SINBAD DIGITAL LIBRARY PRESERVATION

USING IRODS DATA GRID

Marco Pereira, Marco Fernandes, Joaquim Arnaldo Martinsa and Joaquim Sousa Pinto

IEETA - Instituto de Engenharia Electr

onica e Telem

atica de Aveiro, Universidade de Aveiro, Portugal

Keywords:

Digital preservation, Digital libraries, Data grids.

Abstract:

Digital libraries are important instruments to make knowledge accessible to everyone. Maintaining the infor-

mation stored within a digital library accessible to the public while ensuring that it remains protected from

outside threats is one of the key concerns in digital libraries research. This paper describes possible ways to

integrate SInBAD, the University of Aveiro digital library system with a grid based preservation system.

1 INTRODUCTION

Digital preservation is a challenge faced by all digi-

tal libraries. The content that they store must be kept

available to users in a format suitable to their needs

but it must also be safe from catastrophic events that

would lead to loss of information. A single copy of a

ﬁle available on a centralised server is always at risk

of disappearing due to data corruption, natural disas-

ters, malicious attacks or human error, yet in spite of

this risk some digital libraries currently in place were

not designed to avoid it. A solution to this problem

can be the use of data grids as storage space (Moore

et al., 2005b). This approach is adopted by GRITO

project. Data grids themselves lack any kind of spe-

cialised management policies, that are in fact the key

to preserve content, since the decision of when to re-

cover content that has been potentially damaged, or

when to search a digital library for newly added con-

tent can be as vital as keeping backups. GRITO aims

to solve this problem, providing a stable grid platform

for digital preservation. By integrating SInBAD

the

current digital library system used by University of

Aveiro

with GRITO’s grid we wish to expand SIn-

BAD’s digital preservation capabilities.

In this paper we describe different strategies that

can be used to achieve integration between SIn-

BAD and GRITO’s grid. We begin by providing an

overview of what is digital preservation, proceed to

a brief explanation of some related work and of the

http://grito.intraneia.com

http://sinbad.ua.pt

http://www.ua.pt

projects we are trying to integrate. We then describe

possible ways to create a link between the projects,

expose our conclusions and future work perspectives.

2 DIGITAL PRESERVATION

Digital information is generated at an high rate every-

day. People casually take digital photos and create

documents on their computers without ever consid-

ering that the information that are creating is at risk.

Due to the high pace of technological evolution infor-

mation created just a few years ago is at risk of being

rendered unusable by obsolescence of the formats and

equipment in which it is stored (Kenney et al., 2003).

Digital obsolescence is not the only problem associ-

ated with digital information: traditional threats like

natural disasters or malicious attacks can also cause

information loss.

Digital preservation can be seen as the necessary

steps to ensure access to digital information over ex-

tended periods of time (Webb, 2003), while main-

taining digital information’s integrity and authentic-

ity (Ferreira, 2006). A digital preservation system is a

system that allows the preservation of digital informa-

tion respecting the above requirements. A reference

model for the development of digital preservation sys-

tems is the International Organization for Standard-

ization (ISO) standard 14721:2003 (OAI, 2002), a

standard that provides activities, concepts and termi-

nology to be used when developing an archive system.

107

Pereira M., Fernandes M., Arnaldo Martins J. and Sousa Pinto J. (2009).

SINBAD DIGITAL LIBRARY PRESERVATION USING IRODS DATA GRID.

In Proceedings of the 4th International Conference on Software and Data Technologies, pages 107-112

DOI: 10.5220/0002257601070112

 SciTePress

3 RELATED WORK

There are a number of projects that can be viewed as

relevant in the area of digital preservation.

Chronopolis

is a project that proposes a preser-

vation architecture “based on an integration of digital

library, data grid, and persistent archive technology”

(Moore et al., 2005a). Chronopolis proposed model

is interesting, but since it relies on Storage Resource

Broker as a grid middleware we can’t fully adopt it.

PANIC (Hunter and Choudhury, 2006) is a project

that aims to take independent developed digital

preservation projects and integrate their tools into a

grid framework. Tools collected this way are exposed

via web services and with the help of orchestration

tools can be used in preservation efforts. The tools

that this project expose can potentially be used by our

own integration efforts in order to, for example, pro-

vide format migration tools.

