NEW APPROACH TO AUDIO SEARCH BASED ON KEY-EVENT

DETECTION PROCEDURE

Igor E. Kheidorov, Peter D. Kukharchik and Yan Jingbin

Belarussian State University, 4, Nezalezhnosti av., Minsk, Belarsu, Belarus

Keywords: Audio search, Keyword spotting.

Abstract: In this paper a new approach to audio search in multimedia data bases is developed based on key-event

detection procedure. The main idea of the proposed approach is to present each audio fragment as sequence

of context dependent “key-events”, specially determined or taken from the data base. Wavelets and support

vectors method were used as the basis for the created procedure of key-events selection and classifier

training. The experiments show good results and perspectives for the proposed approach.

1 INTRODUCTION

Information flow grows year by year, and as a result

multimedia databases in different applied areas are

already collected and ready for indexing.

Computational capabilities of modern signal

processing devices become higher and higher, and

new information technologies allow the processing

of not only text and image information but also

video, speech and audio signals. Managing the huge

amount of data leads to some difficulties connected

with information storing and retrieving in image

databases. In order to solve the data managing

problem new instruments for indexation, searching

and visualization were developed (

Chelba, Silva and

Acero, 2007)

. The first system suitable for indexation

and searching in large image databases was

developed in the end of 1990

. Modern systems

support indexation, retrieval and displaying of

different types of multimedia content, such as audio,

video, and some types of images, but up to the

moment there is no perfect universal system able to

index any type of audio with high accuracy (

Chen,

2008).

In the paper the new approach for universal

indexing system creation is proposed based on “key-

event” detection ideology. The section 2 is devoted

to the introduction to the “key-event” method,

section 3 gives an idea of “key-event” creation

procedure, in section 4 there are experimental results

for music genre recognition and keyword search

tasks.

2 KEY-EVENT IDEOLOGY

Audio data indexing can be considered as a typical

recognition task. The main problem is to find the

procedure, which minimizes average risk when

having a finite set of data, i.e. the procedure which

that minimizes empirical risk. The success in

indexation system creation is connected with

development and implementation of new

fundamental mathematical methods, algorithms and

schemes which allow the modelling of acoustic

signal as a structure with several parallel existing

conditions. The most effective are the graphical

probability models, hierarchical hidden Markov

models (HMM) (Wilpon, Rabiner etc., 1990.),

neural networks (NN), Support Vector Method

(SVM).

The main problem of modern audio indexing

systems is to find the appropriate feature vector for

the signal. Characteristics for each type of signal

differ each other for music, speech, noise sounds,

etc, and this fact essentially complicates the

indexing procedure. In order to decrease the

calculation score and construct fast search algorithm

it can be used the multi-stage procedure which

include several one-by-one stages:

speech/music/noise/silence discrimination, speech

language recognition, determination of speaker

changing points, male/female speech distinguishing,

etc.

Such approach provides good and practically

acceptable results but has the drawbacks:

Kheidorov I., Kukharchik P. and Jingbin Y. (2009).

NEW APPROACH TO AUDIO SEARCH BASED ON KEY-EVENT DETECTION PROCEDURE.

In Proceedings of the International Conference on Signal Processing and Multimedia Applications, pages 33-37

DOI: 10.5220/0002185900330037

 SciTePress

• The error caused on upper processing stages

leads to the total error of the search procedure.

For example, if the speech fragment was

falsely recognized as the music one the

keyword search will never even start.

• In a number of cases it is very hard to

distinguish speech from music on the

preliminary stage because of their similarity

on the most parameters (for example, Chinese

speech);

• In the real system we need to pass throw all

stages of analysis to find the required audio

fragment not depending on its context. In the

case of speech indexing different words have

different features with different distinction

power, and this apriory information has to be

used for fast search. For example, it very hard

to find very short words like “yes” or “no”,

but not a problem to find the specific long

word “synchrophasotron”.

In order to overcome these drawbacks there were

developed main approaches of content-sensitive

adaptable system, suitable for direct indexing an

search of different type of information in

audiodocuments.

In order to introduce “key-event” method lets do

three assumptions about audio signal. The first one

is that wavelet-image of audio contains all

significant information about time and spectrum-

based signal features (Kukharchik, Kheidorov etc.

