ISEE: AN INFORMATION SECURITY
ENGINEERING ENVIRONMENT
Jingde Cheng, Yuichi Goto and Daisuke Horie
Department of Information and Computer Sciences, Saitama University, 255 Shimo-Okubo, Sakura-Ku, Saitama, Japan
Keywords: Security engineering, Information security engineering environment, ISO/IEC security standards, Formal
methods.
Abstract: Security Engineering has some features that are intrinsically different from Software (Reliability)
Engineering. Traditional software engineering environments are not adequate and effective for designing,
developing, managing, and maintaining secure software systems. This position paper presents ISEE, an
information security engineering environment we are developing, that integrates various tools and provides
comprehensive facilities to support design, development, management, and maintenance of security
facilities of information/software systems continuously and consistently, and guides and helps all users to
perform their tasks regularly according to ISO/IEC security standards. The paper presents the basic ideas on
development of ISEE, basic requirements for ISEE, and a design of ISEE. ISEE is the first real information
security engineering environment.
1 INTRODUCTION
As opposed to Software (Reliability) Engineering to
provide principles, methodologies, and tools for
designing, developing, operating, and maintaining
reliable software systems (Finkelstein&Kramer,
2000, IEEE-CS, 1990, Naur&Randell, 1969),
Security Engineering intended to provide principles,
methodologies, and tools for designing, developing,
operating, and maintaining secure software systems.
Security Engineering has the following features
that are intrinsically different from Software
(Reliability) Engineering.
First, as Anderson pointed out, Software
(Reliability) Engineering is about ensuring that
certain things happen, while Security Engineering is
about ensuring that they do not (Anderson, 2008).
Second, the reliability of a target software system
is not necessarily an object of engineering that must
be managed and/or controlled continuously, while
the security of a target software system is
necessarily an object of engineering that must be
managed and/or controlled continuously. In general,
we do not need to continuously consider improving
the reliability of a target software system anytime,
except the system has some failure or some new
requirement is specified for the system. However,
because assailants (crackers) are active persons who
can get knowledge and skills day after day and then
continuously attack target software systems always
with new techniques, we have to continuously
consider improving the security of a target software
system anytime. This is particularly true in
designing, developing, operating, and maintaining
persistent computing systems (Cheng, 2005, 2005,
2006, 2007).
Third, the whole reliability of a target software
system is usually the sum total of reliability of its all
components, while the whole security of a target
software system is not necessarily the sum total of
security of its all components but usually only as
good and strong as the weakest security of some
component or link between components in the
system.
Traditional software engineering environments
(Devanbu&Stubblebine, 2000, Dittrich et al., 2000,
Finkelstein&Kramer, 2000, Harrison et al., 2000)
are not adequate and effective for designing,
developing, operating, and maintaining secure
software systems. To deal with those features in
Security Engineering that are intrinsically different
from Software (Reliability) Engineering, we have to
find new principles, establish new methodologies,
develop new tools, and integrates them into an
engineering environment for designers, developers,
administrators/end-users, and maintainers to design,
395
Cheng J., Goto Y. and Horie D. (2009).
ISEE: AN INFORMATION SECURITY ENGINEERING ENVIRONMENT.
In Proceedings of the International Conference on Security and Cryptography, pages 395-400
DOI: 10.5220/0002242103950400
Copyright
c
 SciTePress

develop, operate, and maintain secure software
systems.
We have proposed the general concept of an
information security engineering environment
(Cheng et al., 2008). However, no requirement
analysis and definition for a real information
security engineering environment has been done
detailedly and no real environment has been
designed and implemented.
This position paper presents ISEE, an
information security engineering environment we
are developing, that integrates various tools and
provides comprehensive facilities to support design,
development, management, and maintenance of
security facilities of information/software systems
continuously and consistently, and guides and helps
all users to perform their tasks regularly according to
ISO
/IEC security standards. ISEE is the first real
information security engineering environment.
The rest of this paper is organized as follows:
Section 2 presents our basic ideas on development of
ISEE, Section 3 presents basic requirements for
ISEE, Section 4 presents a design of ISEE, and some
concluding remarks are given in Section 5.
2 BASIC IDEAS ON
DEVELOPMENT OF ISEE
An Information Security Engineering
Environment is an engineering environment that
integrates various tools and provides comprehensive
facilities for designers, developers,
administrators/end-users, and maintainers of
information/software systems such that they can use
the tools and facilities to ensure the whole security
of the target system anytime consistently and
continuously (Cheng et al,. 2008). Note that the
major point we made in the above definition is “to
ensure the whole security of the target system
anytime consistently and continuously” that
emphasizes the wholeness of security of
information/software systems and the continuity and
randomness concerning time.