An iRODS based preservation system (Hedges

et al., 2009) was described in a paper published in the

Future Generation Computer Systems journal. The

paper describes the use of iRODS rules as support for

digital preservation, an iRODS trait that we use in the

GRITO project. This paper can be seen as a validation

of the choice of iRODS as underlying grid technology.

4 SInBAD

SInBAD is the digital library and archiving system

used by University of Aveiro. One of the key fea-

tures of SInBAD’s design is the emphasis placed on

integration with existing subsystems. SInBAD uses a

modular architecture (Almeida et al., 2006), (Fernan-

des et al., 2008) to provide access to heterogeneous

content (theses, research papers, audiovisual material,

posters,photos) to the members of the academic com-

munity. Different modules expose a coherent inter-

face to the outside world via web services, and each

module has its own web site. SInBAD also provides

a portal that allows search in all modules. Content re-

trieval is also possible via web services, provided that

one knows the correct identiﬁer for the content.

The modular architecture allows content to be dis-

tributed throughout the university network. In spite

of this apparent distribution, content is still located

in the same geographical area, thus being in danger

in case of, for example, natural disaster. Format ob-

solescence must also be taken into account: as digi-

tal container formats evolve, preserved content format

should also evolve, so that it never becomes obsolete

http://chronopolis.sdsc.edu/

SinBAD Portal

Data

Website

Web

Services

Data

(...)

Library Archive

Website

Web

Services

Authentication

Web Service

ID Manager

Web Service

Caterpillar

Web Service

e-ABC

Web Service

PACO

Web Service

ALEPH

Connection

Module

Other SystemsSInBAD Services

Figure 1: Generic SInBAD Architecture.

and thus rendered nearly useless (due to the lack of

appropriate decoders). In order to cope with these

perceived weaknesses the decision was made to in-

tegrate SInBAD with a long term digital preservation

national project, GRITO.

4.1 OAI-PMH

SInBAD implements the Open Archives Initiative

- Protocol for Metadata Harvesting (OAI-PMH)

(de Sompel and Lagoze, 2008). OAI-PMH is a pro-

tocol designed to provide an application-independent

metadata harvest infrastructure.

OAI-PMH requests are represented by HTTP re-

quests, and can take the form of POST or GET

methods. In SInBAD’s case we will be using the

GET method. In this method a request is com-

prised of a base URL, followed by a question mark

(?), followed by a list of arguments in the form of

key=value.Multiple arguments are separated by an

ampersand (&). Every request is required to have one

verb as argument, in order to specify the action that

should be executed. In SInBAD’s case the base URL

is http://sinbad.ua.pt/OAI/ (a test form is available in

the same address).

When a request is issued to a OAI-PMH compliant

repository a response will be generated in the form of

a XML encoded UTF-8 byte stream. The resulting

XML can then be parsed and used as an application

deems necessary.

One possible use for the OAI-PMH is the retrieval

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

108

of identiﬁers, that can be used to access content using

several methods exposed in SInBAD’s web services.

5 GRITO

GRITO is a Portuguese digital preservation project,

funded by FCT (GRID/GRI/81872/2006). It aims to

use data grids as a support for digital preservation.

In order to avoid investment in expensive resources

GRITO plans to leverage existing resources in re-

search grids (by extending them to allow their use for

digital preservation) while also creating a grid cluster

exclusively dedicated to digital preservation. The ﬁ-

nal goal of the project will be to integrate both types,

creating a low cost digital preservation grid that can

be used by public institutions.

The grid middleware that will be used is iRODS

developed by the San Diego Supercomputer Center

(SDSC). iRODS is a grid middleware that provides

management policies in the form of rules. In iRODS

management policies can be changed in run time (Ra-

jasekar et al., 2006), and its functionalities can be tai-

lored to speciﬁc needs. New rules can be created by

combining and creating microservices (small proce-

dures written in C programing language). It can also

function in a federation of grid clusters and present

collections contained in them as one, a trait that will

help GRITO integrate grids under the control of dif-

ferent institutions on a single preservation grid.

iRODS offers several means to interact with the

grid. Out of the box provides a set of command line

tools (itools) inspired by known UNIX commands

(like icp to copy ﬁles, or irm to remove ﬁles). In-

teraction with the grid can also be achieved by using

a PHP client API (Prods), a Java based API (Jargon

)

and on Linux systems collections can be mounted as

a regular folder with the use of a FUSE module.

