N-GRAMS-BASED FILE SIGNATURES FOR MALWARE

DETECTION

Igor Santos, Yoseba K. Penya, Jaime Devesa and Pablo G. Bringas

Lab, Deusto Technological Foundation, Bilbao, Spain

Keywords:

Security, Computer viruses, Data-mining, Malware detection, Machine learning.

Abstract:

Malware is any malicious code that has the potential to harm any computer or network. The amount of malware

is increasing faster every year and poses a serious security threat. Thus, malware detection is a critical topic in

computer security. Currently, signature-based detection is the most extended method for detecting malware.

Although this method is still used on most popular commercial computer antivirus software, it can only achieve

detection once the virus has already caused damage and it is registered. Therefore, it fails to detect new

malware. Applying a methodology proven successful in similar problem-domains, we propose the use of n-

grams (every substring of a larger string, of a ﬁxed lenght n) as ﬁle signatures in order to detect unknown

malware whilst keeping low false positive ratio. We show that n-grams signatures provide an effective way to

detect unknown malware.

1 INTRODUCTION

The term malware was coined to name any computer

program with malicious intentions, such as viruses,

worms, or Trojan horses. As one may think, parallel

to the grow of the Internet, the amount, power, and

variety of malware increases every year (Kaspersky,

2008), as well as its ability to avoid all kind of security

barriers.

The classic method to detect these threats consists

on waiting for a certain number of computers to be in-

fected, determining then a ﬁle signature for the virus

and ﬁnally ﬁnding a speciﬁc solution for it. In this

way, based on the list of signatures (also known as

signature database (Morley, 2001)), the malware de-

tection software can provide protection against known

viruses (ie. those on the list). This approach has

proved to be effective when the threats are known in

beforehand, and is the most extended solution within

antivirus software. Still, as already mentioned, it fails

when facing new ones.

Moreover, upon new virus apparition and until the

corresponding ﬁle signature is obtained, mutations of

the original virus released in the meanwhile may es-

cape to detection based on that signature.

These facts have led to a situation in which

malware writers develop new viruses and different

ways for hiding their code, while researchers design

new tools and strategies to detect them (Nachenberg,

1997). Such evolution makes very difﬁcult to de-

velop an universal malware detector. Thus, the task of

the researcher is to achieve very good results against

known malware and to turn the attempt of writing new

undetectable virus more difﬁcult.

Generally, there are several indicators to evaluate

the effectiveness of a new malware detection system.

First, we have to look at its malware detection ra-

tio (i.e. the amount of viruses of a sample that the

software detects). Second, we have to look at the

false positive ratio (i.e. the amount of non malicious

programs that are erroneously classiﬁed as malware),

since it determines how practical the method is to be

commercialised: a new system able to detect a lot of

malware but at the cost of a high rate of false positives

is not practical in the real world, where the system

must deal with a lot of benign software that should

not be classiﬁed as malware.

Therefore, antivirus companies usually prefer a

modest detection ratio with low (or ideally zero) false

positive ratio rather than a notable detection one with

high also a false positive ratio.

Language recognition is a research area that has

tackled a similar problem, since they also have to

deal with the retrieval of information that is hard to

see at the ﬁrst glance. The most extended technique

against this problem has been the use of the so-called

317

Santos I., Penya Y., Devesa J. and Bringas P. (2009).

N-GRAMS-BASED FILE SIGNATURES FOR MALWARE DETECTION.

In Proceedings of the 11th International Conference on Enterprise Information Systems - Artiﬁcial Intelligence and Decision Support Systems, pages

317-320

DOI: 10.5220/0001863603170320

 SciTePress

n-grams. For instance, in Chinese document classi-

ﬁcation (Zhou and Guan, 2002) or text classiﬁcation

(Jacob and Gokhale, 2007).

N-grams are all substrings of a larger string with

a length n. A string is simply split into substrings of

ﬁxed length n. For example, the string “MALWARE”,

can be segmented into several 4-grams: “MALW”,

“ALWA”, “LWAR”, “WARE” and so on.

Against this background, this paper advances the

state of the art in two main ways. First, we address

here a new methodology for malware detection based

on the use of n-grams for ﬁle signatures creation. Sec-

ond, we tackle the issue of dealing with false positives

using a parameter named d to control how strict the

method behaves to classify the instance as malware

or benign software in order to avoid false positives.

The remainder of this paper is structured as fol-

lows. Section 2 discusses related work. Section 3

introduces the method proposed in this paper. Section

4 describes the experiments performed and discusses

the obtained results. Finally, Section 5 concludes and

outlines the avenues of future work.

2 RELATED WORK

Lately, the problem of detecting unknown malicious

code has been addressed by using machine learning

and data mining (Schultz et al., 2001). In their re-

search they propose to use differentdata mining meth-

ods for detection of new malware, however, none of

the techniques proposed had good balance between

false positive ratio and malware detection ratio in their

experimental results.

