SITEGUIDE: AN EXAMPLE-BASED APPROACH TO WEB SITE

DEVELOPMENT ASSISTANCE

Vera Hollink, Viktor de Boer and Maarten van Someren

University of Amsterdam, Science Park 107, Amsterdam, The Netherlands

Keywords:

Information architecture, Web site modeling, Web site design support.

Abstract:

We present ‘SiteGuide’, a tool that helps web designers to decide which information will be included in a new

web site and how the information will be organized. SiteGuide takes as input URLs of web sites from the

same domain as the site the user wants to create. It automatically searches the pages of these example sites

for common topics and common structural features. On the basis of these commonalities it creates a model

of the example sites. The model can serve as a starting point for the new web site. Also, it can be used to

check whether important elements are missing in a concept version of the new site. Evaluation shows that

SiteGuide is able to detect a large part of the common topics in example sites and to present these topics in an

understandable form to its users.

1 INTRODUCTION

Even the smallest companies, institutes and associa-

tions are expected to have their own web sites. How-

ever, designing a web site is a difﬁcult and time-

consuming task. Software tools that provide assis-

tance for the web design process can help both am-

ateur and professional web designers.

Newman and Landay (2000) studied the current

practices in web design and identiﬁed four main

phases in the design process of a web site: discov-

ery, design exploration, design reﬁnement and pro-

duction. A number of existing tools, such as Adobe

Dreamweaver

and Microsoft Frontpage

provide

help for the latter two phases, where an initial design

is reﬁned and implemented. These tools however,

do not support collecting and structuring the content

into an initial conceptual model (Falkovych and Nack,

2006). In this paper, we present ‘SiteGuide’, a system

that helps web designers to create a setup for a new

site. Its output is an initial information architecture

for the target web site that shows the user what infor-

mation should be included in the website and how the

information should be structured. Figure 1 shows a

screenshot of the SiteGuide system.

An important step in the discovery phase of web

http://www.adobe.com/products/dreamweaver

http://ofﬁce.microsoft.com/frontpage

site design is reviewing web sites from the same do-

main as the target site (Newman and Landay, 2000).

For instance, a person who wants to build a site for

a small soccer club will often look at web sites of

some other small soccer clubs. The information ar-

chitectures of the examined sites are used as source

of inspiration for the new site.

Reviewing example sites can provide useful infor-

mation, but comparing sites manually is very time-

consuming and error-prone, especially when the sites

consist of many pages. The SiteGuide system cre-

ates an initial information architecture for a new site

by efﬁciently and systematically comparing a set of

example sites identiﬁed by the user. SiteGuide auto-

matically searches the sites for topics and structures

that the sites have in common. For example, in the

soccer club domain, it may ﬁnd that most example

sites contain information about youth teams or that

pages about membership always link to pages about

subscription fees. The common topics are brought to-

gether in a model of the example sites. The model

is presented to the user and serves as an information

architecture for the new web site.

SiteGuide can also be used in the design reﬁne-

ment phase of the web design process as a critic of

a ﬁrst draft of a site. The draft is compared with the

model, so that missing topics or unusual information

structures are revealed.

143

Hollink V., de Boer V. and van Someren M.

SITEGUIDE: AN EXAMPLE-BASED APPROACH TO WEB SITE DEVELOPMENT ASSISTANCE.

DOI: 10.5220/0001825401430150

In Proceedings of the Fifth International Conference on Web Information Systems and Technologies (WEBIST 2009), page

ISBN: 978-989-8111-81-4

Figure 1: A screenshot of the SiteGuide system showing a topic for a web site of a hotel.

2 PROBLEM DEFINITION

The SiteGuide system has two main usage scenarios,

shown in Figure 2. In both scenarios the user starts the

interaction by inputting the URLs of the home pages

of a small set of example web sites. SiteGuide then

scrapes and analyzes the sites and captures their com-

monalities in a web site model. The model forms the

suggested information architecture for the new site.

