USING WORDNETS AND ONTOLOGIES

FOR TEXT-MEANING ASSIGNMENT

Implementation Details of the KYOTO Project First Phase

Aleˇs Hor´ak and Adam Rambousek

Faculty of Informatics, Masaryk University, Botanick´a 68a, 602 00 Brno, Czech Republic

Keywords:

Wordnet, Semantic network, Ontology, Fact extraction.

Abstract:

The vision of Semantic Web introduced ontologies as the main unifying tool for management of the knowledge

and semantic structure of text documents. However, linking the real text documents with the ontologies (of

various kinds and various degree of complexity) is still a matter of current research in knowledge representation

projects.

In this paper, we are presenting the work results of the KYOTO project database implementation. The goal of

the project is to provide a complex system for automatic processing of documents in order to extract known

facts, link them with shared ontology and use this knowledge for Question Answering about the document

topic.

We give details about the design and implementation of the KYOTO database, which interlinks national Word-

Net semantic networks with the general SUMO ontology to offer the basis of the future shared ontology.

1 INTRODUCTION

The standardization of the techniques of knowledge

representation and reasoning is driven by designing

and incorporating ontologies into the text processing

approaches (Mars, 1995). In the process of the design

of a knowledge processing system, one of the ﬁrst de-

cisions must be the choice of the level of complex-

ity of the applied ontological system. Current general

ontological systems range from an encyclopaedia-like

system Cyc (Lenat, 1995), through the predicate logic

based SUMO (Niles and Pease, 2001) to easily ex-

ploitable semantic networks based on the Princeton

WordNet (Fellbaum, 1998). The number of applica-

tions that are using these ontologies for the processing

of textual knowledge is proportionalto the level of the

ontology complexity – the more straightforward the

ontology is, the more projects make use of it.

In the following text, we describe the KYOTO

project (Vossen, 2008), which aims at a straightfor-

ward application of the WordNet like ontologies in

the multilingual form (denoted as the Global WordNet

Grid) and a shared common ontology corresponding

to the level of the Suggested Upper Merged Ontology

(SUMO) as the central knowledge backbone. The on-

tology here serves as a meaning description tool for

all the terms and facts that are extracted, compared

and stored within the KYOTO system.

2 THE KYOTO PROJECT –

WORDNETS, ONTOLOGIES

AND TEXT

WordNet semantic networks allow to express ba-

sic language relations

in a multigraph structure di-

rectly processable by computer systems in many use-

ful ways.

However, description of more complicated

structured knowledge, e.g. relations with more than

one participants, cannot be encoded in a WordNet-

standard way that could be further analysed and used

by computers.

In the KYOTO system, this (potential) drawback

of WordNet is solved by the idea of extending the

WordNet into a Global WordNet Grid of multiple lan-

guages with a shared ontology in the center. Interlink-

hyperonymy/hyponymy, synonymy/antonymy, holo-

nymy/meronymy, etc.

deriving sets of similar objects, classes of more general

objects or objects with opposite meaning

303

Horák A. and Rambousek A. (2009).

USING WORDNETS AND ONTOLOGIES FOR TEXT-MEANING ASSIGNMENT - Implementation Details of the KYOTO Project First Phase.

In Proceedings of the 4th International Conference on Software and Data Technologies, pages 303-307

DOI: 10.5220/0002243403030307

 SciTePress

Figure 1: The schema of the KYOTO database within the KYOTO system.

ing of national wordnets is not a new idea, it was in-

troduced e.g. in the EuroWordNet (Vossen, 1998) and

Balkanet (Christodoulakis, 2004) projects. In these

projects the “pivot,” i.e. the interlingual index, was

represented directly by the English WordNet. This

solution had several advantages and several disad-

vantages. From the point of view of the knowledge

analysis, the biggest disadvantage was that the lexical

knowledge structure was “hidden” in the English lex-

icon without the possibility to really extract it for the

purpose of further computer processing.

Since the ﬁrst publicly available WordNet, the

Princeton WordNet (Miller, 1990), more than ﬁfty

national wordnets have been developed all over the

world. However, the availability of the wordnets is

limited – that is also a reason why the idea of a com-

pletely free Global WordNet Grid has appeared.

It is a known fact that, for instance, the results

of EuroWordNet are not freely accessible though the

participants of the project have developed (and are de-

veloping) more complete and larger WordNets for the

individual languages. Practically the same can be said

also about the results of the Balkanet project. If one

wants to exploit WordNets for different languages it is

always necessary to get in touch with the developers

and ask them for the permission to use the WordNet

data.

Another reason for building and having the com-

pletely free Global WordNet Grid is the fact that the

particular WordNets can be linked to the selected on-

tologies (e.g. Sumo/Milo) and domains. This has al-

ready took place with the WordNets developed in the

Balkanet project. The links to the ontologies should

be provided for all WordNets included in the Global

WordNet Grid.