In a verge closer to our view, N-grams were used

ﬁrst for malware analysis by an IBM research group

(Kephart, 1994). They proposed a method to automat-

ically extract signatures for the malware. Still, there

was no experimental results in their research.

Furthermore, Assaleh et al in (Abou-Assaleh

et al., 2004) addressed an n-grams-based signature

method to detect computer viruses. In that approach,

given a set of non malicious programs and computer

viruses code, n-grams proﬁles for each class of soft-

ware (malicious or benign software) were generated,

in order to later classify any unknown instance into

benign or malicious code using a k-nn algorithm with

k = 1. That experiment had very good results in terms

of malware detection ratio; still, no false positive ratio

was given in the experiment results. This lack of false

positives in the experimental results and the absence

of any technique to control the appearance of them

renders this method to be unpractical in a commercial

way.

3 METHOD DESCRIPTION

Our technique relies on a large set of training values

in order to build representation for each ﬁle in that set.

This set is composed of a collection of malware soft-

ware and benign programs. Speciﬁcally, the malware

is made up of different kind of malicious software (i.e.

computer viruses, Trojan horses, spyware, etc ).

Once the set is chosen, we extract n-grams for

every ﬁle in that set that will act as the ﬁle sig-

nature. Hereafter, the system can classify any un-

known instance as malware or benign software. To

this extent, we classify the unknown instance using k-

nearest neighbour algorithm (Fix and Hodges, 1952),

one of the simplest machine learning algorithms that

can be used in classifying issues. This algorithm re-

lies on identifying the k most nearest (say most sim-

ilar) instances, to later classify the unknown instance

based on which class (malware or benign) are the k-

nearest instances.

The following measure function is used in order

to detect how much the unknown instance looks like

the known ones:

∑

xεX

f(x)

card(X) + card(Y)

(1)

where X is the set of the n-grams of the unknown in-

stance, x is any n-gram in the set X, Y is the set of

n-grams of the instance its class is known, and f(x) is

the number of coincidences of the n-gram x in the set

When every instance of the known set is measured

comparing it with the unknown instance, we select

the k highest values of the measured instance, and we

consider the unknown instance as malware only if on

the k most alike ﬁles the amount of malware instances

minus the amount of benign instances is greater or

equal than a parameter d, as shown in the following

formula:

MW(K) − GW(K) >= d (2)

where MW(K) is the amount of malware instances in

the k nearest neighbours, GW(K) is the amount of be-

nign software in the k nearest neighbours and d is the

parameter d.

This parameter d controls how strict the system is

going to be in order to classify the unknown instance

as malware or benign software. Moreover, this pa-

rameter is what we are going to use to keep low the

false positive ratio; with a high value of d (that has to

be always lesser or equal than k), we predict that the

false positive ratio is going to keep low.

ICEIS 2009 - International Conference on Enterprise Information Systems

318

4 EXPERIMENTAL RESULTS

In order to perform our experiments, a computer se-

curity software company provided us with a slice of

a larger malware database. More accurately, it con-

sisted of 149882 malware ﬁles and texts associated

to them, and 4934 benign software with their texts.

These texts have been extracted by several tools that

provide information of the execution of the malware

instances in a safe environment. In this way, these as-

sociated texts gave us a very valuable information of

the behaviour of malware instances.

The huge size of the database (100 GB) makes the

dataset to be nearly unpractical for research purposes;

therefore, we decided to use a small portion of it for

our experiments. In this way, we choose randomly

1000 malware ﬁles and 1000 benign software ﬁles to

accomplish our experiments, having an equal quantity

of malware and benign instances. This sample repre-

sents only a 1% of the original database, anyway the

amount of the sample is large enough to show us if

n-grams ﬁle signatures are able to achieve detection

of unknown malware.

Further, we divided this dataset into a set of train-

ing (the known ﬁles) and a set for classifying (the un-

known ones). This kind of division is usually per-

formed in machine learning experiments. In this way,

we train the model with enough information to build

representationfor capturing features of the behaviours

of the malware. To this extent, we divide the sample

into a set of training, that is going to be compound

by the 66% of the total sample and a 34% of benign

software.

With the training set we train the model for later

test the model with the remaining 34%. The 66% to

act as the training instances can train the model in a

efﬁcient way, as the 34% of the instances for testing

are able to show the capability of the model for de-

tecting new and unknown malware.

4.1 Parameters

There are three main parameters in our experiments:

the size of the n-grams, the number of nearest neigh-

bours for the knn algorithm and the limit that marks

the nature of the unknown instance as malware (this

value is over the half).

First, the size of the n-grams, or n, allows us to

decide how long in bytes the n-gram will be. In the

experiments presented here, we run tests with n = 2,

n = 4, n = 6 and n = 8.

Second, k; the number of nearest neighbours for

the knn algorithm. It is hard to establish an optimal

value for this parameter, and it usually depends on the

system’s behaviour.

Finally, the parameter d, as aforementioned, es-

tablishes how strict is going to be the system for clas-

sifying a unknown instance as malware. One of our

primary goals is to keep as low as possible the amount

of false positives, therefore this parameter is going to

take the same value as k in at least half of the tests

run.