In the modeling scenario the information architecture

is the end point of the interaction and is outputted

to the user. In the critiquing scenario the user has

already created a ﬁrst draft version of his new site.

SiteGuide compares the draft with the model of the

example sites and outputs the differences.

Figure 3 shows the structure of an example site

model. A model consists of a set of topics that ap-

pear in the example sites. To communicate the model

to a user, SiteGuide describes each topic with a set

of characterizing features. These features explain to

the user what the topic is about. They consist of key

example

sites

draft of

new site

differences

model

human

readable

statements

human

readable

statements

build

model

compare

format

Figure 2: The two usage scenarios of the SiteGuide sys-

tem. − denotes the modeling scenario. − denotes the

critiquing scenario.

topic B

features

...

topic C

features

...

topic D

features

...

topic A

structural features

characterizing features

topic E

features

...

● keywords: weather, wind

● title: Weather conditions

● example page:

www.surf.com/weather.html

...

● on average 2.1 pages

● on average 6 incoming links

...

Figure 3: Example of an example site model. A model con-

sists of topics that have characterizing and structural fea-

tures (only shown for topic A). Frequently occurring hyper-

links between topics are denoted by arrows.

phrases which are extracted from the contents of the

pages that handle on the topic as well as titles of these

pages, anchor texts of links pointing to the pages and

terms from the page URLs. Additionally, SiteGuide

shows a link to a page that exempliﬁes the topic.

To inform the user on how a topic should be em-

bedded in the site, SiteGuide shows structural fea-

tures that describe how the topic is represented in the

pages of the example sites. It shows the average num-

ber of pages about the topic, the average number of

incoming and outgoing links for those pages and links

between topics (e.g., pages on topic A frequently link

to pages on topic B).

In the modeling scenario the topics of the model

are presented to the user as a set of natural language

statements. The screenshot in Figure 1 shows the cur-

rent visualization of the output of a topic. The infor-

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

144

mation architecture is also exported to an XML ﬁle,

so that it can be imported into other web design tools

that provide alternative visualizations, such as proto-

typing or wireframing tools.

The output of the critiquing scenario is a set of

similar statements that describe the differences be-

tween the example sites and the draft. In this scenario

SiteGuide indicates which topics are found on most

example sites but not on the draft site and which top-

ics are found on the draft site but not in any of the

example sites. In addition, it outputs topics that are

both on the draft and the example sites, but that have

different structural features.

3 METHOD

The main task of SiteGuide is to ﬁnd topics that oc-

cur on most example sites. For this, SiteGuide iden-

tiﬁes pages of different example sites that handle on

the same topic and maps these pages onto each other.

A mapping can be seen as a set of page clusters. Each

cluster contains all pages from example sites that han-

dle on one topic.

We design our clustering format in such a way that

it is able to capture differences between web sites in

the information they present and in the way the infor-

mation is organized. All pages of the example sites

must occur in at least one page cluster, but pages may

occur in multiple clusters. In the simplest case a clus-

ter contains one page from each example site. For

example, a cluster can contain for each site the page

about surﬁng lessons. However, if on one of the sites

the information about surﬁng lessons is split over sev-

eral pages, these pages are placed in the same cluster.

It can also happen that a cluster does not contain pages

from all sites, because some of the sites do not con-

tain information on the cluster’s topic. Pages occur

in more than one cluster, when they contain content

about more than one topic.

We developed a heuristic method to ﬁnd a good

mapping between a set of example sites. A space of

possible mappings is deﬁned and searched for a good

mapping. Below we ﬁrst explain how SiteGuide mea-

sures the quality of a mapping. Then we explain how

it searches for the mapping that maximizes the quality

measure. Finally, the generation of the example site

model from the mapping and the comparison between

the model and a draft of the new site are discussed.