This middleware was not specially designed to

handle some of the speciﬁc requirements that digi-

tal preservation scenarios impose, but since it is open

source it could be extended (Barateiro et al., 2008) to

accommodate such requirements.

6 INTEGRATING SINBAD AND

IRODS

Since SInBAD is a deployed production system it is

a requirement of the integration that as little changes

as possible should be made to it. This excludes any

https://www.irods.org/index.php/

http://www.sdsc.edu/srb/jargon/

possible integration scheme were SInBAD would be

changed, requiring the creation of a transparent digital

preservation system.

In order to place content from SInBAD into the

preservation grid it is possible to adopt a strategy

where no changes are made to SInBAD itself, since

SInBAD already exposes all the needed interfaces as

web services. In the future SInBAD must be able to

recover content from the grid. To achieve that goal

some modiﬁcations will have to be made, yet these

changes should be kept only to the essential for con-

tent recovery.

The use of the OAI-PMH allows us to obtain in-

formation about the content that was added to each

collection since a speciﬁc date (along with informa-

tion on how to retrieve it). We can then use the in-

formation retrieved with OAI-PMH on how to access

content to use SInBAD’s existing web services. These

web services allow us to retrieve the content stored in

the digital library (we must also retrieve any remain-

ing associated metadata) and place it into the grid,

thus achieving integration without disturbing the ex-

isting SInBAD infrastructure.

In this integration scheme iRODS with an ex-

tended service set (Barateiro et al., 2008) will be

responsible for the preservation of any content har-

vested from SInBAD. To harvest content from SIn-

BAD two approaches can be taken:

• Creation of an iRODS microservice.

• Creation of an Intermediary system.

The merits and drawbacks of each approach will

be discussed in the following sections.

6.1 iRODS Microservice

Creating an iRODS microservice (illustrated by Fig-

ure 2) is an option to achieve integration between

iRODS and SINBAD. iRODS already provides the

necessary tools to enable a rule to be executed peri-

odically, so periodic harvest of content can be consid-

ered a trivial task.

The integration process would become a two mi-

croservices rule:

1. A microservice would contact SInBAD using the

OAI-PMH protocol, generating a list of targets to

be retrieved.

2. A microservice would take as input the list of tar-

gets and use SInBAD’s web services to retrieve

and store content into the grid.

Since iRODS microservices must be written in C

we consider that ideal libraries to deal with these steps

SINBAD DIGITAL LIBRARY PRESERVATION USING IRODS DATA GRID

109

SInBAD Portal

Website

Web

Services

(...)

Library Archive

Website

Web

Services

SInBAD Services / Other Services

iRODS

Module

Preservation

Grid

Figure 2: SInBAD/iRODS integration using a microservice.

are libcurl

, expat

and gsoap

. All of these libraries

allow us to develop the needed microservices with

minimal effort, by providing multiple ﬁle transfer pro-

tocols, XML parsing and webservices support respec-

tively.

The advantage of this approach would be the ra-

tional use of resources. The iRODS server (that is

assumed to be always accessible) is an underused re-

source on a digital preservation scenario. By using

a rule to periodically harvest SInBAD’s content we

could use some otherwise unused processing cycles,

releasing SInBAD (a system that is accessible to the

public) of that task, and since content would be har-

vested directly from SInBAD to the preservation grid,

network trafﬁc would be reduced.

The drawback of the approach is the tight integra-

tion with iRODS. By creating an iRODS module we

are creating speciﬁc code that would be hard to reuse

and maintain in case of major platform change (ex-

tensive modiﬁcations in SInBAD or grid middleware

change). This tight integration would mean that in the

future content recovery would be made by executing

a new set of rules in the iRODS engine, that would

themselves invoke the necessary services in SInBAD.

