TRAINING OF SPEAKER-CLUSTERED ACOUSTIC MODELS FOR

USE IN REAL-TIME RECOGNIZERS

Jan Van

ek, Josef V. Psutka, Jan Zelinka, Ale

s Pra

ak and Josef Psutka

Department of Cybernetics, West Bohemia University, Pilsen, Czech Republic

Keywords:

Acoustic models training, discriminative training, clustering, gender-dependent models.

Abstract:

The paper deals with training of speaker-clustered acoustic models. Various training techniques - Maximum

Likelihood, Discriminative Training and two adaptation based on the MAP and Discriminative MAP were

tested in order to minimize an impact of speaker changes to the correct function of the recognizer when a

response of the automatic cluster detector is delayed or incorrect. Such situation is very frequent e.g. in on-

line subtitling of TV discussions (Parliament meetings). In our experiments the best cluster-dependent training

procedure was discriminative adaptation which provided the best trade-off between recognition results with

correct and non-correct cluster detector information.

1 INTRODUCTION

One of the most important problems of speaker-

independent LVCSR systems is their worse ability

to get over the inter-speaker variability. This prob-

lem becomes serious if the recognizer works in real

time and in tasks where speakers change frequently.

Such task is e.g. the on-line closed captioning of

Parliament meetings - the task which is experimen-

tally tested by the TV since 11/2008 (experimental

broadcasting). One of the ways how to handle this

problem is the incremental speaker adaptation or us-

ing gender-dependent acoustic models or even models

obtained from more detailed clustered voices. This

paper describes our experiments with unsupervised

speaker clustering and following discriminative train-

ing of various initial acoustic models. The goal of

the work is to minimize an impact of delayed or in-

correct response of cluster detector to the changes of

speakers. Such situation is very frequent just in on-

line subtitling of TV discussions. All the discussed

methods came from frame-based discriminative train-

ing (DT) that seeks such solution (such acoustic mod-

els) which yield on one hand favorable quality (in-

creased accuracy) of discriminative training, on the

other hand obtained DT models should not be overly

sensitive to imperfect function of a cluster-detector.

Let us mention that the clustering algorithm is de-

scribed in Section 2, the Discriminative Training or

Frame-Discriminative training are described in Sec-

tion 3. The incorporating DT to a cluster-dependent

training procedure is discussed in Section 4.4 and re-

sults of completed experiments are described in Sec-

tion 5.

2 AUTOMATIC CLUSTERING

Training of gender-dependent models is the most pop-

ular method how to split training data into two more

acoustically homogeneous classes (Stolcke, 2000).

But for particular corpora, it should be veriﬁed that

the gender-based clusters are the optimal way, i.e. the

criterion L =

∏

P(u|M(u)), where u is an utterance in

a corpus and M(u) is a relevant acoustic model of its

reference transcription, is maximal. Because of some

male/female ”mishmash” voices contained in corpora

we proposed an unsupervised clustering algorithm

which can reclassify training voices into more acous-

tically homogeneous classes. The clustering proce-

dure can start from gender-dependent splitting and it

ﬁnishes in somewhat reﬁne distribution which yields

higher accuracy score (Zelinka, 2009). In addition,

we can use the algorithm to ﬁnd out more than only

two acoustically homogeneous clusters. Thereafter,

two ways of clustering procedure are possible. The

ﬁrst approach is just to split randomly initial training

data into n clusters and run the algorithm. The second

way is to prepare clusters hierarchically. It means to

split data via the algorithm into two clusters and after

131

Vanek J., V. Psutka J., Pražák A. and Psutka J. (2009).

TRAINING OF SPEAKER-CLUSTERED ACOUSTIC MODELS FOR USE IN REAL-TIME RECOGNIZERS.

In Proceedings of the International Conference on Signal Processing and Multimedia Applications, pages 131-135

DOI: 10.5220/0002262001310135

 SciTePress

that to continue in the same way with the both sub-

clusters. The number of ﬁnal clusters can naturally

be the power of two only. This way produces more

size-balanced clusters and it does not need as much

computation time as the ﬁrst direct way. But the ﬁnal

clusters do not need to be so compact.

