GRAPH STRUCTURE LEARNING FOR TASK ORDERING

Yiming Yang, Abhimanyu Lad, Henry Shu, Bryan Kisiel

Language Technologies Institute, Carnegie Mellon University, Pittsburgh, PA, U.S.A.

Chad Cumby, Rayid Ghani, Katharina Probst

Accenture Technology Labs, Chicago, IL, U.S.A.

Keywords: Task-order optimization, Graph structure learning, Link analysis.

Abstract: In many practical applications, multiple interrelated tasks must be accomplished sequentially through user

interaction with retrieval, classification and recommendation systems. The ordering of the tasks may have a

significant impact on the overall utility (or performance) of the systems; hence optimal ordering of tasks is

desirable. However, manual specification of optimal ordering is often difficult when task dependencies are

complex, and exhaustive search for the optimal order is computationally intractable when the number of

tasks is large. We propose a novel approach to this problem by using a directed graph to represent partial-

order preferences among task pairs, and using link analysis (HITS and PageRank) over the graph as a

heuristic to order tasks based on how important they are in reinforcing and propagating the ordering

preference. These strategies allow us to find near-optimal solutions with efficient computation, scalable to

large applications. We conducted a comparative evaluation of the proposed approach on a form-filling

application involving a large collection of business proposals from the Accenture Consulting & Technology

Company, using SVM classifiers to recommend keywords, collaborators, customers, technical categories

and other related fillers for multiple fields in each proposal. With the proposed approach we obtained near-

optimal task orders that improved the utility of the recommendation system by 27% in macro-averaged F1,

and 13% in micro-averaged F1, compared to the results obtained using arbitrarily chosen orders, and that

were competitive against the best order suggested by domain experts.

1 INTRODUCTION

Search, classification and recommendation

techniques have been intensively studied and

successfully applied as sub-domains of Information

Retrieval (IR). An open research challenge is to

make the best use of these techniques in a global

context, to accomplish a higher level goal through a

multiple-step process where task-specific search

engines, classifiers and recommendation systems are

needed in different steps. User relevance judgments

in early steps are automatically propagated to later

steps to enrich the context for later tasks. While

research on “IR in context” has recently gained

prominence 0, how to define and leverage context

remains an important and challenging problem.

Consider the process of creating a project

proposal in a large consulting organization. The

principal investigators would rely on past

information to make several key decisions about the

new project, e.g., retrieving past proposals that are

similar to the current one, finding companies that

have been targeted (successfully or unsuccessfully)

with this kind of project, choosing experts who

should be included, engagements and achievements

from the past that are relevant to the current

proposal, and so on.

That is, in order to attain a complex goal, the

users need to go through a multi-step process, and

interact with different systems for retrieval,

classification, expert finding, customer selection,

etc., which provide useful suggestions to the user at

each decision-making step, and receive feedback

from the user. The performance of the system at

each step is “context-sensitive”, i.e., it depends on

the previously accomplished tasks because the user

feedback at any of the earlier steps can be used as

additional input to the system in each later step. The

over-all performance, or the “utility”, of the system

in the multi-step process depends on the order of the

tasks being carried out. Hence, finding the optimal

order of tasks is important. However, manual

164

Yang Y., Lad A., Shu H., Kisiel B., Cumby C., Ghani R. and Probst K. (2009).

GRAPH STRUCTURE LEARNING FOR TASK ORDERING.

In Proceedings of the 11th International Conference on Enterprise Information Systems - Artiﬁcial Intelligence and Decision Support Systems, pages

164-169

DOI: 10.5220/0001989001640169

 SciTePress

specification of the near-optimal ordering may be

non-trivial when the high-level goal is sufficiently

complex or the dependencies among a large number

of tasks are subtle.

We present a formulation of the task ordering

problem as utility optimization for systems in a

multi-step process and propose a relaxation of the

objective function in terms of pair-wise order task

order preferences. We show that the problem of

finding the optimal order from partial orders is

equivalent to a known NP-Hard problem. We

propose an approximation in the form of a novel

application of link analysis (HITS and PageRank)

that is effective as well as computationally efficient.

