware agents that contributed in spreading it.

4 EXPERIMENTAL RESULTS

4.1 Variables and Methodology

The simulation goes on until at least one goal exists

and/or a download is still in progress. A "come-

back" mode is implemented and selectable before

the simulation starts, in order to simulate the real

behaviour of some P2P users who, realizing that

they cannot download anymore (since they have low

credits or, in this case, bad reputation), disconnect

their client, and then connect again, so to start from

the initial pool of credits/reputation. When this mode

is active, at the beginning of each turn all the agents

that are under a given threshold reset it to the initial

value, metaphorically representing the disconnection

and reconnection. This will be discussed later.

In the following table a summary of the most

important parameters for the experiments are given:

Table 1: The main parameters.

In all the experiments, the other relevant

parameters are fixed, while the following ones

change:

Table 2: The scenarios.

A crucial index, defining the wellbeing of the

P2P system, is the ratio among the number of

inauthentic resources and the total number of files

on the network. The total number is increasing more

and more over time, since new resources are

introduced iteratively. Another measure collected is

the average reputation of loyal and malicious agents

at the end of the simulation; in an ideal world, we

expect malicious ones to be penalized for their

behaviour, and loyal ones to be rewarded. The

results were obtained by a batch execution mode for

the simulation. This executes 50 times the

simulation with the same parameters, sampling the

inauthentic/total ratio every 50 steps. This is to

overcome the sampling effect; many variables in the

simulation are stochastic, so this technique gives an

high level of confidence for the produced results. In

2000 turns, we have a total of 40 samples. After all

the executions are over, the average for each time

step is calculated, and represented in a chart. In the

same way, the grand average of the average

reputations for loyal and malicious agents is

calculated, and represented in a bar chart. In figure

1, the chart with the trend of inauthentic/total

resources is represented for the results coming from

experiments 1, 2, 3, 5 and 6. The results of

experiment 4 is discussed later.

Figure 1: The trends of the results.

4.2 Evaluation of Results

Experiment 5 depicts the worst case: no negative

payoff is given. The ratio initially grows and, at a

certain point, it gets constant over time, since new

SIMULATING THE HUMAN FACTOR IN REPUTATION MANAGEMENT SYSTEMS FOR P2P NETWORKS - An

Agent Based Model

resources are stochastically distributed among all the

agents with the same probability. In this way also

malicious agents have new resources to share, and

they will send out inauthentic files only for those

resources they do not own. In the idealized world

modelled in this simulation, since agents are 50

malicious and 50 loyal, and since the ones with

higher reputation are preferred when asking for a

file, it’s straightforward that malicious agents’

reputation fly away, and that an high percentage of

files in the system are inauthentic (about 63%).

Experiment 1 shows how a simple RMS, with quite

a light punishing factor (3) is already sufficient to

lower the percentage of inauthentic files in the

network over time. We can see a positive trend,

reaching about 28% after 2000 time steps, which is

an over 100% improvement compared to the

situation in which there was no punishment for

inauthentic files. In this experiment the verification

percentage is at 30%. This is quite low, since it

means that 70% of the files remain unchecked

forever (downloaded, but never used). In order to

show how much the human factor can influence the

way in which a RMS works, in experiment 2 the

verification percentage has been increased up to

40%, leaving the negative payoff still at 3. The

result is surprisingly good: the inauthentic/total ratio

is dramatically lowered after few turns (less than

10% after 200), reaching less than 1% after 2000

steps. Since 40% of files checked is quite a realistic

percentage for a P2P user, this empirically proves

that even the simple RMS proposed here

dramatically helps in reducing the number of

inauthentic files. In order to assign a quantitative

weight to the human factor, in experiment 3, the

negative payoff is moved from 3 to 4, while bringing

back the verification percentage to 30%. Even with a

higher punishing factor, the ratio is worse than in

experiment 2, meaning that it’s preferable to have a

higher verification rate, compared to a higher

negative payoff. Experiment 6 shows the opposite

trend: the negative payoff is lighter (2), but the

verification rate is again at 40%, as in experiment 2.

The trend is very similar – just a bit worse - to that

of experiment 3. In particular, the ratio of

inauthentic files, after 2000 turns, is about 16%. At

this point, it gets quite interesting to find the “break

even point” among the punishing factor and the

verification rate. After some empirical simulations,

we have that, compared with 40% of verification and

3 negative payoff, if now verification is just at 30%,

the negative payoff must be set to a whopping value

of 8, in order to get a comparable trend in the ratio.

This is done in experiment 4: after 2000 turns,

there’s 1% of inauthentic files with a negative

payoff of 3 and a verification percentage of 40%,

and about 0.7 with 8 and 30% respectively. This

clearly indicates that human factor (the files

verification) is crucial for a RMS to work correctly

and give the desired aggregate results (few

inauthentic files over a P2P network). In particular, a

slightly higher verification rate (from 30% to 40%)

weights about the same of a heavy upgrade of the

punishing factor (from 3 to 8).