2.1 Algorithm Description

The algorithm is based on similar criterion like the

main training algorithm – maximize likelihood L

of the training data with reference transcription and

models. The result of the algorithm is a set of trained

acoustic models and a set of lists where all utter-

ances are assigned to exactly one cluster. Number of

clusters (classes) n has to be set in advance and for

gender-dependent modeling or for hierarchical split-

ting is naturally n = 2. The process is modiﬁcation of

the Expectation-Maximization (EM) algorithm. The

unmodiﬁed EM algorithm is applied for estimation of

acoustic model parameters. The clustering algorithm

goes as follows:

1. Random splitting of training utterances into n

clusters. The clusters should have similar size. In

case of two initial classes there is reasonable to

start the algorithm from gender-based clusters.

2. Train (retrain) acoustic models for all clusters.

3. Posterior probability density P(u|M) of each

utterance u with its reference transcription is

computed for all models M (so-called forced-

alignment).

4. Each utterance is assorted to the cluster with the

maximal evaluation P(u|M) computed in the pre-

vious step:

t+1

(u) = arg max

P(u|M). (1)

5. If clusters changed than go back to step 2. Other-

wise the algorithm is terminated.

Optimality of results of the clustering algorithm is

not guaranteed. Besides, the algorithm depends on

initial clustering. Furthermore, even convergence of

the algorithm is not guaranteed, because there can be

a few utterances which are reassigned all the time.

Therefore, it is suitable to apply a little threshold

as a ﬁnal stopping condition or to use ﬁxed number

of iterations. Thus, if we would like to verify that

the gender-dependent splitting is ”optimal” so we use

this male/female distribution as initial and start algo-

rithm. The intention is to complete the algorithm with

more reﬁned clusters, in which ”masculine” female

and ”feminine” male voices and also errors in man-

ual male/female annotations will be reclassiﬁed. This

should improve a performance of the recognizer.

3 DISCRIMINATIVE TRAINING

Discriminative training (DT) was developed in a re-

cent decade and provides better recognition results

than classical training based on Maximum Likelihood

criterion (ML) (Povey, 2003; McDermott, 2006). In

principle, ML based training is a machine learn-

ing method from positive examples only. DT on

the contrary uses both positive and negative exam-

ples in learning and can be based on various ob-

jective functions, e.g. Maximum Mutual Informa-

tion (MMI) (Bahl at al., 1986), Minimum Clas-

siﬁcation Error (MCE) (McDermott, 2006), Mini-

mum Word/Phone Error (MWE/MPE) (Povey, 2003).

Most of them require generation of lattices or many-

hypotheses recognition run with appropriate language

model. The lattices generation is highly time con-

suming. Furthermore, these methods require good

correspondence between training and testing dictio-

nary and language model. If the correspondence is

weak, e.g. there are many words which are only in

the test dictionary then the results of these methods

are not good. In this case, we can employ Frame-

Discriminative training, which is independent on a

used dictionary and language model (Kapadia, 1998).

In addition, this approach is much faster. In lat-

tice based method with the MMI objective function

the training algorithm seeks to maximize the poste-

rior probability of the correct utterance given the used

models (Bahl at al., 1986):

MMI

(λ) =

∑

r=1

log

)

P(s

)

∑

|s)

P(s)

, (2)

where λ represents the acoustic model parameters, O

is the training utterance feature set, s

is the correct

transcription for the r’th utterance, κ is the acoustic

scale which is used to amply confusions and here-

with increases the test-set performance. P(s) is a

language model part. Optimization of the MMI ob-

jective function uses Extended Baum-Welch update

equations and it requires two sets of statistics. The

ﬁrst set, corresponding to the numerator (num) of the

equation (2), is the correct transcription. The sec-

ond one corresponds to the denominator (den) and

it is a recognition/lattice model containing all possi-

ble words. An accumulation of statistics is done by

forward-backward algorithm on reference transcrip-

tions (numerator) as well as generated lattices (de-

nominator). The Gaussian means and variances are

updated as follows (Kapadia, 1998):

ˆµ

num

(O) − Θ

den

(O) + D

num

− γ

den

+ D

(3)

SIGMAP 2009 - International Conference on Signal Processing and Multimedia Applications