2 A CONCRETE EXAMPLE

Consulting organizations generate documents as part

of every project they undertake. Consider the task of

assigning meta-data to these documents so that they

can be searched and browsed more effectively in

future.

Each document has multiple fields (Table 1),

some containing free text, and others filled with

categorical or nominal values. We consider filling

each meta-data field by the authors or curators as a

task. The tasks in each document are carried out step

by step by the authors, using multiple prediction

systems like enterprise-internal search engines,

classifiers and recommendation systems to find

relevant contents or items for each field. From the

prediction systems’ point of view, the input of the

first task is a “bag of features” obtained from the

text in the document. The input of the second task is

the merged bag of features, including both the input

and output of the previous task. Similarly, the input

of any later task contains the initial input and all the

outputs of the tasks prior the current one. Since the

task orders are not fixed, any subset of the tasks can

be possibly carried out before some task. Note that

the output of each task is examined and corrected by

the user, which corresponds to the user feedback that

is propagated to subsequent prediction tasks.

Given a large collection of archived documents,

we want to learn an ordering of the tasks so that the

overall utility of the system is maximized through

efficient propagation of user feedback. However, the

order in which the fields in these documents were

filled by the authors was not recorded. Therefore,

from such a data collection, we cannot directly

ascertain which task orders are more preferred, in

terms of a given utility function. We must develop a

new way for learning the optimal task order, as

described below.

3 LEARNING TO ORDER

We want to formulate the problem in a way that

good ordering of tasks can be automatically learned

from the data. For this, we split the dataset into three

subsets, and call them the task-training set, the

order-training set and the test set, respectively. We

use the task-training set to learn task-specific

models for each task. We use the order-training set

to empirically find the best ordering of the

prediction tasks. We use the test set to evaluate the

utility of the system in performing multiple tasks in

the optimal order, as determined by each of the

ordering methods, for cross-method comparison. We

restrict our attention to classification tasks in the rest

of the paper. However, the proposed task ordering

method, which is the main focus of this paper,

applies to any type of prediction tasks in general.

In the next section, we consider a naïve

approach, which gives the exact solution to the

problem but is computationally intractable. In

Section 3.2, we propose a relaxation of the objective

function in terms of partial order preferences among

prediction tasks. In Section 3.3, we demonstrate a

novel application of link analysis algorithms to find

an approximately optimal task order based on a

graph-theoretic representation of pair-wise

preferences.

3.1 A Naïve Approach

Let n be the number of training instances (e.g., IT

proposals), and m be the number of tasks per

instance. Assume that all the task-specific models,

i.e. classifiers, are already pre-trained, and the utility

metric is pre-specified as well.

Given a specific order, i.e., a sequence of m

tasks, its expected utility on all possible instances

can be empirically estimated by running the task-

specific models in the specified order on each of the

training instances, and using human-assigned labels

to evaluate the utility of the system-made

predictions. Comparing the average utility scores of

all possible orders, we can find the best order.

However, this approach is computationally

intractable because the number of possible

permutations of tasks is m!, leading to a time

complexity of O(m!n).

3.2 Partial-order Preferences

A natural choice is to relax the objective as follows:

find the sequence that best satisfies pair-wise partial-

order preferences among the tasks. In other words,

we want the sequence that maximizes the sum of the

GRAPH STRUCTURE LEARNING FOR TASK ORDERING

165

partial-order preference scores for all the pairs in

the sequence. By “partial order preference” we mean

that task i should be carried out before task j but the

two tasks do not need to be adjacent in the sequence.

We can empirically estimate the expected benefit, or

the “preference score”, for each task pair by

calculating the utility scores for a large number of

randomized orders of M tasks conditioned on “i

before j” and “i after j”, respectively. We define the

preference score of pair

),( ji

as the difference

between the mean utility under the first condition

and the mean utility under the second condition.

