SECURITY AND DEPENDABILITY IN AMBIENT

INTELLIGENCE SCENARIOS

The Communication Prototype

Alvaro Armenteros

Security Products for Bussines, Telefónica I+D, Madrid, Spain

Antonio Muñoz, Antonio Maña, Daniel Serrano

Department of Computer Science, Universidad de Malaga, Spain

Keywords: Security patterns, Security services, Ambient Intelligence.

Abstract: Ambient Intelligence (AmI) refers to an environment that is sensitive, responsive, interconnected,

contextualized, transparent, intelligent, and acting on behalf of humans. Security, privacy, and trust

challenges are amplified with AmI computing model and need to be handled. Along this paper the potential

of SERENITY in Ambient Intelligence (AmI) Ecosystems is described. Main objective of SERENITY

consists on providing a framework for the automated treatment of security and dependability issues in AmI

scenarios. Besides, a proof of concept is provided. In this paper, we describe the implementation of a

prototype based on the application of the SERENITY model (including processes, artefacts and tools) to an

industrial AmI scenario. A complete description of this prototype, along with all S&D artefacts used is

provided in following sections.

1 INTRODUCTION

One of the key aspects of the new emerging

environments of Ambient Intelligence is Security.

Dependability for these environments is also an

important feature to be considered. In this paper, we

will consider the problems and challenges arising

concerned to security and dependability in Ambient

Intelligence. We will provide an overview of the

current solutions proposed for them as well as an

instance of a real world scenario related to AmI

where those solutions are applied to cover its S&D

requirements as a practical way to validate them and

explore challenges arising for these kinds of

scenarios.

This paper is structured as follows: section 2 is a

background. Section 3 introduces some

considerations of security and dependability in AmI

scenarios. Section 4 presents the SERENITY

(SERENITY project, 2006) approach. In section 5

we describe a proof of concept on a wireless

communication scenario. Finally section 6 some

conclusions.

2 BACKGROUND

Among the more relevant approaches for modelling

security and dependability aspects in Ambient

Intelligence (AmI) ecosystems found in literature,

we highlight those based on Components,

Frameworks, Middleware, Agents and the enhanced

concept of Pattern. Concerning components, these

capture expertise in the form of reusable software

elements to solve a problem under a set of context

conditions, provided by a set of well defined

interfaces and an associated description of their

behaviour (Merabti et. al, 2004; Zhang Shi, 1998).

Middleware based approaches capture expertise

in the form of standard interfaces & components.

Then applications developers are provided with a

simpler aspect to access a set of specialized,

powerful and complex capabilities. However, some

issues arise such as the high computational cost of

the middleware components, especially for those

small devices involved in AmI ecosystems with

limited capabilities, as well as the security

infrastructure of middleware systems, which is

Armenteros A., Muñoz A., Maña A. and Serrano D. (2009).

SECURITY AND DEPENDABILITY IN AMBIENT INTELLIGENCE SCENARIOS - The Communication Prototype.

In Proceedings of the 11th International Conference on Enterprise Information Systems - Information Systems Analysis and Speciﬁcation, pages 49-56

DOI: 10.5220/0001949500490056

 SciTePress

restricted to authorization and access control in most

cases (BEA White Paper, url; Object Management

Group, url). The potential use of Frameworks is

found in developing secure services (Wilson et. al,

2003; Sanchez, 2007 ). In (Sampemane et. al, 2004)

a framework that uses ontologies and the Common

Criteria classification of security requirements are

described. This is intimately related with the main

approach of this paper, where the use of ontology

facilitates reasoning about the requirements and also

reusability of goal and domain knowledge across a

large body of software developers. From a different

perspective there is the Agent paradigm, which is

especially well suited for highly distributed

environments such as AmI scenarios thanks to

properties like: autonomy, interaction, context

awareness and goal-oriented nature. But in case of

modelling security aspects are much more limited

(Boudaoud et. al, 2002) because an agent is an

independent entity and many security solutions can

not be represented as agents.

The concept of security pattern was introduced to

support the system engineer in selecting appropriate

security or dependability solutions. However, most

security patterns are expressed in textual form, as

informal indications on how to solve some (usually

organizational) security problem (IBM's Security

Strategy team, 2004; Yoderand et. al, 2000 ). Some

of them make use of more precise representations

based on UML diagrams (E. B. Fernandez, 2000).

