AN ADAPTIVE CLASSIFIER DESIGN

FOR ACCURATE SPEECH DATA CLASSIFICATION

Omid Dehzangi, Ehsan Younessian

Nanyang Technological University, Singapore

Fariborz Hosseini Fard

SoundBuzz PTE LTD, Subsidiary of Motorola Inc., Singapore

Keywords: Nearest neighbor, Linear discriminant analysis, Adaptive distance measure, Weight learning algorithm.

Abstract: In this paper, an adaptive approach to designing accurate classifiers using Nearest Neighbor (NN) and

Linear Discriminant Analysis (LDA) is proposed. A novel NN rule with an adaptive distance measure is

proposed to classify input patterns. An iterative learning algorithm is employed to incorporate a local weight

to the Euclidean distance measure that attempts to minimize the number of misclassified patterns in the

training set. In case of data sets with highly overlapped classes, this may cause the classifier to increase its

complexity and overfit. As a solution, LDA is considered as a popular feature extraction technique that aims

at creating a feature space that best discriminates the data distributions and reduces overlaps between

different classes of data. In this paper, an improved variation of LDA (im-LDA) is investigated which aims

to moderate the effect of outlier classes. The proposed classifier design is evaluated by 6 standard data sets

from UCI ML repository and eventually by TIMIT data set for framewise classification of speech data. The

results show the effectiveness of the designed classifier using im-LDA with the proposed ad-NN method.

1 INTRODUCTION

The NN classifier is one of the oldest and the most

successful methods of non-parametric pattern

classification (Cover and Hart, 1998). However, it

has some weaknesses in cases that patterns of

different classes have overlap in some regions in the

feature space. It also considers all the stored

instances the same for classification, but the

instances are different in being representative of

their typical classes.

The performance of the NN classifier depends

crucially on how to choose a suitable distance

metric. Many methods have been developed to

locally adapt the distance metrics such as the

flexible metric method proposed in (Friedman,

1994), the discriminant adaptive method in (Hasti

and Tibshirani, 1996) and the adaptive metric

method in (Domeniconi et al., 2002). The common

idea underlying these methods is that they estimate

feature relevance locally at each query pattern. This

leads to a weighted metric for computing the

similarity between the query patterns and training

data. In (Wang et. al., 2007), a simple locally

adaptive distance measure is proposed that uses a

heuristic measure to specify the weight of each

training instance. The method we propose in this

paper uses a locally adaptive metric to improve the

performance of the basic NN classifier. An iterative

learning algorithm is employed to incorporate a local

weight to the Euclidean distance measure that

attempts to minimize the number of misclassified

patterns in the training set. In case of data sets with

highly overlapped classes, examples in the

overlapping area are considered to be noisy as for

learning these examples. the learning algorithm

would be in contradiction with other training

examples or would need to increase its complexity

in order to accommodate them. Learning these

difficult examples may lead the algorithm to be

unable to generalize well.

As a solution to this problem, linear discriminant

analysis (LDA) is considered as one of the most

traditional methods to find a linear feature

transformation method, which maximizes the ratio

of between-class scatter and the within-class scatter.

Dehzangi O., Younessian E. and Hosseini Fard F. (2009).

AN ADAPTIVE CLASSIFIER DESIGN FOR ACCURATE SPEECH DATA CLASSIFICATION.

In Proceedings of the 6th International Conference on Informatics in Control, Automation and Robotics - Robotics and Automation, pages 67-71

DOI: 10.5220/0002206200670071

 SciTePress

The earliest of such methods, Fisher's Linear

Discriminant Analysis (LDA) (Fisher, 1936), tries to

find a linear combination of input variables that best

discriminates between different class distributions

and is still a powerful technique for feature

extraction to reduce overlaps between different

classes of data (Duda and Hart, 2001). However,

LDA does not take into account the conjunctions

between different pairs of classes in a multi-class

problem (Loog et al., 2001). In such cases, if one or

more classes are far away from others (i.e. outlier

classes), there is no need to maximize their between-

class scatter covariances in the transformed space.

