EFFECTS OF CRAWLING STRATEGIES ON THE

PERFORMANCE OF FOCUSED WEB CRAWLING

Ari Pirkola and Tuomas Talvensaari

University of Tampere, Department of Information Studies, Finland

Keywords: Focused crawling, Web crawling.

Abstract: Focused crawlers are programs that selectively download Web documents (pages), restricting the scope of

crawling to a specific domain or topic. We investigate different focused crawling strategies including the

use of data fusion in focused crawling. Documents in the domains of genomics and genetics were fetched by

Nalanda iVia Focused Crawler using three crawling strategies. In the first one, a text classifier was trained

to identify relevant documents. In the latter two strategies, the identification of relevant documents was

based on query-document matching. In experiments, the crawling results of the single strategies were

combined to yield fused crawling results. The experiments showed, first, that different single strategies

overlap only to a small extent, identifying mainly different relevant documents. Second, a query-based

strategy where the words of the link context were weighted gave the best coverage (i.e., number of relevant

documents) after 10 000 and 40 000 documents had been downloaded. The combination of the two query-

based strategies was the best fused strategy but it did not perform better than the best single strategy.

1 INTRODUCTION

Focused crawling (FC) refers to the process of

gathering Web documents (pages) dealing with a

specific domain or topic (Castillo, 2004; Chakrabarti

et al., 1999; Novak, 2004; Tang et al., 2005; Zhuang

et al., 2005). Depending on the purpose of focused

crawling, different methods are applied to process

the downloaded pages, e.g. they can be indexed for a

domain specific search engine or a digital library.

There are different strategies to identify relevant

documents during crawling. Two prevailing ones are

classifier-based and query-based approaches. In the

former approach relevant documents are identified

by a text classifier that is trained for the domain or

topic in question. In the latter approach

identification is based on query-document matching.

In many information processing areas data fusion

has yielded noticeable performance improvements.

The term refers to the use of techniques that

combine data from different complementary sources

(http://en.wikipedia.org/ wiki/Data_fusion). Fusion

is performed in the hope that the fused system is

more effective than the single systems separately.

Even though the use of data fusion does not

guarantee effectiveness improvements (Beitzel et al.,

2004), many studies, for example in the field of

information retrieval, have shown that data fusion

helps to improve the effectiveness of systems (e.g.

Braschler, 2004; Manmatha et al., 2001; Montague

and Aslam, 2002). Braschler (2002) applied data

fusion successfully in multilingual information

retrieval. Manmatha et al. (2001) developed an

unsupervised probabilistic method for combining

retrieval results from different retrieval systems.

They showed that the method performed as well as

the best current combination techniques. Montague

and Aslam (2002) were able to improve retrieval

results by combining document ranking functions. In

FC the use of data fusion is an unexplored area. It is

therefore interesting and important to study whether

the effectiveness of FC can be improved by

combining the crawling results obtained by different

focused crawling systems / strategies.

In this paper we investigate whether fused

focused crawling strategies produce better

performance than the component single crawling

strategies separately, and which of the single

strategies selected for testing in the study yields the

best performance. We report the first results of a

current research project investigating different

approaches to focused crawling. In crawling

experiments we used the Nalanda iVia Focused

Crawler (http://ivia.ucr.edu/), created by Chakrabarti

et al. (1999). In the system, page relevance

probabilities are computed based on a logistic

376

Pirkola A. and Talvensaari T.

EFFECTS OF CRAWLING STRATEGIES ON THE PERFORMANCE OF FOCUSED WEB CRAWLING.

DOI: 10.5220/0002037603760381

In Proceedings of the Fifth International Conference on Web Information Systems and Technologies (WEBIST 2009), page

ISBN: 978-989-8111-81-4

regression classifier. Three single strategies were

investigated in the present study: a classifier-based

approach and two query-based approaches. In the

experiments the crawling results of the single

strategies were combined to yield fused crawling

results. The performance of the fused strategies was

then compared to that of single strategies, and the

performance of the single strategies was compared

to each other. The results reported in this paper are

based on 30 different crawls in the domains of

genomics and genetics.

