MODELING SERVICE SYSTEMS

IN SERVICE-ORIENTED ENVIRONMENTS

Dionisis X. Adamopoulos

Department of Technology Education & Digital Systems, University of Piraeus, Greece

Keywords: Service design, New telecommunications services, Service engineering, Service creation, UML.

Abstract: The advent of deregulation combined with new opportunities opened by advances in telecommunications

technologies has significantly changed the paradigm of telecommunications services, leading to a dramatic

increase in the number and type of services that telecommunication companies can offer. Building new

advanced multimedia telecommunications services in a distributed and heterogeneous environment is very

difficult, unless there is a methodology to support the entire service development process in a structured and

systematic manner, and assist and constrain service designers and developers by setting out goals and

providing specific means to achieve these goals. Therefore, in this paper, after a brief presentation of a

proposed service creation methodology, its service design phase is examined in detail focusing on the

essential activities and artifacts. In this process, the exploitation of important service engineering techniques

and UML modelling principles is especially considered. Finally, alternative and complementary approaches

for service design are highlighted and a validation attempt is briefly outlined.

1 INTRODUCTION

There is a need to support the complex service

creation process in order to ensure that resulting

services actually perform as planned and as required

by customers and service providers. In this paper, in

order to structure and control the service

development process from requirements capture and

analysis to service implementation, to reduce the

inherent complexity, and to ensure the thorough

compatibility among the many involved tasks, a

service creation methodology, conformant to the

open service architectural framework specified by

the Telecommunications Information Networking

Architecture Consortium (TINA-C) (Berndt,

2003)(TINA-C, 2003), is proposed.

2 THE PROPOSED SERVICE

CREATION METHODOLOGY

Telecommunications operators need to master the

complexity of service software, because of the

highly diversified market demands, and

consequently, because of the necessity to quickly

and economically develop and introduce a broad

range of new services. To achieve such an

ambitious, yet strategic to the telecommunications

operator’s goal, a service creation methodology

based on the rich conceptual model of TINA-C is

proposed (Adamopoulos, 2003).

The proposed service development process is

based on an iterative and incremental, use case

driven approach. An iterative service creation life

cycle is adopted, which is based on successive

enlargement and refinement of a telematic service

through multiple service development cycles within

each one the telematic service grows as it is enriched

with new functions. More specifically, after the

requirements capture and analysis phase, service

development proceeds in a service formation phase,

through a series of service development cycles. Each

cycle tackles a relatively small set of service

requirements, proceeding through service analysis,

service design, service implementation and

validation, and service testing. The telematic service

grows incrementally as each cycle is completed.

In the following paragraphs the service design

phase of the proposed methodology is examined

focusing on its essential characteristics and artifacts.

X. Adamopoulos D.

MODELING SERVICE SYSTEMS IN SERVICE-ORIENTED ENVIRONMENTS.

DOI: 10.5220/0001821600850088

In Proceedings of the Fifth International Conference on Web Information Systems and Technologies (WEBIST 2009), page

ISBN: 978-989-8111-81-4

3 THE SERVICE DESIGN PHASE

During this phase the service developer defines the

behaviour of the service concepts (service

Information Objects, IOs) that were identified in the

service analysis phase and structures the telematic

service in terms of interacting service computational

objects (service components or service objects),

which are distributable, multiple interface service

objects. They are the units of encapsulation and

programming. While service IOs mainly explain

how a service is defined, service Computational

Objects (COs) reveal what actions have to be

performed in order to execute the service. Therefore,

the output of this phase is (mainly) the dynamic

view of the internal structure of the telematic

service.

Initially important characteristics of the user

interface of the service are defined by examining the

related prototype (produced during service analysis)

and taking into account the feedback from the users

of the service. The adherence to specific GUI

standards and user interface design principles is also

decided in this activity. The application of the

Model-View separation principle, according to

which the service logic should not be bound to a

particular user interface, is proposed (Constantine,

2005)(Larman, 2006).

After identifying the service COs, by taking into

account the service conceptual model(s) and the

TINA-C service architecture, a (separate) service

interaction diagram is created for each service

operation under development in the current service

development cycle. Service interaction diagrams

illustrate how service objects communicate in order

to fulfil the service requirements. More specifically,

initially the expanded use cases suggested the

service events which were explicitly shown in

service sequence diagrams, then an initial best guess

at the effect of these service events was described in

service operation contracts, and finally the identified

service events represent messages that initiate

service interaction diagrams, which illustrate how

service objects interact via messages to fulfil the

required tasks.

Therefore, service interaction diagrams reveal

choices in assigning responsibilities to service

objects. The responsibility assignment decisions are

reflected in the messages that are sent to different

service objects. Responsibilities are related to the

obligations that a service object has in terms of its

behaviour. In the service implementation phase,

methods will be implemented to fulfil responsibili-

ties or alternatively responsibilities will be

implemented using methods, which either act alone

or collaborate with the methods of other service

objects.