Thus, they do not contribute in the estimation of the

uniform between-class covariance (Jarchi and

Boostani, 2006). In this paper, an improved version

of LDA is investigated that redefines the between-

class scatter matrix by integrating a simple weight

into it. In the transformed feature space, different

classes of data have lower degrees of overlap with

one another. Then, our proposed ad-NN classifier

can be applied to the input patterns in the new space

with lesser risk of overfiting. In order to assess our

method, combination of the im-LDA and the ad-NN

are applied on eight UCI ML driven data sets. The

proposed classifier design is also applied on TIMIT

speech data set, attempting to classify huge amount

of speech frames with 60 different phoneme classes.

2 ADAPTIVE DISTANCE USING

WEIGHTED INSTANCES

The nearest neighbour classifier assigns label of a

test pattern according to the class label of its nearest

training instance. To introduce the weighted version

of NN rule, here, the notation of basic NN rule is

briefly described. Assume that classification of

patterns in an m-dimensional space is under

investigation. Having a set of training instances

{(X

)}, where X

i=1,…,n are training feature

vectors and C

,k=1,…,M are the labels. NN rule

finds the nearest neighbor of a new test pattern X

using a distance function and assigns X to C

(the

class label of the winner class). The Euclidean

distance have been conventionally used to measure

the distance between X and Y:

d( , ) = ( - )

Yxy

∑

(1)

In the first step, the distance as a dissimilarity

measure between query pattern X and the j

instance

is changed to a similarity measure. This is done

by a linear conversion as follows:

( , ) = 1 - d( , ) /

XXXm

(2)

where,

m is the maximum distance which can ever

occur Between two training instances in the whole

training set, since the data is normalized in the range

of [0, 1] in the first place. As a result, instead of

finding minimum distance pattern to X, we search

for instance X

such that μ(X,X

) is maximized. This

can be interpreted as normalizing the distance from

[

m , 0] to a real number in the interval [0, 1]. Now,

we can introduce the weighted nearest neighbor rule.

The pattern is classified according to consequent

class of the winner instance X

win

. The winner

instance is specified using:

{

}

= 1,...,

= argmax ( , ) .

win X X w

(3)

where w

is the weight assigned to the j

instance by

the learning algorithm which is introduced in section

2.1 Instance Weighting Algorithm

For an M-class problem, assume that n labeled

patterns {X

, i=1,2,…,n} are available from various

classes. In this section, we propose an algorithm to

learn the weight of each pattern using other labeled

training instances. The calculated weight is optimal

in the sense that it maximizes the classification rate

of the classifier on the training data. At the

beginning, a weight of one is assigned to each

pattern in the whole training set (i.e. w

=1, k=1,...,

n).

In the following, the weight of each instance is

specified assuming that the weights of all other

training instances are given and fixed. The weight w

of instance k with class label of Q can be found as

follows. First, the problem is considered a 2-class

problem of class Q as positive “p” and class

Q as

negative “n”. The w

is set to zero (i.e., instance X

does not contribute in classification decision). Given

current weights of all other training instances and a

training set of P positive and N negative labeled

patterns, the decision results of the weighted

instance NN classifier described in section 3 can be

grouped into four categories: true positives (TPs)

denoting samples correctly labelled as positives;

false positives (FPs) denoting negative samples

incorrectly labeled as positives; true negatives (TNs)

denoting samples correctly labeled as negatives; and

ICINCO 2009 - 6th International Conference on Informatics in Control, Automation and Robotics

false negatives (FNs) denoting positive samples

incorrectly labeled as negatives.

Training patterns of class Q which are classified

correctly with the current values of instance weights

are removed from the training set. These patterns

will be classified correctly regardless of the value of

. Similarly, training patterns of class Q which are

misclassified with the current assigned weights are

also removed from the training set. These patterns

will be misclassified regardless of the value of w

For each training pattern left in the training set (i.e.

instances in TN and FN), a score is calculated using

the following measure:

max{ ( , ). | 1,2,...,n, }

()

(, )

tj j

Xwj jt

=≠

(4)

where μ(X

) represents the similarity of patterns X

and X

calculated using (2).

Those instances that have X

as their nearest

neighbor are called associates of X

. It can be shown

that X

is an associate of X

, if S(X

) is less than w

We have,

() (, ) ()(, )

ktktk ttk

w SX w XX SX XX

>⇒⋅ >⋅

(5)

From (4) we have,

. ( , ) max{ ( , ). | 1,..., , }

ktk tjj

wXX XXwj njtk

μμ

>=≠

(6)

From (3) and (6), it is concluded that X

is the

winner instance to classify X

. Given the weighted

instance NN classifier introduced in previous

section, associate set of instance X

can be defined

fomally as,

{}

_(,)

|1,..., ()

tkt

Associate set X w

Xt nt kw SX

=≠>

(7)

By altering w

, the associate set of X

is changed

that cause modification in classification error rate of

the classifier. Our aim is to determine w

such that

the error-rate of the classifier on training set is

minimized given that the weights of all other

training instances are given and fixed. We define an

accuracy measure as,

TP FPAccuracy =−

(8)

We try to find a proper w

such that associate set

of X

includes more FN instances which need to be

classified as “p” and exclude more TN instances

which are the instances of class “n”. The optimal

weight of the instance X

is calculated by

maximizing Accuracy measure assuming that the

weights of all other instances are given and fixed. To

do this, the set of patterns X

are ranked in ascending

order of their scores. We define a threshold

initialized with zero. Then, assuming that X

and X

t+1

are two successive patterns in the ranked list, a

threshold is computed as,

th = (Score(X

) + Score(X

+1))/2 (9)

The threshold is then altered from the least score

to the greatest and associated accuracy of the

classifier with respect to the each threshold is

measured. The value of the best threshold (i.e.

leading to the best accuracy) is simply used as the

weight of the instance X

. The proposed instance

weighting mechanism assigns a weight to each

instance attempting to better discriminate between

the patterns of the same class and patterns of all

other classes. The search for the best combination of

instance weights is conducted by optimizing each

instance in turn assuming that the order of the

instances to be optimized is fixed.

3 OVERVIEW OF LDA

The proposed algorithm in section 2.1 to learn the

weight of each instance attempts to minimize the

classification error in the training data. In case of

data sets with highly overlapped classes, examples

in the overlapping area are considered to be noisy as

for learning these examples. Learning these difficult

examples may lead the algorithm to be unable to

generalize well. The goal of LDA is to find an

optimal linear transformation of input feature

vectors such that the class separability in the new

space is maximized. In order to find an optimal

linear discrimination transform, Fisher (Fisher,

1936) proposed a criterion that maximizes the ratio

of between-class to within-class scatter matrices.

The aim is to look for a linear discriminant

transform

{}

arg max

LDA ij

(10)

where,

is the Fisher criterion that is determined

as follows:

WSW

(11)

where S

is between-class scatter matrix and S

within-class scatter matrix. Columns of

LDA

are

eigenvectors corresponding to the (C-1) largest

eigenvalues of

−

. Now, each sample X in data

AN ADAPTIVE CLASSIFIER DESIGN FOR ACCURATE SPEECH DATA CLASSIFICATION

set can be transformed to a new space by

multiplying to the matrix

w :

LDA

Yw X=

(12)

Y is a new transformed sample corresponds to X.

