TIMELINESS FOR DYNAMIC SOURCE SELECTION IN

SITUATED PUBLIC DISPLAYS

F. Reinaldo Ribeiro

Departamento de Informática, Escola Superior de Tecnologia, Castelo Branco, Portugal

Rui José

Departamento de Sistemas de Informação, Universidade do Minho, Guimarães, Portugal

Keywords: Dynamic Sources, Information Integration, Timeliness, Public Displays, Situated Displays, Social

Information Systems, Web Information Filtering and Retrieval, Web 2.0.

Abstract: Dynamic sources, which make regularly updated data available for use by other applications, are

increasingly a key enabling feature of the web. They are extensively used in all sorts of social media

applications where they are re-combined in multiple ways to generate new aggregate services. Public

situated displays are an emergent area where dynamic sources can also play a key role in providing situated

and frequently updated content. However, the specificities of public displays raise the need for automated

selection of the most relevant sources to present. This study addresses relevance from the perspective of

timeliness. We propose a timeliness model that supports the most common types of dynamic source. To

validate that model, we set an experiment with a public display exhibiting content from dynamic sources

and receiving from users feedback on its timeliness. The results from this experiment suggest a reasonable

match between our model and the users’ perspectives on timeliness. The results also show that the model is

able to make comparative calculations of timeliness for different types of dynamic source. These results

enable us to conclude that timeliness functions may help to significantly increase the relevance of content

automatically selected from dynamic sources.

1 INTRODUCTION

A key enabling feature of the Web in the social

software era is the integration of multiple data

sources into combined services that exhibit an

aggregate view that is constantly being updated from

the original sources. This model is extensively used

in social media applications and is also at the core of

the mashup concept, in which information from

various sources is recombined to form new

applications. In this paper we will use the term

Dynamic Source to refer to these information

sources that make regularly updated data available

for use by other applications and look in particular at

how they can be leveraged for the generation of

content for digital situated displays.

Public situated displays are an emergent area

where dynamic sources can play a key role in

providing situated and frequently updated content.

However, the common scenario for interaction with

public displays is very different from the traditional

web scenarios and raises specific challenges that

may limit the applicability of dynamic sources as

content generators. The problem with dynamic

sources is that, precisely because they are dynamic,

the relevance of the respective information is likely

to face considerable oscillations. Any particular

source may, at some point, be producing content that

is timely while at some other point may have

nothing to show or its content may be strongly

deprecated. For example, a feed from a blog with

many recent messages on some hot topic may be

very relevant when the new messages are being

posted and then quickly become outdated when the

posting activity stops.

In a traditional web scenario these variations in

the relevance of the sources are not a major concern.

The navigation experience gives people full control

over which information to access and many cues on

which information to select. Multiple data items

from various sources are typically presented in the

form of short summaries with links for further

667

Reinaldo Ribeiro F. and JosÃl’ R.

TIMELINESS FOR DYNAMIC SOURCE SELECTION IN SITUATED PUBLIC DISPLAYS.

DOI: 10.5220/0001841906600665

In Proceedings of the Fifth International Conference on Web Information Systems and Technologies (WEBIST 2009), page

ISBN: 978-989-8111-81-4

details, and people can easily evaluate which ones

may be of interest and navigate accordingly. On the

contrary, in a public display, the interaction model is

essentially a push model, in which the system makes

most of the decisions on what is going to be

presented next. People are very limited in their

ability to influence the display decisions, not only

for the technical considerations resulting from the

lack of a mouse and keyboard, but essentially due to

the fact that the display is public and shared.

Furthermore, given that people will not normally

have the possibility to request for further details, all

the content is presented. As a result, there is a high

probability that at any moment the display will be

showing deprecated or otherwise irrelevant

information.

In this work, we explore an alternative model

that basically consists in maintaining a potentially

large pool of possible sources and selecting for

presentation only those that are currently more

relevant. In general, the relevance of a particular

resource is an indication of the pertinence of that

resource to the current needs of the users, but in this

work we are only concerned with the time

dimension, i.e. evaluating how timely the

information is.

