AN EXTENSION OF ONTOLOGY BASED DATABASES TO HANDLE

PREFERENCES

Dilek Tapucu

1,3

, Yamine Ait-Ameur

, St´ephane Jean

and Murat Osman

Unalir

LISI/ENSMA and University of Poitiers, BP 40109, 86961 Futuroscope Cedex, France

Department of Computer Engineering, Ege University, 35100 Bornova,

Izmir, Turkey

Department of Computer Engineering, Izmir Institute of Technology, 35340 Urla,

Izmir, Turkey

Keywords:

User preferences, Ontology based database, Preference based querying.

Abstract:

Ontologies have been deﬁned to make explicit the semantics of data. With the emergence of the SemanticWeb,

the amount of ontological data (or instances) available has increased. To manage such data, Ontology Based

DataBases (OBDBs), that store ontologies and their instance data in the same repository have been proposed.

These databases are associated with exploitation languages supporting description, querying, etc. on both

ontologies and data. However, usually queries return a big amount of data that may be sorted in order to ﬁnd

the relevant ones. Moreover, in the current, few approaches considering user preferences when querying have

been developed. Yet this problem is fundamental for many applications especially in the e-commerce domain.

In this paper, we ﬁrst propose an extension of an existing OBDB, called OntoDB through extension of their

ontology model in order to support semantic description of preferences. Secondly, an extension of an ontology

based query language, called OntoQL deﬁned on OntoDB for querying ontological data with preferences is

presented. Finally, an implementation of the proposed extensions are described.

1 INTRODUCTION

Nowadays, ontologies are well accepted to describe

the explicit semantics of concepts and objects ma-

nipulated in a given domain. Domain ontologies are

used to provide with deﬁnitions and speciﬁcations of

these manipulated concepts. Several application do-

mains have seen the emergence of ontologies in or-

der to characterise the universe where these mod-

els act. Among these application domains, seman-

tic web, databases,ontology engineering are the most

well known. Ontologies are described according to

ontology models. These models introduce the notion

of classes and instances, and a signiﬁcant amount of

classes and instances are deﬁned when ontologies are

described. Storing, retrieving and manipulating on-

tology classes and instances is a major requirement of

Ontology engineering. In the last decade, the notion

of ontology based database (OBDB) has been devel-

oped (Dehainsala et al., 2007; Pierra et al., 2005) in

order to offer an infrastructure allowing management

of ontologies and their instances (Chong et al., 2005;

Petrini and Risch, 2007). At least these models store

the ontology and its instances, but some of them also

store the ontology model and extensively use meta

modeling techniques. However, the currently deﬁned

OBDB do not deal with the representation of the non

functional aspects related to the ontology models. By

non functional aspects, we mean concepts that are

capable to describe externally deﬁned properties like

quality, preferences or security. Indeed, most of the

well known ontology models like Owl, Plib, etc. do

not provide with such resources to represent such con-

cepts. Each time non functional concepts are intro-

duced, ad hoc concepts or extensions are introduced

in the ontology models like Owl, Plib, etc. or spe-

ciﬁc attributes like note or remark or a particular prop-

erty are used to encode these non functional aspects.

Rather than extending a speciﬁc ontology model, our

proposal consists in introducing a side model to de-

scribe the non functional concepts together with the

ontology model inside an OBDB. The advantage of

this approach is the possibility to adopt non func-

tional descriptions to any ontology model keeping its

deﬁnition unchanged. We particularly study the no-

tion of preference in this context. Technically, this

208

Tapucu D., Ait-Ameur Y., Jean S. and Osman Ünalir M. (2009).

AN EXTENSION OF ONTOLOGY BASED DATABASES TO HANDLE PREFERENCES.

In Proceedings of the 11th International Conference on Enterprise Information Systems - Databases and Information Systems Integration, pages

208-213

DOI: 10.5220/0002010102080213

 SciTePress

extension is possible only if the meta-model allows

to describe the ontology model can be manipulated.

Indeed, such an extension requires to be able to at-

tach ontology model elements to the non functional

model element. In our work, with the OntoDB ontol-

ogy based database, such a manipulation is possible.