I.E., 2008). All features like formants, fundamental

frequency, cepstrums, formats, short energy

parameters, etc. can be calculated using wavelet

image of audio, and can be considered as

transformations of wavelet image. These means that

we suppose that all necessary information (including

time dependences) about audio can be obtained

based on wavelet.

The second assumption is that any audio

fragment can be described as a set of specially

determined “events”, each event presents

acoustically significant property for the certain audio

part. The event has to be an important feature which

is typical for the specific type of audio objects. In

the broad sense such acoustical events (we will call

them “key-events”) presents the audio fragment

semantics, and can be used for the direct description

and indexing of audio. Specially selected “key-

events” can be transformed into indexes suitable for

storing in data bases.

The third assumption is that SVM classifier can

be trained to model any selected event in audio

signal with different accuracy. In other words, it is

supposed the SVM kernel can approximate any

feature parameter (transformation) of audio signal.

The developed and proposed “key-event” search

method includes two main stages: audio content

dependent “key-event” creation for target audio, and

target audio search based on its “key-events”

presentation. Each target audio has to be found by

looking for the key events appearance in a

continuous audio stream. The “key-event” search

can be done in the order of calculation complexity

growth, i.e. the simplest “key-event” has to be found

in the first order, then the second one and so on.

Each next search can be done within the framework

of the previous search results, and the final decision

has to be done by specially trained decoder (for

example, HMM). The search scheme is presented on

fig.1.

Figure 1: Audio search scheme based on key-event

ideology.

The main advantage of the proposed approach is

that we try to find the feature vector (which presents

the “key-event”) mostly suitable and typical for the

given content. This activity lets us to describe audio

in the terms of features of the specific audio, not by

common features like cepstrums and others. Such

approach allows usage of a priory audio information

as much as possible, and this information is to be

presented by “key-events”. The number of “key-

events” can differ for different audio fragments. Of

course, the procedure of “key-event” selection for

each audio is very complicated and time consuming,

but it can be iteratively. The most successful key-

events can be stored in the data base as the basis for

new “key-events”. Time by time the “key-event”

data base will be enlarged and finally will contain

the most of possible events for audio, and the new

target audio can be easily described in terms of

“key-events”. Different “key-events” can be joined

in an arbitrary order to form the semantic description

Target audio

Keyev

Audio stream

Target audio positions

Keyev

Keyevents

HMM decoder

SIGMAP 2009 - International Conference on Signal Processing and Multimedia Applications

of target audio in human comprehensible terms.

genre recognition and keyword search tasks.

3 SUPPORT VECTOR

MACHINES FOR KEY-EVENTS

DETECTION

As it was noticed earlier the idea of “key-events” is

very powerful from the viewpoint of direct semantic

audio analysis. The “key-event” detection procedure

can provide the rough semantic context of audio.

The main problem of “key-event” search ideology is

to find the appropriate “key-events”. In this paper

the “key-event” search idea is developed and

introduces on two sample tasks: keyword spotting,

and music recognition.

For keyword search task at the singular case the

phonemes can be taken as “key-events”, and the

key-word spotting procedure is typical for this task

and based on automatic speech recognition (ASR)

engine. But the presentation of speech as sequence

of phonemes is not an optimal one because of

several reasons. First of all, a lot of significant

information which is contained on phoneme

boundaries can be lost. The second reason is that

usage of ASR needs full presentation of speech as a

sequence of phonemes, such presentation is

abundant for keyword search procedure.

Its main idea is to substitute the term “keyword”

by the term “key-event”, which gives number of

points with the maximum probability of keyword

appearance. The “key-event” can include a series of

features from wide range of characters with different

discrimination power. For example, the “key-event”

can be an appearance of a certain pair of -

frequencies (in tonal dialing, for example), as well

as the form or behavior of speech first formant

(quick grow, for example). In this case the keyword

search can be done as a sequential search of key

events, typical to the given keyword. One key word

can be characterized by several key events, which

has to be detected in an order reverse to their

complexity.

In order to create a set of simple key-events it

was proposed to use SVM technique. There are

several reasons to use SVM for this task. The

principle distinguish of SVM classifiers from

common classification methods like HMM or

Gaussian models is that SVM directly approximates

class boundaries and not describe the probability

densities on training set. Within the framework of

the proposed approach the SVM will be used in

order to determine if the given “key-event” is

presented at audio fragment. Two-class SVM (class

“yes” and class “no”) is suitable for these task.

