OPTIMIZATION OF SPARQL BY USING CORESPARQL

Jinghua Groppe, Sven Groppe and Jan Kolbaum

IFIS, University of Luebeck, Ratzeburger Allee 160, D-23538 Luebeck, Germany

Keywords: Semantic Web, RDF, SPARQL, coreSPARQL, Query Optimization, Query Rewriting.

Abstract: SPARQL is becoming an important query language for RDF data. Query optimization to speed up query

processing has been an important research topic for all query languages. In order to optimize SPARQL

queries, we suggest a core fragment of the SPARQL language, which we call the coreSPARQL language.

coreSPARQL has the same expressive power as SPARQL, but eliminates redundant language constructs of

SPARQL. SPARQL engines and optimization approaches will benefit from using coreSPARQL, because

fewer cases need to be considered when processing coreSPARQL queries and the coreSPARQL syntax is

machine-friendly. In this paper, we present an approach to automatically transforming SPARQL to

coreSPARQL, and develop a set of rewriting rules to optimize coreSPRQL queries. Our experimental

results show that our optimization of SPARQL speeds up RDF querying.

1 INTRODUCTION

The Semantic Web uses the Resource Description

Framework (RDF) (Beckett, 2004) as its data format

to describe information in the web. RDF provides a

model and syntax for describing data, but it does not

provide querying functionalities. A number of RDF

querying languages have been developed, e.g. RQL,

N3, Versa, SeRQL, Triple and RDQL. When (Haase

et al., 2004.) compares these six languages,

SPARQL (Prud’hommeaus and Seaborne, 2007) has

not emerged. SPARQL was first proposed on 12th

October 2004 and became an official W3C

Recommendation on 15th January 2008. Many RDF

stores support or plan to support SPARQL, e.g. Jena

(Wilkinson et al., 2003) and Sesame (Broekstra et

al., 2002). SPARQL becomes increasingly important

as an RDF query language.

The optimization of queries has been an active

research topic for improving the performance of

query processing. An important optimization

technique is rewriting of queries. While query

rewriting has been extensively studied in the

relational databases and XML areas, there is no

complete and thorough work on rewriting of

SPARQL queries. Therefore, we focus on the

rewriting and simplification of SPARQL queries. In

this paper we develop a core fragment of the

SPARQL language to simplify SPARQL, which we

name coreSPARQL, and a set of rules to optimize

coreSPARQL queries.

SPARQL supports a large number of different

language constructs, which brings flexibility of

expressiveness, but also redundancy of expressions.

For example, the three expressions of SPARQL in

Figure 1 have the same semantics. Redundant

expressive power increases the difficulties of query

processing. It is also obvious that the syntax for

Expression 1 is user-friendly, but Expression 3 is

more easily to be interpreted by a machine.

Expression 1 Expression 2 Expression 3

(1 [?x 3]). [] rdf:first 1;

rdf:rest _:b.

_:b rdf:first [$x 3];

rdf:rest rdf:nil.

_:b1 rdf:first 1.

_:b1 rdf:rest _:b2.

_:b2 rdf:first _:b3.

_:b3 ?x 3.

_:b2 rdf:rest rdf:nil.

Figure 1: Three SPARQL expressions with same

semantics.

In order to reduce the number of cases, which

must be considered when processing SPARQL

queries, and in order to make SPARQL queries more

machine-processable, we suggest the coreSPARQL

language, which is a core fragment of the SPARQL

language. coreSPARQL posses the same expressive

power as SPARQL, but does not contain redundant

This work is funded by the German Research Foundation

(DFG) project GR 3435/1-1 LUPOSDATE.

107

Groppe J., Groppe S. and Kolbaum J. (2009).

OPTIMIZATION OF SPARQL BY USING CORESPARQL.

In Proceedings of the 11th International Conference on Enterprise Information Systems - Databases and Information Systems Integration, pages

107-112

DOI: 10.5220/0001983501070112

 SciTePress

language constructs of SPARQL and only allows

machine friendly syntax. We develop an approach,

which automatically transforms SPARQL queries to

coreSPARQL queries.