Perhaps the first and the most valuable contribution

as pioneer in security is the work from Joseph Yoder

and Jeffrey Barcalow (Yoderand et. al, 2000), a

natural evolution of this work is presented by

Romanosky in (S. Romanosky, 2001). Eduardo B.

Fernandez in his work about authorization patterns

(E. B. Fernandez, 2000) proposes a further step in

the abstraction of patterns. In (Fernandez et. al,

2001) authors propose the decomposition of the

system into hierarchical levels of abstraction.

Other authors propose other alternatives to

provide formal characterizations of patterns. The

idea of precisely specifying a given class using class

invariants and pre- and post-conditions

(Soundarajan, e. al, 2006). Also Mikkonen in (T.

Mikkonen, 1998) focus his approach on behavioural

properties. In this approach data classes are used to

model role objects, but guarded actions (in an action

system) are used to model roles methods.

3 SOME CONSIDERATIONS OF

S&D IN AMI SCENARIOS

The Information Society Technology Advisory

Group vision is that AmI applications will be

influenced by the computational, physical and

behavioural contexts that surround the user (for

instance, because of resource availability and

security or privacy requirements). The concepts of

system and application as we know them today will

disappear, evolving from static architectures with

well-defined pieces of hardware, software,

communication links, limits and owners, to

architectures that will be sensitive, adaptive,

context-aware and responsive to users’ needs and

habits. AmI ecosystems offer highly distributed

dynamic services in environments that will be

heterogeneous, large scale and nomadic, where

computing nodes will be omnipresent and

communications infrastructures will be dynamically

assembled.

AmI environments impose some constraints in

the connectivity framework, power computing as

well as energy budget. This makes of AmI a

significantly different case within distributed

systems. The combination of heterogeneity,

dynamism, sheer number of devices, along with the

growing demands placed on software security and

dependability (S&D), make application development

vastly more complex. Also, the provision of security

and dependability for applications becomes

increasingly difficult to achieve with the existing

security engineering mechanisms and tools.

In the new AmI scenarios, not only systems as a

whole but also individual applications running in or

supported by those systems will have to adapt to

dynamic changes to hardware and software, and

even firmware configurations, to unpredicted and

unpredictable appearance and disappearance of

devices and software components. In other words

applications must be able to adapt dynamically to

new execution environments. As a consequence pre-

defined trust relationships between components,

applications and their system environments can no

longer be taken for granted. Therefore, the increased

complexity and the unbounded nature of AmI

applications make it impossible, even for the most

experienced and knowledge-able S&D engineers, to

foresee all possible situations and interactions which

may arise in AmI environments and therefore create

suitable solutions to address the users’ security and

dependability requirements. Additionally S&D

engineers will be faced with pieces of software,

communication infrastructures and hardware de-

ICEIS 2009 - International Conference on Enterprise Information Systems

vices not under their control. Thus, approaches

based on the application-level security will not be

sufficient to provide security and dependability to

the AmI eco system as a whole.

An AmI environments relevant feature is that

they will contain a large number of heterogeneous

computing and communication infrastructures and

devices that will provide new functionalities,

enhance user productivity, and ease everyday tasks.

These devices will hold a variety of data with

different security and privacy requirements. This

information will be used in different ways in

different applications and computing contexts and,

therefore, different policies (possibly contradicting)

will be applied. Hence, in such settings, securing the

device or the information alone or even each

individual application is not sufficient, and context

information should be integrated in order to be able

to choose appropriate security mechanism on-the-

fly.

Because of their complexity, and because

elements will be under the control of different

owners, security mechanisms will need to be

supervised (monitored) in order to identify potential

threats and attacks and decide on recovery actions, if

possible. Thence some existing approaches can

provide suitable solutions to sup-port the dynamic

evolution of security policies for specific security

mechanisms at particular system operation layers

(application, networking). However, these

approaches cannot be extended to support the

dynamic evolution of general security mechanisms

(as opposed to security policies for a single

mechanism). Furthermore, their results are

extremely complicated to integrate, monitor and

dynamically evolve as would be required by AmI

ecosystems. For the very same reasons, S&D

approaches for AmI ecosystems cannot hope to

synthesize new S&D mechanisms or new

combinations of these mechanisms fully

automatically and dynamically. Thus we can

summarize the individual challenges that we have

devised so far into a simpler and yet tougher grand

challenge:

The provision of S&D in AmI ecosystems

requires the dynamic application of the expertise of

security engineers in order to dynamically react to

unpredictable and ever-changing contexts. The

intuitive solution would be to create an “intelligent”

system able to analyze the requirements and the

context in order to synthesize new solutions.