3.1 Quality Measure

As in most clustering tasks, the quality of an example

site mapping is better when the pages in the clusters

are more similar to each other. However, in most do-

mains pages of one site are more similar to pages on

the same site that handle on other topics than to pages

of other sites on the same topic. As a result, a stan-

dard clustering method would mainly form groups of

pages from one example site instead of identifying

topics that span multiple sites. We solve this prob-

lem by focussing on similarities between pages from

different sites. We deﬁne the quality of a page cluster

as the average similarity of the pages in the cluster to

all other pages in the cluster from other web sites.

Most web pages contain some text, so that text

similarity measures can be used to compute the sim-

ilarity between two pages. However, web pages are

not stand-alone texts, but part of a network that is con-

nected by links. In SiteGuide we make use of the in-

formation contained in the link structure by comput-

ing the similarity between the pages’ positions in their

link structures. As extra features we use the similar-

ity between page titles, page URL’s and the anchors

of the links that point to pages. Below, each of these

ﬁve types of similarity are discussed in more detail.

The quality of a page cluster is a combination of

the ﬁve similarity measures. The quality of cluster C

in mapping M is:

quality(C,M) =

∑

sim

∈Sims

· sim

(C,M)) − α · S

Here Sims are the ﬁve similarity measures, which are

weighted with weighting parameters w

. S

is the

number of example sites that have pages in cluster C.

α is a parameter.

The term −α · S

subtracts a ﬁxed amount (α)

for each of the S

sites in the cluster. Consequently,

adding pages of a site to a cluster only improves the

cluster’s score if the pages bear a similarity of at least

α to the pages of the other sites in the cluster. In this

way the size of the clusters is automatically geared

to the number of sites that address the same topic, so

that we do not need to specify the number of clusters

beforehand.

Text similarity between two pages is expressed as

the cosine similarity between the terms on the pages

(Salton and McGill, 1983). This measure enables

SiteGuide to identify parts of the texts that pages have

in common and ignore site-speciﬁc parts. Stop word

removal, stemming and t f · id f weighting are applied

to increase accuracy.

Anchor text similarity between two pages is de-

ﬁned as the cosine similarity between the anchor texts

of the links that point to the pages. For the computa-

tion of page title similarity and URL similarity we use

the Levenshtein distance (Levenshtein, 1966) instead

of the cosine similarity. Levenshtein distance is more

suitable for comparing short phrases as it takes the or-

SITEGUIDE: AN EXAMPLE-BASED APPROACH TO WEB SITE DEVELOPMENT ASSISTANCE

145

der of terms into account and works at character level

instead of term level.

We developed a new measure to compute the sim-

ilarity between the positions of two pages in their

link structures. We look at the direct neighborhood

of each page: it’s incoming and outgoing links. The

link structure similarity of a cluster is the propor-

tion of the incoming and outgoing links of the pages

that are mapped correctly. Two links in different link

structures are mapped correctly onto each other if

both their source pages and their destination pages are

mapped onto each other.

3.2 Finding a Good Mapping

A naive approach for ﬁnding a mapping with a high

quality score would be to list all possible mappings,

compute for each mapping the quality score, and

choose the one with the highest score. Unfortunately,

this approach is not feasible, as the number of possi-

ble mappings is extremely large (Hollink et al., 2008).

To make the problem computationally feasible, we

developed a search space of possible mappings that

allows us to heuristically search for a good mapping.

We start our search with an initial mapping that is

likely to be close to the optimal solution. In this map-

ping each page occurs in exactly one cluster and each

cluster contains no more than one page from each ex-

ample site. The initial mapping is built incrementally.

First, we create a mapping between the ﬁrst and the

second example site. For each two pages of these

sites we compute the similarity score deﬁned above.

The so called Hungarian Algorithm (Munkres, 1957)

is applied to the two sites to ﬁnd the one-to-one map-

ping with the highest similarity. Then, the pages of

the third site are added to the mapping. We compute

the similarity between all pages of the third site and

the already formed pairs of pages of the ﬁrst two sites

and again apply the Hungarian Algorithm. This pro-

cess is continued until all example sites are included

in the initial mapping.