We are developing ISEE based on the following
considerations:
First, ISEE itself should be a persistent
computing system (Cheng, 2005, 2005, 2006, 2007)
to provide continuous supports for all users anytime.
Design, development, management, and
maintenance of security facilities of target systems
should be continuously performed. It is not enough
only to design and develop security facilities.
Continuous maintenance (maybe including re-design
and re-development) of target systems, in particular,
those persistent computing systems (Cheng, 2005,
2005, 2006, 2007), are very important for protecting
the systems from new attacks.
Second, ISEE should support all tasks in design,
development, management, and maintenance of
security facilities of target systems by guiding and
helping all users (designers, developers,
administrators/end-users, and maintainers of target
systems) to perform their tasks according to ISO
/IEC
security standards. Because the whole security of
any target system is only as good and strong as the
weakest link in the system, some common standards
shared and followed by all designers, developers,
administrators/end-users, and maintainers of target
systems are necessary to all tasks in engineering the
systems in order to ensure the strength of the whole
security of target systems. At present, the most
established and widely accepted common standards
are ISO
/IEC security standards (ISO/IEC, 2005,
2007, 2008).
Third, ISEE should support all users to use
formal methods as more as possible in design,
development, management, and maintenance of
security facilities of target systems. Because the
strongest security of any target system can be
obtained only by formal (mathematical) analysis and
verification, formal methods should be used by all
designers, developers, administrators/end-users, and
maintainers of target systems as more as possible in
design, development, management, and maintenance
of target systems. Therefore, supports for formal
methods in all tasks in engineering the systems
should be provided by ISEE.
Finally, ISEE should support all tasks of all users
consistently. Because the security of any target
system is required at all phases of the information
cycle, i.e., gathering, creating, processing, storing,
transmitting and deleting, the consistency among all
tasks of designers, developers, administrators/end-
users, and maintainers of target systems must be
kept and maintained. Therefore, all supports for all
tasks in engineering the systems must be consistent.
3 BASIC REQUIREMENTS FOR
ISEE
We analyzed and defined basic requirements that
ISEE should satisfy as follows:
R1: ISEE must provide tools and facilities to
continuously support all tasks in design,
development, management, and maintenance of
security facilities of target systems.
SECRYPT 2009 - International Conference on Security and Cryptography
396

The reason to require ISEE to satisfy
requirement R1 has been explained in Section 1 and
Section 2. Here “to continuously support” means
that ISEE should support all tasks in design,
development, management, and maintenance of
security facilities of a target system through the
whole lifetime of the system, and should be ready at
anytime for any request from any user.
R2: ISEE must provide tools and facilities for all
users to design, develop, manage, and maintain
security facilities of target systems regularly
according to ISO/IEC security standards.
To ensure the whole security of any target
system, some common standards for all components
of the system, all tasks in design, development,
management, and maintenance of security facilities
of the system, and all tools of ISEE are
indispensable. At present, ISO/IEC security
standards are the best choice. On the other hand,
maybe there is no ISO/IEC security standard
effective for some tasks. In those cases, it is needed
to look for other effective standards.
R3: ISEE must provide tools and facilities for all
users to use formal methods as more as possible in
design, development, management, and maintenance
of security facilities of target systems to check
whether the security facilities are certainly
consistent with ISO/IEC security standards or not.
The formal methods mentioned above may be
well established formal representation, verification,
or reasoning methods, originally provided by ISEE,
or developed by users themselves.
R4: ISEE must provide tools and facilities for all
users to perform their tasks in a guided regular
order.
The whole security of a target system is ensured
only if its designers, developers, administrators/end-
users, and maintainers perform appropriate tasks in a
regular order. To guide users to perform their tasks
in a previously defined regular order can decrease
failure in the target system.
R5: ISEE must provide tools and facilities for its
users to manage and maintain security facilities of
target systems as rapidly as possible.
Because any delay of response to crackers’
attacks must increase the possibility of information
leaks, falsification, or destruction, management and
maintenance of security facilities of target systems
should be performed as rapidly as possible.
4 DESIGN OF ISEE
We designed ISEE according to the above basic
requirements. First of all, based on ISO/IEC 12207
(ISO/IEC, 2008) we clarified concrete tasks in
design, development, management, and maintenance
of security facilities of target systems as follows:
Infrastructure Management
Human Resource Management
Quality Management
Risk Management
Information Management
Software Requirement Analysis
Software Architectural Design
Software Detailed Design
Software Implementation
Software Qualification Testing
Software Installation
Software Integration
Software Construction
Software Configuration Management
Software Operation
Software Maintenance
Software Disposal
Software Documentation Management
Software Quality Assurance
Software Verification
Software Validation
Software Review
Software Problem Resolution
Recovery
Environment Management
We also clarified ISO/IEC security standards for
the concrete tasks. Then, we defined a model of
software life cycle processes that specifies all tasks
with a right order in design, development,
management, and maintenance of security facilities
of target systems (Horie, 2009). Finally, we
specified functions of components of ISEE.