Besides considering the ratio of inauthentic files

moving on a P2P network, it’s also crucial to verify

that the proposed RMS algorithm could punish the

agents that maliciously share inauthentic files,

without involving too much unwilling accomplices,

which are loyal users that unconsciously spread the

files created by the former ones. In the agent based

simulation, this can be considered by looking at the

average reputation of the agents, at the end of the

2000 time steps. In the worst case scenario, the

malicious agents, that are not punished for

producing inauthentic files, always upload the file

they are asked for (be it authentic or not). In this

way, they soon gain credits, topping the loyal ones.

Since in the model the users with a higher reputation

are preferred when asking files, this phenomenon

soon triggers an explosive effects: loyal agents are

marginalized, and never get asked for files. This

results in a very low average reputation for loyal

agents (around 70 after 2000 turns) and a very high

average value for malicious agents (more than 2800)

at the same time. In experiment 1 the basic RMS

presented here, changes this result; even with a low

negative payoff (3) the average reputations after

2000 turns, the results are clear: about 700 for loyal

agents and slightly more than 200 for malicious

ones. The algorithm preserves loyal agents, while

punishing malicious ones. In experiment 2, with a

higher verification percentage (human factor), we

see a tremendous improvement for the effectiveness

of the RMS algorithm. The average reputation for

loyal agents, after 2000 steps, reaches almost 1400,

while all the malicious agents go under the lower

threshold (they can’t either download or share

resources), with an average reputation of less than 9

points. Experiment 3 explores the scenario in which

the users just check 30% of the files they download,

but the negative payoff is raised from 3 to 4. The

final figure about average reputations is again very

good. Loyal agents, after 2000 steps, averagely

reach a reputation of over 1200, while malicious

ones stay down at about 40. This again proves the

proposed RMS system to be quite effective, though,

with a low verification rate, not all the malicious

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

agents get under the lower threshold, even if the

negative payoff is 4. In experiment 6 the verification

percentage is again at the more realistic 40%, while

negative payoff is reduced to 2. Even with this low

negative payoff, the results are good: most malicious

agents fall under the lowest threshold, so they can’t

share files and they get an average reputation of

about 100. Loyal agents behave very well and reach

an average reputation of more than 900. Experiment

4 is the one in which we wanted to harshly penalize

inauthentic file sharing (negative payoff is set at 8),

while leaving an high laxity in the verification

percentage (30%). Unlikely what it could have been

expected, this setup does not punish too much loyal

agents that, unwillingly, spread unchecked

inauthentic files. After 2000 turns, all the malicious

agents fall under the lowest threshold, and feature an

average reputation of less than 7 points, while loyal

agents fly at an average of almost 1300 points. The

fact that no loyal agent falls under the “point of no

return” (the lowest threshold) is probably due to the

fact that they do not systematically share inauthentic

files, while malicious agents do. Loyal ones just

share the inauthentic resources they never check.

Malicious agents, on the other side, always send out

inauthentic files when asked for a resource they do

not own, thus being hardly punished by the RMS,

when the negative payoff is more than 3.

4.3 Comeback Mode

It is straightforward to imagine that an agent could

simply disconnect and reconnect to the network, in

order to start from an initial reputation value and

overcome the limits of this RMS. In order to

simulate this, a “comeback mode” (CBM) has been

implemented in the simulation. The agents, when

reaching the lowest threshold, are simply reset to the

initial reputation value (that’s what would happen if

they disconnected and reconnected).

Even with CBM activated, the results are very

similar to those in which this mode is off. They are

actually a bit worse when the negative payoff is low

(3) and so is the verification percentage (30%): the

ratio of inauthentic files in the network is quite high,

at about 41% after 2000 turns versus the 27%

observed in experiment 1, which had the same

parameters, but no CBM. When the verification

percentage is increased to 40%, though, things get

quite better. Now the ratio of inauthentic files has

the same levels as in experiment 2 (less than 1%

after 2000 steps). Also with a lower verification

percentage (again at 30%), but leaving the negative

payoff at 4, the figure is almost identical to the one

with the same parameters, but without a CBM. After

2000 turns, the inauthentic files ratio is about 12%.

The experiments show that malicious agents,

even resetting their own reputation after going below

the lowest threshold, can’t overcome this basic

RMS, if they always produce inauthentic files. This

happens because, even if they reset their reputation

to the initial value, it’s still low compared to the one

reached by loyal agents; if they shared authentic

files, this value would go up in few turns, but since

they again start spreading inauthentic files, they

almost immediately fall under the thresholds again.

4.4 Scaling Issue

Changing the numbers of agents, agent based

models can suffer from scaling issues, meaning that

the results obtained with a certain number of agents

don’t hold when this number changes significantly.

To verify this, two more experiments were carried

on. The number of agents is increased to 150 (three

times the previous value). Coherently, the number of

edges, the initial pool of resources and the number

of resources introduced at each turn are also tripled.

