MINING OF ASSOCIATION RULES FROM DISTRIBUTED DATA

USING MOBILE AGENTS

Gongzhu Hu and Shaozhen Ding

Department of Computer Science, Central Michigan University, Mount Pleasant, MI 48859, U.S.A.

Keywords:

Mobile agent, Distributed data mining, Privacy preserving.

Abstract:

In this paper, we propose an agent-based approach to mine association rules from data sets that are distributed

across multiple locations while preserving the privacy of local data. This approach relies on the local systems

to ﬁnd frequent itemsets that are encrypted and the partial results are carried from site to site. In this way, the

privacy of local data is preserved. We present a structural model that includes several types of mobile agents

with speciﬁc functionalities and communication scheme to accomplish the task. These agents implement the

privacy-preserving algorithms for distributed association rule mining.

1 INTRODUCTION

More and more data analysis applications today, in-

cluding data mining, deal with data that are dis-

tributed across multiple locations rather than on a sin-

gle site. Various techniques have been developed in

recent years for distributed applications, such as data

warehousing, schema mapping and integration, and

mobile agents.

Security has always been a challenge in dis-

tributed applications. One of the security issues is

privacy-preserving. Although quite a number of ap-

proaches have been proposed in the past but few re-

search results have been reported using the mobile

agent technique for distributed data mining tasks and

preserving privacy.

In this paper, we present an agent-based archi-

tecture for distributed association rule mining. The

architecture involves several mobile agents, each of

which performs some speciﬁc functions for the data

mining task. These functions implements the exist-

ing privacy-preserving distributed data mining algo-

rithms. Our implementation of this architecture and

experiments show that the proposed approach pro-

duces the correct results and the privacy of data at

individual sites are protected while the mobile agents

carry the data traveling across the network.

2 DISTRIBUTED MINING OF

ASSOCIATION RULES

The Fast Distributed Algorithm (FDM) (Cheung

et al., 1996) was one of the approaches dealing with

the issue of efﬁciently mining on the distributed sites.

The work in (Kantarcioglu and Clifton, 2004) devel-

oped a encryption scheme to achieve privacy preserv-

ing for DDM. Our mobile agent method is based on

these previous work, hence we brieﬂy review them

here.

2.1 Basic Notations

The notations and terminologies for distributed as-

sociation rule mining are similar to regular (non-

distributed) mining, but with extensions to represent

the local-vs-global situation.

site i

s minimum support threshold

globally frequent k-itemsets

i(k)

globally frequent k-itemsets at site S

i(k)

Locally frequent k-itemsets in C

i(k)

candidate sets generated from F

i(k−1)

X.sup

Local support count of itemset X at site S

2.2 Globally and Locally Frequent

Itemsets

One of the properties related to frequent itemsets is

Hu G. and Ding S. (2009).

MINING OF ASSOCIATION RULES FROM DISTRIBUTED DATA USING MOBILE AGENTS.

In Proceedings of the International Conference on e-Business, pages 21-26

DOI: 10.5220/0002231600210026

 SciTePress

that every globally frequent itemset must be locally

frequent at some sites. If an itemset X is globally fre-

quent and also locally frequent at a site S

, X is called

globally frequent at site S

. The set of global frequent

itemsets at a site will form a basis for the site to gen-

erate its own candidate sets.

Another two properties involve an itemset and all

of its subsets. First, if an itemset X is locally frequent

at site S

, then all of its subset is also locally frequent

at site S

. Second, if an itemset X is globally frequent

at a site S

, then all of its subsets are also globally

frequent at site S

In the FDM algorithm, the locally frequent k-

itemsets F

i(k)

and globally frequent k-itemsets F

i(k)

site S

can be seen by other sites, and hence need pro-

tection, commonly by cryptographic techniques.

2.3 Encryption Scheme

Like other distributed computing tasks, cryptographic

techniques should apply to distribute data mining to

protect of data privacy. A revised version of FDM was

proposed in (Kantarcioglu and Clifton, 2004) that re-

placed the “support count exchange” step in the origi-

nal FDM by what are called Secure Union and Secure

Sum.