Since the number of task pairs is

m , the partial-

order utility estimation is computationally tractable

for a moderate m.

However, no efficient algorithm is known for

deriving the optimal order based on the partial-order

preference scores. In fact, this problem is exactly

equivalent to the Linear Ordering Problem (LOP) 0,

which is known to be NP-hard. Nevertheless, this

problem formulation opens an opportunity for us to

solve the problem heuristically with link structure

analysis over the task dependence network.

3.3 A Novel Application of Link

Structure Analysis

The pair-wise partial-order preferences over tasks

can be represented using a fully connected directed

graph that we call the partial-order-preference

network, or POPNET for short. The nodes represent

tasks. A directed edge from node i to node j

represents the preference (in terms of difference in

utility scores) for ordering task j before task i. If it is

more preferable to order task j before task i, then the

directed edge from node i to node j will have a

positive weight, and the edge from node j to node i

will have a corresponding negative weight of equal

magnitude. We do this for every pair of nodes to

derive a fully connected graph, which can be

interpreted as a dependence network – a positive

edge from node i to node j means that task i depends

on task j, in the sense that we expect higher utility

by ordering task j before task i. Intuitively, this

means that our goal is to place those tasks earlier in

the global order, that many other tasks depend on.

This intuition enables us to leverage standard

link analysis algorithms for heuristically ordering

the tasks. Recall that in conventional link structure

methods like HITS, a good “authority” is defined as

a node with in-links from many good hubs, and a

good “hub” is defined as a node with out-links

pointing to many good authorities 0. Applying this

concept to our problem, a good authority

corresponds to a task that meets the partial-order

preferences simultaneously for multiple task pairs if

it is carried out earlier. Intuitively, the authority

scores computed from POPNET are good heuristics

for task ordering. Moreover, the authority scores

also imply the transitivity of partial-order

preferences, i.e., if task A is more preferable than

task B for earlier placement, and if task B is more

preferable than task C, then task A is more

preferable than task C.

Similarly, we can also apply the PageRank

algorithm 0 to the POPNET matrix, so that

“popular” nodes (i.e., nodes with high PageRank)

will correspond to those nodes that many other

nodes in the graph link to, and hence correspond to

tasks that many other tasks depend on. On the other

hand, nodes that are not dependencies of other nodes

will receive a low PageRank and end up towards the

later part of the total order. This makes intuitive

sense since these nodes correspond to tasks that are

less crucial towards successfully solving other tasks.

Note that due to the special semantics of the

ordering problem, the adjacency matrix (say, P) of

the POPNET graph is skew symmetric i.e. P

= –P.

This special structure is different from the structure

of Web graph, where link analysis algorithms are

conventionally applied 00. It is easy to show that for

a skew symmetric adjacency matrix, the hub score

and authority score of each node are identical (since

−

Table 1: Meta data fields of documents.

Keywords,

ItemType,

IndustryKeywords,

TechnologyKeywords,

VendorProductKeywords, BusinessFunctionKeywords,

TopicTags,

Creator,

Submitter,

Modifier,

Alliances,

Offerings,

Client,

PertinentToOrgUnit,

PertinentToServiceLine, PertinentToDomainSpecialty,

PertinentToWorkgroup,

PertinentToCountry

To summarize, our solution for task ordering

consists of two steps: first, use a training set to

estimate the pair-wise partial-order preferences

(Section 3), and second, apply link analysis to

POPNET for task ordering. In the second step, we

can use either HITS or PageRank as two alternative

algorithms. We name these variants of our approach

as POP.HITS and POP.PAGERANK, respectively.

ICEIS 2009 - International Conference on Enterprise Information Systems

166

The time complexity of the first step is

)(

kmO where k is the number of randomized

sequences of size

m for each task pair in the

calculation of partial-order preferences. The time

complexity of the second step is

)(

mO with a

conventional Subspace Iteration algorithm to

compute the first eigenvectors in the HITS or

PageRank method.

