AN ARCHITECTURE FOR THE RAPID DEVELOPMENT OF

XML-BASED WEB APPLICATIONS

Jos´e Paulo Leal

DCC-FC & CRACS, University of Porto, R. Campo Alegre, 823, 4150-180 Porto, Portugal

Jorge Braz Gonalves

ESEG, Polytechnic Institute of Guarda, Av. Dr. Francisco S Carneiro, 50, 6301-559 Guarda, Portugal

Keywords:

Web application generation, XML transformations, Architectural patterns, Data management applications.

Abstract:

Our research goal is the generation of working web applications from high level speciﬁcations. Based on

our experience in using XML transformations for that purpose, we applied this approach to the rapid devel-

opment of database management applications. The result is an architecture that deﬁnes of a web application

as a set of XML transformations, and generates these transformations using second order transformations

from a database schema. We used the Model-View-Controller architectural pattern to assign different roles

to transformations, and deﬁned a pipeline of transformations to process an HTTP request. The deﬁnition of

these transformations is based on a correspondence between data-oriented XML Schema deﬁnitions and the

Entity-Relationship model. Using this correspondence we were able produce transformations that implement

database operations, forms interfaces generators and application controllers, as well as the second order trans-

formations that produce all of them. This paper includes also a description of a RAD system following this

architecture that allowed us to perform a critical evaluation of this proposal.

1 INTRODUCTION

The work described in this paper is part a research

effort aimed to the automatic creation of web applica-

tions from XML speciﬁcations. It builds on previous

work (Leal and Domingues, 2007) focused on the de-

velopment of web interfaces to systems with a loose

coupling to the web server. In this previous work we

develop an XML domain speciﬁc language describ-

ing the target system and used XML transformations

to process that description. This domain speciﬁc lan-

guage lacks the features to be classiﬁed as an Archi-

tectural Description Languages (ADL) (Medvidovic

and Taylor, 2000) but provides a similar level of ab-

straction, focusing on system and interconnection of

its components rather than on lines of code.

The development of prototypes of applications is

the corner stone of the Rapid Application Develop-

ment (RAD). It was proposed by James Martin as

a model of iterative software development (Martin,

1991), aiming to shorten the software development

cycle, producing faster results and reducing costs

without losing quality. The RAD model became pop-

ular and has been used on tools for different database

management systems and/or programminglanguages.

Some of these RAD tools are used for development of

web applications, as is the case of Omnis, Intraweb,

RAD-Studio, Delphi-forPHP, WebSnap, and Turbo-

Gears, to name a few.

2 OVERALL ARCHITECTURE

The architecture we propose is strongly based on

XML technologies. XML (Bray et al., 2006) was

originally created as a formalism for deﬁning web for-

matting languages, with XHTML – the XML com-

pliant successor of HTML – as the ﬁrst language to

use this paradigm. Nevertheless, XML was quickly

adopted to transfer and archive data. Being an auto-

descriptive and text-based formalism, XML docu-

ments are easily processed by different systems, inde-

274

Paulo Leal J. and Braz Gonalves J. (2009).

AN ARCHITECTURE FOR THE RAPID DEVELOPMENT OF XML-BASED WEB APPLICATIONS.

In Proceedings of the 11th International Conference on Enterprise Information Systems - Databases and Information Systems Integration, pages

274-277

DOI: 10.5220/0001951202740277

 SciTePress

pendently of their platform. Although created also for

web formatting, XSLT (Clark, 1999) have outgrown

its original role of transforming XML documents to

XSL-fo or XHTML, and is routinely used to convert

between any two XML languages. In our approach

all these XML technologies play a role in the conﬁg-

uration of automatically generated applications, and

indeed also in its generation.

Applications software and other programs with

graphical interaction are usually structured using

the Model-View-Controller (MVC) architectural pat-

tern (Gamma et al., 1994). This pattern was proposed

by Trygve Reenskaug in 1978 as a design solution for

Smalltalk (Reenskaug, 1979). In this architecture we

used the MVC pattern to structure a set of transforma-

tions that implement the distinct features of the gen-

erated applications.

Model data-to-data transformations implement data

management operations;

View data-to-XHTML transformations produce

forms based interfaces to interact with portions of

the database;

Controller data-to-state transformations manage a

set of parameters that controls all transformations.

Having identiﬁed a set of transformations that can

be used to conﬁgure a web application, we need to

produce these transformations for a given data man-

agement application. Assuming a ﬁx set of data man-

agement operations, these transformations can be ob-

tained from the schema of the database.

An XML Schema Deﬁnition (XSD) is a standard

way to describe the structure and content of XML

documents. In a sense, an XSD is similar to the

schema of a database, although with some limitation

when describing relationships.

Our infrastructure to this transformation-based

RAD system works in two stages: ﬁrst an XSD doc-

ument is processed and generated a set of transfor-

mations for a speciﬁc application; then these trans-

formations are used for running the generated appli-

cations. In the architecture we propose, each stage

corresponds to its own individual component: the ap-

plication generator and the application engine

The application generator is itself a web applica-

tion for generating web applications from XSD docu-

ments and managing applications conﬁgurations. The

generation of web applications results from applying

a set of second order transformations to the uploaded

XSD document, to the produce ﬁrst order transfor-

mations that deﬁne the applications; then these ﬁrst

order transformations are installed in the application

engine.

The application engine, with a set of ﬁrst order

transformations, is the actual web application gener-

ated by this RAD system. In fact, the application en-

gine is common to a set of web applications generated

by the same application generator.

3 Transformations

The distinctive feature of this RAD architecture is the

use of XSLT transformations to generate and run web

applications. In the applications engine transforma-

tions act as participants of the Model-View-Controller

pattern and are generated from the XML Schema

Document modelling the data. This sections starts

with the database operations that are the model of the

generated application, proceeds with forms interfaces

that provide views to the generated applications an

concludes with the control of model and views.

To implement database operations on data-

oriented XML documents we need to identify a

database schema in its structure, given as an

XML Schema Document (XSD). To represent the

database schema we use the Entity-Relationship

Model (ERM) (Elmasri and Navathe, 2003). It is al-

most straightforward to map the XSD concepts of ele-

ment and attribute type deﬁnitions, into the ERM con-

cepts of entity, attribute and relationship. Only the last

- relationships - pose some difﬁculties since the XML

data model (infoset) is not completely equivalent to

the ERM.

In the ERM, entity types deﬁne sets of entities and

is only natural to relate them with elements types with

multiple occurrences. In an XSD, an occurrence in-

dicator speciﬁes the minimum and maximum num-

ber of times an element of a given type can be re-

peated. Thus, we use the indicator

maxOccurs

with

value

‘‘unbound’’

to identify entities in an XSD.

Given a database schema extracted from a XSD,

each operation-entity pair can be implemented by a

simple XSLT transformation on the database instance,

and a few parameters.

Second order transformations are responsible gen-

erating these transformations from the XSD. For each

entity detected on the XSD (an element type deﬁ-

nitions with unbound repetition) and each supported

operation (insertion, query, modiﬁcation, deletion) an

XSLT with the appropriated transformation is gener-

ated.

We use a similar approach to create also a forms

based graphical users interface from the XSD, us-

ing also XSLT transformations. To accomplish this,

we started by analysing how RAD systems usually

map ERM concepts into forms based interfaces and

AN ARCHITECTURE FOR THE RAPID DEVELOPMENT OF XML-BASED WEB APPLICATIONS

275

then used the same correspondence between ERM

and XSD.

Entity types are usually mapped to forms in the

GUI and their attributes to visual controls (such as

text boxes, radio buttons, selectors, etc), depending

of their type. There are a few special cases regarding

attributes.

Table 1 presents a summary of the correspondence

between XSD, the Entity-Relationship Model (ERM)

and Graphical Users Interfaces (GUIs) components.

This table is the basis to understand how to create

a collection of HTML forms to manage the content

of data-oriented XML document. The transforma-

tions that generate these forms receive as source the

database document and produces an HTML form with

the current entity as initial value. The current entity is

passed to the transformation using parameters.

As in the transformations that implement database

operations, second order transformations process the

XSD for generating these HTML forms. For each en-

tity detected on the XSD is generated and HTML page

with a form containing the controls associated with its

ERM attributes.

The ﬁrst order transformations discussed previ-

ously fulﬁl the roles of Model and View in the ap-

plication engine. To extend this approach to the com-

plete MVC pattern we deﬁne how the Controller can

be generated from an XSD document.

For each user, there is a set of parameters used

for controlling each and every transformation, and

the transformation pipeline itself, that receives also

HTTP parameters. In this architecture, all these pa-

rameters are grouped in an XML document that re-

sides solely in memory (i.e. is never serialised). Since

this document reﬂects the users interaction state and

bound to each users’ state, we will refer to it simply

as State. Some parameters are required by the infras-

tructure and for that reason will have reserved names,

with a standard preﬁx.

The State document is used both for as target of

Model transformations and for extracting parameters

to every transformation. Unlike in the previous par-

ticipants of the MVC pattern, there is a single Con-

trol transformation. This transformation is the ﬁrst to

be processed in the transformation pipeline, changing

the current values of parameters and thus controlling

the following transformations. The Controller trans-

formation processes both the Data and the State (as

transformation parameters) and generated a new in-

stance of the State. As usual, the second order trans-

formations that generate the Controller transforma-

tion uses the XSD to extract the entities and attributes

required to redeﬁne control parameters.

When an HTTP request is received from a web

browser it triggers three transformations in sequence,

producing an HTML document that is sent back to the

browser in the HTTP response.

Two DOM objects - Data and State – have a cen-

tral role in this process. The former reﬂects the appli-

cation data as persisted in a XML document ﬁle; there

is a Data object for each application managed by the

application engine. The latter is the state of the inter-

action with each user; there is a State object for each

active user session. Both these objects are used in all

three transformations: the Data object is the transfor-

mation data source and the State object contains the

transformation parameters.

4 EXPERIMENTAL EVALUATION

The architecture described in the previous sections

was implemented as a Java web application using the

Tomcat servlet container. In this section we highlight

the main issues encountered in the development.

We managed to implement the infrastructure of

our RAD system with a very simple design: its con-

sists of pair of servlets - one for the application gen-

erator and other for the application engine - and a col-

lection of objects representing applications.

Both servlets manage a set of applications. Each

application instance contains a DOM object and a

collection of preloaded transformations. The main

method of this class invokes a transformation on the

data object that is outputted to different objects ac-

cording to its type: model transformations are copied

to the data object itself and serialized in the ﬁle sys-

tem; controller transformations change the DOM ob-

ject representing the state; view transformations pro-

duce HTML outputted to the HTTP response channel.

When the Application class is instanced the cor-

responding data ﬁle is loaded to its DOM object as

well as all it’s transformations. As some HTTP re-

quests just change the current view and do not activate

model transformations, the data object is serialised to

its data ﬁle only when it is actually changed. This

class is thread safe to ensure data integrity in concur-

rent operations.

As would be expected, the implementation of sec-

ond order transformations was more challenging. The

ﬁrst issue we has to solve was the different ways in

which an element can be typed in an XSD. Just to

give a few examples:

• types in XML Schema can be either anonymous

or named, and named types can be reuse in several

deﬁnitions;

• elements and attributes can be grouped and reused

in several deﬁnitions;

ICEIS 2009 - International Conference on Enterprise Information Systems

276

Table 1: Correspondence between XSD, ERM and GUIs.

XML Schema Entity-Relationship Model Users Interface

Repeatable element Entity Form

Nested Repeatable element Entity, Relationship (1:N) Sub-form

ID attribute Primary key Text label

IDREF attribute Relationship (1:1) Selector (single selection)

IDREFS attribute Relationship (1:N) Selector (multiple selection)

Other Attributes Attribute Visual control

Simple element (PCDATA) Attribute Visual control

Complex element Structured attribute Group of controls

• type deﬁnitions can be created by extending other

type deﬁnitions.

To simplify the detection of entities, attributes

and relationships we start by normalising XSD doc-

uments. As would be expected, the normalisation is

also an XSLT transformation that unfolds all reusable

deﬁnitions into an XSD only with anonymous types

without any for of reference.

The templates for identifying entities, attributes

and relationships are imported by all second or-

der transformations that produce the three classes

of XSLT transformations from the normalised XSD.

Note that only the Controller transformations is re-

sumed to a single transformation. In this evaluation

prototype there is a second order transformation for

each database operation The number of view trans-

formations depends on the style of application.

The style of application is a particular set o second

order transformations that can be selected in the appli-

cation generator when an XSD is uploaded to the sys-

tem. We implemented a simple application style that

produces always a form (depending of entity type) for

every operation; this style has a single has a single

second order transformation. We implemented also

an extended application style where search operations

generate a listing with all matching entities, with an-

chors for editing operationon that entity; this style has

two second order transformations, one for each kind

of visualisation. More complex application styles can

also be programed, modifying all the three classes of

transformations.

5 CONCLUDING REMARKS

This article presents an architecture for rapid develop-

ment of web applications based on XML documents

and transformations. Our goal was the generation of a

functional application from an XML speciﬁcation, in

this case an XML Schema deﬁnition.

We used the Model-View-Controller architectural

pattern to structure a set of transformations and identi-

ﬁed different classes of transformationswith each par-

ticipant in that pattern. We shown that a data-oriented

XML Schema deﬁnition can be corresponded to the

classic Entity-Relationship model used for modelling

databases. Using this correspondence we were able

produce transformations to implement database oper-

ations, forms interfaces and applications control, as

well as the meta transformations that produce them.

We deﬁne also a pipeline to process the ﬁrst order

transformations to process an HTTP request. We

implemented a system following this architecture to

evaluate experimentally the RAD approach we pro-

posed.

REFERENCES

Bray, T., Paoli, J., Sperberg-McQueen, C. M., Maler, E.,

and Yergeau, F. (2006). Extensible markup language

(xml). http://www.w3.org/TR/xml/.

Clark, J. (1999). Xsl transformations (xslt) w3c recommen-

dation. http://www.w3.org/TR/xslt.

Elmasri, R. and Navathe, S. (2003). Fundamentals of

Database Systems. Addison Wesley.

Gamma, E., Helm, R., Johnson, R., and Vlissides, J.

(1994). Design Patterns - Elements of Reusable

Object-Oriented software. Addison Wesley Profes-

sional.

Leal, J. and Domingues, M. (2007). Rapid development

of web interfaces to heterogeneous systems. In van

Leewen et al., J., editor, SOFSEM 2007: Current

Trends in Theory and Practice of Computer, number

4262 in Lecture Notes in Computer Science, pages

716–725. Springer-Verlag.

Martin, J. (1991). Rapid Application Development.

Macmillan Coll Div, New York.

Medvidovic, N. and Taylor, R. N. (2000). A classiﬁcation

and comparison framework for software architecture

description languages. IEEE Transactions on Soft-

ware Engineering, 26(1).

Reenskaug, T. (1979). Models - views - controllers. Tech-

nical report, Xerox PARC.

AN ARCHITECTURE FOR THE RAPID DEVELOPMENT OF XML-BASED WEB APPLICATIONS

277