6.2 Intermediary System

Creating an intermediary system to serve as proxy be-

tween SInBAD and iRODS is another option. This

approach (illustrated by Figure 3) follows the current

http://curl.haxx.se/libcurl/

http://expat.sourceforge.net/

http://www.cs.fsu.edu/ engelen/soap.html

subsystems driven SInBAD philosophy, and would

interact with SInBAD as an back-ofﬁce administra-

tion tool. It would be a modular system, allowing the

use of other preservation technologies like, for exam-

ple the use of a peer-to-peer based preservation sys-

tem in addition to the iRODS based system.

This intermediary system would follow a three

step approach:

1. Contact SInBAD using OAI-PMH and discover

all the content added since the last contact.

2. Fetching all the new content and corresponding

metadata.

3. Submit content/metadata pairs to the iRODS grid.

Each of these steps can be seen as a module, the

ﬁrst step as a module that provides access to the OAI-

PMH protocol, the second step a module that provides

access to SInBAD’s digital contents and the third step

as a module that allows the use of the iRODS infras-

tructure. Although the majority of SInBAD’s subsys-

tems are written in .net framework, all the resources

needed to integrate SInBAD with GRITO can be ac-

cessed in a platform neutral way due to the use of

web services. This allows us to write this intermedi-

ary system in Java in order to use the provided Jargon

API, therefore avoiding the use of the command line

tools. The Jargon API provides the necessary meth-

ods to place content in the grid, to associate metadata

to content and allows the creation of queries (based on

the available metadata) that can be used to selectively

retrieve content from the grid.

To avoid duplication of management policies a

rule could be created in iRODS that when executed

would trigger the preservation process, by invoking

a web service of the intermediary system. This ap-

proach assumes that all management policies (con-

tent harvest, format migration) will be placed on the

iRODS middleware.

The advantage of this approach would be ﬂexibil-

ity. In the event of a grid platform migration only

the submission mechanism would need to be changed,

and in the event of a major SInBAD change no mi-

croservices would have to be changed on the iRODS

side. This ﬂexibility extends into the future, since this

system can be seen as an administration tool, it can

be extended to manage content recovery (detailed in

section 8).

The drawback of this approach would be resource

usage. The creation of a proxy system would generate

more network trafﬁc than the iRODS module, since

content would be retrieved to this intermediary system

and only after submitted to the grid (assuming that

this application is running on a different machine than

the iRODS rule server). In a digital library scenario,

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

110

SInBAD Portal

Website

Web

Services

(...)

Library Archive

Website

Web

Services

Preservation

Grid

iRODS

SInBAD Services / Other Services

(...)

P2P

Network

P2P

Middleware

Preservation System

Figure 3: SInBAD/iRODS integration using an intermedi-

ary system.

this drawback can be made less relevant by scheduling

content harvest to periods of low network activity.

7 CONCLUSIONS

Integration between SInBAD and iRODS will be an

interesting addition to the SInBAD architecture Table

1 presents a comparison between integration options.

Since we wish to promote ﬂexibility in the adopted

solution, the option of creating an intermediary sys-

tem is the best way to integrate SInBAD with IRODS.

In order to retrieve content from the grid both alter-

natives require the same changes in SInBAD, but the

intermediary system follows more closely the current

SInBAD’s philosophy. We consider that the possibil-

ity of integration with different preservation mecha-

nisms (such as peer-to-peer networks, or content con-

version services) that the intermediary system pro-

vides is the key factor in this decision.

8 FUTURE WORK

After this analysis, active development of a working

prototype of the intermediary system has begun. Plac-

ing content into the preservation grid is only a step for

a complete preservation scenario. For the complete

scenario we must be able to recover content that was

placed in the grid, and this will lead to the creation of

a new recovery web service within SInBAD, because

the existing web services are not recovery friendly.