SPARQL queries written by users or generated

by applications are often un-optimized, and thus

sub-optimal. Sub-optimal queries impact query

processing performance. Based on coreSPARQL, we

develop a set of simplification rules to rewrite

coreSPARQL queries, and transform a sub-optimal

query into an optimal query by eliminating

redundant parts and optimizing sub-expressions. Our

performance study shows that after our optimization,

SPARQL can be processed more efficiently, and the

transformation of SPARQL to coreSPARQL has a

low overhead. Due to the limitation of space, we do

not present our experiment results in this paper.

Related Work. (Pérez et al., 2006) suggests several

rules for rewriting AND, UNION and OPTIONAL

expressions in SPARQL queries. The purpose of the

rewriting is constructing a critical fragment of

UNION-free graph pattern expressions for the study

of evaluation complexity.

(Bernstein et al., 2007), (Groppe et al., 2007a),

(Broekstra et al., 2002) and (Groppe et al., 2009)

reorder triple patterns in order to reduce the size of

intermediate results. (Groppe et al., 2007a) pushes a

filter expression upward if all the variables in the

filter expression has already been bound. (Bernstein

et al., 2007) reorders triple patterns according to

their selectivity, which is estimated based on

schemas. (Broekstra et al., 2002) and (Groppe et al.,

2009) both observe that the number of variables

might impact the sizes of the intermediate resultant

data. (Broekstra et al., 2002) reorders the triple

patterns according to the number of variables, while

(Groppe et al., 2009) considers the number of the

new variables, which have not been bound so far,

because the occurred variables are bound with the

result of previous triple patterns.

An amount of work contributes to the rewriting

of relational algebra, and develops a number of

equivalency rules (Arasu et al., 2006) (Chaudhuri,

1998) (Ioannidis, 1996) (Jarke and Koch, 1984).

Some of our and other equivalency rules for

rewriting SPARQL queries are adapted from the

equivalency rules for relational algebra, e.g. the

rules for comparison operators.

Several contributions are dedicated to the

transformation of SPARQL queries to SQL queries,

and the storage of RDF data in relational databases,

and thus use proven database technologies, e.g.

(Chong et al., 2005), (Chebotko et al., 2007) and

(Cyganiak, 2005).

(Groppe et al., 2007b), (Weiss et al., 2008) and

(Groppe et al., 2009) suggest different indices for

fast data access. (Groppe et al., 2009) develops a

new approach to compute join of triple patterns by

dynamically restricting triple patterns.

2 RDF AND SPARQL

Figure 2 presents an example of RDF data and of a

SPARQL query.

RDF data is a set of triples of the form Subject

Predicate Object, which are RDF terms, e.g. IRIs,

literals or blank nodes. Figure 2 provides an example

of RDF data with 3 triples. SPARQL selects RDF

data based on graph pattern matching, where the

core component of SPARQL graph patterns is a set

of triple patterns s p o. s p o corresponds to the

subject (s), predicate (p) and object (o) of a RDF

triple, but they can be variables as well as RDF

terms. A triple pattern matches a subset of the RDF

data, where the RDF terms in the triple pattern

correspond to the ones in the RDF data. The query

result of a triple pattern consists of pairs of variables

with their bound values, i.e. corresponding RDF

terms in the matched subset of the RDF data. The

result of a set of triple patterns is the join of the

result of each triple pattern.

Book.rd

Book.sparql

@prefix ex: <http://book/>

ex:book1 ex:title “XML”.

ex:book2 ex:title “Index”.

ex:book2 ex:pages 90.

prefix ex: <http://book/>

SELECT ?y, ?z

WHERE { ?x ex:title ?y.

?x ex:pages ?z.}

Figure 2: RDF data and SPARQL query.