Let we have a set of training vectors which

belong to two different classes,

()

yxyx ,,...,,

where

Rx ∈

and

{

}

1,....,1−∈

. The train aim is to

find the optimal hyper plane

0=+ bwx which

divides data and maximizes the distance between

this plane and the closest data points for each class.

In order to solve this task it is possible to use

Lagrange function:

()

[]

{}

∑

++−= 1)(

bwxywbwL

iii

αα

(1)

where

- Lagrange multiplier (Krebel U., 1998.).

Such approach lets to divide the target task on two

sub-tasks which can be easily solved. We can find

the solution like:

∑

iii

xyw

[]

xxwb +−=

(2)

where

x - two support vectors,

, 0>

y , 1

−

y . In order to solve the non-separable

task Cortes и Vapnik involve fictive values

0≥

and penalty function

()

∑

ζζ

, where

measure of false classification. The solution is

identical to the case of separable task with the

exception of necessity to modify Lagrange

multipliers

≤

0 ,

li ,...1

. The choice of C is

not fixed and we will suppose

200=C in all

experiments

But in practice data mostly can not be divided by

the linear plane, but can be divided in other features

space after non-liner transform. For such case SVM

with nonlinear discrimination can be used based on

kernel functions. There are three main kernel

functions of non-linear reflection: polynomial, radial

base Gauss function, exponential radial base

function.

The “key-event” selection procedure was

organized in the following way. Wavelet image of

the key-word was analyzed in different scales in

order to find the candidates on simple events, typical

for the certain word. The selection procedure

consists of two stages. The first one is necessary to

create a set of candidate features to become a “key-

event”. The second stage is SVM training and

testing for each candidate, in order to select the

candidates with the highest discrimination power.

The pair “Feature vector-SVM” forms the “key-

event”. The discrimination power of such “key-

event” can be defined as the probability of right

recognition with the previously limited probability

of false alarm. The right recognition rate is

determined for each “key-event” during testing as

NEW APPROACH TO AUDIO SEARCH BASED ON KEY-EVENT DETECTION PROCEDURE

the number of event appearances in target audio

fragments related to the total number of such

fragments. In such manner the probability of each

“key-event” for each type of audio is known before

the recognition experiment, and forms the

observation probability matrix which used by HMM

decoder.

In other words, selected “key-events” forms a set

of observations

{}

oooO ,...,

, where

- number

of “key-events”. For target audio for each

observation

Mmo

<1,

, there is a

corresponding probability

(

)

. The main task of

SVM classifier is to answer the question: does the

“key-event” occur in an audio stream, or not. If the

“key-event”

o was detected it means that the

estimated probability of this event is

()

. Then

these probabilities can be processes by the HMM

decoder instead of typical description of observation

sequences by Gaussian mixtures.

Figure 2: Wavelet image of audio.

One of the great problems within the framework

of this approach is to create reasonable candidates to

be “key-events”. On this stage any apriory

information about audio signal structure is welcome.

But in general it was proposed the following

procedure for creation candidates to be “key-

events”. Wavelet image of audio (fig.2) is processed

in order to form different “time-frequency” cells of

different forms and sizes.

In the simplest case the domain divider is a

rectangular grid which contains cells with different

widths and heights. The relations between energy

means inside cells can be considered as feature

vector which is able to present not only energy

correlations in one moment, but between different

time moments.

4 EXPERIMENT

First series of experiments was devoted to genre

recognition task. Experiments were conducted in

order to prove the idea for four music genres on a

small data base. The main efforts were devoted to

the search of features and corresponding SVM

kernels for different music genres and musicians.

Ideally each musician or genre has to be described

by his own “features vector-SVM” pair, which

reflects its peculiarities. For music signal it was

supposed that the most essential information inside

the music is the cross-correlations between main

spectrum lines (fig.2), this relationships were

selected as “key-event” candidates (prototypes).

This information together with behavior of spectral

lines is the main distinctive feature for music, but

the problem is to choose the “key” essential feature

for the given music. The experiment shows that the

common average error is 2.69 % (table 1). The worst

classification results are shown for audio files

segmentation which contain classics (accuracy

96.25%) and disco (accuracy 96.53%). Speech

segments classification accuracy is 98.3 %. The

average accuracy level is 97.31 %, and this fact

shows the effectiveness of the proposed

segmentation scheme.

Table 1: Music genre recognition result.