132

num

) −Θ

den

) + D

(σ

+ µ

)

num

− γ

den

+ D

− µ

(4)

where j and m are the HMM-state and Gaussian in-

dex, respectively, γ

is the accumulated occupancy

of the Gaussian, Θ

(O) and Θ

) are a posteriori

probability weighted by the ﬁrst and the second order

accumulated statistics, respectively. The Gaussian-

speciﬁc stabilization constants D

are set to maxi-

mum of (i) double of the smallest value which ensures

positive estimated variances, and (ii) value Eγ

den

where constant E determines the stability/learning-

rate and it is a compromise between stability and

number of iteration which is needed for well-trained

models (Povey at al., 2001). In Frame-Discriminative

case, the denominator lattices generation and its

forward-backward processing is not needed. The de-

nominator posterior probability is calculated from a

set of all states in HMM. This very general denomi-

nator model leads to good generalization to test data.

Furthermore, statistics of only few major Gaussians

are needed to be updated and its probability has to be

exactly calculated in each time. It can tend to very

time-efﬁcient algorithm (Povey at al., 1999). Opti-

mization of the model parameters uses the same two

equations (3) and (4), the computation of Θ

den

(O) and

den

is modiﬁed only. In case that only limited data are

available, maximum a posteriori probability method

(MAP) (Gauvain at al., 1994) can be used even for

discriminative training (Povey at al., 2003). It works

in the same manner as the standard MAP, only the in-

put HMM has to be discriminatively trained with the

same objective function. For discriminative adapta-

tion it is strongly recommended to use I-smoothing

method to boost stability of new estimates (Povey

at al., 2002).

4 EXPERIMENTS DESCRIPTION

4.1 Train Data and Acoustic Processing

The corpus for training of the acoustic models con-

tains 100 hours of parliament speech records. All

data were manually annotated. The digitization of

an analogue signal is provided at 44.1 kHz sample

rate and 16-bit resolution format. The aim of the

front-end processor is to convert continuous speech

into a sequence of feature vectors. Several tests were

performed in order to determine the best parame-

terization settings of the acoustic data (see (Psutka,

2001) for methodology). The best recognition results

were achieved using PLP parameterization (Herman-

sky, 1990) with 27 ﬁlters and 12 PLP cepstral coef-

ﬁcients with both delta and delta-delta sub-features

(see (Psutka, 2007) for details). Therefore one fea-

ture vector contains 36 coefﬁcients. Feature vectors

are computed each 10 milliseconds (100 frames per

second).

4.2 Acoustic Model

The individual basic speech unit in all our experi-

ments was represented by a three-state HMM with

a continuous output probability density function as-

signed to each state. As the number of triphones is too

large, phonetic decision trees were used to tie states

of triphones. Several experiments were performed to

determine the best recognition results according to the

number of clustered states and also to the number of

mixtures. In all presented experiments, we used 8

mixtures of multivariate Gaussians for each of 5385

states. The baseline acoustic model was speaker and

gender independent (there were no additional infor-

mation about speaker available).

4.3 Training Data Clustering

The whole training corpus was split into several (two

or more) acoustically homogeneous classes via algo-

rithm introduced in the Subsection 2. In all cases

the initial splitting was achieved randomly due to

no additional speaker/sentence information available.

The whole set of sentences (46k) was split into four

classes in two different ways. Firstly, we used hier-

archical division method. It means that we divided

the training set into two classes (2Cl) and than each

class was split again into another two classes (ﬁnally

we had four clusters 4Cl

). Secondly, we split the

whole training set into four classes directly (4Cl

All splittings were done using algorithm presented

above. Examples of shifts between clusters (sen-

tences, which were moved from the one cluster to an-

other) for hierarchical division can be seen in Table 1.

Table 1: Example of the shift between clusters.