The SPARQL query Book.sparql in Figure 2

consists of the SELECT clause and the WHERE

clause. The SELECT clause identifies the variables to

appear in the query results, and the WHERE clause

contains two triple patterns, which identify the

constraints on RDF data. The triple pattern ?x ex:title

?y matches the first two triples of Book.rdf, such that

its result is {<?x=ex:book1, ?y=“XML”>, <?x=ex:book2,

?y=“Index”>}. The triple pattern ?x ex:pages ?z

matches the last triple of Book.rdf, such that the result

is {<?x=ex:book2, ?z=90>}. The two triple patterns

impose a join over the common variable ?x, such

that the result of the two triple patterns is

{<?x=ex:book2, ?y=“Index”, ?z=90>}. The final query

result is {<?y=“Index”, ?z=90>}.

SPARQL provides rich capabilities to select and

filter data, and we refer the interested reader to

ICEIS 2009 - International Conference on Enterprise Information Systems

108

(Prud’hommeaus and Seaborne, 2007) for a

complete description of SPARQL.

3 CORESPARQL

SPARQL allows redundant language constructs and

supports abbreviated syntax. The redundancy brings

the flexibility of expressiveness and abbreviations

bring the simplification of expressions, but they do

not increase the expressive power of the language.

That a SPARQL query can be expressed in different

forms increases the number of cases to be processed;

the abbreviated syntaxes are not machine-friendly.

In order to make SPARQL queries more machine-

processable, and to reduce the number of cases,

which must be considered when processing

SPARQL queries, we abstract a subset from the

SPARQL language, and name the subset

coreSPARQL.

3.1 Defining coreSPARQL

In Definition 1, we describe coreSPARQL in terms

of the common and different properties with

SPARQL. Figure 3 demonstrates several SPARQL

and corresponding coreSPARQL components.

component

SPARQL

coreSPARQL

triple pattern

s1 p1 o1;

p2 $x.

s1 p1 o1.

s1 p2 ?x.

blank node []

[ p o].

:b p o.

group graph pattern

{ {s1 p1 o1}

s2 p2 o2. }

{ s1 p1 o1.

s2 p2 o2. }

&& operator Filter(A && B). Filter(A).

Filter(B).

Figure 3: SPARQL and corresponding coreSPARQL

components.

Definition 1 (coreSPARQL). coreSPARQL is a

core fragment of SPARQL. A coreSPARQL query is

also a SPARQL query. coreSPARQL has the same

expressive power as SPARQL, but allows only

machine-friendly syntax, and eliminates many

redundant language constructs. Especially, in

coreSPARQL,

• all triple patterns are only in the form: s p o.;

• a group graph pattern cannot directly nest

another group graph pattern;

• variable names start only with ?;

• blank nodes [] are not allowed;

• RDF collections of the form (…) are not

allowed;

• neither prefixed IRIs nor IRIs, which are relative

to a BASE-declaration, are allowed.

• the keyword a is not allowed;

• the && operator is not allowed. 

3.2 Transforming SPARQL to

CORESPARQL

SPARQL provides user-friendly syntax to write

RDF queries, and coreSPARQL queries are easy to

program. Therefore, the next task for us is to find a

way to automatically transform SPARQL queries to

coreSPARQL queries. We develop a set of

transformation rules, such that a SPARQL query can

be transformed into a coreSPARQL query by

recursive application of these rules, i.e. if the

expression of a left-hand side of a rule occurs in a

SPARQL query, it is replaced with the right-hand

side of the rule.

We use the following notation to describe these

rules: we write s (s1, s2,…), p (p1, p2, …), o (o1, o2,…)

for the subject, predicate, and object of a triple

pattern, os (os1, os2, …) for a list of objects, e.g. os =

, o

, …, o

, where m≥1, and pos (pos1, pos2, …)

for predicate-object-lists, e.g., pos=p

; p

; …;

, where m≥1. A blank node [ ] is replaced by a

blank node label, e.g. _:b, where b must be not used

elsewhere in the query. Note that some patterns in

the following rules may be not supported by

SPARQL. Such patterns are intermediate results of

the transformation, and will be translated to standard

language constructs after the transformation.

• Rule 1: eliminating Object-Lists:

1.1 s1 p1 o1, os. => s1 p1 o1. s1 p1 os.

• Rule 2: eliminating Predicate-Object-Lists:

2.1 s1 p1 os1; pos. => s1 p1 os1. s1 pos.

• Rule 3: eliminating blank nodes [].

