SERVICE ORIENTED P2P NETWORKS FOR

DIGITAL LIBRARIES, BASED ON JXTA

Marco Pereira, Marco Fernandes, Joaquim Arnaldo Martins and Joaquim Sousa Pinto

IEETA - Instituto de Engenharia Electr

onica e Telem

atica de Aveiro, Universidade de Aveiro, Portugal

Keywords:

Peer-to-Peer, Digital Libraries, Service Oriented Architecture, Web Services.

Abstract:

Digital libraries tend to be based on centralised models. This centralised approach has both advantages and

drawbacks. Regarding the drawbacks we notice that the central server used is a single point of failure that

can effectively render a digital library unusable if it fails. In this kind of approach we are also ignoring

potential resources that are available in other computers on the network. This paper describes a peer-to-peer

network architecture based on JXTA and on SOA (Service Oriented Architecture) that can be used as a support

infrastructure for a digital library.

1 INTRODUCTION

Digital libraries can be seen as infrastructures used

in the management, storage and distribution of dig-

ital content. As such they often employ centralised

architectures in the support services that they require

as well in the servers that are exposed to the outside.

This approach is not without problems, as a failure in

any centralised node can render the digital library un-

usable. Such failure can come from physical events

such as power loss or from the inability to cope with

increased demands for content.

We proposed that a peer-to-peer network could

be used as underlying infrastructure for digital li-

braries (Fernandes et al., 2008a). With the use of a

peer-to-peer network designed to take advantage of

free resources that exist on computers (both storage

resources and CPU cycles) it would be possible to

create a scalable and reliable digital library, always

taking into account that peer-to-peer networks suf-

fer from speciﬁc problems. One of those problems

is that searching for content, which is a key opera-

tion in digital libraries, on a peer-to-peer network is

not an trivial task. Existing peer-to-peer networks

search capabilities are rather limited (often they only

allow querying for the ﬁle name or type) and depend-

ing on the underlying peer-to-peer architecture we can

never be 100% sure that we have found all the de-

sired contents. Metadata based search can be used

to strengthen search capabilities and carefully chosen

network architecture can be used to minimise the loss

of search results.

In this paper we begin by introducing a peer-to-

peer network architecture, we proceed to describe

how Apache Lucene (LUC, 2008) can be used to pro-

vide rich search throughout the network and how we

can leverage the peer-to-peer infrastructure to provide

support services using a webservices based strategy;

ﬁnally we present some test data from a reference im-

plementation and draw some conclusions.

2 RELATED WORK

There are several projects that seek to harness the

power of peer-to-peer networks and use it in digital

libraries scenarios. In this section we reference some

of those projects.

P2P-4-DL (Walkerdine and Rayson, 2004) is a

plugin for the Lancaster P2P Application Framework

(Walkerdine et al., 2008) that allows the creation of a

digital library based on a peer-to-peer network. It uses

a Napster-like system where references (comprised of

author, title and keywords) are uploaded to an index

peer. The references can then be used when searching

the network for content. Since the references are con-

stituted by ﬁxed ﬁelds there is little ﬂexibility in the

search patterns that can be produced.

EDUTELLA (Nejdl et al., 2002) is a project

that aims to provide RDF based metadata search on

the JXTA peer-to-peer network, allowing for richer

search experiences than the ones currently used on

141

Pereira M., Fernandes M., Arnaldo Martins J. and Sousa Pinto J. (2009).

SERVICE ORIENTED P2P NETWORKS FOR DIGITAL LIBRARIES, BASED ON JXTA.

In Proceedings of the 4th International Conference on Software and Data Technologies, pages 141-146

DOI: 10.5220/0002257501410146

 SciTePress

most peer-to-peer applications. EDUTELLA is di-

rected to the exchange of educational content on an

internal level (inside an institution) and is presented

as a service within the JXTA network. EDUTELLA

is only responsible for handling metadata, leaving all

the data collection and metadata extraction for avail-

able backends.