3.1 The Improved LDA Method

By Projection of data in a lower dimensional space,

LDA can also reduce the computation complexity

caused by redundant information in the data which is

useful for solving classification problems. However,

LDA has some weaknesses. LDA considers all the

classes the same to calculate between-class scatter

matrix. If one or more classes are outliers, there is

no need to maximize their between-class scatter

covariance in the transformed space. Therefore,

different weights should be integrated in the

covariance estimation procedure. The aim in the

weighted version of LDA is to alleviate the role of

an outlier class. This is done by redefining between-

class scatter matrix.

Assume that we use the between-class scatter

matrix definition that is based on (Loog et al., 2001):

()()

Bijijij

iji

SPP

μμμμ

−

==+

=−−

∑∑

(13)

where, C is the number of classes, p

is a prior

probability for class i and p

is a prior probability for

class j,

is the mean of training samples of class i.

Incorporating a weight

into between-class

scatter matrix leads to a new formula:

1()()

Bijijijij

iji

SNN

ϕμμμμ

−

==+

=−−

∑∑

(14)

where,

is Fisher discrimination value of the

resulting

that is determined in (11), N is the

number of training samples, N

and N

are the

number of training samples of class i and j,

respectively. By incorporating this weight, the

farther the classes are from each other, the less their

contribution is in the between class scatter matrix

calculation.

4 EXPERIMENTAL RESULTS

In order to evaluate the performance of the designed

classifier, two sets of experiments have been

conducted.

4.1 Experiments using Standard Data

First, a number of standard data sets are used which

derived from UCI ML repository (Merz and

Murphy, 1996). Some statistics of the data sets are

shown in Table 1.

Table 1: Statistics of the data sets used in our experiments.

Data set

# of

attributes

# of

patterns

# of

Classes

Pima 8 768 2

Wine 13 178 3

Hepatitis 19 155 2

Image Seg. 15 210 7

Balance 4 625 3

Heart Clev. 13 303 5

To evaluate the classification accuracy on the

data sets, the average result of ten trials of ten-fold

cross validation is reported. Results, which are

shown in the Table 2, illustrate that our proposed

method is led to the best performance on all the data

sets compared to basic combinations.

Table 2: Error rates of combination of LDA and NN along

with our proposed method on 6 UCI ML data sets.

As it can be seen in Table 2, im-LDA

outperforms LDA in multi-class data sets. This

shows the effectiveness of the weight incorporated

in the definition of between-class scatter matrix.

Table 2 also shows that in the transformed feature

space using im-LDA where different classes of data

have lower degrees of overlap, ad-NN with adaptive

local distance measure clearly improves the

generalization ability of the basic NN.

4.2 Experiments using Real Data

In this section, we validate the proposed method on

the TIMIT corpus (Garofolo, 1988) because of its

high-quality phone labels. All results reported are

framewise classification error rates for TIMIT

complete test set (the 1344 si and sx sentences). The

Data set

Basic

LDA+

Basic

Im-

LDA+

Basic NN

Im-

LDA+

ad-NN

Pima 29.06 25.96 25.54 22.47

Wine 5.09 3.23 2.88 2.32

Hepatitis 19.87 14.47 14.33 12.89


Seg.

8.63

7.48 6.21 5.32

Balance 18.69 17.51 15.67 14.19

Heart

Clev

20.75 19.26 16.92 15.29

Ave. error 17.02 14.65 13.59

12.08

ICINCO 2009 - 6th International Conference on Informatics in Control, Automation and Robotics

speech waveforms are parameterized by a standard

Mel-Frequency Cepstral Coefficient (MFCC) front

end. The cepstral analysis uses a 25 msec Hamming

window with a frame shift of 10 msec. Each input

pattern X

consists of the current frame of 12 MFCCs

and energy plus delta and acceleration coefficients,

and two context frames on each side, making a total

of (13 + 13 + 13) * 5 = 195 components. This

formulation was arrived at by experimentation with

varying numbers of context frames left and right of

the frame being classified. The training set has about

1.1 million frames and the test set has about 400

thousand frames. Each frame has an associated 1-of-

60 phonetic label derived from the TIMIT label files.

