THE HIXOSFS MUSIC APPROACH VS COMMON MUSICAL FILE

MANAGEMENT SOLUTIONS

Nicola Corriero, Vittoria Cozza and Fabrizio Fattibene

Department of Computer Science, University of Bari, Via Orabona 4, Bari, Italy

Keywords:

Operating system, Linux, Filesystem, System calls, FUSE, Multimedia.

Abstract:

Hixosfs music is an extension of ext2 Linux ﬁlesystem, with additional features to easy accessing and cate-

gorizing musical ﬁles. Specially it extends the inode struct inside the Virtual ﬁle system, considerating as ﬁle

proprieties meta information such as album, author, title related to the content of a musical ﬁle. Comparition

have been done respect to the Linux ﬁle system in user space Musicmeshfs, the Linux ext2 xattr feature, and ad

hoc user space programs for efﬁciently retriving multimedia data. Since Hixosfs music manages the musical

tags at kernel level, it offers higher performances then the other solutions but with less ﬂexibility.

1 INTRODUCTION

In this work we present and compare different way

to manage at ﬁle system (fs) level musical ﬁle collec-

tion of various format. We address both the problems

of store inside a folder tree a musical collection in a

conﬁgurable way with MusicMeshFS(Corriero, 2008)

and xattr and the problem of access in a fast way the

musical tag (e.g. author, album) values with Hixosfs

music. Manage musical ﬁles in a Linux fs makes pos-

sible to use the shell tools as ﬁnd, beside of ad hoc

commands for speciﬁc musical fs that keep under con-

sideration metadata. Generally speaking GNU/Linux

fs are based on a common kernel layer called Virtual

File System (VFS) then they keep the same logical

structure and are all presented at the user in the same

way. At this level structs and operations common to

all fs types have to be deﬁned. To implement a new

fs means to know the kernel internals, learning kernel

module programming and either to know the VFS ar-

chitecture to modiﬁes its structs. For example Hixosfs

music, respect ext2 fs, extends the inode struct to in-

clude musical tags in the metainformations associated

to a ﬁle.

Linux offers already a way to extend inode attributes

but without physically modifying the inode struct

with the xattr feature. This solution is currently used

in most common Linux fs and it offers an easy in-

terface to the ﬁnal user that can choose and add run-

time all the couples attribute-name attribute-value he

likes to store with the command attr. Finally an

other way to manage tags in fs is by writing a new

fs in userspace, this can be done even from not kernel

developers, thanks the the userspace library offered

by Filesystem in Userspace (FUSE) project(Szeredi,

2008). In this way an user can rideﬁne the ﬁle oper-

ations keeping under consideration metainformation

related to a ﬁle, and to have a different virtual view

of his fs that anyway is not physically modiﬁed. Mu-

sicMeshFS (MMFS) is an example of fs based on fuse

for multimedia data.

2 HIXOSFS MUSIC

Hixosfs music architecture(Corriero, 2009) generally

recalls the widely used ext2 ﬁle system, but it extends

the information stored in the inode with tags such as

author, title, year and album for musical data. The

hixosfs project required the linux headers to be modi-

ﬁed, new system calls for read and write tags and the

new hixosfs module to be implemented: chtag and re-

tag, the ﬁnal user recall the syscall by the tools chmu-

sic and statmusic with analogous functionality of the

well known chown and stat but obviously consider-

ating musical tags(hix). The header ”linux/fs.h” has

been changed to extend the deﬁnition of iattr struct

with musical tag. Specially the function setattr

with the task to propagate at the inode the change re-

lated to iattr struct, has been extended specifying the

new tags deﬁnition that will be stored inside the in-

ode.

The inode is the kernel struct for all the ﬁle type man-

189

Corriero N., Cozza V. and Fattibene F. (2009).

THE HIXOSFS MUSIC APPROACH VS COMMON MUSICAL FILE MANAGEMENT SOLUTIONS.