The current behaviour of SInBAD is to create a

Table 1: Comparison between iRODS microservice and an

Intermediary system.

iRODS

Microservice

Intermediary

system

Programming

language

multiple

(C/Java)

Resource usage low moderate

Integration

with SInBAD

tight loose

Integration with digital

preservation system

tight loose

Ability to deal with

changes in SInBAD

moderate moderate

Ability to deal with

changes in manage-

ment policies

high high

Ability to deal with

changes of digital

preservation system

none high

Perceived

maintenance effort

moderate low

new identiﬁer each time content is added to a repos-

itory. This behaviour does not allow the use of the

existing methods to recover content using the preser-

vation system. New methods that allow authorised

users to repair compromised content with the help of

the content stored in the preservation system must be

created. These methods can be added to existing web

services, or grouped in a new web service. As was

mentioned before SInBAD is a production system, so

the preferred approach will be to group all the needed

methods in a new web service in order not to disturb

the rest of the system.

ACKNOWLEDGEMENTS

This work was funded in part by the Portuguese

Foundation for Science and Technology grants

SFRH/BD/23976/2005 and GRID/GRI/81872/2006.

REFERENCES

(2002). Reference Model for an Open Archival Informa-

tion System (OAIS), Blue Book, Issue 1. CCSDS -

Consultative Committee for Space Data Systems.

http://public.ccsds.org/publications/archive/650x0b1.pdf.

Almeida, P., Fernandes, M., Alho, M., Martins, J. A.,

and Pinto, J. S. (2006). Sinbad - a digital library

to aggregate multimedia documents. In AICT-ICIW

’06: Proceedings of the Advanced Int’l Conference on

Telecommunications and Int’l Conference on Internet

and Web Applications and Services, page 173, Wash-

ington, DC, USA. IEEE Computer Society.

SINBAD DIGITAL LIBRARY PRESERVATION USING IRODS DATA GRID

111

Barateiro, J., Antunes, G., Cabral, M., Borbinha, J. L., and

Rodrigues, R. (2008). Using a grid for digital preser-

vation. In ICADL, pages 225–235.

de Sompel, H. V. and Lagoze, C. (2008). The open

archives initiative protocol for metadata harvesting.

http://www.openarchives.org/OAI/ openarchivespro-

tocol.html.

Fernandes, M., Almeida, P., Martins, J., and Pinto, J.

(2008). A digital library framework for university of

aveiro. In Borwein, J., Rocha, E., and Rodrigues, J.,

editors, Communicating Mathematics in the Digital

Era, pages 111–123. A K Peters.

Ferreira, M. (2006). Introduc¸

a preservac¸

ao digital –

Conceitos, estrat

egias e actuais consensos. Univer-

sidade do Minho, Escola de Engenharia.

Hedges, M., Blanke, T., and Hasan, A. (2009). Rule-based

curation and preservation of data: A data grid ap-

proach using irods. Future Generation Computer Sys-

tems, 25(4):446 – 452.

Hunter, J. and Choudhury, S. (2006). Panic: an integrated

approach to the preservation of composite digital ob-

jects using semantic web services. Int. J. Digit. Libr.,

6(2):174–183.

Kenney, A. R., McGovern, N. Y., Entlich,

R., Kehoe, W. R., and Olsen, E.

(2003). Digital preservation management.

http://www.library.cornell.edu/iris/tutorial/dpm/.

Moore, R., Berman, F., Middleton, D., Schottlaender, B.,

JaJa, J., and Rajasekar, A. (2005a). Chronopolis -

federated digital preservation across time and space.

pages 171–176.

Moore, R., Rajasekar, A., and Wan, M. (2005b). Data grids,

digital libraries, and persistent archives: An integrated

approach to sharing, publishing, and archiving data.

Proceedings of the IEEE, 93(3):578–588.

Rajasekar, A., Wan, M., Moore, R., and Schroeder,

W. (2006). A prototype rule-based distributed

data management system. In HPDC workshop on

”Next Generation Distributed Data Management”.

https://www.irods.org/index.php/Publications.

Webb, C. (2003). Guidelines for the Preservation of Dig-

ital Heritage. United Nations Educational Scientiﬁc

and Cultural Organization - Information Society Divi-

sion. http://unesdoc.unesco.org/images/0013/001300/

130071e.pdf.

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

112