The rest of this paper is organized as follows.

Section 2 discusses the motivation of the study and

presents the research questions. The methodology

and data is presented in Section 3. Section 4

describes the evaluation measures. Section 5

contains the findings and Section 6 conclusions.

2 MOTIVATION AND RESEARCH

QUESTIONS

There are two main factors that decrease the

effectiveness of FC. First, FC is only capable of

finding documents that are located in the same Web

community as one or more of the seed URLs entered

into the FC program. In other words, FC can only

find documents that through some routes are linked

to at least one of the seed URLs (start URLs).

Documents outside these routes are missed. To

address this problem it is possible to use a large set

of seed URLs. However, effort costs of selecting

large seed URL sets by hand are prohibitive. If seed

URLs are selected automatically, then increasing the

number of relevant seed pages also increases the

number of irrelevant seed pages. This in turn

decreases FC effectiveness. One approach that

would be interesting to study would be the use of

very heterogeneous seed URL sets, for example

URLs from many different countries and URLs

representing different types of top level domains.

Such a seed set could guide crawling to many

different relevant routes.

Second, identification of links that point to

relevant pages or good routes is always incomplete,

and it is likely that even the most effective FC

program or strategy misses a large number of

relevant links and documents even though the

documents are located inside the same Web

community as the seed URLs. However, FC research

has still developed several methods that improve the

effectiveness of FC, such as tunneling (Bergmark et

al. 2002), reinforcement learning (Rennie and

McCallum, 1999) context graphs (Diligenti et al.,

2000), and the utilization of the hierarchical

structure of Web documents (Chakrabarti et al.

2002). Also link popularity statistics, e.g. PageRank

(Brin and Page, 1998) can be used in FC (in this

study it was not used). This paper contributes to the

issue by investigating the effectiveness of different

FC strategies. The specific research questions are as

follows:

(1) What is the degree of overlap between single

focused crawling strategies? This issue provides

background information for the two research

questions below.

(2) Which of the three single strategies examined

in the study yields the highest coverage (number) of

relevant documents?

(3) Does a fused strategy yield a better coverage

in comparison to a coverage yielded by the best

single strategy? Which combination of the three

strategies yields the highest coverage?

3 METHODS AND DATA

3.1 Crawling Program and the Three

Strategies

Next we describe the program and the three crawling

strategies. The first strategy (strategy 1 in Findings

section) was based on Nalanda’s basic features, i.e.,

unlike other strategies we did not modify the

program. For each downloaded page u, Nalanda

calculates Pr(t|u), i.e., the probability of relevance of

u to the topic t. Nalanda extracts the outlinks <u,v>

on the page, and assigns the yet-unseen page v the

same probability of relevance Pr(t|v) = Pr(t|u). The

URL of v is inserted into the URL queue with

priority Pr(t|v). The probabilities are assigned with a

logistic regression classifier that, for every topic,

was trained with positive and negative instances of

the topic in question. The same Google queries that

were used in retrieving the seed URLs (Section 3.2)

were used in acquiring the positive examples. For

each topic, about 300 on-topic pages were used in

training the classifier. The negative examples were

taken partly from a sample of “random” pages, and

partly from the positive examples of other topics.

The random pages were retrieved by querying

Google with a query generated by a random phrase

generator (http://watchout4snakes.com/

creativitytools/RandomWord/RandomPhrase.aspx).

The number of negative examples was also 300.