3.1 [] => _:b

3.2 [ pos ]. => _:b pos.

3.3 [ pos ] p1 os1. => _:b pos. _:b p1 os1.

3.4 s1 p1 [ pos ]. => s1 p1 _:b. _:b pos.

• Rule 4: eliminating RDF collections ( ), where e

(e1, e2,..) is an element of the collection, i.e. a

variable, a literal, a blank node, or a collection.

Here, we introduce a variant of the collection, e.g.

(e)

s=_:b

. to restrict that the blank node, which is

allocated for the collection (e), must be _:b.

4.1 (e) pos. => _:b rdf:first e.

_:b rdf:rest rdf:nil.

_:b pos.

4.2 (e). => _:b rdf:first e. _:b rdf:rest rdf:nil.

4.3 (e1 e2 e3…). => _:b rdf:first e1.

_:b rdf:rest (e2 e3…).

OPTIMIZATION OF SPARQL BY USING CORESPARQL

109

4.4 s p (e1 e2 ...). => s p _:b. (e1 e2 ...)

s=_:b

4.5 (e1 e2…)

s=_:b

. => _:b rdf:first e1.

_:b rdf:rest (e2…).

4.6 (e)

s=_:b

. => _:b rdf:first e. _:b rdf:rest rdf:nil.

4.6 () => rdf:nil

• Rule 5: eliminate the keywork a:

5.1 a => rdf:type

• Rule 6: eliminate directly nested group graph

patterns

6.1 { {A} …} => { A …},

where {A} is not a part of a OPTIONAL, or a

UNION, or a GRAPH graph pattern; A does not

consist of only Filter expressions either.

6.2 { {Filter(e).} … }

{ Filter(true) …}, if the result of the static

=> analysis of e is true.

{ Filter(false)…}, if the result of the static

analysis of e is false or a

type error.

For example, the expression 10>1 is statically

analyzed to true, and thus {Filter(10>1)).} = Filter(true)..

In the group graph pattern {Filter(bound(?x)).}, the

variable x will never be bound. Therefore, the static

analysis of bound(?x) detects a type error, and thus

{Filter(bound(?x)).} = Filter(false).. For the details on the

static analysis and type errors, see Section 11.2

Filter Evaluation in the SPARQL specification

(Prud’hommeaux and Seaborne, 2007).

• Rule 7: eliminating && operator, where A, B and

C are conditional expressions.

7.1 Filter(A && B). => Filter(A). Filter(B).

7.2 (A && B) || C => (A || C) && (A ||C).

7.3 !(A || B) => !A && !B

7.4 !(A && B) => !A || !B

• Rule 8: eliminating prefixes and BASE

declarations.

8.1 p:a => <prefix(p) a>,

where prefix(p) is a function to resolve the

prefixed IRI p:a according to defined PREFIX and

BASE declarations. The PREFIX and BASE

declarations are deleted in the coreSPARQL query.

Example 1. Using this example, we demonstrate

how to transform a SPARQL expression t1 = (1 [ p

o1] (2)). into the corresponding coreSPARQL

expression by recursively applying the rules above.

1. Applying Rule 4.3 on t1: t1 => t2. t3.:

_:b1 rdf:first 1. (t2)

_:b1 rdf:rest ([ p o1] (2)). (t3)

2. Applying Rule 4.4 on t3: t3 => t4. t5.

_:b1 rdf:rest _:b2. (t4)

([ p o1] (2))

s=_:b2

. (t5)

3. Applying Rule 4.5 on t5: t5=> t6. t7.

_:b2 rdf:first [ p o1]. (t6)

_:b2 rdf:rest ((2)). (t7)

4. Applying Rule 3.4 on t6: t6 => t8. t9.

_:b2 rdf:first _:b3. (t8)

_:b3 p o1. (t9)

5. Applying Rule 4.4 on t7: t7 => t10. t11.

_:b2 rdf:rest _:b4. (t10)

((2))

s=_:b4

. (t11)

6. Applying Rule 4.6 on t11: t11 => t12. t13.:

_:b4 rdf:first (2). (t12)

_:b4 rdf:rest rdf:nil. (t13)

7. Applying Rule 4.4 on t12: t12 => t14. t15.:

_:b4 rdf:first _:b5. (t14)

(2)

s=_:b5

. (t15)

8. Applying Rule 4.6 on t15: t5 => t16. t17.:

_:b5 rdf:first 2. (t16)

_:b5 rdf:rest rdf:nil. (t17)

The result of transformation consists of the triple

patterns t2, t4, t8, t9, t10, t13, t14, t16 and t17.