Fig. 1 shows all tasks with the right order and
Fig. 2 shows all components of ISEE and
relationships among them.
ISEE: AN INFORMATION SECURITY ENGINEERING ENVIRONMENT
397

Figure 1: Tasks with a right order in design, development, management, and maintenance.
Figure 2: Components of ISEE.
ISEE consists of the following components:
ISEDS is an information security engineering
database system that manages all common data in
ISEE (Horie, 2008). ISEDS manages data of
ISO/IEC security standards and their related
documents, data of published cases (e.g., STs, ISMS
documents, and so on), and data acquired by users in
their tasks. ISEDS is a main component of ISEE and
plays the most important role in ISEE. All users of
ISEE can easily retrieve and use data in ISEDS by
using various tools of ISEE.
Requirement analysis tool supports users to
create risk analysis documents.
SECRYPT 2009 - International Conference on Security and Cryptography
398

Requirement verification tool supports users to
formally verify requirement specification documents.
Requirement review tool supports stakeholders
to review requirement documents.
Design tool supports users to generate templates
of design specification documents.
Design verification tool supports users to
formally verify design specification documents.
Design validation tool supports users to validate
design specification documents.
Design review tool supports stakeholders to
review design specification documents.
Implementation tool supports users to create
source codes.
Implementation verification tool supports users
to formally verify source codes.
Implementation validation tool supports users
to validate source codes.
Implementation review tool supports
stakeholders to review source codes.
ST generation tool supports users to generate
templates of STs (Security Targets).
ST verification tool supports users to formally
verify STs.
ST validation tool supports users to validate STs.
ST review tool supports stakeholders to review
STs.
Risk detection tool receives information
acquired in management of target systems and
automatically detects risks that have not been
assumed in advance according to ISO/IEC security
standards.
Risk analysis tool supports users to create
documents of detected risks.
Disposal planning tool supports users to decide
plan of system disposal and generates documents for
disposal plan.
Problem resolution tool enumerates proposals
of problem resolution according to documents of
risk analysis and cases of problem resolution and
generates problem resolution documents.
Security control clause decision tool supports
users to create ISMS (Information Security
Management Systems) documents.
ST applying tool guides users to apply ST
certification.
ISMS applying tool guides users to apply ISMS
certification.
Recovery tool supports users to create
documents for recovery plan, and automatically
backup and recover data of information systems and
information assets.
Notification tool notifies stakeholders
information of system disposal and recovery.
5 CONCLUDING REMARKS
We have presented our basic ideas on development
of ISEE: an information security engineering
environment we are developing, basic requirements
for ISEE, and a design of ISEE. This position paper
presented our ongoing work. Some techniques and
tools have been developed (Horie, 2008, 2009, 2009,
Morimoto et al., 2007, 2008, Yajima et al. 2009) and
other techniques and tools are being developed.
In the future, an integrated engineering
environment combining ISEE and some traditional
software engineering environment will provide full
powerful supports for design, development,
operation, and maintenance of information/software
systems with high reliability and security
requirements.
REFERENCES
Anderson, R. J., 2008. Security Engineering: A Guide to
Building Dependable Distributed Systems, John Wiley
& Sons, 2nd edition.
Cheng, J., 2005. Connecting Components with Soft
System Buses: A New Methodology for Design,
Development, and Maintenance of Reconfigurable,
Ubiquitous, and Persistent Reactive Systems. In
Proceedings of the 19th International Conference on
Advanced Information Networking and Applications,
Vol. 1, pp. 667-672. IEEE Computer Society Press.
Cheng, J., 2005. Comparing Persistent Computing with
Autonomic Computing. In Proceedings of the 11th
International Conference on Parallel and Distributed
Systems, Vol. II, pp. 428-432. IEEE Computer Society
Press.
Cheng, J., 2006. Persistent Computing Systems as
Continuously Available, Reliable, and Secure
Systems. In Proceedings of the 1st International
Conference on Availability, Reliability and Security,
pp. 631-638. IEEE Computer Society Press.
Cheng, J., 2007. Persistent Computing Systems Based on
Soft System Buses as an Infrastructure of Ubiquitous
Computing and Intelligence (Invited Paper). Journal
of Ubiquitous Computing and Intelligence, Vol. 1, No.
1, pp. 35-41. American Scientific Publishers.
Cheng, J. Goto, Y., Morimoto, S., and Horie, D., 2008. A
Security Engineering Environment Based on ISO/IEC
Standards: Providing Standard, Formal, and Consistent
Supports for Design, Development, Operation, and
Maintenance of Secure Information Systems. In
Proceedings of the 2nd International Conference on
Information Security and Assurance, pp. 350-354.