Step number of sentences [%]

(i) Cl(x)

i−1

→ Cl(x)

Cl(x)

i−1

→ Cl(y)

1 83.26 16.73

2 87.30 12.70

3 92.05 7.95

4 97.10 2.90

5 98.44 1.56

6 98.81 1.18

7 99.29 0.71

8 99.32 0.67

TRAINING OF SPEAKER-CLUSTERED ACOUSTIC MODELS FOR USE IN REAL-TIME RECOGNIZERS

133

Where Cl(x)

i−1

→ Cl(x)

means no-shift between

cluster x and Cl(x)

i−1

→ Cl(y)

means shift between

cluster x to any other cluster y (y 6= x) in two following

iteration steps (i − 1,i)

4.4 Discriminative Training of

Clustered Models

Our next attention was to explore a suitable way of a

discriminative training procedure for clustered acous-

tic models. This procedure should hold favorable

characteristics of DT models on one hand, but on the

other hand developed acoustic models should not be

overly sensitive to imperfect function of a cluster-

detector, e.g. a negative impact of wrong-selected

acoustic model. Such situation could happen for in-

stance in real-time recognition tasks in case that the

reaction of the cluster-detector to a change of speaker

is not immediate and/or the detector evaluates the

change incorrectly. We performed a set of experi-

ments in which an impact of speaker-independent and

speaker-clustered acoustic models both in combina-

tion with maximum likelihood and frame-based dis-

criminative training were tested. In case when only

single acoustic model is trained, the situation is sim-

ple. The model is trained from all data under ML ap-

proach or some DT objective function. Nevertheless

some parameters could be tuned, for example a num-

ber of tied-states and a number of Gaussians per state.

In DT case, the number of tuned parameters is higher

but it is still an optimization task. In our experiments

corresponding models are marked as SC (Single Clus-

ter), precisely SC ML and SC DT for ML and DT, re-

spectively. The DT model was developed from SC via

two discriminative training iterations. The E constant

was set to one. Furthermore, the I-smoothing was ap-

plied and smoothing constant τ

was set to 100. If the

training data are split into more than one cluster, the

situation is a bit complicated because of more training

strategies that we have in our disposal. Naturally the

same training procedure can be used for each part of

data. This would be concluded by a set of indepen-

dent models. For a real application such approach is

not a good option because ﬁnal models have differ-

ent topology which is generated during a tied-states

clustering procedure and therefore obtained models

cannot be simply switched/replaced in the recognizer.

The better strategy is to split the training procedure

just after state clustering. In our experiments such

model sets are marked with sufﬁx ML and DT for

ML and DT, respectively. Secondly, the ML or DT

adaptation can be applied. In our experiments the

adaptation starts from SC ML or SC DT and two it-

erations were done via MAP or DT-MAP with pa-

rameter τ equal to 25. Two models developed by

these techniques are marked with sufﬁx ML

Adapt

and

Adapt

4.5 Tests Description

The test set consists of 100 minutes of speech from 10

male and 10 female speakers (5 minutes from each)

which were not included in training data. In all recog-

nition experiments a language model based on zero-

grams was applied in order to judge better a quality

of developed acoustic models. In all experiments the

perplexity of the task was 3828, there were no OOV

words.

5 RESULTS

In all our experiments the recognition accuracy was

evaluated. Obtained results are shown in Table 2,

where SC ML and SC DT were trained from the

whole training data via Maximum Likelihood and

Discriminative Training, respectively. In the second

part of Table two recognition results for each training

procedure and clustering method are shown. The best

recognition result was found for each utterance across

appropriate acoustic models (the same level of clus-

tering and the same training procedure). The worst

result was found by analogical way. The difference

between corresponding results illustrates the drop of

recognition accuracy when the cluster-detector fails.

As was described in Section 4.3, 2Cl is an acoustic

model with two clusters. 4Cl

and 4Cl

are the

four-clusters acoustic models which were obtained

by hierarchical and direct clustering, respectively.

We achieved a signiﬁcant gain in terms of recogni-

tion accuracy for all cluster-dependent acoustic mod-

els against standard (single-cluster) acoustic models

(SC ML and SC DT ). The two-clusters acoustic mod-

els gave only slightly better results than single-cluster

models. But in the four-clusters case the achieved im-

provement is signiﬁcant. The comparison between

the hierarchical (4Cl

) and direct (4Cl

) cluster-

ing method showed that the direct method gave clus-

ters whose corresponding acoustic models yield bet-

ter recognition results. The maximum gain (improve-

ment 5.29% absolutely for SC ML) was achieved for

4Cl

Adapt

(Discriminatively trained directly clus-

tered four-clusters acoustic models). In this case, the

accuracy 76.66% was obtained if the cluster-detector

works ideally. But on the other hand the recogni-

tion results are considerably worse when the clus-

ter information is not correct. From this point of

view the best tradeoff between recognition results

SIGMAP 2009 - International Conference on Signal Processing and Multimedia Applications

134

Table 2: The results of recognition experiments.

Acc [%]

SC ML 71.37

SC DT 73.60

Cluster identiﬁcation best worst

2Cl ML 71.76 66.65

2Cl DT 74.01 69.29

2Cl ML

Adapt

71.64 67.53

2Cl DT

Adapt

74.03 71.36

4Cl

ML 72.62 52.14

4Cl

DT 75.17 55.83

4Cl

Adapt

72.83 62.78

4Cl

Adapt

74.39 69.48

4Cl

ML 74.69 54.18

4Cl

DT 74.01 56.69

4Cl

Adapt

74.65 59.03

4Cl

Adapt

76.66 67.28

of the cluster-based acoustic model with correct and

non-correct cluster information are 2Cl DT

Adapt

the two-clusters case and 4Cl

Adapt

in the four-

clusters case. In the two-clusters case the recognition

results are slightly worse (improvement 2.66% abso-

lutely for SC ML) than for the four-clusters approach.

But if the cluster detector information is wrong, the

recognition results were almost the same in compari-

son with the original SC ML acoustic model.

6 CONCLUSIONS

The goal of our work was to build the cluster-

dependent acoustic model which yields higher recog-

nition accuracy than non-clustered model and which

is more robust when a response of the automatic

cluster-detector is delayed or incorrect. This prob-

lem becomes serious if the recognizer works in

real-time and in tasks where speakers change fre-

quently. We tested several methods based on a

combination of unsupervised clustered training data

and discriminative/non-discriminative training proce-

dures. If the cluster-detector works ”almost” correctly

then the best cluster-dependent training procedure is

4Cl

Adapt

. But the question is what results we

obtain if the splitting process continues, e.g. for lev-

els 8, 16 ... In our next research we would like to

concentrate on this problem and also on the question

how to build a quick cluster-detector which will work

correctly and really in real-time.

ACKNOWLEDGEMENTS

The work was supported by the Ministry of Education

of the Czech Republic, project no. M

SMT 2C06020.

REFERENCES

Povey, D. at al. (1999). Frame discrimination training

for hmms for large vocabulary speechrecognition. In

ICASSP.

Povey, D. at al. (2001). Improved discriminative train-

ing techniques for large vocabulary continuous speech

recognition. In ICASSP.

Povey, D. at al. (2002). Minimum phone error and i-

smoothing for improved discriminative training. In

ICASSP.

Povey, D. at al. (2003). Mmi-map and mpe-map for acoustic

model adaptation. In EUROSPEECH.

Bahl, L.R. at al. (1986). Maximum mutual information esti-

mation of hidden markov model parameters for speech

recognition. In ICASSP.

Gauvain, L. at al. (1994). Maximum a-posteriori estima-

tion for multivariate gaussian mixture observations of

markov chains. In IEEE Transactions SAP.

Hermansky, H. (1990). Perceptual linear predictive (plp)

analysis of speech. Acoustic. Soc., Am.87.

Kapadia, S. (1998). Discriminative Training of Hidden

Markov Models. PhD thesis, Cambridge University,

Department of Engineering.

McDermott, E. (2006). Discriminative training for large

vocabulary speech recognition using minimum classi-

ﬁcation error. IEEE Trans. Speech and Audio Process-

ing, Vol. 14. No. 2.

Povey, D. (2003). Discriminative Training for Large Vo-

cabulary Speech Recognition. PhD thesis, Cambridge

University, Department of Engineering.

Zelinka, J. (2009) Audio-Visual Speech Recognition. PhD

thesis, West Bohemia University, Department of Cy-

bernetics.

Psutka, J. (2001) Comparison of MFCC and PLP Pa-

rameterization in the Speaker Independent Continu-

ous Speech Recognition Task. In EUROSPEECH.

Psutka, J. (2007) Robust PLP-Based Parameterization for

ASR Systems. In SPECOM.

Stolcke, A. (2000). The sri march 2000 hub-5 conversa-

tional speech transcription system. In NIST Speech

Transcription Workshop. College Park, MD.

TRAINING OF SPEAKER-CLUSTERED ACOUSTIC MODELS FOR USE IN REAL-TIME RECOGNIZERS

135