The pages fetched by Nalanda were indexed with

the Lemur search engine (http://www.lemurproject.

org/) that ranked the pages based on their probability

EFFECTS OF CRAWLING STRATEGIES ON THE PERFORMANCE OF FOCUSED WEB CRAWLING

377

of relevance to the entered query. The same queries

that were used in searching for seed URLs were used

to represent the topics, however they were modified

to fit Lemur’s query language. Of course, the

probabilities calculated by the classifier could have

been used to rank the pages, but Lemur was used to

provide stronger evidence. Also, Lemur was also

used in other strategies, and it is important to use

compatible probability scores when the crawling

results are combined.

The second strategy (strategy 2 in Findings

section) was based on a modified version of the

Nalanda crawler. Instead of a text classifier, the

probabilities were assigned directly using the Lemur

search engine. Specifically, the structured query

mode of Lemur was used. The topic of each crawl

was “translated” into the query language of the

search engine. The probabilities Pr(t|u) and Pr(t|v)

were determined by matching a query to the page u.

The similarity score given by the search engine was

used as the probability. Further, in the second

strategy, the context of each link <u, v> was also

used in determining Pr(t|v). The context words of

each link, meaning words that appeared no more

than 5 DOM tree nodes apart from the link, were

matched against the topic query. That is, Pr(t|v) =

Pr(t|c

), where c

is the context of the link <u,v>.

However, the context probability was used only if it

exceeded Pr(t|u). If it applied that Pr(t|c

) < Pr(t|u),

then Pr(t|v) = Pr(t|u). In this way, it was ensured that

each unseen page was assigned a minimum

probability of relevance of the linking page.

The third strategy (strategy 3 in Findings

section) differed from the second one only slightly.

In the third strategy, the words of the link context

were weighted based on their distance from the link

node. The words that appeared in the link node itself

were given the highest weights while words further

apart were given linearly decreasing weights. We

purposefully selected two nearly similar strategies

since it is interesting to observe how similar

crawling results they produce.

3.2 Test Topics and Seed URLs

In experiments we used two kinds of test topics in

the domains of genomics and genetics: specific

topics and general topics. As specific topics we used

five TREC (http://trec.nist.gov) Genomics Track

(Hersh et al., 2005) test topics from the year 2004

(the topic numbers 1, 10, 20, 30, and 40). TREC is

an annual research forum to develop and evaluate

information retrieval methods and systems.

Genomics Track focuses on genomics information

retrieval. There were also five general topics. They

were created by one of the authors who has expertise

in biology and genomics information retrieval.

Statistical information, such as term and document

frequencies and the total number of hits for a query

in the Medline database (http://www.ncbi.nlm.nih.

gov/pubmed/) are some measures to determine topic

specificity. We used the latter measure.

For seed URL retrieval, queries containing

synonyms and morphological variants of the topic

words were constructed based on the topics. The

seed URLs were retrieved by means of the Google

search engine (http://www.google.com). The first 50

seed URLs returned by Google in response to the

constructed queries were selected as a seed URL set

for each topic. The majority of the seed URLs were

of the type .com, .edu, .gov, .org, .de, and .uk.

Below are two example topics. The first one

represents a general topic and the second one a

specific topic.

Topic: Find information on hereditary diseases

Seed URL Query: hereditary (disease OR diseases)

#Medline_hits: 28 074

Topic: NEIL1. Find articles about the role of NEIL1 in

repair of DNA.

Seed URL Query: (neil1 OR "nei endonuclease" OR

flj22402 OR fpg1 OR nei1 OR hfpg1) dna (repair OR

lesion OR lesions)

#Medline_hits: 54

There were 10 topics, and accordingly 10 seed

URL sets, each containing 50 URLs. In all, 30

crawls were performed (three strategies x 10 topics).

Crawling was stopped after 40 000 documents had

been downloaded. So each result list contained

40 000 documents. Due to the rapid change of the

Web all crawls were performed within a time period

of two weeks, i.e., there was no great space of time

between the crawls.

4 EVALUATION

In Section 2 we defined the three research questions.

In this section we describe the evaluation measures

for the research questions.