This paper describes how a preference model can

be attached to an ontology model through the manip-

ulation of the meta-model level. We show how a spe-

ciﬁc preference model is linked to the concept of class

or property of the ontology model. Section 2 is an

overview of the material set up in this paper. Section

3 presents the preference model that we have deﬁned,

shows how preferences are linked to ontological con-

cepts like classes and/or properties. Handling these

preferences in the OntoDB ontology based database

is presented in section 4. Section 5 sets up the ap-

proach on a case study and ﬁnally a conclusion and

some perspectives are presented.

2 STATE OF THE ART

This section presents the material needed to set

our approach. We ﬁrst present the ontology based

database that support the description of an ontology

together with its instances. The second part presents

the approaches that have been proposed to handle

preferences in the database and semantic web areas.

2.1 Ontology Based Database

In the last years, many OBDB architectures have been

proposed. They can be classiﬁed in 3 categories ac-

cording to the number of schemas used.

Type 1 OBDBs. In type 1 OBDBs, information is

represented in a single schema composed of a unique

triple table (subject, predicate, object) (Chong et al.,

2005; Petrini and Risch, 2007; Alexaki et al., 2001;

Broekstra et al., 2002; Dehainsala et al., 2007; Pierra

et al., 2005). But this approach raises serious per-

formance issues when queries require many self-joins

over this table.

Type 2 OBDBs. Type 2 OBDBs store separately on-

tology descriptions and instance data in two differ-

ent schemas (Alexaki et al., 2001; Broekstra et al.,

2002). The schema for ontology descriptions depends

upon the ontology model used to represent ontolo-

gies (e.g., RDFS, OWL, PLIB). It is composed of ta-

bles used to store each ontology modeling primitive

such as classes, properties and subsumption relation-

ships. Separating representation of ontology descrip-

tions and instance data leads to better query response

time. However, this approach assumes a ﬁxed ontol-

ogy model.

Type 3 OBDBs. OntoDB (Dehainsala et al., 2007;

Pierra et al., 2005) proposes to add another schema

to type 2 OBDBs. This schema called meta-schema

records the ontology model into a reﬂexive meta

model. For the ontology schema, the meta-schema

plays the same role as the one played by the sys-

tem catalog in traditional databases. Indeed, meta-

schema may allow: (1) generic access to the ontology,

(2) support of evolution of the used ontology model,

and (3) storage of different ontology models (OWL,

DAML+OIL, PLIB, etc.). Next, we will present the

OntoDB ontological database which we interpreted to

extend to handle preferences.

2.2 The OntoDB: Ontology based

Database

In order to set up our approach, is needed to have

an infrastructure allowing to encoding ontologies and

the deﬁned preference model together with a manip-

ulation language for exploiting the extension to pref-

erences. For our work, the OntoDB ontology based

database and the OntoQL language have been chosen.

OntoDB ensures models and their instances persis-

tency, whereas OntoQL allows to manage and query

ontologies and preferences.

The OntoDB Architecture. The OntoDB architec-

ture is composed of four parts presented on Figure 1:

-The meta-base part (1). The meta-base (catalog sys-

tem), is a traditional part of databases. It contains sys-

tem tables used to manage all the data contained in

the database. In OntoDB, it contains in particular the

description of all tables and columns deﬁned in the

three other parts of this architecture.

-The data part (3). It represents domain objects de-

scribed by ontology classes membership and values of

properties deﬁned on these classes. These objects are

represented according to the table per class approach.

-The ontology part (4). It contains ontologies deﬁn-

ing semantics of the various domains covered by

the database. OntoDB supports the PLIB ontology

model.

-The meta-schema part (2). The meta-schema part

records the ontology model used into a reﬂexivemeta-

model. For the ontology part, the meta-schema part

plays the same role as the one played by the meta-

base in traditional databases.

The OntoQL Exploitation Language The OntoQL

exploitation language has been designed to exploit the

power offered by the OntoDB architecture (Jean et al.,

2006). Indeed, OntoQL is capable to access and ma-

nipulate the model, its instances and its meta-model.

