EXTRACTING PRECISE ACTIVITIES OF USERS FROM HTTP

LOGS

Kiyotaka Takasuka

, Kazutaka Maruyama

, Minoru Terada

and Yoshikatsu Tada

Graduate School of Information Systems, The University of Electro-Communications

1–5–1 Chofugaoka, Chofu, Tokyo, Japan

Information Technology Center, The University of Tokyo, 2–11–16 Yayoi, Bunkyo, Tokyo, Japan

Department of Information and Communication Engineering, The University of Electro-Communications

1–5–1 Chofugaoka, Chofu, Tokyo, Japan

Graduate School of Information Systems, The University of Electro-Communications

1–5–1 Chofugaoka, Chofu, Tokyo, Japan

Keywords:

HTTP request, Browsing history, User proﬁle, Filtering.

Abstract:

Browsing histories are often used to build user proﬁles for browsing supports and personalizations. But,

the browsing history also contains HTTP requests generated concomitantly with user activity(concomitant

request), which must be removed in order to build correct user proﬁles. Current ﬁltering methods are based

on rather simple characteristics of requests such as the extension of the ﬁle name or reported content types.

We invent a more efﬁcient ﬁltering method based on other characteristics such as the intervals of requests and

the referer relations of requests. In this paper we analyze these characteristics in real web transactions and

evaluate their usefulness on ﬁltering.

1 INTRODUCTION

As the number of the Internet users grows, the amount

of information on web has explosively swelled. The

phenomenon is well known as information explosion.

Many researchers have been tackling the problem

from various aspects, such as information retrieval,

recommendation and extraction. We focus on the data

preprocessing from the aspects of browsing supports

and personalizations. The browsing history is often

used to build the user proﬁle at these researches. The

following can be used as the source of the browsing

history:

1. the browsing history itself,

2. the access log recorded by the web server,

3. the access log recorded by the proxy server, and

4. the access log recorded by the network sniffer.

The source #2, #3, and #4 above collect many ex-

tra HTTP requests in contrast to #1. The browser

records only HTTP requests which explicitly occurs

by the user. We call the requests base requests. On

the other hand, the access log recorded by the web

server, proxy server or network sniffer includes extra

requests which implicitly are occurred by the browser

after loading the obviously requested web page, such

as images embedded in the web page, icons, css ﬁles

and javascript ﬁles. We call the requests concomi-

tant requests. In the point of view of building the

user proﬁle, the browser’s history is suitable because

it includes only explicit users’ activities. If users

provided their own history in some way, such as by

the web browser extension, precise activities could be

collected.

The access log is also available for this purpose

with the elimination of the concomitant requests. But

it is difﬁcult because the number of concomitant re-

quests is huge against the number of the base requests.

This problem is specially difﬁcult when the access log

recorded by the proxy server or the network sniffer is

used.

It is necessary to remove concomitant requests

when these access logs are used as the data source.

Traditional methods are to restrict the extension of

the ﬁle name in URLs and the content-type included

in the HTTP response. However, these methods are

not enough when requests to advertisements or XML

ﬁles are included in the access log. Many requests

to advertisements don’t have the extension of the ﬁle

name in URLs, their content-types of the response are

the same as base requests. These remaining concomi-

tant requests affect the user proﬁle. Therefore, the

341

Takasuka K., Maruyama K., Terada M. and Tada Y.

EXTRACTING PRECISE ACTIVITIES OF USERS FROM HTTP LOGS.

DOI: 10.5220/0001840403410346

In Proceedings of the Fifth International Conference on Web Information Systems and Technologies (WEBIST 2009), page

ISBN: 978-989-8111-81-4

method of removing concomitant requests and iden-

tifying base requests from the access log recorded by

the web server, proxy server or network sniffer is re-

quired.

2 PURPOSE

Our goal is to get rid of concomitant requests from the

access log recorded by the web server, proxy server or

network sniffer, to extract base requests from all the

log. In this paper, we describe

1. the classiﬁcation of requests,

2. the proposal of a ﬁltering method using a timing

at which requests were generated, and

3. th implementation and evaluation of the proposed

ﬁltering method.

3 RELATED WORK

Many researches use the access log to build the user

proﬁle for the browsing support. The log wrote down

by the web or proxy server is used in many case.

In the case of the proxy server(J.Wang, Z.Chen,

L.Tao, W.-Y.Ma, and L.Wenyin, 2002), a content-type

included in the HTTP response header is available for

the ﬁltering. The header identiﬁes whether a response

is in text format or not. However,the removal by this

method is not enough. The access log recorded by

the proxy includes concomitant requests to advertise-

ments and frames. These remaining requests affect

the user proﬁle.