Note that there are further redundancies, which

we allow in coreSPARQL, as they can be processed

in a machine-friendly way. For example, the

wildcard * in SELECT [ DISTINCT | REDUCED ] * and

DESCRIBE *, can be replaced by the concrete

variables in triple patterns. REDUCED keyword can

be replaced by DISTINCT or can be deleted. Any

operations on constants can be replaced by the result

of their applications.

4 REWRITING CORESPARQL

QUERIES

While the coreSPARQL query does not contain

redundant language constructs, a coreSPARQL

query may not be optimal, e.g. containing redundant

constraints. For example, if we have two constraints

bound(?x). Filter(?x=1). in a SPARQL query, then the

constraint bound(?x) is redundant: bound(?x) requires

that the variable x is bound with a value, and

Filter(?x=1) implies that x is bound to the value 1. The

reason for sub-optimal SPARQL queries is that

queries written by users or generated in applications

are often non-optimized. The sub-optimal queries

impact significantly query processing performance.

As well as being sub-optimal, queries are also

possibly unsatisfiable. A query is unsatisfiable if the

query selects the empty result for any RDF data.

Therefore, if we can detect that a query is

unsatisfiable, we can avoid the submission and

evaluation of the unsatisfiable query, and thus save

ICEIS 2009 - International Conference on Enterprise Information Systems

110

processing time and query cost. A query is

unsatisfiable, if it contains conflicting constraints.

For example, two constraints IsIRI(?x) and Filter(?x =

“http:://example.com”) contradict each other: IsIRI(?x)

requires that ?x is an IRI, but Filter(?x =

“http:://example.com”) requires that ?x is a string.

In order to optimize queries and improve the

evaluation performance, we develop a set of

equivalency rules to detect conflicting and redundant

constraints. By recursive application of these rules, a

coreSPARQL query can be optimized to a more

simple expression, or even to an empty expression,

i.e. the query is unsatisfiable.

We use the rewriting rules in

Table 1 to simplify coreSPARQL queries, where

C (C1, C2, …) represents a literal, G a graph pattern or

the query pattern, i.e. the outer-most graph pattern,

and E (E1, E2,…) an expression. Additionally, we

introduce a new graph pattern: void graph pattern,

denoted by ⊥. Contrary to the empty group pattern {}

in SPARQL, which matches any RDF graph, a void

graph pattern ⊥ does not match any RDF graph. If a

SPARQL query is simplified to the void graph

pattern, the query is unsatisfiable. Note that ⊥ is an

intermediate result during simplification, and any

satisfiable SPARQL expressions will not contain ⊥

after optimization.

5 CONCLUSIONS

We suggest the coreSPARQL language, which is a

core fragment of SPARQL, but has the same

expressiveness as SPARQL. Optimization

approaches, SPARQL engines and all applications,

which process SPARQL queries, benefit from

coreSPARQL, because coreSPARQL posses

machine-friendly syntax and thus is easy to program,

contains less language constructs and thus reduces

the number of cases to be considered.

We develop a set of transformation rules to

translate SPARQL queries to coreSPARQL queries,

and a set of rewriting rules to further optimize

coreSPARQL queries. We develop a prototype of

our approach, which shows that our optimization

speeds up SPARQL query processing.

Table 1: Rewriting rules for optimizing coreSPARQL

queries.

Eliminating the same components:

• G G => G

Constant propagation:

• Filter(?x=C). Filter(…?x…). =>

Filter(?x=C). Filter(…C…).,

if ?x is not the parameter of a bound function.

E.g. Filter(?x=10). Filter(?x>5). =>

Filter(?x=10). Filter(10>5).