UML defines two kinds of interaction diagrams,

either of which can be used to express similar or

even identical message interactions; namely collabo-

ration diagrams, which illustrate object interactions

in a graph or network format, and sequence

diagrams, which illustrate interactions in a kind of

fence format (Evits, 2006). The use of collaboration

diagrams for the expression of service interaction

diagrams is preferred over the use of sequence

diagrams, because collaboration diagrams are

characterised by expressiveness, an ability to convey

more contextual information (such as the kind of

visibility between service objects), and a relative

spatial economy.

Nevertheless, either notation can express similar

constructs. What is really important is that service

interaction diagrams is one of the most significant

artifacts created during both service analysis and

service design, because the skilful assignment of

responsibilities to service objects and the design of

collaborations between them are two of the most

critical (for the satisfaction of the service require-

ments and thus for the successful realisation of a

service) and unavoidable tasks (which also require

the application of design skill) that have to be

performed during service creation (Larman, 2006).

This activity of the service design phase consists

mainly from the following steps:

Step 1:

Identify the service COs.

During this step, the service IOs depicted in the

service conceptual models (main and ancillary) that

were created in the service analysis phase are

considered as potential candidates for service COs.

In many cases, service IOs are mapped to one

corresponding service CO encapsulating the

information defined by the service IO and providing

an operational interface to access that information.

However, the mapping between service IOs and

service COs is not necessarily one to one.

Furthermore, the existence of a relationship between

service IOs, either provides a good rationale for

encapsulating them together in the same service CO

or indicates the need for a binding between

interfaces of their corresponding service COs

(Declan, 2000)(Demestichas, 2004). This mapping

process is significantly simplified by adopting the

use of the generic (access session, service session,

and communication session related) service COs,

proposed by the TINA-C service architecture

(TINA-C, 2003), in terms of their identified

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

functionality and not in terms of specific interfaces /

feature sets.

Step 2:

Consider the generic TINA-C service scenar-

ios and select the most appropriate.

After identifying the service COs and before

proceeding to the construction of the service

interaction diagrams, the computational views of a

number of generic TINA-C service scenarios,

deduced by the computational modelling guidelines

of TINA-C (TINA-C, 2003), should be considered.

These are useful for improving structure and general

comprehension throughout the service design phase,

and for offering to the service developer(s) a generic

pattern of thought, compatible with fundamental

TINA-C concepts, that he / she could use / consider

when designing the service interaction diagrams.

Step 3:

Form the service interaction diagrams.

A telematic service is composed of a set of

service COs interacting with each other via

messages with the objective to complete the required

service operations. The service operation contracts

present an initial best guess at responsibilities and

post conditions for the service operations. Service

interaction diagrams illustrate the proposed design

solution (in terms of service COs) that satisfies

theses responsibilities and post conditions, and

therefore the corresponding service operations.

A service interaction diagram in the form of a

UML collaboration diagram is created for each one

of the service operations that were identified in the

service analysis phase. The objective is to fulfil the

responsibilities and the post-conditions of the corre-

sponding service operation contracts, recognising

however that their accuracy should be questioned.

As was explained in step 1 of this activity the

service COs that participate in the service interaction

diagrams are drawn from the service conceptual

model(s). Therefore, the links between them are ac-

tually instances of the associations present in the ser-

vice conceptual model(s), represent connection paths

between service object instances, and indicate that

some form of navigation between the instances is

possible. More specifically, in order for a service

object to send a message to another service object it

must have visibility to it. Thus, it is important to en-

sure that the necessary (attribute, parameter, locally

declared or global) visibility is present in order to

support the required message interaction (Jacobson,

2006)(Larman, 2006).

Finally, all telematic services have a “Start Up”

use case and some initial service operation related to

the starting up of the telematic service. Therefore,

there should also be a “Start Up” service interaction

diagram, which is proposed to be created last.

Although the “Start Up” service operation is the

earliest one to execute, the development of its

service interaction diagram should be delayed until

after all other service operations have been

considered. This ensures that significant information

has been discovered concerning what initialisation

activities are required to support the “Start-Up”

service operation interaction diagram. The way that

a telematic service starts and initialises is affected by

related concepts / guidelines in the TINA-C service

architecture (e.g. it is assumed that the IA must be

present at the provider domain), and is dependent

upon the DPE, the programming language, and the

operating system that is being used.

Another important artifact created during service

design is the service design class diagram, which

illustrates the specifications for the software classes

of a telematic service using a strict and very infor-

mative notation. More specifically, from the service

interaction diagrams the service designer identifies

the software classes (service classes) that participate

in the software realisation of the telematic service

under examination, together with their methods, and

from the service conceptual model(s) the service

designer adds detail to the service class definitions.

A service design class diagram typically includes

/ illustrates service classes, their attributes and

methods, attribute type information, navigability,

and associations and dependencies between service

classes. In practice, service design class diagrams

and service interaction diagrams are usually created

in parallel. Furthermore, in contrast with a service

conceptual model, a service design class diagram

shows definitions of software entities (service

components), rather than real-world concepts.