This notion of timeliness is of an obvious

importance in setting the relevance for any type of

source, but different sources will handle the effect of

time differently. For most sources, the relevance

measure should guarantee that the information has

not lost its value since publication, but in some

cases, a higher relevance may be associated with a

particular point in time, e.g. the day of an event, and

not necessarily decay as time goes by.

The objective of this work is to develop a set of

methods for optimizing the timeliness of content

from dynamic sources selected for presentation at

public displays. This broad research goal embraces

the following set of research objectives: to

understand the key criteria for evaluating the

timeliness of content across several types of

dynamic source; to propose and validate a model for

timeliness; to uncover any elements that may affect

people’s perception of timeliness.

To pursue these goals, we started by analyzing

time-related meta-data from a large number of real

sources. Based on that analysis, we propose two

timeliness formulas for two common types of

source, those based on a publication date and those

based on a planned event date. To support the

evaluation of that model we created a public display

system where date items were scheduled using those

formulas and asked people to classify the timeliness

of what was being presented. This was

complemented with another experiment designed to

investigate the fairness of the model when

comparing the timeliness of sources with different

time criteria. Results show a clear relation between

timeliness as determined from our formulas and

timeliness as perceived by people.

2 RELATED WORK

Research on situated public displays has received

considerable attention recently, with many projects

addressing the issues of how to enable information

access and share, and enhance collaboration within

organizations or communal spaces (Russell and Sue

2002). The BlueScreen project (Payne, David et al.

2006) selects and displays adverts in response to

users detected in the audience. It utilizes Bluetooth-

enable devices as proxies for identifying users and

utilizes history information of past users’ exposure

to certain sets of adverts. Advertisements are

preferentially shown to those users that have not

seen them yet. Muller (Muller, Kruger et al. 2007)

describes a mechanism to adapt advertisements on

digital signage to the interests of the audience. Here,

each advertisement has a set of keywords and the

system keeps a history of all advertisements a user

was interested in. Groupcast (McCarthy, Costa et al.

2001) is a display that respond to the local audience

within a corporate environment to display media

contents. It explores user identification and their

profiles to identify common areas of interest.

This work also builds on previous work in

recommendation systems and retrieval models for

feed search (Bihun, Goldman et al. 2007; Seo and

Croft 2007; Arguello, Elsas et al. 2008). A key

distinguishing characteristic is the different set of

assumptions of the specific problem domain.

Previous work has address the issue mostly as an

information retrieval problem, where the starting

point is some type of search phrase, user profile, or

interaction history that enables relevance of new

items to be determined by the similarity to the search

query. Our goal is not to achieve a match between

potential sources and any representation of users’

interests, simply because we do not have any such

representation. In this work, we focus on the

evaluation of relevance in a way that is inherent to

the source and independent of the presentation

context. More specifically, we define our problem as

a problem of selecting from a fixed set of sources

the items that are currently more timely to present.

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

668

3 DYNAMIC SOURCES AND

TIME

A dynamic source is specified by the indication of

the source that produces it and by a collection of

query parameters, such as search keys or constraints

that determine the dataset to be produced. This

specification, frequently in the form of a URL,

represents a formal statement of a particular

information need. As a result of an access to the

resource, a dataset is produced that is normally

composed by multiple data items. Depending on the

type of source, these data items may be text, images,

videos or any other media type, and they may have

their own individual metadata. The resource is

expected to be regularly updated and regularly

consumed, using methods such as dedicated APIs or

XML feeds. As a result, the set of data items

returned by the source may vary in subsequent

requests for the same resource, and each individual

item may itself be updated.

A key part of this work is a model for the

timeliness of the data items obtained from dynamic

sources. A high level goal for that model is to

achieve a reasonable match with common sense

notions of timeliness. Additionally, such model

should also address the following requirements:

 R1: Leverage on the time-related metadata

that is effectively available in the data items

 R2: Address the time-related specificities of

the various types of data items, while enabling

their comparison in terms of timeliness.

 R3: Be optimized for automated scheduling

in which the timeliest content is cyclically

selected from a pool with potential sources.