E.g. Filter(?x=“work”). Filter(Lang(?x)=“EN”)). =>

Filter(Lang(“work”) = “EN”).

Variable binding:

• Filter(bound(?x)). Filter(…?x…). => Filter(…?x…).,

if ?x of Filter(…?x…) is neither a parameter of a

bound function nor inside an operand of ||.

• Filter(!bound(?x)). Filter(…?x…). => ⊥,

if ?x of Filter(…?x…) is neither a parameter of a

bound function nor inside an operand of ||.

E.g. Filter(bound(?x)). Filter(?x>10). => Filter(?x>10).

E.g. Filter(!bound(?x)). Filter(?x=“red”). => ⊥

Functions IsIRI, IsBlank, IsLiteral:

• IsIRI(C) => true, if C is an IRI;

false, if C is not aIRI.

E.g. IsIRI(<mailto:alice@work.example>) => true

E.g. IsIRI(“mailto:alice@work.example”) => false

The rules for the functions IsURI, IsBlank, IsLiteral are analogous to

this one.

Funtions LangMatches, Regex:

• LangMatches(C, L) =>

true, if C matches L;

false, if C does not match L

E.g. LangMatches(“work@EN”, “EN”) => true

E.g. LangMatches(“work”, “EN”) => false

The rules for the function Regex are analogous to this one

Function Lang:

• Lang(C1@C2) => C2

E.g. Lang(“work”@EN) => “EN”

Function Filter:

• Filter(false). => ⊥ • Filter(true). => {}

• C1 op C2 =>

true, if C1 op C2 = true;

false, if C1 op C2 = false;

E.g. Filter(1>10). => Filter(false). => ⊥

Elimination of ⊥ and {}

• G Optional ⊥ => G • G Optional { } => G

• G UNION { } => G • G UNION ⊥ => G

• G {} => G • G ⊥ => ⊥

• G Graph n { } => G, • Graph n ⊥ => ⊥

where n is a variable or an IRI

E.g. Graph ?g ⊥ => ⊥

E.g. {s p o} ⊥ => ⊥

OPTIMIZATION OF SPARQL BY USING CORESPARQL

111

Table 1: Rewriting rules for optimizing coreSPARQL queries (cont.).

Comparison operators:

• FILTER(?x op1 C1). FILTER(?x op2 C2). =>

FILTER(?x op1 C1).,

if ((op1=op2 ∧ (C1 op1 C2) ∧ op1∈{<, <=, >=, >}) ∨ ((C1 op1 C2) ∧ C1≠C2 ∧

(op1, op2∈{<, <=} ∨ op1, op2∈{>=, >})) ∨ (C1=C2 ∧ ((op1=‘<’ ∧ op2=‘<=’) ∨

(op1= ‘>’ ∧ op2= ‘>=’))))

FILTER(?x op2 C2)., if ((op1=op2 ∧ (C2 op1 C1) ∧ op1∈{<, <=, >=, >}) ∨ ((C2 op2 C1) ∧ C1≠C2 ∧

(op1, op2∈{<, <=} ∨ op1, op2 ∈ {>=, >})) ∨ (C1=C2 ∧ ((op2=‘<’ ∧ op1=‘<=’) ∨

(op2= ‘>’ ∧ op1= ‘>=’))))

FILTER(false)., if ((C1>C2 ∧ op1∈{>, >=} ∧ op2∈{<, <=} ) ∨ (C1<C2 ∧ op1∈{<, <=} ∧ op2∈{ >, >=}) ∨

(C1=C2 ∧ op1≠op2 ∧ (op1, op2∈{=, !=} ∨ op1, op2∈{<,>})))

FILTER(?x op1 C1). FILTER(?x op2 C2)., otherwise.

E.g. Filter(?x>10). Filter(?x>30). => Filter(?x>30).; Filter(?x>30). Filter(?x<10). => Filter(false).