Correct Critical errors Non-critical

errors

Classics 96,25 % 2,03 % 1,72 %

Pop 97,68 % 1,03 % 1,29 %

Rock 97,6 % 2,17 % 0,024 %

Disco 96,53 % 3,47 % 0 %

Average

mean

97,31 % 2,03 % 0,66 %

The second experiment was devoted to the keyword

spotting task. In order to make the experiment on the

key-event based keyword search the following data

base was created. Data base vocabulary contains 520

phonetically balances Russian phrases. This data

base was collected at Radiophysics department of

Belarussian State University. As a minimal acoustic

unit it was chosen a context dependent phoneme-

allophone. Full set of allophones describes the whole

speech variety. This data base guarantees presence

of all types of phoneme and can be used for the

adequate estimation of segmentation algorithm.

Phonetically balanced database contains 53

speakers, 18 females and 35 males, all phrases are

processed by speech –detector and contains speech

only. For each phrase the phonetic transcription is

known, allophones boundaries are detected using

specially developed software and checked manually.

SIGMAP 2009 - International Conference on Signal Processing and Multimedia Applications

This data base was used to train the phone

recognizer based on continuous HMM, each state is

connected with the correspondent phoneme. This

recognizer was used in order to construct the ASR-

prototype and estimate the output phoneme

probabilities during the keyword spotting procedure,

as well as in order to find the context-dependent

key-events mostly suitable for the given key-word.

The key-word detection accuracy of 5, 10 and 20

words for different number of key-events and

ordinary phonetic ASR-based searcher are presented

in table 2. The used ASR system was based on

HMM and trained on the same data base as it was

used for key-event search procedure.

Table 2: Key-word search accuracy for different

techniques.

Number of words for search

Searcher

type

5 words 10 words 20 words

Key-events 80,5% 80,2% 79,6%

ASR-based 68,5% 67,2% 66,3%

The False acceptance rate for the same key-word

search system is presented in table 3.

Table 3: False acceptance rate for key-word search.

Number of words for search

Searcher

type

5 words 10 words 20 words

Key-events 3,5% 5,8% 6,2%

ASR-based 26,1% 30,8% 32,2%

5 DISCUSSION

It can be noticed from the experiment results that the

proposed context dependent key-events technique

provides the higher search accuracy in comparison

with ordinary ASR techniques based on HMM. The

false acceptance rate is much lower than for another

technique because each SVM classifier for the “key-

event” was trained in order to minimize FAR.

The main drawback of the method of key-words

search based on “key-events” is that it very

complicate to chose the suitable “key-events”. It is

not very reasonable to start the complicated key-

event determination procedure for all possible

keywords. The idea is that all possible “key-events”

suitable for key-word search can be united into

common data base which will be used for initial

“key-events” estimation in specific cases.

6 CONCLUSIONS

The algorithm of “key-events” creation and usage

was proposed for audio sequences indexing and

search. The “key-event” is a “feature vector-SVM

classifier” pair, and the fixed probability of each

event can be determined during SVM testing. This

probability was proposed to use as estimation of

observation probabilities for HMM-based decoder.

The experiments show good results and perspectives

for the proposed approach.

ACKNOWLEDGEMENTS

The paper was proposed under the partial support of

International Science and Technology Center,

project B-1375.

REFERENCES

Chelba, C., Silva J. and Acero, A., 2007. In Computer

Speech and Language, “Soft Indexing of Speech

Content for Search in Spoken Documents”. 21(3), pp.

458-478.

Kukharchik, P.D., Kheidorov, I.E., Bovbel, E.I., Ladeev,

D.D., 2008. In Image and Signal Processing, “Speech

signal processing based on Wavelets and SVM for

vocal tract pathology detection”. LNCS 5099,

Springer, pp.385-389.

Wilpon, J.G., Rabiner, L.R., Lee, C.H., and. Goldman,

E.R, 1990. In IEEE Transactions on Acoustics, Speech

and Signal Processing, “Automatic recognition of

keywords in unconstrained speech using Hidden

Markov Models”.

Chen, B., Chen, Y.T., 2008. In Pattern Recognition

Letters, “Extractive Spoken Document Summarization

for Information Retrieval”. 29(4), pp. 426-437.

Krebel U., 1998. Advances in Kernel Methods: Support

Vector Learning. MIT Press.

NEW APPROACH TO AUDIO SEARCH BASED ON KEY-EVENT DETECTION PROCEDURE