To make a user proﬁle, the access log recorded

by the web server is used(Yunjuan Xie, Vir V. Phoha,

2001). In this case, the access log is cleaned in

the preprocessing to remove noises. The ﬁlter re-

moves concomitant requests by checking the sufﬁxes

of URLs using the black list of the extension. A re-

quest is removed as the concomitant request if the re-

quest have the extension which is included in the list.

But this method doesn’t remove correctly too.

The access log recorded by the web server is tar-

geted in the data mining. (Yong Zhen Guo, Kotagiri

Ramamohanarao and Laurence A. F. Park, 2007) (Ra-

makrishnan Srikant, Yinghui Yang, 2001). The ﬁlter

removes requests to images, extracts requests using

the white list of the extension. A request is treated as

the base request when the list includes the extension

of its ﬁle name. After all, these cases are not enough

too.

4 THE ANALYSIS OF HTTP LOG

We analyzed the access log recorded by the proxy

server. In this access log, access to 7 sites which we

had selected were recorded. The selected 7 sites are

very popular and standard on web. We got several

knowledges through an analysis of access to these 7

sites.

4.1 Classiﬁcation of the Requests

We classify the request as follows.

1. Base request

2. Concomitant request

3. Static request

4. Periodical request

5. Interaction-induced request

A web page generally consists of one base page

and a lot of concomitant objects. A request to the

base page is a base request. The base request is the

one to the URL included the anchor which the user

just clicked. A request to the concomitant object is

a concomitant request. The concomitant object is the

one except the base page gotten to display the web

page on browser. An example of the base page and

concomitant objects is shown in ﬁgure 1.

Figure 1: An example of a base page and concomitant ob-

jects.

Time relation between the base request and its

concomitant requests is shown in ﬁgure 2. A ﬁrst base

request occurs by a click which the user performs ac-

tively. There is latency from the base request to the

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

342

arrival of the response, concomitant requests are gen-

erated after the response arrives, the web page is ren-

dered on browser. The user clicks a link he wants

to browse. Then a next base request is generated. If

the user opens several tabs at the same time under tab

browsing, it is thought that base requests are gener-

ated at the same time.

Figure 2: An example of a time relation between a base

request and its concomitant requests.

We had viewed the top page of the 7 sites for 5

minutes. The number of concomitant requests gener-

ated every access are shown in table 1. Only one base

request causes many concomitant requests

We classiﬁed concomitant requests to three

classes based on characteristics. We describe the de-

tails of each class in the following.

4.1.1 Static Request

Many concomitant requests occur generally after a

base request. Many requests classiﬁed as this class are

necessary to display base page. For example, many

images displayed on the web page, the css ﬁle which

have the structure of the web page and the javascript

ﬁle which have the action of the web page.

The static request have follow three characteris-

tics.

1. Generated in a short period of time from base re-

quest

2. The number of requests is inherent in the web

page, same for every access unless the web page

is updated.

3. Many requests can be traced to the base request

using the referer in the HTTP request header.

All static requests were generated at 0.818 [sec] in

the Yahoo’s top page. All of 53 concomitant requests

were classiﬁed as the static request. 52 of these re-

quests had the referer to the base page. One concomi-

tant request, which was a request to the favorite icon

image, didn’t have a referer.

4.1.2 Periodical Request

The request on this class is automatically generated

by Ajax and Adobe Flash to refresh some part of the

web page periodically. The periodical request have

follow two characteristics.

1. Regularly generating,

2. The number of generating depends on the display

period

The purpose generating the periodical request is

to renew regularly the speciﬁc images and strings

of characters. Therefore regularly generating is the

largest characteristic, many requests on this class get

images and XML ﬁles.

4.1.3 Interaction-induced Request

The user’s interaction makes Ajax and Adobe Flash

generate the concomitant request on this class. Char-

acteristics which the interaction-induced request have

are the following.

1. Caused by the user interaction.

2. The number of generating depends on the amount

of the user interaction.

The interaction-induced request occurs when an

image changes by the user interaction. Great many

interaction-induced requests were generated as a re-

sult of the interaction continuously in Google Maps.

5 PROPOSED METHOD

We propose a method removing the static request in

addition to the traditional method using the extension

and content-type.

The proposed method have two features:

1. Using the time interval from the base request to

the concomitant request,

2. Reconstructing the base-concomitant relation

based on the referer to tackle the browsing in par-

allel using multi tabs.

While the base request is caused by user’s action,

the concomitant request is generated by the browser.

The user’s action is slower than the browser’s one.

Therefore the time interval from the base request to

each concomitant request is especially short. This in-

terval is shorter than the time interval between base

requests. The proposed method uses this difference

of the time interval from the base request. Our pro-

posal assesses a request of which the period is shorter

than a threshold as the concomitant request.