In Proceedings of the International Conference on Signal Processing and Multimedia Applications, pages 189-192

DOI: 10.5220/0002230801890192

 SciTePress

agement, hixosfs music extends the inode deﬁnition

with a struct tag.

The struct tag has four ﬁelds for a total of about

100 byte of stored information, theoretically an

i-node can be extended until 4 kb then it’s possible

to customize it with many tags for your purpose.

It’s convenient to choose tags that are most of the

time used in the ﬁle search to di-scriminate the ﬁles

depending their content. We chose here what was

able to maximize the time of search musical ﬁles

by most commonly used criteria as album or author

name and so on.

A new module have been created, the Hixosfs

module that includes hixosfs operations deﬁni-

tion. Certain functions as hixosfs read inode,

hixosfs update inode and hixosfs new inode don’t

differ too much respect to read and update for ext2 ﬁle

system. In addition there is a new part for the man-

agement of the new content based ﬁle attribute in the

struct iattr and inode. Finally two new system calls

Chtag and retag have been implemented to allow to

write and read the struct tag from hixos inode.

All described modiﬁcation have been done start-

ing from 2.6.23 kernel, but can easily integrated in

newer kernel versions. Beside standard user mode

tools (stat, chmod, ls and so on), speciﬁc command

are needed to directly handle with new ﬁle tags.

There are two kind of user space programs hixosfs

requires, to read/write tags from/to inodes and as well

to interface with the tag based ﬁle management of-

fered by hixosfs. At the ﬁrst group belong programs

as statmusic (think at shell command stat) and

chmusic (think at chown and so on), at the second

orderby, ls, find, with an intuitive meaning.

3 EXTENDED ATTRIBUTES

Currently Linux fs as ext2 (Remy Card), ext3, reis-

erfs allows to manage with metainformation related

to a ﬁle with xattr feature. Patching the kernel with

xattr you have a way to extend inode attributes that

doesn’t physically modify the inode struct. This is

possible since in xattr the attributes are stored as a

couple attribute-value out of the inode as a variable

length string. Generally the basic command used to

deal with extended attributes in Xattr is attr that

allows to speciﬁes different options to set and get at-

tribute values, to remove attributes to list all of them

and then to read or writes these values to standard out-

put. The programs we implemented in our testing sce-

nario are based on this user space tool.

4 FILE SYSTEM IN USERSPACE

FUSE is an open source project with GPL and LGPL

license that offers a Linux kernel module to allow

to not privileged users to create their own fs without

write kernel level code, in fact customizing fuse you

can create your own fully functional fs directly in user

space. This approach is used to write virtual fs, that

don’t care about store data on the disk but of arranging

them to offer a virtual view of such data to the ﬁnal

user. For the MMFS design please refers to (Corriero,

2008).

5 PERFORMANCE MEASURES

In this section performance measurements made on

hixosfs are presented. The monitored operation are

about reading e writing tags from and to a ﬁle, read-

ing from disk the folders content, the operation of

ordering a group of ﬁles with user passed parame-

ters. The time required to perform this operations

by hixosfs has been measured and compared with the

time needed in the some situation by:

• a fuse based ﬁle system approach, specially mu-

sicmeshfs (MMFS)

• xattr Linux fs feature

• an ad hoc user space program

All analyzed case have in common a musical

ﬁles processing phase application based on TagLib

C(Wheeler, 2008) library to extract musical tags such

as author, track, title year, album. The time it-

self has been measured by the unix command time

command1 that gives as output the execution times

of input command command1. As you can expect

the study shows that performing such operations with

hixosfs gives an huge optimization in term of time

since it works in kernel mode with operating system

privileges. Every action done for the discovery of in-

formation involves a system call and then a software

interrupt for each system call.