AN EXTENSION OF ONTOLOGY BASED DATABASES TO HANDLE PREFERENCES

209

Figure 1: The OntoDB four parts architecture.

For example, when an ontology is stored, OntoQL is

capable to manage the ontology (e.g. Hotels, Cities,

Prices, rate), itself, its instances (e.g. Ibis Poitiers,

hotel, Sheraton Paris) and the model that describe the

ontologies (e.g. #class, #property, #datatype).

The OntoQL language is equipped with an

data deﬁnition language DDL

(CREATE, ALTER

clauses),

a data manipulation language

(INSERT

INTO, DELETE, UPDATE clauses)

and a query lan-

guage

(SELECT).

These language modules allow to

accessing either the ontology model level (by pre-

ﬁxing the accessed date with the # symbol) and the

ontology and its instances (when no preﬁx is avail-

able). For example, creating a preference concept

at the ontology model level is performed by adding

another new concetpt in the

ENTITY

meta-model

resource using the following OntoQL clause;

CREATE ENTITY #Preference ( oid int, ... );

Then, accessing and querying preferences is per-

formed by;

SELECT oid FROM Preference WHERE ...

2.3 Preferences

Several approaches handling preferences have been

proposed in various areas of information systems. In

this paper, we concentrate on the main areas semantic

Web and databases areas.

Handling preferences in databases has been the

subject of several research work (Kieling, 2002;

Agrawal and Wimmers, 2000; Viappiani et al., 2006).

These approaches consider a set of preferences that

are evaluated on the logical model of a database.

Extensions of the SQL language are deﬁned within

a speciﬁc preference clause. These approaches are

strongly linked to the logical model of the database,

and therefore it is required for an user to have a good

knowledge of this logical model.

In the context of the semantic Web, preferences

have been studied following two main approaches

(Siberski et al., 2006), (P. Gursk and Vanekov, 2008),

(Toninelli et al., 2008). The ﬁrst one consists in

introducing speciﬁc properties in the ontologies, at-

Figure 2: Our Model for Preferences.

tached to classes. The second one consists in using

speciﬁc attributes of the ontology model like note,

or deﬁnition to encode the preference. In both ap-

proaches, SPARQL queries take into account prop-

erty or attribute values. By examining preferences

on databases and semantic Web, we identify that they

both use deﬁnitions of the notion of preferences built

on manipulated models themselves. They all intro-

duce the preference notion at the model level. These

approaches are static and not ﬂexible enough to han-

dle different preference models.

3 OUR APPROACH

Our approach consists in associating any side prefer-

ence model to any ontology based database that al-

lows to manipulate the ontology model through its

meta-model. Indeed, according to Figure 2, the pref-

erence resource concept of the preference model is

associated to the class or property concepts available

in the ontology model. Let us brieﬂy describe the el-

ements composing these model and link.

3.1 Ontology Resource Deﬁnition

The property or class resource is introduced in order

to attach a preferenceto an ontology. Moreover,Prop-

erty or Class Instance resource is used to deﬁne spe-

ciﬁc instances of the ontology.

3.2 Preference Model

The preference model introduces speciﬁc resources

allowing to deﬁning preferences. Two categories of

preferences are introduced: interpreted and non inter-

preted ones.

Interpreted Preferences. Interpreted preferences are

those preferences that can be given an interpretation

ICEIS 2009 - International Conference on Enterprise Information Systems

210

by means of an evaluation. The nature of their deﬁni-

tion depends on the attached interpretation function.

a- Enumerated Preferences are interpreted by a set

of property values or class instances imported from

the ontology population. For example a preference

can be deﬁned on ”Bob Marley” as an instance of

singer and on ”reggae” as a property value of a song

type. This enumeration is arbitrary deﬁned by the

preference modeler.

b- Numeric references are interpreted by numeric val-

ues. For example, the rating of a hotel can be deﬁned

as 1, 2, 3, or 4 stars in a given tourism domain.

c- Boolean preferences are interpreted as the presence

or the absence of a given feature. For example a pref-

erence on hotels can be expressed as the presence of

the following triple (’air conditioning’, ’wiﬁ’, ’swim-

ming pool’).