Freelib (Amrou et al., 2006) is an ongoing open-

source project that proposes the usage of a peer-

to-peer network based on the Symphony protocol

(Manku et al., 2003) to build a digital library. Freelib

tries to leverage access patterns to bring content to

locations closer to where it is actually needed by di-

rectly connecting peers with common interests (or at

least place them close enough for them to beneﬁt from

the small world effect (Kleinberg, 2000)). Freelib is

content-oriented and does not provide mechanism to

access support services that a digital library could re-

quire.

3 P2P ARCHITECTURE FOR

DIGITAL LIBRARIES

For our digital library we want to avoid the centralised

design that is the Achilles’ heel of the traditional im-

plementations and we also want to minimise loss of

search results. With those two requirements we ruled

out the possibility of implementing a peer-to-peer ar-

chitecture based on a pure centralised approach (for

example mandatory concentration of network search

capabilities in only one peer) and on fully decen-

tralised approach (due to the possible loss of search

results). We choose to adopt an hybrid architecture in

order to take advantage of the best traits of the cen-

tralised and decentralised approach. In our proposed

architecture the function of the Super peer will be to

collect individual peer indexes to help speed up the

search process.

We must recognise that in some special situations

it could be better to be in a decentralised network,

without any Super peer, so the developed architecture

allows for a peer to choose its operation mode. In our

architecture a peer can choose to register with a Super

peer using it to process queries, or it can remain in-

dependent and address queries to all neighbour peers

that he knows. Using this strategy the network can

survive the loss of all Super peers by having regu-

lar peers falling back to a decentralised architecture

when such failure is detected. The index that each

peer creates contains all the necessary information to

retrieve content from that peer. When retrieving con-

tent from the network we can explore redundancy. If

multiple peers have the same content we can transfer

Standard Interface

WebServices

JXTA - SOAP

Local Index

Network

RequestsReplies

Querying and Indexing

Apache, Lucene

P2P Transport - JXTA

Figure 1: Internal components of a peer.

it in parallel from all of them, to speedup content re-

trieval process. The peer-to-peer network can be used

for more than just storage and retrieval of content.

Spare cycles can be used to provide services to the

digital library. In order to implement the proposed

architecture we use the JXTA (JXT, 2008a) peer-to-

peer framework. With this framework we were able

to implement the proposed features. JXTA creates

an overlay network that makes peers appear to be di-

rectly connected with each other when in fact they are

not. By using Apache Lucene to index ﬁles we cre-

ate a rich search environment in the network (detailed

in section 4). JXTA provides a mechanism for search

of resources that can be used to ﬁnd peers or services

on the network. Using this mechanism (called adver-

tisements) and the library JXTA-SOAP (JXT, 2008b)

we were able to provide services by creating simple

webservices. This process is detailed in section 5.

4 METADATA BASED SEARCH

OVER P2P NETWORKS

As was said in section 1 search in peer-to-peer net-

works is usually limited to the name or type of a

ﬁle. This is not a desired scenario in a network de-

signed to support digital libraries so we decided to use

an Apache Lucene based indexing system (Fernandes

et al., 2008b). By using this system we can lever-

age Lucene’s powerful full-text search exposing it to

the network, thus creating a rich search environment

where, for example, one could search for the author,

the year of publication or even content of a book in-

stead of searching for the name of the ﬁle that stores

the book. This indexing scheme can be extended to

handle every conceivable digital media.

Besides metadata speciﬁc to each content type we

also keep generic information about a ﬁle that can be

used to retrieve it. That information includes a hash

(that allow us to identify the same ﬁle stored in dif-

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

142

ferent peers), an identiﬁer of the peer that has the ﬁle,

the physical ﬁle location on a peer, the ﬁle size and

name. These management ﬁelds can be used as part

of a query, along with content speciﬁc ﬁelds. There

are scenarios where it can be interesting for a peer

to index only speciﬁc content types (such as DICOM

or PDFs ﬁles). To support this approach we use Java’s

reﬂection capabilities combined with a properties ﬁle.