To work with hixosfs music and related user mode

tools you have to to patch and recompile the kernel

source, to compile user space programs, to create a

hixosfs fs (ext2-modiﬁed) with a 256 byte inode by,

e.g, mkfs.ext2 -I 256 ... and ﬁnally to mount

hixosfs fs in your tree To test his way of working and

then do performance comparisons, after preparing the

system, we populated the fs with a collection of 80 Gb

of musical data. The main command used to add ﬁles

inside the hixosfs music is addmusic and the sintax is:

addmusic FILENAME | FOLDERNAME

SIGMAP 2009 - International Conference on Signal Processing and Multimedia Applications

190

By using this command you can ﬁnd the hixosfs music

already mounted and copy music ﬁle inside it. Other-

wise it’s possible to use cp to physically copy ﬁles

in the partition and then filltag to populate the

hixosfs inode tags struct. The usage is:

filltag FILENAME

The command open ﬁle with taglib function to ﬁnd

metainformation about music and uses a system call

to insert this information in the inode. Since it uses

a system call the operation is a high priority kernel

mode task. Once fs contains musical ﬁles, they can

be ordered by an ad hoc program called orderby. The

syntax is:

orderby [-a tag1 | -b tag2]

For example with the command:

#orderby author year

we have all ﬁle in fs in a tree with the ﬁrst node as

a folder with as name each track author, the second

node as a folder with as name the track year and in the

third node, ﬁnally, the music ﬁle itself. The trick of

using hard links for implementing orderby allows

coexisting in safe way more then one order.

Figure 1: orderby.

5.1 Musicmeshfs vs Hixosfs

Musicmeshfs is an example of ﬁle system based on

the fuse library. The concept of orders is common

at both hixosfs and MMFS. In the case of MMS the

string used at mounting fs time, includes a reference

to a particular required orders. For example mount-

ing with the option Author#Year creates a three levels

tree: ﬁrst level with author of the tracks, second year

of the tracks in the database for each author, then the

track ﬁles themself. The MMFS implementation in-

cludes a database that stores the metainformation and

the data organization according user choose. In fact

Table 1: Hixosfs vs mmfs.

ls in MMFS ls in hixosfs

13.10 sec 0.20 sec

in general a virtual fs never changes the real ﬁles, but

it just shows them at the user according a chose order.

Since MMFS is a kind of read-only fs, the only access

you can do to write in fact is only to change a ﬁle tag,

a command that seems interesting to perform to do

a comparison with hixosfs is the common command

that shows the ﬁles according predeﬁned order such

ls. In the simple case of a fs, let’s say with folder ar-

ranged by author (that implies one folder for one au-

thor), by executing ls, MMFS executes the command

as a run time query (select ... ) to the db of the infor-

mation related to the author and show them in a ﬁle

system fashion. MMFS is high customizable in fact

it’s possible to query the database in a conﬁgurable

and easy way thanks MMFS language, but the access

to a db is not costless. From one other side Hixosfs

doesn’t query a db to search for metadata but keeps

them in the inode itself can move inside the folders

with ls command faster as in table 1.

5.2 Xattr vs Hixosfs

As introduced earlier, Xattr is a Linux feature to sup-

port extended ﬁle attributes. To use Xattr means to

compile the kernel with the support of such tags, to

create the fs with extended attributes and mount the

fs with mount -o remount,user xattr what where, then

to use ad hoc programs to read and write the extended

attributes. To deal with extended attributes we used

attr that allows to speciﬁes different options to read

and write attribute values; The way we used this com-

mand is like in the following example:

• attr -s autore -V Valore

/mnt/Musica/mia musica.ogg: creates the couple

(autore, Valore) for the musical ﬁle musica.ogg;

• attr -g autore /mnt/Musica/mia musica.ogg:

allows to read the couple of values associated to

the attribute autore;

• attr -l /mnt/Musica/mia musica.ogg: allows

to read all the couple attribute values;

To populate the fs with extended attributes we created

a read Xattr script that recall attr -s command to

associate to each ﬁle of our testset the following at-

tributes: author, album, title, year. Then getXattr

script to read the attributes.

