TRANSFORMATION OF ORGANIZATION OF SOFTWARE
REQUIREMENTS SPECIFICATIONS
Yusuke Matsuo and Atsushi Ohnishi
Department of Computer Science, Ritsumeikan University, 1-1-1 Noji-Higashi, Kusatsu, Shiga 525-8577, Japan
Keywords: Organization of Software Requirements Specification, Transformation of Software Requirements
Specification.
Abstract: Specific software functional requirements can be organized with different ways, such as user class oriented
organization, functional hierarchy oriented organization, stimulus oriented organization, and so on. User
class oriented software requirements specification is easy to understand for each class of the user’s
behaviours, but difficult to understand functional hierarchy. We adopt a controlled requirements language
named X-JRDL as a requirements language and propose a transformation method between two software
requirements specifications organized in different ways.
1 INTRODUCTION
In software development and maintenance, a
software requirements specification (SRS) is often
referred for revising requirements, designing
software, and modifying the specification. Specific
requirements of an SRS can be organized with
different ways (IEEE 1998). In (IEEE 1998) eight
templates of specific requirements of an SRS are
proposed. These are two temples organized by mode,
a template organized by user class, a template
organized by object, a template organized by feature,
a template organized by stimulus, a template
organized by functional hierarchy, and a template by
multiple organizations. Even if each of differently
organized SRSs specifies exactly the same software
requirements, the understandability of them are
different each other.
For example, user oriented SRSs may be
organized by user class, so readers who want to
know what kind of functions should be used by a
certain user and what kind of inputs should be
entered by a certain user prefer SRSs organized by
user class, while the readers cannot easily know
them in case of SRSs organized by functional
hierarchy. If an SRS organized by functional
hierarchy can be transformed into an SRS organized
by user class, the above problem can be solved, but
manual transformation of SRSs with different ways
is difficult in case of large SRSs especially.
Actually, only the section 3.2 of these templates
are different, but other sections are same each other
(IEEE 1998). The authors propose a method to
automatically transform SRSs of different
organizations and have developed a prototype
system based on the method.
2 REQUIREMEMTS LANGUAGE:
X-JRDL
We developed requirements model named
Requirements Frame and a text-base requirements
language named X-JRDL based on the model
(Ohnishi 1996). In this research we adopt X-JRDL
as a requirements language, since it is quite easy to
transform SRSs with X-JRDL organized differently.
Since X-JRDL aims to specify requirements of
file-oriented applications, this language provides 6
noun types (human, function, file, data, control, and
device) and 16 concepts including data flow, control
flow, data creation, file manipulation, data
comparison, and structure of data/file/function. The
16 concepts (10 verb type concepts and 6 adjective
type concepts) are shown in Table 1.
291
Matsuo Y. and Ohnishi A. (2009).
TRANSFORMATION OF ORGANIZATION OF SOFTWARE REQUIREMENTS SPECIFICATIONS.
In Proceedings of the 4th International Conference on Software and Data Technologies, pages 291-294
Copyright
c
SciTePress
Table 1: Concepts provided by X-JRDL.
Concept
Meaning
DFLOW
Data flow
CFLOW
Control flow
ANDSUB
And-tree structure
ORSUB
Or-tree structure
GEN
Data creation
RET
Retrieve a record in a file
UPDATE
Update a record in a file
DEL
Delete a record in file
INS
Insert a record in a file
MANIP
File manipulation
EQ, NE, LT, GT,
LE, GE
Logical operators
There are several verbs to represent one of these
concepts. For example, to specify a concept data
flow, we can use input, output, print out, display,
and send, and so on. Each concept has its own case
structure. The “cases” (Fillmore 1968) mean concept
about agents, objects, goals of the operations (Shank
1977). For example, the data flow (DFLOW)
concept has object, source, goal, and instrument
cases. The object case object corresponds to a data
which is transferred from the source case object to
the goal case object. So, a noun assigned to the
object case should be a data type noun. A noun in
the source or goal cases should be either a human or
a function type noun. If and only if a human type
noun is assigned to source or goal cases, some
device type noun should be specified as an
instrument case. These are illustrated in Fig. 1.
DFLOW
object
instrument
source
goal
deviceinstrument
function,
human
goal
function,
human
source
dataobject
noun typecase
Figure 1: Case structure of data flow (DFLOW).
When a user wants to write requirements of
another application domain, he may need a verb not
categorized into these 16 concepts. In such a case, he
can use a new verb if he defines its case structure.