Secure union means that each site participates in

both encryption and decryption of F

i(k)

. In other

words, each site S

will hold an encryption-description

key pair (e

), and F

i(k)

will be encrypted by e

generate F

ei(k)

. The union of all the F

ei(k)

is then

calculated as F

e(k)

n−1

i=0

ei(k)

. This value is then

decrypted by each site’s decryption key d

and we

can get the result as F

(k)

. However, we don’t know

whether the items in F

(k)

are globally supported, in

which we need to calculate the sum of the item

counts securely. Secure union involves a notion called

“commutative encryption” for an encryption model in

which all the parties participates in both encryption

and decryption. The detailed algorithm for secure

union is given in (Kantarcioglu and Clifton, 2004).

Secure sum is an algorithm to get the sum of

items’ support count in every site in a secure way.

Assuming that we have n sites and an item x, the task

is to obtain

∑

i=1

x.sup

and protect x.sup

from other

sites. Each site generates a random number r

added

to x.sup

and sends the sum to the next site and the

following sites will do the same. At the last site, we

get the

∑

i=1

x.sup

∑

i=1

. This value then travels

through all the sites, and the random number r

is sub-

tracted from the sum at each site. The ﬁnal result will

∑

i=1

x.sup

as desired.

The privacy-preserving distributed association

rule mining algorithm is separated into two parts:

(1) computing

∑

n−1

i=0

i(k)

, and (2) testing whether x ∈

∑

n−1

i=0

i(k)

is globally supported.

3 AGENT-BASED MODEL

Mobile agents are the basis of an emerging technol-

ogy that promises to make it much easier to design,

implement and maintain distributed systems (Lange

and Oshima, 1998a), (Lange and Oshima, 1998b).

Because of the special characteristics, mobile agents

are very suitable for distributed data mining. Based

on the privacy-preserving method discussed in Sec-

tion 2, we propose a structural model of six types of

agents to work together for the data mining task.

3.1 Agents and their Functionalities

We proposed three objects in our agent framework:

local host, agent server and agent. There are many

local hosts and agents, and an agent server that com-

municates with the local hosts through agents.

3.2 Agents

We deﬁne six types of agents to be used in our scheme

as described below.

Encrypt Secure Union Agent (ESUA)

This agent tries to coordinate the n hosts to participate

encryption of each F

i(k)

(locally frequent k-itemset at

host i). It carries the following necessary information:

a. Mining task description “secure union”;

b. Prime number p for the encryption schema;

c. Host address list;

d. An array, P, of (itemset, item

label) pairs, where

each item

label is uniformly distributed between

0 and p− 1 and represents one itemset;

e. Support count s.

Once the host obtains this information from the

agent, it will scan the local database and calculate

i(k)

. At the same time, the host randomly generates

the encryption and decryption keys (e,d) by using the

prime number p. For every x ∈ F

i(k)

the host searches

P to get an integer P

, and calculates C

= P

mod(p)

for encryption. After the agent gets the encrypt re-

sult C

= ∪

j=0

, where m is the size of F

i(k)

, it will

perform some internal computation and migrate to the

next host. Other hosts accept the array of integers C

and encrypt it with their own encryption keys. There

ICE-B 2009 - International Conference on E-business

are n ESUA agents working in the network at the same

time in each itinerary of mining k-itemset, because

each host generates one F

i(k)

Decrypt Secure Union Agent (DSUA)

Once all the ESUAs come back to the Agent Master,

the master is able to create C =

∑

n−1

i=0

, the union of

ciphers in each host, as an array. The DSUA carries

the integer array C of C

’s and travels through every

host to pursue decryption. The information carried by

this agent includes:

a. Mining task description “decrypt union”;

b. Host address list;

c. Cipher list C.