The ﬁle contains the mapping of the ﬁle extensions

to an appropriate Document Handler class, and can

be speciﬁed by any application that uses our library,

implementing the necessary infrastructure for the cre-

ation of specialised peers.

When using a network with a Super peer, Lucene’s

generated indexes should migrate from the original

peer to the Super peer. This is done to concentrate

the search in a few peers, thus reducing the need for

ﬂooding the network with query messages. Index mi-

gration poses two potential problems: the migration

can generate signiﬁcative amounts of network trafﬁc

and migrated indexes can become out–of–date. This

issue can be solved by propagating any changes in the

indexes to the Super peers. In a digital library sce-

nario where changes in the indexes are not frequent

(and when happen they are scheduled) index migra-

tion will pose no major problems.

5 WEB SERVICES - SUPPORT

OVER A P2P NETWORK

The architecture described in the above sections can

handle content search and transfer. This means that

we are using the storage resources available in the

network, but we can also leverage the peer-to-peer in-

frastructure to use some of the available CPU cycles

to provide support services to our digital library. By

using the JXTA-SOAP library we can make our peers

offer services using the known webservices interface.

For the time being these services are only visible on

the peer-to-peer network but they provide to the dig-

ital library load sharing capabilities and ﬂexibility, as

well as an added layer of reliability. Using this ap-

proach services can be replicated (each peer should

have a pre-installed set of services), ensuring that

there is always at least one peer offer a required ser-

vice and creating an opportunity for sharing the work-

load among several peers. Each peer can offer a dif-

ferent set of services, and each service is announced

to the network using standard JXTA advertisements

(JXT, 2007), that have a WSDL (Web Services De-

scription Language (Christensen et al., 2001)) ﬁle em-

bedded. When a peer needs a service it can retrieve

these advertisements from the network and choose a

Peer 1

Service A

(...)

(...)

P2P Network

Peer 2

Service A?

Figure 2: Service discovery.

peer (or several) that is providing the desired service.

The service itself is described by the WSDL ﬁle em-

bedded in the advertisements, but peers can use an ex-

tended set of attributes (such as service name or peer

id) placed in the advertisement to discover the service

(illustrated by Figure 2). A peer can query the net-

work for services by name and then use the extended

attributes to discover more information about the peer

that is offering the service, ensuring that he can select

the best peer (or peers) for the task. After this phase

a peer follows regular procedures to call a webservice

(with the difference that instead of having HTTP as

transport protocol it has JXTA).

A problem with the current implementation is that

only allows the use of byte arrays in SOAP messages

for ﬁle transfers. This is not an efﬁcient method of

moving data and creates limits to the size of the ﬁle

that can be transferred and is also a possible threat on

the stability of the network, as it is possible to render

a peer useless by forcing it to run out of memory. The

solution would be the use of attachments, but we were

unable to use them in the JXTA-SOAP context since

when we added the attachment to the SOAP message

it disrupted the JXTA message, causing an exception.

Alternatives include contributions to the JXTA-SOAP

library (to provide proper attachments support) or the

use of other transfer mechanisms (such as the use of

an reference that would enable the use of an interme-

diary FTP or HTTP server or even a native JXTA ﬁle

transfer after the service has been requested). The last

alternatives will break the web services facade we are

striving to maintain.

SERVICE ORIENTED P2P NETWORKS FOR DIGITAL LIBRARIES, BASED ON JXTA

143

6 TESTS

We have selected a series of tests to be conducted on

a reference implementation of the peer-to-peer net-

work architecture. These tests are supposed to re-

ﬂect some operations that would be used on a daily

basis on the network. We used a network of 7 com-

puters (described in Table 1) in a local network (100

mbits) environment, with all computers connected to

the same Ethernet switch (that provides connectivity

with the rest of the laboratory’s network). We could

have chosen to host several peers on each computer

but we believe that this would compromise the results

of the service test. Please note that all graphics pre-

sented use a logarithmic scale on the Y axis for read-

ability purposes.