Unfortunately, given the state of the art in both

security engineering and intelligent systems, this

approach is not a promising one in the foreseeable

future. To meet this challenge in our time we need to

look more closely to what technology is available

for S&D mechanism in AmI ecosystems.

Security related common problems of systems can

be classified into three categories, according to

whether they threat confidentiality, integrity or

availability of systems. In the following we will

describe each of them.

Confidentially is the property that information

holds when it remains unknown to unauthorized

principals. In the case of AmI environments almost

all the communication are carried out through

wireless connections. It is well known that wireless

connections are more vulnerable to attacks than

wired connections since the information could be

transmitted to anyone in the network range. Hence,

we would expect that some of the security solutions

existing for wireless networks could be adapted to

AmI environments.

Among the most used techniques for distributed

systems it is worth to mention those based on

encryption and decryption. These techniques achieve

a certain level of security by obscurity. Examples of

these techniques are stream cipher and; block cipher

techniques by Vernam and Maubogne (Richard W.

Hamming, 1980) More recent techniques in the

same line of research include those introduced in

(Gideon Yuval, 1979) by Schneier. Public Key

Infrastructure is also a technique used to achieve

confidentiality. In some cases, it is more convenient

to combine both public and private key

cryptographic systems. This leads to the well known

hybrid systems.

Integrity is the property that is violated when

information is altered without authorization. This

definition applies to the information held in a host as

well as for the information in transit between hosts.

As we mention before, wireless networks are more

vulnerable to attacks than wired ones. The main

reason being that anyone on the range of the wireless

network can receive the signal. Thus, a man-in-the-

middle attack is easy to be performed and, as a

consequence, an attack on the data integrity.

Some of techniques used widely in distributed

systems are Errors Detection Code (Gideon Yuval,

1979), Hash’s tables (Maña et. al, 2006), MAC

(Message Authentication Code) or Digital Signature.

These techniques could be also applied to the new

emerging environments of AmI, though we should

take into account the new problems arising,

concerning the nature of AmI.

Availability is the property of a system that grants

and legitimizes requests by the authorized parties. A

possible attack occurs when a malicious principal is

SECURITY AND DEPENDABILITY IN AMBIENT INTELLIGENCE SCENARIOS - The Communication Prototype

able to achieve that the service is denied to an

authorized principal by means of overloading the

system. In any AmI environment where the users are

connected to the host, it is possible to carry out an

attack by denying the service. This could put under

risk the availability of the system.

4 INTRODUCING THE

SERENITY APPROACH

The objective of the SERENITY Project is to

provide a framework for the automated treatment of

security and dependability issues in AmI scenarios.

In order to do that the SERENITY Project focuses

has two main cornerstones: (i) capturing the specific

expertise of security engineers in a way that allows

its automated processing; and (ii) providing means

to perform run-time monitoring of security and

dependability mechanisms. They have been

deployed by means of:

1. A set of modelling artefacts used to capture

security expertise (called S&D artefacts). We use

the term S&D solution to refer to an isolated

component that provides a security and/or

dependability service to an application. S&D

artefacts are used to represent S&D solutions at

different levels of abstraction. The representation

of S&D solutions at different levels of

abstraction responds to the needs of using them

at the different phases of the software

development process. These S&D artefacts are

presented in this section.

2. A development-time framework (the

SERENITY Development-time Framework,

SDF) supporting:

• The development of S&D solutions by

means of the aforementioned S&D artefacts.

The SDF includes processes and tools used by

security experts for the creation of new S&D

solutions. S&D solutions developed using the

SDF include semantic information related to its

informational description and its operational

behaviour.

• The development of secure applications

following the SERENITY approach. These

secure applications rely on SERENITY for

fulfilling its security and dependability

requirements. Applications developed by this

way are called SERENITY-aware applications.

They include references to SERENITY S&D

artefacts. At run-time these references are

resolved so that S&D solutions are provided

and can be used by applications.