When the host accepts this agent, it decrypts each

∈ C in the cypher list as D

= C

mod(p), while

d is the decryption key and p is the prime number

generated at the host. The new array D = ∪

will

be carried by the agent.

Encrypt Sum Agent (ESA)

An Encrypt Sum Agent will carry Rule Set that con-

tains pairs of item

label, count. It travels through all

the hosts to obtain the encrypted support count. The

information the ESA carries includes:

a. Mining task description “secure sum”;

b. Host address list;

c. An array of RuleSet {item label

,count

};

d. A large integer m that satisﬁes m > 2|DB|.

The host generates a random number, R

, uni-

formly distributed between 0 to m− 1 for each Rule-

Set. At the same time, it scans the local database to

calculate the local support count sup

for each item in

the RuleSet as

(count

← R

− s× |DB

| + sup

+ count

) mod m.

(1)

This number will be passed to the next host for a sim-

ilar operation. There will be one ESA agent working

in the process of ﬁnding the k frequent itemset.

Decrypt Sum Agent (DSA)

Decrypt Sum Agent carries the array of RuleSet ex-

tracted from the returned ESA agent. It travels

through all the hosts and let each host subtract the ran-

dom number they generate when dealing with ESA.

The information DSA carries includes:

a. Mining task description “decrypt sum”;

b. Host address list;

c. An array of RuleSet {item

label

,count

};

Each host applies count

← count

− R

and sets

the changed RuleSet back to the agent. The agent mi-

grates to the next host for decryption.

Broadcast Agent (BA)

When DSA comes back to the agent master, the glob-

ally frequent k-itemsets F

can be calculated from the

decrypted RuleSet. In order to let each host calculate

i(k)

and C

i(k)

, BA is used to carry F

to every host.

The information BA carries includes:

a. Mining task description “broadcast”;

b. F

BA does not request any data from the host; it just

notiﬁes host that the current global frequent k-itemset

has been calculated and asks the host to prepare F

i(k)

for next iteration. There are n BAs for each of the k

iterations. BA agents help to reduce the number of

candidate itemsets. When a BA arrives at a local host,

the host machine calculates C

i(k)

based on F

i(k)

, while

the size of C

i(k)

is usually smaller than the global can-

didate k-itemset C

Over Agent (OA)

Once Agent Master found that either all the RuleSets

extracted from DSA are not globally supported or the

size of C

i(k)

is 0, it will dispatch this OA agent to no-

tify the hosts that the algorithm has terminated.

3.3 Agent Master (Server)

The agent master has two primary functions: activate

an agent server to perform the needed task; create new

agents and dispatch them to remote hosts. The actions

taken by the agent server is given in Algorithm 1.

Each of the actions is performed according to the

encryption scheme described in section 2.3.

3.4 Host

Each host machine performs local association rule

mining and the encryption/decryption operations

upon the arrival of different types of agents. These

operations are based on the description given in sec-

tion 3.2. For example, the action “Encrypt secure sum

agent” looks like this:

Extract rs ← A.task.RuleSet and

m ← A.task.m from A;

Generate a random number array R uniformly

distributed in [0, m− 1];

for i = 0 to rs.size− 1

support

count ← the support count of

itemset that matches rs[i].item label;

MINING OF ASSOCIATION RULES FROM DISTRIBUTED DATA USING MOBILE AGENTS

Algorithm 1: Agent server.

begin1

Decide frequent 1-itemsets and a prime2

number p;

Assign a item

label for each itemset;3

Create n ESUA agents for n hosts;4

for i = 0 to n− 1 do5

Create one thread to dispatch ESUA[i];6

end7

Receive agent A;8

switch A.description do9

case “Secure Union”: secure union;10

case “Decrypt Union”: decrypt union;11

case “Secure Sum”: secure sum;12

case “Decrypt Sum”: decrypt sum;13

case “Broadcast”: broadcast;14

case “Over”:15

if all OAs have returned back then16

Terminate.17

end18

end19

rs[i].count ← (rs[i].count + R[i]

+support

count

−s× |DB

|) mod m;

Pass rs to A and A migrates to next host;

4 EXPERIMENTS AND RESULTS

We have conducted several experiments to apply the

proposed agent approach to perform association rule

mining on data sets of various sizes. Because the

methods of extracting association rules from a fre-

quent itemset with a given support and conﬁdence

thresholds are the same with or without using agent

approach, we only show the calculation of the fre-

quent itemsets and will not go further to show the as-

sociation rules.