Operators ||, ! and ¬

• E || true => true • false || false => false • E || E => E • !(A1 op A2) => A1 ¬(op) A2

• ?x op1 C1 || ?x op2 C2 =>

?x op1 c1, if ((op1=op2 ∧ (C2 op1 C1) ∧ op1∈ {<, <=, >, >=}) ∨ ((C2 op1 C1) ∧ C1≠C2 ∧ (op1, op2∈{<, <=} ∨

op1, op2∈{>=, >})) ∨ (C1=C2 ∧ ((op1=‘<=’ ∧ op2=‘<’) ∨ (op1=‘>=’ ∧ op2=‘>’)))

?x op2 C2, if ((op1=op2 ∧ (C1 op1 C2) ∧ op1∈{<, <=, >, >=}) ∨ ((C1 op2 C2) ∧ c1≠c2 ∧ (op1, op2∈{<, <=} ∨

op1, op2∈{>=, >})) ∨ (C1=C2 ∧ ((op2=‘<=’ ∧ op1=‘<’) ∨ (op2= ‘>=’ ∧ op1=‘>’))))

Bound(?x) , if (op1=¬(op2) ∧ C1=C2),

?x op1 C1 || ?x op2 C2, otherwise

• ¬(=) => != • ¬(!=) => = • ¬(<) => >= • ¬(<=) => > • ¬(>) => <= • ¬(>=) => <

REFERENCES

Arasu, A., Babu, S., Widom, J., 2006. The CQL

continuous query language: semantic foundations and

query execution. VLDB Journal, 15(2): 121-142.

Beckett, D. (editor), 2004. RDF/XML Syntax

Specification (Revised), W3C Recommendation, 10th

February 2004.

Bernstein, A., Stocker, M., Kiefer, C., 2007. SPARQL

Query Optimization Using Selectivity Estimation.

ISWC’07.

Broekstra, J., Kampman, A., van Harmelen., 2002.

Sesame: A Generic Architecture for Storing and

Querying RDF and RDF Schema. ISWC’02.

Chaudhuri, S., 1998. An Overview of Query Optimization

in Relational Systems, In ACM PODS’98.

Chebotko, A., Lu, S., Fotouhi, F., 2007. Semantics

Preserving SPARQL-to-SQL Translation. Technical

report TR-DB-112007-CLF.

Chong, E. I., Das S., Eadon G., Srinivasan J., 2005. An

Efficient SQL-based RDF Querying Scheme, VLDB’05.

Cyganiak, R., 2005. A relational algebra for SPARQL.

Technical report HPL-2005-170.

Groppe, S., Groppe, J., Kukulenz, D., Linnemann, V.,

2007a. A SPARQL Engine for Streaming RDF Data,

3rd International Conference on Signal-Image

Technology & Internet-Based Systems (SITIS’07).

Groppe, J., Groppe, S., Ebers, S., Linnemann, V., 2009.

Efficient Processing of SPARQL Joins in Memory by

Dynamically Restricting Triple Patterns. ACM SAC’09.

Groppe, S., Groppe, J., Linnemann, V., 2007b. Using an

Index of Precomputed Joins in order to Speed Up

SPARQL Processing, ICEIS’07.

Haase, P., Broekstra, J., Eberhart, A., Volz, R., 2004. A

Comparison of RDF Query Languages. in ISWC'04.

Ioannidis, Y. E., 1996. Query optimization, In ACM

Computing Surveys, Vol. 28, No. 1.

Jarke, M., Koch, J., 1984. Query Optimization in Database

Systems, In ACM Computing Surveys, Vol. 16, No. 2.

Pérez, J. Arenas, M., Gutierrez C., 2006. Semantics and

Complexity of SPARQL. ISWC’06.

Prud’hommeaux E., Seaborne A., 2007. SPARQL Query

Language for RDF, W3C Recommendation, 15 Jan.

2007.

Weiss, C., Karras, P., Bernstein, A., 2008. Hexastore:

Sextuple Indexing for Semantic Web Data

Management, VLDB’08.

Wilkinson, K., Sayers, C., Kuno, H. A., Reynolds, D.

2003. Efficient RDF Storage and Retrieval in Jena2.

In SWDB’03 co-located with VLDB’03.

ICEIS 2009 - International Conference on Enterprise Information Systems

112