3.1 Time Related Meta-data

To identify the possible criteria for calculating

timeliness, and particularly to understand the

implication of the requirement R1, we started this

work with an analysis of time-related meta-data

across a varied and representative sample of

dynamic sources, including news feeds, blogs, event

announcements and queries to social software web

sites. The objective was to study the key

characteristics of a representative set of dynamic

sources in order to identify the main criteria for

calculating timeliness taking into account the data

and metadata produced by the various types of

resource. Through a period of 3 weeks, we have

collected time-related parameters from 117 sources

of various types. We have analyzed the time-related

data that was actually available for those types and

its update frequency. Based on that analysis, we

identified three main groups of sources: information

items with publication date, event-related items with

event date, and content shared on social software

web sites. The first two are clearly distinct in the

semantics of their time-related meta-data, as we will

describe next. The social software web sites were

harder to aggregate because each site has its own

time semantics, which greatly undermines any

attempt of using a common model. We thus chose

not to address the sources from that particular group

and focus our study only on the first two groups.

3.2 A Timeliness Model

The next phase in our work was the definition of a

timeliness model for each of the two groups

identified. We chose to study the timeliness of

individual items rather than the timeliness of

dynamic sources, because the data items on any

particular source will typically exhibit very distinct

time-related parameters that would distort the

selection process.

In the case of information items with publication

date, timeliness is essentially determined by the time

elapsed since the time of publication. However the

decay factor associated may vary considerably

across different types of sources, which leads to

introduce a decay parameter that defines the decay

of the information with time (Equation 1).

PDt

−

(1)

Where:

 T

: the timeliness of the item i;

 PD

the publish date of item i;

 t: the actual time;

 K

: decay level of the source for item i

In the case of event-related items with event

date, timeliness is essentially tied to the date of the

event, steadily growing as the event approaches and

then dropping abruptly as the event comes to an end

(Equation 2).

()

tSTh

thl

−×

⎟

⎠

⎞

⎜

⎝

⎛

−

−+

−

−+

5,0

(2)

Where:

 l

, h

, l

and h

represent change times for the

timeliness function (defined as amount of time

since this point to event start time);

 ST

: the event start time;

 t ;the actual time;

 h(t) :Heaviside step function.

TIMELINESS FOR DYNAMIC SOURCE SELECTION IN SITUATED PUBLIC DISPLAYS

669

4 EXPERIMENT

To validate the previous models and also to uncover

any meaningful user perspectives on timeliness, we

set an experiment with a public display showing

content from dynamic sources and receiving

feedback from users on the timeliness of the content.

For this trial, we developed a display system that

used different scheduling algorithms to select the

next item to display and we then asked users what

they thought about the timeliness of what was being

presented on the display. This was complemented

with an evaluation of the fairness of the algorithms

when choosing between multiple source categories.

4.1 Timely Display System

We have developed a timely display system that

collects data from a pool of predefined dynamic

sources, selects the timeliest items and displays the

respective content on a public display. As

represented in Figure 1, the key input for the system

is the set of dynamic sources considered for our

study. Those sources are organized in categories,

with the items in the same category sharing the same

timeliness formula and respective parameters.

Figure 1: Timely display system.

Two different scheduling queues were created

for each category: a timely queue and a random

queue. The timely queue contains the 15 items, from

all the items in all the sources in the respective

category that ranked higher according to the applied

timeliness formula (see table 1). The random queue

also contains 15 items, but randomly selected from

the same category. The timeliness value is regularly

updated to reflect not only the passage of time, but

also the new items being produced by the sources.

The set of queues from the various categories is

the input for the scheduler, which must select the

next item that is effectively going to be presented.

Each time the scheduler needs to select a new item,

it picks an item from one of the queues. In this

experiment with users, this selection was made at

random, in order to help distribute the number of

schedules between all categories including the

random ones. The selection within each queue

follows a simple round-robin algorithm. Information

was displayed as represented in Figure 2.

Figure 2: Situated display screenshot.

At the left we have the next items to be

presented. The main display area displays the

information of the currently selected item, but does

not include any reference to time related meta-data.

Every 25 seconds the display information is updated

with a new item being selected for presentation.

For the purpose of this study, we selected a total

of 117 dynamic sources of general interest for our

target community. Those sources were grouped

according to the nature of their source into the five

categories described in Table 1.