4.2 Results

In the experiments, we have built ﬁle signatures that

are made up of the set of n-grams for every ﬁle in

the sample (2000 ﬁles), for n=2, n=4, n=6 and n=8.

These ﬁles content n-grams of the texts retrieved from

the executables. We split these ﬁles containing the ﬁle

signatures into two separate ﬁles for every value of n.

One of the two ﬁles contents the n-grams of the ﬁles

that are going to be used as the training set, and the

other one contents the n-grams of the ﬁles that are

going to be used as the test set.

Figure 1 shows the obtained false positive and de-

tection ratio over the parameters n, k and d. More

accurately, for n = 2, the detection ratio is quite low,

achieving a maximum detection ratio of 69.66%, thus

2-grams do not seem to be appropriate for ﬁle signa-

tures. In this experiment we achieved best results for

detection ratio for n = 4, getting a maximum detec-

tion ratio of 91.25 % for k = 7 and d = 2. For the

following n values, detection ratio is lower than for

n = 4, however, the second best results are achieved

for a value for n of 8.

Besides, the false positive ratio and detection ratio

themselves do not show the potential of the system. If

we focus on the best results when false positive ratio

is 0%, we achieve the best result for n = 4, k = 17 and

d = 17, keeping a 74.37% detection ratio.

5 CONCLUSIONS AND FUTURE

WORK

As the amount of malware and its variety is growing

every year, malware detection rises to become a topic

of research and concern. Further, classic signature

methods provide detection when the threat is known

in beforehand. It fails, however, when confronted to

unknown malware.

In this way, our method uses n-grams signatures to

achieve detection of unknown malware. In our exper-

iment we have chosen a set of decompiled malware

code and texts that have result of the monitorizing

of the execution of those ﬁle to act as the unknown

N-GRAMS-BASED FILE SIGNATURES FOR MALWARE DETECTION

319

Figure 1: Detection and false positive ratio.

threats and other set to act as the known threats. Un-

der these premises, we extract the n-grams of the

known ﬁles and the n-grams of the unknownones. For

any instance of the unknown set, we are going to clas-

sify into malware or benign software, based upon the

coincidences of n-grams between the set of n-grams

of the known ﬁles and the set of n-grams of the un-

known ones.

We have demonstrated that n-grams-based

methodology signatures can achieve detection of

new or unknown malware. Furthermore, with the

inclusion of the parameter d in the classiﬁcation

method, we have achieved a way to conﬁgure how

strict the system will be for classifying an unknown

instance as malware; thus, it is a way for controlling

the false positive ratio.

This method provides a good detection ratio and

the possibility to control the false positive ratio. This

way, this method can be applied in order to detect as

much malware as it can or it can be conﬁgured to give

a 0% false positive ratio.

Future work will focus on further research of the

capability of n-gram analysis in malware detection,

experiments with different and larger malware col-

lections, and combination of this technique with be-

havioural analysis of malicious code.

REFERENCES

Abou-Assaleh, T., Cercone, N., Keselj, V., and Sweidan,

R. (2004). N-gram-based detection of new malicious

code. In COMPSAC Workshops, pages 41–42.

Fix, E. and Hodges, J. L. (1952). Discriminatory analysis:

Nonparametric discrimination: Small sample perfor-

mance. Technical Report Project 21-49-004, Report

Number 11.

Jacob, A. and Gokhale, M. (2007). Language classiﬁca-

tion using n-grams accelerated by fpga-based bloom

ﬁlters. In HPRCTA ’07: Proceedings of the 1st in-

ternational workshop on High-performance reconﬁg-

urable computing technology and applications, pages

31–37, New York, NY, USA. ACM.

Kaspersky (2008). Kaspersky security bulletin 2008: Mal-

ware evolution january - june 2008.

Kephart, J. O. (1994). A biologically inspired immune sys-

tem for computers. In In Artiﬁcial Life IV: Proceed-

ings of the Fourth International Workshop on the Syn-

thesis and Simulation of Living Systems, pages 130–

139. MIT Press.

Morley, P. (2001). Processing virus collections. In Proceed-

ings of the 2001 Virus Bulletin Conference (VB2001),

pages 129–134. Virus Bulletin.

Nachenberg, C. (1997). Computer virus-antivirus coevolu-

tion. Commun. ACM, 40(1):46–51.

Schultz, M. G., Eskin, E., Zadok, E., and Stolfo, S. J.

(2001). Data mining methods for detection of new

malicious executables. In SP ’01: Proceedings of

the 2001 IEEE Symposium on Security and Privacy,

page 38, Washington, DC, USA. IEEE Computer So-

ciety.

Zhou, S. and Guan, J. (2002). Chinese documents classiﬁ-

cation based on n-grams. In CICLing ’02: Proceed-

ings of the Third International Conference on Com-

putational Linguistics and Intelligent Text Processing,

pages 405–414, London, UK. Springer-Verlag.

ICEIS 2009 - International Conference on Enterprise Information Systems

320