4.1 Data Set

The data set is a table that records 7985 transac-

tions of the banking services. The task of associa-

tion rules mining is to ﬁnd the relationships between

different kinds of banking services. In this table, the

columns (HMEQC, CKCRD, MMDA, etc.) represent

13 different banking services. This database table

uses Boolean value to show whether a banking ser-

vice exists in a transaction. A sample data is shown

in Table 1. The dataset is distributed across three

sites with 2034, 2013 and 3938 records, respectively.

The items’ names are those banking services as the

column names in Table 1. An item

label is gener-

ated along with the name of each of the banking ser-

vices. For example, the item

label for HMEQLC is

2373416.

The agent server uses a prime number p =

5555527 and the support threshold s = 5%. The en-

cryption and decryption keys at the three sites are

(757019, 4119587), (952657, 1364743) and (555557,

3409073), respectively. Due the page limitation, we

only show the details of the process for generating the

frequent 1-itemsets.

4.2 Frequent 1-Itemsets

The locally frequent 1-itemsets and their support

counts at the three site S

, S

, and S

are shown in

Table 2.

The agent server dispatches three ESUAs to every

host to perform encrypt secure union. We will brieﬂy

show the process for one item, HMEQLC, with its

item

label 2373416. According to the algorithm de-

scribed before, the item label is encrypted at the three

sites as:

: 2373416

757019

(mod 5555527) = 542566

: 542566

952657

(mod 5555527) = 3334375

: 3334375

555557

(mod 5555527) = 589086

The three DSUAs will decrypt the secret

“item

label” 589086 using their decryption keys as

: 589086

4119587

(mod 5555527) = 4644358

: 4644358

1364743

(mod 5555527) = 4213937

: 4213937

3409073

(mod 5555527) = 2373416

We can see that after leaving S

, the item label

is recovered back to 2373416 that is cast to the item

HMEQLC. The other items go through the same en-

crypt and decrypt process, and the ﬁnal item

labels

map to the correct item names.

In the next step, we use “secure sum” to test

whether these locally frequent itemsets are also glob-

ally frequent. The agent server sends an ESA (En-

crypt Sum Agent) with an integer m = 20000 that is

larger than 2 × |DB|. The count ﬁeld will be modi-

ﬁed securely at each host according to Equation (1).

Let’s take an example of 2373416 that represents

HMEQLC. The initial RuleSet is (item

label, count) =

(2373416, 0). With the random numbers for the item

HMEQLC at the three sites 11510, 5914, and 18213,

the secure sum calculations for the support counts are

ICE-B 2009 - International Conference on E-business

Table 1: Transaction data table (a small fraction of 7,985 transactions).