The trend is very similar: with a low negative payoff

(3) and a low verification rate (30%), we have just a

slightly higher ratio of inauthentic files. The same

comparison is carried on with the average final

reputations. Again, the results are very similar, even

if the system with more agents has a slightly worse

aggregate behaviour than the smaller one. Generally

speaking we conclude that the difference is very

low, so the scaling issue is not influencing the

results shown, on a 1:3 basis. In future works this

study will be extended to even more agents.

5 CONCLUSIONS

AND OUTLOOK

First of all in this paper we look for the factors

controlled by users determining the effectiveness of

RMSs in P2P network. Two are the critical points:

the decision of sharing inauthentic files and the

decision to verify or not the downloaded files.

While the benefit of not verifying is determined

by the saved time (verifying is incompatible with

making new searches and starting new downloads),

the benefit of spreading inauthentic files must be

confirmed by the simulation. Without the

mechanism for punishing malicious agents,

inauthentic files increase sharply, and at the end of

simulation the reputation of malicious agents is

SIMULATING THE HUMAN FACTOR IN REPUTATION MANAGEMENT SYSTEMS FOR P2P NETWORKS - An

Agent Based Model

much higher than loyal ones', and this is reached

very soon. Thus, producing inauthentic files is a

worthy strategy, under no enforcement mechanism.

However, the behaviour of malicious agents

strikes back against them: they are not attackers and

have the goal of downloading resources, as well.

Here we assume that if a file is verified, then the

reputation of the uploader is decreased immediately,

due to the lower cost of this action. A more fine

grained model should consider also this human

factor. Analogously we do not consider the

possibility to punish peers without first receiving

and checking a file - a behaviour which should be

prevented by the software itself - as well as we do

not consider the possibility of punishing even if the

file is authentic. As stated in the Introduction, our

goal is to model the behaviour of normal user, not of

hackers attacking the system.

The second question of the work is: how to

evaluate the role of these factors by means of agent

based simulation? Which factors have most impact?

The simulation framework for reputation gives

interesting results: the key factor to lower the

number of inauthentic files in a file sharing P2P

system is the proportion of verifications made by

peer. Even a low figure like 30% sharply limits the

behaviour of malicious agents when we do not

consider the possibility of whitewashing after

comeback. The role of punishment, in terms of

reputation points, has instead a more limited impact.

Surprisingly, even when whitewashing is

allowed, the number of inauthentic files in the

system can be limited if peers verify files 40% of the

times. The same results cannot be achieved by

increasing the figure of the punishment and

decreasing the proportion of verifications.

The moral of our study is that a mechanism for

stimulating users to check the authenticity of files

should be promoted, otherwise the entire file sharing

system is flooded by inauthentic files. In contrast,

usual approaches to RMS (Josang et al., 2007)

consider verification as automatic, thus ignoring the

human factor: since we show that verification has a

sharp effect according to its rate, it cannot be

ignored in simulating the effect of a RMS. Thus, we

identify the conditions when even a simple RMS can

dramatically reduce the number of inauthentic files

over a P2P system and penalize malicious users,

without banishing them from the network, as

proposed in other models based on ostracism. The

proposed model is very simple. The reader must be

aware of several limitations, which are the object of

ongoing work. Resources are not divided in

categories; inauthentic files, in reality, are mostly

found in newer resources. Thus, we are aiming at

using real data to differentiate the kinds of resources,

distinguishing in particular newly requested

resources. At present we distinguish malicious

agents from loyal agents based on their response, but

all the agents have the same behaviour for other

aspects, e.g. they verify with the same proportion. It

could be useful to simulate using different

parameters in each agent of the two classes.

Bandwidth is not considered: thus all downloads

proceeds at the same rate, even if the decision to

upload to a peer is based on his reputation.

Moreover, a peer decides to upload on the basis of

which agent has the highest reputation. It is well

known that this algorithm can create unbalance

among peers, but we abstract here from this

problem, since we are not proposing a new P2P

mechanism but checking the efficacy of a RMS on

the specific problem of inauthentic files. Note,

however, that this strategy has a negative effect

when malicious peers get high reputation, but if the

reputation system is well tuned, malicious agents

should never get high reputation.

Finally, we allow agents to disconnect and

reconnect, but this whitewashing happens without

changing their position on the graph, or behaviour.

The real improvement in our ongoing work,

however, is moving from reactive agents to more

sophisticated ones, able to learn from what is

happening in the network. While in the current

model agents stochastically decide whether to

upload an inauthentic file or not, or to verify or not,

cognitive agents adapt to the circumstances, looking

how many objectives they can achieve using their

current strategy, and looking for new alternatives.

Modelling adaptive agents allows to check for

further vulnerabilities, like what happens when

agents produce inauthentic files at a variable rate

which does not decrease too much their reputation.

REFERENCES

Josang A., Ismail R, and Boyd. C., 2007. A survey of trust

and reputation systems for online service provision.

Decis. Support Syst., 43(2): pp 618–644.

Kamvar S. D., Schlosser M. T., and Garcia-Molina H.,

2003. The eigentrust algorithm for reputation

management in p2p networks. In WWW ’03:

Proceedings of the 12th international conference on

World Wide Web, pp 640–651, USA, ACM Press.

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies
