SOFTWARE PRODUCT LINE TESTING

A Systematic Review

Beatriz P´erez Lamancha

Software Testing Centre (CES), School of Engineering

University of the Republic,Montevideo, Uruguay

Macario Polo Usaola, Mario Piattini Velthius

Alarcos Research Group, Information Systems and Technologies Department

University of Castilla-La Mancha, Ciudad Real, Spain

Keywords:

Testing, Software product line, Systematic review.

Abstract:

Software product lines constitute a new paradigm where industrial production techniques are adapted and ap-

plied to software development. Reuse and the maintenance of traceability between the different artefacts in the

line are fundamental requirements in this paradigm, articulating the best practices for software development in

an environment that is perfectly controlled by software engineering methods. This article presents a system-

atic review of the literature which deals with testing in software product lines. The objective is to analyse the

existing approaches to testing in software product lines, discussing the signiﬁcant issues related to this area

of knowledge and providing an up-to-date state of the art which can serve as a basis for innovative research

activities. The paper also analyses how SPL research can contribute and dynamise the research in software

testing.

1 INTRODUCTION

A software product line (SPL) is a set of software-

intensive systems sharing a common, managed set of

features that satisfy the speciﬁc needs of a particu-

lar market segment or mission and that are developed

from a common set of core assets in a prescribed way

(Clements and Northrop, 2002). In Europe, the term

product family (PF) or system family (SF) is used

to refer to an SPL (van der Linden, 2002). In soft-

ware engineering, SPL represents a recent develop-

ment paradigm, in which the reuse is proactive and

predictive and not opportunistic as with classic devel-

opment (in which, typically, the software is ﬁrst con-

structed and encapsulated and then reuse is consid-

ered) (McGregor et al., 2002; Krueger, 2006). SPL

development requires the intensive use of models,

processes, automated support, etc., all with the goal

of having the SPL investment (which will be high)

and its corresponding products (which will be lower

than classic development) recompense the individual

development of each product. In SPL, the best prac-

tices and techniques in Software Engineering will be

articulated and applied. The research and state of the

art must be improved and integrated in this context.

Recently, Bertolino (Bertolino, 2007) presented a

general analysis of the state of the art in testing re-

search which serves as a roadmap for the most rel-

evant challenges. This work begins with some im-

portant past achievements, while its destination con-

sists of four identiﬁed goals which research tends, but

which remain unreachable. She calls these dreams.

The routes from achievements to dreams are paved

by outstanding research challenges. The four dreams

are: universal test theory, test-based modelling, 100

percent automatic testing and efﬁcacy-maximized test

engineering. She also distinguishes the transversal

challenges that run through all four of the identiﬁed

dreams. One of them is testing within the emerging

development paradigm, in which the software prod-

uct line can be categorised.

This work presents a systematic review of the lit-

erature (Kitchenham, 2004) which deals with testing

in software product lines. Our objective is to analyse

the existing approaches to testing in software prod-

uct lines, discussing the signiﬁcant issues related to

Pérez Lamancha B., Polo Usaola M. and Piattini Velthius M. (2009).

SOFTWARE PRODUCT LINE TESTING - A Systematic Review.

In Proceedings of the 4th International Conference on Software and Data Technologies, pages 23-30

DOI: 10.5220/0002248400230030

 SciTePress

this area of knowledge and providing an up-to-date

state of the art that can serve as a basis for innovative

research activities. As mentioned earlier, SPL artic-

ulates and applies the best practises and techniques.

This work also analyses whether SPL can help to

achieve the challenges deﬁned by Bertolino to reach

the four dreams in testing research.

The paper proceeds as follows: Section 2 presents

the steps followed to do the systematic review, show-

ing the inclusion and exclusion criteria. Section 3

categorises and summarises the primary studies found

following the systematic review. Section 4 studies the

way in which the studies found in software product

line testing help to achieve the testing challenges de-

ﬁned by Bertolino. Finally, the conclusions are out-

lined and future work is described.