d- Interval preferences are interpreted by intervals of

values. For example, the cheap and expensive prefer-

ences can be deﬁned respectively by the [10-20] and

[90-100] intervals.

e- Fuzzy preferences are interpreted by a probabil-

ity rating the presence of a given feature. If we

take the previous example, we get (’air condition-

ing’ 0,9, ’wiﬁ’ 0.5, ’swimming pool’ 0.2) meaning

that a strongest preference is allowed to air condition-

ing while having a swimming pool is weaker. Notice

that Boolean preference corresponds to a fuzzy pref-

erence with a rating value equal 1.

Uninterpreted Preferences. Uninterpreted prefer-

ences are deﬁned as an enumeration of a set of prop-

erties and classes values that are picked from an on-

tology without any constraint on the chosen values. It

corresponds to an ad hoc expressed preference.

Context based Preferences. When a preference is

deﬁned according to a context, it is possible to specify

the context in which a given preference is expressed.

For example, the ”cheap” preference is interpreted

differently if we consider the country where the pref-

erence is interpreted. Therefore, a speciﬁc attribute

is added to describe the context where a preference is

interpreted.

Ontology Preference Link. Once ontological con-

cepts, resources and preferences are deﬁned, a link

pref link, obeying to the class diagram of UML is de-

scribed. The role of this link is to attach a preference

to a given ontological concept that may be a class or

a property. This link is used to reach the preferences

attached to ontological data. The availability of a ma-

nipulation language allowing to access meta-model

data elements, concepts data elements and instances

in required. In our study, the OntoQL language is

used for this purpose.

4 Handling Preference in OntoDB

One can notice that current ontology models do not

offer the possibility to handle preferences expressed

on ontology concepts and instances. Since the On-

toDB architecture coupled with the OntoQL lan-

guage, allows to manipulate the ontology model, we

suggest to feed the ontology model with the prefer-

ence model. As a result, we will get, in the same

universe, both the ontology model and the preference

model. An explicit link between the property or class

ontology model concept and the preference model

concept is deﬁned as well.

4.1 Extension of the OntoDB with

Preferences

The extension of OntoDB to handle the preferences

consists in describing a set of

CREATE

OntoQL clauses

that create all the data elements of the UML data

model of preferences deﬁned in Figure 2. The fol-

lowing table shows the creation of the Preference

root entity, the creation of the Preference URI at-

tached to a preference and the creation of the Prefer-

ence Deﬁnition as inherited from the preference con-

cept.

CREATE ENTITY CREATE ENTITY CREATE ENTITY

#Preference( #Preference URI( #Preference

#oid int, #code int, Definition

#URI REF( #name string, UNDER

#Preference URI)); #classification #Preference(

string); #oid int);

4.2 Linking Ontologies and Preferences

at the Ontology Model Level

Once the preferences are deﬁned, they need to be

linked and attached to the ontological concept they

act on. This link, is established by the Pref link class

of the UML class diagram of the preference model

of Figure 2. The following OntoQL statements al-

lows to create such a link in the OntoDB ontology

based database. Practically, to encode composition,

the preference link is absorbed by the ontology model

concept property or class. It becomes an attribute of

the property or class ontology model element. The

following OntoQL statement is deﬁned.

ALTER ENTITY #property or class ADD ATTRIBUTE #PREF Link REF

(#Preference) ARRAY

AN EXTENSION OF ONTOLOGY BASED DATABASES TO HANDLE PREFERENCES

211

4.3 Querying with Preferences

In order to handle the preferences in the OntoQL

queries, a preference interpreter has been developed

on top of the OntoQL engine. This is materialized

by adding a

PREFERRING

clause in the OntoQL

SELECT

clause. An interpretation function is associated to

each kind of preference available in the preference

model. The form of the

SELECT

clause becomes:

SELECT ’selection’ FROM ’tableReference’ PREFERRING

’preferenceIdentifer’

5 A CASE STUDY

Let us assume that we have a customer who wants a

reservation for a Lodging Service to book an Hotel

Room. The customer submits a request to the holi-

day booking system. It includes the information about

the destination, travelling time and maximum bud-

get. The system ﬁnds the most suitable hotel based

on the information provided by the customers prefer-

ences (eg. standard, cheap).