The KYOTO project will incorporate and expand

the Global WordNet Grid and will be the ﬁrst system

that exploits the beneﬁts of storing the deﬁnitions of

terms and facts in a computer processable logical sys-

tem using the Grid’s shared ontology.

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

304

Figure 2: Three national wordnets in the KYOTO Database Viewer.

3 THE KYOTO DATABASES

The KYOTO database is built over the DEBVisDic

application with the DEB server either set up at one

central locality or it can be set up by several KYOTO

partners. The DEB platform provides important back-

grounds for the KYOTO project universal features

(see Figure 1).

3.1 The DEB Architecture

The Dictionary Editor and Browser (DEB) plat-

form (Hor´ak et al., 2006; Hor´ak and Rambousek,

2007; Hor´ak et al., 2008) has been developed as a gen-

eral framework for fast development of wide range of

dictionary writing applications. The DEB platform

provides several very important foundations that are

common to most of the intended dictionary systems.

These foundational features include:

• a strict separation to the client and server parts

in the application design. The server part pro-

vides all the necessary data manipulation func-

tions like data storage and retrieval, data index-

ing and querying, but also various kinds of data

presentations using templates. The client part of

the application concentrates on the user interac-

tion with the server part, it does not produce any

complicated data manipulation. The client and

server parts communicate by means of the stan-

dard HTTP (or secured HTTPs) protocol.

• a common administrative interface that allows to

manage user accounts including user access rights

to particular dictionaries and services, dictionary

schema deﬁnitions, entry locking administration

or entry templates deﬁnitions.

• XML database backend for the actual dictionary

data storage. Currently, we are working with

the Oracle Berkeley DB XML (Chaudhri et al.,

2003; DB XML, 2007) database, which provides

a ﬂexible XML database with standard XPath and

XQuery interfaces. The DEB applications are not

limited to DB XML, because the database layer

can be replaced transparently without the need to

change the application itself.

Based on these common features several developed

and widely used dictionary applications have been

implemented, including the well-known WordNet ed-

itor DEBVisDic that has been used in several national

wordnets development recently (Czech, Polish, Hun-

garian or South African languages). With this evi-

dence, we believe that DEB is the right concept for

the KYOTO multilingual knowledge base.

3.2 The Database Implementation

In the DEB platform environment, all the wordnets

are usually stored on single DEBVisDic server. In

the KYOTO project, each WordNet is provided by

different project partner and each of them may have

different requirements (for example licensing issues).

Thanks to the client-server nature of the DEB plat-

form, KYOTO database can offer three possible types

of encapsulating wordnets in the server:

• a WordNet can be physically stored on the central

server. This is the traditional DEBVisDic setup

and offers the best performance.

USING WORDNETS AND ONTOLOGIES FOR TEXT-MEANING ASSIGNMENT - Implementation Details of the

KYOTO Project First Phase

305

Figure 3: SUMO and OWLWN ontology with the English WordNet.

• a WordNet can be stored on a DEBVisDic server

located at the WordNet owner’s institution. All

servers can then communicate with each other

(depending on the server setup). The central

server has only the knowledge of which server

to contact, instead of having the full WordNet

database stored locally, and all queries are dynam-

ically resolved over the Internet. This option may

be slower as it depends on the quality of connec-

tion to different servers and their performance. On

the other hand, the WordNet owner has full con-

trol over the displayed data and access permis-

sions.

• a mixed solution – some wordnets are stored on

central server and some are stored on their respec-

tive owners’ servers. This is just an extension of

the previous option. Again, the performance of

the whole system depends on the performance of

single servers, but the speed can be improved if

the most used wordnets are stored on the central

server.

The DEB framework provides several possibilities of

working with the WordNet data.

Basically, each WordNet can be presented to the

users in one of the following forms:

• by means of a simple purely HTML interface

working in anyweb browser. This interface is able

to display one WordNet dictionary or the same

synset in several WordNets. Synsets are displayed

using XSLT templates – the server can provide

several view of the synset data ranging from a

terse view up to a detailed view. The view can be

even different for each dictionary. An example of

such presentation of synsets in three WordNets is

displayed in Figure 2. This type of WordNet view

is probably the best for public anonymous access

to the KYOTO knowledge base, since it does not

need any installation of user software or packages.

• using the full DEBVisDic application. This appli-

cation needs to be installed as an extension of the

freely available Firefox web browser, but it offers

much more complex functionality than the web

access. Each WordNet is opened in its own win-

dow which offers several views of the WordNet

data (a textual preview, hypero/hyponymic tree

structures, user query lists or XML) and also the

possibility to edit the data (for users with the write

permissions).

• by means of a deﬁned interface of the DEBVis-

Dic server, the Application Programming Inter-

face (API). This way any external application

may query the server and receive WordNet entries

(in XML or other format) for a subsequent pro-

cessing.