The SDF is supported by on-line repositories

populated with S&D artefacts. Security experts

use these on-line repositories in order to store the

S&D solutions they develop. And, application

developers access to on-line repositories when

they are developing SERENITY-aware

applications in order to look for S&D solutions

to reference from their applications. A detailed

description of the development of application

based on these on-line repositories can be found

at (Serrano et. al, 2008).

3. A Run-time framework, called SERENITY

Run-time Framework (SRF). The SRF provides

support to applications at run-time, by managing

S&D solutions and monitoring the systems'

context. SERENITY-aware applications are

developed by means of open architectures that

are complemented at run-time by the SRF.

In order to facilitate the understanding of the

SERENITY approach the rest of this section

introduces how it is possible to capture security

expertise by means of the SERENITY S&D

artefacts.

The SERENITY Project provides five main S&D

artefacts to represent S&D solutions: S&D Classes,

S&D Patterns, Integration Schemes, S&D

Implementations and Executable Components.

These S&D artefacts, depicted in figure 1, represent

S&D solutions using semantic descriptions at

different levels of abstraction. All S&D artefacts, but

Executable Components, are represented using XML

files. Executable Components are code.

• To start, S&D Classes represent abstractions of

a security service that can be provided by

different S&D solutions characterized for

providing the same S&D Properties and

complying with a common interface. At the level

of S&D Classes, S&D solution descriptions are

very simple, containing some information about

the name of the solution, and its creators, the

security properties provided, and the interface

offered by the solution. Regarding to the security

properties, SERENITY provides a formalism

created for representing and reasoning about

security properties (called S&D properties),

interested readers can refer to (Aresdani Aboba,

2003) .

• S&D Patterns are detailed descriptions of

abstract S&D solutions. As presented in Figure 1,

each S&D Pattern belongs at least to one S&D

Class. At this level of abstraction the description

of S&D solutions are more detailed than in the

ICEIS 2009 - International Conference on Enterprise Information Systems

previous one (S&D Classes). These descriptions

contain all the information necessary for the

selection, instantiation, adaptation, and dynamic

application of the security solution represented in

the S&D Pattern. Since each S&D Pattern may

have a different interface, they contain a

specification that allows mapping the abstract

calls defined in the S&D Class interface into the

specific calls defined by the S&D Pattern

interface. Also, S&D Patterns include behavioural

description of the security mechanisms they

represent. Besides, they include the pattern

semantics, which are related to the semantics of

the security properties provided. Finally, S&D

Patterns include information about the restrictions

imposed by the solution. It is important to take

into account that the S&D Patterns we are using in

the SERENITY Project differ from the current

concept of patterns in software engineering. S&D

Patterns are components containing detailed

information about S&D solutions. These

components (S&D Patterns) are machine

readable.

class Pattern detail v 4

S&DPattern

S&DImplementation

S&DClassS&DProperty

S&DSolution

ExecutableComponent

IntegrationScheme

BelongsTo

Combi nes

RefersT o

Provides

Com pl ies

BelongsTo

Implements

RefersTo

Figure 1: Class Pattern detail.

• Integration Schemes are an especial type of

S&D Pattern that represent S&D solutions that are

built by combining several S&D Patterns. While

S&D Patterns are independent or atomic

descriptions of S&D solutions, Integration

Schemes describe solutions for complex

requirements achieved by the combination of

smaller S&D solutions (represented by means of

S&D Patterns).

• S&D Implementations represent the

components that realize the S&D solutions. S&D

Implementations are not real implementations but

their representation/description. This is the lower

abstraction level, at this level S&D solutions are

defined in terms of the technology used in their

development and how to make use of it.

• Finally, Executable Components are the actual

implementations (pieces of code) of S&D

solutions. The automatic processing of Executable

Components is based on the use of the

information provided by the S&D artefacts

representing the S&D solution implemented by

them.

S&D Classes, S&D Patterns and S&D

Implementations are development-time oriented

artefacts, and Executable Components are especially

suitable for run-time. These S&D artefacts are

organized as a hierarchy, that is to say, each S&D

Class has several S&D Patterns, and each S&D

Pattern has several S&D Implementations. As

aforementioned, SERENITY-aware applications

include references to S&D artefacts. Depending on

the S&D artefact level of abstraction used by

application developers, at run-time the SRF is more

flexible when selecting S&D Solutions. The main

purpose of introducing this hierarchy is to facilitate

the dynamic substitution of the S&D Solutions at

run-time, while facilitating the development process.