We deﬁne ﬁve mapping modiﬁcation operations

that can be used to traverse the search space. To-

gether, these operations sufﬁce to transform any map-

ping into any other mapping. This means that the

whole space of possible mappings is reachable from

any starting point. The operations are:

• Split a cluster: the pages from each site in the clus-

ter are placed in a separate cluster.

• Merge two clusters: place all pages from the two

clusters in one cluster.

• Move a page from one cluster to another cluster.

• Move a page from a cluster to a new, empty cluster.

• Copy a page from one cluster to another cluster.

With these operations SiteGuide reﬁnes the ini-

tially created mapping using a form of hill climbing.

In each step it applies the operations to the current

mapping and computes the effect on the similarity

score. When an operation improves the score it is re-

tained; otherwise it is undone. It keeps trying modiﬁ-

cation operations until it can not ﬁnd any more opera-

tions that improve the score with a sufﬁcient amount.

The ﬁve operations can be applied to all clus-

ters. To increase efﬁciency, SiteGuide tries to improve

clusters with low quality scores ﬁrst.

3.3 From Mapping to Model

The next step is to transform the mapping into a model

of the example sites. The mapping consists of page

clusters, while the model should consist of descrip-

tions of topics that occur on most of the example sites.

Each cluster becomes a topic in the model. Topics

are characterized by the ﬁve characterizing features

mentioned in Section 2. SiteGuide lists all terms from

the contents of the pages and all URLs, titles and an-

chor texts. For each type of term we designed a mea-

sure that indicates how descriptive the term or phrase

is for the topic. For instance, content terms receive a

high score if they occur in all example sites frequently

in pages on the topic and infrequently on other pages.

These scores are multiplied by the corresponding sim-

ilarity scores, e.g., the score of a content term is mul-

tiplied by the topic’s content similarity. The result of

this is that features that are more important for a topic

are weighted more heavily. The terms and phrases

with scores above some threshold (typically 3 to 10

per feature type) become characterizing features for

the topic. The most central page in the cluster (the

page with the highest text similarity to the other pages

in the cluster) becomes the example page for the topic.

To ﬁnd the structural features of the topics,

SiteGuide analyzes the pages and links of the corre-

sponding page clusters. It determines for each site

over how many pages the information on a topic is

spread and counts the number of incoming and outgo-

ing links. Furthermore, it counts how often the topic

links to each other topic. The question is which of

these numbers indicate a stable pattern over the var-

ious example sites. Intuitively, we recognize a pat-

tern in, for instance, the number of outgoing links of

a topic, when on all sites the pages on the topic have

roughly the same number of outgoing links. We have

formalized this intuition: when the numbers for the

various sites have low variance, SiteGuide marks the

feature as a common structural feature.

In the current version of SiteGuide the output of

the modeling scenario consists of a series of human

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

146

readable statements (see Figure 1). For each topic

SiteGuide outputs the characterizing features, the ex-

ample page and the common structural features. In

the next version, the model will be shown graphically,

more or less like Figure 3.

For the critiquing scenario we developed a vari-

ant of the web site comparison method which en-

ables SiteGuide to compare the example site model

to a draft of the new site. This variant uses the hill

climbing approach to map the model to the draft, but

it does not allow any operations that alter the exam-

ple site model. In this way we ensure that the draft

is mapped onto the model, while the model stays in-

tact. Once the draft is mapped, SiteGuide searches

for differences between the draft and the example site

model. It determines which topics in the model do not

have corresponding pages in the draft and reports that

these topics are missing on the new site. Conversely,

it determines which topics of the draft do not have

counterparts in the example sites. Finally, it com-

pares the structural features of the topics in the new

site to the common structural features in the example

site model and reports the differences.

4 EVALUATION

To determine whether SiteGuide can provide useful

assistance to users who are building a web site, we

need to answer two questions. 1) Do the discovered

topics represent the subjects that are really addressed

at the example sites? 2) Are the topic descriptions un-

derstandable for humans? To answer the ﬁrst question

we compared mappings created by SiteGuide to man-

ually created example site mappings. For the second

question we asked humans to interpret SiteGuide’s

output.