Due to the large number of training data and

large number of classes, TIMIT data set seems to be

a suitable task to evaluate our proposed classifier. In

Table 3, framewise classification error rates on the

TIMIT test set using our classifier is compared to the

existing methods.

Table 3: Framewise phoneme classification error rate on

TIMIT test set.

Classifier Error Rate

Recurrent Neural Nets (Schuster, 1997)

34.7%

Bidirectional LSTM (Graves, 2005)

29.8%

im-LDA + ad-NN

28.7%

The results show that the proposed classifier

design outperforms previous works in classification

of speech frames on TIMIT task.

5 CONCLUSIONS

In this paper, a novel classifier design based on

combination of an improved version of LDA and an

adaptive distance NN was presented. LDA, as a

preprocessing step, was used to transform input data

to a new feature space in which different classes of

data has lower degrees of overlap. In the

classification step, a novel learning algorithm was

used to assign a weight to each stored instance,

which was then contributed in the distance measure,

with the goal of improvement in generalization

ability of the basic NN. In this way, different weighs

were given to the transformed samples based on a

learning scheme which optimized the weights

according to the classification error rate. Our

proposed method was evaluated by various UCI ML

data sets. Results showed that the proposed method

improves the generalization ability of basic NN. By

using TIMIT speech data set, the effectiveness of

our approach in real problems like speech data

classification was also proved.

REFERENCES

Cover, T.M., Hart, P.E., 1967. Nearest Neighbor Pattern

Classification. IEEE Transaction on Information

Theory 13, 21-27.

Friedman, J., 1994. Flexible metric nearest neighbor

classification. Technical Report 113, Stanford

University Statistics Department.

Hastie, T., Tibshirani, R., 1996. Discriminant adaptive

nearest neighbor classification. IEEE Transactions on

Pattern Analysis and Machine Intelligence, 18: 607-

615.

Domeniconi, C., Peng, J., Gunopulos, D., 2002. Locally

adaptive metric nearest neighbor classification. IEEE

Transactions on Pattern Analysis and Machine

Intelligence, 24: 1281-1285.

Wang, J., Neskovic, P., Cooper, L.N., 2007. Improving

nearest neighbor rule with a simple adaptive distance

measure. Pattern Recogition Letters, 28: 207-213.

Fisher, R.A., 1936. The Use of Multiple Measurements in

Taxonomic Problems, Annals of Eugenics, 7:179-188.

Duda, R.O., Hart, P.E., Stork, D., 2001. Pattern

Classification 2nd Edition. Wiley, New York.

Loog, M., Duin, R.P.W., Haeb-Umbach, R., 2001.

Multiclass linear dimension reduction by weighted

pairwise fisher criteria, IEEE Transactions on Pattern

Analysis and Machine Intelligence, 23: 762-766.

Jarchi, D., Boostani, R., 2006. A New Weighted LDA

Method in Comparison to Some Versions of LDA,

Transaction on Engineering and Computational

Technology, 18: 18-45.

Garofolo, J.S., 1988. Getting started with the DARPA

TIMIT CD-ROM: An acoustic phonetic continuous

speech database, National Institute of Standards and

Technology (NIST), Gaithersburgh, MD.

Merz, C.J., Murphy, P.M., 1996. UCIRepository of

Machine Learning Databases. Irvine, CA: University

of California Irvine, Department of information and

Computer Science. Internet:

http://www.ics.uci.edu/~mlearn/MLRepository.html

Schuster, M., Paliwal, K.K., 1997. Bidirectional recurrent

neural networks. IEEE Transactions on Signal

Processing, 45: 2673-2681.

Graves, A., Schmidhuber, J., 2005. Framewise Phoneme

Classification with Bidirectional LSTM and Other

Neural Network Architectures. International Joint

Conference on Neural Networks.

AN ADAPTIVE CLASSIFIER DESIGN FOR ACCURATE SPEECH DATA CLASSIFICATION