6.1 Index Management

Index management can be seen as a two part process.

The ﬁrst part deals with index creation and update

while the second part deals with Index migration.

Regarding index creation previous tests (Fernan-

des et al., 2008b) indicated that Lucene was the best

option to provide advanced search and indexing ca-

pabilities to a peer-to-peer network. Initial content

indexing is a task that should be made before expos-

ing the peer to network. Since Lucene allows queries

to be made while it is indexing content but offers no

assurance that the contents being indexed will appear

in the generated results it is important to plan when

to index new content (thus updating the indexes) in

order to provide the most complete result set to our

network users. Focusing on index migration we can

deﬁne two scenarios: initial index migration that oc-

curs when a peer joins the network for the ﬁrst time

and elects to transfer its index to a Super peer and

migration updates sent to the Super peer when new

content has been indexed. We conducted an initial

index migration test where indexes migrated from a

peer to a Super peer. Index transfer was designed to

mirror a regular ﬁle transfer (with minor differences

on control issues). Test results (seen in Table 2) show

a regular increase in migration time as the size of the

index grows. Some indexes can achieve sizes in the

GB magnitude. The migration of one of those indexes

can cause some disruption on the network, so in order

to avoid any problems migration times should be care-

fully chosen, and an indexing strategy that allows in-

cremental updates must be adopted. In extreme cases

where a peer has an existing index that is too large

to be migrated we could implement a mechanism to

allow the Super peer to forward queries to that peer.

Based on test result coupled with the previous guide-

Table 1: Peer speciﬁcations.

Peer CPU RAM OS

Pentium III @

863MHz

320Mb OpenSuse 11.0

2 Pentium 4 @ 2.8GHz 512Mb

Windows Server

2003

3 Pentium 4 @ 2.4GHz 1Gb Windows XP Pro

4 Pentium 4 @ 2.8GHz 2Gb OpenSuse 11.0

5 Pentium 4 @ 3.2GHz 2Gb Windows XP Pro

Core2 Duo @

3.0GHz

2Gb Windows Vista Basic

2x Quad Xeon @

3.2GHz

2Gb

Windows Vista Busi-

ness x64

Table 2: Time taken to transfer an index.

Index Size (Mb) Time (s)

4 × 10

−5

0.58

0.86 0.87

1.7 1.17

18 7.53

53 19.78

100 38.67

lines index migration will not be a problem in our

peer-to-peer network.

6.2 Content Search

This test is designed to measure the time that a peer

takes to ﬁnd content on the network. The test is di-

vided in two scenarios: in the ﬁrst we use a Super

peer to centralise all the searches and in the second

we remove the Super peer in order to test search on

the network when a decentralised architecture is used.

In both scenarios we start with searches that return

no results and progress to obtaining each time more

results. As expected in both scenarios the time taken

to search the network increases as the number of re-

trieved results also increases. As we can see in Figure

3 the time taken to retrieve results from the network

is acceptable. Since the results arrive in small units

we can devise a strategy that would allow incremental

display of results to a human user in order to increase

the overall feeling of responsiveness of the peer-to-

peer system.

Comparing both scenarios we can see that using a

Super Peer presents better search times when there are

only a few results to be sent over the network. This is

behaviour can be explained by the overhead involved

in establishing connections with other known peers, a

network trait when using a decentralised architecture.

As the number of results increase the time taken to

perform the search in each scenario becomes similar.

This can be explained by the increased effort of per-

forming a centralised search and points out that Super

peers must be chosen carefully, not by what they can

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

144

0.8

0.84

0.98

1.06

1.38

2.58

3.25

40 500 1000 2000 5000 8000

Time (Seconds)

Search Results

Without superpeer

With superpeer

Figure 3: Time taken to search the network.

offer to the network but by their hardware capabilities

(in an ideal scenario Super peers would be dedicated

machines).