We used web sites from three domains: windsurf

clubs, primary schools and small hotels. For each

domain 5 sites were selected as example sites. We

purposely chose very different domains: the wind-

surf clubs are non-proﬁt organizations, the school do-

main is an educational domain and the hotel domain

is commercial. Table 1 shows the main properties of

the three domains.

The SiteGuide system generated example site

models for the three domains. We compared these

models to gold standard models that we had con-

structed by hand. The gold standard models consisted

of a mapping between the example sites and for each

page cluster a textual description of the topic that was

represented by the cluster. The textual descriptions

were 1 or 2 sentences in length and contained around

20 words. For example, in the school domain one

Table 1: Properties of the evaluation domains and the gold

standards (g.s.): the total, minimum and maximum number

of pages in the example sites, the number of topics in the

g.s., the number of topics that were found in at least 50% of

the sites (frequent topics) and the percentage of the pages

that were mapped onto at least one other page.

domain total min-max topics frequent % pages

pages pages in g.s topics mapped

in g.s. in g.s.

hotel 59 9-16 21 7 81%

surﬁng 120 8-61 90 12 76%

school 154 20-37 42 17 80%

topic was described as ‘These pages contain a list of

staff members of the schools. The lists consist of the

names and roles of the staff members.’. Features of

the gold standards are given in Table 1.

To validate the objectivity of the gold standards,

for one domain (hotels) we asked another person to

create a second gold standard. We compared the top-

ics in the two gold standards and found that 82% of

the topics were found in both gold standards. From

this we concluded that the gold standards were quite

objective and are an adequate means to evaluate the

output of SiteGuide.

4.1 Evaluation of the Mappings

First, we evaluated the page clusters that were gener-

ated by SiteGuide to see to what extend these clusters

coincided with the manually created clusters in the

gold standards, in other words, to what extend they

represented topics that were really addressed at the

example sites. We counted how many of the clusters

in the generated mapping also occurred in the gold

standards. A generated cluster was considered to be

the same as a cluster from the gold standard if at least

50% of the pages in the clusters were the same. We

considered only topics that occurred in at least half

of the example sites (frequent topics), as these are the

topics that were present on most of the example sites.

The quality of mappings is expressed by precision,

recall and f-measure over the page clusters. When

gold

are the clusters in a gold standard and C

test

are

the clusters in a generated mapping, the measures are

deﬁned as:

precision = |C

test

∩ C

gold

|/|C

test

recall = |C

test

∩ C

gold

|/|C

gold

f−measure =

(2·precision·recall)

(precision+recall)

In a pilot study (Hollink et al., 2008) we tested

the inﬂuence of the various parameters. We gener-

ated example site mappings with various weights for

SITEGUIDE: AN EXAMPLE-BASED APPROACH TO WEB SITE DEVELOPMENT ASSISTANCE

147

Table 2: Quality of the example site mappings and quality

of the comparison between drafts and example sites.

domain precision recall f-measure removed added

topics topics

detected detected

hotel 1.00 0.43 0.60 0.54 0.52

surf 0.33 0.42 0.37 0.25 0.26

school 0.47 0.41 0.44 0.33 0.88

the similarity measures. On all three domains giving

high weights to text similarity resulted in mappings

with high scores. In the hotel domain URL similar-

ity also appeared to be effective. Increasing the mini-

mum similarity parameter (α) meant that we required

mapped pages to be more similar, so that precision

was increased, but recall decreased. Thus, with this

parameter we can effectively balance the quality of

the topics that we ﬁnd against the number of topics

that are found. When the SiteGuide system is used by

a real user, it obviously cannot use a gold standard to

ﬁnd the optimal parameter settings. Fortunately, we

can estimate roughly how we should choose the pa-

rameter values by looking at the resulting mappings

as explained in (Hollink et al., 2008).