Table 1: Categories and parameters (ns:number of sources;

tf: timeliness function; p: parameters; ti: total items).

Category ns tf p ti

News 38 Eq. 1 K=24 ≅900

Magazines W. 46 Eq. 1 K=48 ≅900

Blogs 22 Eq. 1 K=48 ≅400

Announcements 10 Eq. 1 K=48 ≅250

Events 1 Eq. 2 l

=120; h

=96;

=36; h

=24;

≅10

News and headlines are frequently updated

sources (e.g., from TVs, newspapers). Blogs

includes content from blogs (usually opinions and/or

comments). Magazines and websites represent news

from magazines, websites and similar sources on

specific type of contents. Announcements category

includes contents like classified announcements and

advertisements. Finally, events represents sources

for which timeliness is strictly connected to the

event start date. The total number of items in each

category (column ti) is just an indicative value, as

this number is always changing due to the dynamic

nature of the content sources. Parameters were

defined according the nature of the content and our

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

670

own perception of how their timeliness could

evolve.

4.2 The Display Setting

The experiment took place at a reception hall. The

setting is composed by two different displays: the

Information Display and the Feedback Display. The

Information Display shows the items that were

selected for presentation. The Feedback display is a

small touch screen display that is used to collect

users’ opinions about the timeliness of what is being

presented on the Information display. The display

poses to the users the question “What is your

opinion about the timeliness of the content that is

presented on the display?” and users are able to

select between four possible answers (2 if Very

Timely; 1 if Timely; 0 if Not Timely and -1 if No

Opinion). Each user response is associated to the

content that is currently on the situated display and

is stored in a database. To prevent the same user

from voting multiple consecutive times a delay of

five seconds was introduced between feedbacks.

Every time a new item is scheduled, the system

registers the schedule start time; schedule end time;

scheduler queue; item source; item title; item link;

item publication date and event start date (if content

is an event). Every time a user gives feedback, the

system registers the user opinion on content

timeliness and associates it with the displayed item.

5 RESULTS AND DISCUSSION

During the 3-weeks of our experiment the display

made 33823 schedule decisions corresponding to

8577 distinct items belonging to 102 sources (no

items were selected from 15 sources). For the same

period we collected a total of 669 timeliness

classifications. To improve the quality of the data we

eliminated classifications made very close to the

moment of transition between items (for which there

was some ambiguity on the association) and at night

(for which there were very few people). In the end,

our analysis was based on 320 valid classifications

referring to 239 distinct items from 67 distinct

sources.

5.1 Timeliness Perspectives

The first goal of our data analysis was to identify

how the timeliness of the items selected using our

timeliness model had been perceived differently,

when compared with the perception of timeliness in

the randomly selected items. Figure 3 shows the

“mean” value of user classifications for timely and

random queue for each category.

0,0

0,5

1,0

1,5

2,0

Random Blogs

Timeliness Blogs

Random

Magazines/Websites

Timeliness

Magazines/Websites

Random

Announcements

Timeliness

Announcements

Random Events

Timeliness Events

Random News

Timeliness News

Figure 3: Comparative statistical analysis.

When comparing the two queues in each

category a considerable improvement can be

observed for all categories. The least successful

category is blogs with a 25% improvement.

The graphs in Figure 4 display the timeliness

function for new along with the respective timeliness

classifications submitted by people. The horizontal

axis represents time in hours since publication or

until the event date.

Figure 4: News:Timeliness functions vs users’ evaluation.

The existence of randomly selected items has

allowed us to obtain classifications for items that

were ranking low in timeliness and despite a relative

scattering on users’ evaluations, there seems to be a

clear match between our formula and the

classifications made by people.

5.2 Fairness between Categories

A complimentary experiment was made to assess

the fairness of the timely algorithm when

competitively selecting items from multiple

categories. We used the same sources and categories

as the basic input, but this time, for each category,

we considered a single queue based on our timely

algorithm. The selection of the data items to be

scheduled was made by selecting from all those

queues the 30 most timely items, regardless of their

category. This forced the data items of all the

categories to compete among each other for

scheduler selection.