5.1 Tourism Ontology Instantiation

The tourism ontology described by Figure 3 and the

corresponding ontology instances are deﬁned in the

OntoDB database through two families of OntoQL

statements. The ﬁrst statement consists in creating the

classes of the ontology. The next OntoQL statement

describes the creation of the Hotel.

Figure 3: Tourism Ontology Concepts.

CREATE Class Hotel ( #id int, #name String, #starRate int,

#price int, #airCond boolean, #tv boolean, #wifi boolean,

#pool boolean, #jakuzi boolean);

In order to deﬁne ontology instances, the

INSERT

INTO

OntoQL clause is used. For example, to deﬁne

the Kyriad hotel corresponding to the #51 hotel in-

stance, we deﬁne the following OntoQL statement.

INSERT INTO Hotel (id, name, starRating, price, airCond,

tv, wifi, pool, jakuzi, tennisCourt, casino)

VALUES (51, ’Kyriad ’,3,55, yes,yes,yes, no,no,no,no);

5.2 Preferences in the Tourism Domain

When addressing the tourism domain, qualities of

tourism institutions are evaluated by national or in-

ternational organizations. For our study, we restrict

the deﬁnition of such quality features to hotels. For

example, we are interested in deﬁning the :

- star rating meaning that a hotel has one, two,

etc stars in the starRating quality classiﬁcation. The

OntoQL statement that deﬁnes a three star rating is

described by:

INSERT INTO #Numeric Preference( #number value, #code,

#name, #classification) VALUES(3, 51, ’standard’,

’starRating’);

- very cheap, cheap, expensive, very expensive that

is attributed to a price in the cost quality classiﬁcation.

The following OntoQL statement describes the cheap

quality as being any number belonging to the interval

[45..60].

INSERT INTO Interval Preference( #min value, #max value,

#code, #name, #classification) VALUES(45, 60, 100, ’cheap’,

’cost’);

5.3 Attaching Preferences

When the preferences and the ontologies are deﬁned,

it is possible to link ontology classes to the prefer-

ences that are expressed on these classes. For this pur-

pose, the manipulated ontology class is augmented by

preferences thanks to the

ALTER

clause. A preference

is attached to an instance of a hotel. For example, the

preference cheap is attached to the Kyriad hotel using

the following

UPDATE

OntoQL clause. Here, we put

names for readability but identiﬁers are in fact used.

UPDATE Hotel set #pref link=ARRAY[’cheap’, ’standard’, ’full

board’] where name=’Kyriad’

name price starRating PREFERENCE(cost,quality, ...)

Kyriad 55 3 [cheap,standard,full board]

5.4 Querying Ontologies

Once the three previous steps are realized, it becomes

possible to address queries to the ontology and its in-

stances. Next, we give two examples of queries with

quality.

1- The query that gives the 3 stars hotels is written

SELECT name, starRate FROM Hotel PREFERRING ’standard’

When the

PREFERRING

clause is interpreted, the

query is automatically rewritten as follows,

SELECT name, starRate, preference From Hotel WHERE

starRate=3;

name starRate preference

Kyriad 3 standard

ICEIS 2009 - International Conference on Enterprise Information Systems

212

2- The query cheap hotels is written as,

SELECT name, price FROM hotel PREFERRING ’cheap’;

When the

PREFERRING

clause is interpreted, the

query is automatically rewritten as follows,

SELECT name, price, preference From Hotel WHERE price

BETWEEN 45 and 60;

name price preference

Kyriad 55 cheap

Notice that all the authorized construction of the

OntoQL language can be used in building the query.

The last clause is the

PREFERRING

clause. It is used for

rewriting the queries into standard OntoQL queries.