We can also discuss the results in the context of

the actual network topology used. When in the pres-

ence of fast connections (as in this case) results show

that a totally decentralised network will perform bet-

ter than a network with a super peer (there is always

the possibility of congestion if a large number of peers

is present). Since the time taken to search the net-

work in both scenarios appears to converge any net-

work induced delay will have impact on the search

time. This shows that when dealing with heteroge-

neous networks the best choice will be the use of an

hybrid topology with carefully chosen Super peers

that would ensure some degree of independence from

peers on slower connections when searching the net-

work.

6.3 TIFF to PNG Conversion Web

Service

In order to test the peer-to-peer implemented webser-

vice we designed a test to measure the time that takes

a conversion service to run and return results. Due to

constraints (described in section 5) the maximum size

of a ﬁle (or group of ﬁles) is limited. The conversion

service is available on six peers and the time taken

to convert a batch of ﬁles is compared with a refer-

ence time obtained when converting the same ﬁles in

sequence on only one computer (peer 2 described in

Table 1). The test ﬁles are tiffs generated from the

pages of a pdf, with an average size of 980kb.

When the conversion service is used the peer re-

questing the service is responsible for the distribution

of the load as he wishes. In this case a simple strategy

of statically assigning the ﬁles needing conversion to

each peer prior to actually requesting the service, so

that each peer had at least one ﬁle to convert. The

downside of this strategy is that a slow peer poten-

4.01

4.25

6.18

7.38

10.73

19.43

10 20 30

Number Of Files

Reference Time

Using all peers

Using top 3 peers

Figure 4: Conversion Times.

tially receives as much work as a fast peer, increasing

the overall time of the conversion. We initially con-

ducted two tests, one using only 3 peers (peers 5, 6

and 7 described in Table 1), selected because we con-

sider that they possess the best hardware conﬁgura-

tions and a test using 6 peers (peers 2 to 6 of Table 1).

As we can see on Figure 4 the time taken to convert

a given set of ﬁles using the distributed service was

lower than the reference time. It is important to no-

tice that increasing the amount of peers that offer the

conversion service yields only marginal beneﬁts when

converting small amounts of ﬁles, since the overhead

of the parallel service calls offsets most of the per-

formance gains that would come from the increased

number of peers.

Table 3: Time taken to convert ﬁles.

No. of ﬁles Top 3 Peers (s) With Peer 1 (s) Ref. Time (s)

10 4.25 8.05 6.18

20 7.55 17.57 12.67

30 10.73 26.9 19.43

We also performed a test to illustrate the impact

that a peer single peer can have when it is ill equipped

to handle a service. In this test we repeated the ﬁrst

test, replacing peer 5 with peer 1. Table 3 presents the

result of this test in comparison with the initial test.

As we can see a single peer can have a relevant impact

in the time that takes to execute a task. This result

underlines the relevance of choosing an appropriate

service replication strategy (since offering services in

a peer that is ill equipped to handle them is counter-

productive) and of the load distribution mechanism,

that should take into account hardware speciﬁcations

as well as the peer availability to actually execute the

task. It is important to note that since all peers were

on the same local network any transfer or network la-

tency problems that could arise in WAN scenarios are

not present.

SERVICE ORIENTED P2P NETWORKS FOR DIGITAL LIBRARIES, BASED ON JXTA

145

7 CONCLUSIONS

In this article we proposed a peer-to-peer network that

is able to support digital libraries and support ser-

vices. The tests made with the reference implemen-

tation of our proposed P2P network architecture pre-

sented interesting results, that we believe that can be

improved thus providing a strong incentive to con-

tinue this project. The possibility of using the net-

work in both decentralised and hybrid architectures

provides ﬂexibility, and by choosing the right archi-

tecture according with the number of peers and con-

nection type we can optimise network performance.