Since a newly defined verb, its concept, and its
case structure can be registered in the verb
dictionary, he can use his own verbs as well as
provided verbs.
The case structure of each verb enables to detect
illegal usages of data and lack of cases. Suppose a
requirement sentence, "A user enters a retrieval
command with a terminal." Since the objective is “a
retrieval command” that is data type noun, “enters”
should be categorized into the DFLOW concept.
With the case structure of the DFLOW, this sentence
will be analyzed as shown in Table 2.
Table 2: Analysis of a requirement sentence "A user enters
a retrieval command with a terminal."
Concept: DFLOW
object
source
goal
instrument
retrieval
command
user
NOT
specified
terminal
In this sentence the goal case noun is not
specified. If indispensable case is not specified,
previously specified nouns of the same type become
candidates of the omitted case. In this way, a
requirement sentence is transformed into an internal
representation named CRD (Conceptual
Requirements Description). CRD is exactly based on
the case structures.
X-JRDL provides to use pronouns and omission
of nouns. We frequently come across such features
in Japanese sentences. The X-JRDL analyzer
automatically assigns a concrete word into a
pronoun or a lacked case.
The X-JRDL analyzer has a dictionary of nouns,
verbs and adjectives. When a requirements definer
uses a word which is not appeared in the dictionary,
the analyzer guesses a type of new noun and a
concept of new verb and adjective with the
Requirements Frame (Ohnishi 1996).
3 TRANSFORMATION OF SRS
ORGANIZATION
Specific requirements in SRS can be organized
differently and there exist several templates for SRS
(IEEE 1998). The section 3.2 of these templates are
different, but other sections are same each other. In
other words, only functional requirements are
differently specified.
As shown in section 2, each requirement
sentence with X-JRDL can be transformed into CRD
representation. We can express same requirement
sentence differently. For example, “User inputs
commands to system with keyboard” can be
ICSOFT 2009 - 4th International Conference on Software and Data Technologies
292
expressed as “System accepts commands from user
with keyboard” or “Commands form user with
keyboard are received by system.” These three
sentences can be transformed into the same CRD
representation. This fact means that the CRD
representation is independent of surface expression
and shows conceptual meaning. We can derive
surface expression depending on organizations from
CRD representation.
For the organization of user class, we focus on
human type nouns in an SRS with X-JRDL, because
these nouns are external users of the SRS. Then we
make sections for each of the nouns.
For the organization of stimulus, we focus on
requirements sentences of data flow. If a human type
noun is assigned as the source case object, a noun
assigned as the object case of the sentence can be
regarded as an external input. Then we make
sections for each of the external inputs.
For the organization of functional hierarchy, we
focus on function type nouns. Then we make
sections for each of the nouns. Figure 2 shows a part
of SRS of stock management system organized by
functional hierarchy.
1) Stock management system consists of stock-in
manager, stock-out manager, and stock file
manager.
1.1) Stock-in manager
It receives a control from stock managing
officer and also gets stock-in data including
item name and amount via keyboard, then with
them updates stock master file and returns the
control to stock managing officer.
1.2) Stock-out manager
It consists of retriever, stock-deliverer, and
orderer.
1.2.1) Retriever
It receives control from stock managing officer.
….
Figure 2: SRS organized by functional hierarchy.
X-JRDL analyzer first clarifies unknown words
by asking to describer, and then divides complex
sentences and compound sentences into simple
sentences each of which has just one verb. Next, it
transforms each simple sentence into internal
representation, namely CRD representation. Table 3
shows transformed eight CRD representations of the
SRS shown in Figure 2.
In order to transform into SRS of user class
organization, we focus on human type nouns. There
exists only one human type noun in the example.
Table 3: CRD representations.
1: concept
agent
object
object
object
2: concept
source
goal
3: concept
agent
object
object
4: concept
agent
source
goal
instrument
5: concept
agent
source
goal
6: concept
source
goal
7: concept
agent
object
object
object
8: concept
source
goal
That is stock managing officer. In Table 3, there
exist 4 CRD representations including “stock
management officer.” So, we can select these 4
representations and transform them into 4
requirements sentences whose subjects are stock
managing officer as shown in Figure 3.
1) Stock managing officer
Stock managing officer passes control to stock-
in manager and retriever. He enters stock-in
data to stock-in manager with keyboard. He
gets control from stock-in manager.