6 CONCLUSIONS

This paper has presented an extension of a database

architecture in order to handle preference modeling

and querying with preferences not at the database log-

ical model but at the semantic level offered by the on-

tology. This extension requires:

- the explicit representation of the ontology in the

database. As a consequence, we have been able to

attach the preferences to the classes and to the prop-

erties of the ontology and not to the columns of the

logical model of the database where instances or data

are stored;

- the possibility to access and to manipulate the ontol-

ogy model through the access and manipulation to the

meta-model and ﬁnally,

- the availability of an exploitation language allowing

to manipulating both the instances, their classes and

the meta-model in the case of ontologies.

These requirements are fulﬁlled by the OntoDB

ontology based database and by the OntoQL exploita-

tion language. The extension of the ontology model

with the preference model permitted to attach various

types of preferences to classes and/or properties of

the ontology. As a consequence, we have been able

to describe semantic queries that handle preferences

expressed at the semantic level, and thus abstracting

from the logical model. We believe that the possi-

bility to access the meta-model level well adapted to

deﬁne model extensions that preserve upward com-

patibility with the extended model. This work has

opened several new directions and perspectives. In-

deed, such extensions are possible for other different

domain characterizations like security, user proﬁles or

model annotations.

REFERENCES

Agrawal, R. and Wimmers, E. L. (2000). A framework for

expressing and combining preferences. In SIGMOD

Conference, pages 297–306.

Alexaki, S., Christophides, V., Karvounarakis, G., and

Tolle, K. (2001). Managing Voluminous RDF De-

scription Bases. In Proceedings of the 2nd Interna-

tional Workshop on the Semantic Web, pages 1–13.

Broekstra, J., Kampman, A., and van Harmelen, F. (2002).

Sesame: A Generic Architecture for Storing and

Querying RDF and RDF Schema. In Proceedings

of the 1st International Semantic Web Conference

(ISWC’02), pages 54–68.

Chong, E. I., Das, S., Eadon, G., and Srinivasan, J. (2005).

An Efﬁcient SQL-based RDF Querying Scheme. In

Proceedings of the 31st international conference on

Very Large Data Bases (VLDB’05), pages 1216–1227.

Dehainsala, H., Pierra, G., and Bellatreche, L. (2007). On-

toDB: An Ontology-Based Database for Data Inten-

sive Applications. In Proceedings of the 12th Interna-

tional Conference on Database Systems for Advanced

Applications (DASFAA’07), pages 497–508.

Jean, S., A¨ıt-Ameur, Y., and Pierra, G. (2006). Query-

ing Ontology Based Database Using OntoQL. In

Proceedings of On the Move to Meaningful Internet

Systems 2006:(ODBASE’06), volume 4275 of Lecture

Notes in Computer Science. Springer.

Kieling, W. (2002). Foundations of preferences in database

systems. In Mars, N. J. I., editor, Knowledge and Data

Engineering, pages 311–322. IOS Press, Amsterdam.

P. Gursk, T.Horvth, J. J. and Vanekov, V. (2008). User pref-

erence web search. experiments with a system con-

necting web and user. In To appear in the Computing

and Informatics Journal, pages 25–32.

Petrini, J. and Risch, T. (2007). Semantic Web Abridged

Relational Databases. In Proceedings of the 18th In-

ternational Conference on Database and Expert Sys-

tems Applications (DEXA’07), pages 455–459.

Pierra, G., Dehainsala, H., A¨ıt-Ameur, Y., and Bellatreche,

L. (2005). Base de Donn´ees `a Base Ontologique :

principes et mise en œuvre. Ing´enierie des Syst`emes

d’Information, 10(2):91–115.

Siberski, W., Pan, J. Z., and Thaden, U. (2006). Querying

the semantic web with preferences. In In Proceed-

ings of the 5th International Semantic Web Conference

(ISWC, pages 612–624.

Toninelli, A., Corradi, A., and Montanari, R. (2008).

Semantic-based discovery to support mobile context-

aware service access. Computer Communications,

31(5):935–949.

Viappiani, P., Faltings, B., and Pu, P. (2006). Preference-

based search using example-critiquing with sugges-

tions. Journal of Artiﬁcial Intelligence Research,

27:2006.

AN EXTENSION OF ONTOLOGY BASED DATABASES TO HANDLE PREFERENCES

213