Overlap was measured using the measure of

overlap rate. It refers to the percentage of identical

URLs downloaded for each pair of single strategies

and for all three strategies. Overlap shows the degree

to which different single strategies find the same

pages. We expect the overlap rates not to be very

high because small differences may accumulate to

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

378

large differences during crawling. This may hold

also for the two query-document matching strategies

examined in this study that do not differ much from

each other.

Coverage was measured using the measure of

coverage rate after N downloaded documents. It

refers to the number of downloaded documents

above the selected relevance threshold (see below)

after N documents (=10 000 and 40 000) have been

downloaded. The sooner relevant documents are

downloaded during the crawling process, the better

and more efficient the crawling system / method is

(Baeza-Yates et al., 2005). We compare the

coverage of each single strategy to each other and

against that of each fused strategy, i.e., coverage

rates of strategies 1, 2, and 3 are compared to each

other and to those of strategies 1+2, 1+3, 2+3, and

1+2+3. We are interested in the following question:

When an equal number of documents have been

downloaded for two strategies which one of these

has been fetched more probably relevant documents

(i.e., documents with probabilities above the selected

threshold). In all comparison situations coverage

was calculated after 10 000 and 40 000 documents

were downloaded. In the case of fused strategies the

result lists of the two / three single strategies were

combined by taking from each list the first 5000 /

3333 (3334) documents (=10 000 in total), and the

first 20 000 / 13 333 (13 334) documents (=40 000

in total). In this manner we can directly compare the

coverage rates of different strategies.

We took samples of documents at different

positions of the ranked crawling result lists, assessed

the relevance of the sample documents, and selected

a reasonable probability threshold on the basis of the

assessment. In this manner we were able to anchor

the probabilities to the actual relevance of the

documents. Documents above the selected threshold

were taken for the evaluation of the crawling results.

The selected probability threshold was prob. > 0.45.

The probability scores of the Lemur search engine

are in the range of 0.4 – 1.0 where 0.4 is zero

probability; scores > 0.6 do no appear very often. On

average 84% of documents above the threshold of

0.45 were relevant. This figure is based on the

assessment of 450 documents and it represents all 10

topics (45 documents per topic) and both high and

low rank document positions in the result lists of

prob. > 0.45. The relevance of documents was

evaluated by one of the authors who has expertise in

biology and genomics information retrieval (this is

the reason why genomics and genetics were selected

as test domains). Documents that discussed the

topic, contained facts about the topic (e.g. database

entries and Web forms), or contained relevant

literature references were considered relevant.

5 FINDINGS

Table 1 reports the overlap results. The results are

categorized based on the topic type. As described

before, strategy 1 refers to the classifier-based

crawling, strategy 2 to the first query-based and

strategy 3 to the second query-based crawling. In

each case the first column shows the absolute

number of downloaded pages for a strategy pair / the

three strategies, and the second column shows the

overlap percentages. For example, crawling based

on the strategies 1 and 2 gave 797 documents for the

general topics. Of these pages 7.1% shared the same

URL.

As can be seen from Table 1, in all cases overlap

rates are low. In all but one case the figures are less

than 10%. The two query-based strategies have the

highest overlap rates: 9.4% and 13.6%. However,

even these figures are low. It should be noted that

the query-based strategies were very similar: The

only difference was whether or not the context

words of links were weighted. Overall, the results

show that different FC strategies overlap only to a

small extent, identifying mainly different relevant

documents.

Table 2 and Figure 1 report the coverage results.

Table 2 shows the number of probably relevant

documents for 10 000 documents and Figure 1 for

40 000 documents. In Table 2 the highest figures are

highlighted in a bold font. As can be seen, the

second query-based strategy, i.e., strategy 3, and the

combination of the two query-based strategies (2+3)

are the best strategies, and they perform almost

equally well. The fused strategy performs slightly

better in the case of general topics whereas in the

case of specific topics strategy 3 provides a slightly

higher coverage. After 10 000 documents had been

downloaded crawling based on the combination of

strategies 2 and 3 yielded 7163 documents, and

strategy 3 yielded 6944 documents. In the case of

40 000 documents strategy 3 outperforms the fused

strategy of 2+3 (Figure 1).