Figure 3: SRS organized by user-class.
In the above example, requirements including
stock managing officer are specified and other
requirements such as functional structures are
TRANSFORMATION OF ORGANIZATION OF SOFTWARE REQUIREMENTS SPECIFICATIONS
293
omitted. So, each class of the users can easily
confirm the correctness of transformed requirements.
Other requirements will be attached to the
transformed requirements in order to keep the
completeness of the SRS.
In order to transform into SRS of stimulus
organization, we focus on external inputs in the SRS.
There exists only one external input, that is, “stock-
in data.” There exist two representations including
“stock in data.” We can select the 3
rd
representation
and the 4
th
representation in Table 3 and transform
them into two requirements sentences whose
subjects are stock-in data as shown in Figure 4.
1) Stock-in data
Stock-in data consists of item-name and
amount. Stock-in data is transferred from
stock managing officer with keyboard to
stock-in manager.
Figure 4: SRS organized by external inputs.
In Figure 4, only external input is specified and it
is very easy to check what kind of functions receives
these inputs.
We have developed a prototype system based on
our method with Java. Although our system is based
on Japanese-base language, our method is
independent of Japanese language.
We applied our method to an SRS of stock
management system using the prototype system This
SRS consists of 27 requirements sentences with X-
JRDL and organized by functional hierarchy. We
transformed this SRS into SRS by user class and
SRS by stimulus correctly, but some requirements
such as functional hierarchy are not transformed,
because requirements of functional hierarchy are not
categorized into user-class requirements or stimulus
requirements.
4 RELATED WORKS
In (Nuseibeh, Kramer, and Finkelstein, 1994), they
claim that SRS is specified from multiple viewpoints
and propose a consistency check method among
requirements form different viewpoints.
In (Martinez, Arias, Vilas, 2005), they propose a
merging method of requirements described by
different stakeholders.
In (Heitmeyer, Jeffords, Labaw, 1996), authors
propose a consistency checking method of formally
specified SRS. The above three methods cannot
generate SRS of differently organized.
In the author’s previous work (Zhang and
Ohnishi, 2004), a scenario from a certain viewpoint
can be transformed into a scenario from a different
viewpoint. The previous method enables to
transform scenarios from different viewpoints, but it
cannot be applied to SRS transformation.
5 CONCLUSIONS
We have developed a transformation method for
SRS by different organizations. We can transform
SRSs by user-class, functional hierarchy, and
stimulus organizations. Automatic transformation of
SRSs will contribute to generate differently
organized SRSs of high quality and lessen efforts of
specifying differently organized SRSs.
In (IEEE 1998) more types of organizations are
specified. These are organization by mode,
organization by object, organization by feature. The
enhancement of the transformation method for SRS
by these three organizations is left as a future work.
REFERENCES
Fillmore C.J., 1968. The Case for Case, Universals in
Linguistic Theory, ed. Bach & Harrms, Holy, Richard
and Winston Publishing, Chicago.
Heitmeyer C., Jeffords R., Labaw B., 1996. Automated
Consistency Checking of Requirements Specifications,
ACM Transactions on Software Engineering and
Methodology (TOSEM), Vol.5, Issue 3, pp.231-261.
IEEE, 1998. IEEE Recommended Practice for Software
Requirements Specification, IEEE std 830-1998.
Martinez A., Arias J., Vilas A., 2005. Merging
Requirements Views with Incompleteness and
Inconsistency, IEEE Australian Software Engineering
Conference (ASWEC’05), pp. 58-67.
Nuseibeh B., Kramer J., and Finkelstein A., 1994. A
Framework for Expressing the Relationships Between
Multiple Views in Requirements Specification, IEEE
Transactions on Software Engineering, Vol.20, No.4,
pp.760-763.
Ohnishi A., 1996. Software Requirements Specification
Database based on Requirements Frame Model, IEEE
2
nd
International Conference on Requirements
Engineering (ICRE96), pp.221-228.
Shank R., 1997. Representation and Understanding of
Text, Machine Intelligence 8, Ellis Honrood Ltd.,
Cambridge, pp.575-607.
Zhang H., Ohnishi A., 2004. A Transformation Method of
Scenarios from Different Viewpoints, IEEE 11
th
Asia-
Pacific Software Engineering Conference
(APSEC2004), pp.492-501.
ICSOFT 2009 - 4th International Conference on Software and Data Technologies
294