For instance, at run-time all S&D Patterns (and their

respective S&D Implementations, see figure 1)

belonging to an S&D Class will be selectable by the

SRF in response to an S&D Class-based request by

the application.

5 THE PROOF OF CONCEPT: A

WIRELESS

COMMUNICATIONS

PROTOTYPE SCENARIO

In this section we describe a target scenario for

applying previously presented SERENITY

approach, as well as the corresponding prototype

from a SERENITY perspective, as a remarkable

example of a scenario related on AmI and with

direct application in the industry. It is important to

SECURITY AND DEPENDABILITY IN AMBIENT INTELLIGENCE SCENARIOS - The Communication Prototype

clarify that we can’t consider any pure AmI scenario

for the time being, since AmI is an emerging

concept and current technologies don’t allow actual

AmI deployments in the widest sense of the term.

But he proposed scenario depicts key characterises

of AmI environments. In fact, the scenario shows

that in addition to the impact in the future AmI

scenarios, the SERENITY approach can have a

short-to-medium term impact as an enhancement of

many current technologies.

The proposed scenario focuses on the provision

of seamless and access-controlled communication

over a wireless network, which provides connection

and access to multiple resources in the company,

such as internal digital documents, data bases,

intranet services and internet connection. Moreover,

it offers a convenient mobility to users, who do not

need to be physically connected to any cable or

access point.

In a conventional company network, security

policies are usually assigned in a fixed way, thus not

including AmI features or dynamic changes based

on context at run-time, and a thorough knowledge of

S&D issues is needed when deploying the wireless

network and the associated access control to

information. In order to improve this conventional

situation, in the proposed scenario we include AmI

features and use the SERENITY model. In this AmI

communication scenario, several context features are

considered in order to improve S&D. In particular,

we highlight user location and device authentication.

Location is a key factor in the access control

policies of the scenario: some re-sources may or

may not be accessed depending on the current

position of the re-questing user in the office.

Location information is provided by an existing

Indoor Location System (ILS). Furthermore, device

identity is also used as a factor to allow/deny access

to certain resources: only users whose devices are

properly authenticated as company devices (and thus

trusted devices), will have access to resources with a

high security level.

In the scenario we consider several situations

dealing with the network security. In all of them we

have one or more users trying to access resources

through the wireless network from a specific

location. Users are first authenticated with their

identity, associated with a user profile. An Access

Control Server (ACS) decides to grant or deny the

access taking into account:

• Location: using information provided by an ILS.

• User identity: users are authenticated to initiate a

session and then can be properly classified as a

certain profile (administrator, employee,

visitor…).

• Device identity: each device is identified by using

a Trusted Platform Module (TPM).

We can extract many requirements from this

scenario, but for the sake of simplicity we focus on

S&D requirements and within them especially on

those related to Ami issues. In order to better

address them, a SERENITY-enabled prototype has

been developed, aiming to denote the benefits of

applying the SERENITY approach and show its

good suitability for AmI environments. Taking into

account those S&D requirements, we have designed

the following prototype architecture where the

SERENITY model has been adopted:

Figure 2: Scenario Architecture.

In this figure, we can recognize all the main

actors involved in the scenario. At first glance you

may observe the SERENITY enabled entities

(denoted with the SERENITY icon). These entities

include an SRF instance providing all the

functionalities mentioned in section 4.

• The Wi-Fi infrastructure is main access network

in the company. Additionally, it is the base for

localization since it’s achieved by Wi-Fi signal

triangulation (using several access points).

• The Authentication Server processes user

connection requests, and allows or denies them

attending to presented user credentials. It uses a

database as a user data repository. It uses the

EAP-RADIUS protocol (Chiba et. al, 2008).

• The Location Server implements a Wi-Fi based

ILS that tracks real-time location of all connected

users.

• User devices can be any able to connect to Wi-Fi

network. In our scenario we use laptops with

TPM chips for device identification, as well as

ICEIS 2009 - International Conference on Enterprise Information Systems

SERENITY-aware client applications and a SRF

instance.