The scores of the example site models generated

with optimal parameter values are shown in Table 2.

The table shows the scores for the situation in which

all frequent topics that SiteGuide has found are shown

to the user. When many topics have been found we

can choose to show only topics with a similarity score

above some threshold. In general, this improves pre-

cision, but reduces recall.

Next, we evaluated SiteGuide in the critiquing

scenario. We performed a series of experiments in

which the 5 sites one by one played the role of the

draft site and the remaining 4 sites were example

sites. In each run we removed all pages about one of

the gold standard topics from the draft site and used

SiteGuide to compare the corrupted draft to the ex-

amples. We counted how many of the removed top-

ics were identiﬁed by SiteGuide as topics that were

missing in the draft. Similarly, we added pages to

the draft that were not relevant in the domain. Again,

SiteGuide compared the corrupted draft to the exam-

ples. We counted how many of the added topics were

marked as topics that occurred only on the draft site

and not on any of the example sites. The results are

given in Table 2.

Table 2 shows that SiteGuide is able to discover

many of the topics that the sites have in common, but

also misses a number of topics. Inspection of the cre-

ated mappings demonstrates that many of the discov-

ered topics can indeed lead to useful recommenda-

tions to the user. We give a few examples. In the

school domain SiteGuide created a page cluster that

contained for each site the pages with term dates. It

also found correctly that 4 out of 5 sites provided a list

of staff members. In the surﬁng domain, a cluster was

created that represented pages where members could

leave messages (forums). The hotel site mapping con-

tained a cluster with pages about the facilities in the

hotel rooms. The clusters can also be relevant for the

critiquing scenario: for example, when the owner of

the ﬁfth school site would use SiteGuide, he would

learn that his site is the only site without a staff list.

Some topics that the sites had in common were not

found, because the terms did not match. For instance,

two school sites provided information about school

uniforms, but on the one site these were called ‘uni-

form’ and on the other ‘school dress’. This example

illustrates the limitations of the term-based approach.

In the future, we will extend SiteGuide with WordNet

(Fellbaum, 1998), which will enable it to recognize

semantically related terms.

4.2 Evaluation of the Topic Descriptions

Until now we counted how many of the generated top-

ics had at least 50% of their pages in common with a

gold standard topic. However, there is no guarantee

that the statements that SiteGuide outputs about these

topics are really understood correctly by the users of

the SiteGuide system. Generating understandable de-

scriptions is not trivial, as most topics consist of only

a few pages. On the other hand, it may happen that

a description of a topic with less than 50% overlap

with a gold standard topic is still recognizable for hu-

mans. Therefore, below we evaluate how SiteGuide’s

end output is interpreted by human users and whether

the interpretations correspond to the gold standards.

We used SiteGuide to create output about the ex-

ample site models generated with the same optimal

parameter values as in the previous section. Since we

only wanted to evaluate how well the topics could be

interpreted by a user, we did not output the structural

features. We restricted the output for a topic to up to

10 content keywords and up to 3 phrases for page ti-

tles, URLs and anchor texts. We also displayed for

each topic a link to the example page.

Output was generated for each of the 34 frequent

topics identiﬁed in the three domains. We asked 5

evaluators to interpreted the 34 topics and to write

a short description of what they thought each topic

was about. We required the descriptions to be of the

same length as the gold standard descriptions (10-30

words). None of the evaluators were domain experts

or expert web site builders. It took the evaluators on

average one minute to describe a topic, including typ-

ing the description. By comparison, ﬁnding the topics

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

148

in the example sites by hand (for the creation of the

gold standard) took about 15-30 minutes per topic.