Trans. id HMEQC CKCRD MMDA PLOAN AUTO ATM SVG CD MTG IRA TRUST CKING CCRD

513394 0 0 0 0 0 0 0 0 0 0 0 1 0

513414 1 0 1 0 0 1 1 0 0 0 0 1 0

513421 0 0 0 0 1 1 1 0 1 0 0 1 0

513479 0 0 1 0 0 0 0 0 0 0 0 1 0

513660 0 0 0 0 0 1 1 0 0 0 0 1 0

513865 0 0 0 0 0 0 1 0 0 0 0 1 0

513708 0 0 1 0 0 1 0 1 0 0 0 1 0

513822 1 0 0 1 1 0 1 0 0 0 0 1 0

513862 0 0 0 0 0 1 1 0 0 0 0 1 0

513972 0 0 0 0 0 1 1 1 0 1 0 1 0

513983 1 0 0 0 0 1 1 0 0 1 0 1 0

514019 0 0 0 0 0 1 1 0 1 0 0 1 0

514122 0 1 0 0 1 0 1 0 0 0 0 1 1

514126 0 0 1 0 0 1 0 0 0 0 0 1 0

514153 1 0 0 0 0 0 1 1 0 0 1 1 0

514172 0 0 0 0 0 1 0 0 0 0 0 1 0

514472 0 0 0 0 0 1 0 0 0 0 0 1 0

... ... . . . ... ... ... ... ... ... ... ... . . . ... .. .

Table 2: Locally frequent 1-itemsets and support counts.

1(1)

at S

2(1)

at S

3(1)

at S

HMEQLC 335 HMEQLC 334 HMEQLC 667

CKCRD 249 CKCRD 221 CKCRD 442

AUTO 189 AUTO 198 AUTO 355

ATM 787 ATM 791 ATM 1495

SVG 1247 SVG 1255 SVG 2441

CD 476 CD 526 CD 957

MTG 179 MTG 135 MTG 280

IRA 207 IRA 226 IRA 433

CKING 1761 CKING 1735 CKING 3358

CCRD 315 CCRD 31 CCRD 591

TRUST 109

: (0 + 11510 + 335 - 2034 × 0.05) mod 20000

= 11743

: (11743 + 5914 + 334 - 2013 × 0.05) mod 20000

= 17890

: (17890 + 18213 + 647 - 3938 × 0.05) mod 20000

= 16553

Then, three DSAs (Decrypt Sum Agent) at the

three sites proceed as follows:

: (16553− 11510) mod 20000 = 5043

: (5043 − 5914) mod 20000 = 19129

: (19129− 18213) mod 20000 = 916

Since the result support count for the item HME-

QLC is 916, which is less than m/2, HMEQLC is in-

cluded in the globally frequent 1-itemsets F

. Sim-

ilarly, the same procedure applies to the other items

in Table 2. Eleven of the 12 items, except (TRUST,

19990) that has a support count 19990 larger than

m/2, are identiﬁed as globally frequent after the pro-

cess. This result is the same as the case when the

Aprior algorithm is applied when all transactions are

on one site rather than distributed. Note that neither

the encrypt sum nor the decrypt sum operation reveals

the local information during the process.

Next, the agent server dispatches BA (Broadcast

Agent) to each host and lets them generate F

i(1)

. As

the result, all the 11 globally frequent 1-itemsets are

also locally frequent at each host. That is, F

i(1)

= F

for i = 1,2,3.

We also calculated frequent 2, 3, and 4-itemsets

and the results are also the same as the non-distributed

case.

From the global k-itemsets, generation of associ-

ation rules is straightforward and we do not show the

results here.

5 RELATED WORK

A research ﬁeld referred to as distributed data mining

(DDM) that is expected to perform partial analysis of

data at individual sites and combine those results to

obtain the global results (da Silva et al., 2006).

The privacy-preservingproblem in DDM has been

a research topic for some time. Early work on this is-

sue can be found in (Clifton and Marks, 1996), for

example. Metrics for quantiﬁcation and measurement

of privacy preserving data mining algorithms was pro-

posed in (Agrawal and Aggarwal, 2001). The pa-

per (Rizvi and Haritsa, 2002) presented a scheme to

achieve a high degree of privacy and at the same time

retain a high level of accuracy in the mining results.

A revised version of FDM was proposed in (Kantar-

cioglu and Clifton, 2004) that included an encryption

MINING OF ASSOCIATION RULES FROM DISTRIBUTED DATA USING MOBILE AGENTS

scheme to preserve privacy.