On the web services side, The performance gain is

interesting, yet raw performance gains are always de-

pendent of the degree of parallelism that a particular

application supports. As such we prefer to point out

that the added reliability, and the possibility of dis-

tributing the workload among different peers in sce-

narios where multiple services are available in the

network are the key features that justify the use of

P2P networks on digital libraries scenario. We con-

sider that more work is required in order to provide

an optimised strategy for choosing how to distribute

the workload in a way that the potentialities of the

peers with more resources are fully explored. In the

future it could prove to be interesting the creation of

a mechanism that would allow service migration, so

that when a peer considers that it would beneﬁt the

network to replicate an existing service this could be

done without human intervention. This is a real possi-

bility due to the mechanisms that allow the discovery

of new services.

Although we are aiming to use this peer-to-peer

architecture on LANs we should never rule out the

possibility of extending it to WANs. This implies

that we should develop a way to reliably pass network

boundaries and ﬁrewalls so that our peer-to-peer net-

work can be used on larger scales. This is a scenario

where super peers will play a fundamental role.

ACKNOWLEDGEMENTS

This work was funded in part by the Portuguese

Foundation for Science and Technology grant

SFRH/BD/23976/2005.

The authors would like to thank Jo

ao Pereira

(a30777@ua.pt) for his help and feedback during data

collection.

REFERENCES

(2007). Jxta v2.0 protocol speciﬁcation. Available from:

https://jxta-spec.dev.java.net/.

(2008). Apache lucene. Available from:

http://lucene.apache.org/java/docs/index.html.

(2008a). Jxta homepage. Available from:

https://jxta.dev.java.net/.

(2008b). Jxta-soap project. Available from:

https://soap.dev.java.net/.

Amrou, A., Maly, K., and Zubair, M. (2006). Freelib:

Peer-to-peer-based digital libraries. In AINA ’06: Pro-

ceedings of the 20th International Conference on Ad-

vanced Information Networking and Applications -

Volume 1 (AINA’06), pages 9–14, Washington, DC,

USA. IEEE Computer Society.

Christensen, E., Curbera, F., Meredith, G., and

Weerawarana, S. (2001). Web services de-

scription language (wsdl) 1.1. Available from:

http://www.w3.org/TR/wsdl.

Fernandes, M., Almeida, P., Martins, J. A., and Pinto, J. S.

(2008a). Soppa: Service oriented p2p framework for

digital libraries. In ICEIS 2008: 10th International

Conference on Enterprise Information Systems, pages

p. 215 – 219.

Fernandes, M., Martins, J. A., Pinto, J. S., and Almeida,

P. (2008b). Search engines evaluation for p2p based

digital libraries. In EATIS 2008: Euro American Con-

ference on Telematics and Information Systems.

Kleinberg, J. (2000). The small-world phenomenon: an al-

gorithm perspective. In STOC ’00: Proceedings of

the thirty-second annual ACM symposium on Theory

of computing, pages 163–170, New York, NY, USA.

ACM.

Manku, G. S., Bawa, M., and Raghavan, P. (2003). Sym-

phony distributed hashing in a small world. In

USITS’03: Proceedings of the 4th conference on

USENIX Symposium on Internet Technologies and

Systems, pages 10–10, Berkeley, CA, USA. USENIX

Association.

Nejdl, W., Wolf, B., Qu, C., Decker, S., Sintek, M., Naeve,

A., Nilsson, M., Palm

er, M., and Risch, T. (2002).

Edutella: a p2p networking infrastructure based on

rdf. In WWW ’02: Proceedings of the 11th interna-

tional conference on World Wide Web, pages 604–615,

New York, NY, USA. ACM.

Walkerdine, J., Hughes, D., Rayson, P., Simms, J., Gilleade,

K., Mariani, J., and Sommerville, I. (2008). A frame-

work for p2p application development. Comput. Com-

mun., 31(2):387–401.

Walkerdine, J. and Rayson, P. (2004). P2p-4-dl: Digital

library over peer-to-peer. In P2P ’04: Proceedings of

the Fourth International Conference on Peer-to-Peer

Computing, pages 264–265, Washington, DC, USA.

IEEE Computer Society.

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

146