4 DATASETS

We collected a set of 33,000 business proposals

(“documents”) from Accenture, a large consulting

organization. Each of the documents is associated

with a list of 18 metadata fields, as shown in Table

The number of tasks for our dataset is 18, which

is relatively small compared to the number of tasks

that might arise in some other potential applications,

e.g. diagnostic tests in the medical domain, or

potentially hundreds of tests for troubleshooting

complex aircraft failures. Solving the NP-hard LOP

problem has an exponential time complexity, which

may not be tractable for the large number of tasks;

heuristic approaches using HITS or PageRank

provide alternative solutions for scalability.

Nevertheless, the relatively small number of tasks in

the Accenture dataset enables us to compute the

LOP optimal solution, and to compare its

performance with that of using HITS, PageRank and

other baseline methods in a controlled setting.

Evaluations using datasets with larger numbers of

tasks requires substantial development of those

benchmark datasets, which is beyond the scope of

this paper.

5 EXPERIMENTS

We conducted a comparative evaluation of the two

approaches proposed in this paper – namely

POP.HITS, and POP.PAGERANK. We further

compare these approaches against three baselines –

(i) RANDOM: The average performance of using

arbitrary orders, (ii) EXPERT: A task order

proposed by a team of domain experts, and (iii)

LOP: An exact solution to the LOP problem. We use

an off-the-shelf state of the art exact solver as

described in 0, that uses a branch and bound search

with several heuristics to speed up the search for the

best order. Nevertheless, while matrices up to 20x20

take less than 5 seconds to solve, a 35x35 matrix

takes more than 10 minutes, due to a time

complexity that depends on the factorial of the size

of the matrix. The output of each of these methods is

an order in which the task of filling each field should

be performed, aiming to maximize the utility of all

systems in the process and hence minimizing human

effort. Therefore, comparing these methods amounts

to comparing the overall accuracy of the predictions

made by the classifiers used in the corresponding

filling order.

5.1 Experimental Setting

We used 33,000 structured documents which is a

subset of the Accenture data (cf. Section 4), and

divided them into three non-overlapping parts as

described in Section 3 – task-training set (12,000

documents), order-training set (3,000 documents),

and test set (18,000 documents).

Using the task-training set, we trained an SVM

classifier for each of the meta-data fields – i.e., one

field at a time was chosen as the target for

prediction, and the rest of the fields were used as the

source or predictor variables. We pick SVM

classifiers for each task, which have been reported as

competitive performers on a variety of domains 0.

Next, the fields of the documents in the order-

training set were randomly permuted and the

classifiers trained in the previous step were used to

make predictions on the fields in these random

orders. Note that we can use multiple permutations

of fields for each document to derive a better

estimate of the pair-wise preferences, limited only

by computational resources. In this paper, we limit

ourselves to one permutation per document. The

performance statistics of the classifiers were then

used to populate the POPNET matrix. Finally, the

optimal order derived in the previous step was used

to determine the order in which predictions would be

made for the fields of all documents in the test set.

The overall performance of the classifiers was then

measured on the Test set.

5.2 Performance Measures

We evaluated the performance of the proposed and

the baseline methods using the F1 metric, which is

the harmonic mean of recall (fraction of relevant

items retrieved) and precision (fraction of retrieved

items that are relevant) 0. Higher F1 values signify

better performance, and are attained only when both

recall and precision are high, thus providing a

reliable summary of classification performance.

To measure effectiveness across a wide range of

categories that may appear with different

GRAPH STRUCTURE LEARNING FOR TASK ORDERING

167

frequencies in the dataset, we report micro-averaged

F1 as well as macro-averaged F1. Micro-averaging

gives equal weight to each individual prediction, and

hence, is dominated by categories with a large

number of documents. On the other hand, macro-

averaging gives equal weight to each category, and

hence, may be useful in highlighting the

performance on rare categories 0.