An expert coder determined whether the interpre-

tations of the evaluators described the same topics as

the gold standard descriptions. Since both the evalu-

ators’ topic descriptions and the gold standard topic

descriptions were natural language sentences, it was

often difﬁcult to determine whether two descriptions

described the exact same topic. We therefore had the

coder classify each description in one of three classes:

a description could either have a partial match or an

exact match with one of the gold standard topics or

have no matching gold standard topic at all. An exact

match means that the description describes the exact

same topic as the gold standard topic. A partial match

occurs when a description describes for instance a

broader or narrower topic. To determine precision the

coder matched all topic descriptions of the evaluators

to the gold standard descriptions. To determine re-

call the coder matched all gold standard descriptions

to the evaluators’ descriptions in the same manner. To

determine the objectivity of the coding task, we had a

second expert coder perform the same task. The two

coders agreed on 69% of the matches, considering the

possible variety in topic descriptions, we consider this

an acceptable level of inter-coder agreement.

Averaged over the domains and evaluators, 94% of

all evaluators’ topic descriptions were matched to one

of the gold standard topics when both partial and ex-

act matches were considered. In other words, 94% of

the topics that were found by SiteGuide corresponded

(at least partially) with a topic from the gold standard

and were also interpreted as such. When only exact

matches were counted this ﬁgure was still 73%. This

indicates that for most topics SiteGuide is capable of

generating an understandable description.

We calculated precision and recall based on the

relaxed precision and recall used in ontology match-

ing literature (Ehrig and Euzenat, 2005), resulting in

the same formula for precision and recall as in Sec-

tion 4.1, where |C

test

∩ C

gold

| is the number of exact

matches plus 0.5 times the number of partial matches.

In Table 3 we display the relaxed precision, recall and

f-measure values for the three domains. The average

precision over all domains is 0.83, showing that most

of the topics that SiteGuide found could indeed be in-

terpreted and that these interpretations corresponded

to correct topics according to our gold standard. The

average recall is 0.57, which means that more than

half of the topics from the gold standard were cor-

rectly identiﬁed and outputted by SiteGuide. Both

precision and recall do not vary much across domains,

indicating that SiteGuide is capable of identifying and

displaying topics in a wide range of domains. The re-

Table 3: Results of the manual evaluation for the three do-

mains.

domain precision recall f-measure

hotel 0.90 0.54 0.68

school 0.78 0.54 0.64

surf 0.81 0.63 0.71

sults in Table 3 are considerably better than those in

Table 2. This shows that for a number of topics where

the page overlap with the gold standard was less than

50%, the displayed topic could still be interpreted cor-

rectly by humans.

5 RELATED WORK

Existing tools for assisting web site development help

users with the technical construction of a site. Tools

such as Dreamweaver

or Frontpage

allow users to

create web sites without typing HTML. Other tools

evaluate the design and layout of a site on usability

and accessibility, checking for example for dead links

and buttons and missing captions of ﬁgures (see for

an overview (Web Accessibility Initiative, 2008; Bra-

jnik, 2004)). However, none of these tools help users

to choose appropriate contents or structures for their

sites or critique the content that is currently used.

Our approach is in spirit related to the idea of on-

tologies. The goal of an ontology is to capture the

conceptual content of a domain. It consists of struc-

tured, formalized information on the domain. The

web site models presented in this paper can be viewed

as informal ontologies as they comprise structures of

topics that occur in sites from some domain. How-

ever, our models are not constructed by human ex-

perts, but automatically extracted from example sites.

Another related set of tools are tools that im-

prove link structures of web sites, such as PageGather

(Perkowitz and Etzioni, 2000) and the menu optimiza-

tion system developed by Hollink et al. (Hollink et al.,

2007). These tools do not provide support on the con-

tents of a site. Moreover, they need usage data, which

means that they can only give advice about sites that

have been online for some time.

The algorithm that underlies the SiteGuide system

is related to methods for high-dimensional clustering,

which are, for instance, used for document cluster-

ing. However, there are several important differences.

The task of SiteGuide is to ﬁnd topics in a set of web

sites instead of an unstructured set of documents. It

is more important to ﬁnd topics that appear in many

sites than to group pages within sites. This is reﬂected

in the similarity measure. Another difference is that

in SiteGuide the relations (links) between pages are

SITEGUIDE: AN EXAMPLE-BASED APPROACH TO WEB SITE DEVELOPMENT ASSISTANCE

149

taken into account. The extent to which relations be-

tween pages within one site match the relations in

other sites contributes to the similarity between pages.