TIMELINESS FOR DYNAMIC SOURCE SELECTION IN SITUATED PUBLIC DISPLAYS

671

For a period of 6 days, we registered the

schedules made and the number of items available in

each category. The results are presented in Table 2

and are divided into two parts. The first corresponds

to the period between 8 am and 8 pm, and the

second corresponds to the entire day period.

Table 2: Results for fairness between categories.

8am-8pm

Available

items (1)

Display (2)

Total

schedules

% of air

time

% distinct

items

start ∆ new

News 703 3166 4541 53,8% 21,7%

Blogs 290 112 1099 13,0% 22,1%

Announc. 98 13 8 0,1% 1,8%

Mag & W 766 427 2659 31,5% 21,7%

Events 10 7 132 1,6% 17,7%

All Day

News 703 3428 9705 48,4% 26,8%

Blogs 290 112 3221 16,1% 23,1%

Announc. 98 13 40 0,2% 2,7%

Mag & W 766 451 6752 33,7% 29,3%

Events 10 7 320 1,6% 35,3%

(1) Number of items at the start of the experiment and

number of new items published during the experiment.

(2) Total number of schedules, % of the total number of

schedules and % of items that were scheduled.

When comparing the fairness between

categories, we can observe that some categories are

able to gain many more schedules that others. This is

in part due to their natural dynamic, but still it is an

indicator that some of the parameters in the formulas

may have to be fine tuned to increase fairness.

Another interesting effect is the existence of

differences between the daily period and all day

period. This were due to the nature of some sources

(e.g. usually blogs are updated out of the day period)

and also because of their origin (many of the

magazines were from sources with different time

zones from our one). The relatively high number of

schedules on events is justified because there were

four events occurring during this experiment. We

can also observe that only part of the items were

ever displayed, e.g. 21,7% for news during the day

period. This was a natural consequence of the fact

that we had a much higher number of potential data

items than time to present them all.

6 CONCLUSIONS

This study has investigated how the notion of

timeliness can be added to dynamic sources and

contributes to improve the relevance of data items

selected for presentation in public displays. We have

proposed a formula for modeling the timeliness of

various types of dynamic sources that builds on time

related meta-data effectively available on common

sources and is simple to calculate.

The results of the study suggest a reasonable

match between our concept of timeliness and the

concept as perceived by users. Therefore the

introduction of timeliness as a criterion for item

selection is expected to have an impact on the

perceived relevance of the data presented in public

displays. Evaluation of fairness has shown that there

are multiple factors that must be considered to

ensure a balanced selection among multiple

categories or even among the various sources in the

same category, including different time zones and

different dynamics in the generation of new items. A

change in the model suggested by those results is the

introduction in the formula of an initial period with

no decay to attenuate the effect of different time

zones and support a better match with daily rhythms.

A more in-depth study of those effects and how to

handle them is part of future work in this topic.

ACKNOWLEDGEMENTS

The first author was supported by a FCT scholarship

(SFRH/BD/31292/2006).

REFERENCES

Arguello, J., J. L. Elsas, et al., 2008. Document

Representation and Query Expansion Models for Blog

Recommendation. Int. Conf. on Weblogs and Social

Media, Seatle.

Bihun, A., J. Goldman, et al., 2007. Ranking blog

documents. US Patent & Trademark Office.

McCarthy, J. F., T. J. Costa, et al., 2001. UniCast, OutCast

& GroupCast: Three Steps toward Ubiquitous

Peripheral Displays. Int. Conf. on Ubiquitous

Computing, Springer-Verlag.

Muller, J., A. Kruger, et al., 2007. Maximizing the Utility

of Situated Public Displays. Adjunct Proceedings of

User Modeling, Corfu.

Payne, T., E. David, et al., 2006. Auction Mechanisms for

Efficient Advertisement Selection on Public Displays.

European Conference on Artificial Intelligence.

Russell, D. M. and A. Sue, 2002. Using Large Public

Interactive Displays for Collaboration. W. on

Collaboration with Interactive Walls and Tables.

Seo, J. and W. B. Croft, 2007. UMass at TREC 2007 Blog

Distillation Task. Text Retrieval Conference.

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

672