In the service design phase, Specification and

Description Language (SDL) can be used to describe

the behaviour of a telematic service exploiting the

finite state machine concept. Then, the SDL specifi-

cation will serve also as a basis for validation, simu-

lation and test case generation (Combes, 2005). In

general, for making formal models of telematic

services and being able to reason about these

models, SDL is undoubtedly the notation of choice,

as the tool support for SDL is perhaps the most

advanced of all the formal notations existing today.

However, adopting an SDL-based approach cannot

guarantee that the developed services will be error

free and the value of SDL for service creation

purposes is questioned, as it may introduce

unnecessary complexity in the service design phase.

Furthermore, the application of SDL can be difficult

(or even problematic) in the case of relatively

complex telematic services with many service

MODELING SERVICE SYSTEMS IN SERVICE-ORIENTED ENVIRONMENTS

objects interacting in non-trivial ways, due to the

problem of state space explosion.

In the service design phase, service COs have a

dominant role. Their interfaces are the result of the

examination of the service IOs and the correspond-

ing information models that they participate in,

which reveal the way that service IOs are related to

each other. This aggregation of interfaces into a ser-

vice CO ensures the semantic understanding that op-

erations at one interface may affect the behaviour of

other interfaces because they may be linked by a

common, underlying information model captured by

the service CO. Therefore, such information models

influence considerably the parameters and the se-

mantics of the operations found on the interfaces of

the service COs.

In order to aid the service development process

TINA-C, proposes and prescribes a set of generic

interfaces for the generic TINA-C service COs.

These interfaces correspond to the interactions that

take place between business administrative domains,

support a particular session role, and are defined by

the appropriate reference point specifications.

TINA-C assembles the proposed interfaces into

feature sets (TINA-C, 2003).

4 CONCLUDING REMARKS

Real use cases are members of the service design use

case model, and service interaction diagrams are

members of the service object behaviour model,

because they describe the behaviour of service COs,

and service design class diagrams compose the

service class model. Furthermore, for reasons of

completeness, the service design model includes

service state diagrams for service COs / classes as

members of the service design state model. Such

diagrams may be useful to summarise the results of a

service design (at the end of the service design

phase) or when the service code is to be produced

with a code generator that will be driven by the state

diagrams.

Finally, it has to be stressed that the proposed

service creation methodology (and thus its service

design phase) was validated and its true practical

value and applicability was ensured as it was applied

to the design and development of a real complex

representative telematic service (a MultiMedia

Conferencing Service for Education and Training,

MMCS-ET). More specifically, a variety of

scenarios were considered involving the support of

session management requirements (session estab-

lishment, modification, suspension, resumption, and

shutdown), interaction requirements (audio / video,

text, and file communication), and collaboration

support requirements (chat facility, file exchange

facility, and voting). Considering all the artifacts

produced in the service design phase, the MMCS-ET

was implemented using Microsoft’s Visual C++ to-

gether with Microsoft’s Distributed Component

Object Model (DCOM) (Adamopoulos, 2002)

(appropriately extended with a high-level API in

order to support continuous media interactions) as a

distributed object-oriented environment.

REFERENCES

Adamopoulos, D.X., Pavlou, G., Papandreou, C.A., 2003.

Advanced Service Creation Using Distributed Object

Technology. In IEEE Communications Magazine, Vol.

40, No. 3, pp. 146-154.

Adamopoulos, D.X., Pavlou, G., Papandreou, C.A., 2002.

Continuous Media Support in the Distributed

Component Object Model. In Computer Communica-

tions, Vol. 25, No. 2, 2002, pp. 169-182.

Berndt, H., Hamada, T., Graubmann, P., 2003. TINA: Its

Achievements and its Future Directions. In IEEE

Communications Surveys & Tutorials, Vol. 3, No. 1.

Combes, P., Renard, B., 2005. Service Validation. In

Computer Networks, Vol. 31, No. 17, pp. 1817-34.

Constantine, L.L., Lockwood, L.A.D., 2005. Software for

Use: A Practical Guide to the Models and Methods of

Usage-Centered Design, Addison-Wesley.

Declan, M., 2000. Adopting Object Oriented Analysis for

Telecommunications Systems Development. In Pro-

ceedings of IS&N ’00, LNCS, Vol. 1238, Springer-

Verlag, pp. 117-125.

Demestichas, P.P., et al, 2004. Issues in Service Creation

for Open Distributed Processing Environments. In

Proceedings of ICC ’04, Vol. 1, pp. 273-279.

Evits, P., 2006. A UML Pattern Language. Macmillan

Technology Series.

Jacobson, I., Booch, J., Rumbaugh, J., 2005. Unified Soft-

ware Development Process. Addison-Wesley.

Larman, C., 2006. Applying UML and Patterns: An

Introduction to Object-Oriented Analysis and Design

and the Unified Process. Prentice Hall.

TINA-C, 2003. Service Architecture. Version 5.0.

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies
