A Service Based Approach for a Cross Domain

Reference Architecture Development

Liliana Dobrica

and Eila Ovaska

University Politehnica of Bucharest, Faculty of Automatic Control and Computers

Spl. Independentei 313, Romania

VTT Technical Research Centre of Finland, Oulu, Kaitoyvala 1, Finland

Abstract. One trend of software engineering is that systems are in transition

from component based architectures towards service centric ones. Also

techniques from software product lines can help in a quality based and

systematic reuse. The content of this paper addresses the issue of how to

perform design and quality analysis of cross domain reference architecture. The

reference architecture is designed based on the domains requirements and

features modelling. We propose a service based approach for cross-domain

reference architecture development. Throughout the sections we try to introduce

an innovative way of thinking founded on bridging concepts from software

architecture, service orientation, product line and quality analysis with the

purpose to initiate and evolve software systems products.

1 Introduction

In software development domain systems of yesterday become components of today.

The fundamental principle stating that “any system consists of components” is

common for any technical system and it is sometimes called “a law of nature” [6].

Among the requirements and constraints that have to be satisfied we can mention a

higher diversity and complexity of systems and components, increased quality,

productivity and reuse content, standardization, stricter requirements for time-to-

market. The domain technology causes exponential growth of the designed systems.

Nowadays many systems are used as subsystems in a variety of domains such as

enterprise systems, embedded systems, and so on. In these domains there is a variety

of functions; however they might be composed of a limited number of common

software/hardware components. Nowadays in various industries it has been

recognized a significant duplication of development effort for hardware, software and

services [1]. Due to the escalating complexity level, the technology trends and the

bigger competition in the world market, a coherent and integrated development

strategy is required. It becomes a research priority the creation of a generic platform

and a suite of abstract components with which new developments in different

application domains can be engineered with minimal effort. Generic platforms, or

reference designs, can be based on a common architectural style that supports the

Dobrica L. and Ovaska E. (2009).

A Service Based Approach for a Cross Domain Reference Architecture Development.

In Proceedings of the 4th International Conference on Evaluation of Novel Approaches to Software Engineering - Evaluation of Novel Approaches to

Software Engineering, pages 33-44

DOI: 10.5220/0001969600330044

 SciTePress

composition of systems out of pre-validated independently developed subsystems that

meet the requirements of the different application domains. Given a core architectural

style, different components are created for different application domains, while

retaining the capability of component reuse across these domains.

Reference architecture (RA) serves several purposes, of which the most important

are knowledge base, starting point and reuse. Knowledge base represents a common

terminology for software system architects. The shared terminology enables architects

to share experiences more efficiently. Starting point means that architectural

documentation can be used as a starting point for an iterative development process,

reducing in this way the effort for designing architectures for new products. Reuse is

in the sense that the RA describes the generic structure and behavior of the services.

This makes integrating existing “compliant” software components easier and thus

increases the reuse potential of those services. The RA functionality, interfaces and

constraints are abstract and complex. Not all the development organizations will

understand them well. Not knowing RA capabilities may lead to the architecture not

being fully used. However, the aim is that all products should fit into the provided

architecture and benefit from it. Requirements that have already been considered

might be re-implemented for various products. An impact of multi-implemented

requirements could be an unstable RA.

In this paper we propose a coherent and integrated development strategy for

complex systems that considers the architecture the main driver. We argue with our

experiences in the software architectures design and analysis for various domains [4,

5] and other researchers’ recent studies that will be revealed during the paper. Our

contribution is in the synthesis of the most important issues that can be applied in a

cross domain development strategy based on quality. We propose a service based

approach for cross-domain RA development.

2 Background

2.1 Software and Service Architecture

Software architecture (SA) provides design-level models and guidelines for

composing software systems. The SA is defined as “the structure or structures of the

system, which comprise software components, the externally visible properties of

those components, and the relationships among them” [12]. The SA description is

designed to address the different perspectives one could have on the architecture.

Each perspective is a view. The information relevant to one view is different from that

of others and should be described using the most appropriate technique. Several

models have been proposed that include a number of views that should be described

in the software architecture. The view models have something in common, and that is

that they address the static structure, the dynamic aspect, the physical layout and the

development of the system. In general, it is the responsibility of the architect to decide

which view to use for describing the SA. Architectural styles are recurring patterns of

system organization whose application results in systems with known, desirable

properties. In practice, an architectural style consists of rules and guidelines for the

partitioning of a system into subsystems and for the design of the interactions among

subsystems. The subsystems must comply with the architectural style to avoid a

property mismatch at the interfaces between subsystems.

Service architecture is a set of concepts and principles for specification, design,

implementation and management of software services [7]. This definition is similar to

SA that also includes the principles for guiding its design and evolution and has a

strong influence over the lifecycle of a system [10]. Service architecture refers mostly

to the software architecture of applications and middleware which is the software that

is located between applications and network layer. A middleware layer hide the

underlying network environment complexity insulating applications from explicit

protocol handling, disjoint memories, data replication and parallelism. Furthermore,

the middleware layer masks the heterogeneity of operating systems, programming

languages and networking technologies to facilitate application programming and

management [8]. A service based approach provides support for adaptability and

flexibility of components and frameworks [9]. A design approach of services at

architectural level has to consider quality attributes and standards.

2.2 The Software Product Line Development

In general the software product line development consists of two stages which are

domain engineering and application engineering [15]. Domain engineering is divided

in: Domain Analysis, Domain Design and Domain Implementation. The domain

analysis consists in capturing information and organizing it as a model. Some

methods, such as FODA (Feature-Oriented Domain Analysis) [3] propose a set of

notations for the domain modeling using the notion of "features" to refer to products

properties. The input represents domain knowledge and outputs are domain

requirements. The domain design consists in establishing the product line

architecture. The domain implementation consists of implementing the architecture

defined during the domain design as software components. The results represent core

assets such as, domain requirements, product-line architecture and components. The

application engineering stage consists in building products based on the results of

domain engineering and users needs. During application analysis of a new system, the

requirements from the existing domain model, which matches the user’s needs, are

selected. Applications are assembled from the existing reusable components.

Variability management is a key issue in the success of product line development.

2.3 Quality Evaluation Techniques at the Architectural Level. Scenarios

Evaluation techniques are categorized in questioning and measuring techniques [12].

The first category generates qualitative questions to ask about a SA and they are

applied to evaluate SA for any given quality. Questioning techniques include

scenarios, questionnaires and checklists. Measuring techniques suggest quantitative

measurements to be made on SA. They are used to answer specific questions and to

address specific software qualities, and therefore they are not as broadly applicable as

questioning techniques. This category includes metrics, simulations, prototypes and

experiences. In terms of quantitative and qualitative aspects, both classes of

techniques are needed for evaluating SA. Various analyzing models expressed in

formal methods are included in quantitative techniques. Qualitative techniques

illustrate SA evaluations using scenarios. Scenarios are rough, qualitative evaluations

of architecture. Scenarios are necessary but not sufficient to predict and control

quality attributes and have to be supplemented with other evaluation techniques.

Including questions about quality indicators in the scenarios enriches SA evaluation.

The existing practices with scenarios are systematized in [12]. The usage of

scenarios is motivated by the consensus it brings to understanding of what a particular

software quality really means. Scenarios are a good way of synthesizing individual

interpretations of a software quality into a common view. This view is more concrete

than the general software quality definition and it also incorporates the specifics of a

system to be developed, i.e. it is more context sensitive. Scenarios are a postulated set

of uses or modifications of the system and they are typically one sentence long and

the modifications reflected in scenarios could be a change to how one or more

components perform an assigned activity, the addition of a component to perform

some activity, the addition of a connection between existing components, or a

combination of these factors. The scenario development is based on the system

requirements that are considered in the architecture. Scenarios have to be sufficiently

concrete to ensure the expressiveness of the analysis.

3 Our Approach

3.1 Architecture Design

We define a cross domain approach that extends to three levels the architecture

development of a software system (Fig. 1.). We consider the system as a collection of

cooperating services that deliver required functionality. These services may be

executed in a networked environment and may be recomposed dynamically. The RA

level includes core services and focuses on commonality analysis. Also the RA

includes rules or constraints on how core services should be combined to realize a

particular functional goal. Domain architecture level includes domain specific

services and requires variability management concerns. The last level is dedicated to

the set of product architectures, where rules for product derivation and configuration

are included. A feature model is a prerequisite of our approach [2]. This model is

essential for both variability management and product derivation, because it describes

the requirements in terms of commonality and variability, as well as defining

dependencies. We have built a UML meta-model for features modelling (Fig. 2.). The

features model specifies dependencies called composition rules. The requires rule

expresses the presence implication of two features and the mutually exclusive rule

captures the mutual exclusion constraint on feature combinations.

Reference Architecture

(cross domain)

Core Services

Domain Architecture

Domain Specific

Services

Variability

management

Product Architecture

Concrete

Services

Rules for product

derivation and

configuration

Commonality

Fig. 1. Architecture development approach.

RA defines quality attributes, architectural styles and patterns and abstract

architectural models (Fig. 3.). Quality attributes clarify their meaning and importance

for core service components. The interest of the quality attributes for the RA is how

the quality attribute interacts with and constrains the achievement of other quality

attributes. Services have to meet many quality attributes. Modifiability of a service is

divided into the ability to support new features, simplify the functionality of an

existing system, adapt to new operating environments, or restructure system services.

Integrability measures the ability of the parts of a system to work together. It depends

on the external complexity of the components, their interaction mechanisms and

protocols, and the degree to which responsibilities have been cleanly partitioned.

realize

Root

Features

Model

Features

Composition

Rules

Requires Mutual

exclusion

Core Services

Specific Services

Package

Leaf

Mandatory Optional Alternative Optional

Alternative

Fig. 2. Features - UML metamodel.

The styles and patterns are the starting point for architecture development.

Architectural styles and patterns are means to achieve qualities. A style defines a class

of architectures and is an abstraction for a set of architectures that meet it. An

architectural pattern is a documented description of a style or a set of styles that

expresses a fundamental structural organization schema applied to high-level system

subdivision, distribution, interaction, and adaptation [13].

Reference Architecture

Styles and

Patterns

Core Services

Quality

Attributes

Service

Taxonomy

Taxonomy of Constraints

and Requirements

Standards

Fig. 3. RA realization.

Design patterns, on the other hand, are on a detailed level. They refine single

components and their relationships in a particular context [14]. In this way the RA

creates the framework from which the architecture of new products is developed. It

provides generic architectural services and imposes an architectural style for

constraining specific domain services in such a way that the final product is

understandable, maintainable, extensible, and can be built cost-effectively. Potential

reusability is highest on RA level. Core services and the architectural style of the RA

are reused in every domain architecture. RA is build based on a service taxonomy.

We adopted the idea from WISA [11] of an existing knowledge on software

engineering that is integrated and adapted to service engineering. The standards

related to each domain, applicable styles and patterns and existing concepts of

services and components are the driving forces in system development. A service

taxonomy defines the main categories called domains. Typical features that have been

abstracted from requirements characterize services. The reason of service taxonomy is

to guide the developers on a certain domain and getting assistance in identifying the

required supporting services and features of services.

Domain architecture describes ready made building blocks that assist

application/products developers in using specific domains services. When the RA has

been defined, the existing components and services are considered as building blocks

in the architecture of the set of products. The domain services provides variable assets

repository. Variability appears in functional and non-functional requirements

(including quality attributes). A structured domain architecture repository may be

provided at this level. A schema for this repository has to be defined in a form of

relationships between services. In this way we are mapping domain specific services

to core abstract services. Specialization relation is a solution to be used for variability

management. Run-time quality attributes variability requires tool support for

modelling. The tool must provide monitoring mechanisms, measuring techniques and

decision models for making tradeoffs [13].

Product architecture level consists of concrete services derived and configured

based on rules. The goal of product derivation is to reach a configuration in which

necessary variabilites have been bound. The decision model for bounding specific

services of a domain to a product may be in a tabular form or a more comprehensive

tool based on the feature types and composition rules. By selecting a consistent set of

features required for the individual product, the corresponding domain specific

services that realize those features are selected from the domain architecture

repository to constitute the product.

3.2 Architecture Analysis

We have applied an analysis method that consists of the following five steps:

1. Deriving of change categories from the problem domain. Fig. 4. presents five

categories of the change scenarios derived from the problem domains. A change

scenario related to one of these categories may require other changes in the other

categories. It is recommended to consider this possibility in the scenario development

process. Usually it occurs when the problem domain is organized so that it is easy to

identify the main sources for the addition of subsequent features in the domain.

2. Scenarios identification. Possible changes may happen in the life of the system

based on the derived categories. Scenarios should illustrate the kinds of anticipated

changes that will be made to the system. A common problem of the scenario

development is when to stop generating scenarios. Using a set of standard quality

attribute-specific questions we ensure proper coverage of an attribute by the

scenarios. The boundary conditions should be covered. A standard set of quality-

specific questions allows the possibility of extracting the information needed to

analyze that quality in a predictable, repeatable fashion. The architecture is a good

one and it is not necessary to generate scenarios to verify the functional requirements.

Otherwise these should also be considered when verifying functionality. For

analyzing the modifiability we must look for possible changes in the problem domain.

Software

technology

Domain-specific

Hardware

Functional

requirements

Non-functional

requirements

General- purpose

Hardware

Problem domain of a software system CHANGES

Fig. 4. Categories of scenarios.

3. Architecture Description could be performed in parallel with the previous one.

Architecture description may use multiple views. For a common level of

understanding a small and simple lexicon could be used in describing structures.

4. Evaluate the effect of the scenarios on the architecture elements. The effect is

estimated by investigating which services are affected by that scenario. The cost of

the modifications associated with each change scenario is predicted by listing the

services that are affected and counting the number of changes. The objective is to get

a measurement of the quality of the core and domain services with respect to the

anticipated variability in functional or non-functional characteristics.

5. Scenario interaction. The result of the effects evaluation represents the input for

this step. The activity is to determine which scenarios affect the same service. High

interactions of unrelated scenarios indicate a poor separation of concerns. If any of the

scenarios affect a core service this is no more part of the RA, but a domain specific.

4 Example

4.1 Example Description

Our example is abstracted from our experiences with the architecture design of a

scientific on-board silicon X-ray array (SIXA) spectrometer control software. SIXA is

a multi-element X-ray photon counting spectrometer. It consists of specific domain

hardware elements. The SIXA measurement activity consists of observations of time-

resolved X-ray spectra for a variety of astronomical objects. Fig. 5 introduces the

context view of SIXA considering it a measurement controller. External elements are

a command interface and physical devices, i.e. sensors and actuators. The system is

programmed and operates using a set of commands sent from a command interface.

Parameters

Start

Stop

Measurement

Controller

Command

Interface

commands

Physical devices

(Detectors)

Science data

data reports

Fig. 5. Context view of the system.

The role of the spectrometer controller is to control the following modes: (a)

Energy Spectrum (EGY), which consists of three energy-spectrum observing modes:

Energy-Spectrum Mode (ESM), Window Counting Mode (WCM) and Time-Interval

Mode (TIM). (b) SEC, which consists of single event characterization observing

modes: SEC1, SEC2 and SEC3. Each mode could be controlled individually. A

coordinated control of the analog electronics is required when both measurement

modes are on.

EGY_Controller SEC_Controller

SECwithEGY_Fetures EGY_Fetures SECFetures

AbstractSpectrometerFetures

Depends Depends Depends

Depends

Depends Depends

SECwithEGY_Controller

Fig. 6. Mapping features into packages.

The analysis result of requirements for domain engineering is the features model.

This has been structured in packages (Fig. 6.). The with reuse aspect of reusability is

described in the architecture by the abstract features. The abstract features

encapsulated in three main abstract domains MeasurementController, Data

Management and DataAcquisition, are completely reused in all the derived products.

The AbstractSpectrometerFeatures package has the highest degree of reusability but

also the highest degree of dependability. The abstract features depend on the

commonality between EGY and SEC features. A change in the problem domain of a

product is reflected in the degree of reusability of the abstract domain features.

The sets of products that could be derived from the domain specific services during

application engineering are: (1) P1 – EGYController includes specific services of a

standalone control of EGY mode; (2) P2 – SECController includes specific services

of a standalone control of SEC mode; (3) P3 – SECwithEGYController includes

specific services of coordinated control.

4.2 Example Architectural Design

The architecture model is documented around multiple views describing conceptual

and concrete levels, for each view a static and dynamic perspective being offered.

Architecture documentation addresses specific concerns for measurement control,

data acquisition control and data management. The views are illustrated with

diagrams expressed in UML-RT, a real-time extension of UML.

<<Multiple Domain>>

Measurement

<<Domain>>

MeasurementControl

<<Domain>>

DataManagement

<<Domain>>

DataAcquisitionControl

<<Service>>

EGY DM

<<artifact>>

VariabilityManagementTool

EGY_Controller SEC_Controller SECwithEGYController

<<artifact>>

RepositorySchema

<<artifact>>

RulesForProductDerivationAndConfiguration

<<Service>>

SAC

<<Service>>

EGY DAC

<<Service>>

SEC DAC

<<Service>>

SEC DM

Fig. 7. Spectrometer controller cross domain architecture design approach.

The conceptual level considers a functional decomposition of the architecture into

domains. The relationships between architectural elements are based on pass control

and pass data or uses. The concrete level considers a more detailed functional

description, where the main architectural elements are packages, capsules, ports,

protocols. The relationships are association, specialization, generalization, etc.

Considering the dynamic aspect statechart diagrams and message-sequence charts are

also part of this description level. Fig. 7 presents the spectrometer controller cross

domain architecture design approach. The RA encapsulated in the Measurement

«Domain» is composed of three core abstract «Domain»s Measurement Control,

DataAcquisitionControl and DataManagement. In each core «Domain» abstract

features are collected. The MeasurementControl is responsible for services of starting

and stopping the operating mode for data acquisition according to the commands

received from the command interface and according to the events generated in other

parts of the software. DataAcquisitionControl service collects events (science data) to

the spectra data file during observation of a target. This abstract service includes as

well as hides data acquisition details. DataManagement abstract services provide

interfaces for storing science data, opening/closing/writing the data files, hiding

storing details and controlling transmission of the stored data to command interface.

Domain architecture: Domain architecture consists of domain specific services and

variability management services. Each of the three core services is specialized in

domain specific services. For example, MeasurementControl is specialized in

StandAloneControl (SAC) and CoordinatedControl (CC), DataAcquisitionControl

(DAC) is specialized in EGY_DataAcquisitionControl (EGY_DAC) and

SEC_DataAcquisitionControl (SEC_DAC), Data Management (DM) is specialized in

EGY_Data Management (EGY_DM) and SEC_DataManagement (SEC_DM). This

architecture includes services associated to variability management.

Table 1. Domain specific services and products.

Domain Specific Service Products

P1 P2 P3

MeasurementControl SAC x x

CC x

DataAcquisitionControl EGY_DAC x x

SEC_DAC x x

DataManagement EGY_DM x x

SEC_DM x x

Product architecture: Product architecture for the sets of products includes rules

for product derivation and configuration. Table 1 presents domain specific services

and products derivation. Products are horizontally distributed and the domain services

are dispersed vertically. Each cell t

of the table is marked if product P

uses

component C

. For example, two products, P1 and P2, include a SAC service of the

measurement control domain.

4.3 Example Architecture Analysis

We have defined twelve change scenarios for changes in general purpose hardware,

domain specific hardware, technology, functionality, non-functional requirements and

other changes. For example a scenario in domain specific hardware category is: “Add

a hard disk for SEC products.” Then we have analyzed the concrete structural view of

the SA. A good SA design provides a good localization of changes. Most of the

changes required by scenarios are applied to one component, which indicates a good

decoupling of concerns. An important change is the addition of the hard disk, a

variation among products. This scenario requires changes localized to specific

domains services. By structuring the architecture in abstract domain services, which

encapsulate common features of the multiple domains and domain specific services at

a concrete level, which in turn represents specialization of the optional, alternative

and optional alternative features, the effects of the change scenarios are minimized

and localized. Changes did not affect the core services of the cross domain RA, which

confirms the stability of the architecture across domains. The results of the analysis

depend on the description of the architecture. By using only the decomposition view

on the conceptual level the effects of the change scenarios are reduced because not all

the details are included. On the concrete level, the views developed with the help of a

CASE tool the effect of change scenarios is more relevant. This is an argument for

that the evaluation method should be applied iteratively while the architecture design

becomes more detailed. The purpose of the evaluation is to analyze the architecture to

identify potential risks by predicting the quality of the products before they have been

built. Iterative methods promote analysis at multiple resolutions as a means of

minimizing risk at acceptable levels of time and effort. Areas of high risk are

analyzed more profoundly (simulated, modeled or prototyped) than the rest of the

architecture. Each iteration determines where to analyze more deeply in the next

iteration.

The measurement controller domain also requires run-time qualities such as

performance, safety and reliability. These are mandatory root features for the domain.

However variants could include variability in these aspects. These variable features

must be considered from the cross domain design perspective in order to minimize the

risk that the final software products do not conform to these quality attributes. For

architectural evaluation of these aspects several progresses have been identified in the

literature that will be analyzed in our future work. It is important to estimate what is

the degree of reuse at architectural level and what are the reusable assets when the

variability of these run-time qualities is considered.

5 Conclusions

We have proposed an approach for software development based on a cross-domain

RA. We have provided an incremental design and analysis approach based on

services, which is more practical, easy to follow and benefits of advantages provided

by service engineering. Our approach has been validated by a simple example. The

problem dimension for the development of a cross-domain RA increases due to the

larger number of requirements and constraints that may be specified by the complex

systems domains. Building the features model may require a tool in order to manage

the analysis and structuring the abstract features in domains. The cross domain RA

contains core services of the domains included in the abstract features package. The

appropriate architectural style is provided by a knowledge base through a service

taxonomy. A domain architecture repository is a solution for variability management

of specific services. A decision support tool is proposed for product derivation. The

role of this tool is to bound variabilities in order to get a service configuration for a

product architecture. In our example we developed a tabular form for the decision

model. When the complexity increases a more elaborated tool is required and is a

subject of our future research. The analysis strategy based on scenarios has been used

to verify architecture against anticipated changes in domain knowledge. From the

commonality viewpoint analysis results should consider if scenarios affect core

services of the RA. If these core services are affected they should be domain specific.

Future research work is needed to develop systematic ways of bridging

requirements taxonomy of each domain to a cross domain RA. However this paper

presented the main concepts and justified why this concepts are required. When

several domains adopt a service oriented approach it is possible to develop products

which address functions from across two or more domains and consume services from

multiple domains. Seeking engagement of communities of practice across domains is

a more challenging but worthwhile goal. It remains to be seen as to how relevant

international bodies foster such engagement. An essential prerequisite however is to

have in place a coherent core services for each specific domain that can be used as a

point of reference in establishing cross domain exchanges.

References

1. Kopetz H.: The ARTEMIS Cross-Domain Architecture for Embedded Systems, (2007)

2. Kang. K., S. Cohen, J. Hess, W. Novak, A. Peterson: Feature-Oriented Domain Analysis

Feasibility Study, SEI Technical Report CMU/SEI- 90-TR-21 (1990)

3. Niemelä E., Evesti A., Savolainen, P, Modeling Quality Attribute Variability, Procs. of the

Int. Conf ENASE., INSTICC Press, (2008) 169-176

4. Dobrica L., Niemelä E.: A survey on software architecture analysis methods, IEEE Trans.

on Soft. Eng. Journal, 28(7), (2002) 638-653

5. Dobrica L., Niemelä E.: Modeling Variability in the Software Product Line Architecture of

Distributed Services, Procs of SERP 2007, (2007) 269-275

6. Szypersky C.: Component Software Beyond Object-Oriented Programming, Addison-

Wesley (1999)

7. TINA, Service Architecture Specification, http://www.tinac.com, (1997)

8. Dobrica L, Niemelä E: Adaptive middleware services, Procs. IASTED AI’2002, (2002)

9. Costa E., G. Blair, G. Coulson: Experiments with reflexive middleware, Procs. ECOOP’98

Workshop Reflexive Object Oriented Programming and Systems (1998)

10. IEEE Recommended Practice for Architectural descriptions of Software Intensive Systems,

Std1 417-2000, (2000)

11. Niemelä E, Kalaoja J, Lago P: Towards an architectural knowledge base for wireless

service engineering, IEEE Trans. on Soft. Eng., 31 (5), (2005) 361 – 379

12. Bass L., P. Clements, R. Kazman: Software Architecture in Practice, Addison-Wesley,

(1998)

13. Buschmann F., R. Meunier, H. Rohnert: Pattern-Oriented Software Architecture:A System

of Patterns, John Wiley and Sons, (1996)

14. Gamma E., R. Helm, R. Johnson, J. Vlissides: Design Patterns: Elements of Reusable

Object-Oriented Software, Addison Wesley, (1994)

15. Pohl K., Böckle, G., van der Linden, F.: Software Product Line Engineering. Foundations,

Principles, and Techniques. Springer-Verlag, (2005)