EXTRACTING PRECISE ACTIVITIES OF USERS FROM HTTP LOGS

343

Table 1: The number of concomitant requests when top pages of 7 sites are opened. A “request” is omitted in the table. For

example, a “Concomitant” means the concomitant request.

Yahoo Google Google image Google map Nicovideo

Youtube Wikipedia

Concomitant 53 6 1 1653 88 95 26

Static

53 6 1 14 86 46 26

Periodical

0 0 0 0 2 49 0

Interaction-induced

0 0 0 1639 0 0 0

If the user opens multiple new tabs at the same

time, then more than one base requests occur simul-

taneously, and concomitant requests generated from

different base requests are mixed in the access log. In

order to identify the concomitant requests, we need

to ﬁnd out the trees of the derivations of the reqeusts;

each concomitant request was yielded from one of the

base requests. The referer header in the request helps

us to do it, and the feature 1 above can be applied to

the case of the tab browsing.

6 PERFORMANCE MEASURES

We introduce the performance measures to evaluate

our proposal. We use a precision and recall used in

information retrieval. These values are deﬁned as fol-

lows:

Precision =

| Extracted∩ Browser |

| Extracted |

(1)

Recall =

| Extracted∩ Browser |

| Browser |

(2)

F-measure =

2· Precision· Recall

Precision+ Recall

(3)

where Extracted is a result set of the ﬁltering, Browser

is a set of base reqeusts, Precision is the accuracy of

the extraction, Recall is the ratio between the base re-

quests which the extracted set includes and the set of

all base requests. F-measure is the value integrated

the precision and recall.

7 EXPERIMENTS

We evaluate the accuracy of the proposed method by

applying it to the access log recorded by the proxy

server in the single tab browsing. There are two

experimental data sets, the access log of restricted

browsing and comparatively unrestricted browsing.

At ﬁrst we investigate the upper performance limit

of our proposal using the access log of the restricted

This site is a popular video sharing service in Japan.

http://www.nicovideo.jp/

browsing in section 7.1, the practical performance of

the proposed method using the access log of the unre-

stricted browsing in section 7.3.

7.1 Restricted Experiment

We apply the proposed method to the access log of

the restricted browsing in order to make our proposal

the most effective. Finding out the upper performance

limit facilitates the evaluation of the performance in

the section 7.3. A comparative method restricts the

content-type to “text/html” only.

7.1.1 Experimental Data Set 1

We accessed to the web page as the effects on the user

and network performance are as invariable as possi-

ble. All of the access to the web page were generated

from the machines with the same settings and place.

The machines for web browsing and the proxy server

exist at a LAN.

We browsed web pages selected at random in a

site, had 5 minutes interval between base requests.

The number of web pages we browsed in each site

was about 10 pages. 5 minutes interval is the nec-

essary time to generate all of static requests. In this

experiment, the web browsing was performed on sin-

gle tab to make the base-concomitant relation obvi-

ous. Target sites of the browsing were restricted in 6

sites, the number of browsed web pages was 60 pages.

We use Firefox2.0as the browser and Squid2.6

as the

proxy server.

The number of base requests was 60 because the

number of browsed web pages was 60. The number

of concomitant requests was 1567. We call an access

log used in this experiment an experiment log. The

characteristics of 6 sites selected as the target of this

experiment are shown in table 2.

7.1.2 Result of the Restricted Experiment

Performance measures of the proposed method are

shown in table 3. We set a threshold in order to re-

move the concomitant request as 5 [sec].

http://www.squid-cache.org/

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

344

Table 2: Websites selected in the target of the restricted experiment.

Site Classiﬁcation Adobe Flash Periodical requests # of images

Yahoo Search engine used none many

Google Search engine none none few

Google Image

Image Search none none medium

Nicovideo Video hosting website used used many

Youtube

Video hosting website used used many

Wikipedia

Encyclopedia on web none none few

Table 3: The evaluation of ﬁltering performance using experiment log. A “method” is omitted in the table. For example, A

“Traditional” means the traditional method. A “request” is omitted too.

Result of ﬁlter # of base # of concomitant Precision[%] Recall[%] F-measure

Initial condition 1627 60 1567 3.8 100 6.0

Traditional 133 60 73 45.1 100 62.2

Proposed

236 60 176 25.4 100 40.5

Combined 84 60 24 71.4 100 83.3

The precision of the proposed method is 25.4

[%], this value is less than the one of the traditional

method. But, performance measures are improved

by combining the proposed method with the tradi-

tional method. This indicates that our proposal is able

to remove concomitant requests which the traditional

method can’t remove. The proposed method and tra-

ditional method respectively work as making up for

deﬁciencies in each.

We analyzed actually a result of the ﬁlter. Many

concomitant requests which the ﬁlter can’t remove

were the periodical request and interaction-induced

request. The combined method can remove the static

request which the proposed method targeted.