Strategy 1 (classifier-based approach) does not

perform well. This is probably due to the fact that it

is often difficult to adequately model the off-topic

class, which can impair the performance of the

classifier. It is often easier to present the topic as a

query than to train a classifier, especially in narrow,

easily defined topics. Effectiveness and

implementability were the primary reasons for

investigating the query-based strategies in this study.

EFFECTS OF CRAWLING STRATEGIES ON THE PERFORMANCE OF FOCUSED WEB CRAWLING

379

Table 1: Overlap rates (%) between the single strategies. Probability threshold 0.45.

Topic type

1+2

1+3

2+3

1+2+3

General 797 7.1 787 6.1 2028 9.4 677 3.0

Specific 421 4.5 455 4.0 2649 13.6 376 1.9

Table 2: Coverage (=number of documents with prob > 0.45) after 10 000 downloaded documents.

Topic type 1 2 3 1+2 1+3 2+3 1+2+3

General

1057 3637 3695 2784 2786 3924 3117

Specific

561 2815 3249 2063 2031 3239 2686

All

1618 6452 6944 4847 4817 7163 5803

Coverage after 40 000 downloaded documents. General

and specific topics

5000

10000

15000

20000

25000

1 2 3 1+2 1+3 2+3 1+2+3

Strategy

#documents

Figure 1: Coverage for 40 000 documents.

6 CONCLUSIONS

In this paper we reported the first results of a current

research project on different approaches to focused

Web crawling. The results showed that the

combination of the two query-based strategies was

the best fused strategy but it did not perform better

than the best single strategy, i.e., a query-based

approach where the words of the link context were

weighted. Comparing the results of this study to

those in the literature is difficult due to many

different evaluation measures and definitions of

page relevance in the field of focused crawling.

Srinivasan et al. (2005) also discuss this problem

and point out that this is typical of a field that is still

in its most creative phase.

There are not many studies that have compared

different crawlers / strategies. Perhaps the most

comprehensive work is that of Srinivasan et al.

(2005). The researchers developed a general

framework to evaluate focused (topical) crawlers,

and used it to evaluate four off-the-shelf crawlers:

BreadthFirst (a simple strategy for crawling); BSF1

and BSF256 that are variations of best-first search;

InfoSpiders where the identification of relevant links

is based on keyword vectors and neural nets. The

study showed that BSF1 and BSF256 yielded the

best performance for 4000-page crawls. For a long

crawl (50 000 pages) InfoSpiders performed best.

There are many other FC strategies / approaches

than those investigated in this paper. For example, in

the Context Graph approach (Diligenti et al., 2000) a

graph of several layers deep is constructed for each

page and the distance of the page to the target pages

is computed. The context graphs are used to train a

classifier with features of the paths that lead to

WEBIST 2009 - 5th International Conference on Web Information Systems and Technologies

380

relevant pages. We are presently investigating the

issues presented in this paper more extensively. In

addition to new strategies, we consider the effects of

a search engine used to rank the pages and seed

URL sets on crawling performance. One aim of this

study is to find an effective strategy for multilingual

focused crawling (Pirkola and Talvensaari, 2009).

ACKNOWLEDGEMENTS

This study was funded by the Academy of Finland

(research projects 125679 and 129835).

REFERENCES

Baeza-Yates, R., Castillo, C., Marin, M. and Rodriguez,

A., 2005. Crawling a country: better strategies than

breadth-first for web page ordering. Proc. of the 14th

International conference on World Wide Web /

Industrial and Practical Experience Track, Chiba,

Japan, pp.864-872.

Beitzel, S., Jensen, E., Chowdhury, A, Grossman, D.,

Frieder, O. and Goharian. N., 2004. Fusion of effective

retrieval strategies in the same information retrieval

system. Journal of the American Society for

Information Science and Technology, 55(10): 859-868.