5.3 Results

Table 2 shows the performance obtained using

different task ordering approaches. We run each

method (except EXPERT) ten times to estimate the

mean and the standard error of the performance in

terms of micro-averaged and macro-averaged F1.

For each pair of methods, we conducted a sign test

(with n = total number of binary decisions on which

the two methods in the pair differed, for each field of

each document in the test set). The differences

among the performance of EXPERT, LOP,

POP.HITS, and POP.PAGERANK are statistically

insignificant, whereas the improvement of any of

these methods over the RANDOM baseline is highly

statistically significant (p-value << 1%).

Table 2: Comparison of task ordering approaches (mean ±

s.e.).

Method

Micro

averaged F1

Macro

averaged F1

RANDO

0.5261 ± 0.0002 0.3294 ± 0.0015

EXPERT 0.6005 ± 0.0000 0.4216 ± 0.0000

LOP 0.5991 ± 0.0009 0.4175 ± 0.0007

POP.

HITS

0.5943 ± 0.0000 0.4198 ± 0.0000

POP.

PAGERANK

0.5927 ± 0.0050 0.4140 ± 0.0015

POP.HITS beats RANDOM by a substantial

margin – 27% in terms of macro F1 and 13% in

terms of micro F1. Hence, our approach provides an

effective way of choosing an optimal order in the

absence of any domain knowledge as well as

understanding of the prediction systems, in which

case, the user may be forced to choose an arbitrary

(random) task order. Given that the space of possible

permutations grows at a factorial rate with respect to

the number of tasks, it is unlikely that such an

arbitrary order would perform well on average.

POP.HITS provides competitive performance

against the EXPERT order, with the difference being

statistically insignificant. Note that the EXPERT

order requires domain knowledge and sufficient

understanding of the sequence of tasks and their

dependencies. Such expertise might not be readily

available. Our proposed approach automatically

infers such task dependencies and suggests a task

order that performs close enough to the order that

would be proposed by a panel of experts.

The differences in the performance of the link

analysis based approaches (POP.HITS and

POP.PAGERANK) and the exact LOP solution are

also statistically insignificant. While LOP is known

to be an NP-hard problem, making it not scalable to

applications with a large number of tasks, the

proposed approaches provide a computationally

efficient alternative through the use of HITS and

PageRank, which have been successfully applied to

Web-scale problems.

An interesting observation is that – on the one

hand, the domain experts have sufficient knowledge

of the tasks, but they may not understand the

behavior and dynamics of various prediction

systems – i.e., how the systems combine various

features to make a sequence of predictions. This

might lead to suboptimal task orders that do not take

into account the complex interactions of system

predictions. On the other hand, our proposed

approach lacks any domain knowledge whatsoever,

but it can observe the empirical behavior of systems

(i.e., any choice of retrieval or classification

systems) on the given set of tasks, to suggest a near-

optimal order. How to combine the knowledge of

domain experts and the statistical prowess of the

proposed method is an interesting topic for future

exploration.

6 DISCUSSIONS

The importance of research on IR in context has

been realized in recent years 0. Users rarely perform

IR tasks in isolation; instead, studies show that an

overall information-seeking task often involves a

multitasking search session comprising of a

sequence of related searches, affected by various

contextual factors like time, place, and user feedback

0. However, thorough investigations in leveraging

context are relatively sparse so far. Yang et al.

investigated how to improve information distillation

tasks (retrieval, adaptive filtering and novelty

detection) by leveraging the history of user

interactions as the context 0. In this paper, we

approach the problem of IR in context from a

different angle, i.e., how to improve the total utility

of multiple systems in a multi-step process with user

ICEIS 2009 - International Conference on Enterprise Information Systems

168

interactions, specifically, by offering a novel

solution to the problem of optimally ordering a set of

interrelated prediction tasks.

The partial-order preferences part of our

formulation for the task ordering problem relates our

work to Cohen et al. 0, who used a similar pair-wise

preference formulation for the problem of ranking

Web pages when user feedback is available in the

form of pair-wise preferences. However, their main

focus was on finding a good linear combination of

preference functions. The problem of finding the

optimal total order was addressed using a simple

greedy algorithm, which provides an approximate

solution within a factor of two of the optimal order.