• using the Term Editor – a Wiki-based WordNet

browser and editor developed within the KYOTO

project.

In all cases, users (or external applications) can au-

thenticate with a login and password over a secure

HTTP connection. Each user can be given a read-only

or read-write access to particular WordNets.

All the national WordNets are provided in Lexi-

cal Markup Framework (LMF) format (Francopoulo

et al., 2008). The DEBVisDic server is optimized for

its own WordNet format, so all the data are converted

from and to LMF using XSLT stylesheets. For batch

operations (importing and exporting the whole Word-

Net), a special application based on

libxml

(Veillard,

2002) is used, because this solution offers fast conver-

sion. For example, 80MB XML ﬁle takes two days to

including DEBVisDic or the Term Editor

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

306

convert using XSLT, and only 40 minutes using the

special conversion application.

3.3 Interlinking Wordnets and

Ontologies

All wordnets in the KYOTO database are interlinked

using the common central ontology. The solution is

not limited to one ontology only. At the current state,

SUMO and OWL-WN ontologies are used, both of

them are stored in the OWL format.

An ontology is either referenced from a synset, or

a user can browse it independently using the DEB

HTML interface (similar to the WordNet HTML in-

terface, see Figure 3). However, the ontology browser

is not based on the DEBVisDic WordNet browser,

because of the differences in structure and format.

It is a standalone module integrated to the KYOTO

database.

The ontology application allows the user to search

for classes, properties, descriptions and relations

within a single query.

4 CONCLUSIONS

This paper has presented the main ideas of developing

the multilingual Global WordNet Grid with a shared

knowledge ontology within the KYOTO project.

We have described the design and implementation

of the KYOTO database storing the wordnets and on-

tologies in a versatile DEB (Dictionary Editor and

Browser) server, which allows to abstract the actual

data structures and provides the requested high level

functionality to the system.

ACKNOWLEDGEMENTS

This work has been partly supported by the Min-

istry of Education of CR within the Center of basic

research LC536 and in the National Research Pro-

gramme II project 2C06009 and by the Czech Science

Foundation under the project 102/09/1842.

REFERENCES

Chaudhri, A. B., Rashid, A., and Zicari, R., editors (2003).

XML Data Management: Native XML and XML-

Enabled Database Systems. Addison Wesley Profes-

sional.

Christodoulakis, D. (2004). Balkanet Final Report. Univer-

sity of Patras, DBLAB. No. IST-2000-29388.

DB XML (2007). Oracle Berkeley DB XML web.

http://www.oracle.com/database/berkeley-db/xml.

Fellbaum, C., editor (1998). WordNet: An Electronic Lexi-

cal Database. MIT Press.

Francopoulo, G., Bel, N., George, M., Calzolari, N., Mona-

chini, M., Pet, M., and Soria, C. (2008). Multilingual

resources for NLP in the Lexical Markup Framework

(LMF). Language Resources and Evaluation Journal.

Hor´ak, A., Pala, K., and Rambousek, A. (2008). The Global

WordNet Grid Software Design. In Proceedings of

the Fourth Global WordNet Conference, Szeg´ed, Hun-

gary. University of Szeg´ed.

Hor´ak, A., Pala, K., Rambousek, A., and Rychl´y, P. (2006).

New clients for dictionary writing on the DEB plat-

form. In DWS 2006: Proceedings of the Fourth Inter-

national Workshop on Dictionary Writings Systems,

pages 17–23, Italy. Lexical Computing Ltd., U.K.

Hor´ak, A. and Rambousek, A. (2007). Dictionary Man-

agement System for the DEB Development Platform.

In Proceedings of the 4

International Workshop on

Natural Language Processing and Cognitive Science

(NLPCS, aka NLUCS), pages 129–138, Funchal, Por-

tugal. INSTICC PRESS.

Lenat, D. (1995). CYC: A large-scale investment in knowl-

edge infrastructure. Communications of the ACM,

38(11):33–38.

Mars, N. (1995). Towards very large knowledge bases. Ios

Press.

Miller, G. (1990). Five Papers on WordNet. International

Journal of Lexicography, 3(4). Special Issue.

Niles, I. and Pease, A. (2001). Towards a standard upper on-

tology. In Proceedings of the 2nd International Con-

ference on Formal Ontology in Information Systems,

pages 2–9. ACM New York, NY, USA.

Veillard, D. (2002). The XML C library for Gnome

(libxml). http://xmlsoft.org/.

Vossen, P., editor (1998). EuroWordNet: a multilingual

database with lexical semantic networks for European

Languages. Kluwer.

Vossen, P. (2008). KYOTO Project (ICT-211423), Knowl-

edge Yielding Ontologies for Transition-based Orga-

nization. http://www.kyoto-project.eu/.

USING WORDNETS AND ONTOLOGIES FOR TEXT-MEANING ASSIGNMENT - Implementation Details of the

KYOTO Project First Phase

307