Bergmark, D., Lagoze, C. and Sbityakov, A., 2002.

Focused crawls, tunneling, and digital libraries. Proc.

of the 6th European Conference on Research and

Advanced Technology for Digital Libraries, Rome,

Italy, September 16-18, pp. 91 – 106.

Braschler, M., 2004. Combination approaches for

multilingual text retrieval. Information Retrieval, 7 (1-

2): 183-204.

Brin, S. and Page, L., 1998. The anatomy of a large-scale

hypertextual Web search engine. Computer Networks

and ISDN Systems, 30(1-7): 107-117.

Castillo, C., 2004. Effective Web crawling. Ph.D. Thesis.

University of Chile, Department of Computer Science,

180 pages. http://www.chato.cl/534/article-63160.html

Chakrabarti, S., van den Berg, M. and Dom, B., 1999.

Focused crawling: a new approach to topic-specific

Web resource discovery. Proc. of the Eighth

International World Wide Web Conference, Toronto,

May 11 - 14.

Chakrabarti, S., Punera, K. and Subramanyam, M., 2002.

Accelerated focused crawling through online

relevance feedback. Proc. of the 11th International

Conference on World Wide Web, Honolulu, Hawaii,

May 7 - 11, pp. 148-159.

Diligenti, M., Coetzee, F. .M., Lawrence, S., Giles, C.L.

and Gori, M., 2000. Focused crawling using context

graphs. Proc. of the 26th International Conference on

Very Large Databases (VLDB), pp. 527-534.

Hersh, W. R., Bhuptiraju, R. T., Ross, L., Johnson, P.,

Cohen, A. M. and Kraemer, D. F., 2005. TREC 2004

genomics track overview. Proceedings of the

Thirteenth TExt REtrieval conference (TREC-13)

(Gaithersburg, MD). http://trec.nist.gov/pubs/

trec13/t13_proceedings.html

Manmatha, R., Feng, F. and Rath, T., 2001. Using models

of score distributions in information retrieval. Proc. of

the 27th ACM SIGIR Conference on Research and

Development in Information Retrieval, New Orleans,

Louisiana.

Montague, M. and Aslam, J. 2002: Condorcet fusion for

improved retrieval. Proc. of the Eleventh International

Conference on Information and Knowledge

Management, McLean, VA, November 4-9, pp. 538-

548.

Novak, B., 2004. A Survey of focused Web crawling

algorithms. Proc. of SIKDD 2004 at Muticonference

IS, Ljubljana, Slovenia, October 12-15, pp. 55–58.

Pirkola, A. and Talvensaari, T. 2009. Developing a system

for multilingual focused crawling. Submitted to

WWW’2009 - 18

International World Wide Web

Conference, Madrid, Spain, April 29-24, 2009. Poster

manuscript.

Rennie, J. and McCallum, A., 1999.Using reinforcement

learning to spider the web efficiently. Proc. of the

Sixteenth International Conference on Machine

Learning (ICML).

Srinivasan, P., Menczer, F., Pant, G. 2005. A general

evaluation framework for topical crawlers.

Information Retrieval, 8(3): 417-447.

Tang, T., Hawking, D., Craswell, N. and Griffiths, K.,

2005. Focused crawling for both topical relevance and

quality of medical information. Proc. of the 14th ACM

International Conference on Information and

Knowledge Management CIKM '05.

Zhuang, Z., Wagle, R. and Giles, C.L., 2005. What's there

and what's not?: focused crawling for missing

documents in digital libraries. Proc. of the 5th

ACM/IEEE-CS Joint Conference on Digital Libraries,

Denver, CO, pp. 301 – 310.

EFFECTS OF CRAWLING STRATEGIES ON THE PERFORMANCE OF FOCUSED WEB CRAWLING

381