It is noteworthy that our solution for the problem

goes beyond other approximation algorithms for

LOP. That is, the link-analysis based approach for

heuristically optimizing the task order enables us to

leverage the transitivity of partial-order preferences,

which is not a property of other algorithmic

approximations for LOP. By modelling such

transitive relations explicitly, we hope to make our

method more robust against noisy or insufficient

data by estimating all pair-wise preferences more

reliably through the use of the transitivity. It is

possible to combine the strength of our current

method with those of other approximation

algorithms for LOP, which is an interesting topic for

future research.

In our proposed approach, the pair-wise task

order preferences are empirically estimated by

directly observing the performance of the classifiers

with respect to different task orders. This has the

benefit of allowing direct optimization of arbitrary

performance metrics, for instance, domain-specific

utility metrics that assign different costs to each

prediction task. It would be interesting to experiment

with different choices of the metric used to populate

the partial order matrix and the metric used to

evaluate the system, and assessing the effect of

matching vs. mismatching the two choices.

7 CONCLUSIONS

This paper examines the task ordering problem for

prediction systems in a multi-step process. We

propose a formulation of the problem in terms of

pair-wise preferences of task orders that are learned

in a supervised fashion and represented using

directed graphs. Such a formulation naturally lends

itself to the application of link analysis approaches

like HITS and PageRank, which provide reasonable

heuristics for optimizing the overall utility of a

sequence of prediction tasks, and more importantly,

enable efficient computation of optimal sequence for

applications with a large number of tasks.

Experiments on a real collection of structured

documents provide promising empirical evidence for

the effectiveness of the proposed methods: the

performance in terms of macro and micro F1 of the

classifiers improved by 27% and 13%, respectively,

over the performance of random ordering, and was

statistically indistinguishable from the performance

obtained when using an expert-suggested ordering of

the tasks.

REFERENCES

Brin, S. and Page, L. The anatomy of a large-scale

hypertextual Web search engine. Proceedings of the

7th World-Wide Web Conference, (1998)

Caruana, R. and Niculescu-Mizil, A. An empirical

comparison of supervised learning algorithms.

Proceedings of the 23rd international conference on

Machine learning (2006)

Charon, I. and Hudry, O. A branch-and-bound algorithm

to solve the linear ordering problem for weighted

tournaments. Discrete Applied Mathematics (2006)

Cohen, W.W. and Schapire, R.E. and Singer, Y. Learning

to order things. Journal of Artificial Intelligence

Research (1999)

Ingwersen, P. and Jarvelin, K. Information retrieval in

context: IRiX. ACM SIGIR Forum (2005)

Joachims, T. Text categorization with support vector

machines: Learning with many relevant features.

Proceedings of ECML-98, 10th European Conference

on Machine Learning (1998)

Kleinberg, J. Authoritative sources in a hyperlinked

environment. ACM-SIAM Symposium on Discrete

Algorithms, (1998)

Lewis, L. Evaluating Text Categorization, Proceedings of

Speech and Natural Language Processing Workshop

(1991)

Ozmutlu, S. and Ozmutlu, H.C. and Spink, A.

Multitasking Web searching and implications for

design. Proceedings of the American Society for

Information Science and Technology (2003)

Reinelt G. The Linear Ordering Problem: Algorithms and

Applications. Research and Exposition in

Mathematics, (1985)

Rijsbergen, C.J. Information Retrieval. Butterworths

(1979)

Yang, Y. and Lad, A. and Lao, N. and Harpale, A. and

Kisiel, B. and Rogati, M. Utility-based information

distillation over temporally sequenced documents.

Proceedings of the 30th annual international ACM

SIGIR conference on Research and development in

information retrieval (2007)

GRAPH STRUCTURE LEARNING FOR TASK ORDERING

169