7.2 Practical Experiment

We evaluate the practical performance measures of

the proposed method and traditional one. A subject

browsed less restricted than the restricted experiment.

7.2.1 Experimental Data Set 2

We selected a male graduate student as the subject.

He was in his early 20s, belonged to the information-

related department. The subject performed the web

browsing in the same environment as the restricted

experiment. He browsed under followtwo restrictions

for about 30 minutes.

1. The single tab browsing

2. Browsing mainly on each websites used in the re-

stricted experiment

The number of browsed web pages was 113 pages.

So base requests were 113. On the other hand,

concomitant requests were 3704. We didn’t restrict

strongly websites he browsed so that we aimed to

evaluate more practically than the restricted experi-

ment. Therefore 40 out of 113 base requests differ

from websites used in Section 7.1, In addition, the

set of base requests contained a few of requests to

the same URL, the set had respectively two URLs

browsed two times and three times.

7.3 Result of the Practical Experiment

We evaluated the traditional method and combined

method changing a threshold every 1 [sec] from 1

[sec] to 5 [sec]. The result is shown in table 4.

The precision is improved by adding the proposed

method to traditional method compared with the tra-

ditional method only. We focus on the case in which

threshold is 1 [sec], because the recall doesn’t de-

crease untill this threshold. In this threshold, the pre-

cision is improved about 25 [%] compared with the

traditional method only.

The precision is less than the one of the restricted

experiment. To browse in more practically environ-

ment, intervals between base requests were short. Ac-

tually, in the usual browsing many user shift to next

page immediately. So, a threshold needs to be less

than the restricted experiment because the recall is de-

creased in the same threshold as the restricted experi-

ment by the incorrect removal of base requests.

EXTRACTING PRECISE ACTIVITIES OF USERS FROM HTTP LOGS

345

Table 4: The evaluation of the ﬁltering in more practically browsing. A “request” and “method” are omitted in the table.

Result of ﬁlter # of base # of concomitant Precision[%] Recall[%] F-measure

Initial condition 3817 113 3704 3.0 100 5.8

Traditional

283 113 170 39.9 100 57.0

Combined (1[sec])

175 113 62 64.6 100 78.5

Combined (2[sec])

168 111 57 66.1 98.2 79.0

Combined (3[sec])

108 57 51 52.8 50.4 51.6

Combined (4[sec])

105 54 51 51.4 47.8 49.5

Combined (5[sec])

85 42 43 49.4 37.2 42.4

8 CONCLUSIONS

In this paper, we classiﬁed each request recorded in

the access log. We assumed that we would extract

only the requests to the URLs included the anchors

which the user just clicked from the access log. In ad-

dition, we proposed the ﬁlter to remove especially the

static request and evaluated the ﬁlter. We performed

the evaluation using experiment log and more prac-

tical log to analyze how traditional method and pro-

posed method had worked.

As a result, the proposed method can improve the

performance to remove the concomitant request by

adding to traditional method. We conclude that pro-

posed method and traditional method work as making

up for deﬁciencies in each.

9 FUTURE WORKS

We hope to explore to direction as follow:

Evaluating in Multi Tab Browsing. HTTP logs

used in this paper were recorded by the single

tab browsing. But, in recent web browsing users

browse usually by multi tab. So, it is necessary to

evaluate in the multi tab browsing.

Removing the other Two Kind of Request. The

proposed method targets at the static request. It

is impossible to remove the periodical request

and interaction-induced request by the proposed

method. Therefore a method to remove these

requests is needed.

Extending Target Websites. Experiments in this pa-

per targeted at speciﬁc websites. This make the

comparison between performances easy. In the

future work we hope to extend the target website

to the other and make a ﬁlter independent of web-

sites.

REFERENCES

J.Wang, Z.Chen, L.Tao, W.-Y.Ma, and L.Wenyin (2002).

Ranking user’s relevance to a topic through link anal-

ysis on web logs. In Proceedings of the 4th interna-

tional Workshop on Web information and data man-

agement, pages 49–54.

Ramakrishnan Srikant, Yinghui Yang (2001). Mining web

logs to improve website organization. In Proceedings

of the 10th International conference on World Wide

Web, pages 430–437.

Yong Zhen Guo, Kotagiri Ramamohanarao and Laurence

A. F. Park (2007). Personalized pagerank for web

page prediction based on access time-length and fre-

quency. In Proceedings of the 2007 IEEE/WIC/ACM

International Conference on Web Intelligence, pages

687–690.

Yunjuan Xie, Vir V. Phoha (2001). Web user clustering from

access log using belief function. In Proceedings of the

1st international conference on Knowledge capture,

pages 202–208.

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

346