Mobile agent as one of the models for distributed

applications has been used for data mining tasks. Sev-

eral agent-based data mining methods were devel-

oped, such as creating an accurate global model using

a modiﬁed decision tree algorithm (Baik et al., 2005),

and a bidding mobile agent scheme (Peng et al., 2005)

to achieve privacy. The paper (Cartrysse and van der

Lubbe, 2004) addressed the privacy problems in agent

technology and offered several solutions.

6 CONCLUSIONS

Distributed data mining is one of the distributed appli-

cations for which there are potential risks of leaking

data privacy when distribute sites communicate to ob-

tain global knowledge. In this paper, we proposed an

agent-based approach to address this problem to mine

association rules securely from data resides across

multiple sites. The privacy preserving characteristics

of this approach relies on the encryption and decryp-

tion techniques that are applied to the calculation of

the union of the frequent k-itemsets and the sum of

the support counts. In the proposed method, several

types of agents are used to perform the encryption and

decryption of the secure union and secure sum oper-

ations. In an experiment with about 8,000 transac-

tions, the result (globally frequent k-itemset) by our

approach applied to the data distributed cross three

sites is the same as the result that would be obtained

from the Aprior algorithm with the same data reside

on a single host. And, the data carried by the agents

are scrambled, indistinguishable and only being en-

crypted and decrypted when all the hosts participate.

Although our agent system is capable of securely

computing the frequent itemsets, there are areas that

need further study such as system stability (e.g. re-

cover from single site crash) and security improve-

ment (e.g. trustworthiness of the agent server).

REFERENCES

Agrawal, D. and Aggarwal, C. C. (2001). On the de-

sign and quantiﬁcation of privacy preserving data min-

ing algorithms. In Proceedings of the 20th ACM

SIGMOD-SIGACT-SIGART symposium on Principles

of Database, pages 247–255. ACM.

Baik, S. W., Bala, J., and Cho, J. S. (2005). Agent based dis-

tributeddata mining. In Parallel and Distributed Com-

puting: Applications and Technologies, volume 3320

of Lecture Notes in Computer Science, pages 42–45.

Springer.

Cartrysse, K. and van der Lubbe, J. C. A. (2004). Privacy

in mobile agents. In IEEE First Symposium on Multi-

Agent Security and Survivability, pages 73–82. IEEE

Computer Society.

Cheung, D. W.-L., Ng, V. T. Y., Fu, A. W.-C., and Fu, Y.

(1996). Efﬁcient mining of association rules in dis-

tributed databases. IEEE Transactions on Knowledge

and Data Engineering, 8(6):911–922.

Clifton, C. and Marks, D. (1996). Security and privacy im-

plications of data mining. In ACM SIGMOD Work-

shop on Research Issues on Data Mining and Knowl-

edge Discovery, pages 15–19.

da Silva, J. C., Klusch, M., Lodi, S., and Moro, G. (2006).

Privacy-preserving agent-based distributed data clus-

tering. Web Intelligence and Agent Systems, 4(2):221–

238.

Kantarcioglu, M. and Clifton, C. (2004). Privacy-

preserving distributed mining of association rules on

horizontally partitioned data. IEEE Transactions on

Knowledge and Data Engineering, 16(9):1026–1037.

Lange, D. B. and Oshima, M. (1998a). Mobile agents with

Java: The Aglet API. World Wide Web, 1(3):111–121.

Lange, D. B. and Oshima, M. (1998b). Programming

and Deploying Java Mobile Agents Aglets. Addison-

Wesley Longman Publishing.

Peng, K., Dawson1, E., Nieto1, J. G., Okamoto1, E., and

Lpez, J. (2005). A novel method tomaintain privacy in

mobile agent applications. In Cryptology and Network

Security, volume 3810 of Lecture Notes in Computer

Science, pages 247–260. Springer.

Rizvi, S. J. and Haritsa, J. R. (2002). Maintaining data pri-

vacy in association rule mining. In Proceedings of

the 28th International Conference on Very Large Data

Bases, pages 682–693. ACM.

ICE-B 2009 - International Conference on E-business