IEEE Computer Society Press.
Devanbu, P. T., Stubblebine, S., 2000. Software
Engineering for Security: A Roadmap. In Proceedings
of the Conference on The Future of Software
ISEE: AN INFORMATION SECURITY ENGINEERING ENVIRONMENT
399

Engineering, International Conference on Software
Engineering, pp. 227-239. ACM Press.
Dittrich, K., Tombros, D., Geppert, A., 2000. Databases in
Software Engineering: A Roadmap. In Proceedings of
the Conference on The Future of Software
Engineering, International Conference on Software
Engineering, pp. 291-302. ACM Press.
Finkelstein, A., Kramer, J., 2000. Software Engineering: A
Roadmap. In Proceedings of the Conference on The
Future of Software Engineering, International
Conference on Software Engineering, pp. 3-22. ACM
Press.
Harrison, W., Ossher, H., Tarr, P., 2000. Software
Engineering Tools and Environments: A Roadmap. In
Proceedings of the Conference on The Future of
Software Engineering, International Conference on
Software Engineering, pp. 261-277. ACM Press.
Horie, D., Morimoto, S., Azimah, N., Goto, Y., Cheng, J.,
2008. ISEDS: An Information Security Engineering
Database System Based on ISO Standards. In
Proceedings of the 3rd International Conference on
Availability, Reliability and Security, pp. 1219-1225.
IEEE Computer Society Press.
Horie, D., Yajima, Kasahara, T., Goto, Y., Cheng, J.,
2009. A New Model of Software Life Cycle Processes
for Consistent Design, Development, Management,
and Maintenance of Secure Information Systems. In
Proceedings of the 8th IEEE/ACIS International
Conference on Computer and Information Science, to
appear, IEEE Computer Society Press.
Horie, D., Yajima, K., Azimah, N., Goto, Y., Cheng, J.,
2009. GEST: A Generator of ISO/IEC 15408 Security
Target Templates. Studies in Computational
Intelligence, to appear, Springer-Verlag.
IEEE Computer Society, 1990. IEEE Standard 610: IEEE
Standard Computer Dictionary – A Compilation of
IEEE Standard Computer Glossaries. IEEE Computer
Society Press.
IEEE Computer Society, 1990. IEEE Standard 610.12-
1990: IEEE Standard Glossary of Software
Engineering Terminology. IEEE Computer Society
Press.
ISO/IEC, 2005. ISO/IEC 15408-1:2005: Information
Technology - Security Techniques - Evaluation
Criteria for IT Security.
ISO/IEC, 2005. ISO/IEC 27001: Information technology -
Security techniques - Information security
management systems.
ISO/IEC, 2005. ISO/IEC 27002: Information technology -
Security techniques - Code of practice for information
security management.
ISO/IEC, 2007. ISO/IEC 27006: Information technology -
Security techniques - Requirements for bodies
providing audit and certification of Information
Security Management Systems.
ISO/IEC, 2008. ISO/IEC 12207: Systems and Software
Engineering Software Life Cycle Processes.
ISO/IEC, 2008. ISO/IEC 27000: Information technology -
Security techniques - information security
management systems - Overview and vocabulary.
ISO/IEC, 2008. ISO/IEC 27005: Information technology -
Security techniques - Information security risk
management.
Morimoto, S., Shigematsu, S., Goto, Y., Cheng, J., 2007.
Formal Verification of Security Specifications with
Common Criteria. In Proceedings of the 22nd Annual
ACM Symposium on Applied Computing, pp. 1506–
1512. ACM Press.
Morimoto, S., Shigematsu, S., Goto, Y., Cheng, J., 2008.
Classification, Formalization and Verification of
Security Functional Requirements. In V. Geffert et al.
(Eds.), SOFSEM 2008: Theory and Practice of
Computer Science, 34th Conference on Current
Trends in Theory and Practice of Computer Science,
Novy Smokovec, High Tatras, Slovakia, January 19-
25, 2008, Proceedings. Lecture Notes in Computer
Science, Vol. 4910, pp. 622-633. Springer-Verlag.
Naur, P., Randell, B., (Eds.), 1969. Software Engineering:
Report of a conference sponsored by the NATO
Science Committee, Garmisch, Germany, 7-11 Oct.
1968. NATO.
Yajima, K., Morimoto, S., Horie, D., Azreen, N. S., Goto,
Y., Cheng, J., 2009. FORVEST: A Formal
Verification Support Tool of Security Specifications
with ISO/IEC 15408. In Proceedings of the 4th
International Conference on Availability, Reliability
and Security, pp. 624-629. IEEE Computer Society
Press.
SECRYPT 2009 - International Conference on Security and Cryptography
400