2 SYSTEMATIC REVIEW

A systematic literature review is a means of iden-

tifying, evaluating and interpreting all available re-

search relevant to a particular research question, topic

area or phenomenon of interest (Kitchenham, 2004).

We followed the guidelines deﬁned by Kitchenham

(Kitchenham, 2004), the template deﬁned by Biol-

chini et al. (Biolchini et al., 2005) and the procedure

deﬁned by Pino et al. (Pino et al., 2007) for the pri-

mary studies selection (there are the individualstudies

contributing to a systematic review, which is a form

of secondary study). The goal of this systematic re-

view is to identify experience reports and initiatives

carried out in Software Engineering related to testing

in software product lines. The question is: Which ini-

tiatives have been carried out to deal with testing in

the Software Product Lines? The keywords identiﬁed

and their synonyms are the following:

• Software Product Line: product line, software

product lines, product families, product family,

software family, system families

• Testing: test

With these keywords, the search string deﬁned

was:

((”product line” OR ”software product lines” OR

”product families” OR ”product family” OR ”soft-

ware family” OR ”system families” ) AND (”testing”

OR ”test”))

Only studies written in English were included.

The source search method was to research each of the

selected sources using web search engines. The se-

lected source list of electronic databases is:

• SCOPUS document database

(http://www.scopus.com),

• Science@Direct on the subject of Computer Sci-

ence (http://www.sciencedirect.com),

• Wiley InterScience on the subject of Computer

Science (http://www.interscience.wiley.com),

• IEEE Digital Library (http://www.computer.org)

• ACM Digital Library (http://portal.acm.org)

In addition to the source list, we hand-searchedthe

following projects and web pages:

• Engineering Software Architectures, Processes

and Platforms for System-Families - ESAPS

(http://www.esi.es/esaps/)

• From Concepts to Application in System-Family

Engineering - CAFE

(http://www.esi.es/Cafe)

• FAct-based Maturity through Institutionalisation

Lessons-learned and Involved Exploration of

System-family engineering - FAMILIES

(http://www.esi.es/Families)

• RITA - Environment for Testing Framework-

based Software Product Families

(http://www.cs.helsinki.ﬁ/group/rita)

• Franhoufer IESE, PuLSE

(http://www.iese.fraunhofer.de/)

• Software Engineering Institute, Product Line Sys-

tems Program

(http://www.sei.cmu.edu/programs/pls)

The inclusion criterion was based on the review of

the title, abstracts and keywords of the articles iden-

tiﬁed in the search. All the studies related to the

research topic were selected except editorials, pref-

aces, article summaries and summaries of tutorials,

workshops, panels and poster sessions. The proce-

dures for the deﬁnition of the studies is the follow-

ing: the search strings must be executed in the se-

lected sources. To select an initial set of studies, the

abstract of everything obtained from web search en-

gines is read and evaluated according to the exclusion

and inclusion criteria. To reﬁne this initial set of stud-

ies, their full text is read. The search strings were

adapted to the search engine for each source. Due to

the lack of standardisation between the electronic re-

sources, we had to implement the search strategy in-

dividually for each database. We applied the search

terms to the titles, abstracts and keywords of the ar-

ticles in the identiﬁed electronic databases. In some

database, we were not allowed to restrict the search to

those ﬁelds. In that case, we searched all the ﬁelds.

The results of the execution of the search strings in

each of the source databases is 23 primary studies. All

selected studies were assumed to be of high quality,

given that they were published in the selected sources.

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

This means that the accepted publications have gone

through a strict review procedure which guarantees

their quality.

3 SOFTWARE PRODUCT LINE

TESTING

This section summarises the information extracted in

the systematic review and presents the state of the art

relating to testing in software product lines. The pri-

mary studies were categorised in:

• Unit Testing (UT)

• Integration Testing (IT)

• Functional Testing (FT)

• SPL Architecture Testing (AT)

• Embedded systems Testing (ET)

• Testing Process (TP)

• Testing effort in SPL (TE)

Once the primary studies were chosen, extraction

of the relevant information for the systematic review

was carried out. The extracted information is sum-

marised in Table 1 which shows - for each paper -

the category, how variability is dealt with, the testing

technique used, if there is a tool or prototype to sup-

port it, if an example is shown, if the proposal was

tested in an artiﬁcial setting and if the proposal was

tested in an industrial setting.

A huge interest in SPL testing level is seen in the

papers found. In particular, functional testing and

variability testing with UML models and use cases

are the most popular topics. Several proposals ex-

ist for test automation but they are generally proto-

types. Overall, there are very few experiments or case

studies documented that put theoretical proposals into

practise. The studies relating to testing processes in

SPL are guidelines, but there is no testing process de-

ﬁned for SPL. In particular, topics like testing plan-

ning, effort and management are not included in the

existing literature.

In the following, a state ofthe art summary of soft-

ware product lines is presented, organised by the cat-

egories deﬁned above.

3.1 Unit Testing

There are no speciﬁc techniques for unit testing, only

recommendations which have not been tested in arti-

ﬁcial or industrial environments. McGregor (McGre-

gor, 2001) deﬁnes unit-test plans, test cases and re-

ports that become part of the documentation that ac-

companies a core asset. The software units must be

tested when the core assets are created.

3.2 Integration Testing

For integration testing McGregor (McGregor, 2001)

proposes two techniques that can be used to mitigate

the problem of testing the integration of all possible

combinations of all variations. Combinatorial test de-

signs can be used to greatly reduce the number of

combinations that need to be tested, while the other

technique is to perform integration testing incremen-

tally, in which case the number of combinations that

must be covered is much smaller. The RITA Tool,

presented in (Tevanlinna, 2004), is a prototype which

supports integration testing of product families and

frameworks. RITA works with the commonality and

variability in product families and the polymorphism

in framework based software. In (Kauppinen et al.,

2004), two criteria for framework-based product fam-

ilies are deﬁned based on traditional structural cover-

ages.

3.3 Functional Testing

The largest number of works were found for func-

tional testing. Several authors deﬁne techniques for

test case derivation in SPL, most of them from use

cases modiﬁed to represent variability in the line.

This is the case with Bertolino et al. (Bertolino

et al., 2004), McGregor (McGregor, 2001), Nebut et

al. (Nebutet al., 2004), Olimpiewel al.(Olimpiew and

Gomaa, 2005) and Reuys et al. (Reuys et al., 2005).

Only the last work was applied in an industrial envi-

ronment.

Bertolino et al. (Bertolino et al., 2004) adapt

the use cases to SPL (PLUCs - Product Line Use

Cases) in which the variations are described explicitly

with tags. The test cases are derived manually using

the Category Partition method. This methodology is

called PLUTO (Product Line Use Case Test Optimi-

sation). Nebut et al. (Nebut et al., 2004) have a very

similar proposal, they proposeassociating contractsto

the SPL use cases to express the dependencies adding

UML tagged values and the pre and post conditions

are UML notes expressed in ﬁrst-order logic. They

present a tool to automate the test case derivation.

McGregor (McGregor, 2001) creates generic test

cases from the use-case scenarios and then speciﬁc

test cases are derived for the product. The variabil-

ity combination is resolved with the orthogonal arrays

technique.

Olimpiewel al. (Olimpiew and Gomaa, 2005) cre-

ate test models from use cases. They ﬁrst create activ-

SOFTWARE PRODUCT LINE TESTING - A Systematic Review

ity diagrams from the use cases, then create decision

tables from the activity diagrams and ﬁnally, create

test templates from the decision tables and from the

path in the activity diagram. Test data is generated to

satisfy the execution conditions of each test template.

Reuys et al. (Reuys et al., 2005) obtain the test

cases from the use cases, using activity diagrams to

deﬁne all the use case scenarios. Test case scenarios

are speciﬁed in sequence diagrams without specifying

concrete test data. Later, they are reﬁned to include

detailed test inputs, expected results, additional infor-

mation and test scripts relevant to this scenario. This

technique is called ScenTED (Scenario based TEst

case Derivation) and has been applied in a case study

at Siemens AG Medical Solutions HS IM. They also

present a tool to support this method.

Related to test case derivation from sequence di-

agrams, Nebut et al. (Nebut et al., 2003) propose a

method supported by a toolset, in which behavioural

test patterns (behTP) are obtained from high-level se-

quences which are used to automatically generate test

cases speciﬁc to each product. Each behTP represents

a high-level view of some scenarios which the system

under test may engage in. Another work by Kang et

al. (Kang et al., 2007) extends sequence diagram no-

tation to represent variability in use case scenarios.

From a test architecture deﬁned using the Orthogo-

nal Variability Model (OVM)(Pohl et al., 2005) and

sequence diagrams, test scenarios are derived. The

Orthogonal Variability Model (OVM) is also used by

Cohen et al. (Cohen et al., 2006) to deﬁne a cover-

age test model for SPL which takes into account the

coverage of variability combinations.

Two works propose to deﬁne testing meta-models.

Due˜nas et al. (Due˜nas et al., 2004) deﬁne a meta-

model to represent the variability in scenarios and test

cases and use state transition diagrams to model the

test case behaviour. The variability is deﬁned by an

algebraic expression. Baerisch (Baerisch, 2007) de-

ﬁnes two models to represent SUTs and the tests ex-

ecuted on the SUTs: test models, which express the

intention of the test, represent the domain-speciﬁc re-

quirements that are veriﬁed by the test and system

models which describe the SUT and must include in-

formation about the features and interfaces that are

relevant for the deﬁnition and the execution of tests.

For functional testing automation, Ardis et al.

(Ardis et al., 2000) present a case study at Bell Labs.

There three test strategies suitable for general use in

product line testing automation based on a design for

testability were developed. They require an architec-

ture that minimises the cost of both the generation and

the testing of each family member.

For legacy systems, Geppert et al. (Geppert et al.,

2004) obtained a family of generic test cases by gen-

eralising existing (or new) test cases driven by the

parameters of variation of the commonality analysis.

They use a decision tree to generate the speciﬁc test

cases.

An interesting result is the controlled experiment

described by Denger et al. (Denger and Kolb, 2006)

to investigate the effectiveness and efﬁciency of code

inspection and functional testing by detecting differ-

ent defect types in the common and variable parts of

reusable code components in the context of product

line development. They conclude that code inspec-

tions and functional testing ﬁnd different types of de-

fects with different effectiveness and efﬁciency. The

results indicate that standard techniques are not sufﬁ-

cient to address variant-speciﬁc defects.

3.4 SPL Architecture Testing

To improve the testability, Kolb et al. (Kolb and

Muthig, 2006) propose designing the product line ar-

chitecture in such a way that it supports the testing

of the reusable product line components and the dif-

ferent products, considering testing in the architecture

design phase.

3.5 Embedded System Testing

The works found for testing in embedded systems

are generally speciﬁc to a particular domain and have

been tested in artiﬁcial environments or industries.

Kim et al. (Kim et al., 2006) present a tool that sup-

ports the development of SPL for embedded systems

of control, using FORM (Feature-Oriented Reuse

Method) and using simulation for testing. Kishi et

al. (Kishi and Noda, 2006) apply formal veriﬁcation

techniques (model checking) to verify the design of

embedded systems in SPL. They use Gomaa et al.’s

proposal to represent the variability in UML mod-

els and present a tool that supports this approach.

Pesonen et al. (Pesonen et al., 2006) use aspects

to implement specialisations at the core assets level

in embedded systems for smoke testing the devices.

They present experiment results with the Symbian

OS. Trew (Trew, 2005) presents an analysis of the

causes of the problems reported in a Philips television

SPL and deﬁnes a set of rules to use from this.

3.6 Testing Process

With respect to the testing process, there is no de-

ﬁned and proven methodology. The existing propos-

als are guidelines for testing activities. For McGregor

(McGregor, 2001), testing in the context of a product

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

Table 1: Primary studies summary.

Paper

Category

Variability

Technique

Tool

Example

Artiﬁcial setting

Industrial setting

(Ajila and Dumitrescu, 2007) TE Change in SPL NO NO NO YES

(Ardis et al., 2000) FT Scenarios, Drivers NO YES NO YES

(Baerisch, 2007) FT System metamodel Testing metamodel NO NO NO NO

(Bertolino et al., 2004) FT Use Cases Category Partition NO YES NO NO

(Clements and Northrop,

2007)

FT NO YES NO NO

(Cohen et al., 2006) FT Orthogonal Var.

Model

Coverage and adequacy

metrics

NO YES NO NO

(Denger and Kolb, 2006) FT Inspections, functional

testing

NO NO YES NO

(Due˜nas et al., 2004) FT Classes Testing metamodel,

state chart

NO NO NO NO

(Geppert et al., 2004) FT Legacy systems Decision tree NO YES NO YES

(Kang et al., 2007) FT,TA Sequence diag. OVM in Architecture,

Sequence diag.

NO YES NO NO

(Kauppinen et al., 2004) IT Coverage metrics NO YES NO NO

(Kim et al., 2006) ET FORM Simulation YES YES NO NO

(Kishi and Noda, 2006) ET UML models Model checking YES NO YES NO

(Kolb and Muthig, 2006) AT SW Architecture testability model NO NO NO NO

(McGregor, 2001) FT, IT,

UT, TP

Use Cases Combinatory design

testing

NO YES NO NO

(Nebut et al., 2003) FT Use Cases, Se-

quence diag.

Sequence diag. YES NO YES NO

(Nebut et al., 2004) FT Use Cases Use Cases YES NO YES NO

(Olimpiew and Gomaa,

2005)

FT Use Cases, Activ-

ity diag.

Decision tables NO NO NO YES

(Pesonen et al., 2006) ET Aspects Smoke test NO YES NO YES

(Pohl and Metzger, 2006) FT, TP Use Cases Activity diag. NO NO NO NO

(Reuys et al., 2005) FT Use Cases, Activ-

ity diag.

Sequence diag. YES YES NO YES

(Tevanlinna, 2004) IT YES NO NO NO

(Trew, 2005) ET NO YES NO YES

line includes testing the core assets, the product spe-

ciﬁc software and their interactions. Pohl et al. (Pohl

and Metzger, 2006) outline six essential principles for

SPL system testing that should be taken into account

when developing test techniques for SPL engineering.

These principles are:

(1) Preserve variability in domain test artefacts,

(2) Test commonalities in domain engineering, (3)

Use reference applications to determine defects in fre-

quently used variants, (4) Test commonalities based

on a reference application, (5) Test correct variabil-

ity bindings and (6) Reuse application test artefacts

across different applications. The SEIs Framework

(Clements and Northrop, 2007) proposes a separate

framework for testing in SPL, deﬁning the following

guidelines for this testing: Structure the set of test-

ing processes to test each artefact as early as possible,

structure test artefacts to accommodate the product

line variation, maintain the test artefacts, structure the

testing software for traceability from the test code it-

self to the code being tested, reuse product line assets

for system integration testing and automate regression

testing.

3.7 Testing Effort

Ajila et al. (Ajila and Dumitrescu, 2007) make a study

of the changes in the product line architecture of a

large telecommunications equipment supplier. They

conclude that code size is not a good predictor of

testing effort at either product or product line levels

and that testing effort does not seem to depend on the

product’s target market.

SOFTWARE PRODUCT LINE TESTING - A Systematic Review

4 SOFTWARE TESTING

RESEARCH AND SPL

Bertolino(Bertolino, 2007) presents the achieve-

ments, challenges and dreams in testing research.

The software product lines can be categorised in the

transversal challenge: testing within the emerging de-

velopment paradigms. Below, the challenges are de-

scribed.

• Explicit test hypotheses: Make explicit the test

practise behind the selection of every ﬁnite test

set, by which a sample is taken as the representa-

tive of several possible executions

• Test effectiveness: Provide analytical, statistical,

or empirical evidence of the effectiveness of the

test-selection criteria in revealing faults, in order

to understand the classes of faults for which the

criteria are useful.

• Empirical body of evidence: Produce an empirical

body of knowledge which is the basis for building

and evolving the theory for testing.

• Compositional testing: Understand how we can

reuse the test results observed in the unit testing,

and what conclusions can be inferred about the

system resulting from the composition, and which

additional test cases must be run on the integra-

tion.

• Model-based testing: How can we combine dif-

ferent styles of modelling, and the need for ways

to combine model-based criteria with other ap-

proaches.

• Anti-model-based testing: Parallel to model-

based testing, several efforts are being devoted to

novel forms of testing which lay directly on the

analysis of program executions.

• Test oracles: Find more efﬁcient methods for re-

alising and automating oracles.

• Test input generation: Automatic generation of

test inputs.

• Domain-speciﬁc test approaches: Extend domain

speciﬁc approaches to the testing stage, and in

particular to ﬁnd domain-speciﬁc methods and

tools to push test automation.

• On-line testing: Monitoring a system’s behaviour

in real life operation, using dynamic analysis and

self-test techniques.

• Controlling evolution: Strategies to scale up re-

gression testing to large composite systems.

• Leveraging user population and resources: Aug-

ment in-house quality assurance activities by us-

ing data dynamically collected from the ﬁeld.

• Testing patterns: Patterns offer well-proven solu-

tions to recurring problems, making explicit the

successful procedures, which is highly desirable.

• Understanding the costs of testing: Incorporate

estimation functions of the cost/effectiveness ra-

tio of available test techniques.

Table 2 enumerates the challenges in testing

to achieve the dreams as deﬁned by Bertolino

(Bertolino, 2007) and the challenges to enriching the

state of art in testing. The table was completed with

the studies found in the systematic review presented

here and several challenges are addressed today in

SPL testing. Especially, model based testing and test

input generation seem to be fundamental for testing in

SPL. Unfortunately, other challenges are not covered

for SPL today. The state of the art in SPL testing is

still not mature, mainly in test oracle deﬁnition and

testing management topics, like testing effort or test-

ing costs in the SPL context and in general, there is a

lack of empirical results in the existent works.

5 CONCLUSIONS

This paper has presented an analysis of the current

state of the art in software product lines testing, link-

ing them with recent research in software testing. In

general, SPL in Software Engineering is a young dis-

cipline, but a very promising one, proving that most

of the results and beneﬁts obtained from SPL can

be extrapolated to other methodologies or develop-

ment paradigms. In the case of testing, Bertolino

(Bertolino, 2007) has pointed out a transversal chal-

lenge to the development of testing techniques and

their reuse from emerging paradigms, as product lines

may well be. Among the other research lines iden-

tiﬁed by this author is a tendency towards the use of

models for the design of systems and the derivation of

test cases from them, which had also been noted as a

necessity by Harrold (Harrold, 2000) nearly a decade

ago. Another critical research line for SPL is test au-

tomation and re-execution.

In our case, we are implementing a model-driven

development approach to the design of an experimen-

tal software product line as a basis to automate the

generation of test cases using model-based testing

techniques adapted to software product lines. In the

proposal, we are interested in the automated deriva-

tion of test cases from design models using QVT

transformations (OMG, 2008), all while paying spe-

cial consideration to the reuse of the deﬁnition of the

oracle, which is the most costly in the test case gener-

ation (Bertolino, 2007; Baresi and Young, 2001).

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

Table 2: Software product line testing studies according to the dreams and challenges of testing.

Dream: Universal test theory

Explicit test hypotheses Test effectiveness Compositional testing Empirical body of evidence

(Kolb and Muthig, 2006),

(Ardis et al., 2000)

(Denger and Kolb, 2006) (McGregor, 2001), (Gep-

pert et al., 2004)

(Reuys et al., 2005),

(Denger and Kolb, 2006)

Dream: Test-based modeling

Test oracles Model-based testing Anti-model-based testing

(McGregor, 2001),(Nebut et al., 2003),(Nebut

et al., 2004),(Bertolino et al., 2004), (Kang et al.,

2007),(Olimpiew and Gomaa, 2005),(Due˜nas et al., 2004),

(Reuys et al., 2005),(White and Schmidt, 2006), (Baerisch,

2007)

Dream: 100 percent automatic testing

On-line Testing Test input generation Domain-speciﬁc test ap-

proaches

(Kishi and Noda, 2006) (Nebut et al., 2003),(Nebut et al., 2004), (Reuys et al.,

2005),(Ardis et al., 2000),(Tevanlinna, 2004), (Due˜nas

et al., 2004)

(Pesonen et al., 2006),

(Kim et al., 2006),(Kishi

and Noda, 2006),(Trew,

2005)

Dream: Efﬁcacy-maximized test engineering

Understanding the costs of

testing

Controlling evolution Leveraging user population

and resources

Testing patterns

(Ajila and Dumitrescu,

2007),(Cohen et al., 2006)

ACKNOWLEDGEMENTS

This research is ﬁnanced by the projects: PRALIN

(PAC08-0121-1374) and MECCA (PII2I09-

00758394),”Cons. de Ciencia y Tecnol. de la

Junta de Comunidades de Castilla-La Mancha”.

REFERENCES

Ajila, S. and Dumitrescu, R. (2007). Experimental use of

code delta, code churn, and rate of change to under-

stand software product line evolution. The Journal of

Systems and Software, 80(1):74–91.

Ardis, M., Daley, N., Hoffman, D., Siy, H., and Weiss, D.

(2000). Software product lines: a case study. Software

Practice and Experience, 30(7):825–847.

Baerisch, S. (2007). Model-driven test-case construction.

Foundations of Software Engineering, pages 587–590.

Bertolino, A. (2007). Software testing research: Achieve-

ments, challenges, dreams. In Internation Conference

on Software Engineering, pages 85–103. IEEE Com-

puter Society.

Bertolino, A., Gnesi, S., and di Pisa, A. (2004). Pluto: A test

methodology for product families. Software Product-

family Engineering: 5th International Workshop, PFE

2003, Siena, Italy, November 4-6, 2003: Revised Pa-

pers.

Biolchini, J., Mian, P., Natali, A., and Travassos, G. (2005).

Systematic review in software engineering. Sys-

tem Engineering and Computer Science Department

COPPE/UFRJ, Technical Report ES, 679(05).

Clements, P. and Northrop, L. (2007). A framework for

software product line practice, version 5.0.

Clements, P. C. and Northrop, L. M. (2002). Salion, inc.:

A software product line case study. Technical Report

CMU/SEI-2002-TR-038.

Cohen, M., Dwyer, M., and Shi, J. (2006). Coverage and

adequacy in software product line testing. Proceed-

ings of the ISSTA 2006 workshop on Role of software

architecture for testing and analysis, pages 53–63.

Denger, C. and Kolb, R. (2006). Testing and inspecting

reusable product line components: ﬁrst empirical re-

sults. Proceedings of the 2006 ACM/IEEE interna-

tional symposium on International symposium on em-

pirical software engineering, pages 184–193.

Due˜nas, J., Mellado, J., Cern, J., Arciniegas, J., Ruiz, J., and

Capilla, R. (2004). Model driven testing in product

family context. Technical Report ISSN 1381 - 3625,

University of Twente.

Geppert, B., Li, J., RoBler, F., and Weiss, D. (2004). To-

wards generating acceptance tests for product lines.

Software Reuse: 8th International Conference, ICSR

2004, Madrid, Spain, July 5-9, 2004: Proceedings.

Kang, S., Lee, J., Kim, M., and Lee, W. (2007). To-

wards a formal framework for product line test de-

velopment. Computer and Information Technology,

2007. CIT 2007. 7th IEEE International Conference

on, pages 921–926.

Kauppinen, R., Taina, J., and Tevanlinna, A. (2004). Hook

and template coverage criteria for testing framework-

based software product families. Proceedings of

the International Workshop on Software Product Line

Testing, pages 7–12.

SOFTWARE PRODUCT LINE TESTING - A Systematic Review

Kim, K., Kim, H., Ahn, M., Seo, M., Chang, Y., and Kang,

K. (2006). Asadal: a tool system for co-development

of software and test environment based on product line

engineering. International Conference on Software

Engineering, pages 783–786.

Kishi, T. and Noda, N. (2006). Formal veriﬁcation and

software product lines. Communications of the ACM,

49(12):73–77.

Kitchenham, B. (2004). Procedures for performing system-

atic reviews. Keele University, UK, Technical Report

TR/SE-0401-ISSN, pages 1353–7776.

Kolb, R. and Muthig, D. (2006). Making testing prod-

uct lines more efﬁcient by improving the testability

of product line architectures. Proceedings of the IS-

STA 2006 workshop on Role of software architecture

for testing and analysis, pages 22–27.

Krueger, C. (2006). The emerging practice of software

product line development. Military Embedded Sys-

tems, (2nd semester):34–36.

McGregor, J. (2001). Testing a Software Product Line.

Carnegie Mellon University, Software Engineering In-

stitute.

McGregor, J., Northrop, L., Jarrad, S., and K, K. P. (2002).

Initiating software product lines. IEEE Software,

19(4):24–27.

Nebut, C., Fleurey, F., Le Traon, Y., Jezequel, J., and

de Beaulieu, C. (2004). A requirement-based ap-

proach to test product families. Software Product-

family Engineering: 5th International Workshop, PFE

2003, Siena, Italy, November 4-6, 2003: Revised Pa-

pers.

Nebut, C., Pickin, S., Le Traon, Y., and Jezequel, J.

(2003). Automated requirements-based generation of

test cases for product families. Automated Software

Engineering, 2003. Proceedings. 18th IEEE Interna-

tional Conference on, pages 263–266.

Olimpiew, E. and Gomaa, H. (2005). Model-based testing

for applications derived from software product lines.

Proceedings of the 2005 workshop on Advances in

model-based testing, pages 1–7.

OMG (2008). Meta object facility (mof) 2.0

query/view/transformation, v1.0. Technical Re-

port formal/2008-04-03.

Pesonen, J., Katara, M., and Mikkonen, T. (2006).

Production-testing of embedded systems with as-

pects. LECTURE NOTES IN COMPUTER SCIENCE,

3875:90.

Pino, F., Garcia, F., and Piattini, M. (2007). Software pro-

cess improvement in small and medium software en-

terprises: A systematic review. Software Quality Jour-

nal.

Pohl, K., Bckle, G., and van der Linden, F. (2005). Software

Product Line Engineering: Foundations, Principles,

and Techniques. Springer.

Pohl, K. and Metzger, A. (2006). Software product line

testing. Communications of the ACM, 49(12):78–81.

Reuys, A., Kamsties, E., Pohl, K., and Reis, S. (2005).

Model-based system testing of software product fam-

ilies. Pastor, O.; Falcao e Cunha, J.(Eds.): Advanced

Information Systems Engineering, CAiSE, pages 519–

534.

Tevanlinna, A. (2004). Product family testing with rita.

Proceedings of the Eleventh Nordic Workshop on Pro-

gramming and Software Development Tools and Tech-

niques (NWPER’2004), pages 251–265.

Trew, T. (2005). Enabling the smooth integration of core

assets: Deﬁning and packaging architectural rules for

a family of embedded products. LECTURE NOTES

IN COMPUTER SCIENCE, 3714:137.

van der Linden, F. (2002). Software product families in

europe: the esaps and cafe projects. Software, IEEE,

19(4):41–49. TY - JOUR.

White, J. and Schmidt, D. (2006). Fireant: A tool for

reducing enterprise product line architecture deploy-

ment, conﬁguration, and testing costs. Engineering

of Computer Based Systems, 2006. ECBS 2006. 13th

Annual IEEE International Symposium and Workshop

on, pages 507–508.

ICSOFT 2009 - 4th International Conference on Software and Data Technologies