It seems relevant to compare now the operation

of extraction extended attributes thanks getXattr with

the hixosfs statmusic. This command is similar to the

THE HIXOSFS MUSIC APPROACH VS COMMON MUSICAL FILE MANAGEMENT SOLUTIONS

191

Table 2: Hixosfs vs xattr.

getXattr * statmusic *

29.725 sec 2.987 sec

the standard Unix user mode tool stat, specially the

output of stat is the list of tags content for each

input ﬁle, while in the case of statmusic musical

tags are showed too:

# statmusic Bohemian Rhapsody.mp3

File Name: Bohemian Rhapsody.mp3

Author: Queen

Title: Bohemian Rhapsody

Album: A Night at the Opera

Year: 1975

The time comparison result are in the table 2. As

you expect since the way hixosfs and xAttr physically

store and access tags, statmusic gives better perfor-

mances.

5.3 Open Read vs Hixosfs

Open Read is an ad hoc program that open a music

ﬁle, extract tags and then it shows them on the screen:

TagLib_File* tlf = taglib_file_new(argv[i]);

TagLib_Tag* tlt = taglib_file_tag(tlf);

printf("\nAlbum: %s", taglib_tag_album(tlt));

Open read uses the taglib library that works with

the standard system call fopen or/and lseek and print

on the screen with printf C standard function. We

compared the use of Open read with the use of

statmusic in hixosfs that recalls the system call

retag and read the tags directly from the inode and

shows them on the screen. Comparing the time spent

by both approach we had less then 1 second (0.03 sec)

needed from statmusic, respect 4.19 minutes re-

quired in the case of the ad hoc program.

6 CONCLUSIONS

This work comparison analysis shows that the faster

way to handle musical metadata, in term of time spent

to deal with, is when the tags management happens at

kernel level: the case of hixosfs and xattr feature.

Hixosfs music appears to be an innovative approach to

manage musical ﬁle tags at fs kernel level and it gives

higher performances when dealing with an huge num-

ber of ﬁles. If we think of a partion formatted hixosfs

that collect only musical data, hixosfs appears the best

performant solution. The huger advantage in time in

the case of hixosfs is because tags are stored inside

the inode and they are accessed by high priority ker-

nel space calls: the system calls. From the operating

system efﬁciency side a further disavantage is an in-

tuitive memory lost. In fact hixosfs music allocates

for each ﬁle memorization in the hixosfs formatted

partition, a 256 byte inode even if the ﬁle has to be

tagged with no attributes so better if we use hixosfs

only for a whole partition for musical data or as the fs

for embedded devices as ipod or mp3reader.// From

user side the problem is that the tags are ﬁxed at fs

design time even if here we chose the most common

tags for indexing musical data such as author, album,

year, title, that we extracted from musical ﬁle since

the use of taglib. As further development we imagine

to extend the inode with different kind of tags chosen

from the ﬁnal user and to implement user space com-

mands that can allow to the user to copy the tag in the

inode to the tag in the ﬁle and the opposite easily. In

the case of working with a fs in userspace as MMFS

or using xattr feature they had lower performances in

term of time but they offer high ﬂexibility for tag se-

lection and management. A further work can be to

extend fuse library to make it to offer an abstraction

layer over hixosfs music. Hixosfs design also can be

enriched to became a network fs well suited for the

musical ﬁles sharing and to simplify the indexing of

ﬁles inside the network.

REFERENCES

Hixosfs ﬁle system. http://www.di.uniba.it/hixos/hixosfs/

index.html. home page.

Corriero, C. Hixosfs music: a ﬁlesystem in linux kernel

space for musical ﬁles. MMEDIA 2009. home page.

Corriero, Cozza, D. t. Z. (SIGMAP 2008). A conﬁgurable

linux ﬁle system for multimedia data.

Remy Card, Theodore Ts’o, S. T.

http://e2fsprogs.sourceforge.net/.

Szeredi, M. (2008). Fuse. http://fuse.sourceforge.net. Home

page.

Wheeler, S. (2008). Taglib. http://developer.kde.org/

wheeler/taglib.html. Home page.

SIGMAP 2009 - International Conference on Signal Processing and Multimedia Applications

192