Also, the ﬁnal model of the sites includes relations be-

tween topics.

6 CONCLUSIONS

The SiteGuide system provides assistance to web de-

signers who want to build a web site but do not know

exactly which content must be included in the site.

It automatically compares a number of example web

sites and constructs a model that describes the fea-

tures that the sites have in common. The model can be

used as an information architecture for the new site.

In addition, SiteGuide can show differences between

example sites and a ﬁrst version of a new site.

SiteGuide was applied to example web sites from

three domains. In these experiments, SiteGuide

proved able to ﬁnd many topics that the sites had in

common. Moreover, the topics were presented in such

a way that humans could easily and quickly under-

stand what the topics were about.

Although the results of the evaluation are promis-

ing, user experiments are needed to test the value of

SiteGuide in practice. In an experiment we will ask

users to design a web site. Half of the users will per-

form this task with the help of SiteGuide and the other

half without. Comparison of the time needed for the

design and the quality of the resulting drafts will show

how useful the system is in practice.

In the near future SiteGuide will be extended with

a number of new features. Semantics will be added to

the similarity measure in the form of WordNet rela-

tions. We will connect the output to prototyping tools,

so that users can directly start editing the proposed

site design. Finally, SiteGuide could output additional

features such as style features (e.g., colors and use

of images) or the amount of tables, lists, forms, etc.

More research is needed to determine how these fea-

tures can be compared automatically.

REFERENCES

Brajnik, G. (2004). Using automatic tools in accessibility

and usability assurance processes. In Proceedings of

the Eighth ERCIM Workshop on User Interfaces for

All, Vienna, Austria, pages 219–234.

Ehrig, M. and Euzenat, J. (2005). Relaxed precision and

recall for ontology matching. In Proceedings of the K-

Cap 2005 Workshop on Integrating Ontologies, Banff,

Canada, pages 25–32.

Falkovych, K. and Nack, F. (2006). Context aware guid-

ance for multimedia authoring: Harmonizing do-

main and discourse knowledge. Multimedia Systems,

11(3):226–235.

Fellbaum, editor, C. (1998). WordNet: An electronic lexical

database. MIT Press, Cambridge, MA.

Hollink, V., Van Someren, M., and De Boer, V. (2008). Cap-

turing the needs of amateur web designers by means

of examples. In Proceedings of the 16th Workshop on

Adaptivity and User Modeling in Interactive Systems,

urzburg, Germany, pages 26–31.

Hollink, V., Van Someren, M., and Wielinga, B. (2007).

Navigation behavior models for link structure opti-

mization. User Modeling and User-Adapted Interac-

tion, 17(4):339–377.

Levenshtein, V. I. (1966). Binary codes capable of correct-

ing deletions, insertions and reversals. Soviet Physics

Doklady, 10(8):707–710.

Munkres, J. (1957). Algorithms for the assignment and

transportation problems. Journal of the Society of In-

dustrial and Applied Mathematics, 5(1):32–38.

Newman, M. W. and Landay, J. A. (2000). Sitemaps, story-

boards, and speciﬁcations: A sketch of web site design

practice. In Proceedings of the Third Conference on

Designing Interactive Systems, New York, NY, pages

263–274.

Perkowitz, M. and Etzioni, O. (2000). Towards adaptive

web sites: Conceptual framework and case study. Ar-

tiﬁcial Intelligence, 118(1-2):245–275.

Salton, G. and McGill, M. J. (1983). Introduction to Mod-

ern Information Retrieval. McGraw-Hill, New York,

NY.

Web Accessibility Initiative (2008). Web ac-

cessibility evaluation tools: Overview.

http://www.w3.org/WAI/ER/tools/. Last accessed:

July 4, 2008.

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

150