• The ACS runs a Control Application which

implements the core functionalities of the system:

it controls the user accesses to resources based on

user profiles, their location and the “identity” of

their devices. This Control Application is

designed a full SERENITY-aware application

that relies on an instance of the SRF, which is

responsible for the selection and provision of the

most suitable S&D solutions to fulfils requests

from the applications. For instance, the SRF

decision may result in a dynamic reconfiguration

of filter rules in the firewall.

• The Firewall isolates the wireless network from

the rest of the (wired) network and is dynamically

configured by ACS (rules can be changed “on the

fly”)

The prototype point out the good conditions of

the SRF for AmI environments by showing its

negotiation feature in action: there is one SRF

instance in the central ACS and several instances in

client devices. The central SRF and device instances

can interact and negotiate with the SRFs in the

devices in order to provide appropriate distributed

solutions such as client-server protocols, enhancing

distributed security and flexibility.

In the prototype we provide a set of artefacts

addressing specific requirements for the scenario but

these artefacts are not strictly bound to it. Taking

advantage of the S&D Pattern approach, these

artefacts could be used in other environments since

they represent independent S&D Solutions.

Alternatively, we might have used previously

developed S&D patterns and solutions instead of

developing them. The artefacts used for the scenario

are:

• TPM-based device identification pattern: this

pattern represents a mechanism to identify a

device, based on the TPM technology. In the

same way that humans identify themselves in

different ways (e.g. by means of biometrics), a

TPM-enabled device can claim its “identity” by

cryptographic means, using a TPM for that

purpose. TPMs provide a set of hardware-based

cryptographic functions that allow making these

claims in a trusted way. TPMs implement a

challenge-response protocol that allows control

servers to obtain proofs of the identity of the

device.

• Zone-based security measurement pattern: the

solution represented by this pattern provides a

security assessment for specific zones inside

controlled areas: obtain a qualitative value or

measurement of the security taking in count

predefined zone profiles.

• Access Control Integration Scheme: in our

scenario, previous patterns are conceived to work

together. The different solutions represented by

these patterns in isolation are not enough to take a

decision on access control. However, a combined

solution can be used to provide fine-grained

access control. For this purpose, SERENITY

provides a very useful artefact: the Integration

Scheme that allows the creation of a new pattern

based on the composition of other patterns. In our

case an Integration Scheme is used to provide a

final access control decision.

The overall result of the application of SERENIY

approach on the proposed scenario shall be denoted

by the following perceived benefits: Simplicity for

adding new factors to the control access, that is the

system administrator just needs to add new patterns

implementing those factors to de S&D Library.

Combining the factors is as easy as creating

Integration Schemes using different patterns. And

last but not least the high adaptability provided by

the event collector mechanism and the monitoring

system the control system counts with a ready-to-use

high adaptable engine to provide the best solution

available in each case.

On the other hand, we must not ignore some

implications and challenges. Firstly extra code needs

to be added in order to get a proper Executable

Component, and therefore to be executed in a SRF

environment. At this point, dealing with proprietary

software presents an important issue: in the real

world, system developers and integrators use

existing commercial solutions, which normally can’t

be modified. In this case we have used software

wrappers providing the SERENITY interface.

Providing the events and monitoring data, an

extension of the previous point is considering all the

monitoring stuff you need to provide to allow SRF

to treat correctly the use of every S&D Solution.

However, these issues must not discourage potential

adopters of SERENITY.

6 CONCLUSIONS

The realization of the Ambient Intelligence concept

entails many important challenges, but the most

important barriers to this realization, is the lack of

adequate support for security. Along this paper we

have presented the SERENITY approach consisting

SECURITY AND DEPENDABILITY IN AMBIENT INTELLIGENCE SCENARIOS - The Communication Prototype

on a new model for addressing the security issues in

the development of distributed applications and

systems for Ambient Intelligence scenarios. We

showed as the main objective of the SERENITY

Project is to provide a framework for the automated

treatment of security and dependability issues in

AmI scenarios. SERENITY is focused on two main

cornerstones: (i) capturing the specific expertise of

security engineers; and (ii) providing means to

perform run-time monitoring of the security and

dependability mechanisms. Finally we provide a

proof of concept by means of the Wireless

Communication prototype, which is related on AmI

and with direct application in the industry.

ACKNOWLEDGEMENTS

This work is funded by the 6

Framework

Programme of the European Union developed in the

SERENITY (IST-027587) Project.

REFERENCES

SERENITY project. Funded by European Commission.

Directorate General Information Society & Media.Unit

D4 - ICT for Trust and Security, under grant IST-

027587. http://www.SERENITY-project.org, 2006.

Merabti M. Shi Q. Askwith B. Llewellyn-Jones, D.

Utilising component composition for secure

ubiquitous computing. In Proceedings of 2nd UK-

UbiNet Work-shop., 2004.

Zhang Shi, Q. An effective model for composition of

secure systems. 1998. Journal of Systems and

Software, 433:233-44.

BEA White Paper. BEA WebLogic Security Framework:

Working with Your Security Eco-System.

http://www.bea.com.

Object Management Group. The Common Object Request

Broker: Architecture and Specification.

http://www.omg.org.

Gilson Wilson and Ullas O. Tharakan. Unified security

framework. In Trinity College Dublin, editor, In ISICT

'03: Proceedings of the 1st international symposium

on Information and communication technologies,

pages 500-505, 2003.

Le Gruenwald Carlos Sanchez and Mauricio Sanchez. A

monte carlo framework to evaluate context based

security policies in pervasive mobile environments. In

New York, USA, ACM, editor, In MobiDE '07:

Proceedings of the 6th ACM international workshop

on Data engineering for wireless and mobile access.,

pages 41-48. ACM, 2007.

R. Sampemane G. Ranganathan A. Campbell R.H. Hill. A

framework for automatically satisfying security

requirements. In Workshop on pecification and

Automated Processing of Security Requirements' -

SAPS'04 at the 19th IEEE International Conference on

Automated Software Engineering., 2004.

C. Boudaoud, K.; McCathieNevile. An intelligent agent-

based model for security management. In iscc, editor,

Seventh International Symposium on computers and

Communications, page 877, 2002.

IBM's Security Strategy team, 2004. Introduction to

Business Security Patterns. An IBM White Paper.

Available at http://www-

3.ibm.com/security/patterns/intro.pdf. 2004.

J. Yoder and J. Barcalow. Architectural patterns for

enabling application security. In MA: AddisonWesley

Publishing Company. Reading, editor, Pattern

Languages of Program Design., volume 4, pages 301-

336, 2000.

E.B. Fernandez. Metadata and authorization patterns. In

Technical report, Florida Atlantic University, 2000.

Romanosky, S., 2001. Security Design Patterns, Part 1,

1.4.

E.B. Fernandez and Rouyi. Pan. A pattern language for

security models. In PLoP01 Conference., 2001.

Soundarajan N. Hallstrom, J. O. Pattern-based system

evolution: A case-study. In the Proc of the 18th

International Conference on Software Engineering

and Knowledge Engineering. San Francisco Bay,

USA., 2006.

T. Mikkonen. Formalizing design patterns. In IEEE

Computer Society Press.,editor,

In Proc. Of 20th

ICSE., pages 115-124, 1998.

Richard W. Hamming. Coding and Information Theory.

Prentice-Hall, 1980. ISBN 0-13-139139-9.

Gideon Yuval. “How to Swindle Rabin”. Cryptologia, 3:

187189, Jul 1979. ISSN 0161-1194.

A. Maña, C. Rudolph, G. Spanoudakis, V. Lotz, F.

Massacci, M. Melideo, and J. M. López-Cobo.

Security Engineering for Ambient Intelligence: A

Manifesto. Integrating Security and Software

Engineering. IDEA Group, 2006. ISBN 1-59904-148-

Daniel Serrano, Antonio Maña, and Athanasios-Dimitrios

Sotirious. Towards precise and certified security

patterns. In Proceedings of 2nd International

Workshop on Secure systems methodologies using

patterns, Spattern 2008, pages 287-291, Turin, Italy,

September 2008. IEEE Computer Society. ISBN 978-

0-7695-3299-8.

Aresdani Aboba B, Calhoun P, 2003 RADIUS Support For

Extensible Authentication Protocol EAP. IETF RFC

3579 , updates: RFC 2869.

Chiba M, Dommety G, Eklund M, Mitton D, Aboba B.,

2008 Dynamic Authorization Extensions to Remote

Authentication Dial In User Service. IETF RFC 5176.

Obsoletes: RFC 3576.

ICEIS 2009 - International Conference on Enterprise Information Systems
